FEDERAL SIGNAL CORPORATION
y
COMPACT, ECONOMICAL STROBE LIGHT
Available in 12-48VDC and 120VAC
Screw-on dome available in
five colors
Surface mount
5
Low profile — only 3
Type 4X enclosure
UL and cUL Listed and
CSA Certified
/8" high
Streamline
®
Low Profile Mini Strobe
Model LP6
The Model LP6 is a very compact, high power strobe light designed for applications where space is critical. At 3 strobe light is ideal for fork lift applications where head room is important. The LP6 also mounts easily to small control panels.
The LP6 features a two joule power supply that works in multiple voltages from 12-48VDC to 120VAC. Modular construction incorporates a powerful flash tube and vibration resistant circuit board.
The LP6 housing utilizes a unique screw-on dome for easy relamping and service. The polycarbonate base and lens combination gives this strobe excellent impact and corrosion resistance and meets Type 4X requirements. The LP6 is also UL Listed, cUL Listed and CSA Certified.
The LP6 is available in five colors — amber, blue, clear, green and
red.
This economical light does not sacrifice power for price or size.
5
/8" high, this
Operating Flash Rate/ Joule Candela
Model Voltage Current Minute Output Peak
LP6 12-48VDC 0.44-0.10 amps 65-95 2.2 175,000 51.5
LP6 120VAC 0.10 amps 65-95 2.2 175,000 51.5
1
Peak candela is the maximum light intensity generated by a flashing light during its light pulse
2
ECP (Effective Candela) is the intensity that would appear to an observer if the light were burning steadily
1
ECP
2
yr
5
W
A
Y
T
N
R
A
R
STREAMLINE®LOW PROFILE MINI STROBE (LP6)
#10-32 Pan Head Screws (3)
Screw-On
Dome
Lexan™ Surface
Mounting Base
SPECIFICATIONS
Lamp Life*: 7,000 hours 7,000 hours Lamp Style: Strobe Strobe Operating Temperature: -31˚F to 150˚F -35˚C to 65˚C
HOW TO ORDER
• Specify model, voltage and color
• Please refer to Model Number Index LP6 beginning on page 375
Net Weight: 0.65 lbs. 0.29 kg Shipping Weight: 0.85 lbs. 0.39 kg Height: 3.63" 9.2 cm Diameter: 5.0" 12.7 cm
* Optimal hours under ideal conditions.
REPLACEMENT PARTS
Description Part Number Description Part Number
Dome, Amber K8589037A PC Assembly, 012-048VDC K2005083A-01 Dome, Blue K8589037A-01 PC Assembly, 120VAC K2001887A-02 Dome, Clear K8589037A-02 O-Ring K8589038A Dome, Green K8589037A-03 Base Gasket K8589039A Dome, Red K8589037A-04 Strobe Tube K149130A
2645 Federal Signal Dr., University Park, IL 60466 Tel: 708.534.4756 Fax: 708.534.4852 www.federalsignal-indust.com
