Page 1
HOW TO SETUP YOUR FANATIC INFLATABLE
user manual
Page 2
HOW TO SETUP YOUR FANATIC INFLATABLE
1 2 3
Unpack and unroll your Fanatic Inatable SUP on a at
surface - grass is ideal.
Make sure the valve of the
board is in the outer/upper
position. The valve must be
released for ination. To release the valve, push slightly
downwards and twist to the
left or right until you nd the
upper position.
Connect the air hose with a
twist to the pump and plug
the end piece of the hose
into the valve of the board.
Turn it clock-wise for a safe
connection.
2
1
1
15 PSI
4 5 6
Start pumping with your
Power Pump switched on
double stroke action.
Pump up your board. If it
gets too exhausting, switch
to single stroke action, it´s
much easier to reach full
pressure with single stroke
action.
Pump until you reach 15 PSI
minimum pressure, for more
stiffness you can inate up
to 20 PSI.
Page 3
7 8 9
Place the cap on the valve
and close it.
Flip the board over to attach
the n. Use the n screw to
place the little plate at the
front of the n box.
Insert the end of the n base
with the metal pin into the
slot of the box and slide it
backwards inside of the box,
until you can push the front
part of the n base into the
n box.
10 11
12
Use the n screw to line up
the plate hole with the hole
in the n base.
Connect the screw and the
plate through the hole. No
tools are needed, you‘re
done!
Please have a look at
our HOW TO STAND UP
PADDLE GUIDE and see
how to adjust your paddle
and how to use your board
on the water. Enjoy!
