Installation Instructions / Warranty

Tub Spout 06500001

Tub Spout with Diverter 06501000

Commercial Tub Spout 06500001
Commercial Tub Spout with Diverter 06501000

Product Specification

Inlet size - 1/2” female

06500000

06501000

Installation Considerations

The 06500 and 06501 tub spouts require a 1/2” male threaded pipe nipple, extending 4” - 4 1/4”
outside the surface of the finished wall.

IMPORTANT: Please read the installation instructions for the shower valve before
installing the 06501000 tub spout with diverter. Some shower valves cannot be used
in combination with diverter tub spouts.

Installation

Seal the wall around the nipple with a good quality
waterproof bathroom sealant.

Wrap the threads on the nipple with several layers
of TeflonTM thread tape.

Screw the tub spout to the nipple. Tighten with a
strap wrench to prevent damage to the finish.
