Fairchild FEBFSL206MRN_H428v1, FSL206MRN User Manual

User Guide for

FEBFSL206MRN_H428v1

Evaluation Board

Integrated Controller

FSL206MRN

5W Auxiliary Power Supply

Featured Fairchild Product:

FSL206MRN

Direct questions or comments

about this evaluation board to:

“Worldwide Direct Support”

Fairchild Semiconductor.com

Table of Contents

1. Introduction ............................................................................................................................... 3

1.1. General Description ........................................................................................................... 3

1.2. Features .............................................................................................................................. 3

2. Specifications ............................................................................................................................ 4

3. Photographs............................................................................................................................... 5

4. PCB Layout ............................................................................................................................... 6

5. Test Conditions ......................................................................................................................... 7

6. Performance of Evaluation Board ............................................................................................. 8

6.1. Startup Performance........................................................................................................... 8

6.2. Normal Operation .............................................................................................................. 9

6.3. Voltage Stress of Secondary Diode and Drain ................................................................ 10

6.4. Output Ripple and Noise .................................................................................................. 11

6.5. Short Protections .............................................................................................................. 12

6.6. Brown-In and Brownout Protection ................................................................................. 14

6.7. Temperature Measurement .............................................................................................. 14

6.8. Output Regulation and Efficiency ................................................................................... 15

6.9. Standby Power Consumption ........................................................................................... 17

6.10. EMI Measurement ......................................................................................................... 19

7. Schematic ................................................................................................................................ 21

8. Transformer Specification ...................................................................................................... 22

9. Bill of Materials ...................................................................................................................... 26

10. Revision History ..................................................................................................................... 27

This user guide supports the evaluation kit for the FSL206MR. It should be used in conjunction with the FSL206MR datasheet as well as Fairchild’s application notes and technical support team. Please visit Fairchild’s website at www.fairchildsemi.com

1. Introduction

This document is an engineering report describing measured performance of the FSL206MR.

1.1. General Description

The FSL206MR integrated Pulse Width Modulator (PWM) and SenseFET is specifically designed for high-performance offline Switched-Mode Power Supplies (SMPS) with minimal external components. This device is an integrated high-voltage power regulator that combines an avalanche-rugged SenseFET with a current mode PWM control block.

The integrated PWM controller includes: 7.8V regulator for no bias winding, UnderVoltage Lockout (UVLO) protection, Leading-Edge Blanking (LEB), an optimized gate turn-on/turn-off driver, EMI attenuator, Thermal Shutdown (TSD) protection, temperature-compensated precision current sources for loop compensation, and faultprotection circuitry. Protections include Overload Protection (OLP), Over-Voltage Protection (OVP), Abnormal Over-Current Protection (AOCP), and Line Under-Voltage Protection (LUVP). During startup, the FSL206MR offers good soft-start performance.

.

The internal high-voltage startup switch and the Burst-Mode operation with very low operating current reduce the power loss in Standby Mode. As a result, it is possible to reach power loss of 150mW with no-bias winding and 25mW with bias winding at noload condition when the input voltage is 265V

1.2. Features

 Internal Avalanche Rugged SenseFET: 650V  Precision Fixed Operating Frequency: 67kHz  No-Load <150mW at 265V  Winding; <25mW with Bias Winding  No Need for Auxiliary Bias Winding  Frequency Modulation for Attenuating EMI  Line Under-Voltage Protection (LUVP)  Pulse-by-Pulse Current Limiting  Low Under-Voltage Lockout (UVLO)  Ultra-Low Operating Current: 300µA  Built-In Soft-Start and Startup Circuit  Protections: Overload Protection (OLP), Over-Voltage Protection (OVP),

Thermal Shutdown (TSD), Abnormal Over-Current Protection (AOCP)

 Auto-Restart Mode for All Protections

AC

without Bias

AC

.

V

CC

2 6,7,8

V

STR

5

Drain

V

LS

Good

Internal

Bias

VCCV

REF

I

DELAY

3

FB

4

FB

Line

Sense

2V/1.5V

V

FB

V

SD

V

CC

V

OVP

V

BURL/VBURH

4.5R

H if VLS>2V L if VLS<1.5V

LUVP

OLP

OVP

TSD

CC

Soft-Start

R

VCCGood

7V/8V

OSC

with EMI Attenuator

PWM

V

LEB

SQQ

R

REF

S

R

7.8V

HV

REG

Q

Gate

Q

HV

REG Off

Driver

V

R

SENSE

AOCP

1

GND

TSD

Figure 1. Internal Block Diagram

2. Specifications

Table 1. Evaluation Board Specifications

Output Full-Load Condition 5V / 1A

Fairchild Device FSL206MR

Input Voltage Range 90 ~ 265 VAC

Frequency 60Hz

Maximum Output Power 5W

3. Photographs

Figure 2. Top View (Dimension 64 x 33[mm2])

Figure 3. Bottom View (Dimension 64 x 33[mm

2

])

4. PCB Layout

Figure 4. Top Overlay

Figure 5. Bottom Overlay

Figure 6. Bottom Layer

5. Test Conditions

Evaluation Board #

Test Date

Test Equipment

Test Items

FEBFSL206MRN_H428 Evaluation Board Ver. 1.0

August 18, 2010

AC Source: 6800 Series Electronic Load: Chroma 63030 Oscilloscope: LeCroy 24Xs-A Power Meter: Yokogawa WT210

1. Startup Performance

2. Normal Operation

3. Voltage Stress of Secondary Diode and Drain

4. Output Ripple and noise

5. Short Protections

6. Brown-in and Brownout Protection

7. Temperature Measurement

8. Output Regulation and Efficiency

9. Standby Power Consumption

10. Conducted EMI Measurement

6. Performance of Eval uation Board

6.1. Star tup Performance

Figure 7. Startup Time (AC Input to VCC UVLO

HIGH) = 114ms, 90V

(CH1: V

(200V/div), CH2: V

DS

(10V/div), CH4: I

and Full-Load Condition

AC

(200mA/div), Time: 20ms/div

DS

(2V/div), CH3: VCC

FB

Figure 9. Startup Time (AC Input to V HIGH) = 114ms, 265V (CH1: V

(200V/div), CH2: V

DS

(10V/div), CH4: I

and Full-Load Condition,

AC

(200mA/div), Time: 20ms/div

DS

(2V/div), CH3: VCC

FB

UVLO

CC

Figure 8. Soft-Start, 90V

(CH1: V

(10V/div), CH4: I

(200V/div), CH2: V

DS

(200mA/div), Time: 2ms/div

DS

Figure 10. Soft-Start, 265V

Condition, (CH1: V

CH3: V

(10V/div), CH4: I

CC

(200V/div), CH2: V

DS

2ms/div

and Full-Load Condition

AC

(2V/div), CH3: VCC

FB

and Full-Load

AC

(200mA/div), Time:

DS

(2V/div),

FB

6.2. Normal Operation

Figure 11. Full-Load Condition, 90VAC, (CH1: V

(200V/div), CH2: V

CH4: I

DS

(2V/div), CH3: VCC (10V/div),

FB

(500mA/div), Time: 10µs/div

Figure 13. No-Load Condition, 90VAC, (CH1: V

(200V/div), CH2: V

CH4: I

DS

(2V/div), CH3: VCC (10V/div),

FB

(200mA/div), Time: 10ms/div

DS

Figure 12. Full-Load Condition, 265VAC, (CH1:

V

(200V/div), CH2: V

DS

(10V/div), CH4: I

(500mA/div), Time: 10µs/div

DS

Figure 14. No-Load Condition, 90V (200V/div), CH2: V

CH4: I

FB

(200mA/div), Time: 50µs/div

DS

(2V/div), CH3: VCC

FB

(CH1: V

AC,

(2V/div), CH3: VCC (10V/div),

DS

Figure 15. No-Load Condition, 265V

(200V/div), CH2: V

CH4: I

DS

(2V/div), CH3: VCC (10V/div),

FB

(200mA/div), Time: 10ms/div

AC,

(CH1: V

DS

Figure 16. No-Load Condition, 265V

(200V/div), CH2: V

CH4: I

DS

(2V/div), CH3: VCC (10V/div),

FB

(200mA/div), Time: 50µs/div

(CH1: V

AC,

DS

6.3. Voltage Stress of Secondary Diode and Drain

Figure 17. V

Diode with 265V

(10V/div), CH4: I

V

DIODE

Figure 19. V

Voltage with 265V

CH2: V

DIODE.MAX

at Startup=35.8V, 5V Output

& Full-Load Condition, CH2:

AC

(200mA/div), Time:

DS

2ms/div

at Startup = 540V, Drain

DS.MAX

(200V/div), CH4 :IDS (200mA/div),

DS

& Full-Load Condition,

AC

Time: 2ms/div

Figure 18. V

DIODE.MAX

Output Diode with 265V

CH2: V

(10V/div), CH4: IDS (200mA/div), Time:

DIODE

at Normal = 35.7V, 5V

& Full-Load Condition,

AC

5µs/div

Figure 20. V

Voltage with 265V

CH2: V

(200V/div), CH4 :IDS (200mA/div),

DS

Time: 2ms/div & 5µs/div

at Normal = 514V, Drain

DS.MAX

& Full-Load Condition,

AC

6.4. Output Ripple and Noise

V

Maximum output ripple is measured at maximum output power in Burst Mode.

Figure 21. Recommended Test Setup

Figure 22.

and Full-Load Condition, CH2: VO (20mV/div),

= 7.4mV, Output with 90V

O_RIPPLE

Time: 5µs/div

AC

Figure 23.

O_RIPPLE

= 7.8mV, Output with 265V

and Full-Load Condition, CH2: VO (20mV/div),

Time: 5µs/div

Figure 24.

and No-Load Condition, CH2: VO (20mV/div),

= 24.2mV, Output with 90V

O_RIPPLE

Time: 10ms/div

AC

Figure 25.

O_RIPPLE

= 26.6mV, Output with 265V

and No-Load Condition, CH2: VO (20mV/div),

Time: 10ms/div

AC

Figure 26.

V

Ripple at 90V

O_RIPPLE

= 47.8mV, Maximum Output , CH2: VO (20mV/div),

AC

Time: 1ms/div

6.5. Short Protections

Figure 27.

Ripple at 265V

O_RIPPLE

= 64.8mV, Maximum Output

, CH2: VO (20mV/div),

AC

Time: 1ms/div

Figure 28. OLP Triggered: VFB = 5.10V, Output Short with 90VAC and Full-Load, CH1: VDS (200V/div),

CH2: V

(2V/div), CH3: VCC (10V/div), CH4: IDS (500mA/div), Time: 100ms/div and 10ms/div

FB

Figure 29. OLP Triggered: VFB = 5.08V, Output Short with 265VACand Full-Load, CH1: VDS (200V/div), CH2:

(2V/div), CH3: VCC (10V/div), CH4: IDS (500mA/div), Time: 100ms/div and 10ms/div

V

FB

Figure 30. OLP Triggered: VFB = 5.10V, Opto-CouplerSecond Short (Open-Loop Test), with 90VACand Full-

Load, CH1: V

(200V/div), CH2: VFB (2V/div), CH3: VCC (10V/div), CH4: IDS (500mA/div), Time: 500ms/div

DS

and 20ms/div

Figure 31. OVP Triggered: VCC = 24.1V, Opto-Coupler Second Short (Open-Loop Test), with 265VACand

Full-Load, CH1: V

(200V/div), CH2: VFB (2V/div), CH3: VCC (10V/div), CH4: IDS (500mA/div), Time:

DS

500ms/div and 20ms/div

6.6. Brown-In and Brownout Protection

V

Figure 1. Brown-In 65

Condition, CH1: V

(2V/div), CH3: V

(200mA/div), Time: 200ms/div

CC

and Full-Load

AC

(50V/div), CH2: VFB

IN

(10V/div), CH4: IDS

Condition, CH1: V

CH3: V

6.7. Temperature Measurement

Figure 2. Brown-out 58VAC and Full-Load

(50V/div), CH2: VFB (2V/div),

(10V/div), CH4: IDS (200mA/div), Time:

CC

IN

200ms/div

Table 2. Temperature Test Result

Input Voltage 90VAC 110VAC 230VAC 265VAC

Temperature

DIODE

Transformer

Room Temperature

IC

44.0°C 43.3°C 44.6°C 46.2°C

56.8°C 56.8°C 57.7°C 58.2°C

49.7°C 49.8°C 51.6°C 52.6°C

24.4°C 24.4°C 24.4°C 24.4°C

6.8. Output Regulation and Efficiency



Test condition: with bias winding



Test method:

- Test after 15 minutes aging

- Test in order: from high line input to low line input

- Test in order: from heavy load to light load

Figure 3. Efficiency vs Output Load and Input Voltage

Table 3. Efficiency Test Result

90VAC 110VAC 230VAC 265VAC

5.023V 1.000A 5.023V 1.000A 5.022V 1.000A 5.022V 1.000A

5.00W

3.75W

2.50W

1.25W

Average

6.887W 6.765W 6.801W 6.908W

72.93% 74.25% 73.84% 72.70%

5.026V 0.750A 5.025V 0.750A 5.024V 0.750A 5.024V 0.750A

5.119W 5.075W 5.209W 5.273W

73.64% 74.26% 72.34% 71.46%

5.027V 0.500A 5.027V 0.500A 5.026V 0.500A 5.026V 0.500A

3.402W 3.416W 3.566W 3.676W

73.88% 73.58% 70.47% 68.36%

5.028V 0.250A 5.028V 0.250A 5.028V 0.250A 5.028V 0.250A

1.754W 1.745W 1.822W 1.855W

71.66% 72.03% 68.99%T 67.76%

73.03% 73.53% 71.41% 70.07%



Test condition: Without bias winding (removing R12)



Test method:

- Test after 15 minutes aging

- Test in order: from high line input to low line input

- Test in order: from heavy load to light load

Figure 4. Efficiency vs Output Load and Input Voltage

Table 4. Efficiency Test Result

90VAC 110VAC 230VAC 265VAC

5.023V 1.000A 5.023V 1.000A 5.023V 1.000A 5.023V 1.000A

5.00W

3.75W

2.50W

1.25W

Average

7.001W 6.901W 7.074W 7.213W

71.75% 72.79% 71.01% 69.64%

5.025V 0.750A 5.025V 0.750A 5.024V 0.750A 5.024V 0.750A

5.216W 5.186W 5.396W 5.489W

72.25% 72.67% 69.83% 68.65%

5.026V 0.500A 5.026V 0.500A 5.025V 0.500A 5.025V 0.500A

3.488W 3.522W 3.788W 3.909W

72.05% 71.35% 66.33% 64.27%

5.028V 0.250A 5.028V 0.250A 5.028V 0.250A 5.028V 0.250A

1.817W 1.826W 1.962W 2.002W

69.18% 68.84% 64.07% 62.79%

71.31% 71.41% 67.81% 66.34%

6.9. Standby Power Consumption

Table 5. With Bias Winding Condition

90VAC 110VAC 230VAC 265VAC

No Load

10mA 20mA 50mA 70mA

100mA

12mW 13mW

94mW 94mW

172mW 169mW

386mW 384mW

520mW 523mW

729mW 729mW

Table 6. Without Bias Winding Condition

90VAC 110VAC 230VAC 265VAC

No Load

10mA 20mA 50mA 70mA

100mA

46mW 56mW

128mW 135mW

207mW 215mW

428mW 436mW

566mW 576mW

775mW 787mW

19mW 102mW 182mW 409mW 552mW 772mW

114mW 202mW 283mW 513mW 664mW 881mW

24mW

107mW

191mW

420mW

569mW

786mW

134mW

224mW

306mW

540mW

687mW

908mW

Figure 5. Standby Power at 230VAC

Figure 6. No-Load Condition Standby Power

6.10. EMI Measurement

V

N

V

N

dBµV dBµV

1 PK

MAXH

2 A

MAXH

Date: 11.NOV.2010 15:28:09

100

90

80

70

EN55022Q

60

1

EN55022A

50

40

30

20

10

0

150 kHz 30 MHz

RBW 9 kHz

MT 1 ms

1 MHz 10 MHz

Figure 7. L1 at 230V

PREAMP OFFAtt 10 dB

AC

Marker 1 [T1 ]

55.22 dBµV

150.000000000 kHz

TDF

PR

6DB

dBµV dBµV

1 PK

MAXH

2 A

MAXH

100

90

80

70

EN55022Q

60

EN55022A

50

40

1

30

20

10

0

150 kHz 30 MHz

Date: 11.NOV.2010 15:26:29

RBW 9 kHz

MT 20 ms

PREAMP OFFAtt 10 dB

Marker 1 [T1 ]

31.66 dBµV

150.000000000 kHz

1 MHz 10 MHz

Figure 8. N at 230V

AC

TDF

PR

6DB

V

dBµV dBµV

1 PK

MAXH

2 A

MAXH

100

90

80

70

EN55022Q

60

EN55022A

50

40

1

30

20

10

0

150 kHz 30 MHz

Date: 11.NOV.2010 15:33:27

dBµV dBµV

1 PK

MAXH

2 A

MAXH

100

90

80

70

EN55022Q

60

EN55022A

50

40

1

30

RBW 9 kHz

MT 1 ms

PREAMP OFFAtt 10 dB

Marker 1 [T1 ]

32.81 dBµV

150.000000000 kHz

1 MHz 10 MHz

Figure 9. L1 at 110VAC

RBW 9 kHz

MT 1 ms

1 MHz 10 MHz

PREAMP OFFAtt 10 dB

Marker 1 [T1 ]

33.22 dBµ

150.000000000 kHz

TDF

PRN

6DB

TDF

PRN

6DB

20

10

0

150 kHz 30 MHz

Date: 11.NOV.2010 15:30:40

Figure 10. N at 110VAC

7. Schematic

Figure 11. Schematic

8. Transformer Specification

Customer - P/N: TRN-0299

DATE

08/12/2010 Version A Page 1/4

1.DIMENSION

1. Pin3.6.7.removed

2. wire shield: 2UEW 0.15*1, pin 1

3. Add 14mm insulation tape *4 turns to fix core and bobbin.

UNIT m/m DRAWN CHECK TITLE TRANS

TEL (02)29450588 Ci wun Chen Guo long Huang

FAX (02)29447647

No.26-1, Lane 128, Sec. 2,

Singnan Rd., Jhonghe City, Taipei

County 235, Taiwan (R.O.C.)

Customer - P/N: TRN-0299

SEN HUEI INDUSTRIAL CO.,LTD.

IDENT

N O.

D W G

N O.

TRN-0299

DATE 08/12/2010 Version A Page 2/4

2. Schematic:

1. When W3 is winding, it must winds one layers.

2. W4 layer wire size can be smaller if there is no area for 20 turns.

3. if there is extra area when W4 is winding, please fill the area with barrier tape.

NO

TERMINAL

WIRE TS

INSULATION BARRIER

S F TS Pri S

W1 2 1

W2 1 -

W3 8 10

W4 5 4

CORE ROUNDING TAPE

2UEW 0.2*1

2UEW 0.15*1

TEX-E 0.55*1

2UEW 0.25*1

140 2

45 3

9 3

20 3

3

2mm

UNIT m/m DRAWN CHECK TITLE TRANS

TEL (02)29450588 Ci wun Chen Guo long Huang

FAX (02)29447647

No.26-1, Lane 128, Sec. 2,

Singnan Rd., Jhonghe City, Taipei

County 235, Taiwan (R.O.C.)

SEN HUEI INDUSTRIAL CO.,LTD.

IDENT

N O.

D W G

N O.

Customer - P/N: TRN-0299

TRN-0299

DATE 08/12/2010 Version A Page 3/4

3.1 inductance test: at 67KHz ,1V

P(2-1): 1.4mH ±7%

3.2 Hi-pot test:

AC 3.0KV / 60Hz / 5mA hi-pot for one minute between pri to sec. AC 1.5KV / 60Hz / 5mA hi-pot for one minute between pri to core. AC 1.5KV / 60Hz / 5mA hi-pot for one minute between sec to core.

3.3 insulation test:

The insulation resistance is between pri to sec and windings to core measured by DC 500V, must be over 100MΩ.

3.4 Terminal strength:

1.0Kg on terminals for 30 seconds, test the breakdown.

3. Electrical Specification

UNIT m/m DRAWN CHECK TITLE TRANS

TEL (02)29450588 Ci wun Chen Guo long Huang

FAX (02)29447647

No.26-1, Lane 128, Sec. 2,

Singnan Rd., Jhonghe City, Taipei

County 235, Taiwan (R.O.C.)

SEN HUEI INDUSTRIAL CO.,LTD.

IDENT

N O.

D W G

N O.

TRN-0299

Customer P/N: TRN-0299

DATE 08/12/2010 Version A Page 4/4

4. Materials List

COMPONENT MAT’L MANUFACTURE FILE NO.

1.Bobbin

2.Core

3.Wire

4.Varnish

5.Tape

t=0.064mm

6.Tube

7.Terminals

Phenolic

94V-0,T373J,150°C

PC-40,BH2,2E6

3C85,NC-2H,

UEWE 130°C ℃

UEW-2

130°C

UEW-B

130°C

TEX-E

105°C / 120°C

BC-346A 180°C John C Dolph Co Ltd. E51047 (M)

468-2FC 130°C Ripley resin engineering co inc. E81777 (N)

31CT 130°C Nitto denk CORP. E34833 (M)

Polyester 3M

#1350(b) 130°C

Teflon tube

TFL 150V,200°C

Tin coated-

Copper wire

TDK,Tokin.Tomita.Philip.Nicera.

Tai-I electric wire ＆cable Co Ltd.

Minnesota mining ＆MFG Co Ltd.

EE-16.(TF-1613)

Chang Chun plastics co. ltd.

Ferrite core EE-16

Jung Shing wire Co Ltd. E174837

Chuen Yih wire Co Ltd. E154709(S)

Furukawa electric Co Ltd. E206440

CTI material groupⅡ

Great holding industrial Co Ltd. E156256 (S)

Will for special wire CORP.

E59481(S)

E85640 (S)

E17385 (N)

8.Shield Copper foil Hitachi cable lid. (copper foil: 0.025t x7mm)

UNIT m/m DRAWN CHECK TITLE TRANS

TEL (02)29450588 Ci wun Chen Guo long Huang

FAX (02)29447647

No.26-1, Lane 128, Sec. 2,

Singnan Rd., Jhonghe City, Taipei

County 235, Taiwan (R.O.C.)

SEN HUEI INDUSTRIAL CO.,LTD.

IDENT

N O.

D W G

N O.

TRN-0299

I1613

9. Bill of Materials

Component Qty. Part No. Manufacturer Reference

Chip Resistor 0805 0Ω ±5% 1 R12

Chip Resistor 0805 47Ω ±5% 2 R20, R21

Chip Resistor 0805 510Ω ±5% 1 R25

Chip Resistor 0805 20KΩ ±1% 2 R31, R32

Chip Resistor 0805 453KΩ ±1% 1 R18

Chip Resistor 1206 3K3Ω ±5% 1 R28

Chip Resistor 1206 30KΩ ±1% 1 R30

Chip Resistor 1206 120KΩ ±1% 2 R11, R11A

Chip Resistor 1206 10MΩ ±1% 2 R1, R3

Ceramic Capacitor 472P 1KV +80/-20% 1 C19

0805 MLCC X7R ±10% 102P 100V 1 C21

0805 MLCC X7R ±10% 104P 50V 2 C2, C14

0805 MLCC X7R ±10% 223P 50V 1 C3

1206 MLCC X7R ±10% 104P 50V 1 C24

Electrolytic Capacitor 10µH 400V 105°C 2 KM SAMXON C1, C1A

Electrolytic Capacitor 22µH 50V 105°C 1 LHK JACKCON C20

Electrolytic Capacitor 680µH 10V 105°C 2 GF SAMXON C22, C25

Y1 Capacitor 102P 250V ±20% 1 C23

Inductor DR6X8 5µH 1 TRN0216 SEN HUEI L4

Fixed Inductor 2.2μH ±10% 1 EC36-2R2K SYNTON L1

Fixed Inductor 330μH ±10% 1 EC36-331K SYNTON L2

Transformer EE-16-H 1.4mH 1 TRN0299 SEN HUEI TX1

Diode 1A/1000V DO-41 1 1N4007 TAPING D11

Fast Diode 1A/1000V DO-41 1 FR107 CP D12

Diode DO-210AD 5A/40V 1 SB540 D2

SMD Bridge 0.5A/600V SOIC-4 1 MB6S Fairchild Semiconductor BD1

REGULATOR KA431L ±0.5% 1 Fairchild Semiconductor U6

IC FOD817B SMDIP-B 1 Fairchild Semiconductor U3

IC SMPS Power Switch 1 FSL206MRN Fairchild Semiconductor U1

FUSE GLASS 250V2A Fast Blow 1 3.6*10mm SLEEK F1

Varistor 7ψ470V 1 VZ1

PCB PLM0049 REV1 1

10. Revision History

Rev. Date Description

1.0.0 Change User Guide EVB number from FEB428_001 to FEBFSL206MRN_H428v1

1.0.1 3/6/12 Formatting & Editing pass by Tech Docs prior to posting

WARNING AND DISCLAIMER

Replace components on the Evaluation Board only with those parts shown on the parts list (or Bill of Materials) in the Users’ Guide. Contact an authorized Fairchild representative with any questions.

This board is intended to be used by certified professionals, in a lab environment, following proper safety procedures. Use at your own risk. The Evaluation board (or kit) is for demonstration purposes only and neither the Board nor this User’s Guide constitute a sales contract or create any kind of warranty, whether express or implied, as to the applications or products involved. Fairchild warrantees that its products meet Fairchild’s published specifications, but does not guarantee that its products work in any specific application. Fairchild reserves the right to make changes without notice to any products described herein to improve reliability, function, or design. Either the applicable sales contract signed by Fairchild and Buyer or, if no contract exists, Fairchild’s standard Terms and Conditions on the back of Fairchild invoices, govern the terms of sale of the products described herein.

DISCLAIMER

FAIRCHILD SEMICONDUCTOR RESERVES THE RIGHT TO MAKE CHANGES WITHOUT FURTHER NOTICE TO ANY PRODUCTS HEREIN TO IMPROVE RELIABILITY, FUNCTION, OR DESIGN. FAIRCHILD DOES NOT ASSUME ANY LIABILITY ARISING OUT OF THE APPLICATION OR USE OF ANY PRODUCT OR CIRCUIT DESCRIBED HEREIN; NEITHER DOES IT CONVEY ANY LICENSE UNDER ITS PATENT RIGHTS, NOR THE RIGHTS OF OTHERS.

LIFE SUPPORT POLICY

FAIRCHILD’S PRODUCTS ARE NOT AUTHORIZED FOR USE AS CRITICAL COMPONENTS IN LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE EXPRESS WRITTEN APPROVAL OF THE PRESIDENT OF FAIRCHILD SEMICONDUCTOR CORPORATION.

As used herein:1.

Life support devices or systems are devices or systems which, (a)

are intended for surgical implant into the body, or (b) support or sustain life, or (c) whose failure to perform when properly used in accordance with instructions for use provided in the labeling, can be reasonably expected to result in significant injury to the user.

2. A critical component is any component of a life support device or system whose failure to perform can be reasonably expected to cause the failure of the life support device or system, or to affect its safety or effectiveness.

ANTI-COUNTERFEITING POLICY

Fairchild Semiconductor Corporation's Anti-Counterfeiting Policy. Fairchild's Anti-Counterfeiting Policy is also stated on our external website, www.fairchildsemi.com, under Sales Support.

Counterfeiting of semiconductor parts is a growing problem in the industry. All manufacturers of semiconductor products are experiencing counterfeiting of their parts. Customers who inadvertently purchase counterfeit parts experience many problems such as loss of brand reputation, substandard performance, failed applications, and increased cost of production and manufacturing delays. Fairchild is taking strong measures to protect ourselves and our customers from the proliferation of counterfeit parts. Fairchild strongly encourages customers to purchase Fairchild parts either directly from Fairchild or from Authorized Fairchild Distributors who are listed by country on our web page cited above. Products customers buy either from Fairchild directly or from Authorized Fairchild Distributors are genuine parts, have full traceability, meet Fairchild's quality standards for handling and storage and provide access to Fairchild's full range of up-to-date technical and product information. Fairchild and our Authorized Distributors will stand behind all warranties and will appropriately address any warranty issues that may arise. Fairchild will not provide any warranty coverage or other assistance for parts bought from Unauthorized Sources. Fairchild is committed to combat this global problem and encourage our customers to do their part in stopping this practice by buying direct or from authorized distributors.

EXPORT COMPLIANCE STATEMENT

These commodities, technology, or software were exported from the United States in accordance with the Export Administration Regulations for the ultimate destination listed on the commercial invoice. Diversion contrary to U.S. law is prohibited.

U.S. origin products and products made with U.S. origin technology are subject to U.S Re-export laws. In the event of re-export, the user will be responsible to ensure the appropriate U.S. export regulations are followed.

Fairchild FEBFSL206MRN_H428v1, FSL206MRN User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
