Opti-V Stove
Model: PGP10
Gebruiksaanwijzing / Installatievoorschrift
NL DE FR
The product complies with the European Safety Standards EN60065 and the European Standard Electromagnetic Compatibility (EMC)
EN55014-1 & EN55014-2, EN6100-3-2 and EN6100-3-3 These cover the essential requirements of EEC Directives 2006/95/EC and 2004/108/EC
Patents pending Application No. : GB 1509765.2
UK
NO
08/52878/0 Issue 1
1
705
580
420
360
420
2
3
4
NL..........................................1
DE..........................................2
FR..........................................3
UK..........................................4
NO..........................................5
NL
BELANGRIJK: LEES DEZE GEBRUIKSAANWIJZING AANDACHTIG DOOR EN BEWAAR DEZE VOOR NASLAGDOE-
LEINDEN
1
WICHTIG: DIESE ANLEITUNG IST SORGFÄLTIG ZU STUDIEREN UND ZUR SPÄTEREN VERWENDUNG
AUFZUBEWAHREN
DE
2
FR
IMPORTANT : CES INSTRUCTIONS DOIVENT ÊTRE LUES ATTENTIVEMENT ET CONSERVÉES AFIN DE POUVOIR ÊTRE
CONSULTÉES ULTÉRIEUREMENT
3
Opti-V Stove : PGP 10
IMPORTANT: THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE
UK
Contents of Carton
• Opti-V Stove Model PGP10
• Remote control
• 4 x feet and xing screws
• power cable
Important Safety Advice
When using electrical appliances, basic precautions should
be followed to reduce the risk of re, electric shock, and
injury to persons, including the following:
If the appliance is damaged, check immediately with the
supplier before installation and operation.
Do not use this appliance in the immediate surroundings of
a bath, shower or swimming pool.
Means for disconnection must be incorporated in the xed
wiring in accordance with the wiring regulations.
Do not use outdoors.
In the event of a fault disconnect the appliance from mains
supply.
Switch off the appliance when not required for long periods.
If the supply cord is damaged, it must be replaced by a
special cord or assembly available from the manufacturer
or its service agent.
Warning - No naked ame sources, such as candles, should
be placed on this apparatus.
Warning - The appliance shall not be exposed to dripping
or splashing and that no objects lled with liquid, such as
vases, shall be placed on the apparatus.
Warning - this appliance is of Class I construction and must
be connected to a mains outlet with protective earthing
connection.
Electrical
WARNING – THIS APPLIANCE MUST BE EARTHED
Do not switch the appliance on until properly installed. Please
read all the safety warnings and operating instructions.
on’ button ( ).
To turn the effect off, press the shadow ‘light off’ button( ).
For battery replacment refer to the embossed diagram on the
back of the remote control.
NOTE - Use Lithium batteries only - CR2025
Attention should be drawn to the environmental aspects of
battery disposal.
Manual Control Operation: -
The manual controls are located at the back(top) of the
appliance.(see Fig. 4).
Maintenance
WARNING – ALWAYS DISCONNECT FROM THE POWER
SUPPLY BEFORE ATTEMPTING ANY MAINTENANCE.
Techical Information:
100-240V ~ 50/60Hz
Power consumption 28W
Stand-by Power 1W
Cleaning
For general cleaning use a soft clean duster – never use
abrasive cleaners.
Warranty and Service
For service and warranty of the product log onto the website
http://www.gdbservice.com/
select Faber and select ‘Electric’. Select model Opti-V Stove
PGP10. The series number of the product can be found on
the label on the under side of the product. Please retain your
receipt as proof of purchase.
Installation
Warning.
Do not connect the appliance until the instruction leaet is
read fully.
The appliance can be used free standing or elevated by tting
4 feet to the base with screws provided - see Fig. 2.
Connect the cable (kettle type connection) to the socket at the
back of the appliance and connect other end to mains supply.
Operation - remote control: -
The appliance by default is in standby mode, indicated by a
red light at the front of the appliance.
To activate the remote control, remove the battery isolating
strip, which is used to ensure the remote is fully charged before
use - see Fig.3.
To operate, aim the remote control to the front of the appliance.
Press the standby button ( ) on the remote control (see Fig. 3).
The fuelbed will light up and after approximately 7 seconds
the ame will appear.
Note: The user may notice a blank screen for approximately
3 seconds, every 30 minutes. This is normal and should not
be a cause for concern.
The audio volume may be adjusted up or down by pressing
the volume control buttons ( + and -).
To create the shadow effect on oor, press the shadow ‘light
Recycling
For electrical products sold within the European Community.
At the end of the electrical products useful life it
should not be disposed of with household waste.
Please recycle where facilities exist. Check with
your Local Authority or retailer for recycling advice
in your country.
4
5
This appliance complies with the CE directives.
Saturnus 8 NL-8448 CC Heerenveen
Postbus 219 NL-8440 AE Heerenveen
T. + 31(0)513 656500
F. + 31(0)513 656501
