Paper/credit card entry
ENGLISH
Models P-40/P-45C
Handle
Control switch
Sheet capacity gauge
Pivoting head
Bin
Easy emptying
CAPABILITIES
Will shred: Paper, credit cards and staples
Will not shred: Continuous forms, adhesive labels, transparencies,
newspaper, cardboard, paper clips, laminates or plastic other than
noted above
Paper shred size:
Strip-Cut ........................................................................................6.3mm
Cross-Cut .............................................................................. 3.9 x 50mm
Maximum:
Sheets per pass (Strip-Cut P-40) ............................................................8*
Sheets per pass (Cross-Cut P-45C) ......................................................... 6*
Cards per pass ........................................................................................ 1
Paper width .................................................................................. 229mm
Continuous operation ..............................................................5-7 minutes
* A4 (70g) paper at 220-240v,1.0 Amps; heavier paper, humidity or other than
rated voltage may reduce capacity. Recommended daily usage rates: 10-20
paper passes; 10 cards.
IMPORTANT SAFETY INSTRUCTIONS — Read Before Using!
• Avoid touching exposed blades under Cross-Cut shredder head. • The socket-outlet shall be installed near the equipment and shall be
easily accessible.
Auto-On (I)
Off (O)
Reverse (R)
2
To set lock, push
down and slide
Safety lock
Unlocked (green)
Locked (red)
Sheets per pass
See safety instructions below
• Keep away from children and pets. Keep hands away
from paper entry. Always unplug or set safety lock
when not in use.
• Keep foreign objects – gloves, jewelry, clothing, hair,
etc. – away from shredder openings. If object enters
top opening, switch to Reverse (R) to back out object.
• Never use aerosol, petroleum based or other flammable
products on or near shredder. Do not use canned air
on shredder.
• Do not use if damaged or defective. Do not open shredder
head. Do not place near or over heat or water source.
• 8 (P-40)/6 (P-45C) sheets per pass to avoid jams.
Shredder head
Disconnect power switch
Page 3
Paper jam: Set to Off (O), remove shredder head and empty bin. Replace shredder head, and follow any or
all of the below procedures.
OPERATION
TROUBLESHOOTING
Check paper amount
Set to Off (O)
and plug in
Set to Off (O)
and unplug
Set to Auto-On (I)
Set to Auto-On (I)
Feed into paper entry
and release
Hold card
at edge
Feed into center of entry
and release
Continuous operation:
5-7 minute maximum
NOTE: Shredder runs briefly
after each pass to clear entry.
Continuous operation beyond 5-7
minutes will trigger 20-minute
cool down period.
*Apply oil
across entry
Set to Auto-On (I)
Set to Off (O)
*Only use a non-aerosol vegetable oil in long nozzle container
Shred one sheet
Cross-Cut and Strip-Cut:
Run regularly in reverse for
one minute
Cross-Cut only:
Lubricate when bin is full, or
immediately, if:
• Capacity decreases
• Motor sounds different, or
Shredder stops running
Disconnect power switch must be in ON (I) position to operate shredder. Insert waste bag (Fellowes #36052) for easy disposal.
Shredder doesn’t start:
Alternate slowly back and forth
Set to Reverse
(R) for 2-3
seconds
Set to Off (O)
and unplug
PAPER
CARD
Make sure head is on basket correctly
Wait 20 minutes for motor to cool down
Remove and empty basket
Make sure safety lock is in unlock
(green) position
WARRANTY
LIMITED WARRANTY Fellowes, Inc. (“Fellowes”) warrants the cutting blades of the
machine to be free from defects in material and workmanship for 3 years from
the date of purchase by the original consumer. Fellowes warrants all other parts
of the machine to be free of defects in material and workmanship for 1 year from
the date of purchase by the original consumer. If any part is found to be defective
during the warranty period, your sole and exclusive remedy will be repair or
replacement, at Fellowes’ option and expense, of the defective part.
This warranty does not apply in cases of abuse, mishandling, or unauthorized
repair. ANY IMPLIED WARRANTY, INCLUDING THAT OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE, IS HEREBY LIMITED IN DURATION TO THE
APPROPRIATE WARRANTY PERIOD SET FORTH ABOVE. In no event shall Fellowes be
liable for any consequential or incidental damages attributable to this product.
This warranty gives you specific legal rights. The duration, terms, and conditions of
this warranty are valid worldwide, except where different limitations, restrictions,
or conditions may be required by local law.
For more details or to obtain service under this warranty, please contact us or
your dealer.
MAINTENANCE
Follow oiling procedure below and repeat twice.
Remove shredder head
and cut hanging shreds.
Replace shredder head.
Plug in.
Set to
Reverse (R)
3
Set to Reverse (R)
for 2-3 seconds
Safety Lock prevents accidental operation. To set, wait for shredding to stop, push black button down and slide until you see red.
To unlock push black button down and slide until you see green. For greater safety, always unplug shredder after use.
Page 4
English
This product is classied as Electrical and Electronic Equipment. Should the time come for you to dispose of this product please ensure that you do so in accordance with the
European Waste of Electrical and Electronic Equipment (WEEE) Directive and in compliance with local laws relating to this directive.
For more information on the WEEE Directive please visit www.fellowesinternational.com/WEEE
French
Ce produit est classé dans la catégorie « Équipement électrique et électronique ». Lorsque vous déciderez de vous en débarrasser, assurez-vous d’être en parfaite conformité
avec la directive européenne relative à la gestion des déchets d’équipements électriques et électroniques (DEEE), et avec les lois de votre pays liées à cette directive.
Pour obtenir des plus amples informations sur cette directive, rendez-vous sur
www.fellowesinternational.com/WEEE
Spanish
Se clasica este producto como Equipamiento Eléctrico y Electrónico. Si llegase el momento de deshacerse de este producto, asegúrese que lo hace cumpliendo la Directiva
Europea sobre Residuos de Equipamiento Eléctrico y Electrónico (Waste of Electrical and Electronic Equipment, WEEE) y las leyes locales relacionadas con esta directiva.
Para más información acerca de la Directiva WEEE, visite www.fellowesinternational.com/WEEE
German
Dieses Produkt ist als Elektro- und Elektronikgerät klassiziert. Wenn Sie dieses Gerät eines Tages entsorgen müssen, stellen Sie bitte sicher, dass Sie dies gemäß der
Europäischen Richtlinie zu Sammlung und Recycling von Elektro- und Elektronikgeräten (WEEE) und in Übereinstimmung mit der lokalen Gesetzgebung in bezug auf diese
Richtlinie tun.
Mehr Informationen zur WEEE-Richtlinie nden Sie unter: www.fellowesinternational.com/WEEE
Italian
Questo prodotto è classicato come Dispositivo Elettrico ed Elettronico. Al momento dello smaltimento di questo prodotto, effettuarlo in conformità alla Direttiva Europea sullo
Smaltimento dei Dispositivi Elettrici ed Elettronici (WEEE) e alle leggi locali ad essa correlate.
Per ulteriori informazioni sulla Direttiva WEEE, consultare il sito www.fellowesinternational.com/WEEE
Dutch
Dit product is geclassiceerd als een elektrisch en elektronisch apparaat. Indien u besluit zich te ontdoen van dit product, zorg dan a.u.b. dat dit gebeurt in overeenstemming
met de Europese richtlijn inzake afval van elektrische en elektronische apparaten (AEEA) en conform de locale wetgeving met betrekking tot deze richtlijn.
Voor meer informatie over de AEEA-richtlijn kunt u terecht op www.fellowesinternational.com/WEEE
Swedish
Denna produkt är klassicerad som elektrisk och elektronisk utrustning. När det att dags att omhänderta produkten för avfallshantering se då till att detta utförs i enlighet
med WEEE-direktivet om hantering av elektrisk och elektronisk utrustning och i enlighet med lokala bestämmelser relaterade till detta direktiv.
För mer information om WEEE-direktivet besök gärna www.fellowesinternational.com/WEEE
Danish
Dette produkt er klassiceret som elektrisk og elektronisk udstyr. Når tiden er inde til at bortskaffe dette produkt, bedes De sørge for at gøre dette i overensstemmelse med
det Europæiske direktiv om affald af elektrisk og elektronisk udstyr (WEEE) og i henhold til de lokale love, der relaterer til dette direktiv.
For yderligere oplysninger om WEEE-direktivet bedes De besøge www.fellowesinternational.com/WEEE
Finnish
Tämä tuote luokitellaan sähkö- ja elektroniikkalaitteeksi. Kun tuote poistetaan käytöstä, se on hävitettävä sähkö- ja elektroniikkalaiteromusta annetun EY:n direktiivin
(WEEE) ja direktiiviin liittyvän kansallisen lainsäädännön mukaisesti.
Lisätietoja WEEE-direktiivistä on osoitteessa www.fellowesinternational.com/WEEE
W.E.E.E.
38
Page 5
Norwegian
Dette produktet klassiseres som elektrisk og elektronisk utstyr. Hvis du har tenkt å bortskaffe dette produktet, vennligst se til at du gjør dette i overensstemmelse med det
europeiske WEEE-direktivet (Waste of Electrical and Electronic Equipment) og ifølge lokalt lovverk forbundet med dette direktivet.
For mer informasjon om WEEE-direktivet, vennligst besøk www.fellowesinternational.com/WEEE
Polish
Ten produkt został zaklasykowany do grupy urządzeń elektrycznych i elektronicznych. W celu pozbycia się zużytego sprzętu będącego w Państwa posiadaniu należy
postępować zgodnie z Europejską Dyrektywą w sprawie zużytego sprzętu elektrycznego i elektronicznego (WEEE) oraz z lokalnie obowiązującym prawem.
Więcej informacji znajdziecie Państwo na stronie www: ww w.fellowesinternational.com/WEEE
Russian
Данное изделие классифицировано как электрическое и электронное оборудование. Когда придет время утилизировать данное изделие, пожалуйста, обеспечьте
соблюдение Директивы Евросоюза об утилизации отходов электрического и электронного оборудования (Waste of Electrical and Electronic Equipment, WEEE) и
местных законов, связанных с нею.
Для получения дополнительной информации о директиве WEEE, пожалуйста, посетите веб-сайт
www.fellowesinternational.com/WEEE
Greek
Αυτό το προϊόν είναι ταξινομημένο ως Ηλεκτρικός και Ηλεκτρονικός Εξοπλισμός. Σε περίπτωση που θέλετε ν’ απορρίψετε αυτό το προϊόν, παρακαλείσθε να βεβαιωθείτε ότι
κάνετε την απόρριψη σύμφωνα με την Ευρωπαϊκή Οδηγία σχετικά με τα Απόβλητα Ηλεκτρικού και Ηλεκτρονικού Εξοπλισμού (WEEE) και σύμφωνα με τους τοπικούς νόμους
που σχετίζονται μ’ αυτή την οδηγία.
Για περισσότερες πληροφορίες σχετικά με την Οδηγία WEEE, παρακαλείσθε να επισκεφτείτε την ιστοσελίδα www.fellowesinternational.com/WEEE
Turkish
Bu ürün, Elektriksel ve Elektronik Ekipman olarak sınıandırılmıştır. Bu ürünü ber taraf etme zamanı geldiğinde, lütfen bunun Avrupa Elektriksel ve Elektronik Ekipmanların
Atılması (WEEE) Yönetmeliği ve bu yönetmekle ilgili yerel kanunlar uyarınca yapıldığından emin olun.
WEEE Yönetmeliği hakkında daha fazla bilgi için lütfen www.fellowesinternational.com/WEEE sitesini ziyaret edin
Czech
Tento výrobek je klasikován jako elektrické a elektronické zařízení. Po skončení jeho životnosti zajistěte jeho likvidaci v souladu se Směrnicí 2002/96/ES o odpadu z
elektrických a elektronických zařízeních (OEEZ) a v souladu s místními předpisy, které s touto směrnicí souvisí.
Více informací o směrnici OEEZ najdete na stránkách www.fellowesinternational.com/WEEE
Slovak
Tento produkt je klasikovaný ako elektrické a elektronické zariadenie. Ak nastane čas zlikvidovač tento produkt, zabezpečte, prosím, aby ste tak urobili v súlade s
Európskou smernicou o odpade z elektrických a eletronických zariadeniach (WEEE) a v zhode s miestnymi zákonmi vzčahujúcimi sa na túto smernicu.
Podrobnejšie informácie o Smernici WEEE nájdete na www.fellowesinternational.com/WEEE
Hungarian
Ez a termék Elektromos és elektronikus berendezés besorolású. Ha eljönne az idč, amikor ki kell dobnia a terméket, akkor kérjük, gondoskodjon arról, hogy ezt az Európai
elektromos és elektronikus berendezések hulladékiaról szóló (WEEE) irányelv szerint tegye, megfelelve az irányelvhez kapcsolódó helyi törvényeknek is.
A WEEE Irányelvre vonatkozó további információkért kérjük, keresse fel a www.fellowesinternational.com/WEEE internetes címet
Portuguese
Este produto está classicado como Equipamento Eléctrico e Electrónico. Quando chegar a altura de eliminar este produto, certique-se de que o faz em conformidade com a
Directiva relativa a Resíduos de Equipamentos Eléctricos e Electrónicos (REEE) e em observância da legislação local relativa a esta directiva.
Para obter mais informações sobre a Directiva relativa a Resíduos de Equipamentos Eléctricos e Electrónicos (REEE), visite o endereço www.fellowesinternational.com/WEEE
39
Page 6
Declaration of Conformity
Fellowes Manufacturing Company
Yorkshire Way, West Moor Park
Doncaster, South Yorkshire, DN3 3FB, England
declares that the product
Models P-40 and P-45C
conform with the requirements of the Restriction of Hazardous Substances Directive (2002/95/EC), the Low Voltage
Directive (73/23 EEC) and the Electromagnetic Compatibility Directive (89/336 EEC) and the following harmonized
European Names (EN Standards) and IEC Standards.
Safety: EN 60950-1:2001 ‘Information Technology Equipment’
EMC: Standard
EN 55014-1:2000+A1+A2
EN 55014-2:1997+A1
EN 61000-3-2:2000
EN 61000-3-3:1995+A1
Itasca, Illinois, USA
June 30, 2006 James Fellowes
