Fender 1270P Operation Manual

127

Powered Monitor

ENGLISH - PAGES 4-5

Fender amplifiers and loudspeaker systems are capable of producing very high sound pressure levels which may cause temporary or permanent hearing damage. Use care when setting and adjusting volume levels during use.

ESPANOL - PAGINAS 6-7

Niveles elevados de la intensidad de sonido pueden causar continuos da os auditivos; por ello debe evitar acercarse demasiado a altavoces que funcionen a altos niveles. En tales casos utilice protecciones auditivas.

Este símbolo tiene el propósito de alertar al usuario de la presencia de voltaje peligroso que no tiene aislamiento dentro de la caja.

Este símbolo tiene el propósito de alertar al usario de la presencia de instruciones importantes sobre la operación y mantenimiento en la literatura que viene con el producto.

This symbol warns the user of dangerous voltage levels localized within the enclosure.

This symbol advises the user to read all accompanying literature for safe operation of the unit.

Ce symbole est utilisé pur indiquer à l'utilisateur la présence à l'intérieur de ce produit de tension non-isolée dangereuse.

Ce symbole est utilisé pour indiquer à l'utilisateur qu'il ou qu'elle trouvera d'importantes instructions sur l'utilisation et l'entretien (service) de l'appareil dans la littérature accompagnant le produit.

L’apparecchio viene utilizzato come indicato nel libretto delle istruzioni per l’uso.

L’apparecchio contrassegnate dai caratteri (vedi illustrazione) possono essere conduttrici di tensione pericolosa con cui evitare il contatto.

Dieses Symbol soll den Anwender vor unisolierten gefährlichen Spannungen innerhalb des Gehäuses warnen.

Dieses Symbol soll den Benutzer auf wichtige Instruktionen in der Bedienungsanleitung aufmerksam machen, die Handhabung und Wartung des Produkts betreffen.

FRANCAIS - PAGES 8-9

Les Niveaux de puissance l v s peuvent entrainer des l sions auditives durables. Evitez donc la proximit de haut-parleurs utilis s haute puissance. Lors de haute puissance continue utilisez une protection auditive.

ITALIANO - PAGINE 10-11

L’ascolto di suoni ad alto volume pu provocare danni permanenti all’udito. Evitate perci la diretta vicinanza con altoparlanti ad alta emissione di suono e utilizzate cuffie protettive in caso ci non sia possibile.

DEUTSCH - SEITEN 12-13

Hohe Lautst rkepegel k nnen dauernde Geh rsch den verursachen. Vermeiden Sie deshalb die direkte N he von Lautsprechern, die mit hohen Pegeln betrieben werden. Verwenden Sie einen Geh rschutz bei dauernder Einwirkung hoher Pegel.

14-15

To prevent damage, fire or shock hazard, do not expose this unit to rain or moisture. No user serviceable parts inside, refer servicing to qualified personnel only. Do not alter the AC plug. This unit must be earth grounded. Unplug the AC power line cord before cleaning the unit s exterior (use a damp cloth only). Wait until the unit is completely dry before reconnecting it to power.

WARNING: Exercise caution when servicing this unit. This unit is not completely disconnected from the power source when the power switch is in the OFF position and the power indicator is not lit. In some applications, the power cord is not polarized and the hot and neutral lines may be reversed in use. Consult qualified service personnel.

Para evitar da os, incendios y descargas el ctricas, no exponga esta unidad a la lluvia ni a la humedad.

Contiene piezas cuyo mantenimiento no lo puede realizar el usuario, sino s lo personal cualificado.

No modifique el enchufe de CA.

Esta unidid debe conectarse con toma de tierra.

Desconecte el cable de alimentaci n de CA antes de limpiar la cubierta de la unidad espere a que la unidad est completamente seca antes de volver a conectarla a la corriente.

ADVERTENCIA: Tome las precauciones necesarias cuando realice las operaciones de mantenimiento de esta unidad. A pesar de que el interruptor est en posici n de apagado y el indicador de corriente no se encuentre encendido, la unidad no estar completamente desconectada de la fuente de alimentaci n. En algunas aplicaciones, el conector del cable de alimentaci n no est polarizado y es posible que se invierta la utilizaci n de las l neas ’activas’ y ’neutras’. Consulte con personal cualificado para efectuar el mantenimiento.

Pour eviter l endoummagement de l appareil, un depart d incendie, ou un choc electrique, ne l exposez jamais a l humidite ou a la pluie.

Aucune maintenance ne doit etre effectuee pour les pieces situees dans l appareil. Les reparations et la maintenance doivent etre executees uniquement par un personnel qualifie.

Ne modifiez pas la prise de CA. Cet appareil doit etre mis a la terre. Debranchez le cable d alimentation avant de nettoyer le

boitier de l appareil et attendez que l appareil soit completement sec avant de sl rebrancher sur le secteur.

AVERTISSEMENT : Veuillez prendre des pr cautions lors de l’entretien de cet appareil. M me si l’interrupteur est en position OFF et que le t moin d’alimentation n’est pas allum , cela ne signifie pas que cet appareil est compl tement d connect de la source d’alimentation. Dans certaines applications, la fiche du cordon d’alimentation n’est pas polaris e et les lignes "chaud" et "neutre" peuvent tre invers es durant l’utilisation. Veuillez consulter un personnel qualifi .

Per evitare danni, rischi di incendi o scosse elettriche, non esporre questa unit alla pioggia o all’umidit .

Non contiene parti riparabili dall’utente: fare eseguire la manutenzione soltanto da personale qualificato.

Non alterare la presa C.A.

Questa unit deve essere collegata a terra.

Disconnettere il cavo di alimentazione c.a. prima di pulire la copertura dell’unit ; attendere che l’unit sia completamente asciutta prima di ricollegarla all’alimentazione.

ATTENZIONE: Intervenire sull’unit con la dovuta cautela. Anche se l’interruttore di alimentazione in posizione OFF e la spia di alimentazione non accesa, l’unit non completamente disinserita dalla fonte di alimentazione. In alcuni casi la spina del cavo di alimentazione non polarizzata ed possibile un’inversione della linea "calda" e quella del neutro. Rivolgersi a personale di assistenza qualificato.

Setzen sie dieses ger t niemals regen oder feuchtigkeit aus, um besch digung, brandentwicklung und elektrische schl gen zu vermeiden.

Im ger t sind keine zu wartenden teile. Wartung und reperaturen d rfen nur von qualifizierten technikern durchgef hrt werden.

Manipulieren sie auf keinen fall die netzanschlussbuchse.

Das ger t muss geerdet sein.

Stecken sie das netzkabel aus, bevor sie das geh use des ger ts reinigen. Schliessen sie das ger t erst wieder ans stromnetz an, wenn es vollst ndig getrocknet ist.

WARNHINWEIS: Beim Warten des Ger ts vorsichtig vorgehen. Dieses Ger t ist nicht vollst ndig von der Stromquelle getrennt, auch dann, wenn der Netzschalter ausgeschaltet ist (Position OFF) und die Stromanzeige nicht aufleuchtet. Bei manchen Anwendungen ist das Netzkabel nicht polarisiert und die Leitungen ªHot" (Stromf hrend) und ªNeutral" k nnen beim Gebrauch vertauscht sein. Mit qualifiziertem Wartungspersonal Verbindung aufnehmen.

Your new 11227700PP Powered Monitor delivers the professional quality and performance that has established

Fender as a respected leader in the music industry for over 50 years. The self-powered version of the 1270

stage monitor, your 11227700PP is equipped with its own 100-watt bi-amplifier which feeds the 10-inch woofer and

piezoelectric compression driver independently for clean, full-spectrum response. The control panel

(FIGURE A) accepts a variety of input sources with 3 different jacks; 1) LINE: 1/4—inch phone jack for

balanced or unbalanced line-level input, 2) AMP IN: 1/4—inch phone jack for unbalanced line-level input

and 3) MIC: XLR jack for balanced mic-level input (full-time 15—volt phantom power supplied). The LINE

OUT jack serves as an unbalanced line-level signal feed-through which can be used to connect multiple

11227700PP monitors in a daisy chain configuration. The LINE and MIC inputs are affected by LEVEL and TONE

controls while the AMP IN input is unaffected. The durable one-piece cabinet is made of ABS plastic and has

rubber feet on three sides to provide cabinet

placement at three different listening angles.

A. IEC LINE CORD CONNECTOR - The power

line cord must be connected to a grounded AC

receptacle in accordance with the voltage and

frequency ratings as listed on the 11227700PP

control panel under INPUT POWER.

B. POWER - Turn ON/OFF the 11227700PP with this

rocker switch.

C. POWER INDICATOR - Illuminates when the

11227700PP is receiving power.

D. LINE - Input jack for a balanced or unbalanced

line-level signal. Use a standard 1/4 TRS (Tip,

Ring, Sleeve) plug.

E. MIC - Input jack for a balanced, mic-level

signal. Use a standard XLR mic plug. Full-time

15-volts phantom power is supplied.

F. AMP IN - Input jack for an unbalanced, line-

level signal. Use a standard 1/4 TS (Tip,

Sleeve) plug. The LEVEL {H} and TONE {I}

controls do not affect this input. Adjustments

must be made at the signal source.

G. LINE OUT - Output jack which supplies an

unbalanced line-level signal from any of the

three inputs. LEVEL {H} and TONE {I} affect the signal from the LINE jack {D} and MIC jack {E} inputs.

Connect multiple 11227700PP monitors together by connecting this buffered LINE OUT jack to the AMP IN {F}

jack on another 11227700PP using a standard 1/4 TS patch cord.

H. LEVEL - Adjusts the signal level of the LINE jack {D} and MIC jack {E} inputs.

I. TONE - Adjusts the high-frequency range of the LINE jack {D} and MIC jack {E} inputs.

FFFFeeeennnnddddeeeerr

¤¤

1111222277770000PP

FIGURE A

PPPPoooowwwweeeerrrreeeedddd MMMMoooonnnniiiittttoooorr

SSSSppppeeeecccciiiiffffiiiiccccaaaattttiiiioooonnnnssss

CABINET PLACEMENT

The cabinet can be positioned at three different angles to accommodate various stage sizes and performer movements (Figure B).

25-degrees for small-size stages and for performers that stay close to the 11227700PP Monitor.

45-degrees for medium-size stages and for performers that move farther from their

11227700PP Monitor.

80-degrees for near-field use when the 11227700PP Monitor is placed on a pedestal raising it to ear level.

Reduce feedback potential by using cardioid pattern microphones and keeping them pointed away from speakers.

TYPE: PR 435 PART NUMBER: 071-1271-000 (120V, 60Hz) US, 071-1271-060 (230V, 50Hz) Eur,

071-1271-040 (230V, 50Hz) UK, 071-1271-030 (240V, 50Hz) Aust POWER REQUIREMENTS: 360W POWER OUTPUT: 100W, THD <0.5% (bi-amped) INPUTS: XLR balanced, mic-level (MIC input supplied with full-time 15V phantom power),

1/4” TRS balanced/unbalanced, line-level (LINE);

1/4” TS unbalanced, line level (AMP IN) OUTPUTS: 1/4” TS unbalanced, line-level (LINE OUT) FREQUENCY RESPONSE: 110Hz–20kHz MAXIMUM OUTPUT SPL at 1M: 109dB (continuous), 115dB (peak) INPUT SENSITIVITY: LINE: 100mV RMS, -20dBV, MIC: 10mV RMS, -40dBV

AMP IN: 1V RMS, 0dBV (LEVEL @ maximum for all three inputs) TONE CONTROL: +/-10dB at 12kHz LOW FREQUENCY DRIVER: One 10 in. 4 ohm woofer, with a 2” voice coil (P/N0055911000) HIGH FREQUENCY DRIVER: One Piezoelectric compression driver, with a 1 1/2” diaphragm (P/N 0055741000) CROSSOVER FREQUENCY: 2.2kHz COVERAGE ANGLE: 90 degrees symmetrical at 2kHz DIMENSIONS: Height: 13 3/8 in. (34 cm)

Width: 13 3/8 in. (34 cm)

Depth: 9 1/8 in. (23.2 cm) WEIGHT: 22 lbs. (10 kg)

Product specifications are subject to change without notice.

FIGURE B
