Page 1
Spare Parts Catalogue
PK 41002 MH
(S410-SK-E)
Valid for serial number 100492226
Edition 10/2012 EN
PALFINGER AG
Lamprechtshausener Bundesstraße 8
5101 Bergheim / Austria
www.palfinger.com
Page 2
PK 41002 MH # 1004922260.02
Preface-EN
This catalogue of spare parts is based on latest stages of product design
and development.
If you have maintained and serviced the technically matured equipment
purchased from us in accordance with our instructions, there will scarcely
be any need to consult this spares catalogue.
Should, in spite of this, the occasion arise to order spares, we would
kindly ask you to state precise details as given in the catalouge,
(please refer to "INFORMATION ON THE ORDERING OF SPARE PARTS") so as to
avoid confusion.
We reserve the right to make design modifications.
Preface
Information on the ordering of spare parts
To supply you with the correct parts in the shortest possible
time it is necessary to inform us about following details:
– Loader type, code and serial number (look identification plate)
– Spare parts number
– Required quantity of spare parts
Loader type
Code
Serial number
PK XXXXX–EH
XXX– K–D
000000000
2010
Palfinger Europe GmbH
Mossmühlstraße 1
5203 Köstendorf / Austria
www.palfinger.com
www.palfinger.com
10/2012
Page 3
PK 41002 MH # 100492226 0.20
(-->123456789)
(123456789-->)
(1-16)
(+20)
Page-A
Page-B
ABST Support
DPS+ Dual Power System Plus
FERN Remote control FFST Radio remote control
FERT Type - remote control PALF20 PALFINGER-PALCOM
GGSR Control (reverse acting)
GRA Type - crane Base LKW Mounting LKW
HEM Rear module
HKONS Top seat FFST HK001 Standard seat
HOST Top seat - control KL0 Linear lever control
HPLS High Power Lifting System EHPLS
HSITZ Top seat - standard HS005 Tiltable seat
HYA,PJHY Hydraulic extensions ()
IKONS Standing platform FFST IK002
IS Limitation of rotation (I) IS001 Limitation of rotation over (I)
ISC ISC01
LHA
Valid to crane number
Valid from crane number
consists out of position 1-16
with position 20
Control valve side
Counter control side
R without extension box
R0
R1
R2
R3
R4
R.X
SR. Support controllable from top seat
BMS2 HETRONIC
P3 with display
SAT Semi-trailer installation
EGG Integrated base
Rear-stabilizerHEC
RailingIG IG001
Integrated Stability Control
Crane hook
HSTZY Tiltable stabilizer
HEM900 Rear module +900
HK002 Tiltable seat
HK003 Seat with heater
HK004 Folding seat with heater
KK1 Cross lever control
SHPLS
HS012 Standard seat
A
B
C
D
E
F
G
H
IK004
IK006
IG002 2 port
IS002
IS003
HPSC High Performance Stability Control
LHA03
LHA04
LHA06
LHA08
LHA09
LHA12
One side extension box
Both side extension box
Both side extension box - extended
Extension box telescopic
Both side extension box - extended
Both side extension box - hydraulical
PALFINGER-SCANRECOP2
High Power Lifting System
Super High Power Lifting System
Crane with one hydraulic extension boom
Crane with 2 hydraulic extension booms
Crane with 3 hydraulic extension booms
Crane with 4 hydraulic extension booms
Crane with 5 hydraulic extension booms
Crane with 6 hydraulic extension booms
Crane with 7 hydraulic extension booms
Crane with 8 hydraulic extension booms
Crane with 9 hydraulic extension booms
without IS001, with IG001
with IS001,IG001
with IS002,IG001
3 port
Limitation of rotation, main boom over (I)
Limitation of rotation over (FL)
Support control +SHB
25t with sleeve bearing
8t with sleeve bearing
15t with sleeve bearing
5,4t with sleeve bearing
11t with roller bearing
8t with roller bearing
Signs and symbols
10/2012
www.palfinger.com
Page 4
PK 41002 MH # 1004922260.21
Signs and symbols
LHV Load holding valve
NOTAB Emergency lowering device NOT01 (NOTAB) Lifting cylinder
O Overload protection OSK with lock cylinder
OELKU Oil cooler ÖLK01
PAL Paltronic
PJ Fly-Jib
PJHY Hydraulic extensions see (HYA)
PJKSL Hose-equipment (PJ) J02 1 Auxiliary equipment
PJV Extension see (V)
PUMPE Type - pump PU002
RODRU Rotator (...bar)
S Rope winch SHE with limiting switch - main boom
SCH Slew limitation GR___ Limit of rotation ___ degree
SHB Slew angle dependent capacity limitation SHB01
SKUPP Quick-coupling MULTI1
Multifaster
SL Hose-equipment 2
SLVO Preparation (SL) VSL2
SONSL Control valve section (SL)
SOSTZ Stabilizer ram
STEIL Boom angle monitoring system STEIL1 Boom angle monitoring system
STG Control - support FL
STGA
STRAN Rope winch, strand 1
STT Stabilizer plates STD Standard
STU Hour meter
Control - crane
LHV... see page 0.22
Oil cooler 8.5kW mounted
ÖLK02
ÖLK03
ÖLK04
ÖLK05
ÖLK07
PT050 Paltronic 50
PT150 Paltronic 150
J04 Auxiliary equipments2
PU003
SK
SKE
SHEK Power link rope winch (hydraulic tiltable at main boom)
SHB07
MULTI2
MULTI3
4
T2
T4
T2i
T4i
VSL4
SSZD
SSZT
SCSTD
STÜ02
STÜ03
STEIL2 Monitoring the steep position (PJ)
FLZUS
FFST4
FFST8
FL
I
H
NK
NK2K
2
4
___ Extension ___mm
Oil cooler 10.5kW, loose
Oil cooler 8.5kW, loose
Oil cooler 20kW mounted
Oil cooler 20kW, loose
Oil cooler 10.5kW mounted
Fixed displacement pump
Variable displacement pump
without limiting switch - outer boom
with limiting switch - outer boom
with one pressure range
with 2 pressure ranges + jumper
Quick-coupling, crane
Quick-coupling,(PJ)
Quick-coupling, crane+(PJ)
1 Auxiliary equipment - hose tray
2 Auxiliary equipment - hose tray
1 Auxiliary equipment - hose drum
2 Auxiliary equipment - hose drum
1 Auxiliary equipment - hose drum (inside)
2 Auxiliary equipment - hose drum (inside)
Preparation (SL) 1 auxiliary equipment
Preparation (SL) 2 auxiliary equipment
Brick grab Germany
Brick grab + deadman push button
Type Scandinavian
Stabilizer ram -150 mmSTÜ01
Stabilizer ram +100 mm
Stabilizer ram -100 mm
Control valve - support
Control valve - auxiliary support
remote controlled (4-elements)
remote controlled (8-elements)
remote controlled (12-elements)FFST12
remote controlled (14-elements)FFST14
Floor control
High stand platform
Top seat
Emergency control - crane column
Emergency control - crane column, double circulit
1 strand
2 strand
4 strand
www.palfinger.com
10/2012
Page 5
PK 41002 MH # 100492226 0.22
Signs and symbols
STZ Stabilizer ram STZO
STZS3
STZY3
STZY
STZS3Y
STZYS3
SWERK Slewing system 1GETR 1-Slewing gear
SWK Max. rope winch capacity: 1,5 - 4,5 1,5t - 4,5t
TKKR Crane tank
TKLO Auxiliary tank TL___ Oil tank___l
TOT Dead center TOWI
TOQU
SE continuous
TRANS Transport position monitoring TRAN1
TRAN2
TSCH,TSTB Control valve
M4-12
PVG32
RS210
RS220
RSQ240
SDM081
VDM07
V,PJV Extension V1()
V1A
V1B
V1C
V1D
V1E
V1F
V1G
V1H
V2()
V2A
V2B
V2C
V2D
V2E
V2F
V2G
V2H
V3()
V3A
V3B
V3C
V3D
V3E
V3F
V3G
V3H
LHV Load holding valve LHV14
Type without support
Stabilizer ram - rigid
Stabilizer ram - slewable
Hydraulically tiltable stabilizer cylinder
Page-A=(STZS3) B=(STZY3)
Page-A=(STZY3) B=(STZS3)
2-Slewing gear2GETR
Dead center over balance
Dead center over transverse spar
Armrest
Main boom - horizontal level
DINOIL DN46DN46
REXROTH M4-12
DANFOSS PVG32
NORDHYDRAULIK RS210
NORDHYDRAULIK RS220
NORDHYDRAULIK RSQ240
WALVOIL SDM081
SALAMI VDM07
1 Extension by (HYA ())
1 Extension by (HYA A)
1 Extension by (HYA B)
1 Extension by (HYA C)
1 Extension by (HYA D)
1 Extension by (HYA E)
1 Extension by (HYA F)
1 Extension by (HYA G)
1 Extension by (HYA H)
2 Extensions by (HYA ())
2 Extensions by (HYA A)
2 Extensions by (HYA B)
2 Extensions by (HYA C)
2 Extensions by (HYA D)
2 Extensions by (HYA E)
2 Extensions by (HYA F)
2 Extensions by (HYA G)
2 Extensions by (HYA H)
3 Extensions by (HYA ())
3 Extensions by (HYA A)
3 Extensions by (HYA B)
3 Extensions by (HYA C)
3 Extensions by (HYA D)
3 Extensions by (HYA E)
3 Extensions by (HYA F)
3 Extensions by (HYA G)
3 Extensions by (HYA H)
10/2012
LHV18
LHV19
LHV28 Double-acting laod holding valve
LHV34
www.palfinger.com
Page 6
PK 41002 MH # 100492226
Table of Contents
Page
0 PREFACE
0 .02 Preface-EN
0 .20 Signs and symbols
0 .21 Signs and symbols
0 .22 Signs and symbols
0100 BASE
0100.01000-A Base
0100.01001-A Flow reducing valve
0100.02000-A Attachments TOWI
0100.02200-A Attachments - Clamp housing
0100.03000-A Valve bracket FL
0100.03001-A Valve bracket FL
0100.04000-A Bracket FL
0100.04001-A Bracket FL
0100.05000-A Slewing system
0100.06000-A Piping - slewing system FL
0100.07000-A Piping - lube system
0100.08020-A Piping - control FL,MHPLS
0100.09000-A Hoses FL
0100.10000-A Extension box R3X
0100.10001-A Outrigger extension cylinder UP1407B
0100.10010-A Hose tray R3X
0100.10110-A Hose tray R4X
0100.11000-A Extension - box piping R3X,VDM07
0100.11101-A Pretension valve UV423
0100.12000-A Support STZS3
0100.12001-A Stabilizer ram UP2957
0100.12002-A Check valve EV4109A
0100.12202-A Stabilizer plates
0100.15000-A Oil cooler 10,5kW
0200 CONTROL - SUPPORT VDM07
0200.01000-A Control valve VDM07
0200.01001-A Control valve - details
0200.02000-A Control system
0230 CONTROL - CRANE RSQ240
0230.01000-A Control valve (4-sections) FL,H
0230.02000-A Control system
0230.01000-A Inlet element
0230.02000-A Separate element
0230.04001-A Control valve - details
0230.05000-A End element
0300 SAFETY DEVICES
0300.04000-A Encoder
www.palfinger.com
10/2012
Page 7
PK 41002 MH # 100492226
Page
0301 ELECTRICAL PARTS
0301.02000-A Housing PT050
0301.02100-A Housing PT050
0301.02200-A PT050Attachment board
0301.02300-A Decals PT050
0301.06000-A Adaptor, switch
0301.07000-A Wire plug
0301.08000-A Line-up terminal
0301.09000-A Relay (1)
0301.09100-A Relay (2)
0301.10000-A Miscellaneous
0400 CRANE COLUMN
0400.01000-A Crane column FL
0400.02000-A Attachments - crane column
0400.02001-A Lifiting cylinder - details
0400.02002-A Attachments - Clamp housing
0400.03000-A Piping - lifting cylinder
Table of Contents
0500 MAIN BOOM
0500.01000-B Main boom
0500.01001-A Outer boom ram - details
0500.02000-A Piping - outer boom cylinder
0600 OUTER BOOM
0600.01000-A Outer boom
0600.01001-A Hose clip
0600.01003-A Attachments - Clamp housing
0700 BOOM EXTENSIONS
0700.01000-A Extension boom 1 + piping
0700.01001-A Boom extensions ram 1 details
0700.02100-A Extension boom 2 + piping
0700.02101-A Boom extensions ram 2 details
0700.03100-A Extension boom 3 + piping
0700.03101-A Boom extensions ram 3 details
0700.04000-A Extension boom 4 + piping
0700.04101-A Boom extensions ram 4 details
1000 MISCELLANEOUS
1000.01000-A Miscellaneous
1000.02000-A Crane hook
1000.03000-A Decals (1)
1000.04000-A Decals (2)
1000.05100-A Decals (PK41002-MH)
10/2012
www.palfinger.com
Page 8
Table of Contents
Page
1200 Auxiliary equipment
PK 41002 MH # 100492226
www.palfinger.com
10/2012
Page 9
PK 41002 MH # 100492226
Notes
10/2012
this page is intentionally left blank
www.palfinger.com
Page 10
PK 41002 MH # 1004922260100.01000-A
Base
Description DimensionNo. Qty.Spare part
1 S410G50SA+R3020 1 Crane Base (Standard colour RAL 3020)
2 HBS3586 1 Washer
3 ER 355 1 D 410x360 mmV-Ring
4 HT11166 1 Bearing bush
5 HT11167 1 Bearing bush
6 HBS1381 1 Distance ring
7 EQ 304 1 D 205 DIN 471Circlip
8 HT7778 1 Folding arrow
9 EK 178 1 DIN 9021 M6 ZBWasher
10 ES1150 1 M 6x12 ISO4762- 8.8 Screw
11 ES1329 4 M 6x20 ISO14581- 8.8Screw
12 EK 567 4 D 6 Washer
13 EA4924 1 High pressure filter
100137506-->
EA4925 1 Filter element
TD1553 1 Seal kit
14 S411G35SA+R3020 1 Balance (Standard colour RAL 3020)
15 EQ 245 1 D195 DIN471 Circlip
16 EK 003 4 D 8.4 ISO7089Washer
17 ES 265 4 M 8x20 ISO4762- 8.8 Screw
18 HA8705 1 Bearer
19 EV2733 1 26 VValve HPLS
TD 602 1 Seal kit firm OIL CONTROL
TD 864 1 Seal kit firm OLEOSTAR
see page 0100.01001-A
www.palfinger.com
10/2012
Page 11
PK 41002 MH # 100492226 0100.01000-A
Base
2
16
17
18
17
19
16
MHPLS
1
3
4
8
9
10
11
12
13
14
10/2012
5
15
6
7
www.palfinger.com
Page 12
Flow reducing valve
Description DimensionNo. Qty.Spare part
1 EV2733 1 26 VValve HPLS
TD 602 1 Seal kit firm OIL CONTROL
TD 864 1 Seal kit firm OLEOSTAR
2 EA 261 1 VSTI R1/2" Locking screw
3 EV1776 1 Pressure relief valve
4 EV2887 1 Valve cartridge
5 EV2810 1 26 V Solenoid
PK 41002 MH # 1004922260100.01001-A
www.palfinger.com
10/2012
Page 13
PK 41002 MH # 100492226 0100.01001-A
Flow reducing valve
5
4
3
1
2
10/2012
www.palfinger.com
Page 14
Attachments TOWI
Description DimensionNo. Qty.Spare part
1 HA8720 1 Bearer
2 ES 266 2 M 8x35 ISO4762 Screw
3 EK 003 6 D 8.4 ISO7089Washer
4 EM 026 4 DIN 985 M8 Nut
5 HX 157 1 Hose guide
6 ES 006 2 M 8x25 ISO4762-10.9Screw
7 HX 160 1 D=110 mm Hose guide
PK 41002 MH # 1004922260100.02000-A
www.palfinger.com
10/2012
Page 15
PK 41002 MH # 100492226 0100.02000-A
Attachments TOWI
3
4
3
2
1
7
4
3
5
6
10/2012
www.palfinger.com
Page 16
Attachments - Clamp housing
Description DimensionNo. Qty.Spare part
1 ES 419 2 M 6x12 ISO14581- 8.8 Screw
2 EK 567 2 D 6 Washer
3 HA12140 1 Bearer
4 ES 414 2 M 6x10 ISO4762- 8.8 Screw
5 EK 190 2 d=6.4 ISO7089Washer
6 HA8721 1 Cover
10 EEA11683 1 220x120x91 Connection box
ES3567 4 Screw M 6x25 ISO4762
ES3568 4 Screw M 6x30 ISO4762
ES3569 4 Screw M 6x35 ISO4762
11 EEA4980 1 238x119x68.5Base
12 EEA9864B 1 Version 5.8Basic element
ES3567 4 Screw M 6x25 ISO4762
ES3568 4 Screw M 6x30 ISO4762
ES3569 4 Screw M 6x35 ISO4762
13 EEA6209 1 400x230x180 mmConnection box 3xM 32x1.5
ES3567 4 Screw M 6x25 ISO4762
ES3568 4 Screw M 6x30 ISO4762
ES3569 4 Screw M 6x35 ISO4762
14 EEA9870 1 400x230x180Housing
ES3567 4 Screw M 6x25 ISO4762
ES3568 4 Screw M 6x30 ISO4762
ES3569 4 Screw M 6x35 ISO4762
15 EZ 578 4-6 mm Edge protection (metro goods)
PK 41002 MH # 1004922260100.02200-A
www.palfinger.com
10/2012
Page 17
PK 41002 MH # 100492226 0100.02200-A
Attachments - Clamp housing
15
14
13
1
2
4
5
3
6
10
10/2012
11
12
www.palfinger.com
Page 18
Valve bracket FL
1 ES 465 4 M 12x260 DIN 603Screw
2 HA12137 1 Bearer
3 HXE4485 1 Bracket
4 EK 018 4 D 13 DIN 134 Washer
5 EM 023 4 M 12 DIN 985 Nut
6 EM 026 2 DIN 985 M8 Nut
7 EK 003 2 D 8.4 ISO7089Washer
8 HXE1684 2 Bearer
9 HXE 258 1 Bracket
10 ES2497 2 M 6x20 ISO7380-10.9Screw
11 EZ6155 1 Cover
12 HA8709A 1 Cover
13 ES 418 1 M 6x16 ISO14581- 8.8 Screw
14 EK 567 5 D 6 Washer
15 HBS2886 3 L=52 mmSpacer
16 ES1157 3 M 8x70 DIN 912 Screw
17 ES 175 1 M 6x16 ISO4762- 8.8 Screw
18 HXE 553 1 Bracket
19 ES 414 2 M 6x10 ISO4762- 8.8 Screw
20 HA12189 1 Cover
PK 41002 MH # 1004922260100.03000-A
Description DimensionNo. Qty.Spare part
without lighting
see page 0100.03001-A
21 EK1045 1 Cover
22 ES 419 4 M 6x12 ISO14581- 8.8 Screw
23 EZ 578 4-6 mm Edge protection (metro goods)
23 EZ2204 1-2 mmEdge protection (metro goods)
www.palfinger.com
10/2012
Page 19
PK 41002 MH # 100492226 0100.03000-A
Valve bracket FL
Control system RSQ240 (RC)
2323
1
11
10
15
2
3
6
7
9
4
8
5
20
14
22
21
12
13
10/2012
14
16
19
18
17
www.palfinger.com
Page 20
Valve bracket FL
Description DimensionNo. Qty.Spare part
2 EK 848 1 Mirror
3 EK1250 1 Inclinometer
5 HP 037 1 Protection stirrup
6 ES 994 1 4.2x19 ISO7049Screw
7 HX 001 1 Baffle
8 HXE 553 1 Bracket
without lighting
9 HX 057 1 Cover
10 ES 962 3 D 3x25 mmScrew
11 EF 174 3 Spring
12 EK 535 1 Cover
14 EK 536 1 Cap
15 EK 898 1 Control decal
16 EK 517 1 Symbol sign
17 EK 519 1 Symbol sign
19 EK 540 1 Cap
PK 41002 MH # 1004922260100.03001-A
www.palfinger.com
10/2012
Page 21
PK 41002 MH # 100492226 0100.03001-A
Valve bracket FL
2
3
5
6
2
7
3
12
10
11
9
8
6
7
16
5
15
10/2012
14
17
19
www.palfinger.com
Page 22
Bracket FL
Description DimensionNo. Qty.Spare part
1 ES 419 2 M 6x12 ISO14581- 8.8 Screw
2 EK 567 2 D 6 Washer
3 HXE4238 1 Cover
4 ES 991 1 M 6x30 ISO14581- 8.8Screw
5 EM 026 5 DIN 985 M8 Nut
6 EK 003 7 D 8.4 ISO7089Washer
7 HXE1684 1 Bearer
8 HXE1130 1 Bracket
9 ES 090 3 D 5x12Screw
10 ES 264 1 M 8x16 ISO4762- 8.8Screw
11 ES1155 2 M 8x65 ISO4762- 8.8Screw
12 EM 224 2 Nut
13 HXE 560 1 Bracket
without lighting
see page 0100.04001-A
14 ES 879 3 M 6x10 DIN 7984 Screw
15 HT10270 1 Bracket plate
PK 41002 MH # 1004922260100.04000-A
16 HXE3555 1 Protection stirrup
17 ES1154 2 M 8x60 ISO4762- 8.8Screw
18 ES 374 1 M 8x12 ISO4762- 8.8 Screw
19 HXE4225 1 Bearer
www.palfinger.com
10/2012
Page 23
PK 41002 MH # 100492226 0100.04000-A
Bracket FL
Control system VDM07
15
13
1
2
4
5
6
7
12
6
5
9
17
8
3
2
1
5
6
19
6
18
10/2012
16
14
11
10
9
6
www.palfinger.com
Page 24
Bracket FL
Description DimensionNo. Qty.Spare part
3 EK1250 1 Inclinometer
4 HX 031 1 Baffle
5 HXE 560 1 Bracket
without lighting
6 HX 073 1 Baffle
7 EZ1580 1 Blind plug
9 EK 538 1 Cap
10 EK 898 1 Control decal
11 EK 517 1 Symbol sign
12 EK 519 1 Symbol sign
14 EK 540 1 Cap
PK 41002 MH # 1004922260100.04001-A
www.palfinger.com
10/2012
Page 25
PK 41002 MH # 100492226 0100.04001-A
Bracket FL
4
3
4
5
3
6
7
10
11
10/2012
9
12
14
www.palfinger.com
Page 26
PK 41002 MH # 1004922260100.05000-A
Slewing system
Description DimensionNo. Qty.Spare part
1 HY1115A+00001 4 Cylinder tube (Standard colour RAL 2002)
2 ES1444 4 M10x1x25 DIN 961Screw
3 EK 007 4 D 10.5 ISO7089 Washer
4 EQ 132 4 DIN 471 65X2,5 OTCirclip
5 HK 653 4 Piston
6 EG 111 4 100x95x14.8 mmGuide ring
7 ED1228 4 100x80x12.5 mmSeal ring
8 HK 652 4 L= 42mm Piston
9 EO 035 4 D 24,2x3O-ring
10 HZS 083 2 Rack
11 HIG 270 2 Grease tube
12 EO 027 2 D 11,3x2,4O-ring
13 EO 130 2 D 11x3,5O-ring
14 EZ1208 2 Guide block
15 EV8883-230 1 Load holding valve
16 EK 003 2 D 8.4 ISO7089Washer
17 ES1388 2 M 8x45 ISO4762- 8.8Screw
22 EA1749 2 WEE 12S 3/8" Adaptor
23 HLR14704 1 D 12 Pipe
24 HLR14705 1 D 12 Pipe
25 EA 183 2 GE 12S R1/2"-ED Fitting
26 EA 202 2 EL 12 S L-Coupling
27 HLR14703 1 D 12 Pipe
28 HLR14701 1 D 12 Pipe
29 EA 204 2 G 12 S Fitting
30 HLR14700 1 D 12 Pipe
31 HLR14702 1 D 12 Pipe
32 EA 039 2 GE 12S R3/8"-ED Fitting
www.palfinger.com
10/2012
Page 27
PK 41002 MH # 100492226 0100.05000-A
Slewing system
16
17
HPSC
15
10
9
7
5
4
8
6
3
2
1
30
29
28
29
26
12
27
25
13
11
14
22
23
22
24
15
10/2012
32
31
32
www.palfinger.com
Page 28
Piping - slewing system FL
1 EA 183 2 GE 12S R1/2"-ED Fitting
2 HLR14440 1 D 12 Pipe
3 HLR14441 1 D 12 Pipe
PK 41002 MH # 1004922260100.06000-A
Description DimensionNo. Qty.Spare part
www.palfinger.com
10/2012
Page 29
1
2
3
PK 41002 MH # 100492226 0100.06000-A
Piping - slewing system FL
1
2
3
10/2012
www.palfinger.com
Page 30
Piping - lube system
Description DimensionNo. Qty.Spare part
1 EA 002 3 GE 6L M10x1-ED Fitting
2 EA 001 2 WH 06L M 10x1 Adaptor
3 EA 623 3 WE 06-LM Fitting
4 EA 265 6 D 6 S Cutting ring
5 EA 641 6 M 6 L Nut
6 EH1434 Grease hose
Metered good
7 EO 547 1 D 9,3x1,5 O-ring
8 ED 391 1 KD M10 Sealing ring
9 ES 104 1 M 6x50 ISO4762-10.9Screw
10 HXE 714 1 Grease block
11 EA 005 2 M10x1 DIN71412 Grease nipple
12 HLA1366 1 Grease block
PK 41002 MH # 1004922260100.07000-A
www.palfinger.com
10/2012
Page 31
PK 41002 MH # 100492226 0100.07000-A
Piping - lube system
10
12
2
8
11
9
3
2
7
6
4
5
2
10/2012
1
1
www.palfinger.com
Page 32
Piping - control FL,MHPLS
Description DimensionNo. Qty.Spare part
1 EA1087 1 M 25-S Fitting
2 EA1117 1 VKA 25 Blind plug
3 EA 085 2 GE 25 S R1/1" Fitting
4 EH2150 1 NW 20x800Hose
5 EH6454 1 NW 25x2650Hose
6 EA 401 1 EL 28L L-Coupling
7 EA 115 1 EVW 25 SAngle fitting
8 EA1018 2 GE 25 S R3/4"Fitting
9 HLA 102 1 GE 28 L 3/4" Fitting
10 EH3435 1 NW 25x750 Hose
11 EH5531 1 NW 20x750 Hose
12 EH6528 1 NW 12x2400Hose
13 EA 019 2 EW 16S Angle fitting
14 HLR14716 1 D 18 Pipe
15 EA 237 2 EW 18 L Angle fitting
16 HLR14161 1 D 16 Pipe
17 EH6522 1 NW 16x1650Hose
18 EA 252 1 T 18-L Fitting
19 HLR14715 1 D 18 Pipe
PK 41002 MH # 1004922260100.08020-A
www.palfinger.com
10/2012
Page 33
PK 41002 MH # 100492226 0100.08020-A
Piping - control FL,MHPLS
17
15
19
18
Flow reducing valve
8
16
15
14
8
9
10
11
Control valve VDM07Control valve VDM07
13
13
12
7
Oil cooler
4
1
3
2
3
5
Control valve RSQ240
6
10/2012
High pressure filter
www.palfinger.com
Page 34
Hoses FL
Description DimensionNo. Qty.Spare part
1 EH3199 6 NW 12x3500 Hose
(TOWI)
3 EH6543 1 NW 12x1100Hose
4 EH6545 1 NW 12x1100Hose
5 EH6542 2 NW 12x4250Hose
8 EH 822 1 NW 50x500 Protection hose
8 EH1487 1 NW 50x750 Protection hose
9 EZ4839 1 NW 110x2800Protection hose
(TOWI)
PK 41002 MH # 1004922260100.09000-A
www.palfinger.com
10/2012
Page 35
PK 41002 MH # 100492226 0100.09000-A
Hoses FL
5
5
4
3
Extension boom ram
Outer boom ram
Lifting cylinder
1 111
10/2012
88
9
www.palfinger.com
Page 36
PK 41002 MH # 1004922260100.10000-A
Extension box R3X
Description DimensionNo. Qty.Spare part
1 HTR1192 2 L0157 B0088 S0006 Stop buffer
2 HF 834 2 8 mm l=55 mmGuide block
2 HF 835 2 9 mm l=55 mmGuide block
2 HF 836 2 10 mm l=55 mmGuide block
3 HA7198 2 2 mm Sliding guide
4 HA7199 2 Stiffening plate
for HA7198
5 HA7276 2 4 mm Stiffening plate
5 HA7705 2 3 mm Sliding guide
6 EK 007 2 D 10.5 ISO7089 Washer
7 ES 050 2 M 10x20 ISO4762-10.9 Screw
8 EM 540 8 M 24x1.5 DIN 80705Nut
9 HIG 428A 4 L=46 mmGuide
10 HF 007 16 Guide 5 mm
10 HF 047 16 Guide 2 mm
10 HF 050 16 Guide 3 mm
10 HF 108 16 Guide 4 mm
10 HF 795 16 Guide 6 mm
10 HF 796 16 Guide 8 mm
11 ES 374 8 M 8x12 ISO4762- 8.8 Screw
12 EM 026 2 DIN 985 M8 Nut
13 HA8836 1 Protection stirrup
14 ES 265 2 M 8x20 ISO4762- 8.8 Screw
15 S410A50-A 2 Extension box
16 HF 829 2 8 mm Guide block
16 HF1403 2 7 mm Guide block
17 HT10821 2 Bearer
18 ES 298 4 M 10x20 ISO14581- 8.8Screw
19 HIA 130A 8 Guide 3 mm
19 HF 578A 8 Guide 6 mm
19 HF 577A 8 Guide 5 mm
19 HF 576A 8 Guide 4 mm
19 HF 575A 8 Guide 2 mm
19 HF 608A 8 Guide 1,5 mm
19 HF 727A 8 Guide 7 mm
19 HF 728A 8 Guide 8 mm
19 HF 899A 8 Guide
19 HF 900A 8 Guide
20 ES 314 4 M 10x16 ISO14581- 8.8 Screw
21 HTR3871 2 6 mm Guide block
21 HTR3872 2 8 mm Guide block
22 S410A51-A 2 Extension box
23 UP1407B 2 l=2293 mm Outrigger extension cylinder
see page 0100.10001-A
24 EM 031 2 M 16 DIN 985Nut
25 EK 301 2 D 12 ISO7089-A2-HV140 Washer
26 ES 458 2 M 12x50 ISO4762-10.9Screw
27 EM 003 4 M 8 DIN 934-8 Nut
28 ES 013 4 M 8x30 DIN 933 Screw
29 HT11147 2 L0188xB0058xS002Cover plate
30 EK 003 4 D 8.4 ISO7089Washer
31 ES 858 4 M 8x10 ISO4762- 8.8Screw
www.palfinger.com
10/2012
Page 37
PK 41002 MH # 100492226 0100.10000-A
Extension box R3X
31
29
3
4
55
6
7
8
9
8
11
10
30
12
222
1
15
13
14
10
26
19
25
28
22
27
23
10
2121
19
10
20
18
17
1616
15
23
24
22
10
10/2012
10
www.palfinger.com
Page 38
Outrigger extension cylinder UP1407B
Description DimensionNo. Qty.Spare part
1 UP1407B 1 l=2293 mm Outrigger extension cylinder
2 HY1279A 1 Cylinder tube
3 HSK1164 1 Piston rod
4 TD 526A 1 Seal kit
5 HV 437A 1 M044x1.5 d025xL052 Cylinder nut
PK 41002 MH # 1004922260100.10001-A
www.palfinger.com
10/2012
Page 39
PK 41002 MH # 100492226 0100.10001-A
Outrigger extension cylinder UP1407B
4
4
5
4
4
3
2
1
10/2012
www.palfinger.com
Page 40
Hose tray R3X
Description DimensionNo. Qty.Spare part
1 HX 611 2 L0058.2xB0039.1 xS003.0 Clip
2 ES 297 2 M 8x25 ISO14581- 8.8 Screw
3 HTR 976 1 Bracket plate
4 EZ 437 28 Chain link
5 EZ1368 1 Special single part
6 ES1329 2 M 6x20 ISO14581- 8.8Screw
7 EK 567 4 D 6 Washer
8 EM 014 4 DIN 985-8 M 6 Nut
9 HF 281 1 13.5 mmGuide
10 EZ1367 1 Special single part
11 ES 418 2 M 6x16 ISO14581- 8.8 Screw
12 HA2598 1 Hose tray
13 ES 019 2 M 6x20 ISO4762-10.9 Screw
PK 41002 MH # 1004922260100.10010-A
www.palfinger.com
10/2012
Page 41
PK 41002 MH # 100492226 0100.10010-A
Hose tray R3X
1
2
5
3
10
1
4
6
7
2
7
11
8
13
8
9
10/2012
12
12
www.palfinger.com
Page 42
Hose tray R4X
Description DimensionNo. Qty.Spare part
1 HXE9087 1 Bearer
2 HXE9088 1 Bearer
3 ES 419 6 M 6x12 ISO14581- 8.8 Screw
4 HF 047 1 2 mm Guide
5 HXE9086 1 Cylinder guide
6 ES 879M 4 M 6x10 DIN 7984-A2-80Screw
7 ES 858 4 M 8x10 ISO4762- 8.8Screw
8 EZ4799+00001 1 Link chain (49-sections)
EZ4795 1 Special single part
EZ4796 1 Special single part
EZ4797 8 Chain link
EZ4798 39 Chain link
9 ES1462 2 M 8x25 ISO4762- 8.8 Screw
10 EK 003 2 D 8.4 ISO7089Washer
11 EM 026 2 DIN 985 M8 Nut
12 ES 476 4 M 5x12 ISO14581- 8.8Screw
13 HTR2022 1 Bracket plate
14 HA10348 1 Bearer
15 HXE9092 1 Hose tray
PK 41002 MH # 1004922260100.10110-A
16 HTR2028 1 Bracket plate
17 HXE9085 1 Cover
18 ES 105 2 M 6x40 ISO4762 10.9 Screw
19 ES1330 2 M 6x25 ISO14581- 8.8 Screw
20 HTR4931 1 Distance plate
www.palfinger.com
10/2012
Page 43
PK 41002 MH # 100492226 0100.10110-A
Hose tray R4X
11
5
8
4
7
10
9
6
12
3
13
1
2
3
18
3
19
17
20
12
15
16
7
14
10/2012
www.palfinger.com
Page 44
Extension - box piping R3X,VDM07
Description DimensionNo. Qty.Spare part
1 HLR14920 1 D 12 Pipe
2 HLR14919 1 D 12 Pipe
3 EA 195 6 T 12-SFitting
4 HLR14931 1 D 12 Pipe
5 HLR14932 1 D 12 Pipe
6 HLR14721 1 D 12 Pipe
7 EA2998 2 GR 16/12SFitting
8 EA 343 2 BUZ 16 SBlind plug
9 EA 045 2 M 16-S - M 24x1,5Nut
10 HLR14722 1 D 12 Pipe
11 HLR14720 1 D 12 Pipe
12 EA 774 4 ROV 12-SPlug
13 HLR14957 1 D 12 Pipe
14 HLR14950 1 D 12 Pipe
15 HLR14962 1 D 12 Pipe
16 HLR14963 1 D 12 Pipe
17 HLR14719 1 D 12 Pipe
18 HLR14717 1 D 12 Pipe
19 HLR14718 1 D 12 Pipe
20 HLR14714 1 D 12 Pipe
PK 41002 MH # 1004922260100.11000-A
21 HLR14713 1 D 12 Pipe
22 HLR14712 1 D 12 Pipe
23 EA 204 7 G 12 S Fitting
24 HLR14708 1 D 12 Pipe
25 HLR14707 1 D 12 Pipe
26 HLR 9324A 2 D 12 Pipe
27 EA1749 2 WEE 12S 3/8" Adaptor
28 HLR 9323A 2 D 12 Pipe
29 EH9730 2 NW 8x4100 Hose
30 EH2512 2 NW 8x4100 Hose
31 HLR 9322A 2 D 12 Pipe
32 UV423 2 80 barPretension valve, cpl.
see page 0100.11101-A
33 HLR14706 1 D 12 Pipe
34 HLR14744 1 D 12 Pipe
35 HLR14746 1 D 12 Pipe
36 HLR14745 1 D 12 Pipe
www.palfinger.com
10/2012
Page 45
PK 41002 MH # 100492226 0100.11000-A
Extension - box piping R3X,VDM07
14
2
1
3 3
13
Control valve
4
3
6
7 7
8 8
9
10
5
12 12 1212
11
15
17
Page-B
34
35
36
32
18
20
16
21
30
3
9
3
31
22
19
29
28
23
26
24
23
25
27
10/2012
27
23
28
26
29
30
33
Page-A
3
31
32
www.palfinger.com
Page 46
Pretension valve UV423
Description DimensionNo. Qty.Spare part
1 UV423 1 80 barPretension valve, cpl.
2 EA 039 1 GE 12S R3/8"-ED Fitting
3 EV4107/080 1 Pretension valve
PK 41002 MH # 1004922260100.11101-A
www.palfinger.com
10/2012
Page 47
PK 41002 MH # 100492226 0100.11101-A
Pretension valve UV423
3
2
1
10/2012
www.palfinger.com
Page 48
Support STZS3
Description DimensionNo. Qty.Spare part
1 UP2957 1 Stabilizer ram
see page 0100.12001-A
2 EA 245 2 W 12-S Angle fitting
3 EA 201 2 EGE 12S R3/8-ED Fitting
4 EV4109B 1 Check valve
see page 0100.12002-A
5 EA1749 1 WEE 12S 3/8" Adaptor
6 ES1086 10 M 16x55 DIN 931Screw
7 EK 840 20 D 17 DIN433-140Washer
8 EM 159M 10 M 16 DIN 980-10Nut
9 HLR10208A 1 D 12 Pipe
PK 41002 MH # 1004922260100.12000-A
www.palfinger.com
10/2012
Page 49
PK 41002 MH # 100492226 0100.12000-A
Support STZS3
4
3
5
2
6
7
8
7
1
9
10/2012
www.palfinger.com
Page 50
Stabilizer ram UP2957
Description DimensionNo. Qty.Spare part
1 UP2957 1 Stabilizer ram
2 HY2157 1 Cylinder tube
3 TD1170 1 Seal kit
4 HSK1412A 1 Piston rod
5 HV 389A 1 Cylinder nut
PK 41002 MH # 1004922260100.12001-A
www.palfinger.com
10/2012
Page 51
PK 41002 MH # 100492226 0100.12001-A
Stabilizer ram UP2957
2
4
1
3
3
10/2012
5
3
3
3
www.palfinger.com
Page 52
Check valve EV4109A
Description DimensionNo. Qty.Spare part
1 EV4109B 1 Check valve
2 EA5792 1 Banjo bolt
3 ED 620 1 KD 3/8" Sealing ring
PK 41002 MH # 1004922260100.12002-A
www.palfinger.com
10/2012
Page 53
PK 41002 MH # 100492226 0100.12002-A
Check valve EV4109A
2
1
3
10/2012
www.palfinger.com
Page 54
Stabilizer plates
Description DimensionNo. Qty.Spare part
1 HXE3506 1 D 230 Stabilizer plates
2 EA 412 1 M 6x1 H1 71412 Grease nipple
3 HBS3328 1 d075xD091xL040 Bearing bush
4 HBS3327 1 D114.3xd087.2xL010.0 Cover
5 ES 344 4 M 6x20 DIN 933 Screw
PK 41002 MH # 1004922260100.12202-A
www.palfinger.com
10/2012
Page 55
PK 41002 MH # 100492226 0100.12202-A
Stabilizer plates
5
4
3
1
2
10/2012
www.palfinger.com
Page 56
Oil cooler 10,5kW
Description DimensionNo. Qty.Spare part
1 HA6856 1 Bracket
2 ES 156 4 M 8x16 ISO14581- 8.8 Screw
3 EK 568 4 D 8 Washer
4 EK 905 4 M8 Rubber damper
5 BKA56 1 10kW - 24V Oil cooler
see additional chapter AB002
5 BKA63-24V 1 10,5 kW Oil cooler
see additional chapter AB002
6 EK 003 4 D 8.4 ISO7089Washer
7 EM 026 4 DIN 985 M8 Nut
8 EK 007 3 D 10.5 ISO7089 Washer
9 ES 049 3 M 10x16 DIN 933 Screw
PK 41002 MH # 1004922260100.15000-A
www.palfinger.com
10/2012
Page 57
PK 41002 MH # 100492226 0100.15000-A
Oil cooler 10,5kW
Spare parts see AB002
1
9
2
4
3
7
55
6
8
10/2012
www.palfinger.com
Page 58
Control valve VDM07
Description DimensionNo. Qty.Spare part
1 EV5868 2 VDM07 Control valve
see page 0200.01001-A
2 EA 039 16 GE 12S R3/8"-ED Fitting
2 EA 769 3 GE 16 SR 3/8"-EDFitting
2 HLA 376 2 GE 18 L 3/8-ed Fitting
3 EZ3289 2 2.2 mmRestrictor
4 EA 746 1 vsti M 18x1.5 Locking screw
PK 41002 MH # 1004922260200.01000-A
www.palfinger.com
10/2012
Page 59
PK 41002 MH # 100492226 0200.01000-A
Control valve VDM07
1 1
3
Valve
Pressure/bar
Control valve
KSC = with adaptors and valves
EV = KSC without adaptors and valves
HUV = Main relief valve
P,T = Supply connections
O = with overload protection
x = open center - spool must be ordered seperatly
Fitting
3
2 22 22 2
Restrictor
Lever
Element
Valve
Pressure/bar
Fitting
Restrictor
4
Lever
Element
10/2012
www.palfinger.com
Page 60
Control valve - details
Description DimensionNo. Qty.Spare part
1 EV 990 1 Main relief valve, cpl.
2 EK 715A 1 Sealing cap
3 EZ3291 4 Spring housing, cpl.
4 EZ3292 4 Lever support, cpl.
5 EV5857 1 Main relief valve
6 EV1021 1 M 18x1.5 - 3/8" High pressure carry over port
PK 41002 MH # 1004922260200.01001-A
www.palfinger.com
10/2012
Page 61
PK 41002 MH # 100492226 0200.01001-A
Control valve - details
6
4
3
1
2
5
10/2012
www.palfinger.com
Page 62
Control system
Description DimensionNo. Qty.Spare part
1 HH 519 4 Control lever
2 ES 963 8 M 8x16 ISO7380 Screw
3 HH 478 4 Control lever
4 HSV 862 4 Control rod
5 EK 379 2 D 21 DIN 1441 Washer
6 HI2603 4 Pin
7 HH 513 4 Control lever
8 EQ 116 4 D4 DIN6799 Safety washer
9 HI2735 1 Control axle
10 ES 080 3 M 6x35 DIN 6912 Screw
11 EK 043 3 D 6.4 DIN 134 Washer
12 EM 014 3 DIN 985-8 M 6 Nut
13 ES 105 1 M 6x40 ISO4762 10.9 Screw
14 HA6509 1 Bearer
PK 41002 MH # 1004922260200.02000-A
www.palfinger.com
10/2012
Page 63
PK 41002 MH # 100492226 0200.02000-A
Control system
14
6
5
13
12
4
3
2
1
2
7
8
9
10
11
12
10/2012
www.palfinger.com
Page 64
Control valve (4-sections) FL,H
Description DimensionNo. Qty.Spare part
1 EV6034H 1 Control valve
(MHPLS)
see page 0231.0...
2 EA 053 1 GE 28 L R1/1" Fitting
2 EA 074 7 GE 16S R1/2"-EDFitting
2 EA 183 2 GE 12S R1/2"-ED Fitting
2 EA1018 1 GE 25 S R3/4"Fitting
2 EA1514 1 GE 18-LR 1/1-ed Fitting
3 EA 261 1 VSTI R1/2" Locking screw
4 EA 716 1 EMA3 R1/4" Dial gauge connection
PK 41002 MH # 1004922260230.01000-A
www.palfinger.com
10/2012
Page 65
PK 41002 MH # 100492226 0230.01000-A
Control valve (4-sections) FL,H
Valve
Control valve
KSC = with adaptors and valves
EV = KSC without adaptors and valves
HUV = Main relief valve
P,T = Supply connections
O = with overload protection
x = open center - spool must be ordered seperatly
Fitting
Restrictor
Lever
Element
10/2012
1
4
3
22222
www.palfinger.com
Page 66
Control system
Description DimensionNo. Qty.Spare part
1 ES 265 2 M 8x20 ISO4762- 8.8 Screw
2 EK 003 2 D 8.4 ISO7089Washer
3 HI 827 1 Control axle
4 HH 507 1 Control lever, blue
4 HH 509 Control lever, yellow
5 HSV 861 Control rod
6 HI2603 Pin
7 EQ 116 D4 DIN6799 Safety washer
8 HH 511 Control lever, yellow
8 HH 515 1 Control lever, blue
PK 41002 MH # 1004922260230.02000-A
www.palfinger.com
10/2012
Page 67
PK 41002 MH # 100492226 0230.02000-A
Control system
6
7
88
5
1
2
44
3
10/2012
2
1
www.palfinger.com
Page 68
Inlet element
Description DimensionNo. Qty.Spare part
1 EV4556 1 RSQ 240 Inlet element
2 EV5714 1 35-350 bar Main relief valve
TD 955 1 Seal kit
3 EB1976 1 Lead seal
4 TD 959 1 Seal kit
5 EA1828 1 RI 1/2*1/4" Reduction
6 EV4557 1 Check valve
7 EF 148 1 Spring
8 EA1827 1 Locking screw
9 TD 953 1 Seal kit
11 EV4615 1 Solenoid valve
TD 239 1 Seal kit
12 EV4710 1 26VMagnet coil d=13 mm
13 HLA1123 1 Protecting cap
14 EV4615A 1 Solenoid valve
15 EEA15740 1 26 V Magnet coil d=16 mm
16 EV8790 1 Protecting cap
PK 41002 MH # 1004922260230.01000-A
www.palfinger.com
10/2020
Page 69
5
6
7
8
9
4
1
2
3
10
11
12
13
14
15
16
PK 41002 MH # 100492226 0230.01000-A
Inlet element
13
11
12
16
15
14
4
3
2
9
1
8
10/2020
7
6
5
www.palfinger.com
Page 70
PK 41002 MH # 1004922260230.02000-A
Separate element
Description DimensionNo. Qty.Spare part
1 EM 021 4 DIN 985 M10 CL8 ZB Nut
2 EK 007 4 D 10.5 ISO7089 Washer
3 ES1404 1 Anchor bolt, cpl. (4-elements)
4 EB 925 8 Lead seal
5 EV4560/... 2 -->300 bar Pressure relief valve
TD 956 2 Seal kit
6 EV4935/... 4 -->300 bar Relief pressure valve without anti cavication valve
TD 956 4 Seal kit
7 EV6067 1 133SC - EV6057Control valve - slewing
EV6057 1 Spool 133SC
see page 0231.03001-A
8 EV5117/... 2 300 bar--> Relief pressure valve without anti cavication valve
TD 956 2 Seal kit
9 EV6074 1 135XDControl valve
EV6064 1 Spool 135XD
for overload protection
see page 0231.04001-A
10 EV6072 1 135ADControl valve
EV6062 1 Spool 135AD
see page 0231.04001-A
11 EV6075 1 135ZDControl valve
EV6065 1 Spool 135ZD
see page 0231.04001-A
www.palfinger.com
10/2012
Page 71
PK 41002 MH # 100492226 0230.02000-A
Separate element
11
1
2
6
4
6
4
4
6
10
4
8
9
8
4
7
10/2012
6
4
3
2
5
4
www.palfinger.com
1
Page 72
Control valve - details
Description DimensionNo. Qty.Spare part
1 EK 881 1 RSQ 240 Spring cap
2 EV4537 1 RSQ 240 Spring cap
3 ED 076 2 O-ring with back up ring
4 EV4543 1 RSQ 240 One way restrictor
TD 964 1 Seal kit
5 EV4542 1 RSQ 240 Check valve
TD 964 1 Seal kit
6 EB1976 1 Lead seal
7 EV4534 1 RSQ 240 Lever support, cpl.
8 TD 959 1 Seal kit
9 EV7372 1 RSQ 240 Spool position control
10 EV7370 1 Spool position control
PK 41002 MH # 1004922260230.04001-A
www.palfinger.com
10/2012
Page 73
PK 41002 MH # 100492226 0230.04001-A
Control valve - details
6
7
5
3
8
1
2
PAL50
3
4
6
7
5
3
8
1
10/2012
3
4
9
10
www.palfinger.com
Page 74
End element
Description DimensionNo. Qty.Spare part
1 EV4549 1 RSQ 240 End element
2 EV4546 1 Plug
TD 956 1 Seal kit
PK 41002 MH # 1004922260230.05000-A
www.palfinger.com
10/2012
Page 75
PK 41002 MH # 100492226 0230.05000-A
End element
2
1
10/2012
www.palfinger.com
Page 76
Encoder
Description DimensionNo. Qty.Spare part
1 ES 414 3 M 6x10 ISO4762- 8.8 Screw
2 EEA4680 2 Rubber grummet
3 HXE4384 1 Carrier
4 HA12004 1 Stop buffer
5 EEA10020 1 4 m Inductive switch Opener
6 ES 412 2 M 3x16 DIN 84Screw
7 EK1147A 1 Coupling
100141878-->
8 ES2680 3 M 4x8 DIN 7985 Screw
9 EEA13284 1 P50 Shaft encoder Can Kingdom
10 HA8930 1 Bearer
11 HT8950 1 L0060.0xB0020xS005 Bracket plate
12 EK 190 2 d=6.4 ISO7089Washer
13 ES 087 2 M 6x30 ISO4762- 8.8 Screw
PK 41002 MH # 1004922260300.04000-A
www.palfinger.com
10/2012
Page 77
PK 41002 MH # 100492226 0300.04000-A
Encoder
9
10
8
7
11
12
13
5
6
1
4
10/2012
3
2
1
2
www.palfinger.com
Page 78
PK 41002 MH # 1004922260301.02000-A
Housing PT050
Description DimensionNo. Qty.Spare part
1 EEA 292 1 175x80x15 Cover
2 EEA 391 1 175x80x15 Cover
3 EEA3689 1 175x80x43.5 Base
3 EEA6391 1 175x80x43.5 Base for breather membrane
The membrane are not included in the delivery.
4 EEA3909 1 Breather valve M 12x1.5
4 EEA6395 1 Breather membrane M 12x1.5
5 EEA5406 1 Terminal ISC
EA12480 1 Cover, cpl.
EEA5767 1 Push button, green
EEA9829 1 Emergency cut-off button
ES3628 4 Screw M 4x45
6 EEA5378 1 Terminal ISC
EEA11520 1 Cover + Symbol sign EB2824
EEA9829 1 Emergency cut-off button
ES3628 4 Screw M 4x45
7 EEA5062 1 Terminal PT050
8 EEA5061 1 Terminal PT050
9 EEA1716 1 Valve casing, cpl.
10 EEA3690 1 Base
www.palfinger.com
10/2012
Page 79
PK 41002 MH # 100492226 0301.02000-A
Housing PT050
5
1
2
4
33
6
7
8
9
10/2012
10
www.palfinger.com
Page 80
PK 41002 MH # 1004922260301.02100-A
Housing PT050
Description DimensionNo. Qty.Spare part
1 EEA 441 1 250x80x15 Cover
2 EEA 439 1 250x80x15 Cover
3 EEA5405 1 Terminal ISC
EEA12479 1 Cover + Symbol sign EB2518
EEA3000 1 Key switch (2-positions)
ES3628 4 Screw M 4x45
4 EEA5043B 1 Terminal PT050
EEA11523 1 Cover + Symbol sign EB2516
EEA6077 1 Emergency cut-off button
ES3628 4 Screw M 4x45
5 EEA 269 1 250x80x43.5 Base
5 EEA6392 1 250x80x43.5Base for breather membrane
The membrane are not included in the delivery.
6 EEA3909 1 Breather valve M 12x1.5
6 EEA6395 1 Breather membrane M 12x1.5
7 EEA5774 1 KDP 24/17 Running of cable
8 EEA5775 1 KDP 24/22 Running of cable
www.palfinger.com
10/2012
Page 81
PK 41002 MH # 100492226 0301.02100-A
Housing PT050
1
3
2
4
6
55
10/2012
8
7
www.palfinger.com
Page 82
PT050Attachment board
Description DimensionNo. Qty.Spare part
1 EEA2937 1 12/24V Attachment board
2 EEA3087 1 Typ BLWire plug (6-sections)
3 EB3499 1 Symbol sign
4 EEA1930B 1 PAL 50 Drawer electronics, cpl.
EEA12797 1 Spool position board
EEA12797B 1 Spool position board
5 EEA4658 1 Indicator module
6 EEA5342 1 Attachment board
7 EEA6195B 1 V 4.6Attachment board
8 EEA5367 1 Kit PAL50
EEA2887 4 Spacer l=10 mm
EEA5337 1 Distance pin M 3x14 mm SW5
EEA5338 1 Spacer l=10 mm d=3.2 mm
EEA5343 2 Distance pin M 6x25 mm SW10
EEA5344 2 Distance pin M 6x14 mm SW10
EEA5345 2 Distance pin M 6x10 mm SW10
EEA5348 12 Spacer l=7 mm d=6 mm M3
EEA5360 12 Distance pin M 3x15 mm SW5
EEA5361 2 Distance pin M 3x18 mm SW5
EEA5362 4 Distance pin M 3x8 mm SW5
EM 004 4 Nut DIN 934 M6 CL8 ZB
EM 226 13 Nut M 3 DIN 934
EQ 195 4 Circlip D 6.1 DIN 127
EQ1495 13 Fan disc A 3.2 mm DIN 6798
9 HT10800 1 Cover plate
10 EEA5376 1 Kit ISC/HPSC Pal 50
PK 41002 MH # 1004922260301.02200-A
11 EEA5353 1 ISC/HPSC Pal 50Attachment board
12 EEA5316 1 ISC/HPSC Pal 50Attachment board
13 HT12223 1 Cover plate
www.palfinger.com
10/2012
Page 83
PK 41002 MH # 100492226 0301.02200-A
PT050Attachment board
2
1
4
3
5
7
6
8
Bracket plate for attachment board see position 8
11
10
9
12
10/2012
13
www.palfinger.com
Page 84
Decals PT050
Description DimensionNo. Qty.Spare part
1 EB3205 1 Symbol sign
2 EEA11524 1 Cover + Symbol sign EB2515
3 EEA11520 1 Cover + Symbol sign EB2824
4 EEA12422 1 Cover + Symbol sign EB2514
5 EB2810 1 Symbol sign
6 EEA12479 1 Cover + Symbol sign EB2518
7 EB3059 1 Symbol sign
8 EB2305 1 Symbol sign
9 EA12480 1 Cover, cpl.
10 EB2517 1 Symbol sign
11 EB12008 1 Sign
12 EB2309 1 Symbol sign
13 EB2440 1 Decal
14 EB4492 1 80x80 mm Decal
PK 41002 MH # 1004922260301.02300-A
www.palfinger.com
10/2012
Page 85
PK 41002 MH # 100492226 0301.02300-A
Decals PT050
1
2
3
4
11
5
6
7
8
9
10
13
10/2012
12
14
www.palfinger.com
Page 86
PK 41002 MH # 1004922260301.06000-A
Adaptor, switch
Description DimensionNo. Qty.Spare part
1 EEA3703 1 M 25x1.5 (1x7-17 mm)Fitting
1 EEA3704 1 M 32x1.5 (1x13-21 mm)Fitting
1 EEA3705 1 M 20x1.5 (1x4-13 mm)Fitting
1 EEA 509 1 PG 11 Fitting
2 EEA3706 1 M 32x1.5 (4x5-7 mm) Fitting
2 EEA3707 1 M 32x1.5 (2x8-10 mm)Fitting
2 EEA3708 1 M 25x1.5 (4x4-6 mm)Fitting
2 EEA3709 1 M 25x1.5 (3x5-7 mm)Fitting
2 EEA4444 1 M 32x1.5 (6x4-6 mm)Fitting
2 EEA4987 1 M 32x1.5 (8x3-5 mm)Cartridge
2 EEA6380 1 M 40x1.5 (6x5-7 mm)Fitting
3 EEA3710 1 M 32x1.5 (3x6-8 mm) Cartridge
4 EEA3711 1 M 25x1.5 Blind plug
4 EEA3712 1 M 32x1.5Blind plug
4 EEA3727 1 M 20x1.5Blind plug
5 EEA3713 1 M 25x1.5 Counter nut
5 EEA3714 1 M 20x1.5Counter nut
5 EEA3725 1 M 32x1.5Counter nut
6 EEA3715 1 M 32x1.5 - M 25x1.5 Reduction
6 EEA3726 1 M 25x1.5 - M 20x1.5Reduction
6 EEA4726 1 M 32 - M 25x1.5Reduction
7 EEA3716 1 M 25x1.5 - M 32x1.5 Extension
7 EEA3728 1 M 20x1.5 - M 25x1.5Extension
8 EEA3909 1 Breather valve M 12x1.5
8 EEA6395 1 Breather membrane M 12x1.5
9 EEA6077 1 Emergency cut-off button
10 EEA5767 1 Push button, green
Closer
10 EEA9834 1 Push button, green
Opener - Closer
10 EEA5795 1 Push button, green
(detent)
10 EEA5766 1 Alarm lamp, green
10 EEA9813 1 Alarm lamp, red
11 EEA5768 1 Switch (2-positions)
Closer
11 EEA6325 1 Switch (2-positions)
Opener
11 EEA5769 1 Switch (3-positions)
(spring - detent - spring)
11 EEA6429 1 Switch (3-positions)
(detent - detent - detent)
12 EEA5765 1 Blind plug
13 EEA2998 1 Emergency cut-off button
14 EEA9829 1 Emergency cut-off button
15 EEA3002 1 Key switch (3-positions)
16 EEA3157 1 RONIS 601 Key
17 EEA3001 1 Blind plug
18 EEA4871 1 22 mmSwitch (2-positions)
19 EEA3000 1 Key switch (2-positions)
20 EEA3156 1 RONIS 455 Key
21 EEA5774 1 KDP 24/17 Running of cable
22 EEA5775 1 KDP 24/22 Running of cable
www.palfinger.com
10/2012
Page 87
PK 41002 MH # 100492226 0301.06000-A
Adaptor, switch
1111
555
2222222
666
3
77
444
8
16 mm
9
1010101010
11111111
12
22 mm
13
14
22
21
15
17
16
18
19
20
10/2012
www.palfinger.com
Page 88
Wire plug
Description DimensionNo. Qty.Spare part
1 EK 370 1 C16-3 Protecting cap 14+PE
2 EEA4403 1 Plug box 14+PE
EEA5498 1 Contact C16-3 0.5-1.5 mm²
EEA5500 1 Contact C16-3 0.75-1 mm²
EEA5554 1 Contact C16-3 0.35-0.5 mm²
3 EEA 600 1 C16-3Wire plug 14+PE
EEA5499 1 Contact C16-3 0.75-1 mm²
EEA5497 1 Contact C16-3 0.5-1.5 mm²
EEA5554 1 Contact C16-3 0.35-0.5 mm²
4 EEA5492 1 Diagnostic cable PT050
5 EEA5493 1 Diagnostic cable PT050
6 EEA 028 1 Plug
7 EEA 029 1 Plug box
PK 41002 MH # 1004922260301.07000-A
www.palfinger.com
10/2012
Page 89
PK 41002 MH # 100492226 0301.07000-A
Wire plug
2
1
3
4
5
7
6
10/2012
www.palfinger.com
Page 90
Line-up terminal
Description DimensionNo. Qty.Spare part
1 EEA4552 1 ZDK 27.6 mm Cross connection (2-sections)
2 EEA4553 1 ZDK 27.6 mm Cross connection (3-sections)
3 EEA4554 1 ZDK 27.6 mm Cross connection (4-sections)
4 EEA4555 1 ZDK 27.6 mm Cross connection (5-sections)
5 EEA4556 1 ZDK 27.6 mm Cross connection (6-sections)
6 EEA4557 1 ZDK 27.6 mm Cross connection (10-sections)
7 EEA9803 1 ZDK Stop plate
8 EEA9802 1 ZDK max. 2.5² Line-up terminal
9 EEA4550 1 ZDK max. 2.5² Line-up terminal
10 EEA4551 1 ZDK 27.6 mm Stop plate
11 EEA4559 1 ZDK max. 2.5² Line-up terminal LED
12 EEA4558 1 ZDK End terminal
13 EEA6078 1 Fuse bracket
14 EEA1804 1 7.5 AFuse
14 EEA4577 1 5 AFuse
14 EEA6090 1 1 AFuse
15 EEA 930 Bearing rail
Metered good
PK 41002 MH # 1004922260301.08000-A
16 EEA9827 2 Attaching bracket
17 EEA4548 1 ZDK 23 mm Cross connection (2-sections)
17 EEA4932 1 ZDK 23 mm Cross connection (4-sections)
18 EEA4547 1 ZDK End terminal
19 EEA4543 1 ZDK max. 2.5² Line-up terminal
20 EEA4546 1 ZDK Connection plate
www.palfinger.com
10/2012
Page 91
PK 41002 MH # 100492226 0301.08000-A
Line-up terminal
1
2
3
4
5
6
7
18
15
1
8
19
20
1717
141414
9
10
11
12
13
16
10/2012
www.palfinger.com
Page 92
PK 41002 MH # 1004922260301.09000-A
Relay (1)
Description DimensionNo. Qty.Spare part
1 EE 024 1 24V 10ARelay
2 EE 101 1 24V 12A Relay
3 EE 102 1 24V 7A Relay
4 EE 124 1 24V 7A Relay - gold contakt
5 EE 127 1 24V 8A Relay
6 EEA1456 1 24V 4A Relay
6 EEA4088 1 24V 6A Relay - gold contakt
7 EEA6216 1 24V 10ARelay - projector
8 EEA 986 1 24V 2ATime lag relay
9 EEA4540 1 24-48V 10h Time lag relay - clock generator
9 EEA5351 1 12-240VAC/DCTime lag relay - radio controlled support
10 EEA3481 1 12V 10ATime lag relay - clock generator
11 EEA1812 1 24V 16A Relay
12 EEA4297 1 24V 16A Relay
13 EEA5060 1 8...32VdcTime lag relay
14 EEA1425 1 24V 10ARelay
www.palfinger.com
10/2012
Page 93
PK 41002 MH # 100492226 0301.09000-A
Relay (1)
1
8
2
99
3
10
4
11
5
12
66
7
10/2012
13
14
www.palfinger.com
Page 94
Relay (2)
Description DimensionNo. Qty.Spare part
2 EEA3971 1 24V 6A Relay
3 EEA4972 1 24V 6A Relay
4 EEA2342 1 24V 20A Relay
5 EEA3748 1 24V 18A Relay
6 EEA5339 1 24V 6A Relay
7 EEA5319 1 24VStop plate
PK 41002 MH # 1004922260301.09100-A
www.palfinger.com
10/2012
Page 95
PK 41002 MH # 100492226 0301.09100-A
Relay (2)
2
3
4
5
6
7
10/2012
www.palfinger.com
Page 96
PK 41002 MH # 1004922260301.10000-A
Miscellaneous
Description DimensionNo. Qty.Spare part
1 EEA11926 1 Plug with cable (4-pole) M 12 - 5 m 2x2 CAN-Bus
1 EEA9818 1 Plug with cable (4-pole) M 12 - 1 m
1 EEA9985 1 Plug with cable (3-pole) M 8 - 12 m
1 EEA5382 1 Plug with cable (4-pole) M 12 - 8 m
1 EEA5383 1 Plug with cable (4-pole) M 12 - 12 m
1 EEA5639 1 Angle plug with cable (4-pole) M 12 - 2.6 m
1 EEA13589 1 Connecting cable (3-pole) M 8 - 8 m
1 EEA9815 1 Plug with cable (4-pole) M 12 - 11 m
1 EEA9814 1 Plug with cable (4-pole) M 12 - 3 m
1 EEA11661 1 Angle plug with cable (4-pole) M 12 - 3 m
1 EEA5384 1 Plug with cable (4-pole) M 12 - 15 m
1 EEA12216 1 Plug with cable (4-pole) M 12 - 3 m 2x2 CAN-Bus
1 EEA1150 1 Plug with cable (3-pole) M 12 - 12 m
1 EEA2574 1 Plug with cable (3-pole) M 12 - 8 m
1 EEA5075 1 Plug with cable (3-pole) M 12 - 3 m
1 EEA3105 1 Angle plug with cable (4-pole) M 12 - 2 m
1 EEA5790 1 Plug with cable (4-pole) M 12 - 8 m
1 EEA6076 1 Plug with cable (4-pole) M 12 -5 m
1 EEA13653 1 Connecting cable (4-pole) M 12 - 7.5 m
1 EEA14103 1 Plug with cable (4-pole) M 12 - 2 m
2 EEA 156 1 Plug
3 EEA 772 1 1,5 m Plug with cable LED
3 EEA 773 1 3 m Plug with cable LED
3 EEA2810 1 10 mPlug with cable LED, red
3 EEA2811 1 5 mPlug with cable
4 EEA11002 0 Cable (metre goods) 2x1.5 mm²
4 EEA6213 0 Cable (metre goods) 7x0.5 mm²
4 EEA5260 0 Cable for drag chain (metro goods) CAN 25x1,12x0.5,3x0.34 mm"
4 EEA6172 0 Cable (CAN 34-pole) metre goods 17x1 - 14x0.5 - 3x0.34 mm²
4 EEA5354 0 Cable (metre goods) 18x0.5 mm²
4 EEA11460 0 Cable (metre goods) 36x1.5 mm²
4 EEA1755 0 Cable (metre goods) 4x0.34 mm²
4 EEA5370 0 Cable (metre goods) 33x1.5 mm²
4 EEA3814 0 Cable (metre goods) 3x1 mm²
4 EEA5419 0 Cable (metre goods) 2x1.5 mm²
4 EEA5421 0 Cable (metre goods) 2x2.5 mm²
4 EEA6169 0 Cable (metre goods) 6x0.75 mm²
4 EEA4380 0 Cable (metre goods) 2x0.75 mm²
4 EEA5503 0 Cable (CAN 18-pole) metre goods 15x1 - 3x0.34 mm²
4 EEA 058 0 Cable (metre goods) 3x0.5 mm²
4 EEA 169 0 Cable (metre goods) 2x1 mm²
4 EEA 170 0 Cable (metre goods) 2x1.5 mm²
4 EEA 192 0 Cable (metre goods) 7x1.5 mm²
4 EEA2478 0 Cable (metre goods) 2x2.5 mm²
4 EEA4377 0 Cable (metre goods) 10x1.5 mm²
4 EEA4376 0 Cable (metre goods) 5x2.5 mm²
4 EEA4378 0 Cable (metre goods) 12x0.75 mm²
4 EEA4379 0 Cable (metre goods) 4x0.75 mm²
4 EEA5422 0 Cable 2x2.5 mm² x 2220mm
4 EEA13157 0 Cable (CAN 2x 41-pole) metre goods 25x1 - 12x0.5 - 4x0.34 mm²
5 EK 155 1 l=102x2.5 Cable tie
5 EK 165 1 l=215x4.8 Cable tie
6 EEA5764 1 Fuse bracket
7 EEA6073 1 1AFuse
8 EH 620 1 NW 70x1000 Protection hose
8 EH 822 1 NW 50x500 Protection hose
8 EH 878 1 NW 102x1000 Protection hose
9 EEA6165 1 M 12 Pendulum, cpl.
10 ES 414 2 M 6x10 ISO4762- 8.8 Screw
www.palfinger.com
10/2012
Page 97
PK 41002 MH # 100492226 0301.10000-A
Miscellaneous
1
4
3333
7
55
2
9
11
12
10
13
1515
19191919191919
10
16161616
6
888
18
17
1414
212121
24
20
25
232323
26
27
29
28
10/2012
2222
www.palfinger.com
Page 98
PK 41002 MH # 1004922260301.10000-A
Miscellaneous
Description DimensionNo. Qty.Spare part
11 EEA6321 1 M 12 Pendulum (0-180°)
12 EEA3527 1 Hour meter
13 HT1041 1 Cover plate
14 EEA 080 1 12/24 V Horn
(Alternating tone alert signal)
14 EEA2729 1 12/24 VDC Horn
15 EEA6194 1 12/24 VDC (H6)Horn
15 EEA2753 1 12 m (CE)Horn
(EN12999)
16 EZ1266 1 D 12.2/15.7 mm Protection hose (metre goods)
16 EZ1267 D 16.6/21.2 mmProtection hose (metre goods)
16 EZ1293 D 9.8/13 mm Protection hose (metre goods)
16 EZ2837 D 6.6/10 mmProtection hose (metre goods)
17 EEA5034 1 Female strip (4-sections) Typ BLZF
17 EEA4948 1 Female strip (5-sections) Typ BLZF
17 EEA4947 1 Female strip (9-sections) Typ BLZF
17 EEA4597 1 Female strip (24-sections) Typ BLZF
17 EEA4596 1 Female strip (12-sections) Typ BLZF
17 EEA4595 1 Female strip (10-sections) Typ BLZF
17 EEA4594 1 Female strip (8-sections) Typ BLZF
17 EEA4593 1 Female strip (6-sections) Typ BLZF
17 EEA4592 1 Female strip (3-sections) Typ BLZF
17 EEA4591 1 Female strip (2-sections) Typ BLZF
17 EEA5705 1 Wire plug (15-sections) Typ BLZF
18 EEA1720 1 Wire plug (4-sections) Typ BL
18 EEA2603 1 Wire plug (2-sections) Typ BL
18 EEA2604 1 Wire plug (8-sections) Typ BL
18 EEA2605 1 Wire plug (10-sections) Typ BL
18 EEA2606 1 Wire plug (12-sections) Typ BL
18 EEA2607 1 Wire plug (24-sections) Typ BL
18 EEA2698 1 Wire plug (3-sections) Typ BL
18 EEA3087 1 Wire plug (6-sections) Typ BL
19 EEA 134 12x1 mm² Cable for drag chain (metro goods)
19 EEA 791 18x1 mm² Cable for drag chain (metro goods)
19 EEA1268 12x1.5 mm² Cable for drag chain (metro goods)
19 EEA1705 5x1.5 mm² Cable for drag chain (metro goods)
19 EEA2141 5x1 mm² Cable for drag chain (metro goods)
19 EEA5752 22x1 mm² Cable for drag chain (metro goods)
19 EEA6381 1 25x1.5 mm² Cable for drag chain (metro goods)
20 EEA5591 1 Plug (3-pole)
21 EEA5741 1 1,5 mPlug with cable
21 EEA5742 1 2,5 mPlug with cable
21 EEA6154 1 3,5 mPlug with cable
22 EEA6192 1 12/24 VDCHorn
(Alternating tone alert signal)
22 EEA6193 1 12/24 VDC (H5)Horn
(Continuous tone)
23 EEA2696 1 1.5 mPlug with cable
23 EEA3399 1 3 m Plug with cable
23 EEA9860 1 4 mPlug with cable
24 EEA1718 1 Wire plug
25 EEA1755 4x0.34 mm²Cable (metre goods)
26 EEA5626 1 Connecting piece
27 EEA5625 1 Connecting piece
28 HBS3284 2 l=50 mmSpacer
29 ES 976 2 M 6x60 DIN 931Screw
www.palfinger.com
10/2012
Page 99
PK 41002 MH # 100492226 0301.10000-A
Miscellaneous
1
4
3333
7
55
2
9
11
12
10
13
1515
19191919191919
10
16161616
6
888
18
17
1414
212121
24
20
25
232323
26
27
29
28
10/2012
2222
www.palfinger.com
Page 100
PK 41002 MH # 1004922260400.01000-A
Crane column FL
Description DimensionNo. Qty.Spare part
1 S410S70SA+R3020 1 Crane column (Standard colour RAL 3020)
2 EK 567 4 D 6 Washer
3 ES 419 4 M 6x12 ISO14581- 8.8 Screw
4 HA11662 1 Cover
www.palfinger.com
10/2012
Loading...
