FANTEC SG-220
2U 400mm Server Case without Power Supply
Manufacturer-Item-No. 2213
EAN 4250273422139
FANTEC S G -22 0
2HE 400mm Server Case without Power Supply
19" Server Case for installation in 19" industrial cabinets. Robust
construction and high quality workmanship. Suitable for Security Server,
Web Server, Online Game Server, NAS and SAN.
Expandable with telescopic rails.
• ON/OFF switch, Reset switch
• 2x LEDs for ON/OFF, hard drive access
• 2x USB 2.0 front USB-interface
FANTEC GmbH · Billwerder Billdeich 605B · 21033 Hamburg Deutschland · Tel. +49 (0)40 73 09 2 83 · Fax +49 (0)40 73 09 2 83 - 41
www.fantec.de · www.fantec-forum.de · info@fantec.de · technical changes reserved
Page 2
FANTEC SG-220
2U 400mm Server Case without Power Supply
Manufacturer-Item-No. 2213
EAN 4250273422139
Technical Data
Short Description
• 2U Server Case
• Mainboard type: Micro-ATX
Special Features
• supports ATX PC power supply
• 1x Power LED
• 1x Status LED
Type and Form Factor
• Housing type: 19 inch Ser ver Case
• Height: 2U
• Depth: 4 00mm
Drive Bays
• 2x 3.5" hard disk
• 2x 5.25" module
alternative:
1x 5.25" module + 2x 2.5" HDD/SSD
Fan
• Fan type: 2x 80mm at the front
Slots
• 4x low profile PCI slots
Interfaces
• Data Inter faces: 2x USB 2.0 host
• Network Inter faces: not available
Housing Material / Color
• Casing: 1.0mm, steel, SGCC, silver
• Front: steel, black
• Handles: Anodised aluminum, silver
Included Supply
• Mounting material
Logistic data
• Article Measurements
(Installation Dimension)
430 x 400 x 88 mm ( W x D x H)
• Net Weight Article (total)
4,9 kg
• Dimensions Carton
530 x 490 x 160 mm (W × D × H)
• Item-No.: 2213
• EAN 4250273422139
• Country of Origin
China
Features
• 2x USB 2.0 Front USB
