Streamline

®

Low Profile Light

Model LP2

The Streamline®Model LP2 is a unique, steady burning incandescent
light, ideal for both horizontal and vertical panel mount installation.
This device mounts easily through any 1.54" (39mm)
diameter hole; a lock nut secures the light firmly in place. A gasket
positioned above the mounting surface assures a water-tight and
dust-tight fit. The lamp is easily replaced from below the mounting
surface. Inherent strain relief secures all wiring from the rear, for
added durability. The enclosure consists of a polycarbonate dome
in five colors (amber, blue, clear, green and red), and a polyamide
base; the enclosure with gasket is rated Type 4X.

A 6-watt incandescent lamp is included with the 24VAC/DC and
120VAC units. The double-contact bayonet base (Type S-6) is a
standard lamp style, readily available when replacement is
required. Lamp
AC power.

Like all Federal Signal products, the StreamLine LP2 is designed
with customer applications in mind. The LP2 functions in most
PLC applications (including triac outputs). Careful consideration
has been given to the relationship between lamp shape and lens
design for maximum light output.

When your application calls for a compact signal with unparalleled
reliability, Federal Signal’s Streamline products are the clear choice.

life is approximately 1,500 hours when run on

Operating

Model Voltage Power Current

LP2 24VAC/DC 6 watts 0.30 amps

LP2 120VAC 6 watts 0.06 amps

yr

5

W

A

Y

T

N

R

A

R

STREAMLINE®LOW PROFILE LIGHT (LP2)

Lens

Gasket

Mounting

Surface

Mounting

Lock Nut

3" (76mm)

2.68" (68mm)

2.5"

(65mm)

Bayonet-Base
Lamp

Lamp
Holder

Inherent Strain

Relief Mechanism

0.28" (7mm)

SPECIFICATIONS

Lamp Life:* 1,500 hours 1,500 hours
Lamp Style: Incandescent Incandescent
Operating Temperature: -4°F to 140°F -20°C to 60°C
Net Weight: 3.4 oz. 96.4 g
Shipping Weight: 4.5 oz. 127.6 g
Height — above surface: 2.5" 65.0 mm
Height — below surface: 1.26" 32.0 mm
Diameter: 3.0" 75.0 mm

* Optimal hours under ideal conditions.

REPLACEMENT PARTS

0.63"

(16mm)

1.26"

(32mm)

1.46"

(37mm)

HOW TO ORDER

• Specify model, voltage and color

• Please refer to Model Number Index
LP2 beginning on page 373

Description Part Number

Lamp, 24VAC/DC K8107195A
Lamp, 120VAC K8107195A-01
