Factory Direct Hardware T13H252 User Manual
See current price list for product availability.
000
Engineer/Architect Approval
Model Specified:
Approval: Date:
PRODUCT VARIATION
SHOWER
HANDLE
222
111
333
555
777
999
444
666
888
✔✔✔
MultiChoice™Universal
Pressure Balance Tub and Shower
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue models, both without notice or obligation.
Dimensions are for reference only. See current full-line price book or www.specselect.com for finish options and product availability.
DSP– T13H1 Rev. C
TUB AND SHOWER DESCRIPTION PRODUCT NO.
ROUGH-IN Valve R10000-UNWS
FINISH TRIM only T13H
Specify ''0''
When No Shower
Outlet Required
Shower Valve Only
Standard Brass Fixed
Spray Showerhead
Arm & Flange
2.2 USGPM (8.4 L/min.)
Tub and Shower
3-Function TouchClean Showerhead,
Arm & Flange
2.5 USGPM (9.5 L/min.)
Showerhead
Arm & Flange
1.5 USGPM (5.7 L/min.)
57mm (2.24'')
Lever Blade
Handle
85mm (3.33'')
Metal Lever
Handle
Handshower, 610mm (24'')
S/S Grab Bar with ADA
Slide 1.5 USGPM
(5.7 L/min.) (1)
30° Vandal Resistant
Cast Wallmount
Showerhead
1.5 USGPM (5.7 L/min.)
Specification: (example)
❏ R10000-UNWS ROUGH-IN only
• Concealed in-wall MultiChoice™universal valve
• Back-to-back capability, Integral screwdriver stops
• Heavy Duty forged brass valve body
• 1/2" Universal inlets to accept 1/2" copper,
1/2" iron pipe, PEX or CPVC adaptors
• 1/2" Male thread inlets/outlets
❏ FINISH TRIM ONLY:
• Pressure Balancing cartridge with checks
• Polished chrome plated finish
• Non-removeable red/blue temperature markings
and … with … (add product variation)
with … (add shower)
with … (add valve handle)
T13H153
T13H162
Set screw shower arm flange supplied on Shower Option No. 1, 2, 3 and 8. (1) Two check valves in handshower. Flowrates are at 80 PSI.
Refer to www.specselect.com for individual models. See Page DSP-SHWA Rev. C for Add-On options available.
See Page DSP-B-R10000-HDF for additional Rough-In options.
Note: Use this page front and back as a product submittal sheet.
H
2
Okinetic Technology
®
Showerhead, Arm &
Flange, 1.5 USGPM
(5.7 L/min.)
TECK
®
COMMERCIAL
MultiChoice™Universal
Pressure Balance Tub and Shower
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue models, both without notice or obligation.
Dimensions are for reference only. See current full-line price book or www.specselect.com for finish options and product availability.
DSP-T13H1 Rev. C
Refer to www.specselect.com for individual models. Note: Use this page front and back as a product submittal sheet.
Approvals:
•
CSA certified
•
Complies to ASME A112.18.1
•
Pressure Balance Handle ADA Compliant
and meet Handicapped Accessibility
Standard ASME A117.1 of less
than 5 lbs. operating force.
• Pressure Balance Valve ASSE 1016
•
Handshower back flow
protection provided by
two integral certified check valves in series,
which operate independently,
ASME A112.18.3
and ASME A112.18.1 / CSA B125.1.
•
IAPMO listed
(Contact Delta Representative for State and/or
Local Approvals.)
FLOWRATE vs PRESSURE
P/B VALVE INLETS:
1/2'' Universal inlets accept 1/2" copper,
1/2" iron pipe, PEX or CPVC adaptors
1/2" Male thread inlets/outlets
Note: Measurements may vary ± 6mm (0.25'')
Shower Outlet Flowrates
Tub Filler Flowrates
FRONT VIEW SIDE VIEW
R10000-UNWS Rough-In
with
T13H132 Trim
FLOWRATE vs PRESSURE
g)
TECK
®
COMMERCIAL
117 mm
(4.6")
910 mm
(36.0")
OPTIONAL
910 mm
(36.0")
OPTIONAL
TO FLOOR
178 mm
(7.0")
51 mm
(2.0")
METAL LEVER
HANDLE
STOPS
HOT COLD
INLETS
CLVALVE
BODY
70 mm
(2.75")
152 mm
(6.0")
FLOW
(l /min.)
13
12
11
10
9
8
7
6
5
4
3
2
1
0
10 20 30 40 50 60 70 80
Line Pressure (psig)
Shower Outlets
No. 1 (060890A)
No. 3, 5 & 6 (061048A, 061049A, 061011A)
No. 8 (RP46384)
No. 2 (RP43381)
FLOW
(USGPM)
3.5
3
2.5
2
1.5
1
.5
00
FLOW
(l/min.)
29.5
28
26.5
25
23.5
22
20.5
19
17.5
16
14.5
13
20 30 40 50 60 70 80
Line Pressure (psi
FLOW
(USGPM)
8
7.5
7
6.5
6
5.5
5
4.5
4
3.5
311.5
