MF 12-180
Dustless Construction Cutter
SERVICE
Tool service and maintenance must be performed only by qualified
repair personnel.
When servicing a tool, only use identical replacement parts available
from FEIN.
Repairs on FEIN Power T ools required the use of special tools (pulling devices
and bearing press). Authorized repair centers have trained repair technicians
and equipment necessary to per-form these repairs. Service or repairs performed
by unqualified persons could result in operator injury.
For the location of the repair center near you, please call 1-800-441-9878.
Monday thru Friday, 9AM to 5PM EST. Or, look on our web site at
www .feinus.com and follow the link to “Authorized W arranty Repair Centers”
FEIN Power Tools
1030 Alcon Street
Pittsburgh, PA 15220
Phone: 412-922-8886
Nov . 24, 2004
Fax: 412-922-8767
T oll Free: 1-800-441-9878
FEIN Power Tools
t
r
6
MF 12-180 Parts Lis
Item Item Numbe
10 3-24-31-021-00-7 CABLE CLAMP 1
20 4-30-70-001-00-6 SCREW 2
30 3-24-31-040-00-6 SUPPORT 1
40 3-07-62-216-99-6 ELECTRONIC 1
50 4-17-01-001-17-2 BALL BEARING 1
60 3-07-12-088-02-9 BRUSH HOLDER 2
70 3-07-11-136-00-2 BRUSH 2
80 4-30-70-018-00-9 SCREW 4
90 3-19-01-114-01-4 MOTOR HOUSING 1
100 5-3-273-001-11-7 ARMATURE 1
110 3-14-28-118-00-7 AIR CONDUCTING RING 1
120 3-24-16-098-00-5 COVER PLATE 1
140 4-30-70-007-00-2 SCREW 4
200 3-12-06-110-01-5 GEAR HOUSING 1
210 4-17-05-019-00-1 NEEDLE BEARING 1
220 3-09-01-032-00-3 SPRING 1
230 3-02-17-327-00-3 PIN 1
240 4-06-12-137-00-8 SEALING RING 1
250 3-28-05-185-00-2 BUTTON 1
260 3-24-19-115-00270 3-34-06-284-00-9 SHAFT 1
280 4-17-01-010-05-4 BALL BEARING 1
290 3-24-16-101-00-9 COVER PLATE 1
305 3-38-09-229-01-2 BEVEL GEAR ASSY 1
320 3-26-24-117-00-9 WASHER 1
330 4-24-43-003-04-3 LOCK WASHER 4
450 4-17-01-007-22-6 BALL BEARING 1
480 3-28-05-156-00-8 SLIDING SWITCH 1
490 5-1-273-001-11-5 FIELD COIL 1
500 4-30-70-017-00-1 SCREW 2
510 3-28-16-055-00-0 SWITCH BAR 1
520 3-28-16-052-00-4 SWITCH ROD 1
530 4-30-41-039-99-9 SCREW 2
540 3-07-01-218-00-3 SWITCH 1
550 3-12-01-100-00-9 COVER 1
560 3-14-15-082-00-4 BOLSTER 1
570 3-14-13-007-00-7 CABLE PROTECTIVE SLEEVE 1
580 3-07-05-035-01-3 CABLE 1
700 6-38-01-178-00-4 INNER FLANGE 1
710 3-13-36-017-00-7 GUARD MOUNTING SPACER 1
730 4-30-35-010-04-6 SCREW 1
740 3-13-36-010-00-2 BLADE SLIDE PLATE 1
Description Reqd
BEARING PLATE 1
750 3-13-36-011-00-1 DEPTH STOP ROD 1
760 4-20-01-007-05-3 NUT 1
770 3-13-36-012-00-4 SLEEVE 1
780 4-30-35-013-05-8 SCREW 1
790 3-13-36-013-00-8 WASHER 1
800 3-13-36-014-00-6 SLEEVE 1
810 3-13-36-015-00-0 THUMB SCREW 1
820 3-13-36-002-01-4 BLADE GUARD WITH VAC ATTACHMENT 1
830 3-13-36-006-00-4 EDGE CAP 1
840 3-13-36-007-00-8 SCREW 2
850 3-13-36-008-00-6 SCREW 2
860 3-13-36-003-00-9 LOCKING TAB 1
870 3-13-36-020-00-1 WASHER 3
880 3-13-36-005-00-1 SCREW 3
890 3-13-36-004-00-7 SCREW 2
900 3-13-36-016-00-3 SPRING 1
910 6-35-02-146-01-1 SAW BLADE 1
920 4-30-69-005-04-4 SCREW SHOE 4
930 3-13-36-009-00-0 GUARD COVER 1
940 3-13-36-018-01-4 HANDLE ASSY 1
950 3-13-36-019-00-9 SCREW 2
960 4-30-35-008-04-0 SCREW 4
