Federal Signal LP7 Data Sheet

Model LP7

StreamLine® Low Profile
Combination Sounder/Strobe

LP7 sounder/strobe combines the features of a mini sounder with a fully integrated xenon strobe circuit.

Operating voltage ranges from 18-28VDC with an average of only 68 mA current consumption.

The LP7 has two switchable tone patterns: “Sweeping” and “Continuous”. The LP7 has a range of 82-100 dBa @ 10 feet
(92-110 dBa @ 1m), dependent upon tone selected. Volume control is set by DIP switch, which allows for 20 dBa of
adjustment.

The LP7 features a bright xenon strobe that produces 0.7 joules of flash energy with a flash frequency of 60 flashes per
minute. The beacon will operate jointly with any tone selected.

The Federal Signal Model LP7 sounder/strobe is PLC compatible. It is ideal for wall or panel mount applications where low
voltage is required.

FEATURES

• Available in 18–28VDC

• Fully integrated xenon strobe circuit

• Four lens colors: Amber, Blue, Clear and Red

• Heavy duty ABS plastic body

MODEL VOLTAGE

LP7-18-30* 18-28VDC 0.068 amps 60 0.7 82-100 92-110

* Indicates color: (A) Amber, (B) Blue, (C) Clear or (R) Red

OPERATING
CURRENT

• 82–100 dBa @ 10' (92–110 dBa @ 1m)

• IP54 (IP65 with optional deep base)

• CE Certified

FLASH RATE/
MINUTE

JOULE
OUTPUT

DECIBELS
10' 1M

130

StreamLine® Low Profile Combination Sounder/Strobe (LP7)

VISUAL SIGNALS

3.5"/ 88.9 mm

3.66" / 93.0 mm

SPECIFICATIONS HOW TO ORDER

Lamp Life: 10,000 Hours

Light Source: Strobe tube

Operating Temperature: 14°F to 131°F -10°C to 55°C

Net Weight: 11.1 oz 0.31 kg
Shipping Weight: 13.5 oz 0.38 kg

Height: 3.5" 88.9 mm
Diameter: 3.66" 93.0 mm

LP7

TYPE
LP7

OPTIONAL ACCESSORIES

Description Part Number

Deep Base, White (1.88" D x 3.63" W) DBLP

18-30

–

VOLTAGE
18-30 (

A

18-28VDC)

COLOR
A Amber
B Blue
C Clear
R Red

2645 Federal Signal Dr., University Park, IL 60484 Tel: [phone] Email: [e-mail] www.fedsig.com | 131
