WSG 20-180
Angle Grinder
SERVICE
Tool service and maintenance must be performed only by qualified
repair personnel.
When servicing a tool, only use identical replacement parts available
from FEIN.
Repairs on FEIN Power T ools required the use of special tools (pulling devices
and bearing press). Authorized repair centers have trained repair technicians
and equipment necessary to per-form these repairs. Service or repairs performed
by unqualified persons could result in operator injury.
For the location of the repair center near you, please call 1-800-441-9878.
Monday thru Friday, 9AM to 5PM EST. Or, look on our web site at
www .feinus.com and follow the link to “Authorized W arranty Repair Centers”
FEIN Power Tools
1030 Alcon Street
Pittsburgh, PA 15220
Phone: 412-922-8886
November 7, 2006
Fax: 412-922-8767
T oll Free: 1-800-441-9878
WSG 20-180 Parts List
Item
Item Number Description Reqd
10 3-19-03-214-00-6 MOTOR HOUSING 1
20 3-07-12-090-03-1 BRUSH HOLDER 2
30 3-07-11-143-00-6 CARBON BRUSH 2
40 4-30-70-027-00-0 SCREW 4
60 5-1-275-003-36-2 FIELD COIL 1
70 4-30-72-011-00-8 SCREW 1
80 3-24-27-117-00-8 COVER 1
90 3-24-27-118-00-6 COVER 1
110 3-12-07-251-00-8 COVER 1
120 3-14-28-144-00-5 CONTACT 1
130 3-14-15-092-00-3 WASHER 1
140 3-07-62-254-99-5 ELECTRONIC 1
160 3-14-28-141-00-0 COVER 1
300 3-12-06-114-03-1 GEAR HOUSING ASSEMBLY 1
310 4-17-06-030-00-7 NEEDLE BEARING 1
320 3-24-19-122-00-9 GEAR HOUSING COVER 1
330 3-06-01-110-00-5 FELT RING 1
340 3-24-11-084-00-9 COVER 1
350 4-17-01-224-02-4 BALL BEARING 1
360 3-24-16-105-00-8 COVER 1
370 4-30-64-002-04-3 SCREW 5
380 3-34-06-291-00-3 SPINDLE 5/8 - 11 1
430 3-26-01-273-00-6 RING 1
445 3-38-09-232-01-6 GEAR SET 1
520 3-26-24-118-02-2 RING 1
530 4-24-43-004-05-7 LOCK WASHER 4
540 4-30-64-009-05-4 SCREW 4
560 3-05-07-230-00-9 BUSHING 1
570 3-02-17-335-00-5 PIN 1
580 4-06-12-137-00-8 SEALING RING 1
590 3-09-01-354-00-4 SPRING 1
600 3-28-05-180-00-4 BUTTON 1
650 3-05-07-169-00-7 BUSHING 1
660 5-32-75-002-36-0 ARMATURE 1
670 3-24-16-106-00-1 MOUNTING PLATE 1
680 3-06-01-050-00-2 FELT RING 1
690 3-24-11-083-00-1 RING 1
700 4-17-01-213-09-6 BALL BEARING 1
720 4-24-43-003-04-3 LOCK WASHER 2
740 3-05-07-168-00-3 BUSHING 1
750 4-17-01-207-03-3 BALL BEARING 1
760 4-30-70-029-00-2 SCREW 2
770 4-30-70-030-00-4 SCREW 2
780 3-18-10-245-01-2 WHEEL GUARD ASSEMBLY 1
790 3-21-19-032-00-2 HANDLE 1
800 6-38-01-095-00-8 INNER FLANGE 1
810 6-38-02-098-00-7 OUTER FLANGE 1
820 3-14-15-089-00-9 BOLSTER 1
840 3-07-19-613-01-2 CONNECTION CABLE 1
900 3-12-04-167-00-0 HANDLE 1
910 3-07-01-278-01-0 SWITCH ASSEMBLY 1
915 4-30-41-001-99-4 SCREW 1
920 3-14-13-094-00-7 PROTECTING SLEEVE 1
935 3-07-07-398-01-9 CABLE 1
940 3-24-31-042-00-8 CLIP 1
950 4-30-70-035-00-2 SCREW 1
955 3-07-17-203-01-4 SUPPORT 1
960 4-30-41-016-04-2 SCREW 2
980 3-09-01-343-00-7 SPRING 1
990 3-28-16-057-00-7 TRIGGER 1
1000 3-12-04-168-00-8 HANDLE, UPPER PART 1
1010 4-30-70-031-00-3 SCREW 8
