Assembly Instructions For
F2733/6
(E) 9/11
2
IMPORTANT
TURN OFF THE POWER AT THE MAIN FUSE
OR CIRCUIT BREAKER BOX
BEFORE STARTING INSTALLATION
Carefully unpack and identify all parts
1
5B
3
5A
before assembly. Bulbs not included.
1. Slip fixture loop down through the fixture
wires, and then screw on top of fixture.
2. Follow enclosed supplement installation
instructions for electrical and fixture
installation onto house outlet box. If you
do not have an outlet box at desired
location to attach the fixture then hire a
qualified electrician to create one.
3. Install the center column onto the
threaded pipe.
4. Install the font onto the bottom of the
fixture.
5. A. Install candle tube by slipping through
sockets.
B. Install type-B, candelabra base, of 60
Watt maximum bulbs (not included).
6. Hang all tassels as shown on drawing.
NOTE: To replace broken tassels, extras
4
6
are included in hardware bag. Replace by
gently bending open pin, remove broken
pin, hook new one, then close back pin.
Avoid bending pin into sharp angle.
