Handbook

On-line handbook

Select one of the following means of access to view your handbook on-line...

Find your handbook on the PeugeOT website, under "MyPeugeOT".

This personal space offers advice and other useful information for the care and maintenance of your vehicle.

Referring to the handbook on-line also gives you access to the latest information available, easily identified by the bookmark, associated with this symbol:

Flash this code for direct access to your handbook.

If the "MyPeugeOT" function is not available on the PeugeOT public website for your country, you can find your handbook at the following address: http://public.servicebox.peugeot.com/ddb/

Select:

the language, the vehicle, its body style, the print edition of your handbook appropriate for the date of registration of your vehicle.

Within the model range, an item of equipment may be not available, an option or fitted as standard. When an option, the customer has the choice of adding to the vehicle's equipment at extra cost when ordering and before the vehicle is produced. Any equipment fitted after the vehicle leaves the production line becomes an aftermarket accessory. The instructions for the user are supplied by the manufacturer of the accessory, it is not covered in this edition of the handbook

Please note the following point:

The fitting of electrical equipment or accessories which are not recommended by PeugeOT may result in a failure of your vehicle's electronic system. Please note this specific warning. It is advisable to contact a PeugeOT dealer to be shown the recommended equipment and accessories.

Key

Welcome

Thank you for choosing a 208. This handbook has been designed to help you make the most

of using your vehicle in all circumstances.

Warning

This symbol marks warnings which it is essential to observe for your own safety, for the safety of others or to avoid any risk of damaging your vehicle.

Information

This symbol draws your attention to additional information for better use of your vehicle.

Protection of the environment

This symbol accompanies advice relating to protection of the environment.

Overview

eco-driving

Monitoring

Instrument panels 14 Indicator and warning lamps 16 Touch screen 28 gauges and indicators 32 Trip computer 38 Trip computer with touch screen 40 Setting the date and time 42

Access

Remote control key 43 Alarm 50 electric windows 52 Boot 54 Panoramic sunroof 55

Comfort

Front seats 56 Rear seats 59 Rear seats 61 Steering wheel adjustment 62 Mirrors 63 Ventilation 65 Heating 68 Manual air conditioning 68 Dual-zone digital air conditioning 70 Front demist - defrost 73 Rear screen demist - defrost 73

Interior ttings 74 Boot ttings 78

Driving

Starting - Stopping the engine 81 Manual parking brake 82 Manual gearbox 83 gear shift indicator 84 5-speed electronic gearbox 85 6-speed electronic gearbox 89 Automatic gearbox 93 Stop & Start 97 Hill start assist 100 Speed limiter 101 Cruise control 103 Park Assist 107 Parking sensors 111

Visibility

Lighting controls 113 LeD lamps 117 Daytime running lamps 117 Automatic illumination of headlamps 119 Headlamp adjustment 120 Cornering lighting 121 Wiper controls 122 Automatic rain sensitive wipers 124 Courtesy lamp 126 Interior mood lighting 127

Contents

Safety

Direction indicators 128 Hazard warning lamps 128 emergency or assistance call 129 Horn 129

Tyre under-ination detection 130

eSC system 133 Front seat belts 136 Airbags 139 Child seats 143 Deactivating the passenger's front airbag 145 ISOFIX child seats 151 Child lock 155

Practical info rmat ion

Temporary puncture repair kit 156 Changing a wheel 161 Snow chains 168 Changing a bulb 169 Changing a fuse 176 Battery 182 electrical energy economy mode 185 Changing a wiper blade 186 Towing the vehicle 187 Towing a trailer 189 Fitting roof bars 191 Advice on care and maintenance 192 Accessories 193

Checks

Bonnet 196 Petrol engines 197 Diesel engines 198 Fuel tank 199 Misfuel prevention (Diesel) 201 Running out of fuel (Diesel) 203

AdBlue

additive and SCR system

(Blue HDi Diesel) 204 Checking levels 212 Checks 215

Technical data

general information 217 Petrol engines / weights 218 Diesel engines / weights 219 Dimensions 220

Identication markings 221

Audio equipment and telematics

emergency or assistance 223 7-inch Touch screen 225 Audio system / Bluetooth 297 Audio system 323

Alphabetical index

Overview

exterior

Remote control key 43-49

- opening / closing

- anti-theft protection

- guide-me-home lighting

- starting

- battery

Lighting controls 113-119 LeD lamps 117 Daytime running lamps 117 Headlamp beam adjustment 120 Cornering lighting 121 Changing bulbs 169-174

- front lamps

- foglamps

- direction indicator repeaters

Door mirrors 63-64

Doors 43-48

- opening / closing

- central locking

- emergency control Alarm 50-51 electric windows 52-53

Panoramic sunroof 55 Roof bars 191 Accessories 193-194

electronic stability programme 133-135 Snow chains 168 Tyre pressures 221 Changing a wheel 161-167

- tools

- removing / refitting

Wipers 122-125 Changing a wiper blade 125, 186

Boot 54

- opening / closing

- emergency release Temporary puncture repair kit 156-160

Park Assist 107-110 Parking sensors 111-112 Towbar 189-190 Towing 187-188

Changing bulbs 173-175

- rear lamps

brake lamp

- 3

- number plate lamps

- foglamp

Fuel tank, misfuel prevention 199-202 Running out of Diesel fuel 203

Interior

Boot fittings 78-79

- rear parcel shelf

- hooks

- boot lamp

- lashing rings

Child seats 143-154 ISOFIX child seats 151-154 electric child lock 155

Bench rear seat 59-60 Rear seats 61

Front seats 56-58 Front armrest 58

Overview

Interior fittings 74-77

- glove box

- 12 V accessory socket

- uSB port / Auxiliary socket

- mats Deactivating the passenger's front

airbag 140

Airbags 139-142

Seat belts 136-138 Warning triangle 80

Overview

Instruments and controls

Touch screen 28-31, 225-296

Bluetooth audio system 297-322

Audio system 323-338

Setting the date/time 42

glove box fuses 179-180

Opening the bonnet 196

uSB port / Auxiliary socket 76

Courtesy lamps 126 Interior mood lighting 127 Rear view mirror 64 emergency or assistance call 129, 223

Manual parking brake 82

Heating, ventilation 65-68 Manual air conditioning 68-69 Dual-zone air conditioning 70-72 Front demisting / defrosting 73 Rear screen demist/defrost 73

Dashboard fuses 176-179

Door mirrors 63-64 electric windows, deactivating 52-53

Manual gearbox 83 gear shift indicator 84 5-speed electronic gearbox 85-88 6-speed electronic gearbox 89-92 Automatic gearbox 93-96 Stop & Start 97-99 Hill start assist 100

Instruments and controls (cont.)

Overview

Trip computer with touch screen 40-41 Setting the date and time with

the touch screen 42

Lighting controls 113-119 Direction indicators 128

Hazard warning lamps 128 Locking/unlocking from inside 47

Memorising speeds 105 Speed limiter 101-102 Cruise control 103-104

Instrument panels 14-15 Warning lamps 16-27 Indicators 32-37 Touch screen 28-31 gear shift indicator 84

Stop & Start 97-99 Alarm 50-51 Park Assist 107-110 Parking sensors 111-112

Headlamp beam adjustment 120

Wiper controls 122-125 Trip computer 38-39, 41

Steering wheel adjustment 62 Horn 129

Overview

Maintenance - Technical data

AdBlue additive 204-211 Checking levels 212-214

- oil

- brake fluid

- coolant

- screenwash fluid

- additive (Diesel with particle emissions filter)

Checking components 215-216

- battery

- air / passenger compartment filter

- oil filter

- particle emissions filter (Diesel)

- brake pads / discs

Changing bulbs 169-175

- front

- rear

Running out of fuel, Diesel 203

Opening the bonnet 196 under the bonnet, petrol 197 under the bonnet, Diesel 198 Petrol engines 217-218 Diesel engines 217, 219

12V battery 182-184 Load reduction, economy mode 185 engine compartment

fuses 176-177, 181

Petrol weights 217-218 Diesel weights 217, 219

Identification markings 221 Dimensions 220

Overview

Dashboard and centre console

Overview

1. Cruise control / speed limiter controls.

2. Steering mounted controls for the touch

screen.

3. Wiper / screenwash / trip computer stalk.

4. Driver's front airbag.

Horn.

5. Lighting and direction indicator stalk

6. Bonnet release lever.

7. Steering wheel adjustment control.

8. Headlamp height adjustment.

9. Switch panel: A. Deactivation of the rear parking sensors

or Activation of Park Assist.

B. Deactivation of the DSC/ASR system. C. Deactivation of the Stop & Start system. D. Reinitialisation of the under-inflation

detection system.

E. Deactivation of the volumetric alarm

monitoring.

F. Activation of the electric child lock.

10. Side adjustable air vents.

11. Front side window demisting/defrosting

vent.

12. Instrument panel.

13. Windscreen demisting/defrosting vent.

14. Sunshine sensor.

15. glove box / Passenger's front airbag

deactivation.

16. Passenger's front airbag.

17. Multifunction screen / Audio system.

18. Central adjustable air vents.

19. Central locking and hazard warning

buttons.

20. Heating / air conditioning controls.

21. 12 V accessory socket. uSB port .

uSB port / auxiliary JACK socket.

22. Open storage. Cup holder.

23. gear lever.

24. Central armrest with storage.

25. Parking brake.

Eco-driving

eco-driving

eco-driving is a range of everyday practices that allow the motorist to optimise their fuel consumption and CO2 emissions.

Optimise the use of your gearbox

With a manual gearbox, move off gently and change up without waiting. During acceleration change up early.

With an automatic or electronic gearbox, give preference to automatic mode and avoid pressing the accelerator pedal heavily or suddenly.

The gear shift indicator invites you engage the most suitable gear: as soon as the indication is displayed in the instrument panel, follow it straight away. For vehicles fitted with an electronic or automatic gearbox, this indicator appears only in manual mode.

Drive smoothly

Maintain a safe distance between vehicles, use engine braking rather than the brake pedal, and press the accelerator progressively. These practices contribute towards a reduction in fuel consumption and CO emissions and also helps reduce the background traffic noise.

If your vehicle has cruise control, make use of the system at speeds above 25 mph (40 km/h) when the traffic is flowing well.

Control the use of your electrical equipment

Before moving off, if the passenger compartment is too warm, ventilate it by opening the windows and air vents before using the air conditioning. Above 30 mph (50 km/h), close the windows and leave the air vents open. Remember to make use of equipment that can help keep the temperature in the passenger compartment down ( s unroof and window blinds...). Switch off the air conditioning, unless it has automatic regulation, as soon as the desired temperature is attained. Switch off the demisting and defrosting controls, if not automatic. Switch off the heated seat as soon as possible.

Switch off the headlamps and front foglamps when the level of light does not require their use.

Avoid running the engine before moving off, particularly in winter; your vehicle will warm up much faster while driving.

As a passenger, if you avoid connecting your multimedia devices (film, music, video game...), you will contribute towards limiting the consumption of electrical energy, and so of fuel. Disconnect your portable devices before leaving the vehicle.

.Eco-driving

Limit the causes of excess consumption

Spread loads throughout the vehicle; place the heaviest items in the bottom of the boot, as close as possible to the rear seats. Limit the loads carried in the vehicle and reduce wind resistance (roof bars, roof rack, bicycle carrier, trailer...). use a roof box in preference. Remove roof bars and roof racks after use.

At the end of winter, remove snow tyres and refit your summer tyres.

Observe the recommendat ions on maintenance

Check the tyre pressures regularly, when cold, referring to the label in the door aperture, driver's side. Carry out this check in particular:

- before a long journey,

- at each change of season,

- after a long period out of use. Don't forget the spare wheel and the tyres on any trailer or caravan.

Have your vehicle serviced regularly (engine oil, oil filter, air filter, passenger compartment filter...) and observe the schedule of operations recommended in the warranty and maintenance record.

With a Blue HDi Diesel engine, if the SCR system is faulty your vehicle becomes polluting; go to a PeugeOT dealer or a qualified workshop without delay to have the emissions of nitrous oxides brought back to the legal level.

When refuelling, do not continue after the third cut-off of the nozzle to avoid any overflow.

At the wheel of your new vehicle, it is only after the first 1 800 miles (3 000 kilometres) that you will see the fuel consumption settle down to a consistent average.

Monitoring

LCD instrument panel

Dials and screens Control buttons

1. engine coolant temperature gauge.

2. Rev counter (x 1 000 rpm or tr/min),

graduation according to engine (petrol or Diesel).

3. engine oil level indicator*.

4. gear shift indicator for a manual gearbox

or gear lever position and gear for an electronic or automatic gearbox.

5. Digital speedometer (mph or km/h) This can be switched off with a long press

on B.

6. Cruise control or speed limiter settings.

7. Service indicator, then total distance

recorder (miles or km).

These functions are displayed successively

on switching on the ignition.

8. Trip distance recorder (miles or km).

9. Analogue speedometer (mph or km/h).

10. Fuel gauge.

A. general lighting dimmer. B. Recalling the service information.

Resetting the function selected (service

indicator or trip distance recorder). Setting the time. Switching the digital speedometer on and

off.

* Depending on version.

Monitoring

Active matrix instrument panel

Dials and screens Control buttons

1. engine coolant temperature gauge.

2. Rev counter (x 1 000 rpm or tr/min),

graduation according to engine (petrol or Diesel).

3. Cruise control or speed limiter settings.

4. gear shift indicator for a manual gearbox

or gear lever position and gear for an electronic or automatic gearbox.

5. Speedometer (mph or km/h).

6. Service indicator, then total distance

recorder (miles or km).

These functions are displayed successively

on switching on the ignition.

7. Trip distance recorder (miles or km).

8. Analogue speedometer (mph or km/h).

9. Fuel gauge.

A. Main lighting dimmer. B. Instrument panel mood lighting. C. Recall of the service information.

Reset the selected function (service

indicator or trip distance recorder).

Monitoring

Indicator and warning lamps

Visual indicators informing the driver that a system is switched on (indicator or deactivation lamp) or has a fault (warning lamp).

When the ignition is switched on

Certain warning lamps come on for a few seconds in the instrument panel and/or instrument panel screen when the vehicle's ignition is switched on. When the engine is started, these same warning lamps should go off. If they remain on, before moving off, refer to the information on the warning lamp concerned.

Associated warnings

The switching on of certain warning lamps may be accompanied by an audible signal and a message in the instrument panel or multifunction screen. The warning lamps may come on continuously (fixed) or flash.

Certain warning lamps may come on in one of two modes. Only by relating the type of lighting to the operating status of the vehicle can it be ascertained whether the situation is normal or whether a fault has occurred.

Monitoring

Operation indicator lamps

If one of the following indicator lamps comes on in the instrument panel and/or instrument panel screen, this confirms that the corresponding system has come into operation.

Warning / indicator lamp State Cause Action / Observations

Left-hand direction indicator

Right-hand direction indicator

Sidelamps fixed. The lighting stalk is in the

Dipped beam headlamps

Main beam headlamps

Front foglamps

Rear foglamp

flashing with buzzer. The lighting stalk is pushed down.

flashing with buzzer. The lighting stalk is pushed up.

"Sidelamps" position.

fixed. The lighting stalk is in the "Dipped

beam headlamps" position.

fixed. The lighting stalk is pulled towards

you.

fixed. The front foglamps are switched on

using the ring on the lighting control stalk.

fixed. The rear foglamp is switched on

using the ring on the lighting control stalk.

Pull the stalk to return to dipped beam headlamps.

Turn the ring on the lighting control stalk rearwards twice to switch off the front foglamps.

Turn the ring on the lighting control stalk rearwards to switch off the rear foglamp.

For more information on the lighting controls, refer to the corresponding section.

Monitoring

Warning / indicator lamp State Cause Action / Observations

Diesel engine pre-heating

Parking brake fixed. The parking brake is applied or not

Foot on the brake pedal

fixed. The ignition switch is at the

2nd position (ignition on).

properly released.

fixed. The brake pedal must be pressed. With an electronic gearbox, press the brake pedal to

flashing. With an electronic gearbox, if you

hold the vehicle on an incline using the accelerator for too long, the clutch overheats.

Wait until the warning lamp goes off before starting. The period of illumination of the warning lamp is determined by the climatic conditions (up to about thirty seconds in extreme climatic conditions). If the engine does not start, switch the ignition off and then on, wait until the warning lamp goes off again, then start the engine.

Release the parking brake to switch off the warning lamp, keeping your foot on the brake pedal. Observe the safety recommendations. For more information on the parking brake, refer to the corresponding section.

start the engine (lever in position N). With an automatic gearbox, with the engine running, press the brake pedal before releasing the parking brake, to unlock the lever and come out of position P. If you wish to release the parking brake without pressing the brake pedal, this warning lamp will remain on.

use the brake pedal and/or the parking brake.

Monitoring

Warning / indicator lamp State Cause Action / Observations

Foot on the clutch*

Stop & Start fixed. When the vehicle stops (red lights,

Automatic wiping

fixed. In the STOP mode of Stop & Start,

flashes for a few seconds, then goes off.

fixed. The wiper control is pushed

changing to START mode is refused because the clutch pedal is not fully down.

traffic jams, ...) the Stop & Start system has put the engine into STOP mode.

STOP mode is temporarily unavailable. or START mode is invoked automatically.

downwards.

You must declutch fully to allow the change to engine START mode.

The warning lamp goes off and the engine restarts automatically in START mode, as soon as you want to move off.

For more information on special cases with STOP mode and START mode, refer to the "Stop & Start" section.

Automatic front wiping is activated. To deactivate automatic wiping, operate the control stalk downwards or put the stalk into another position.

* except for the active matrix instrument panel.

Monitoring

Deactivation indicator lamps

If one of the following indicator lamps comes on, this confirms that the corresponding system has been switched off intentionally. This is may be accompanied by an audible signal and a message in the screen.

Warning / indicator lamp State Cause Action / Observations

Passenger's airbag system

fixed. The control, located in the glove box,

is set to the OFF position. The passenger's front airbag is deactivated. In this case you can install a "rear facing" child seat.

Set the control to the ON position to activate the passenger's front airbag. In this case, do not fit a child seat in the rear-facing position.

Monitoring

Warning lamps

When the engine is running or the vehicle is being driven, illumination of one of the following warning lamps indicates a fault which requires action on the part of the driver. Any fault resulting in the illumination of a warning lamp must be investigated further by reading the associated message in the screen. If you encounter any problems, contact a PeugeOT dealer or a qualified workshop.

Warning / indicator lamp State Cause Action / Observations

STOP fixed, associated with

another warning lamp.

Service fixed, associated with

another warning lamp.

fixed associated with a message (if a display screen is fitted).

It is associated with the engine oil pressure or the engine coolant temperature.

Major faults have occurred. Refer to the section on this warning lamp and you

Faults have occurred for which there is no specific warning lamp.

Stop as soon as it is safe to do so. Park, switch off the ignition and call a PeugeOT dealer or qualified workshop.

must then contact a PeugeOT dealer or qualified workshop.

Identify the fault by reading the message shown in the screen (if a display screen is fitted) and refer to the corresponding section:

- engine oil level alert,

- risk of blockage of the particle emissions filter (Diesel).

- Diesel fuel additive level (Diesel with particle emissions filter),

You must contact a PeugeOT dealer or a qualified workshop.

Monitoring

Warning / indicator lamp State Cause Action / Observations

Braking fixed. The braking system fluid level has

Maximum coolant temperature

Anti-lock Braking System (ABS)

fixed, associated with the ABS warning lamp.

fixed with the needle in the red zone.

fixed. The anti-lock braking system has a

dropped significantly.

The electronic brake force distribution (eBFD) system has a fault.

The temperature of the cooling system is too high.

fault.

You must stop as soon as it is safe to do so. Top up with brake fluid listed by PeugeOT. If the problem persists, have the system checked by a PeugeOT dealer or a qualified workshop.

You must stop as soon as it is safe to do so. Have it checked by a PeugeOT dealer or a qualified workshop.

Stop as soon as it is safe to do so. Wait until the engine has cooled down before topping up the level, if necessary. If the problem persists, contact a PeugeOT dealer or a qualified workshop.

The vehicle retains conventional braking. Drive carefully at reduced speed and contact a PeugeOT dealer or a qualified workshop without delay.

Monitoring

Warning / indicator lamp State Cause Action / Observations

Dynamic stability control (DSC/ASR)

Power steering fixed. The power steering has a fault. Drive carefully at reduced speed.

Engine autodiagnosis system

flashing. The DSC/ASR regulation is

fixed. The DSC/ASR system has a fault. Have it checked by a PeugeOT dealer or a qualified

fixed. The emission control system has a

flashing. The engine management system has

fixed, associated with the SeRVICe warning lamp.

fixed, associated with the STOP warning lamp.

operating.

fault.

a fault.

A minor engine fault has been detected.

A major engine fault has been detected.

The system optimises traction and improves the directional stability of the vehicle in the event of loss of grip or trajectory.

workshop.

Have it checked by a PeugeOT dealer or a qualified workshop.

The warning lamp should go off when the engine is started. If it does not go off, contact a PeugeOT dealer or qualified workshop without delay.

Risk of destruction of the catalytic converter. Have it checked by a PeugeOT dealer or a qualified workshop.

Have it checked by a PeugeOT dealer or a qualified workshop.

You must stop as soon as it is safe to do so. Park, switch off the ignition and contact a PeugeOT dealer or a qualified workshop.

Monitoring

Warning / indicator lamp State Cause Action / Observations

AdBlue

additive

(BlueHDi Diesel)

fixed, on switching on the ignition, accompanied by an audible signal and a

The remaining driving range is between 350 miles (600 km) and 1500 miles (2400 km).

Have the AdBlue as possible: go to a dealer PeugeOT or a qualified workshop, or carry out this operation yourself by referring to the corresponding section.

additive tank topped up as soon

message indicating the remaining driving range.

+ flashing associated with

the SeRVICe warnin g lamp, accompanied by an audible signal and a

The remaining driving range is between 0 and 375 miles (600 km).

You must top-up the AdBlue a breakdown: go to a dealer PeugeOT or a qualified workshop, or carry out this operation yourself by

referring to the corresponding section. message indicating the remaining driving range.

additive tank to avoid

flashing, associated with the SeRVICe warnin g lamp, accompanied by an audible signal and a message indicating that starting is prevented.

The AdBlue

tank is empty: the starting inhibition system required by legislation prevents starting of the engine.

To be able to start the engine, you must top-up the

AdBlue

additive tank: go to a dealer PeugeOT or a qualified workshop, or carry out this operation yourself by referring to the corresponding section. It is essential to add at least 3.8 litres of AdBlue

the tank.

Monitoring

Warning / indicator lamp State Cause Action / Observations

SCR emissions control system (Blue HDi Diesel)

fixed, on switching on the ignition, associated with the SeRVICe and engine diagnostic warning lamps, accompanied by an audible signal and a message indicating an emissions control fault.

flashing, on switching on the ignition, associated with the SeRVICe and engine diagnostic warning lamps, accompanied by an audible signal and a message indicating the remaining driving range.

flashing, on switching on the ignition, associated with the SeRVICe and engine diagnostic warning lamps, accompanied by an audible signal and a message indicating that starting is prevented.

A fault with the SCR emissions control system has been detected.

The remaining driving range is between 0 and 650 miles (1 100 km).

You have exceeded the authorised driving limit: the starting inhibition system prevents starting of the engine.

This alert disappears once the exhaust emissions return to normal levels.

Contact a PeugeOT dealer or a qualified workshop without delay.

To be able to start the engine, you must call on a PeugeOT dealer or a qualified workshop.

Monitoring

Warning / indicator lamp State Cause Action / Observations

Low fuel level fixed with the needle

Engine oil pressure

Battery charge fixed. The battery charging circuit has a

Under-inflation fixed. The pressure in one or more wheels

+ flashing then fixed,

in the red zone.

flashing with the needle in the red zone.

fixed. There is a fault with the engine

accompanied by the Service warning lamp.

There remains approximately 5 litres of fuel in the tank. At this point, you begin to use the fuel reserve.

There remains very little fuel in the tank.

lubrication system.

fault (dirty or loose terminals, slack or cut alternator belt, ...).

is too low.

The tyre pressure monitoring system has a fault or no sensor is detected on one of the wheels.

Refuel as soon as possible to avoid running out of fuel. This warning lamp will come on every time the ignition is switched on, until a sufficient addition of fuel is made. Fuel tank capacity: approximately 50 litres. Never continue to drive until you run out of fuel, as this could damage the emission control and injection systems.

You must stop as soon it is safe to do so. Park, switch off the ignition and contact a PeugeOT dealer or a qualified workshop.

The warning lamp should go off when the engine is started. If it does not go off, contact a PeugeOT dealer or a qualified workshop.

Check the pressure of the tyres as soon as possible. This check should preferably be carried out when the tyres are cold.

under-inflation detection is not assured. Have the system checked by a PeugeOT dealer or a qualified workshop.

Monitoring

Warning / indicator lamp State Cause Action / Observations

Door(s) open fixed, associated with

Seat belt(s) not fastened / unfastened

Airbags on temporarily. This lamp comes on for a

a message identifying the door, if the speed is below 6 mph (10 km/h).

fixed, associated with a message identifying the door, and accompanied by an audible signal if the speed is above 6 mph (10 km/h).

fixed then flashing accompanied by an increasing audible signal.

fixed. One of the airbag or seat belt

A door or the boot is still open. Close the door or boot.

A seat belt has not been fastened or has been unfastened.

few seconds when you turn on the ignition, then goes off.

pretensioner systems has a fault.

Pull the strap then insert the tongue in the buckle.

This lamp should go off when the engine is started. If it does not go off, contact a PeugeOT dealer or a qualified workshop.

Have it checked by a PeugeOT dealer or a qualified workshop.

Monitoring

Touch screen

It gives access to:

- menus for adjusting settings for vehicle functions and systems,

- audio and display configuration menus,

- audio system and telephone controls and the display of associated information.

And, depending on equipment, it allows:

- the display of alert messages and the visual parking sensors information,

- access to the controls for the navigation system and Internet services, and the display of associated information.

For reasons of safety, the driver should only carry out operations that require close attention, with the vehicle stationary.

Some functions are not accessible when driving.

General operation

Recommendations

It is necessary to press firmly, particularly for "flick" gestures (scrolling through lists, moving the map...). A light wipe is not enough. The screen does not recognise pressing with more than one finger. This technology allows use at all temperatures and when wearing gloves. Do not use pointed objects on the touch screen. Do not touch the touch screen with wet hands. uses a soft clean cloth to clean the touch screen.

State of indicator lamps

Some buttons contain an indicator lamp that gives the state of the corresponding function. green indicator: you have switched on the corresponding function. Orange indicator: you have switched off the corresponding function.

Principles

Press the "MENU" button for access to the different menus, then press the virtual buttons in the touch screen. each menu is displayed over one or two pages (primary page and secondary page).

use this button to go to the secondary page.

use this button to return to the primary page.

After a few moments with no action on the secondary page, the primary page is displayed automatically.

use this button for access to additional information and to the settings for certain functions.

use this button to confirm.

use this button to quit.

+ 322 hidden pages
