Installation Instructions for
P1277
Marcia 1 Light Pendant
Pendant
GP I :ENERAL RODUCT NFORMATION
This product is suitable for dry locations only.
This product may be dimmed with a standard incandescent dimmer.
This instruction shows a typical installation.
1A
1
P1277_
CAUTION - RISK OF FIRE
This product requires installation by a qualified electrician.
Before installing be sure to read all instructions and
TURNTHE POWERTOTHE ELECTRICAL BOX OFF.
TOP
1.0
CHAIN LINK
FIXTURE TOP
FIXTURE LOOP
FIXTURE
LAMP
2
JEWEL
1
Follow enclosed supplement installation instructions for electrical and fixture installation onto house outlet box.
2
Install the lamp by screwing it into the socket. Refer to the label on the lamp socket for Max Wattage information.
3
Install and secure the string of beads by hooking them to the top and bottom of the fixture as shown on drawing.
4
Install the font by hooking the support chains to the bottom of the fixture and to the font, then hook the lower string of
5
5
3
3
3
5
5
STRING OF BEADS
SUPPORT CHAIN
STRING OF BEADS
FONT
BOTTOM
beads to the font and hang the jewel.
Install the fixture to the chain by placing the fixture top over the fixture loop, then opening the bottom chain link and
5
securing it to the fixture loop by closing the link.
1

1A
Ce produit nécessite une installation par un électricien
ATTENTION – RISQUE D’INCENDIE
qualifié.Avant d'installer assurez-vous de lire toutes les
instructions etTOURNER LE POUVOIR DE LA BOITE
ELECTRIQUE OFF
1
HAUT
MAILLON DE CHAÎNE
HAUT DE FIXATION
BOUCLE DE FIXATION
FIXATION
AMPOULE
2
BIJOU
1
Suivez supplément ci-joint des instructions électriques et installation d'accessoires dans la boîte de prise de maison.
2
Installer la lampe en la vissant dans la douille. Consulter l'étiquette sur la douille de lampe pour information Max Wattage.
3
Installer et fixer la chaîne de perles en les accrochant au haut et au bas de l'appareil comme indiqué sur le dessin.
4
Installer la police en accrochant la chaînes de prise en charge vers le bas de l'appareil et à la police, puis accrocher la basse
5
5
3
3
3
5
5
CHAÎNE DE PERLES
CHAÎNE DE SOUTIEN
CHAÎNE DE PERLES
FONTE
INFÉRIEUR
chaîne de perles à la police et accrocher le bijou.
5
Installez l'appareil à la chaîne en plaçant le haut de l'appareil au fil de la boucle de fixation, puis ouvrir le maillon de chaîne
de fond et fixez-le à la boucle de l'appareil en fermant le lien.
2

1A
PRECAUCION – RIESGO DE INCENDIO
Este producto requiere la instalación por un electricista
calificado.Antes de instalar,asegúrese de leer todas las
instrucciones y APAGUE EL PODER DE LA CAJA
ELÉCTRICA NO.
1
ARRIBA
ESLABÓN DE LA CADENA
CAPA DEL FIXTURE
LAZO DEL FIXTURE
FIXTURE
AMPOULE
2
JOYA
1
Siga las instrucciones de instalación incluido suplemento para eléctricos e instalación del luminario en caja de salida de la
5
5
3
CADENA DE PERLAS
3
3
CADENA DE APOYO
5
CADENA DE PERLAS
FUENTE
5
INFERIOR
casa.
2
Instale la lámpara enroscándolo en la toma de corriente. Consulte la etiqueta en el zócalo de la lámpara para información
sobre la Max Wattage.
3
Instale y asegure la cadena de granos, les enganchando a la parte superior e inferior de la lámpara como se muestra en el
dibujo.
4
Instalar a la fuente enganchando la cadenas de apoyo a la parte inferior de la unidad y a la fuente, y luego enganchar la
cadena inferior de granos para la fuente y colgar la joya.
5
Instalar la luminaria a la cadena de colocar la tapa del accesorio sobre el bucle de la luminaria, luego abriendo el eslabón
de la cadena de fondo y asegurar al bucle accesorio cerrando el enlace.
3

SAVETHESE INSTRUCTIONS!
