Assembly Instructions For
F2250/3, F2251/4
2
TURN OFF THE POWER AT THE MAIN FUSE OR
BEFORE STARTING INSTALLATION
Carefully unpack and identify all parts before assembly.
Bulb not included.
1. Thread fixture wires through top assembly. Screw top
assembly securely onto top coupler making certain no
slack in wire remain in between.
2. Follow enclosed supplement installation instructions
for electrical and fixture installation onto house outlet
box. If you do not have an outlet box at desired
location to attach the fixture than hire a qualified
electrician to create one.
3. Place Shade over threaded socket then spacer tube and
secure with counter ring.
(E) 10/07
IMPORTANT
CIRCUIT BREAKER BOX
Top Assembly
Coupler
1
Socket
3
4. Install light bulbs (not included). See label located at
socket area for type and maximum allowed wattage.
Shade
Spacer Tube
Counter Ring
Bulb
(not included)
4
