Fab Glass Triangle Floating Glass Shelf

Installation Manual

www.fabglassandmirror.com Call: [phone] Fax: [phone]

Office Timing: 8:30 - 18:00 EST [e-mail]

Drill/Driver Level Tape Measure Screw Driver Hammer Lead Pencil

Tools Needed

Hardware Included With This Order

Bracket
(Qty - 2)

Anchor

(Qty - 4/6)

Screw

(Qty - 4/6)

CAUTION

Congratulations on the purchase of your new Triangle floating glass shelf! We’ve made
it very easy to install. Follow all instructions carefully.

Be careful when using a knife or box cutter to open the packaging. Please read every
step in the instructions before you begin installation. You are responsible for
assembling, installing and taking care of your Shelf according to the instructions.
Users who fail to heed the instructions run the risk of injury, so please be careful and
work with caution.

1

2

3

4

www.fabglassandmirror.com

+ 1 888-474-2221

Fragile Handle with care

FAB GLASS

AND MIRROR

Suppose 14”

7”

Mirror

Mark the height

you want to install Glass

7” 7”

1

Page

Remove your Triangle
corner shelf from the
packaging.

Mark with a pencil on
the wall where you want
to install the shelf. You
can use a tape measure
for precision.

Use a level and make
two marks with a pencil
at points one-half of the
length of the shelf, such
as 7 inches from the
corner on each side of
the wall.

Measure the shelf so you
can check how long one
half of it is. For example,
with a 14-inch long shelf,
one half is 7 inches.

5

6

7

8

7”

7”

7”

7”

7”

2

Page

Line the upper part of
one bracket on the wall
at the point you marked
with pencil. Make a mark
for the bracket’s hole.

Drill a hole at this spot
with an automatic drill.

Insert the anchor into
the hole and press it in
with a hammer.

Check the line
with a level.

9

10

11

12

3

Page

Congratulations!

You have finished installing your

new Triangle corner shelf.

With a screwdriver,
tighten a screw into the
lower part of the bracket
to secure it to the wall.

Repeat this process for
the other bracket.

Insert the shelf where
the gaps appear in the
brackets.

Carefully tighten the
screws.

Hold the top of the
bracket at the wall.

Screw a screw through
the bracket hole into
the anchor, tightening
with a drill.
