Falmec FDNUV36C6SS Specifications
NUVOLA 90
KACL.798#21F
Motor 600 CFM
Version
FDNUV36C6SS / Ceiling – Steel
36" (90 cm)
Collection
Collection
Accessoires
EAN code
8034122709970
Design+
Photograph is for information purposes only
May not correspond to the selected version
FEATURES TECHNICALFEATURES PACKAGING:WEIGHTS AND
VOLUMES
Scotch brite stainless steel
(AISI 304)
Tempered glass, extra light,
painted
Perimeter suction
Electronic control
Fluorescent lighting
Metallic grease filter,
removable and washable
Remote control included
OPTIONAL ACCESSORIES
KACL.815
Protective cleaning cloths for
stainless steel (box 10 pcs)
KACL.798#21F
Motor 600 CFM
Installation type
Ceiling
Dimensions
36 " / 90 cm
Finish
Scotch brite stainless steel (AISI
304)
Type of control
Electronic control
Speed settings
4
Lighting
Fluorescent 2x39 W
Filter
Metallic filter "Base" - 290x267
mm - 2 pz
NUVOLA 90
FDNUV36C6SS / Ceiling – Steel 36" (90 cm)
Gross weight
26 kg
Net weight
23 kg
Volume
3
0,14
m
Packaging size
Length
1120 mm
Height
670 mm
Depth
190 mm
REMOTE MOTOR
Motor 600 CFM
Gross weight
10 kg
Net weight
9 kg
Volumes
3
0,06
m
Packaging size
Length
435 mm
Height
340 mm
Depth
385 mm
CONSUMPTION AND
CONNECTION FEATURES
Current
120V 60Hz
Frequency
Plug type
standard
Technical sheet - 21/06/2018
NUVOLA 90
KACL.798#21F
Motor 600 CFM
Version
FDNUV36C6SS / Ceiling – Steel
36" (90 cm)
Collection
Collection
Accessoires
EAN code
8034122709970
Design+
Hood with motor Side view with junction (optional)
Technical sheet - 21/06/2018
