TABLE OF CONTENTS
Warnings and Cautions ........................................1
FCC Information .............................................5
Location of Parts and Controls ...............................7
Setting Up the Speaker ......................................8
Using the Nigh Light.........................................8
Pairing Your Device ..........................................9
Listening to Audio ..........................................11
Using Pair2 for Stereo or Left/Right Sound ..................12
Care and Maintenance ......................................15
Specifications ..............................................17
Troubleshooting.............................................18
Warranty ...................................................20
CAUTION
• TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER.
THERE ARE NO SERVICEABLE PARTS INSIDE.
• TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
The lightning flash with arrow-head symbol within
an equilateral triangle is intended to alert the user
to the presence of uninsulated “dangerous
voltage” within the unit’s enclosure that may be of
sufficient magnitude to constitute a risk of electric
shock.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and maintenance
accompanying the unit.
(servicing) instructions in the literature
IMP ORTANT SAFETY IN STRUCTIONS
All of the safety and operating instructions should be read,
adhered to and followed before the unit is operated.
1
917703_917725 INS Speak Out
Size:80mmWx80mmH_Output:100%_Prints:1/1,Blk
SAFETY AN D HANDLING INFORMATION
For maximum product life, do not drop, throw, or crush the
speaker. Do not expose it to humidity, dust, or operating
temperatures outside 25°F to 120°F (-4°C to 49°C).
SAVE THES E INSTRUCTION S
DANGER
To reduce the risk of electric shock, burns, fire or injury:
1. Do not use while bathing or in a shower.
2. Do not place or store unit where it can fall or be pulled
into a tub or sink.
3. Do not place in, drop or submerge in water or
other liquid.
4. Do not reach for a unit that has fallen into water.
Unplug it immediately.
5. Care should be taken so that objects do not fall and
liquids are not spilled onto the unit.
WARNING
1. Close supervision is necessary when this appliance/
product is used by or near children or mentally
disabled individuals.
2. Use this unit only for its intended use as described in
this manual.
3. Unplug this unit during lightning storms or when unused
for long periods of time.
4. Never drop or insert an object into any opening.
5. Protect the power cord from being walked on or pinched,
particularly at plug outlets, convenience receptacles and
the point where it exits the unit.
6. Do not allow cord to touch hot surfaces. Wrap cord loosely
around the unit when storing.
7. The unit should be situated away from direct sunlight
or heat sources such as radiators, electric heaters, heat
registers, stoves, or other units (including amplifiers) that
produce heat. Avoid placing on top of stereo equipment
that radiates heat.
2 3
917703_917725 INS Speak Out
Size:80mmWx80mmH_Output:100%_Prints:1/1,Blk
8. Never block the air openings of the unit with materials
such as clothing, plastic bags or papers, or place it on
a soft surface such as a bed or couch, where the air
openings may be blocked.
9. Do not overload the electrical outlet. Use only the power
source as indicated.
10. Do not carry this unit by its cord or use the cord
as a handle.
11. Never operate this unit if it has a damaged cord or plug,
if it is not working properly, or if it has been dropped
or damaged, or dropped into water. If the unit’s power
supply cord or plug is damaged, do not attempt to fix it
yourself.
12. To avoid the risk of electric shock, do not disassemble
or attempt to repair the unit. Incorrect repair can cause
risk of electric shock or injury to persons when the unit
is used.
13. Do not operate in the presence of explosive and/or
flammable fumes.
14. Never remove the plug from the outlet by pulling the
power cord.
FCC INFORMATION
This equipment has been tested and found to comply with
the limits for a Class B Digital Device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the distance between the equipment and
receiver.
4 5
917703_917725 INS Speak Out
Size:80mmWx80mmH_Output:100%_Prints:1/1,Blk
• Connect the equipment to an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
This equipment complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This equipment may not cause harmful interference.
2. This equipment must accept any interference received,
including interference that may cause undesired operation.
Modifications not authorized by the manufacturer may void
the user’s authority to operate this device.
FCC ID: HBOSPEAKOUT
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment .This equipment should be installed and operated with minimum distance 20cm
between the radiator& your body. This transmitter must not be co-located or operating in
LOCATION OF PARTS AN D CONTROLS
1. Power/Pairing Button
2. Pair2™ Button
3. Night Light Button
4. Volume + Button
5. Volume - Button
6. AC Plug Cover
7. AC Plug Bypass
8. Night Light
9. Rotating AC Plug
10. Pair2™ LED Indicator
11. Power/Pairing
LED Indicator
1
2
3
4
5
7
6
8
conjunction with any other antenna or transmitter.
11
10
9
6 7
917703_917725 INS Speak Out
Size:80mmWx80mmH_Output:100%_Prints:1/1,Blk
SETTI NG UP THE S PEAKE R
1. Plug the speaker into an electrical wall outlet and rotate
speaker to desired position.
2. Remove the AC PLUG COVER to use the AC PLUG
BYPASS.
USING THE N IGHT LIGHT
1. Press the NIGHT LIGHT BUTTON to turn the Night Light
on.
2. Press the NIGHT LIG HT BUTTON to turn the Night Light
off.
Note: The Night Light can used when the speaker is powered
on and when the speaker is powered off.
PAIRING YOUR DEVICE
1. Prepare your device to pair using Bluetooth®, making
sure the device is within 33 feet of the speaker. Refer to
your device’s owners manual for details if necessary.
2. Press the POWER/ PAIRING BUTTON. The POWER/
PAIRING LED INDICATOR will turn on and the power on
tone will sound.
3. Press and hold the POWER/PAIRING BUTTON until the
POWER/PAIRING LED INDICATOR starts flashing to
put the speaker in pairing mode.
4. Select “Speak Out” on your device. If prompted, use 0000
as a PIN for the pairing code. The speaker will wait for a
connection in pairing mode for up to 2 minutes.
5. When “Speak Out” is selected, the POWER/PAIRING
LED INDICATOR will be solid blue and the pairing
successful tone will sound to confirm pairing is complete.
Notes:
• To cancel the pairing mode, either press the POWER/
PAIRING BUTTON, a tone will sound and the speaker will
turn off, or wait 2 minutes for the speaker to cancel pairing
8 9
917703_917725 INS Speak Out
Size:80mmWx80mmH_Output:100%_Prints:1/1,Blk
automatically. The POWER/PAIRING LED INDICATOR
will return to solid blue and the unit will remain on.
• The POWER/PAIRING LED INDICATOR will turn
off 5 seconds after pairing. Pressing any button will
activate POWER/PAIRING LED INDICATOR for 5
seconds.
LISTEN ING TO AUDIO
1. Press the POWER/PAIRING BUTTON. The POWER/
PAIRING LED INDICATOR will turn on and the power on
tone will sound.
2. The speaker will automatically remember the last paired
device. Depending on your device, “Speak Out” may need
to be selected in your device’s menu.
3. Press the VOLUME + BUTTON to increase audio volume.
4. Press the VOLUM E - BUTTON to decrease audio volume.
5. To turn the speaker off, press the POWER/PAIRING
B UTTON. The power off tone will sound.
Note: The POWER/PAIRING LED INDICATOR will turn off 5
seconds after powering on. Pressing any button will activate
POWER/PAIRING LED INDICATOR for 5 seconds.
10 11
917703_917725 INS Speak Out
Size:80mmWx80mmH_Output:100%_Prints:1/1,Blk
USING Pair2™ FOR STER EO OR LEFT/ RIGHT SOUND
Two Speak Out™ speakers can be paired for stereo or left/right
sound. Identify which speaker will be the Main speaker and
which speaker will be the Auxiliary speaker as your device only
needs to pair with the Main speaker.
1. Pair your device (see page 9) with the Main speaker.
2. Press the POWER/PAIRING BUTTON on the Auxiliary
speaker until the POWER/PAIRING LED INDICATOR
turns on and the power on tone sounds.
Note: Do not put the Auxiliary speaker into device pairing
mode.
3. Press the Pair2 BUTTON on the Main speaker (the
speaker that is paired with your device). The PAIR2 LED
INDICATOR will start flashing and audio will pause on
the Main speaker. The Main speaker will wait for a Pair2
connection for up to 2 minutes.
4. Press and hold the Pair2 BUTTON on the Auxiliary
speaker until the PAIR2 LED INDICATOR starts flashing
on the Auxiliary speaker.
5. Release the Pair2 B UTTON on the Auxiliary speaker.
6. After a few seconds, the PAIR2 LED INDICATORS on both
the Main Speaker and the Auxiliary speaker will be solid,
the Pair2 stereo tone will sound on each speaker, and the
speakers will be in stereo mode.
7. Resume audio from your device.
8. To put the speakers in left/right mode, press and hold the
Pair2 B UTTON on the Main speaker or the Auxiliary
speaker until the Pair2 left and right tones sound on each
speaker. To put the speakers back into stereo mode, press
and hold the Pair2 BUTTON on the Main speaker
or the Auxiliary speaker until the Pair2 stereo tones sound
on each speaker.
9. To exit out of Pair2 stereo or left/right modes,
power either speaker off by pressing the POWER/
PAIRI NG BUTTON.
Notes:
• To cancel PAIR2 mode, either press the POWER/
PAIRING BUTTON on the Main Speaker, a tone will sound
and the speaker will turn off, or wait 2 minutes for the speaker
to cancel pairing automatically.
• The POWER/PAIRING LED INDICATOR and the
12 13
917703_917725 INS Speak Out
Size:80mmWx80mmH_Output:100%_Prints:1/1,Blk
PAIR2 LED I NDICATOR will turn off 5 seconds after
pairing. Pressing any button will activate POWER/
PAIRING LED INDICATOR and the PAIR2 LED
INDICATOR for 5 seconds.
CARE AND MAINTE NANCE
To clean, wipe the speaker with a soft, dry cloth.
14 15
917703_917725 INS Speak Out
Size:80mmWx80mmH_Output:100%_Prints:1/1,Blk
NOTES
SPECI FICATIONS
Power Input .........................100-240V~50/60Hz 10A
Power Output ...................... .100-240V~50/60Hz 10A
Range ............................. Class 2, up to 33 ft (10 m)
Speaker ................................... 1.5" Full Range (1)
Frequency Response .......................... 100Hz~20KHz
Compatibility ...................... Bluetooth 2.0 or above with
A2DP/AVRCP
Weight .................................... Approx. 242 grams
Dimensions................................... 5.1" x 2.4" x 3.1"
The Bluetooth® word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by Brookstone is under license.
© Brookstone 2015
16 17
917703_917725 INS Speak Out
Size:80mmWx80mmH_Output:100%_Prints:1/1,Blk
TROUBLE SHOOTING
ISSUE SOLUTION
Bluetooth®
disconnection.
Audio is
not clear.
Speaker does
not play audio.
Ensure your device is within 33 feet of
the speaker and reconnect your device
to "Speak Out."
Power the speaker off and then back on.
Adjust your device’s equalizer.
Check the speaker or your device’s
volume level.
Power the speaker off and then
back on.
Confirm device is paired to speaker,
see page 9 for pairing instructions.
TROUBLE SHOOTING (CONTINUED)
ISSUE SOLUTION
Can not put speakers
into Pair2 mode.
Can not switch
speakers between
stereo or left/right
in Pair2 mode.
Confirm your device is paired to the
Main speaker. Please refer to page
9 for pairing instructions.
Confirm there is not a previous device
paired to the Auxiliary speaker.
Confirm both the Main and Auxiliary
speaker are in Pair2 connection
mode. Please refer to page 12 for
Pair2 connection instructions.
Confirm you are pressing and holding
the Pair2 BUTTON on the Main
speaker or the Auxiliary speaker until
the Pair2 stereo or left and right tones
sound on each speaker.
18 19
917703_917725 INS Speak Out
Size:80mmWx80mmH_Output:100%_Prints:1/1,Blk
ONE (1) YEAR LIMITED WARRANTY
Big Blue Audio LLC warrants this product against defects in materials and/
or workmanship under normal use for a period of ONE (1) YEAR from the
date of purchase by the original purchaser (“Warranty Period”). If a defect
arises and a valid claim is received within the Warranty Period, at its option,
Big Blue Audio will either 1) repair the defect at no charge, using new
or refurbished replacement parts, or 2) replace the product with a new
product that is at least functionally equivalent to the original product, or
3) provide a store credit in the amount of the purchase price of the original product.
A replacement product or part, including a user-installable part installed in
accordance with instructions provided by Big Blue Audio, assumes the remaining
warranty of the original product. When a product or part is exchanged, any
replacement item becomes your property and the replaced item becomes Big Blue
Audio’s property. When a store credit is given, the original product must be returned
to Big Blue Audio and becomes Big Blue Audio’s property.
Obtaining Service: To obtain warranty service, call Big Blue Audio Limited Warranty
Service at 866-577-8955. Please be prepared to describe the product that needs
service and the nature of the problem. A purchase receipt is required. All repairs and
replacements must be authorized in advance. Service options, parts availability and
response times will vary. You are responsible for delivery and the cost of delivery
of the product or any parts to the authorized service center for replacement, per
our instructions.
Limits and Exclusions: Coverage under this Limited Warranty is limited to the
United States of America, including the District of Columbia and the U.S. Territories
of Guam, Puerto Rico, and the U.S. Virgin Islands. This Limited Warranty applies only
to products manufactured for Big Blue Audio that can be identified by the “Big Blue
Audio” trademark, trade name, or logo affixed to them or their packaging. The Limited
Warranty does not apply to any non-Big Blue Audio products. Manufacturers or
suppliers other than Big Blue Audio may provide their own warranties to the purchaser,
but Big Blue Audio, in so far as permitted by law, provides these products “as is.”
This warranty does not apply to: a) damage caused by failure to follow instructions
relating to product’s use or the installation of components; b) damage caused
by accident, abuse, misuse, fire, floods, earthquake or other external causes; c)
damage caused by service performed by anyone who is not a representative of
Big Blue Audio; d) accessories used in conjunction with a covered product; e) a
product or part that has been modified to alter functionality or capability; f) items
intended to be periodically replaced by the purchaser during the normal life of the
product including, without limitation, batteries or light bulbs; g) any product sold “as
is” including, without limitation, floor demonstration models and refurbished items;
or h) a product that is used commercially or for a commercial purpose.
BIG BLU E AUDIO SHALL NOT B E LIABLE FOR IN CIDE NTAL OR
CONSEQUENTIAL DAMAGES RESU LTING FROM THE USE OF THIS
PRODUCT, OR ARISING OUT OF ANY BREACH OF TH IS WARRANTY.
TO THE EXTENT PE RMITTE D BY APPLICABLE LAW, BIG BLU E AUDIO
DISCLAIMS ANY AND ALL STATUTORY OR IMPLI ED WARRANTI ES,
INCLUDING, W ITHOUT LIM ITATION, WARRANTI ES OF M ERCHANTABI LITY,
FITNESS FOR A PARTICULAR PURPOSE AND WARRANTIES AGAINST
HIDDEN OR LATENT DE FECTS. I F B IG BLUE AUDIO CANN OT LAWFULLY
DISCLAIM STATUTORY OR I MPLIE D WARRANTIES, THE N TO THE EXTENT
PERM ITTED BY LAW, ALL SUCH WARRANTI ES SHALL B E LIMITE D IN
DURATION TO THE DU RATION OF THIS EXPRESS WARRANTY.
Some states disallow the exclusion or limitation of incidental or consequential
damages or how long an implied warranty lasts, so the above exclusions or
limitations may not apply to you. This warranty gives you specific legal rights and
you may also have other rights, which vary from state to state.
20 21
917703_917725 INS Speak Out
Size:80mmWx80mmH_Output:100%_Prints:1/1,Blk
Find thousands more
great ideas online
917703 917725
Merrimack, New Hampshire, USA 03054 • 800-846-3000 • Brookstone.com
917703_917725 INS Speak Out
Size:80mmWx80mmH_Output:100%_Prints:1/1,Blk
Loading...
