Assembly Instructions For
F2583/3
26"
32"
38"
44"
50"
56"
TURN OFF THE POWER AT THE MAIN
4
BEFORE STARTING INSTALLATION
(E) 5/10
62"
68"
74"
80"
IMPORTANT
FUSE OR CIRCUIT BREAKER BOX
X1
X4
2A
Carefully unpack and identify all parts before
assembly. Bulbs not included.
1. Install socket assembly onto center pipe.
2. A. Turn arms so they are equally spaced apart.
B. Gently place glass shade inside of ring.
C. Install arms onto ring by fastening with cap
screws.
3. Install light bulb (not included). See relamping
label at socket area for type and maximum
allowed wattage.
4. Follow enclosed supplement installation
instructions for electrical and fixture installation
onto house outlet box. If you do not have an
outlet box at desired location to attach the
fixture then hire a qualified electrician to create
one.
1
3
2B
2C
