Feima Robotics J.ME Quick Start Manual

Quickstart Guide V 1.0

© All rights reserved. Shenzhen Feima Robotics Co., Ltd. (www.feimarobotics.com)

Requirements for Flight Environment

1. Never fly in bad weather conditions, such as gale (Grade 4 or higher), snow, rain and fog.

2. Fly in broad space with no tall buildings nearby, for reinforced concrete buildings will affect

compass and shield GPS signal, which finally results in unsafe flight due to poor positioning

performance or failure in positioning.

3. While flying, please keep the aircraft in sight and away from obstacles, the crowd and water

surface.

4. Never fly at the region with high-tension wire, transformer and communication base station,

launching tower, satellite antenna, high iron stand and steel bar for fear of interfering signal.

While flying, please keep the aircraft in broad space and in sight and control flying speed.

Never fly in bad weather conditions, such as gale (Grade 4 or higher), snow, rain, lightening and

fog.

While flying, please keep away from tall buildings, electrical tower, signal tower, high iron stand

and steel bar, tall trees, the crowd and water surface.

If the aircraft flies above 3,500 m altitude, the properties may be affected by decline of

aircraft battery and dynamical system properties due to environmental factors so be careful with it.

GPS positioning of aircraft is not available in arctic and antarctic circle but the user can fly aircraft

with visual positioning system.

No flying

About your J.ME

① Two axial stabilized cloud platform

⑥ Optical flow module

⑪Status indicator

② Blade

⑦ Built-in microphone

⑫ USB interface

③ Power motor

⑧ Intelligent battery

⑬ Power key

④ Obstacle avoidance module

⑨ Ultrasonic module

⑭ Power indicator

⑤ Built-in speaker

⑩ Battery safety buckle

While installing battery, please ensure ⑩ battery safety buckle is installed in place!

The head

The tail

Preparation

Downloading APP J.ME Fly

J.ME Fly is the supporting intelligent APP developed for intelligent aircraft J.ME and the user can

realize various functions of aircraft with J.ME Fly, such as intelligent flight control, shooting and

recording, photo and video editing and social sharing; it can bring the user with unprecedented

perfect intelligent flying experience.

Before using this product, you need to download and install J.ME

Fly App by scanning the QR code on the right and enter

downloading page or explore J.ME Fly App at App Store or

Android market.

Installing the Propeller

Remove the self-locking propeller attached in packing box and identify the positive and negative

propeller according to color marked on top.

Contra-rotating propeller

Contra-rotating motor

Forward-rotating motor

Forward-rotating propeller

The color at the top of motor thread

column and that at the top of propeller

are corresponding to each other so please

rotate propeller at arrow direction.

The indication color is subject to

material object!

Battery Power Check

Short press the power checking button and the power indicator will display the current battery

volume.

Green on 91%~100%

Green flashing 76%~90%

Yellow on 61%~75%

Yellow flashing 46%~60%

Red on 31%~45%

Red flashing 16%~30%

Red quick flashing 0%~15%

The intelligent battery is provided with 1 power checking button and one 3-color LED indicator as

well as battery cell protection function so that the corresponding countermeasures will be done in

case of over-voltage, under-voltage, over-current and over-heat of battery cell; the power checking

button is not able to start battery power supply.

Working electric power check

Short press power key and the power indicator can display volume based on status definition in

intelligent battery and extinguish in 3 s.

Green on The volume is sufficient.

Flashing in Red for 3 times and then off

Low Battery

Charging

① Connect power cord and adapter;
② Connect the power cord plug to power socket;
③ Connect the power adapter and intelligent battery to start charging.

In charging, the power indicator will be

on and current volume will be displayed.

If the power indicator is off, it means the

intelligent battery is charged fully so please

stop charging by disconnecting the adapter.

Please avoid unattended charging.

Power supply socket

Aircraft preparation

Aircraft startup and shutdown

Short press power switch and long press it for 3s and

the aircraft will start up or shut down.

Connect aircraft and J.ME Fly

If the aircraft is started up, connect corresponding

Wi-Fi signal with mobile equipment and the default

name of Wi-Fi is JME-XXXXX (you can check it on

packing box) and the default password is jme12345.

After the mobile phone is connected to Wi-Fi, please

open J.ME Fly and check connection status.

Normal connection status Abnormal connection status

If it displays abnormal connection, please reconfirm Wi-Fi connection status.

Compass Calibration

Calibrate the compass each time after starting up J.ME power supply; otherwise, the system

may not be able to work normally and it may affect flight safety; the compass can be disturbed by

other electronic equipment easily, resulting in abnormal data, affecting flight and even causing

flight accident. The frequent calibration can keep the compass at the best working conditions and

the user can prepare flight after calibrating compass.

Tips:

 Calibrate compass by keeping it 1 m above ground;
 Never calibrate at high magnetic field, such as magnetic mineral, parking lot and

underground reinforced concrete buildings;

 Please avoid taking any magnetic article, such as key or mobile phone while calibrating;
 Calibrate by keeping off large block of metal;
 If the yellow lamp of aircraft indicator still flickers after calibration, check APP display and

calibrate compass again.

Calibrate the compass through 3 circles.

China Telecom

Wireless LAN

Wireless LAN

Selecting network

Setting

Horizontal calibration

Compass calibration

 Put compass on ground horizontally.
 Avoid too fast rotating speed.
 Rotate anticlockwise.

Start calibration.

Calibration Steps

Please select an open site and calibrate based on steps below.

1. Enter J.ME FLY setting interface, select the “enter flying setting page” at top right corner

and slide to “compass calibration” interface to calibrate.

2. Click “Start Calibration”; if the red aircraft status indicator becomes normally on, the compass

calibration procedure starts and then operate following coordinate in the diagram below and

following steps.

Rotate the aircraft body by 360 along Axis Z, and the yellow indicator lamp will turn on after

completion;

Rotate the aircraft body by 360 along Axis Y, and the green indicator lamp will turn on after

completion;

Rotate the aircraft body by 360 along Axis X, the red indicator lamp at head will turn on and

the green indicator lamp at tail will flicker after completion.

Re-calibration is needed if:

The compass data are abnormal and the yellow indicator lamp flickers;

The flight site is far away from last one calibrated by compass;

The structure of aircraft is changed;

During flying, the aircraft drifts seriously or is not able to fly in a straight line; or

Battery is changed.

For more about compass calibration, please check relevant teaching videos.

Main Interface

Connected

Intelligent flight Return flight Landing

1 GPS information status: GPS icon is used for displaying strength of GPS signal;

if the GPS satellites reach 12 grids or above, the aircraft will enter safe flying

status.

2 Distance: The horizontal distance between aircraft and return point

3 Connection status of aircraft: It is used for identifying connection status between

APP and aircraft.

4 Flight speed: flying speed of aircraft

5 Battery status: Displaying real-time remaining volume of intelligent battery

6 General setting: Click the button to enter relevant parameter and configuration

interfaces of aircraft.

7 Start and stop recording

8 Video sharing button: The users can upload the videos shot by aircraft to social

network site, MicroBlog or moments directly.

9 Media library: The users can edit and process the works shot in media library

before uploading.

10 Height scale: The height of current position of aircraft from flying ground.

11 Shutter button: Shooting photos

12 Selection of intelligent flight mode: voice control, motion control, visual tracing

and visual surrounding are available.

13 Return: The aircraft will return from current position to the original takeoff point

and land off.

14 Land: The aircraft lands to the ground vertically from current position and shuts

down motor.

Flight Restriction Interface

Restrict the aircraft to fly within horizontal distance and ground height from takeoff point.

Instant locking: Double click to stop the propeller immediately to brake under emergencies; then aircraft will land directly;

operate with care

Height restriction

Flight protection

Distance restriction

Virtual fence

On Off

Intelligent obstacle avoidance

On Off

Return height

Operation Setting Interface

Camera Setting Interface

Shooting mode: Under shooting mode, the camera can be set as single shooting , 3, 5 and 7

times continuous shooting mode 5, 10, 15 and 20 s timing shooting mode and 5, 10, 15
and 20 s delay shooting mode .

Shooting effect: The user can set shooting effect as required: standard, black & white or negative
film.

Video format: The user can save the video in MP4 or 3GP format.
Exposure Setting Interface

Control Mode

Control Setting

American Japanese

Forward

Up

Down

Back

Left

Right Left

Right

Operation sensitivity

Shooting mode

Shooting effect

Video format

Shooting setting

Standard Black & white negative film

Exposure setting

Automatic exposure

Manual exposure

White balance

The user can set automatic exposure without complex operation.

The user can have more professional settings, for example setting shutter speed as 1 s ~1/8,000

s; and the ISO can be set as 100, 200, 400, 800, 1,600, 3,200 and 6,400.

It provides users with more professional camera setting. AUTO can adjust the white balance.

Image Quality Interface

Photo Size: The user can set photo dimension as 16:9 or 4:3 based on demand.
Photo quality: The user can set photos to high quality, common quality or low quality.
Video quality: The user can set video to 4K, 1,080 P and 720 P.
Other Columns

The user can restore factory settings or format memory card in other columns.

Synchronization time: Synchronize the time of aircraft with the time of mobile phone.

Basic Flight Steps

1. Put the aircraft on flat and smooth ground and face to the aircraft end.

2. Start up the aircraft.

3. Operate J.ME FLY App, connect mobile equipment and enter J.ME FLY control interface.

4. Calibrate magnetometer.

5. After the aircraft GPS signal is normal (it is suggested the GPS satellites is more than 12),

enter safe flight mode; long press take-off button for 3 s until the aircraft flies to 1 m high.

6. Slide “forward” button to move the aircraft away from operator; slide “back” button to fly

nearer; slide “left” button to fly left; slide “right” button to fly right.

7. To land off, press “land” button and the aircraft will land to the ground vertically from current

position and the motor will stop rotating.

8. After shutdown, close the aircraft and J.ME FLY.

Photo Size

Image quality

Photo Quality

High

Common

Low

Video Quality

Time Synchronization

Others

Storage

Sync

Format

Restore factory settings

Instant Take-Off

Use instant take-off function following the steps below:

1. Open J.ME FLY APP to enter the main interface;

2. Confirm the GPS satellites of aircraft reaches 12 or above at outdoor environment.

3. Before flying, check the aircraft based on interface tips;

4. Long press take-off button at lower right corner for 3s and the aircraft will take off; the

aircraft will fly to 1 m above ground and keeps hovering.

One-key Landing

Make sure the surrounding environment meets safe landing conditions; press the “land” button at

lower right corner and “confirm” to enter one-key landing, the aircraft will start up intelligent

landing till the motor stops rotating.

Safe landing conditions: flat ground without water or stone

Connected

Connected

Take off

Connected

Landing or not?

Confirm

Cancel

Intelligent flight Return Land

Control Mode

Control of Virtual Remote Sensing Rod

Slide the upper slider of main interface with your finger and the aircraft can move at the direction

you require; for example, if you slide “forward” slider, the aircraft will move forward immediately

till you loosen the rocker.

Motion Sensing

After entering motion sensing control, long press the screen and the aircraft will move forward,

backward, left or right correspondingly when the mobile equipment moves forward, backward,

left or right.

Voice Operation
APP voice control

Press voice recognition key and give a voice

command as per the picture above; for specific

commands, click voice command instructions.

Intelligent J.ME

J.ME supports intelligent open voice chat;

speak out the following commands to J.ME

(aircraft), the J.ME senior functions can then be

enabled.

Command

Aircraft actions

Reset network

After confirmation, reset SSID and
default password of J.ME.

Start chatting

J.ME will enter voice chat mode
under non-flying mode.

Stop chatting

Exit from chat mode

Besides the above commands, the user can also click in mobile phone APP to start chatting;

after the user enters voice chat mode, J.ME will close flight function and APP will be unable to

connect J.ME. Long press the power key of aircraft and J.ME can also enter or exit voice chat

mode.

Connected

Connected

Connected

Connected

Fly 5 m forward

Start chatting

Aerial Shooting Tips and Skills

Check the aircraft before flight;

Shoot under safe flight status;

Shoot on sunny and breezeless days;

Set camera based on shooting demand, for example, photo format and exposure rate.

Before flying, test flight to plan air line and find a view.

While flying, push the rod at the smallest extent to keep aircraft flying stably.

Appendix: Status Indicator Lamp

The aircraft has:

4 groups of LED status indicators in 3 colors (single rated power is about 30 mW); the functions

of two LED lamps at the head are the same and can be controlled uniformly; meanwhile the

functions of two LED lamps at tail are the same and can be controlled uniformly; the status of

course lamp is defined below:

Functions

Requirements

System startup

The four LED lamps, such as red, yellow and green ones flicker in turn.

Flying allowed

The red lamp at head keeps normally on while the green one at tail flickers.

Magnetometer needs

calibrating

The red lamp at head keeps normally on while the yellow one at tail flickers.

Calibration mode of

magnetometer

All lamps are off; if rotating aircraft horizontally, the red lamp flickers; after completing

horizontal calibration, the green lamp keeps normally on; if rotating aircraft vertically,

the red lamp flickers; after completing vertical calibration, the green lamp flickers; the

yellow lamp flickers if something abnormal.

Low battery alarming

The red lamp at head keeps normally on and the red one at tail flickers slowly.

Serious low battery

alarming

The red lamp at head keeps normally on while the red one at tail flickers quickly.

Flying not allowed

The four LED red lamps keep normally on.

Parameters

Aircraft

Weight (including battery):

About 550 g

Dimensions (excluding

propeller):

169 mm  169 mm  70 mm

Max. applied altitude:

3,500 mm

Endurance:

23 min

Working ambient temperature:

-10 ℃ ~ + 40 ℃

Max. wind bearing grade:

Hovering under Grade 4 (5.5 m/s ~ 8.3 m/s)

Positioning system:

Outdoor: GPS/ GLON ASS/ Beidou three-mode satellite

positioning: indoor: optical flow + ultrasonic wave

Controlled distance: 200 m

Image transmission: 100 m (open without interference)

Max. horizontal flight speed:

8 m/s

Hovering Accuracy

GPS hovering accuracy

Horizontal position accuracy:

±1 m

Vertical position accuracy:

±0.5 m

Optical flow ultrasonic wave

hovering accuracy

Horizontal position accuracy:

± 0.3 m

Vertical position accuracy:

± 0.1 m

Cloud platform

Dual-axial stability

augmentation

Angle of Pitch 15 ~90 (downward), Aileron roll ± 25

Foresight obstacle sensing
system

Obstacle sensing scope:

0.06 ~ 2 m

Applied environment:

Indoor

Visual positioning system
under vision

Speed measurement scope:

Flight speed < 4 m/s (height: 2 m; abundant sunlight > 15 Lux)

Height measurement scope:

0.35 – 3 m

Accuracy hovering scope:

0.35 – 3 m

Applied environment:

There is rich texture on surface and the sunlight conditions are

sufficient (>15 lux, normal light conditions of indoor

fluorescent lamp)

Wi-Fi

Wi-Fi frequency band:

2.4 GHz; 5 GHz

Transmitting power (EIRP): 2.4 GHz: 18 dBm; 5 GHz: 18 dBm

Camera

Image sensor:

1/3.06 inch CMOS; efficient 13 mega pixel

Lens:

FOV 76; 28 mm (35 mm format equivalent) focus point

infinity; f/ 2.0

ISO scope:

100, 200, 400, 800, 1,600, 3,200 and 6,400; the efficient

exposure mode is manual exposure and default: 100

Electronic shutter speed:

1 s ~ 1/8, 000 s

Max. resolution ratio of photo

4,096 * 3,072

Photo shooting mode

Single shooting:

Support taking a candid photograph, default: single shooting

Continuous shooting:

3, 5, 7 photos; default: 5 photos

Timing shooting:

5 s, 10 s, 15 s and 20 s; default: 10 s

Delay shooting:

5 s, 10 s, 15 s and 20 s; default: 10 s

Resolution ratio of video

[4 K]:

3,840  2,160, 20 fps

[1,080 p]:

1,920  1,080, 30 fps, default: 1,080 p 30 fps

[720 p]

1,280  720, 30 fps

Image format:

JPG

Video format:

MP4, 3 GP

Working ambient environment:

-10℃ ~ 40℃

Internal memory

32 GB

Charger

Voltage:

16.8 V

Power:

57 W

Battery (FM 3000)

Rated capacity:

3,000 mAh

Rated energy:

43.2 Wh

Nominal voltage

14.4 V

Battery type:

LiIon 4S

Working ambient environment:

-10℃ ~ 40℃

Charging restriction voltage:

16.8 V

App

App Name:

J.ME Fly

Real-time image transmission:

1,280  720 @ 30 fps

Time delay:

150 ms (subject to real shooting environment and mobile

equipment)

System Requirements

Android 4.3 or higher version, iOS 9.0 or higher version

Warranty Card

Purchase Information

Serial No.: Date of purchase:

Dealer: Tel.:

Add.

User: Tel.:

Add.:

Maintenance Records

Repair Date

Fault and Repair

If any maintenance service is needed, please feel free to call your dealer or contact the customer

service staffs via:

E-mail: J.ME_service @ feimarobotics.com

Hotline: [phone]

Warranty Instructions

1. Please read the following warranty articles and clauses carefully to ensure warranty.
(1) The warranty for aircraft (excluding propeller) and battery remains valid for 12 and 6

months as of date of purchase; in case of maintenance needed, the user should provide

this warranty card and valid purchase certificate (for example, invoice). If the user is not

able to provide valid certificate, the warranty period shall be calculated as of date of

delivery.

(2) If the product has any failure (judged by the Company’s formal employees) under the

premise that the user uses the product in strict accordance with the instruction during

warranty period, we will provide corresponding maintenance for free.

2. We do not provide warranty service for any of the following cases happened within warranty

period but the user may select paid maintenance service:

(1) The user uses the product by mistake, improperly or going against product instruction

during use or connects to unsuitable power supply continuously;

(2) The user makes maintenance improperly or deals with any maintenance, refitting or

disassembly in need of authorization arbitrarily;

(3) The product is impacted or squeezed strongly or put at inappropriate environment (for

example, water and fire);

(4) The user operates the aircraft at high altitude area, in rainy, snowy, gale or any other

inappropriate weather conditions;

(5) The product has any failure or is destroyed because of any accident or other inevitable

external factor.

3. The appearance of product is not warranted.

4. The user can still enjoy our warranty service upon expiration of warranty period by paying

corresponding costs and expenses.

Packing List of J.ME

Before using the product, please check if the product package includes all the following articles/.

In case of any omission, please feel free to contact your dealer.

J.ME body  1

Propeller  4

Intelligent battery 1

Propeller fixing clamp  1

Power adapter  1

Portable paddle bag  1

Power cord  1

Chafing mat  1

TYPE-C USB wire  1

Document  1

Safety Instruction of Battery

Disclaimer

This Manual is applicable to J.ME aircraft battery produced by Shenzhen Feima
Robotics Co., Ltd. (hereinafter referred to as “this Product”) and sets down the
operation and maintenance safety of this Product. Prior to use, please read through the
instructions and warnings stated herein and use this Product in a standard manner. We
bear no liabilities for the consequence caused by the user’s improper use.
Vocabulary
The terms stated herein are used for describing the potential dangers caused by the
improper use of this Product via classification.

Notes: Failure in abiding by this Manual will lead to property loss and slight injury.
Warning: Failure in abiding by this Manual will lead to property loss, major accident

and serious injury.

Warning!

It is a MUST to operate this Product after reading through the whole safe use guide of
intelligent battery and getting familiar with product functions. Failure in using this
Product correctly may lead to serious injury of the operator or others or product
damage and property loss. In light this Product is used for unmanned aerial vehicle
and the procedures are completed, it is required to get familiar with it for certain time
before using it safely and operation must be based on some basic common knowledge.
Failure in having strong safety awareness or operating properly may lead to the
damage of this Product or accessories and property loss and even serious injury of the
operator or others. Keep this Product beyond the reach of kids. Please operate this
Product by abiding by the operating instruction. This Manual contains safety,
operation and maintenance information. Please read through this guide and all
instructions and warnings of Operating Manual before your assembly, setting and use.

Safe Use Guide

Warning: Failure in using, charging or saving this Product correctly may lead to

fire disaster, property damage or personal injury. Please do use this Product as
per the following safe use guide.

1. Keep this Product away from any liquid, never soak it in water or make it wet.

Never use this Product in rain or humid environment. Decomposition reaction may
happen if the internal side of this Product contacts water, which may lead to battery
spontaneous ignition or even explosion.

2. Never use the battery in bulged package, with liquid leaked or damaged package.

Should the above happen, please contact us for further treatment.

3. Before installing this Product or uninstalling it from the aircraft, remember to

power off since battery installation and uninstalling when it is powered on may
damage power interface.

4. Use this Product at -10℃-40℃ ambient temperature because too high temperature

(higher than 75 ℃) may lead to fire and even explosion. Moreover, too low
temperature (lower than -10℃) may seriously damage this Product.

5. Never use this Product in strong static or magnetic field environment; otherwise,

the battery protection panel will be a failure, resulting in the serious fault of aircraft.

6. Never dismantle this Battery by any means or pierce this Product with something

sharp; otherwise, it may lead to fire or even explosion.

7. The internal liquid of this Product is strongly corrosive; leave it away immediately

if any leakage. If the internal liquid splashes to human skin or eye, please wash with
clear water for at least 15 min and see a doctor immediately.

8. If this Product falls from the aircraft, use it again after making sure there is no

damage, liquid leakage or deformation.

9. If this Product falls into water when the aircraft flies or under other circumstance,

please uninstall this Product immediately and put it in a safe and open place. Leave it
away until it is totally dried. Never use the dried battery but scrap it properly as per
the method stated herein. If fire happens to this Product, put off fire with solid
extinguishing apparatus according to the following sequence: water or spraying sand
fire blanket, dry powder and carbon dioxide extinguisher.

10. Never put this Product in micro-wave oven or pressure cooker.

11. Never put the cell of this Product in the plane of electric conductor.

12. Never short circuit the anode and cathode of this Product with wire or other metal

objects.

13. Never collide battery or put heavy articles on battery or charger.

14. In case of any dirt on the battery interface, remove it with dry cloth; otherwise, it

may lead to poor contact, causing energy consumption or charging failure.

15. Never use the battery that is not officially supplied by us. We bear no liabilities for

the battery accident or flight fault caused by the batteries not supplied by us.

Charging

1. Charge this Product with the charger supplied by us; otherwise, we bear no

liabilities for the consequences arising therefrom;

2. Charge this Product by putting it, as well as the charger, in the places where there

are no inflammables and combustibles nearby, such as cement ground. Pay attention
to charging process to avoid accident. Never charge this Product with unattended
status.

3. Never charge this Product soon after the applied aircraft stops flying. This Product

is in high temperature at that time and compulsory charging may damage this Product
very seriously. It would be the best to charge when this Product is cooled to room
temperature naturally. Charging in an ideal environment (10~40℃) will extend the
service life of this Product significantly.

4. Disconnect the charger and this Product after full charging. Check and maintain this

Product regularly and always check the parts such as cell and plug. Never clean this

Product and charger with alcohol or other combustible agent or use a damaged
charger.

Storage & Transportation

1. Keep this Product beyond children's reach. If children swallow it by accident, see a

doctor immediately.

2. Never save this Product near heat source, such as direct sunshine or in vehicle, fire

source or heating furnace in hot summer days. This Product is saved at an ideal
temperature of 22~28℃.

3. Keep the place where this Product is saved dry and never save this Product in water

or in somewhere that water leakage may happen

4. Avoid mechanical impact, grinding, impaling or dropping this Product or shorting

circuit it artificially.

5. Never save or convey this Product together with glass, watch, metal necklace, hair

pin or other metal objects.

6. Never convey the damaged ones. If this Product needs conveying, discharge it

below 50% electric power.

Discard

Abandon this Product in the designated recycling bin after discharging it fully. As this
Product is hazardous chemical, never abandon it in common wastes bin. Scrap it if
water enters. For relevant details, please abide by the laws and regulations on battery
recycling and abandonment.

Maintenance

1. Never use charger in extremely high or low temperature environment.

2. Never save this Product in the environment above 60℃;

3. This Product is specially for UAV so it should be used under low temperature

environment (-10~5℃). Sharp volume reduction of this Product may lead to sharp
reduction of flight time. If using this Product under such environment, please fully
charge and insulate it in advance.

4. Never use this Product in the environment where it is lower than -10℃.

5. It is recommended to heat this Product above 5℃ before installed to aircraft and

temperature above 20℃ through heating would be the best.

Boarding Tips

Before taking this Product to airplane, discharge it below 25% electric power and
avoid fire source before discharging.

Notes: This Product is specially designed for UAV so please use it by abiding by

the safe use guide and product manual of UAV. While both are used, do
remember to abide by the followings:

Use

1. Ensure this Product is fully charged before take-off each time.

2. Never apply this Product to any unmatched aircraft.

3. If this Product or aircraft enters low power alarm mode, land and stop flying

immediately; change a new battery or charge this battery after it cools naturally.

Charging

This Product will stop charging automatically after it is fully discharged. Disconnect
this Product and charger after this Product is fully charged.

Storage & Transportation

1. This Product will discharge to 40%-65% electric power if not used for more than 2

days; while discharging, the temperature may rise, which is quite normal. Save this
Product in a well-ventilated and dry indoor environment instead of a sealed
environment. Special battery box is recommended.

2. Never save this Product in the long run after fully discharging it (for instance, after

the aircraft lands automatically) to avoid over-discharge, which may lead to cell
damage and recovery failure.

3. If this Product is in extremely low power or has not been used for a long time, it

will enter deep sleep mode. Charge it if trying to awaken it.

4. Take out of this Product from aircraft if not used for a long time.

Scrap

1. If this Product cannot be fully discharged thoroughly due to switch failure or water

soaking, never put it in battery recycle bin but contact professional battery recycle
agents for further treatment.

2. Scrap the battery that cannot be started after excessively discharged.

Maintenance

1. Never charge this Product excessively to avoid damaging cell.

2. An idle battery may have lower performance.

3. Charge and discharge this Product for about every three months to maintain its

activity and extend service life.

Disclaimer

Thanks for your confidence in purchasing our robot. This product is within the scope
of special control so juveniles below the age of 18 are forbidden to use it. To better
use this Product and ensure your safety, please read this disclaimer carefully before
using. You are seen as having acknowledged all the contents stated herein once using
this Product!
This product refers to the small UAV developed by Shenzhen Feima Robotics Co.,
Ltd. (hereinafter referred to as “the Company”) for adults. It supports the outdoor or
indoor flight within the scope allowed by laws and safety regulations. When using this
Product and the auxiliary APP, the user should commit to be liable for their behavior
and all the consequences arising therefrom. The user should also commit to use this
Product and auxiliary APP for the current purpose only and agree to abide by the term
and the relevant policies and criteria that are probably prepared by the Company.
The Company may update the disclaimer without a prior notice. For the latest
disclaimer, please log in www.feimarobotics.com.
In case of any discrepancy between the disclaimers of different language versions, the
Chinese version shall prevail while the rest can be used for reference only.
The final right of interpretation of this disclaimer shall owned by Shenzhen Feima
Robotics Co., Ltd.
The Company bears no compensation and legal liabilities for the personal injury and
property loss, both directly and indirectly, arising out of the product use by any of the
causes below.

Failure in reading through J.ME Quickstart Guide, Disclaimer, Packing List, J.ME
User's Manual, Battery Safe Use Instructions and the information released by the

Company via its official website or in installing and operating as per the instructions;
Operation by the operator under poor physical or mental status, such as getting drunk,
taking drugs, narcotic drug, feeling dizzy, weak or sick;
Any relevant moral damage arising out of accident;
Improper maintenance, arbitrarily dismantling and repair of this Product or refitting of
accessories not supplied by the Company;
Tampering the auxiliary APP or aircraft software code arbitrarily;
Using aircraft in the strong interference area such as magnetic field interference zone
and radio jamming area;
Using aircraft in indoor environment where luminous flux fails to meet the
requirements;
Using aircraft in high-altitude region, public safety place, above crowd or dangerous
region and other regions where flight is strongly prohibited;
Misoperation or subjective judgment error;
Improper storage, such as strong impact, squeezing or improper environment (such as
water soaking and fire);
Obvious sign or prompt indicating that the aircraft or battery is abnormal but such

abnormality is not discovered by the operator who fails to check before flight or
notice during flight or the operator still uses it regardless of the discovery;
Poor operation of aircraft due to natural wearing, corrosion or line aging;
The operator’s damage caused by the infringement of any data, audio or video
obtained via using the aircraft and auxiliary APP;
Any indirect loss and legal liabilities caused by the equipment, accessories or APP,
such as the failure in saving images or videos; or
Operator’s failure in abiding by local laws and regulations.

Exceptions

This Product complies with the requirements in Part 15 of FCC for Type B digital
products, including two aspects:
(1) This Product generates no harmful interference.
(2) This Product is able to bear harmful interference that may lead to its abnormal
working and meets the basic requirements specified in 1999/5/EC and the
requirements of other relevant orders. It is forbidden to modify or change this Product
to avoid generating harmful interference while it works. The Company bears no
liabilities for any problem caused by the modification or change.
Make sure to use the special battery holder charger supplied by the Company and deal
with the battery ever used correctly as per the instructions. TYPE-CUSB interface of
the aircraft is connected with data communication interface only and shall not be
connected with power. Please control the aircraft within the visual scope while it flies.
If contacting the aircraft with hand or other objects, such as using hand takeoff or
hand landing function, pay special attention to avoiding contacting propeller. Besides
the above, always keep the aircraft from people, barrier or water surface with certain
distance.
In light of the complicated environment and poor flight conditions indoors, user is
recommended not to use the aircraft indoors for the sake of personal and property
safety. We bear no liabilities for people or article loss caused not by the product
quality.
Never use this Product in (including but not limited to):

Infringing others’ legitimate rights via defamation, harassment, abuse, threatening,

tracking or other ways, such as right of privacy, right of publicity;

Shooting others or personal region without being allowed;

Any adverse or illegal purpose, such as unauthorized investigation, survey, spying,

military activities, etc.

The intellectual property of this Product and the manual shall be owned by Shenzhen
Feima Robotics Co., Ltd. Any organization or individual, without written permission,
is not allowed to duplicate, reprint or release them in any form or by any means. Any
quotation or publication should be stated with reference. It is forbidden to quote,
delete or modify this Manual against the original intention.

©All rights reserved. Shenzhen Feima Robotics Co., Ltd. (www.feimarobotics.com)

Printed in China

§ 15.19 Labelling requirements.

This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause
undesired operation.

§ 15.21 Information to user.

Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.

§ 15.105 Information to the user.

Note: This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

-Consult the dealer or an experienced radio/TV technician for help.

*RF warning for Mobile device:

This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
