FEDERAL SIGNAL CORPORATION

y

PORTABLE WARNING LIGHT

• 12VDC — uses two standard 6VDC

lantern batteries

• 4,000 Hour strobe tube

Battery Powered
Strobe Warning Light

Model BPL26ST

Federal Signal’s Model BPL26ST is a portable, battery-powered
strobe warning light which flashes 65 times per minute. Components
are moisture-proof and reverse polarity protected to ensure
extended battery life and trouble-free performance.

The BPL26ST is available in five fresnel dome colors; amber, blue,
clear, green and red. For increased durability, the dome is made of
impact-resistant polycarbonate materials and the base is constructed
from a high-density polyethylene. A flexible rubber seal covers the
on/off switch to protect it from the elements.

• Five dome colors

• Type 3R weatherproof enclosure

• Magnetic mount

Two Magnetic pads (not shown) are included for simple yet
secure, temporary mounting.

Power is supplied by two standard 6VDC, spring terminal lantern
batteries (not included).

The Model BPL26ST is ideal for job sites requiring temporary
warning lights or for any location where primary power is unavailable.

Operating Flash Rate/

Model Voltage Current Minute Mount

BPL26ST 12VDC 0.48 amps 60 Magnetic

yr

5

W

A

Y

T

N

R

A

R

BATTERY POWERED LIGHT (BPL26ST)

11.12"/282.5 mm

Battery Case

5.5"/139.7 mm

On/Off Switch

7.22"/183.4 mm

SPECIFICATIONS

Lamp Life*: 4,000 Hours 4,000 Hours
Lamp Style: Strobe Strobe
Operating Voltage: 12VDC 12VDC
Net Weight: 2.3 lbs. 1.04 kg
Shipping Weight: 3.5 lbs. 1.59 kg
Height: 10.5" 266.7 mm
Width: 7.22" 183.4 mm
Diameter of Dome: 5.5" 139.7 mm

* Optimal hours under ideal conditions.

REPLACEMENT PARTS

Description Part Number

Dome, Amber K8263079A
Dome, Blue K8263079A-01
Dome, Clear K8263079A-04
Dome, Red K8263079A-02
Dome, Green K8263079A-03
Strobe Tube K8107215A

Magnetic

Mounting Pads

HOW TO ORDER

• Specify model number and color

• Please refer to Model Number Index
BPL26ST beginning on page 375

2645 Federal Signal Dr., University Park, IL 60466 Tel: [phone] Fax: [phone] www.federalsignal-indust.com
