BAT42XV2-BAT43XV2
Schottky Barrier Diodes
Features
• Low Forward Voltage Drop
• Flat Lead, Surface Mount Device at 0.60mm Height
• Extremely Small Outline Plastic Package SOD523F
• Moisture Level Sensitivity 1
• Pb-free Version and RoHS Compliant
• Matte Tin (Sn) Lead Finish
• Green Mold Compound
Cathode
ELECTRICAL SYMBOL
BAT42XV2 Marking : 6B
BAT43XV2 Marking : 7B
Anode
Band Indicates Cathode
BAT42XV2-BAT43XV2 — Schottky Barrier Diodes
January 2010
SOD-523F
Absolute Maximum Ratings * T
=25°C unless otherwise noted
A
Symbol Parameter Value Units
V
RRM
V
R
I
F(AV)
I
FSM
T
J
T
STG
* These ratings are limiting values above which the serviceability of any semiconductor device may be impaired.
Thermal Characteristics T
Maximum Repetitive Reverse Voltage 30 V
Maximum DC Blocking Voltage 30 V
Average Rectified Forward Current 200 mA
Peak Forward Surge Current 4 A
Operating Junction Temperature +125 °C
Storage Temperature Range -65 to +125 °C
=25°C unless otherwise noted
A
Symbol Parameter Value Units
P
D
R
θJA
* Device mounted on FR-4 PCB minimum land pad.
Electrical Characteristics T
Power Dissipation 200 mW
Thermal Resistance, Junction to Ambient 500 °C/W
=25°C unless otherwise noted
A
Symbol Parameter Test Condition Min. Typ. Max. Units
BV
T
Breakdown Voltage IR=100μA
R
I
Reverse Leakage Current VR=25V
R
V
Forward Voltage BAT42XV2
F
BAT43XV2
BAT42XV2, BAT43XV2
Reverse Recovery Time IF=IR=10mA
RR
=10mA
I
F
=50mA
I
F
=2mA
I
F
=15mA
I
F
=200mA
I
F
=100Ω
R
L
=1mA
I
RR
C Capacitance VR=1V, f=1MHz 7 pF
© 2009 Fairchild Semiconductor Corporation www.fairchildsemi.com
BAT42XV2-BAT43XV2 Rev. A1 1
30 V
500 nA
0.40
0.65
0.26
0.33
0.45
1.0
5nS
V
Typical Performance Characteristics
Reverse Current vs Reverse Voltage
6
10
5
10
4
10
[nA]
R
3
10
2
10
1
10
Reverse Current, I
0
10
-1
10
0 5 10 15 20 25 30 35 40
125 oC
Reverse Voltage, VR [V]
75 oC
25 oC
BAT42XV2-BAT43XV2 — Schottky Barrier Diodes
-25 oC
Forward Voltage vs Forward Current
1000
100
[mA]
F
10
1
Forward Current, I
0.1
0 100 200 300 400 500 600 700 800
125 oC
75 oC
Forward Voltage, VF [mV]
25 oC
-25 oC
© 2009 Fairchild Semiconductor Corporation www.fairchildsemi.com
BAT42XV2-BAT43XV2 Rev. A1 2
Typical Performance Characteristics (Continued)
Total Capacitance
20
15
[pF]
T
10
5
Capacitance, C
0
0 5 10 15 20 25 30 35 40
Reverse Voltage, VR [V]
BAT42XV2-BAT43XV2 — Schottky Barrier Diodes
TA=25oC
f=1MHz
Power Derating Curve
250
200
[mW]
D
150
100
50
Power Dissipation, P
0
0 255075100125150
Temperature, TA[oC]
© 2009 Fairchild Semiconductor Corporation www.fairchildsemi.com
BAT42XV2-BAT43XV2 Rev. A1 3
Physical Dimension
BAT42XV2-BAT43XV2 — Schottky Barrier Diodes
SOD-523F
© 2009 Fairchild Semiconductor Corporation www.fairchildsemi.com
BAT42XV2-BAT43XV2 Rev. A1 4
