OPERATING
MANUAL
EN
SMART MODULE
(FGS-214)
DOUBLE SMART MODULE
(FGS-224)
v1.0
Table of contents
1: Important safety information 4
2: Description and features 5
2.1: Description 5
2.2: Main features 5
3: Specications 6
4: Installation 7
4.1: Before installation 7
4.2: Electrical connection 8
5: Adding to Z-Wave network 9
5.1: Adding manually 9
5.2: Adding using SmartStart 9
3
6: Removing from Z-Wave network 10
7: Operating the device 11
7.1: Controlling channels with inputs 11
7.2: Visual indications 11
7.3: Menu 12
7.4: Resetting to factory defaults 12
8: Z-Wave range test 13
9: Activating scenes 14
10: Conguration 15
10.1: Associations 15
10.2: Advanced parameters 17
11: Z-Wave specication 27
12: Regulations 30
4
1: Important safety information
Read this manual before attempting to install the device!
Failure to observe recommendations included in this manual
!
may be dangerous or cause a violation of the law. The manufacturer, Fibar Group S.A. will not be held responsible for any loss or
damage resulting from not following the instructions of operating
manual.
DANGER OF ELECTROCUTION!
The device is designed to control other electrical devices and
operate in their housings. Faulty connection or use may result
in re or electric shock.
All works on the device may be performed only by a qualied
and licensed electrician. Observe national regulations.
Even when the device is turned o, voltage may be present at
its terminals. Any maintenance introducing changes into the
conguration of connections or the load must be always performed
with disabled fuse or power supply.
To avoid risk of electrical shock, do not operate the device with
wet or moist hands.
Do not modify!
Do not modify this device in any way not included in this
!
manual.
Other devices
The manufacturer, Fibar Group S.A. will not be held responsi-
!
ble for any damage or loss of warranty privileges for other connected devices if the connection is not compliant with their
manuals.
This product is intended for indoor use only in dry locations.
Do not use in damp or wet locations, near a bathtub, sink,
!
shower, swimming pool, or anywhere else where water or
moisture are present.
Not a toy!
This product is not a toy. Keep away from children and
!
animals!
Important safety InformatIon
2: Description and features
2.1: Description
The remotely operated FIBARO Smart Module and Double Smart
Module are designed to turn electrical devices or circuits on and o.
Smart Module allows to control one device or circuit and the Double
Smart Module allows to control two devices or circuits.
The compact size of the device allows for the product to be installed
in the housings of other devices. The devices can be controlled either
via the Z-Wave™ network or with buttons connected directly to them.
2.2: Main features
• Works with various types of switches and buttons.
• Supports Z-Wave network Security Modes: S0 with AES-128 encryption and S2 Authenticated with PRNG-based encryption.
5
• Works as a Z-Wave signal repeater (all non-battery operated devices within the network will act as repeaters to increase reliability of the network).
• May be used with all devices certied with the Z-Wave Plus™ certicate and should be compatible with such devices produced by
other manufacturers.
The device is a Security Enabled Z-Wave Plus product
i
and a Security Enabled Z-Wave Controller must be
used in order to fully utilize the product.
DescrIptIon anD features
6
3: Specications
Power supply 100-240V~ 50/60Hz or 24-30V
Rated load current Smart Module (FGS-214):
6.5A
Double Smart Module (FGS-224):
6A per one channel
9.5A total
Compatible load types resistive or incandescent only
Active element micro-gap relay μ
Maximum length of wires 3 meters
Recommended wire
cross-section area
Operating temperature 0–35°C
Ambient humidity 0–95% RH without condensation
Radio protocol Z-Wave (500 series chip)
Radio frequency band 868.0–868.6MHz; 869.7–870.0MHz
Max. transmitting power +5dBm
Range up to 50m outdoors
Dimensions
(Height x Width x Depth)
Classication of installation and use
Mode of operation Type 1.C Action
Pollution degree 2
Software class Class A
0.2–2.0mm2 (24–14 AWG)
(depending on load current)
up to 40m indoors
(depending on terrain and building
structure)
42.5 x 38.25 x 20.3 mm
Automatic electrical control for use in
equipment for household or similar
use
specIfIcatIons
Protection against electric
shock class
Compliance with EU
directives
Radio frequency of individual device must be same as
i
your Z-Wave controller. Check information on the box
or consult your dealer if you are not sure.
Class 0
2011/65/EU
2015/863
2014/53/EU
4: Installation
4.1: Before installation
Connecting the device in a manner inconsistent with this
!
manual may cause risk to health, life or material damage.
• Do not power the device before fully assembling it in the protected environment,
• Check the operating/maintenance manual of the device you want
to control to make sure the connection is safe and allowed,
• Connect only in accordance with the diagram,
• Always use the same power source for L and IN terminals,
• Do not connect devices which are not compliant with the specication or relevant safety standards,
7
• Do not install the device in metal boxes or on metal surfaces for
best radio performance.
Notes for diagrams:
S1 – terminal for 1st button
S2 – terminal for 2nd button
Q/Q1 – output terminal of the 1st channel
Q2 – output terminal of the 2nd channel
IN – input terminal for both channels
L – terminal for live wire
N – terminal for neutral wire
B – maintenance button
1 – device/system housing
2 – electrical device
InstallatIon
8
1
2
1
2
4.2: Electrical connection
1. Switch o the mains voltage (disable the fuse) or disable the
power supply.
2. Connect with one of the diagrams below:
100-240V AC
24-30V DC
NS1 S2
L
Q
B
IN
SMART MODULE
FGS-214
Diagram 1: Example connection of Smart Module
100-240V AC
24-30V DC
NS1 S2
L
Q2
B
DOUBLE
SMART MODULE
FGS-224
INQ1
Diagram 2: Example connection of Double Smart Module
3. Verify correctness of connection.
4. Tighten the terminal screws using PH1 screwdriver.
5. If the device fully assembled, switch on the mains voltage or
enable the power supply.
6. The LED light means the device is powered.
7. Add the device to the Z-Wave network (see the next chapter).
InstallatIon
5: Adding to Z-Wave network
Adding (Inclusion) – Z-Wave device learning mode, allowing to add
the device to existing Z-Wave network.
5.1: Adding manually
To add the device to the Z-Wave network manually:
1. Power the device.
2. Set the main controller in (Security/non-Security Mode) add mode
(see the controller’s manual).
3. Quickly, three times click button connected to S1/S2 or the
maintenance button.
4. LED will start blinking yellow, wait for the adding process to end.
5. If you are adding in Security S2 Authenticated, input the underlined
part of the DSK (label on the bottom of the box).
9
6. Adding result will be conrmed by the Z-Wave controller’s message
and the LED:
• Green – successful (non-secure, S0, S2 non-authenticated),
• Magenta – successful (Security S2 Authenticated),
• Red – not successful.
5.2: Adding using SmartStart
SmartStart enabled products can be added into a Z-Wave
network by scanning the Z-Wave QR Code present on the
product with a controller providing SmartStart inclusion.
SmartStart product will be added automatically within 10 minutes of
being switched on in the network range.
To add the device to the Z-Wave network using SmartStart:
1. To use SmartStart your controller needs to support Security S2
(see the controller’s manual).
2. Enter the full DSK string code to your controller. If your controller
is capable of QR scanning, scan the QR code placed on the box or
the device label.
3. Power the device.
4. Wait for the adding process to start (up to few minutes), which is
signalled with yellow LED blinking.
aDDIng to Z-Wave netWork
10
5. Adding result will be conrmed by the Z-Wave controller’s message
and the LED:
• Green – successful (non-secure, S0, S2 non-authenticated),
• Magenta – successful (Security S2 Authenticated),
• Red – not successful.
In case of problems with adding the device, please re-
i
set the device and repeat the adding procedure.
6: Removing from Z-Wave network
Removing (Exclusion) – Z-Wave device learning mode, allowing to
remove the device from existing Z-Wave network. Removing also results in resetting the device to factory defaults.
Make sure that restoring the parameters to factory
!
defaults will not result in damaging the connected
device, we recommend disconnecting it rst.
To remove the device from the Z-Wave network:
1. Power the device.
2. Set the main controller into remove mode (see the controller’s
manual).
3. Quickly, three times click the maintenance button.
4. LED will start blinking yellow, wait for the removing process to
end.
5. Successful removing will be conrmed by the Z-Wave controller’s
message and red LED colour.
removIng from Z-Wave netWork
7: Operating the device
7.1: Controlling channels with inputs
Momentary switch (parameter 20 set to 0):
1x click – change the state of the channel to the opposite one
Toggle switch without memory (parameter 20 set to 1):
1x switch – change the state of the channel to the state of the switch
(OFF if contacts opened, ON if contacts closed)
Toggle switch with memory (parameter 20 set to 2):
1x switch – change the state of the channel to the opposite one
By default S1 input controls 1st channel and S2 input
i
controls 2nd channel if present. It can be changed us-
ing parameters 24 and 25.
11
By default outputs are set as NO (normally open).
i
It means the contacts will be opened when turned o
and closed when turned on. It can be switched to NC (normally closed), which means the contacts will be closed
when turned o and opened when turned on using parameters 162/163.
7.2: Visual indications
The built-in LED light shows current device status.
After powering the device:
• Green – device added to a Z-Wave network (non-secure, S0, S2
non-authenticated),
• Magenta – device added to a Z-Wave network (Security S2
Authenticated),
• Red – device not added to a Z-Wave network.
Update:
• Blinking cyan – update in progress,
• Green – update successful,
• Red – update not successful.
Menu:
• Blinking green – entering the menu (added as non-secure, S0, S2
non-authenticated),
operatIng the DevIce
12
• Blinking magenta – entering the menu (added as Security S2
Authenticated),
• Blinking red – entering the menu (not added to a Z-Wave network),
• Magenta – test Z-Wave network range,
• Yellow – reset to factory defaults.
7.3: Menu
Menu allows to perform Z-Wave network actions. In order to use the
menu:
1. Press and hold the maintenance button to enter the menu.
2. LED will signal adding status for 3 seconds (see 7.2: Visual
indications), then turn o for another 3 seconds.
3. Release the button when device signals desired position with
colour:
• Magenta – test Z-Wave network range
• Yellow – reset to factory defaults
4. Quickly click the button to conrm.
7.4: Resetting to factory defaults
Reset procedure allows to restore the device back to its factory settings, which means all information about the Z-Wave controller and
user conguration will be deleted.
Make sure that restoring the parameters to factory
!
defaults will not result in damaging the connected
device, we recommend disconnecting it rst.
Resetting the device is not the recommended way of
i
removing the device from the Z-Wave network. Use reset procedure only if the primary controller is missing or
inoperable. Certain device removal can be achieved by the
procedure of removing described.
1. Press and hold the maintenance button to enter the menu.
2. Release button when the device glows yellow.
3. Quickly click the button to conrm.
4. After few seconds the device will be restarted, which is signalled
operatIng the DevIce
with red LED colour.
8: Z-Wave range test
The device has a built in Z-Wave network main controller’s range
tester.
To make Z-Wave range test possible, the device must
i
be added to the Z-Wave controller. Testing may stress
the network, so it is recommended to perform the test only
in special cases.
To test the main controller’s range:
1. Press and hold the maintenance button to enter the menu.
2. Release button when the device glows magenta.
3. Quickly click the button to conrm.
4. Visual indicator will indicate the Z-Wave network’s range (range
signaling modes described below).
13
5. To exit Z-Wave range test, press the button briey.
Z-Wave range tester signalling modes:
• Visual indicator pulsing green - the device attempts to establish
a direct communication with the main controller. If a direct communication attempt fails, the device will try to establish a routed
communication, through other modules, which will be signalled
by visual indicator pulsing yellow.
• Visual indicator glowing green - the device communicates with
the main controller directly.
• Visual indicator pulsing yellow - the device tries to establish a
routed communication with the main controller through other
modules (repeaters).
• Visual indicator glowing yellow - the device communicates with
the main controller through the other modules. After 2 seconds
the device will retry to establish a direct communication with the
main controller, which will be signalled with visual indicator pulsing green.
• Visual indicator pulsing violet - the device does communicate
at the maximum distance of the Z-Wave network. If connection
proves successful it will be conrmed with a yellow glow. It’s not
recommended to use the device at the range limit.
• Visual indicator glowing red - the device is not able to connect
to the main controller directly or through another Z-Wave network device (repeater).
Communication mode of the device may switch be-
i
the device is on the limit of the direct range.
tween direct and one using routing, especially if
Z-Wave range test
14
9: Activating scenes
The device can activate scenes in the Z-Wave controller by sending
scene ID and attribute of a specic action using Central Scene Command Class.
By default all action are activated, change settings of parameters 40
and 41 to disable scene activation for selected actions.
Switch Action Scene ID Attribute
Switch clicked
once
Switch clicked
twice
Switch clicked
S1 terminal
Switch connected to
Switch connected to
* Activating triple clicks will disallow removing using this input.
Switch released** 1 Key Released
S2 terminal
Switch released** 2 Key Released
thrice*
Switch held** 1 Key Held Down
Switch clicked
once
Switch clicked
twice
Switch clicked
thrice*
Switch held** 2 Key Held Down
1 Key Pressed 1 time
1 Key Pressed 2 times
1 Key Pressed 3 times
2 Key Pressed 1 time
2 Key Pressed 2 times
2 Key Pressed 3 times
** Not available for toggle switches.
actIvatIng scenes
10: Conguration
10.1: Associations
Association (linking devices) – direct control of other devices within the Z-Wave system network.
Associations allow:
• reporting the device status to the Z-Wave controller (using Lifeline
group),
• creating simple automations by controlling other devices without
participation of the main controller (using groups assigned to actions on the device).
Commands send to association groups reect input
i
operation according to device conguration, e.g. turning the rst channel on using button will send frame responsible for the same action.
15
Smart Module provides the association of 2 groups:
1st association group – “Lifeline” reports the device status and al-
lows for assigning single device only (main controller by default).
2nd association group – “On/O (1)” is used to turn the associated
devices on/o reecting input operation (uses Basic command class).
Double Smart Module provides the association of 3 groups:
1st association group – “Lifeline” reports the device status and al-
lows for assigning single device only (main controller by default).
2nd association group – “On/O (1)” is used to turn the associated
devices on/o reecting input operation for 1st channel (uses Basic
command class).
3rd association group – “On/O (2)” is used to turn the associated
devices on/o reecting input operation for 2nd channel (uses Basic
command class).
The device allows to control 5 regular or multichannel devices per an
association group, with the exception of “LifeLine” that is reserved
solely for the controller and hence only 1 node can be assigned.
confIguratIon
16
Values sent to association groups depending on settings
Values are sent using Basic Command Class. Values below are default but can be adjusted using parameters 156-161.
Parameter
150/151
0, 1 or 3 –
2
– –
Parameter
Momentary or toggle switches with memory
152/153
(parameter 20/21 set to 0 or 2)
255 (ON) if turned OFF
0 (OFF) if turned ON
0 or 1
2 255 (ON) 99 (max)
Toggle switches without memory
(parameter 20/21 set to 1)
255 (ON) if turned OFF
0 (OFF) during countdown
255 (ON) if turned OFF
0 (OFF) if turned ON
Click
99 (max)
99 (max)
99 (max)
Double
Click
confIguratIon
10.2: Advanced parameters
The device allows to customize its operation to user’s needs using
congurable parameters.
The settings can be adjusted via Z-Wave controller to which the device is added. The way of adjusting them might dier depending on
the controller.
In the FIBARO interface parameters are presented as simple options
in Advanced Settings of the device.
Available parameters:
1. Remember relays state
This parameter determines the state of relays
after power supply failure (e.g. power outage).
17
Description
Parameter size 1B
Default value 1 (restore the state)
Available
values
20. S1 input – switch type
Description
For auto OFF and ashing modes the parameter
is not relevant and the relay will always remain
switched o.
0 – relays remain switched o after restoring
power
1 – restore remembered state of relays after
restoring power
2 – restore remembered state of relays after
restoring power, but for toggle switches (parameter 20/21 set to 1) set the same state as the
current state of the switches
This parameter denes as what type the device
should treat the switch connected to the S1
terminal.
Parameter size 1B
Default value 0 (momentary switch)
0 – momentary switch
Available
values
1 – toggle switch synchronized (contact closed ON, contact opened - OFF)
2 – toggle switch with memory (device changes
status when switch changes status)
confIguratIon
18
21. S2 input – switch type
This parameter denes as what type the device
Description
Parameter size 1B
Default value 0 (momentary switch)
should treat the switch connected to the S2
terminal.
0 – momentary switch
Available
values
24. Inputs orientation
This parameter allows reversing operation of S1 and S2 inputs
without changing the wiring. Use in case of incorrect wiring.
Parameter size 1B
Default value 0 (default)
Available
values
25. Outputs orientation
This parameter allows reversing operation of Q1 and Q2 outputs
without changing the wiring. Use in case of incorrect wiring.
Parameter size 1B
1 – toggle switch synchronized (contact closed ON, contact opened - OFF)
2 – toggle switch with memory (device changes
status when switch changes status)
0 – default (S1 - 1st channel, S2 - 2nd channel)
1 – reversed (S1 - 2nd channel, S2 - 1st channel)
Only in Double Smart Module
confIguratIon
Default value 0 (default)
Available
values
0 – default (Q1 - 1st channel, Q2 - 2nd channel)
1 – reversed (Q1 - 2nd channel, Q2 - 1st channel)
30. Alarm conguration - 1st slot
This parameter determines to which alarm
frames and how the device should react. The
Description
Parameter size 4B
Default value [0x00, 0x00, 0x00, 0x00] (disabled)
parameters consist of 4 bytes, three most signicant bytes are set according to the ocial
Z-Wave protocol specication.
1B [MSB] – Notication Type
2B – Notication Status
19
Available
values
31. Alarm conguration - 2nd slot
Description
Parameter size 4B
Default value
Available
values
3B – Event/State Parameters
4B [LSB] – action:
0x00 – no action, 0x01 – turn ON, 0x02 – turn
OFF, 0x03 – turn ON/OFF continuously
This parameter determines to which alarm
frames and how the device should react. The
parameters consist of 4 bytes, three most signicant bytes are set according to the ocial
Z-Wave protocol specication.
[0x05, 0xFF, 0x00, 0x00]
(Water Alarm, any notication, no action)
1B [MSB] – Notication Type
2B – Notication Status
3B – Event/State Parameters
4B [LSB] – action:
0x00 – no action, 0x01 – turn ON, 0x02 – turn
OFF, 0x03 – turn ON/OFF continuously
confIguratIon
20
32. Alarm conguration - 3rd slot
This parameter determines to which alarm
frames and how the device should react. The
Description
Parameter size 4B
Default value
parameters consist of 4 bytes, three most signicant bytes are set according to the ocial
Z-Wave protocol specication.
[0x01, 0xFF, 0x00, 0x00]
(Smoke Alarm, any notication, no action)
1B [MSB] – Notication Type
2B – Notication Status
Available
values
33. Alarm conguration - 4th slot
Description
Parameter size 4B
Default value
Available
values
3B – Event/State Parameters
4B [LSB] – action:
0x00 – no action, 0x01 – turn ON, 0x02 – turn
OFF, 0x03 – turn ON/OFF continuously
This parameter determines to which alarm
frames and how the device should react. The
parameters consist of 4 bytes, three most signicant bytes are set according to the ocial
Z-Wave protocol specication.
[0x02, 0xFF, 0x00, 0x00]
(CO Alarm, any notication, no action)
1B [MSB] – Notication Type
2B – Notication Status
3B – Event/State Parameters
4B [LSB] – action:
confIguratIon
0x00 – no action, 0x01 – turn ON, 0x02 – turn
OFF, 0x03 – turn ON/OFF continuously
34. Alarm conguration - 5th slot
This parameter determines to which alarm
frames and how the device should react. The
Description
Parameter size 4B
Default value
parameters consist of 4 bytes, three most signicant bytes are set according to the ocial
Z-Wave protocol specication.
[0x04, 0xFF, 0x00, 0x00]
(Heat Alarm, any notication, no action)
1B [MSB] – Notication Type
2B – Notication Status
21
Available
values
35. Alarm conguration – duration
Description
Parameter size 2B
Default value 600 (10min)
Available
values
40. S1 input – scenes sent
Description
3B – Event/State Parameters
4B [LSB] – action:
0x00 – no action, 0x01 – turn ON, 0x02 – turn
OFF, 0x03 – turn ON/OFF continuously
This parameter denes duration of alarm sequence. When time set in this parameter elapses, alarm is cancelled and relays restore normal
operation, but do not recover state from before
the alarm.
0 – innite
1-32400 (1s-9h, 1s step) – duration
This parameter determines which actions result
in sending scene IDs assigned to them. Values
can be combined (e.g. 1+2=3 means that scenes
for single and double click are sent).
Enabling scenes for triple click disables entering
the device in learning mode by triple clicking.
Parameter size 1B
Default value 15 (all active)
0 – no scenes sent
1 – Key pressed 1 time
Available
values
2 – Key pressed 2 times
4 – Key pressed 3 times
8 – Key hold down and key released
confIguratIon
22
41. S2 input – scenes sent
This parameter determines which actions result
in sending scene IDs assigned to them. Values
can be combined (e.g. 1+2=3 means that scenes
Description
Parameter size 1B
Default value 15 (all active)
Available
values
for single and double click are sent).
Enabling scenes for triple click disables entering
the device in learning mode by triple clicking.
0 – no scenes sent
1 – Key pressed 1 time
2 – Key pressed 2 times
4 – Key pressed 3 times
8 – Key hold down and key released
150. First channel – operating mode
This parameter allows to choose operating
mode for channel controlled with Q/Q1 output.
Description
Parameter size 1B
Default value 0 (standard operation)
Available
values
151. Second channel – operating mode
Description
For timed modes (value 1, 2 or 3), time is set
with parameter 154 and reaction to input
change is set with parameter 152.
0 – standard operation
1 – delayed OFF
2 – auto OFF
3 – ashing
Only in Double Smart Module
This parameter allows to choose operating
mode for channel controlled with Q2 output. For
timed modes (value 1, 2 or 3), time is set with
parameter 155 and reaction to input change is
set with parameter 153.
confIguratIon
Parameter size 1B
Default value 0 (standard operation)
0 – standard operation
Available
values
1 – delayed OFF
2 – auto OFF
3 – ashing
23
152.
Description
Parameter size 1B
Default value 0 (cancel mode)
Available
153.
Description
First channel – reaction to input change in delayed/
auto OFF modes
This parameter determines how the device
reacts when changing state of S1 input in timed
modes for rst channel.
0 – cancel mode and set default state
1 – no reaction, mode runs until it ends
values
Second channel – reaction to input change in delayed/
2 – reset timer, start counting time from the
beginning
auto OFF modes
Only in Double Smart Module
This parameter determines how the device
reacts when changing state of S2 input in timed
modes for second channel.
Parameter size 1B
Default value 0 (cancel mode)
0 – cancel mode and set default state
Available
values
154.
Description
Parameter size 2B
Default value 5 (0.5s)
Available
First channel – time parameter for delayed/auto OFF
values
1 – no reaction, mode runs until it ends
2 – reset timer, start counting time from the
beginning
and ashing modes
This parameter allows to set time parameter
used in timed modes for rst channel. For delayed/auto OFF modes it determines duration,
for ashing mode it determines cycle period.
0 – 0.1 seconds
1-32000 – 0.1-3200 seconds, 0.1s step
confIguratIon
24
155.
Description
Parameter size 2B
Default value 5 (0.5s)
Available
values
156.
Description
Parameter size 2B
Second channel – time parameter for delayed/auto
Only in Double Smart Module
This parameter allows to set time parameter
used in timed modes for second channel. For
delayed/auto OFF modes it determines duration,
for ashing mode it determines cycle period.
0 – 0.1 seconds
1-32000 – 0.1-3200 seconds, 0.1s step
S1 input – Switch ON value sent to 2nd association
This parameter denes value sent with Switch
ON command to devices in 2nd association
group when using S1 input.
OFF and ashing modes
group
Default value 255
Available
values
157.
Description
Parameter size 2B
Default value 0
Available
values
158.
Description
S1 input – Switch OFF value sent to 2nd association
S1 input – Double Click value sent to 2nd association
0 – turn o
1-99 – turn on and set level
255 – turn on with last level
This parameter denes value sent with Switch
OFF command to devices in 2nd association
group when using S1 input.
0 – turn o
1-99 – turn on and set level
255 – turn on with last level
This parameter denes value sent with Double
Click command to devices in 2nd association
group when using S1 input.
group
group
confIguratIon
Parameter size 2B
Default value 99
Available
values
0 – turn o
1-99 – turn on and set level
255 – turn on with last level
25
159.
Description
Parameter size 2B
Default value 255
Available
values
160.
Description
S2 input – Switch ON value sent to 3rd association
Only in Double Smart Module
This parameter denes value sent with Switch
ON command to devices in 3rd association
group when using S2 input.
0 – turn o
1-99 – turn on and set level
255 – turn on with last level
S2 input – Switch OFF value sent to 3rd association
Only in Double Smart Module
This parameter denes value sent with Switch
OFF command to devices in 3rd association
group when using S2 input.
group
group
Parameter size 2B
Default value 0
Available
values
161.
Description
Parameter size 2B
Default value 99
Available
S2 input – Double Click value sent to 3rd association
values
0 – turn o
1-99 – turn on and set level
255 – turn on with last level
Only in Double Smart Module
This parameter denes value sent with Double
Click command to devices in 3rd association
group when using S2 input.
0 – turn o
1-99 – turn on and set level
255 – turn on with last level
group
confIguratIon
26
162. Q/Q1 output type
Description This parameter determines type of Q/Q1 output.
Parameter size 1B
Default value 0 (Normally Open)
0 – Normally Open (relay contacts opened
Available
values
163. Q2 output type
Description This parameter determines type of Q2 output.
Parameter size 1B
Default value 0 (Normally Open)
turned o, closed when turned on)
1 – Normally Closed (relay contacts closed
turned o, opened when turned on)
Only in Double Smart Module
0 – Normally Open (relay contacts opened
Available
values
164. Lock simultaneous switching of Q1 and Q2 outputs
Description
Parameter size 1B
Default value 0 (lock disabled)
Available
values
turned o, closed when turned on)
1 – Normally Closed (relay contacts closed
turned o, opened when turned on)
Only in Double Smart Module
When the lock is enabled, both outputs cannot
be turned on at the same time.
0 – lock disabled
1 – lock enabled
confIguratIon
11: Z-Wave specication
Generic Device Class: GENERIC_TYPE_SWITCH_BINARY
Specic Device Class: SPECIFIC_TYPE_POWER_SWITCH_BINARY
Supported Command Classes
Command Class Version Secure
COMMAND_CLASS_ZWAVEPLUS_INFO [0x5E] V2
COMMAND_CLASS_SWITCH_BINARY [0x25] V1 YES
COMMAND_CLASS_ASSOCIATION [0x85] V2 YES
27
COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION [0x8E]
COMMAND_CLASS_ASSOCIATION_GRP_INFO
[0x59]
COMMAND_CLASS_TRANSPORT_SERVICE [0x55] V2
COMMAND_CLASS_VERSION [0x86] V2 YES
COMMAND_CLASS_MANUFACTURER_SPECIFIC
[0x72]
COMMAND_CLASS_DEVICE_RESET_LOCALLY
[0x5A]
COMMAND_CLASS_POWERLEVEL [0x73] V1 YES
COMMAND_CLASS_SECURITY [0x98] V1
COMMAND_CLASS_SECURITY_2 [0x9F] V1
COMMAND_CLASS_CONFIGURATION [0x70] V1 YES
COMMAND_CLASS_CRC_16_ENCAP [0x56] V1
COMMAND_CLASS_NOTIFICATION [0x71] V8 YES
COMMAND_CLASS_PROTECTION [0x75] V2 YES
V3 YES
V2 YES
V2 YES
V1 YES
COMMAND_CLASS_CENTRAL_SCENE [0x5B] V3 YES
COMMAND_CLASS_FIRMWARE_UPDATE_MD
[0x7A]
COMMAND_CLASS_APPLICATION_STATUS [0x22] V1
COMMAND_CLASS_SUPERVISION [0x6C] V1 YES
COMMAND_CLASS_MULTI_CHANNEL [0x60]
(only in FGS-224)
COMMAND_CLASS_BASIC [0x20] V1 YES
V4 YES
V4 YES
Z-Wave specIfIcatIon
28
Multichannel Command Class (only in FGS-224)
Endpoint 1
Generic Device Class: GENERIC_TYPE_SWITCH_BINARY
Specic Device Class: SPECIFIC_TYPE_POWER_SWITCH_BINARY
Description: 1st channel
Command Classes:
COMMAND_CLASS_ZWAVEPLUS_INFO [0x5E]
COMMAND_CLASS_SWITCH_BINARY [0x25]
COMMAND_CLASS_ASSOCIATION [0x85]
COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION [0x8E]
COMMAND_CLASS_ASSOCIATION_GRP_INFO [0x59]
COMMAND_CLASS_SECURITY [0x98]
COMMAND_CLASS_SECURITY_2 [0x9F]
COMMAND_CLASS_SUPERVISION [0x6C]
COMMAND_CLASS_PROTECTION [0x75]
COMMAND_CLASS_NOTIFICATION [0x71]
COMMAND_CLASS_APPLICATION_STATUS [0x22]
Endpoint 2
Generic Device Class: GENERIC_TYPE_SWITCH_BINARY
Specic Device Class: SPECIFIC_TYPE_POWER_SWITCH_BINARY
Description: 2nd channel
Command Classes:
COMMAND_CLASS_ZWAVEPLUS_INFO [0x5E]
COMMAND_CLASS_SWITCH_BINARY [0x25]
COMMAND_CLASS_ASSOCIATION [0x85]
COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION [0x8E]
COMMAND_CLASS_ASSOCIATION_GRP_INFO [0x59]
COMMAND_CLASS_SECURITY [0x98]
COMMAND_CLASS_SECURITY_2 [0x9F]
COMMAND_CLASS_SUPERVISION [0x6C]
COMMAND_CLASS_PROTECTION [0x75]
COMMAND_CLASS_APPLICATION_STATUS [0x22]
Z-Wave specIfIcatIon
Notication Command Class
The device uses Notication Command Class to report dierent events
to the controller using “Lifeline” group (only in Root / Endpoint 1).
29
Notication
Type
System [0x09]
Protection CC
Protection Command Class allows to prevent local or remote control
of the outputs.
Type State Description Hint
Local 0
Local 2
RF 0
Heartbeat (Notica-
tion CC V5) [0x05]
Unprotected - The device is not
protected, and may be operated
normally via the user interface.
No operation possible – button can
not change relay state, any other
functionality is available (menu and
Central Scenes Notication).
Unprotected - The device accept
and respond to all RF Commands.
Event Parameter Status
–
0xFF – enable
(non-changeable)
Inputs connected
with outputs.
Inputs disconnect-
ed from outputs.
Outputs can be
controlled via
Z-Wave.
No RF control – command class ba-
RF 1
Assocation groups mapping
Root Endpoint
Association Group 2 Endpoint 1 Association Group 2
Association Group 3 Endpoint 2 Association Group 2
sic and switch binary are rejected,
every other command class will be
handled.
Association group in
Outputs cannot
be controlled via
Z-Wave.
endpoint
Z-Wave specIfIcatIon
30
12: Regulations
Legal Notices
All information, including, but not limited to, information regarding
the features, functionality, and/or other product specication are
subject to change without notice. Fibaro reserves all rights to revise
or update its products, software, or documentation without any obligation to notify any individual or entity.
FIBARO and Fibar Group logo are trademarks of Fibar Group S.A. All
other brands and product names referred to herein are trademarks
of their respective holders.
Declaration of conformity
Hereby, Fibar Group S.A. declares that the device is in compliance with the essential requirements and other relevant
provisions of Directive 2014/53/EU, 2011/65/EU and
2015/863. The full text of the EU declaration of conformity is available at the following internet address: www.manuals.baro.com
WEEE Directive Compliance
Device labelled with this symbol should not be disposed with
other household wastes. It shall be handed over to the applicable collection point for the recycling of waste electrical and
electronic equipment.
regulatIons
Loading...
