FIBARO SWIPE

FGGC-001

CONTENTS

#1: Description and features 4
#2: Gestures overview 5
#3: Basic activation 6
#4: Adding the device 8
#5: Removing the device 9

FIBARO

v1.0

#8: Sequences of gestures 12
#9: Powering modes 14
#10: Additional features 15
#11: Associations 16

#12: Advanced parameters 17
#6: Operating the device 10
#7: Scene ID 11

#13: Specications 23

#14: Guarantee 24

Important safety information

Read this manual before attempting to install the device!

!

Failure to observe recommendations included in this manual
may be dangerous or cause a violation of the law. The manufacturer,
Fibar Group S.A. will not be held responsible for any loss or damage
resulting from not following the instructions of operating manual.

General information about
the FIBARO System

FIBARO is a wireless smart home automation system, based on the
Z-Wave protocol. All of available devices can be controlled through
a computer (PC or Mac), smartphone or tablet. Z-Wave devices (non­battery powered) are not only receivers, but can also repeat the
signal, increasing the Z-Wave network’s range. It gives advantage
over traditional wireless systems that require direct link between
transmitter and receiver, as a result the construction of the building
could aect network’s range negatively.

3

Every FIBARO network has its unique identication number (home
ID). Multiple independent networks can exist in the building without
interfering. Transmission security of FIBARO System is comparable to
wired systems.

Z-Wave technology is the leading solution in smart home automation.
There is a wide range of Z-Wave devices that are mutually
compatible, independently of manufacturer. It gives the system the
ability to evolve and expand over time. For more information visit:
www.baro.com.

4

NOTE

i

This device may be
used with all de­vices certied with
the Z-Wave Plus cer­ticate and should be
compatible with such
devices produced by
other manufacturers.

#1: Description and features

FIBARO Swipe is a revolutionary battery gesture control pad that

allows you to control devices in your Z-Wave network without actually
touching anything. Swipe up, down, left, right, make a circular gesture
and use sequences to get full and intuitive control of your home.

Installed device perfectly matches your interior design, as it resembles
a picture frame. You can even personalize it with your favourite
picture. Gesture controlled menu allow to add/remove or reset the
device without dismounting it.

The device is equipped with a buzzer that conrms performed
gestures and other actions.

Main features of FIBARO Swipe:

• Compatible with any Z-Wave or Z-Wave+ Controller.

• Supports protected mode (Z-Wave network security mode) with
AES-128 encryption.

• Allows contactless gesture detection.

• Battery and/or VDC powered. When connected to an external, VDC
power source, the battery serves as an emergency power source.

NOTE

i

FIBARO Swipe is a
Security Enabled
Z-Wave Plus product
and a Security Ena­bled Z-Wave Control­ler must be used in or­der to fully utilize the
product.

• Gestures and actions are conrmed by the buzzer and can be
indicated additionally by the built-in LED diode.

• Gesture controlled menu - allows to operate the device without
dismounting it.

FIBARO Swipe is a fully
compatible Z-Wave PLUS device.

DESCRIPTION AND FEATURES

#2: Gestures overview

Basic gestures are used to turn ON and OFF associated devices or

trigger scenes.

Swipe up Swipe down

5

Swipe left Swipe right

Circular gestures are used to e.g. dim/brighten the lights or adjust
the blinds via associations. They can also trigger scenes.

After performing rst circle, the device will start changing the value
(clockwise - increase, counter-clockwise - decrease). Withdrawing the
hand will stop the change.

Clockwise Counter clockwise

Sequences are composed of two or three gestures. User can create
up to 6 custom sequences. They can operate other devices via scenes
only.

Sequence

GESTURES OVERVIEW

6

#3: Basic activation

1. Remove the front magnetic cover.

2. Unmount the Swipe from the back case by sliding the device
down.

3. Remove paper strip protecting the batteries.

4. Mount the Swipe back into the back case by sliding the device up.

5. The device will conrm powering up with an acoustic signal.

6. Place the front magnetic cover.

BASIC ACTIVATION

7. Place the Swipe onto its holder.

8. Place the Swipe within the direct range of your Z-Wave controller.

9. Plug the power source into the micro-USB port if required.

10. Set the main controller in (security/non-security) add mode (see
the controller’s manual).

11. Move and hold your hand close to the center of the pad.

12. If the device is battery powered, high pitched beep will signal
exiting the Standby Mode.

7

13. Loud sound sequence will conrm entering the menu, keep
holding your hand.

14. After hearing two short beeps (green indicator colour), withdraw
the hand and perform swiping up gesture to conrm selection
(two beeps will conrm validity).

15. Wait for the adding process to end.

16. Successful adding will be conrmed by the Z-Wave controller’s
message and 3 short beeps (green visual indicator colour).

BASIC ACTIVATION

8

#4: Adding the device

NOTE

i

Adding in security
mode must be per­formed up to 2 meters
from the controller.

NOTE

i

In case the device is
not added, please re­set the device and re­peat the adding pro­cedure.

Adding (Inclusion) - Z-Wave device learning mode, allowing to add
the device to existing Z-Wave network.

To add the device to the Z-Wave network:

1. Place the Swipe within the direct range of your Z-Wave controller.

2. Set the main controller in (security/non-security) add mode (see
the controller’s manual).

3. Move and hold your hand close to the center of the pad.

4. If the device is battery powered, high pitched beep will signal
exiting the Standby Mode.

5. Loud sound sequence will conrm entering the menu, keep
holding your hand.

6. After hearing two short beeps (green indicator colour), withdraw
the hand and perform swiping up gesture to conrm selection
(two beeps will conrm validity).

ADDING THE DEVICE

7. Wait for the adding process to end.

8. Successful adding will be conrmed by the Z-Wave controller’s
message and 3 short beeps (green visual indicator colour).

#5: Removing the device

9

Removing (Exclusion) - Z-Wave device learning mode, allowing to
remove the device from existing Z-Wave network.

To remove the device to the Z-Wave network:

1. Place the Swipe within the direct range of your Z-Wave controller.

2. Set the main controller in remove mode (see the controller’s
manual).

3. Move and hold your hand close to the center of the pad.

4. If the device is battery powered, high pitched beep will signal
exiting the Standby Mode.

5. Loud sound sequence will conrm entering the menu, keep
holding your hand.

6. After hearing two short beeps (green indicator colour), withdraw
the hand and perform swiping up gesture to conrm selection
(two beeps will conrm validity).

NOTE

i

Removing the Swipe
from the Z-Wave net­work restores all the
default parameters of
the device.

NOTE

i

If the device is bat­tery powered, high
pitched beep will sig­nalize exiting from the
Standby Mode before
entering the menu.

7. Wait for the removing process to end.

8. Successful removing will be conrmed by the Z-Wave controller’s
message and sequence of 2 short beeps, pause, 1 short beep (red
visual indicator colour).

REMOVING THE DEVICE

10

#6: Operating the device

NOTE

i

Gestures are not in­dicated by the LED
diode by default. In
order to enable it, set
the value of parame­ter 3 to 1.

NOTE

i

If the device is battery
powered, high pitch
beep will signalize ex­iting from the Standby
Mode before entering
the menu.

NOTE

i

Menu can also be
operated using the
service button B (see
"Additional features"
on page 15)

Acoustic and visual indications:

The Swipe is equipped with a buzzer and LED diode, signalling ges­ture detection, menu position and status of the device.

Validity of every detected gesture or sequence is signalled by:

• 2 short beeps (GREEN) - gesture/sequence is valid

• Intermittent tone (GREEN) - smooth control using circular

gesture

• 1 long beep (RED) - gesture/sequence is invalid

Menu allows to perform Z-Wave network actions. In order to use the

menu:

1. Move and hold your hand close to the center of the pad.

2. Loud sound sequence will conrm entering the menu, keep
holding your hand.

3. Wait for the buzzer to indicate the desired menu position:

• 1 short beep (WHITE indicator colour) - wake up the device

• 2 short beeps (GREEN indicator colour) - learning mode

(adding/removing)

• 3 short beeps (YELLOW indicator colour) - the device reset

4. To select current position, withdraw the hand and perform swiping
up gesture to conrm selection (two beeps will conrm validity).

NOTE

i

Resetting the device is
not the recommend­ed way of removing
the device from the
Z-Wave network. Use
the reset procedure
only if the primary
controller is missing
or inoperable. Certain
device removal can be
achieved by the pro­cedure of removing
described in "Adding
the device" on page

8.

OPERATING THE DEVICE

Waking up the device:

The Swipe needs to be woken up to receive information about the
new conguration from the Z-Wave controller, like parameters and
associations. Use 1st menu position to wake up the device or click the
button on the back of the device once.

Reset procedure of the Swipe:

Reset procedure allows to restore the device back to its factory set­tings, which means all information about the Z-Wave controller and
user conguration will be deleted. In order to reset the device:

1. Make sure the device is powered.

2. Choose 3rd menu position (3 short beeps).

3. After few seconds the device will be restarted. Not being added
to the Z-Wave network will be signalized with sequence of 2 short
beeps, pause, 1 short beep (RED).

#7: Scene ID

11

Scene ID:

Every basic gesture and sequence has its own Scene ID that is send
to the main controller after recognizing it. Scene activation for basic
gestures is send after second gesture or timeout.

Scene

ID

1

2

3

4

5

6

7 1st sequence Key Pressed 1 time User-dened

Gesture or se-

quence

/\ Key Pressed 1 time ON

/\ /\ Key Pressed 2 times OFF

\/ Key Pressed 1 time ON

\/ \/ Key Pressed 2 times OFF

< Key Pressed 1 time ON

< < Key Pressed 2 times OFF

> Key Pressed 1 time ON

> > Key Pressed 2 times OFF

Circular gesture

(clockwise)

Circular gesture

(counter-clockwise)

Attribute Default action

Key Held Down

Key Released STOP

Key Held Down

Key Released STOP

Change state

UP

Change state

DOWN

NOTE

i

Toggle Mode (param­eter 12) disallows dou­bled gestures.

8 2nd sequence Key Pressed 1 time User-dened

9 3rd sequence Key Pressed 1 time User-dened
10 4th sequence Key Pressed 1 time User-dened
11 5th sequence Key Pressed 1 time User-dened
12 6th sequence Key Pressed 1 time User-dened

SCENE ID

12

#8: Sequences of gestures

Sequences:

User can create sequences of two or three gestures to expand num­ber of possible actions. Every sequence is saved in its advanced pa­rameter (no. 31-36) with 16 bits, every basic gesture is identied with
4 bits.

Gesture values:

Value 4 bits

0 0000 empty

1 0001 /\

2 0010 \/

3 0011 <

4 0100 >

NOTE

i

In case of sequence of
two gesture, eld for
third gesture should
be set to 0.

Ges-

ture

Bit mask of parameter Overall

Size 4 bits 4 bits 4 bits 4 bits 16 bits

Purpose reserved

Example none /\ > <

Example:

binary values

Example:

decimal values

always

0000

always 0 1 * 256 4 * 16 3 * 1 sum = 323

rst

gesture

0001 0100 0011

second

gesture

third

gesture

Rules of creating sequences:

• Maximum of six sequences can be created.

• Each sequence must be unique.

• Sequence can consist of two or three basic gestures (left, right, up
or down).

• Two identical gestures cannot be used next to each other.

SEQUENCES OF GESTURES

Learning a new sequence:

To perform automatic learning of a sequence:

1. Change value of parameter 30 to number of sequence slot you
want to ll (1 to 6).

2. Wake up the device using 1st menu position (see "Operating the
device" on page 10)

3. The device will enter learning mode, which is signalled by con­stant beeping.

4. Perform a desired sequence.

Creating and conguring sequences in the Home Center interface:

1. Go to the device options by clicking the icon on its bar:

2. Drag and drop two or three gestures to create a desired sequence.

3. Conrm the selection by clicking “Conrm a new sequence”.

4. Wake up the device using 1st menu position (see "Operating the
device" on page 10).

5. Click the plus icon ("New Reaction") next to the newly created se­quence.

6. Select the device you want to control.

7. From the available options select the reaction of the controlled
device and complete the setup by clicking "Save".

13

Creating and editing sequences manually:

To manually create or edit a sequence slot:

1. Calculate new value of parameter using table and formula:

Value of parameter = 256 * Value of rst gesture +
+ 16 * Value of second gesture + Value of third gesture

2. Change the value of corresponding parameter (parameters 31 to
36 for slots 1 to 6).

NOTE

i

Setting parameter to
0 will delete the se­quence.

SEQUENCES OF GESTURES

14

#9: Powering modes

CAUTION

!

Using batteries other
than specied may re­sult in explosion. Dis­pose of properly, ob­serving environmental
protection rules.

NOTE

i

The device does not
work as a Z-Wave
repeater, even when
connected to the ex­ternal power supply.

There are two powering modes of the Swipe. By default, powering
mode of the device is updated automatically (in intervals specied in
parameter 5) after changing type of supply.

The Swipe sends detected gestures to the Z-Wave network
immediately, but conguration parameters and associations settings
only at wake up (in time intervals or manually), independently of the
powering mode.

Battery powering mode - by default, the Swipe is supplied with
4 batteries included with the device (type AA 1.5V). They are not
rechargeable and should be replaced after wearing out. The device in
this mode uses power saving function to preserve battery life.

External supply mode - the Swipe can be supplied with a 5V DC
power supply connected to the micro-USB port. In this mode batteries
will work as an emergency supply.

Power saving:

When battery powered, the Swipe will enter Standby Mode by default
(signalled with a low pitch beep) after 5 seconds of inactivity to reduce
the battery usage. In Standby Mode range and frequency of detection
are reduced preventing normal gesture detection. Operation of
power saving mode can be modied in parameter 6.

In order to exit Standby Mode:

1. Move your hand close to the centre of the pad.

2. Wait for the high pitch beep.

3. Move your hand away from the pad.

4. The device is ready to detect gestures.

POWERING MODES

#10: Additional features

Service button B:

The Swipe is equipped with a service B-button, which allows to use
the menu. The B-button is located on back of the device and requires
dismounting the Swipe from its back case.

In order to operate the menu using the B-button:

1. Make sure the device is powered via micro-USB port.

2. Press and hold the B-button.

3. Loud sound sequence will conrm entering the menu, keep
holding your hand.

4. Wait for the buzzer to indicate the desired menu position with short
beeps:

15

• 1 short beep (WHITE) - wake up the device

• 2 short beeps (GREEN) - learning mode (adding/removing)

• 3 short beeps (YELLOW) - the device reset

5. Release the B-button.

6. Click the B-button to conrm selection.

ADDITIONAL FEATURES

16

NOTE

i

Association ensures
direct transfer of
control commands
between devices, is
performed without
participation of the
main controller and
requires associated
device to be in the di­rect range.

NOTE

i

By default 2nd-5th
association groups
are set to toggle
mode - single gesture
will reverse state of
the association group
(turns ON when it’s
OFF, turns OFF when
it’s ON). Can be modi­ed via parameter 12.

NOTE

i

States of the associa­tion groups are aect­ed only by assigned
gestures. Changing
state of associated de­vice by other means
will not update re­membered state of as­sociation group.

#11: Associations

Association (linking devices) - direct control of other devices within

the Z-Wave system network e.g. Dimmer, Relay Switch, Roller Shutter
or scene (may be controlled only through a Z-Wave controller).

The Swipe provides the association of six groups:

1st association group – “Lifeline” reports the device status and al-

lows for assigning single device only (main controller by default).

2nd association group – “Flick UP” is assigned to moving the hand
up over the panel (sends Basic Set command frames).

3rd association group – “Flick DOWN” is assigned to moving the
hand down over the panel (sends Basic Set command frames).

4th association group – “Flick LEFT” is assigned to moving the hand
from the right to the left side of the panel (sends Basic Set command
frames).

5th association group – “Flick RIGHT” is assigned to moving the
hand from the left to the right side of the panel (sends Basic Set com­mand frames) .

6th association group – “Circular AirWheel” is assigned to circu­lar move of the hand clockwise or counter-clockwise over the panel
(sends Switch Multilevel Start/Stop Level Change command frames).

The Swipe in 2nd to 6th group allows to control 5 regular or multichan­nel devices per an association group, with the exception of “LifeLine”
that is reserved solely for the controller and hence only 1 node can be
assigned.

It is not recommended to associate more than 10 devices in general,
as the response time to control commands depends on the number of
associated devices. In extreme cases, system response may be delayed.

ASSOCIATIONS

To add an association (using the Home Center controller):

1. Go to the device options by clicking the icon:

2. Select the „Advanced” tab.

3. Specify to which group and what devices are to be associated.

4. Wait for the conguration process to end. Sending relevant infor­mation to devices added to associated groups may take even a
few minutes.

5. Wake up the device manually to speed up the conguration
process (1st menu position).

#12: Advanced parameters

The Swipe allows to customize its operation to user’s needs. The set­tings are available in the FIBARO interface as simple options that may
be chosen by selecting the appropriate box.

In order to congure the Swipe (using the Home Center controller):

1. Go to the device options by clicking the icon:

2. Select the „Advanced” tab.

Wake up interval

Available settings: 0 or 60-64800 (in seconds, 1min - 18h)

Default setting: 21 600 (every 6 hours)

The Swipe will wake up at each dened time interval and always try to
connect with the main controller. After successful communication at­tempt, the device will update conguration parameters, associations
and settings and then will go into Z-Wave communication standby.

17

After failed communication attempt (eg. no Z-Wave range) the device
will go into Z-Wave communication standby and retry to establish
connection with the main controller after the next time interval.

Setting wake up interval to 0 disables sending Wake Up notication
to the controller automatically. Wake up may be still performed man­ually using 1st menu position.

Longer time interval means less frequent communication and thus a
longer battery life

1. Device orientation

Parameter determines orientation of the Swipe in relation to its de­fault position. Required for proper gestures recognition.

Available settings: 0 - default orientation

1 - 180° rotation

2 - 90° clockwise rotation

3 - 90° counter-clockwise rotation

Default setting: 0 Parameter size: 1 [byte]

2. Buzzer - acoustic signal settings

Acoustic signalling of gestures detection.

Available settings: 0 - gestures detection is not signalled

1 - gestures detection is signalled

Default setting: 1 Parameter size: 1 [byte]

NOTE

i

Active acoustic signals
can be selected in
parameter 4.

ADVANCED PARAMETERS

18

3. LED diode - visual indicator settings

Visual indication of gestures detection.

Available settings: 0 - gestures detection is not indicated

1 - gestures detection is indicated

Default setting: 0 Parameter size: 1 [bytes]

NOTE

i

Parameter 4 is rele­vant only if parameter
2 is set to 1.

4. Buzzer - signalling result of gesture recognition

Acoustic signalling of gesture recognition result (using the built-in
buzzer).

Available settings: 1 - only successful recognition is signalled

2 - only failed recognition is signalled

3 - successful and failed recognition is signalled

Default setting: 3 Parameter size: 1 [byte]

5. Powering mode - interval of updating the current mode

This parameter determines how often the device checks if the USB
power supply is connected and updates powering mode if needed.

Available settings: 0 - powering mode is not updated

1-1080 (in minutes) - time interval

Default setting: 4

(4 minutes)

Parameter size: 2 [bytes]

6. Power saving mode (battery mode)

This parameter determines operation of gesture detection when bat­tery powered.

CAUTION

!

After disabling the
Hold gesture in param­eter 7, menu can be
entered by using the
B-button only!

When Standby Mode is selected, hold gesture must be performed to
exit power saving mode and reactivate normal gesture recognition.
The device in Standby Mode consumes the least battery life.

When Simple Mode mode is selected, gesture recognition is always
active, but only slowly performed gestures will be recognized proper­ly (high battery consumption).

Available settings: 0 - Standby Mode

1 - Simple Mode

2 - the Swipe does not enter power saving

mode

Default setting: 0 Parameter size: 1 [byte]

7. Hold gesture to enter the menu

This parameter allows to choose if the menu can be entered using the
Hold gesture.

Available settings: 0 - Hold gesture to enter the menu enabled

1 - Hold gesture to enter the menu disabled

Default setting: 0 (enabled) Parameter size: 1 [byte]

ASSOCIATIONS

19

10. Scenes sent to the controller

Denes which actions result in sending scenes to 1st “Lifeline” group.

Available settings: 1 - scenes for ick UP gesture enabled

2 - scenes for ick DOWN gesture enabled

4 - scenes for ick LEFT gesture enabled

8 - scenes for ick RIGHT gesture enabled

16 - scenes for clockwise circular gesture ena-

bled

32 - scenes for counter-clockwise circular ges­ture enabled

Default setting: 15 Parameter size: 1 [byte]

11. Associations in Z-Wave network security mode

Parameter defines how commands are sent in specified association
groups: as secure or non-secure. Parameter is active only in Z-Wave
network security mode. It does not apply to 1st “Lifeline” association
group.

Available settings: 1 - 2nd group ”Flick UP” sent as secure

2 - 3rd group ”Flick DOWN” sent as secure

4 - 4th group „Flick LEFT” sent as secure

NOTE

i

Parameter 10 values
may be combined,
e.g. 1+2=3 means that
scenes for ick UP and
DOWN are enabled.

NOTE

i

Parameter 11 values
may be combined,
e.g. 1+2=3 means that
2nd & 3rd group are
sent as secure.

8 - 5th group „Flick RIGHT” sent as secure

16 - 6th group „Circular AirWheel” sent as secure

Default setting: 31 Parameter size: 1 [byte]

12. Control mode of 2nd - 5th „Flick UP/DOWN/LEFT/RIGHT” asso­ciation groups and scenes

Parameter allows to choose control mode for 2nd-5th groups and
scenes.

By default, Toggle Mode is active, meaning that a single ick turns ON
the group and the same ick turns it OFF, doubled icks are inactive.

After disabling Toggle Mode a single ick will turn the device ON and
the same ick doubled will turn it OFF.

Available settings: 1 - Toggle Mode enabled for 2nd association

group

2 - Toggle Mode enabled for 3rd association
group

4 - Toggle Mode enabled for 4th association
group

8 - Toggle Mode enabled for 5th association
group

Default setting: 15 Parameter size: 1 [byte]

NOTE

i

Parameter 12 values
may be combined,
e.g. 1+2=3 means that
2nd & 3rd group are
selected.

NOTE

i

Disabling Toggle Mode
will introduce delay
when performing sin­gle gestures.

ASSOCIATIONS

20

13. Rate of smooth level control

Parameter allows to choose how long the hand has to be held near the
center of the pad after "AirWheel" gesture for the associated devices to
reach their maximum/minimum level.

Available settings: 0-10 - duration in seconds

255 - default settings of controlled devices

Default setting: 255 Parameter size: 2 [bytes]

NOTE

i

Commands sent to
association group for
turn ON/OFF can be
adjusted in parame­ters 20-27.

NOTE

i

Setting parameters
20-27 to appropriate
value will result in:

0 - turning o associ­ated devices

1-99 - forcing level of
associated devices

255 - setting associat­ed devices to the last
remembered state or
turning them on

ASSOCIATIONS - CONTROL FRAMES CONFIGURATION

20. SWITCH ON control frame value for FLICK UP gesture

This parameter allows to set value sent in SWITCH ON command
frame to the association group.

Available settings: 0-99 or 255
Default setting: 255 Parameter size: 2 [bytes]

21. SWITCH OFF control frame value for FLICK UP gesture

This parameter allows to set value sent in SWITCH OFF command
frame to the association group.

Available settings: 0-99 or 255
Default setting: 0 Parameter size: 2 [bytes]

22. SWITCH ON control frame value for FLICK DOWN gesture

This parameter allows to set value sent in SWITCH ON command
frame to the association group.

Available settings: 0-99 or 255

Default setting: 255 Parameter size: 2 [bytes]

23. SWITCH OFF control frame value for FLICK DOWN gesture

ASSOCIATIONS

This parameter allows to set value sent in SWITCH OFF command
frame to the association group.

Available settings: 0-99 or 255
Default setting: 0 Parameter size: 2 [bytes]

24. SWITCH ON control frame value for FLICK LEFT gesture

This parameter allows to set value sent in SWITCH ON command
frame to the association group.

Available settings: 0-99 or 255
Default setting: 255 Parameter size: 2 [bytes]

25. SWITCH OFF control frame value for FLICK LEFT gesture

This parameter allows to set value sent in SWITCH OFF command
frame to the association group.

Available settings: 0-99 or 255
Default setting: 0 Parameter size: 2 [bytes]

26. SWITCH ON control frame value for FLICK RIGHT gesture

This parameter allows to set value sent in SWITCH ON command
frame to the association group.

Available settings: 0-99 or 255
Default setting: 255 Parameter size: 2 [bytes]

27. SWITCH OFF control frame value for FLICK RIGHT gesture

This parameter allows to set value sent in SWITCH OFF command
frame to the association group.

Available settings: 0-99 or 255
Default setting: 0 Parameter size: 2 [bytes]

21

SEQUENCES OF GESTURES

30. Sequence learning mode

Parameter activated by the main Z-Wave controller. Change its value to
launch sequence learning procedure for the desired slot.

Available settings: 0 - learning mode disabled

1-6 - launch sequence learning for selected slot

Default setting: 0 Parameter size: 1 [byte]

31. 1st gestures sequence (SLOT 1)

Value containing sequence of gestures. See "Sequences of gestures" on
page 12 for more information.

Available settings: 0-1076
Default setting: 0 Parameter size: 2 [bytes]

32. 2nd gestures sequence (SLOT 2)

Value containing sequence of gestures. See "Sequences of gestures" on
page 12 for more information.

Available settings: 0-1076
Default setting: 0 Parameter size: 2 [bytes]

NOTE

i

Sequences does not
allow to use same
gestures next to each
other.

NOTE

i

Parameters 31-36 can
also be used to manu­ally set a sequence ac­cording to details de­scribed in "Sequences
of gestures" on page

12.

ASSOCIATIONS

22

33. 3rd gestures sequence (SLOT 3)

Value containing sequence of gestures. See "Sequences of gestures" on
page 12 for more information.

Available settings: 0-1076
Default setting: 0 Parameter size: 2 [bytes]

34. 4th gestures sequence (SLOT 4)

Value containing sequence of gestures. See "Sequences of gestures" on
page 12 for more information.

Available settings: 0-1076
Default setting: 0 Parameter size: 2 [bytes]

35. 5th gestures sequence (SLOT 5)

Value containing sequence of gestures. See "Sequences of gestures" on
page 12 for more information.

Available settings: 0-1076
Default setting: 0 Parameter size: 2 [bytes]

36. 6th gestures sequence (SLOT 6)

Value containing sequence of gestures. See "Sequences of gestures" on
page 12 for more information.

Available settings: 0-1076
Default setting: 0 Parameter size: 2 [bytes]

ASSOCIATIONS

#13: Specications

23

Power supply:

Operational current:

DC supply connector:

Battery type:

EU directives compliance:

Radio protocol:

Radio frequency:

Range:

5V DC power supply and/or batteries

< 60mA

micro-USB

4 x 1.5V AA

EMC 2004/108/EC
R&TTE 1999/5/EC
RoHS 2011/65/EU
LVD 2006/95/EC

Z-Wave+

868.4 or 869.8 MHz EU;

908.4 or 916.0 MHz US;

921.4 or 919.8 MHz ANZ;

869.0 MHz RU;

up to 50m outdoors
up to 40m indoors
(Depending on terrain and building
structure)

Dimensions:

178 x 130 x 29 mm

SPECIFICATIONS

24

#14: Guarantee

1. The Guarantee is provided by FIBAR GROUP S.A. (hereinafter „Manufacturer”),

based in Poznan, ul. Lotnicza 1; 60-421 Poznan, entered in the register of the Nation­al Court Register kept by the District Court in Poznań, VIII Economic Department of
the National Court Register, no. 553265, NIP 7811858097, REGON: 301595664.

2. The Manufacturer is responsible for equipment malfunction resulting from physi-

cal defects (manufacturing or material) of the Device during 12 months for business
/ 24 months for individual customers from the date of its purchase.

3. During the Guarantee period, the Manufacturer shall remove any defects, free of

charge, by repairing or replacing (at the sole discretion of the Manufacturer) any
defective components of the Device with new or regenerated components that are
free from defects. When the repair proves impossible, the Manufacturer reserves
the right to replace the device with a new or regenerated one, which shall be free
from any defects and its condition shall not be worse than the original device
owned by the Customer.

4. In special cases, when the device cannot be replaced with the device of the same

type (e.g. the device is no longer available), the Manufacturer may replace it with a
dierent device having technical parameters similar to the faulty one. Such activity
shall be considered as fullling the obligations of the Manufacturer. The Manufac­turer shall not refund money paid for the device.

5. The holder of a valid guarantee shall submit a guarantee claim through the guar-

antee service. Remember: before you submit a guarantee claim, contact our tech­nical support using telephone or e-mail. More than 50% of operational problems
are resolved remotely, saving time and money spent to initiating guarantee proce­dure. If remote support is insucient, the Customer shall ll the guarantee claim
form (using our website - www.baro.com) in order to obtain claim authorization.
When the guarantee claim form is submitted correctly, the Customer shall receive
the claim conrmation with a unique number (Return Merchandise Authorization

-RMA).

6. The claim may be also submitted by telephone. In this case, the call is recorded

and the Customer shall be informed about it by a consultant before submitting
the claim. Immediately after submitting the claim, the consultant shall provide the
Customer with the claim number (RMA-number).

7. When the guarantee claim form is submitted correctly, a representative of the

Authorised Guarantee Service (hereinafter as „AGS”) shall contact the Customer.

8. Defects revealed within the guarantee period shall be removed not later than 30

days from the date of delivering the Device to AGS. The guarantee period shall be
extended by the time in which the Device was kept by AGS.

GUARANTEE

9. A faulty device shall be provided by the Customer with complete standard equip-

ment and documents proving its purchase.

10. Parts replaced under the guarantee are the property of the Manufacturer. The

guarantee for all parts replaced in the guarantee process shall be equal to the guar­antee period of the original device. The guarantee period of the replaced part shall
not be extended.

11. Costs of delivering the faulty device shall be borne by the Customer. For unjus-

tied service calls, the Service may charge the Customer with travel expenses and
handling costs related to the case.

12. AGS shall not accept a complaint claim only when:

- the Device was misused or the manual was not observed,

- the Device was provided by the Customer incomplete, without accessories or
nameplate,

- it was determined that the fault was caused by other reasons than a material or
manufacturing defect of the Device

- the guarantee document is not valid or there is no proof of purchase,

13. The Manufacturer shall not be liable for damage to property caused by defective
device. The Manufacturer shall not be liable for indirect, incidental, special, conse­quential or punitive damage, or for any damage, including, inter alia, loss of prots,
savings, data, loss of benets, claims by third parties and any property damage or
personal injuries arising from or related to the use of the Device.

14. The guarantee shall not cover:

- mechanical damage (cracks, fractures, cuts, abrasions, physical deformations
caused by impact, falling or dropping the device or other object, improper use or
not observing the operating manual);

- damage resulting from external causes, e.g.: ood, storm, re, lightning, natural
disasters, earthquakes, war, civil disturbance, force majeure, unforeseen accidents,
theft, water damage, liquid leakage, battery spill, weather conditions, sunlight,
sand, moisture, high or low temperature, air pollution;

25

- damage caused by malfunctioning software, attack of a computer virus, or by fail­ure to update the software as recommended by the Manufacturer;

- damage resulting from: surges in power supply and/or telecommunication net­work, improper connection to the grid in a manner inconsistent with the operating
manual, or from connecting other devices not recommended by the Manufacturer.

- damage caused by operating or storing the device in extremely adverse condi­tions, i.e. high humidity, dust, too low (freezing) or too high ambient temperature.
Detailed permissible conditions for operating the Device are dened in the oper­ating manual;

- damage caused by using accessories not recommended by the Manufacturer

- damage caused by faulty electrical installation of the Customer, including the use
of incorrect fuses;

- damage caused by Customer’s failure to provide maintenance and servicing activ­ities dened in the operating manual;

- damage resulting from the use of spurious spare parts or accessories improper for
given model, repairing and introducing alterations by unauthorized persons;

- defects caused by operating faulty Device or accessories.

15. The scope of the guarantee repairs shall not include periodic maintenance and
inspections, in particular cleaning, adjustments, operational checks, correction of
errors or parameter programming and other activities that should be performed by
the user (Buyer). The guarantee shall not cover natural wear and tear of the Device
and its components listed in the operating manual and in technical documentation
as such elements have a dened operational life.

16. If a defect is not covered by the guarantee, the Manufacturer reserves the right
to remove such defect at its sole discretion, repairing the damaged or destroyed
parts or providing components necessary for repair or replacement.

17. This guarantee shall not exclude, limit or suspend the Customer rights when the
provided product is inconsistent with the purchase agreement.

GUARANTEE
