The SNCV1 non contact voltage tester
senses live voltage without touching
the object being tested so you know
whether a wire is HOT or NOT.
Features
Senses 24VAC to 440VAC.
LED & buzzer indicators with analog feel.
Differentiates between hot and neutral.
More pocket tools from Fieldpiece
Model: SNCV1 H26-504
Specifications
Range: 24VAC to 440VAC.
Operating environment: 14 to 131°F
Safety: UL 1244, MAX 600VAC,
CAT III, UL&cULlisted
Battery: LR44 x 2 (included)
Operator’s Guide
TEST ON A
KNOWN LIVE
WIRE BEFORE
USING.
Voltage Test
1. Place the probe tip of
SNCV1 close (~1/4”) to object
being tested for voltage.
2. If a voltage above 24VAC is
detected, the LED will light and
the buzzer will sound. The indicators
get louder and brighter as the voltage
rises or as the probe tip becomes
closer to the source fo voltage.
Find a Break in a Power Cable
Scan power cable to determine the
point where voltage is lost.
