UNIVERSAL BLUETOOTH WIRELESS STEREO
SPEAKER
USER MANUAL
SMPS-665
PLEASE READ THIS USER MANUAL COMPLETELY BEFORE OPERATING THIS
SPEAKER AND RETAIN THIS BOOKLET FOR FUTURE REFERENCE.
DEAR JENSEN® CUSTOMER
Selecting fine audio equipment such as the unit you've just purchased is only the start
of your musical enjoyment. Now it's time to consider how you can maximize the fun
and excitement your equipment offers. This manufacturer and the Electronic
Industries Association's Consumer Electronics Group want you to get the most out of
your equipment by playing it at a safe level. One that lets the sound come through
loud and clear without annoying blaring or distortion and, most importantly, without
affecting your sensitive hearing. Sound can be deceiving. Over time your hearing
"comfort level" adapts to higher volumes of sound. So what sounds "normal" can
actually be loud and harmful to your hearing. Guard against this by setting your
equipment at a safe level BEFORE your hearing adapts.
To establish a safe level:
z Start your volume control at a low setting.
z Slowly increase the sound until you can hear it comfortably and clearly, and
without distortion.
Once you have established a comfortable sound level:
• Set the dial and leave it there.
Taking a minute to do this now will help to prevent hearing damage or loss in the
future. After all, we want you listening for a lifetime.
We Want You Listening For a Lifetime
Used wisely, your new sound equipment will
provide a lifetime of fun and enjoyment. Since
hearing damage from loud noise is often
undetectable until it is too late, this manufacturer
and the Electronic Industries Association's
Consumer Electronics Group recommend you
avoid prolonged exposure to excessive noise.
Customer's Record:
The serial number of this product is found on its back cover. You should note the
serial number of this unit in the space provided as a permanent record of your
purchase to aid in identification in the event of theft of loss.
Model Number: SMPS-665 Serial Number:
IMPORTANT SAFETY INSTRUCTIONS
When used in the directed manner, this unit has been designed and manufactured to
ensure your personal safety. However, improper use can result in potential electrical
shock or fire hazards. Please read all safety and operating instructions carefully
before installation and use, and keep these instructions handy for future reference.
Take special note of all warnings listed in these instructions and on the unit.
1. Read these instructions.
2. Keep these instructions
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat.
9. Only use attachments / accessories specified by the manufacturer.
10. Unplug this apparatus during lightning st orms or when unused for long periods of
time.
1
11. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
12. This appliance shall not be exposed to dripping or splashing water and that no
object filled with liquids such as vases shall be placed on the apparatus.
13. Power Sources – The appliance should be connected to a power supply only of
the type described in the operating instructions or as marked on the appliance. Do
not overload wall outlet.
14. Do not attempt to dismantle, open or repair this product yourself. If a fault occurs,
seek advice from your local qualified service technician or contact the distributor
via the telephone number at the back of this instruction manual.
15. Caution marking and nameplate are located on back of product.
IMPORTANT NOTES
Avoid installing the unit in locations described below:
• Places exposed to direct sunlight or close to heat radiating appliances such as
electric heaters.
• Places subject to constant vibrations.
• Dusty, humid or moist places.
COMPLIANCE WITH FCC REGULATIONS
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
NOTE : This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modifications not expressl y approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
PROTECT YOUR FURNITURE
This model is equipped with non-skid rubber 'feet' to prevent the product from moving
when you operate the controls. These 'feet' are made from non-migrating rubber
material specially formulated to avoid leaving any marks or stains on your furniture.
However certain types of oil based furniture polishes, wood preservatives, or cleaning
sprays may cause the rubber 'feet' to soften, and leave marks or a rubber residue on
the furniture. To prevent any damage to your furniture we strongly recommend that
you purchase small self-adhesive felt pads, available at hardware stores and home
improvement centers everywhere, and apply these pads to the bottom of the rubber
'feet' before you place the product on fine wooden furniture.
2
PRODUCT FEATURES
The SMPS-665 is a Bluetooth stereo speaker with the following features:
• Wireless playback of music from your Bluetooth enabled device via the Bluetooth
connection.
• Hands-free Bluetooth Speakerphone
• Up to 33 feet (10 meters) operating range.
• Auxiliary input jack to play music from your iPod or digital audio player.
• Digital volume control for Bluetooth enabled device.
GETTING STARTED
ACCESSORIES INCLUDED
Carefully remove the unit and all the accessories from the gift box. Please verify that
you have all the following accessories before recycling the gift box.
• User manual
• Audio Cable
• AC Adaptor Input :AC 100V-240V 50/60Hz
Output :DC 9V 2000mA. center-positive
POWER SOURCE
This unit operates on an external AC adaptor rated at DC 9V / 2000mA (included). Do
not attempt to operate the unit from any other power source. You could cause
damage to the unit and void your warranty.
CONNECTING THE AC ADAPTOR
1. Insert the plug located at the end of the AC adaptor wire into the DC input Jack on
the back of the unit.
2. Insert the AC Adaptor plug into a power outlet rated at 120V AC ~ 60Hz.
NOTE: This unit is not magnetically shielded and may cause color distortion on the
screen of some TVs or video monitors. To avoid this, you may need to move
the unit further away from the TV or monitor if unnatural color shifts or image
distortion occurs.
LOCATION OF CONTROLS
3
1. Power On/Off / Phone Button
2. Power Indicator
3. Volume - / Skip Backward Button
4. Voulme + /Skip Forward Button
5. Bluetooth Button
6. Bluetooth Status Indicator
7. AUX-IN Jack
8. DC Input Jack
9. USB Charging Port
TURNING THE SMPS-665 POWER ON/OFF
1. In power off mode, press and hold the Power On/Off Button for 4-5 seconds to
turn the unit ON. The Power indicator goes on and the sound is heard.
2. To turn the unit OFF, press and hold the Power On/Off Button for 4-5 seconds
to turn the unit OFF. The Power and the Bluetooth status indicator both go off.
OPERATING THE UNIT
Pairing (linking) a Bluetooth enabled cell phone or other Bluetooth enabled
device to the speaker
1. If the SMPS-665 has never been paired with a Bluetooth device before. You need
to follow the pairing instructions below to link the SMPS-665 with your Bluetooth
device.
• Turn the SMPS-665 On. Press and hold the Bluetooth Button. A short
beep tone is heard and the Bluetooth Status Indicator will flash rapidly, the
SMPS-665 is now ready to pair (link) with your Bluetooth device.
• Turn on the Bluetooth function of your Bluetooth device and enable the search
4
or scan function to find the SMPS-665.
• Select "SMPS-665" from the device list when it appears on your device screen.
If required, enter the pass code “0000” to pair (link) the SMPS-665 with your
device.
• After successfully pairing (linking) the Bluetooth enabled device, a short beep
tone is heard and the Bluetooth indicator remain lit.
2. After turning on the SMPS-665, a tone will be heard and the unit will search for the
last paired device. The Bluetooth Status Indicator will flash blue. If the
SMPS-665 finds the last paired Bluetooth device, a beep is heard and the
Bluetooth Status Indicator will stop flashing and remain lit.
3. After successfully pairing (linking), you can begin playing music from your
Bluetooth enabled device wirelessly to the speaker.
4. Press the Volum e + / Volume - Button on the speaker to adjust to the
desired volume level.
5. If you want to pair with another Bluetooth device, repeat steps 1 to 4 above.
Notes:
1. Refer to manual of your cell phone, tablet PC, computer or other Bluetooth
enabled devices for Bluetooth operation since it may vary from model to
model.
2. If your Bluetooth enabled device does not support A2DP profile, it will not play
the music through the speaker, even if paired (linked).
3. If you are pairing (linking) your computer to the SMPS-665 using Bluetooth,
you may need to set the speaker as your computer’s default sound device.
4. You may have problems with the Bluetooth relinking if you turn the SMPS-665
off, and then on again right away. Please wait 10 seconds after turning the
SMPS-665 off before turning it on again.
Using the SMPS-665 as a Hands-free Bluetooth Speakerphone
1. Link your cell phone to the SMPS-665 via Bluetooth as described above.
2. When receiving an incoming call on your cell phone, tap the Phone Button on
the speaker to switch the incoming call from cell phone to the SMPS-665. A short
beep tone will be heard confirming the call is being answered. Complete your call
using the built-in microphone and speaker on the SMPS-665.
3. Press the Volume + / Volume - Button on the SMPS-665 to obtain the
desired sound level.
4. To end the call, just tap the Phone Button on the SMPS-665 again. A short beep
sound will be heard and the call will end. If you are playing music from your cell
phone to the SMPS-665 before answering the call, the music will automatically
resume playing when you hang up.
5. To ignore an incoming call, simply press and hold the Phone Button on the
speaker for about 2 seconds, a short beep tone will be heard and the call will be
rejected.
Hang up with the SMPS-665
A quick press on the Phone Button will end the call in progress. A short beep tone
will be heard from the speaker confirming the call has ended.
Redialing the last number with the speaker
The speaker will automatically redial the last number you have dialed by tapping the
speaker Phone Button twice and long beep will heard.
Note: This feature is phone dependent.
Re-linking to the cell phone
If your cell phone is already paired (linked) with the SMPS-665, but became unlinked
even with both Bluetooth devices turned on. You can re-link them by:
1. Turning off the SMPS-665 and then turn it on again to re-link your cell phone. Af ter
5
turning the SMPS-665 ON, the sound will be heard. The SMPS-665 will search
the last paired device. If the SMPS-665 finds & successfully pairs with the last
paired device, the beep will be heard.
2. You can also re-link the SMPS-665 by using Bluetooth operation of your cell
phone. Please refer to operation manual of your cell phone for more information.
PLAYING MUSIC USING THE AUXILIARY INPUT
The SMPS-665 features an auxiliary audio signal input jack for connecting external
audio devices like MP3 players, CD players, iPhones or iPods (except iPod shuffle 3rd
gen) and listen to them your through the speakers.
1. Use the audio cable (included) with one 3.5 mm stereo plug on each end of the
cable.
2. Plug one end into the AUX-IN Jack on the SMPS-665 and the other end of the
cable into the Headphone Jack of your external audio device.
3. Turn on your external audio device.
4. Adjust the volume control on the external device to obtain the desired volume
level.
5. Operate all other functions on external device as usual.
NOTE:
1. The volume controls on the SMPS-665 will not adjust the volume level when in
AUX-IN mode. We recommend connecting the Headphone jack of your
external device to the Aux-in jack on the SMPS-665. Then use the volume
control on the connected device to adjust the volume level.
2. If you connect the Line-Out Jack of your external device to the SMPS-665
Aux-in jack, then the audio level will be very high and you will not be able to
adjust the volume level.
3. If you use AUX IN function when playing Bluetooth audio, the Bluetooth audio
will be temporarily disconnected when the audio cable is plugged in.
Unplugging the audio cable will resume Bluetooth audio.
4. Turn the SMPS-665 off when you finish listening. Don't forget to switch off the
power of your external device as well.
CHARGING YOUR SMART PHONE OR PORTABLE DEVICE
This unit features a USB port for charging your portable device (iPod, iPhone,
Android phone, etc.) when used with the USB charging cord that came with your
device.
1. Plug one end of the USB cable (not included) into the USB Charging Port
located on the back of the SMPS-665. Plug the other end of the cord into the
device you wish to charge.
2. Observe the battery charge indicator on your device and the charging will start
immediately.
3. Unplug the cable when your device is charged.
CAUTION:
Before charging, please refer to the user manual of the device you wish to charge to
make sure the charging current requested does not exceed 1A (1000mA) of charging
current. Overloading the charge circuit may damage the SMPS-665 and void the
warranty.
Note:
1. Some smart phones and portable devices use proprietary USB connections
and circuitry, so they may not charge when plugged into the USB port. This
includes older Apple iPod models including the iPod classic. Please refer to
your device user manual before you attempt to charge them.
2. It is normal for the SMPS-665 to be warm while the USB port is in use and
charging your smart phone or portable device.
6
3. Do not charge your smart phone over 12 hours continuously. Remove your
smart phone from the charger once it is charged.
CARE AND MAINTENANCE
1. Avoid operating your unit under direct sunlight or in hot, humid or dusty places.
2. Keep your unit away from heating appliances and sources of electrical noise such
as fluorescent lamps or motors.
CLEANING THE UNIT
• To prevent fire or shock hazard, disconnect your unit from the power source
when cleaning.
• The finish on the unit may be cleaned with a dust cloth and cared for as other
furniture. Use caution when cleaning and wiping the plastic parts.
• If the cabinet becomes dusty wipe it with a soft dry dust cloth. Do not use any
wax or polish sprays on the cabinet.
• If the cabinet becomes dirty or smudged with fingerprints it may be cleaned with
a soft cloth slightly dampened with a mild soap and water solution. Never use
abrasive cloths or polishes as these will damage the finish of your unit.
CAUTION: Never allow any water or other liquids to get inside the unit while
cleaning.
TROUBLESHOOTING GUIDE
Symptom Possible Problem Solution
AC Adaptor is not
The unit
does not
respond (no
power).
plugged into a wall
outlet or the connector
is not plugged into the
power supply jack on
the back of the unit.
Wall outlet is not
functioning.
Plug the AC adaptor into a wall outlet
and plug the connector into the supply
jack on the unit.
Plug another device into the same
outlet to confirm the outlet is working.
No Sound
Sound is
distorted.
Unit gets
warm after
The SMPS-665 is not
linked with the
Bluetooth enabled
device.
The SMPS-665
placement out of
range.
Volume set too low.
Volume level is set too
high.
Sound source is
distorted.
This is normal.
Go through “Operating the Unit”
process to link the speaker.
Relocate the SMPS-665 within
Bluetooth operating range (30 feet).
Press the Volume + Button to
turn the sound level up. (Not available
in Aux-in mode)
Decrease the volume of the speaker.
If the source sound file is of poor
quality, distortion and noise are easily
noticed with high-power speakers. Try
a different audio source such as a
music CD.
If you are using an external sound
source like older generation of iPod,
try reducing the output volume on the
device itself. Also try turning bass
boost OFF or change the EQ setting.
Turn the speaker off for a period of
time or lower the volume.
7
extended
play at high
volume.
SPECIFICATIONS
Power Requirement
AC-DC adaptor: Input:AC 120V,60Hz
Main unit DC input: DC9V/2000mA
At Spectra, environmental and social responsibility is
a core value of our business. We are dedicated to
continuous implementation of responsible initiatives
with an aim to conserve and maintain the environment
through responsible recycling.
Please visit us at http://www.spectraintl.com/green.htm for more information on
Spectra’s green initiatives or to find a recycler in your area.
Bluetooth® is a registered trademark of Bluetooth SIG, Inc.
90 DAY LIMITED WARRANTY AND SERVICE
VALID IN THE U.S.A. ONLY
SPECTRA MERCHANDISING INTERNATIONAL, INC. warrants this unit to be free
from defective materials or factory workmanship for a period of 90 days from the date
of original customer purchase and provided the product is utilized within the U.S.A.
This warranty is not assignable or transferable. Our obligation under this warranty is
the repair or replacement of the defective unit or any part thereof, except batteries,
when it is returned to the SPECTRA Service Department, accompanied by proof of
the date of original consumer purchase, such as a duplicate copy of a sales receipt.
You must pay all shipping charges required to ship the product to SPECTRA for
warranty service. If the product is repaired or replaced under warranty, the return
charges will be at SPECTRA’s expense. There are no other express warranties other
than those stated herein.
This warranty is valid only in accordance with the conditions set forth below:
1. The warranty applies to the SPECTRA product only while:
a. It remains in the possession of the origina l purchaser and proof of purchase is
demonstrated.
b. It has not been subjected to accident, misuse, abuse, improper service, usage
outside the descriptions and warnings covered within the user manual or
non-SPECTRA approved modifications.
c. Claims are made within the warranty period.
2. This warranty does not cover damage or equipment failure caused by electrical
wiring not in compliance with electrical codes or SPECTRA user manual
specifications, or failure to provide reasonable care and necessary maintenance
as outlined in the user manual.
3. Warranty of all SPECTRA products applies to residential use only and is void when
products are used in a nonresidential environment or installed outside the United
States.
This warranty gives you specific legal rights, and you may also have other rights
which vary from state to state. TO OBTAIN SERVICE please remove all batteries (if
any) and pack the unit carefully and send it freight prepaid to SPECTRA at the
address shown below. IF THE UNIT IS RETURNED WITHIN THE WARRANTY
PERIOD shown above, please include a proof of purchase (dated cash register
8
receipt) so that we may establish your eligibility for warranty service and repair of the
unit without cost. Also include a note with a description explaining how the unit is
defective. A customer service representative may need to contact you regarding the
status of your repair, so please include your name, address, phone number and email
address to expedite the process.
IF THE UNIT IS OUTSIDE THE WARRANTY PERIOD, please include a check for
$30.00 to cover the cost of repair, handling and return postage. All out of warranty
returns must be sent prepaid.
It is recommended that you contact SPECTRA first at 1-800-777-5331 or by email at
custserv@spectraintl.com for updated information on the unit requiring service. In
some cases the model you have may be discontinued, and SPECTRA reserves the
right to offer alternative options for repair or replacement.
SPECTRA MERCHANDISING INTERNATIONAL, INC.
4230 North Normandy Avenue,
Chicago, IL60634, USA.
1-800-777-5331
To register your product, visit the link on the website below to enter your information.
http://www.spectraintl.com/wform.htm
1012 Printed in China
9
Loading...
