SCRT600
SCRT600
ROMAN TUB FAUCET
Product Features
4.0 GPM @ 20 PSI minimum flow rate
Brass body
Ceramic cartridge
Metal Lever handle
Standards/Approvals
SCRT600 meets or exceeds:
IAPMO/UPC (AB1953)
Massachusetts
PRODUCT SPECIFICATION:
Roman Tub faucet shall have a brass body, ceramic cartridge,metal lever handles.
Product shall be able to be installed 8” to 15” centers applications. Product shall be
schön brass works model SCRT600
1
Page 2
SCRT600
ROMAN TUB FAUCET
Other Specifications
Faucet Hole diameter 1-1/2”
Spout height 11 11-16”
Spout reach 8”
Aerator clearance 6 11//16”
Available Finishes
Chrome
Satin Nickel
2
Page 3
SCRT600
ROMAN TUB FAUCET
PARTS LISTING
No Part Number Part Name Q'ty
1 A66D422xx Handle Cap 2
2 A004046N O-Ring (Φ1/4" ID * Φ3/8" OD) 2
3 A008041 Screw (3/16" -24 * 7/16" L) 2
4 A069899xx Metal Handle 2
5 A018073xx Handle Base 2
6 A126108 Fixing Set 2
7-a A507376N Ceramic Disc Cartridge-Cold 2
7-b A507375N Ceramic Disc Cartridge-Hot 2
8 A66D423 Handle Trim Ring 2
9 A072032N O-Ring (Φ1-5/8" ID * Φ1-13/16" OD) 2
10 A663951 Mounting Hardware Assembly 2
11-a A002544C Handle Valve Body-Cold 1
11-b A002544H Handle Valve Body-Hot 1
12 A139720xx Spout 1
13 A66D448xx Lift Rod 1
14 A008191 Screw (M4 * 5 mm L) 1
15 A071342xx Spout Trim Ring 1
16 A66D449 Adaptor Assembly 1
17 A072048N
18 A004107
19 A66D450
20 A072069
21 S2211195xx
22 A604627xx
23 A134036xx Shower Hose (72") 1
24 A105137 Supply Hose 1
25 A031003 Hex Wrench(H2 * 17 mm L * 49 mm L) 1
O-Ring (Φ1-1/16" ID * Φ1-1/4" OD)
O-Ring (Φ1-9/16" ID * Φ1-11/16'' OD)
Mounting Hardware
O-Ring (Φ1/8" ID * Φ1/4" OD)
Hand Shower W/Check Valve
Spray Holder Assembly (3-3/4''L)
1
1
1
1
1
1
XX designates finish matched parts
