SETUP
1. Connect included USB-C cable to Link I/O.
2. Connect other end of USB-C cable to external device. Link I/O status LED will illuminate blue to indicate that it’s receiving power.
3. Connect an instrument to Link I/O’s 1/4” input jack using a 1/4” mono instrument cable.
4. Launch preferred app on external device. For computers, ensure that Link I/O is set as both input and output device for the app
in use.
5. Connect headphones, mixer or powered speakers to Link I/O’s 1/8” headphone jack.
2 4
5
1
3
CONNECTING TO A COMPUTER
No external driver is needed to connect to an Apple computer. For online assistance with Windows USB recording, visit
“Connected Amps” at https://support.fender.com.
CONNECTING TO LIGHTNING-EQUIPPED IOS DEVICES
When connecting an IOS phone or tablet with a Lightning cable port, a Lightning to USB 3 Camera Adapter may be required to
support bus power.
SPECIFICATIONS
TYPE PR 6208 DIGITAL CONNECTION USB-C
POWER Bus powered BIT DEPTH 24 bit
INPUT TYPE 1/4” TS female unbalanced SAMPLE RATES 44.1, 48, 88.2, 96 kHz
INPUT IMPEDANCE 1MΩ DYNAMIC RANGE 107 dB ADC, 107 dB DAC
MAX LEVEL 1.0Vrms (pad o), 2.8Vrms (pad on) DIGITAL FREQ RESPONSE 20 Hz-20 kHz, +0.1/- 0.7dB
PAD 0dB (pad o), -9dB (pad on) OS REQUIREMENTS PC: Windows 10 or later (requires ASIO driver install)
OUTPUT TYPE 1/8” TRS female, stereo Android: 5 or later
MIN LOAD IMPEDANCE 16Ω x2 MAC: OS X 10.9 or later, latest iPhone/iPad models
MAX OUTPUT POWER 25mW/channel @32Ω (Apple smart phones and tablets with Lightning ports
OUTPUT FREQ RESPONSE 20 Hz-20 kHz, +0.6/-1.0 dB may require a Lightning to USB 3 Camera Adapter)
Product specications subject to change without notice.
2
Page 4
PART NUMBERS / REFERENCIAS / RÉFÉRENCE / NÚMERO DAS PEÇAS / NUMERO PARTI / TEILENUMMERN
NUMERY REFERENCYJNE / REFERENČNÍ ČÍSLA / REFERENČNÉ ČÍSLA / REFERENČNE ŠTEVILKE / 部品番号 / 型号
零件號 / НОМЕРА НА ЧАСТИ / BROJEVI DIJELOVA / ONDERDEELNUMMERS / OSANUMBRID / OSIEN NUMEROT
ARITHMOI MEROS / DAĻU NUMURI / DALIŲ NUMERIAI / NUMERE DE PIESĂ / ARTIKELNUMMER
FENDER LINK I/O™ USB AUDIO INTERFACE
2313000000 US, CAN, EU, AU, JP
2313140000 MX
2313150000 CN
Additional manual translations available at www.fender.com/Support
产品中有害物质的名称及含量
有害物质
部件名称
箱体
喇叭单元*
电子部分
接线端子
电线
附件
本表格依据 SJ/T 11364 的规定编制。
O： 表示该有毒有害物质在该部件所有均质材料中的含量均在 GB/T 26572 规定的限量要求以下。
X： 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 GB/T 26572 规定的限量要求。
注： 含有有害物质的部件由于全球技术发展水平限制而无法实现有害物质的替代。
*产品含有喇叭单元时有效。
铅
(Pb)
O
O
X
X
X
O
汞
(Hg)
O
O
O
O
O
O
镉
(Cd)
O
O
X
O
O
O
六价铬
(Cr(VI))
O
O
O
O
O
O
多溴联苯
(PBB)
O
O
O
O
O
O
多溴二苯醚
(PBDE)
O
O
O
O
O
O
A PRODUCT OF
FENDER MUSICAL INSTRUMENTS CORP.
311 CESSNA CIRCLE
CORONA, CALIF. 92878 U.S.A.
FENDER (EDC) B.V.
Transpolispark, Siriusdreef 17-27, Hoofddorp, 2132 WT
TRANSMISORRECEPTOR DIGITAL DE AUDIO
IMPORTADO POR: Fender Ventas de México, S. de R.L. de C.V.
Calle Huerta #279, Int. A. Col. El Naranjo. C.P. 22785. Ensenada, Baja California, México.
RFC: FVM-140508-CI0
Servicio al Cliente: 01(800) 7887395, 01(800) 7887396, 01(800) 7889433
Fender® and Link I/O™ are trademarks of FMIC.
Other trademarks are property of their respective owners.
Copyright © 2025 FMIC. All rights reserved.
PN 70-12000351 ENGLISH REV. A
