1
EDICT
Congratulations on purchasing a Felt Edict. As with all of our
bikes and components, our aim is to provide the rider with the
best product and riding experience. Read this manual supplement
thoroughly, as it’s to help you set your bike up correctly,
and care for it.
For further information, visit:
FELTBICYCLES.COM
INTRODUCTION
CONTENTS
INTRODUCTION
Fast Explained .......................................................................................................................... 2- 3
Geometry .....................................................................................................................................4
SETUP
Shock Setup .................................................................................................................................5
Head Tube Ca ble Guide s .............................................................................................................6
Bottom Bracket C able Guides ......................................................................................................7
CABLE ROUTING
Rear Brake Cable/Hose Routing ...............................................................................................8-9
Rear Shifter Cable Routing ....................................................................................................10-11
Droppe r Post Cable/ Hose Routing..............................................................................................12
Shock Remote Cable Routing .....................................................................................................13
MAINTENANCE
Evaluation ..................................................................................................................................14
Pivot Loc ation / Torque Values ...................................................................................................15
Main Pivot .............................................................................................................................16-17
Seat Tube Pi vot ..................................................................................................................... 18 -19
Seat Sta y Pivot ...................................................................................................................... 20 -21
REPLACEMENT PARTS
Master Parts Lis t .........................................................................................................................22
Hardware Rebuild Kit .................................................................................................................23
Bearing Kit .................................................................................................................................23
Toolkit ........................................................................................................................................24
CONTACT INFORMATION
Contact ......................................................................................................................................25
Page 3
3
2
FAST EXPLAINED FAST EXPLAINED
CONT.
Efcient Pedaling: In order to provide efficient pedaling, FAST relies on both ideal anti-
squat values as well as the flexible carbon stays. As the suspension moves away from the sag
point in either direction, a force is created from either compressing or extending the stays.
This force acts on the shock and helps return it back to sag. This provides a stable,
responsive platform for pedaling.
Large Impacts: Support for large impacts is provided in two ways: decreasing leverage
ratio and carbon flex. The leverage ratio is decreasing which makes it progressively harder
to compress the suspension as it moves through the travel. The carbon stays add to this by
contributing an additional spring force as they are extended through the travel.
Small- Bump Sensitivity: With the pedaling performance and large impact support
handled by the linkage design and flexible carbon stays, the shock can be run with
minimal compression damping. This frees the shock up to remain active and absorb
the smallest of bumps.
FAST, or Felt Active Stay Technology, is a linkage-driven, single pivot
system with exible carbon stays. By replacing the pivot near the dropout
with exible carbon stays a lighter, stiffer, and overall snappier frame
can be made.
COMPRESSED
0% Travel (Top-Out): In order for
the suspension to reach full extension,
the rear triangle is required to
compress.
EXTENDED
100% (Bottom-Out): As the
suspension gets deeper in the
travel, the rear triangle is required
to extend.
NEUTRAL
30% Travel (Sag): At the sag
point (approximately 30%), the
rear triangle is neutral.
Page 4
5
4
SHOCK SETUP
It is very important to have the correct amount of sag so that the suspension can be in the
part of its travel that is most efficient and compliant. Felt recommends starting at 30% and
adding/subtracting up to 5-10% to fine tune to your personal preference.
To measure sag, follow these 4 steps:
1. Push the o-ri ng to the top of t he shock sha ft.
2. Sit on the bi ke with the se at at full rid e height to comp ress the s hock. Boun ce a few times, t hen push the
o-ring b ack to the top o f the shaf t.
3. Gently g et off the b ike, taking car e not to change t he positio n of the o-ri ng. On some sh ock models, t he
sag gradi ents will be p rinted on th e shaft. I n this case, simp ly read your s ag percent age as it is pr inted on the
shock sha ft. If ther e are no sag gra dients, me asure the dis tance of th e o-ring fr om the top of th e shaft. To
achieve 30 % sag, the o- ring shoul d be 12mm from the top of th e shaft. I f there is too mu ch sag (>30%)
add air pre ssure, if the re is not enoug h sag (<30%), reduc e air pressu re.
4. Repeat p rocess unt il desired s ag is achieved .
CORRECT
NOT CORRECT
OR
+ PRESSURE- PRESSURE
GEOMETRY
12mm
A
B
C
D
E
F
G
H
I
J
K
L
M
N
S (16”)
69
73.3
576
90
405
38
436
667
1101
526
51
1
397
596
M (18”)
69
73.3
602
105
450
38
436
694
1128
526
51
1
419
610
L (20”)
69
73.3
628
120
495
38
436
721
1155
526
51
1
441
624
XL (22”)
69
73.3
653
145
540
38
436
748
1182
526
51
1
459
647
Size
Head Tube Angle
Seat Tube Angle
Top Tube Horizontal
Head Tube
Seat Tube
BB Drop
Chainstay
Front Center
Wheelbase
Fork Length
Rake
Lower HS Stack
Reach
Stack
EDICT 3
EDICT 4
EDICT 5
(120mm Fork)
A
B
C
D
E
F
G
H
I
J
K
L
M
N
S (16”)
70
74.3
573
90
405
45
436
661
1093
506
51
1
407
589
M (18”)
70
74.3
573
105
450
45
436
688
1121
506
51
1
429
603
L (20”)
70
74.3
573
120
495
45
436
715
1148
506
51
1
451
617
XL (22”)
70
74.3
573
145
540
45
436
742
1175
506
51
1
470
640
Size
Head Tube Angle
Seat Tube Angle
Top Tube Horizontal
Head Tube
Seat Tube
BB Drop
Chainstay
Front Center
Wheelbase
Fork Length
Rake
Lower HS Stack
Reach
Stack
EDICT FRD
EDICT 1
(100mm For k)
Page 5
7
6
BOTTOM BRACKET
CABLE GUIDES
The bottom bracket cable guide can be adapted to different
configurations with rubber reducers for different sizes of cables.
It can also be used as a battery holder.
Wrap zip tie around
to hold battery
in place.
Di2 (2mm)
Shift (4mm)
Brake (5mm)
HEAD TUBE CABLE GUIDES
The head tube cable guides contain rubber reducers for all cable sizes
that are interchangeable and can be arranged to fit each rider's setup
and personal preferences.
Di2 (2mm) Shift (4mm)
Brake (5mm) Blank Plug
Page 6
9
8
ROUTING
REAR BRAKE
ROUTING
REAR BR AKE CONT.
INTERNAL ROUTING
Page 7
11
10
ROUTING
REAR SHIFTER
ROUTING
REAR SHIFTER CONT.
INTERNAL ROUTING
Page 8
13
12
ROUTING
DROPPER POST
ROUTING
SHOCK REMOTE
INTERNAL ROUTING
Page 9
15
14
In order to a chieve optimu m suspensio n perfo rmance, Felt r ecommend s perfo rming a simpl e pivot check ing
procedu re after eve ry 100 hour s of riding o r annually, whiche ver comes fir st. If any iss ues are disco vered,
please r efer to the be aring rem oval/instal lation sec tion or take your bike to the n earest Fel t dealer.
Pivot Checking Procedure
1. Check torque on a ll pivot bolt s. If bolts a re loose, rem ove, clean and app ly Locti te 242 to the threa ds,
then tigh ten to corre ct torque (s ee technic al section f or torque valu es).
2. With the sh ock install ed, apply pre ssure ver tically and horizon tally to feel fo r any play in the p ivots.
If play is dis covered, ple ase refer t o the technic al sectio n for more infor mation an d instruc tions for
bearing removal/install ation.
3. With the s hock remove d, move the susp ension thro ugh its trav el. There sh ould be lit tle to no fric tion.
If there is a ny fricti on, please re fer to the tec hnical sec tion for mor e informat ion and inst ruction s for
bearing removal/install ation.
EVALUATION
Move Rear Triangle
through travel.
PIVOT LOCATION
Seat Sta y Pivot
Seat Tube Pi vot
Main Pivot
Shock Mounts
15N -m
18N-m
18N-m
15N -m
Page 10
17
16
MAIN PIVOT
item no. description qty.
3802 LLB Max Bearing
Main Pivot Axle
Main Pivot Spacer
Main Pivot Bearing Support
21
14
27
18
MAIN PIVOT
CONT.
Collet Cone 16
Page 11
19
18
SEAT TUBE PIVOT
item no. description qty.
6802 LLB Max
Upper Pivot Axle
Collet Cone
Main Pivot Spacer
Upper Pivot Bearing Suppor t
Rocker Link - Left
22
15
16
27
19
115
SEAT TUBE PIVOT
CONT.
Rocker Link - Right 116
Page 12
21
20
SEAT STAY PIVOT
item no. description qty.
6801 LLB Ma x
Seatstay Yoke Pivot Screw
Seatstay Yoke Pivot Spacer
Rocker Link - Left
13
110
111
115
SEAT STAY PIVOT
CONT.
Page 13
23
22
Main Pivo t Spacer (25mm Lon g)
Seatst ay Yoke Pivot Spacer
Upper Shock Bolt
Rocker Li nk - Left
Lower Sho ck Bolt
item no. description qty.
3802 LLB Max Bearing
6802 LLB Max Bearing
6801 LLB Max Bearing
Main Pivo t Axle
Upper Pi vot Axle
Collet Cone
1
2
2
2
3
2
4
1
5
1
6
2
7
Main Pivo t Spacer
4
9
10
11
12
15
14
1
1
2
1
1
1
MASTER PARTS LIST: DECREE
**Felt offers a bearing rebuild kit as well as a complete hardware
rebuild kit. There is also a tool kit for proper removal and installation
of the bearings. Individual parts may also be ordered. Contact your
local dealer for more information.
Upper Pi vot Bearing Supp ort
Seatst ay Yoke Pivot Screw
Main Pivo t Bearing Suppo rt
2
8
Shock Bolt Collet13 1
Rocker Li nk - Right16
1
HARDWARE REBUILD KIT
BEARING KIT
Page 14
25
24
BRTK-001 BRTK-002 BRTK-003 BRTK-004
BRTK-005 BRTK-006 BRTK-007 BRTK-008
BRTK-009 BRT K-010 BRTK-011 BRTK-012
BRTK-013 BRTK-014 BRTK-015 BRTK-016
BRTK-017 BRTK-018 BRTK-019 BRTK-020
TOOLKIT
sku#964926
CONTACT
INFORMATION
Felt Racing, LLC
12 Chrysler
Irvine, CA 92618
USA
WWW.FELTBICYCLES.COM
Felt GmbH
Industriestr. 39
26188 Edewecht
Germany
