Assembly Instructions For
F2538/3
18-1/2"
24-1/2"
30-1/2"
36-1/2"
42-1/2"
50-1/2"
TURN OFF THE POWER AT THE MAIN FUSE OR
1
Carefully unpack and identify all parts before assembly. Bulbs
not included.
(E) 11/09
56-1/2"
62-1/2"
68-1/2"
74-1/2"
IMPORTANT
CIRCUIT BREAKER BOX
BEFORE STARTING INSTALLATION
3
2B
2A
1. Follow enclosed supplement installation instructions for
electrical and fixture installation onto house outlet box. If
you do not have an outlet box at desired location to attach
the fixture then hire a qualified electrician to create one.
2. A. Slip candle tube onto sockets.
B. Slip candle follower onto candle tubes.
3. Install bulb (not included). See relamping label located at
socket area for type and maximum allowed wattage.
4. Raise cage through socket assembly until it checks inside top
cover. Lock them into position by fastening with finial.
5
