FENDA TECHNOLOGY W15BT User Manual

CANDY BOX

Universal Bluetooth Speaker

QAA14AV002
QAA14AV004

User Manual

R

Thank you for purchasing CANDY BOX Universal Bluetooth Speaker
for smart phones, tablets, notebook computers and other Bluetooth enabled
devices. This product combines high-tech innovation with design to provide
you with years of dependability and enjoyment.

Safety Precautions and Maintenance

Please read these operating and maintenance (servicing) instructions
before installing and operating your speaker.

Warning: To reduce the risk of fire or electric shock, do not expose
this speaker system to rain or moisture (including swimming pools or
objects filled with liquids, such as vases or drinks).

1 2 3 4 5 6

R

Important Safety Instructions

1. Always read Safety and Operation instructions before use. Retain
instructions for later reference.

2. For indoor use only. Do not expose the speaker to liquid, moisture or
humidity.

3. Do not use abrasive cleaners to clean the speaker case as they may
damage the finish. Always unplug the unit before cleaning.

4. Do not expose the speaker to extremely high or low temperatures.

5. Keep the unit away from direct sunlight.

6. Use only accessories and attachments as supplied and designated in
the instruction manual.

7. Do not attempt to open or modify the speaker in any way, as it does
not contain any serviceable parts. Please refer all servicing to
qualified personnel.

8. Please store the unit in a dry place that is free from extreme
temperatures and dust.

9. Always operate the speaker on a flat and level surface.

10. Always operate the speaker away from children and small animals as
they may play with the power cord and other small parts.

11. Always dispose of the packaging and the unit in accordance with the
local regulations and in a responsible manner.

The FCC Wants You To Know

Warning: Changes or modifications to this unit not expressly approved
by the party responsible for compliance could void the user’s authority
to operate the equipment.

NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:

Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.

Speaker Overview

1.Power Switch/Battery
status indicator

2.Volume down

3.Play/Pause button

4.Volume Up

5.TWS pairing indicator

6.Bluetooth indicator

8

9

7.Speaker Mode Switch

8.Charging Port

9.Line-in Audio Jack

Package Contents

Main unit x 1 User manual x 1
USB Charging Cord x 1

User Manual

Fenda Hi-tech Park, Zhoushi Road, Shiyan, Baoan, Shenzhen, China
Email: [e-mail]
www.ravon-audio.com

20140113

Q-experience

A0

W15BT-Grey/Blue

说明书(所有颜色共用）

Bluetooth connect

L-Mono-R

Move the speaker mode
switch to Mono.

Blue tooth

Blueto oth

Device s

Candy Box

On the Bluetooth device, switch on
Bluetooth and search for Candy Box.
For the first time connection, select
Candy Box to start connection.

7 8 9 10 11 12

Press and hold to switch on,
press and hold to switch off.

After your connection is
successful, you will hear “paired”.

Now you can begin to play music on your speaker.
Press “ ” “ ” to adjust volume, and press “ ” to
Pause or Play.

Play

Solid red light means the battery is charging.
Red light off means the charge is complete.
Note: When your battery is slow, the red light
will blink slowly.

Charge

Can be charged by
using the USB to
Micro USB cord
(included)
through computer or
AC adapter with
USB jack (not
included).
Approximately 3
hours required for
full charge.Note:
Battery will
last up to 5 hours
when connected
wirelessly.

Aux in

LINE-IN

Use a 3.5mm cable (not included) to connect the speaker to
another audio source. Press Play on the device and adjust the
volume on the unit to obtain the desired volume.
Note: Play/Pause controls on the unit will not work when using the
“Line-In” audio jack.

Extra:-- Pairing 2 Candy Box
Speakers together(Stereo):

Bluet ooth

Bluetoo th

Devices

Candy Box

L-Mono-R

1. Turn the speaker over and move the speaker mode switch to L.

2. Turn the 2nd speaker over and move the speaker mode switch to R.

3. Press and hold the power button for 5 seconds on the 1st speaker.

4. Press and hold the power button for 5 seconds on the 2nd speaker.

5. Speakers will begin to pair together automatically.

6. Pairing process can take up to 30 seconds. When you hear a “Steel Drum” tone and the
Candy Box 2 indicator light begins to slowly blink, you are ready to pair to your device.

7. Follow the instructions of your device to pair the speakers.

8. Pair your device with speakers by selecting “Candy Box 2” from the Bluetooth listings
on your device.

L-Mono-R

Features

Wirelessly stream music and movies anywhere up to 30 feet.

3.5mm line in jack for playing MP3 and other audio devices.

Passive radiator for rich bass.
Built in rechargeable lithium battery with up to 6 hours of

battery life.

Micro USB charging input.
Allows pairing two products together and creating a stereo

speaker pair (1 product per channel).

Technical Specifications

Transducers: 1 x 2-1/4” (57mm)
Amplifier power: 3W
Frequency response: 150Hz – 20kHz
Signal-to-noise ratio: ＞80dB
Battery type: Li-ion rechargeable
Bluetooth transmitter frequency range: 2.402 – 2.480GHz
Bluetooth transmitter power: 0 – 4dBm
Listening time on battery power: Up to 5 hours (Varies by volume
level and audio content)
Battery charge time: 2 hours
Dimensions (W x D x H): 83mm x 83mm x 95mm
