BLs 1.6
Sheet Metal Shear
SERVICE
Tool service and maintenance must be performed only by qualified
repair personnel.
When servicing a tool, only use identical replacement parts available
from FEIN.
Repairs on FEIN Power T ools required the use of special tools (pulling devices
and bearing press). Authorized repair centers have trained repair technicians
and equipment necessary to per-form these repairs. Service or repairs performed
by unqualified persons could result in operator injury.
For the location of the repair center near you, please call 1-800-441-9878.
Monday thru Friday, 9AM to 5PM EST. Or, look on our web site at
www .feinus.com and follow the link to “Authorized W arranty Repair Centers”
FEIN Power Tools
1030 Alcon Street
Pittsburgh, PA 15220
Phone: 412-922-8886
April 15, 2004
Fax: 412-922-8767
T oll Free: 1-800-441-9878
Fein Power Tools
BLs 1.6 Parts List
Item
10 3-19-01-109-02-4 MOTOR HOUSING 1
20 3-28-16-051-00-1 ROD 1
30 3-28-05-152-00-9 SWITCH BUTTON 1
40 5-1-272-004-11-9 FIELD COIL 1
50 4-30-70-014-00-0 SCREW 2
60 3-14-28-114-00-8 AIR CONDUCTING RING 1
70 3-07-12-087-01-5 BRUSH HOLDER 2
75 3-07-17-193-00-0 BRUSH CAP 2
80 3-07-11-129-00-9 CARBON BRUSH 2
90 4-30-70-015-00-4 SCREW 2
100 3-07-01-060-00-0 SWITCH 1
120 3-07-22-178-01-6 CAPACITOR 1
130 3-24-31-026-00-9 CABLE CLAMP 1
140 4-30-70-001-00-6 SCREW 2
150 3-24-27-108-01-6 COVER 1
160 4-30-70-003-00-3 SCREW 1
170 4-30-70-003-00-3 SCREW 2
180 3-07-07-370-01-8 CABLE 1
190 3-14-13-164-00-9 CABLE PROTECTING SLEEVE 1
250 5-3-272-005-11-5 ARMATURE 1
300 4-17-01-001-17-2 BALL BEARING 2
310 3-26-12-125-00-0 PACKING RING 1
320 4-30-70-026-00-6 SCREW 4
330 3-15-06-353-00-7 INTERMEDIATE BEARING 1
340 3-06-10-033-00-0 SEALING 1
370 4-17-01-202-01-8 BALL BEARING 1
410 4-02-01-036-00-6 CYLINDRICAL PIN 1
420 3-13-08-081-00-6 HOUSING 1
430 3-13-08-083-00-3 PLUNGER 1
440 3-13-08-084-00-1 CONNECTING ROD 1
450 3-13-08-085-00-5 THREATED BOLT 1
460 3-13-08-070-00-8 ECCENTRIC SHAFT 1
480 3-13-08-072-00-0 FIXED BLADE 1
520 3-13-08-087-00-2 HAND GUARD 1
540 3-36-57-166-00-9 SPUR WHEEL 29T 1
560 4-30-35-123-10-2 SCREW 1
590 3-13-08-086-00-8 CONNECTING ROD BOLT 1
600 4-17-01-234-02-3 BALL BEARING 1
610 4-17-05-028-00-6 NEEDLE BUSHING 1
630 4-30-35-004-04-1 SCREW 1
640 4-30-35-113-04-1 SCREW 1
650 4-30-64-017-05-1 GUARD BOLT 1
660 4-30-58-013-04-7 SCREW 1
670 4-20-01-041-00-0 NUT 1
680 3-13-08-082-00-9 SHOE 1
700 4-30-35-014-05-8 SCREW 2
710 4-24-43-004-05-7 LOCK WASHER 2
Item Number Description Reqd.
