FAAC RK65K User Manual

Radio Key® RK-65K

RK-65KS

with RK100M instructions

PROXIMITY ACCESS CONTROL SYSTEM

Phone: [phone] • Fax: [phone]

*U.S. Patent #6317027

STAND ALONE

®

with DYNASCAN

A Division of Soundcraft, Inc.

Website: www.securakey.com

E-mail: [e-mail]

TECHNOLOGY*

Operating Guide

20301 Nordhoff Street
Chatsworth, CA 91311

3321732

Rev. C

COPYRIGHT © 2007

V060107 6451

SOUNDCRAFT, INC.

Radio Key® RK-65K/RK-65KS

Operating Guide

Introduction .........................................................................1

Ordering Transponders ......................................................3

Programming Radio Key® RK-65K/RK-65KS ..................4

Programming Radio Key
Handheld Programmer (RK-HHP) &

Programming Deck (RK-PD1) ......................................6

Programming Steps ..........................................................7

Programming Hints ..........................................................13

Basic Operation ...............................................................19

Converting to RK100M Mode ...........................................21

Warranty ...........................................................................28

Specifi cations ...................................................................29

Certifi cations .....................................................................31

Figure 1, Radio Key® RK-65K & RK-65KS Units ................2

Figure 2, Programming Deck & Hand-Held Programmer ...2

Table of Contents

®

RK100M .................................5

Illustrations

i

Radio Key® RK-65 K Operating Gu ide

INTRODUCTION

The Radio Key

®

RK-65K is a programmable single-door access
control system which controls access for up to 65,000 users. It
can control an electric strike, magnetic lock, or gate operator,
and has an additional programmable input which may be set
as a remote open input or as an LED/Beeper control for use
with the Wiegand output. A Wiegand output is also provided to
allow for later upgrading to an on line system. Information on
using the RK-65K as a Wiegand reader is contained on page 18
The major components are shown in Figures 1 and 2.

The Radio Key® RK-65K Access Control Unit contains the CPU,
memory, access relay, and an internal reader. It has a beeper, and
a bi-color LED indicator. An RK-HHP Handheld Programmer or an
RK-PD1 Program Deck (not included), is used to add or delete tran­sponders, to set the operating mode, to program the password and
latch timer. The Radio Key® RK-65K is compatible with the Secura
Key SecuRelay™, an intelligent relay module used to eliminate the
possibility of break-in by attacking the access control unit.

The current version of this product also replaces the RK100M.
The RK100M reads randomly encoded tags and supports only
100 users. To convert this unit to RK100M mode, follow the
instructions on Page 21.

Secura Key  1

Radio Key® RK-65 K Operating Gu ide

Figure 1 - Radio Key® RK-65K & RK-65KS Units

NOTE: All references to RK-65K also apply to the RK-65KS.

Figure 2 - Programming Deck (RK-PD1)

& Hand-Held Programmer (RK-HHP)

NOTE: Programming sequences are the same

using RK-PD1 or RK-HHP

Secura Key  2

Radio Key® RK-65 K Operating Gu ide

ORDERING TRANSPONDERS

The Radio Key

®

RK-65K works with Secura Key RKCM-02
molded (clamshell) cards, RKCI-02 ISO-standard cards and
RKKT-02 key ring tags. Card Format 303 and Format 201
can be used.

When you order Format 303 transponders for a new project you
will be assigned a new Facility Code and your transponders will
begin with ID number 1. As you need additional cards or tags
you can order the same Facility Code, specifying the starting
number, which will be one digit higher than your highest existing
transponder.

If you use Format 201, these are shipped from stock and you
may receive cards or tags with a different Facility Code than you
originally programmed into the reader. The RK-65K can learn
up to 10 different Facility Codes. If it becomes necessary to mix
transponders with more than one Facility Code in the same reader,
be sure that the transponder ID numbers are not duplicated.

NOTE: RKxx-01 cards or keytags will not work for the

RK65K. The LED will flash amber to let you
know it is the wrong type of card.

Secura Key  3

Radio Key® RK-65 K Operating Gu ide

PROGRAMMING RADIO KEY

®

RK-65K

When the RK-65K is fi rst powered up, the LED will be fl ashing
Red and Green. Present a card to the unit to set the Facility
Code and the fl ashing will end in approximately 10 seconds.

Radio Key Transponders (Key tags and cards) are pre-encoded
and engraved at the factory with a Facility (Site) Code and an
individual card ID number.

You must teach the RK-65K which Facility Code or Codes
(up to 10) it should recognize. You must also enroll the card
ID numbers that will be Valid. The Radio Key

®

cards and tags
are sequentially numbered, so you can validate a block of
transponders.

Be sure to make a record of each person who is issued a
transponder along with the ID number of their card or tag.

Secura Key  4

Radio Key® RK-65 K Operating Gu ide

®

PROGRAMMING RADIO KEY

100M

Radio Key® Transponders (Key Tags and Cards) are pre-en­coded and engraved at the factory with unique Transponder ID
numbers. Because these numbers are unique, Facility Codes
(Site Codes) are not required.

Transponder ID Numbers are not pre-programmed into the Radio

®

100M; you must add them to the system as described below.

Key

Radio Key® 100M allows you to assign a Transponder to each
User ID Number (1 - 100) for programming purposes. The
User ID Number is associated with the individual person using
the transponder.

Be sure to record the User ID Number, the Transponder
ID Number and the user’s name, and keep this informa­tion in a secure place. A blank User Log Form has been

included for this purpose. Do not write on this form; use it as
a photocopy master.

Because a new Transponder ID Number can be assigned to
any available User ID Number, the reader always has capac­ity to store 100 Transponders, even after many Transponders
have been voided from the reader.

Secura Key  5

Radio Key® RK-65 K Operating Gu ide

THE RK-HHP HANDHELD PROGRAMMER AND THE
RK-PD1 PROGRAM DECK

Note: The RK-PD1 or the RK-HHP is required to program

the reader. One RK-PD1 or RK-HHP may be used on
several readers.

The RK-PD1 consists of the 16 following cards:

ENTER “7” SEVEN

“0” ZERO “8” EIGHT

“1” ONE “9” NINE

“2” TWO “ ” THRU

“3” THREE “ ” VALID

“4” FOUR

“5” FIVE SET TIMER

“6” SIX MODE
Presenting these cards to the Radio Key® RK-65K is equivalent
to pressing the identically marked keys on the RK-HHP hand­held programmer. As you present program cards to the unit, it
will chirp to indicate that it has read the card. The next sections
of this manual explain the program card sequences used to
perform the various program functions.

Secura Key  6

“ ”

VOID

®

Radio Key

RK-65 K Operating Gu ide

PROGRAMMING STEPS

To program the Radio Key® RK-65K, you must fi rst enter the
program mode as described in the next section below. Once in
the program mode, the LED will blink amber as an indicator. To
take the unit out of program mode you may select an operating
mode (see page 14) or simp ly allo w 15 sec onds to e lapse without
presenting a program card to the reader.

After you have completed a proper program sequence, the
unit will beep and the LED will fl ash green to indicate that the
program instruction has been accepted. A red light and a beep
at the end of a programming sequence means that you have
made an error. Refer to the appropriate section, and carefully
re-enter the command in the proper sequence.

NOTE: User ID Number and ID Number Values in

the following examples are for demonstration
purposes only; enter the appropriate values for
your system.

Secura Key  7

®

Radio Key

RK-65 K Operating Gu ide

To Enter Program Mode (RK65K/RK100M):

Using your programmer, enter your password and then press
“ENTER”. (All new units are pre-programmed with the password

12345.) The LED will fl ash amber to show that the unit is in
Program Mode. The unit will “time out” and return to Active
(Normal) Mode in 15 seconds if no programming follows.

1 + 2 + 3 + 4 + 5 +

(Password)

(ENTER)

NOTE: If fi ve incorrect passwords are entered, the unit will
sound an alarm and display a red LED for 30 seconds, then
return to normal mode.

Change your Password (RK65K/RK100M):

Put the unit into the Program mode, if necessary (See above).
Press THRU. Then enter the sequence of digits representing
the desired new password (exactly 5 digits). Then press THRU
again. Repeat the new password. Press ENTER. A green light
and beep means that the Password was changed. Note that
12345 is the default (factory) password; use another number
sequence for best security.

Secura Key  8

Radio Key® RK-65 K Operating Gu ide

(THRU)

(New Password - 54321)

+ 5 + 4 + 3 + 2 + 1 +

+ 5 + 4 + 3 + 2 + 1 +

(THRU)

(Re-type New Password - 54321)

(ENTER)

Lost or forgotten Password (RK65K/RK100M)

If the password is lost or forgotten, it can be restored to the
factory default (12345). Remove the Radio Key

®

RK-65K
unit from the wall and disconnect power. With the Data 1 line
(white wire) temporarily connected to the Remote open line
(brown wire), restore power. The factory default (12345) is
now in effect. The LED will fl ash alternately Red and Green.
While this is occurring, set the Facility Code or Codes in the
reader (see below). Remove power and reconnect the unit for
operation, restore power and remount the unit. This procedure
will NOT delete any transponders from reader’s memory.

Setting Facility Code(s) (RK65K)

Before any cards are added to the RK-65K you must set the
Facility Code or Codes. When a new reader is fi rst powered
up the LED should be fl ashing alternately Red and Green. This
indicates that the unit is in the “Learn Facility Code” mode.

Secura Key  9

Radio Key® RK-65 K Operating Gu ide

You can also place a reader in this mode by entering the
Program Mode (see page 8) then pressing Mode followed by
“9” followed by Enter.

+ 9 +

(MODE)

(Mode Number 9)

(ENTER)

While the LED is fl ashing Red/Green present one User
Card for each Facility Code being used to the reader, one
at a time. After you are fi nished, allow the reader to time
out and return to the Normal Mode before proceeding.

NOTE: An invalid facility code will beep with no LED visible.

ADDING AND DELETING USERS (RK65K)

Add A Transponder (Key Tag or Card) To The System:

Place the unit in the Program Mode (See Page 8). Press Add,
followed by the sequence of digits representing the Transponder
ID number. Then press Enter. For example, to add transponder
#12 to the reader the following sequence would be followed:

+ 1 + 2 +

(ADD)

(User ID Number 12)

(ENTER)

Transponder number 12 is now valid.

Secura Key  10

Radio Key® RK-65 K Operating Gu ide

Add A Series Of Transponders To The System (RK65K):

Place the unit into the Program mode (see Page 8). Press Add,
followed by the sequence of digits representing the lowest
transponder ID number. Then press Thru, followed by the
sequence of digits representing the highest transponder ID
number. Then press Enter. For example, to add transponders
#1 through #10 to the system:

+ 1 + + 1 + 0 +

(ADD)

(Starting

User No. 1)

(THRU)

(Ending User ID

Number 10)

(ENTER)

Transponder number 1 through 10 are now valid.

Delete A Transponder From The System (RK65K):

Place the unit in the Program Mode (see Page 8). Press Void,
followed by the sequence of digits representing the transponder
ID number. Then press Enter. For example, to delete transponder
#12, the following sequence would be presented:

+ 1 + 2 +

(User ID Number 12) (ENTER)(VOID)

Transponder #12 is now void.

Secura Key  11

Radio Key® RK-65 K Operating Gu ide

Delete A Series Of Transponders From The System (RK65K):

Place the unit in the Program Mode (see Page 8). Press Void,
followed by the sequence of digits representing the lowest
transponder ID. Then press Thru followed by the sequence of
digits representing the highest number transponder. Finally, press
Enter. For example, to delete transponders #1 through #10:

+ 1 + + 1 + 0 +

(VOID)

(Starting

User No. 1)

(THRU)

(Ending User ID

Number 10)

(ENTER)

Transponders #1 through #10 are now void.

Set the Latch Timer (RK65K/RK100M):

Put the unit into the Program mode, (See Page 8). Press SET
TIMER, then press the sequence of digits represe nting the desired
Latch Time (0 - 65535 seconds) to the unit. Press ENTER. A
green light and beep means that the Latch Timer setting was
changed. (If you set the Latch Timer for “0” seconds, the actual
latch time will be approximately 0.25 seconds.) For example,
to set the latch timer to 15 seconds, the following sequence
would be followed;

+ 1 + 5 +

(SET TIMER)

(15 Seconds)

(ENTER)

Secura Key  12

Radio Key® RK-65 K Operating Gu ide

For longer latch times it may be easier to set the timer with hour:
minute notation. Press SET TIMER; then press the sequence of
digits representing the number of hours (2 digits); then press the
sequence of digits representing the number of minutes; then press
THRU; then ENTER. (The maximum relay time is 18 hours and
00 minutes.) For example, to set the latch timer for 2 hours and
45 minutes the following sequence would be followed:

(THRU)

(ENTER)

+ 0 + 2 + 4 + 5 + +

(SET TIMER)

(2 Hours, 45 Minutes)

If you have set an extended latch time, but need to interrupt it,
follow this procedure. Put the unit in Program Mode (see Page 8).
Then press Set Timer then “1” then Enter. After the Program
Mode expires, present a valid card to the reader. After one
second the relay will return to it’s normal state. You will then
have to reprogram the latch timer to the desired duration.

PROGRAMMING HINTS:
Setting the Latch Timer (RK65K/RK100M):

The latch timer controls the latch relay. The factory preset latch time
is 1 second but it can be changed to any value from .25 seconds
to 18 hours. If the latch timer is set to 0 seconds, this pulses the
latch relay for 0.25 second, suffi cient for most electric turnstiles.
The beeper and LED are always fi xed at one second.

Secura Key  13

Radio Key® RK-65 K Operating Gu ide

Set the Operating Mode (RK65K/RK100M):

The Radio Key

®

RK-65K may be put into any of four operational
modes. The Modes are as follows;
“1” - Active (Normal) -- LED is Off
“2” - Inactive (Locked) -- LED blinks Red
“3” - Door Unlocked -- LED blinks Green
“4” - Toggle Mode – LED is Off

In mode 1, a valid tag or closure of the remote open input will
activate the relay for the time the latch timer is set.

Mode 2 deactivates the unit. No tag can activate the relay, but
the remote open input will activate the relay.

In mode 3, the door is kept unlocked (the relay is kept latched).

In mode 4, when a valid tag is presented or the remote open
input is activated, the relay changes its state from deactivated
to activated or from activated to deactivated. The relay will stay
in this state until another valid tag is presented or the remote
input is activated and so forth.

Secura Key  14

Radio Key® RK-65 K Operating Gu ide

To set the Operating Mode, put the unit into the Program mode,
(See Page 8). Pres s MODE, then pre ss eithe r “1” , “ 2”, “3”, or “4”.
Press ENTER. The Access Control Unit will exit Programming
Mode and enter the selected Mode. For example, to set the
unit to the inactive (locked) mode, the following sequence
would be followed;

+ 2 +

(Mode Number 2)(MODE)

(ENTER)

To Exit Programming Mode Immediately (RK65K/RK100M):

Press MODE, then “1” (or 2, 3, or 4) card to the unit. Press
ENTER. This returns the unit to the selected mode immediately,
bypassing the 15 second timeout.

+ 1 +

(Mode Number 1)

(MODE)

(ENTER)

Timed Antipassback(RK65K)

Timed antipassback is used to discourage card sharing. After
one successful card use, the unit will treat that card as Void
for a preset number of minutes. When timed antipassback is
enabled, it will apply to all valid cards.

Secura Key  15

Radio Key® RK-65 K Operating Gu ide

Enable Timed Antipassback (RK65K):

Place the unit in the Program Mode (see Page 8). Press SET
TIMER, then press ADD, fi nally press ENTER.

+ +

(SET TIMER)

(ADD)

(ENTER)

Set Antipassback Timer (RK65K):

Place the unit in the Program Mode (see Page 8). Press SET
TIMER then press THRU. Press the digits representing the
maximum number of minutes you want antipassback to apply
(01 – 99). Press ENTER. (Antipassback can be from one to
ninety-nine minutes. Depending upon the clock cycle of the
unit when a card is read, the actual antipassback time may be
as little as one-half the time selected.)

+ + 1 + 5 +

(SET TIMER)

(THRU)

(ENTER)

Disable Timed Antipassback (RK65K):

Place the unit in the Program Mode (see Page 8). Press SET
TIMER then VOID, fi nally press ENTER.

+ +

(SET TIMER)

(VOID)

(ENTER)

Secura Key  16

Radio Key® RK-65 K Operating Gu ide

Confi gure the Relay (RK65K/RK100M)

The relay is set at the factory to be normally open and to close
upon presentation of a valid transponder or upon activation of
the remote open (Request to Exit) input. It may be changed to
normally closed or to SecuRelay™ operation. A normally open
relay is used for a “fail-secure” electric lock or door strike and
to trigger a gate operator. A normally closed relay is used for
“fail-safe” devices such as magnetic locks. The Secura Key
SecuRelay™ (sold separately) is a remote intelligent relay
used to prevent entry when the access control unit is physically
attacked. (NOTE: When placed in the SecuRelay™ mode the
“Remote Open” input is disabled.) To confi gure the relay, put
the unit in the Program mode (See Page 8). Press THRU two
times. Then press either the “6”, “7” or “8”. Press ENTER.

Selections are:

6. Normally Open (Factory default)

7. Normally Closed

8. SecuRelay™ Option.
For example, to configure the relay normally closed, the

following sequence would be followed:

+ + 7 +

(THRU)

(ENTER)(THRU)

Secura Key  17

Radio Key® RK-65 K Operating Gu ide

Using the RK-65K as a Wiegand Output Reader

The RK-65K can be connected to a multidoor access control
system (such as the Secura Key SK-ACP) using the Wiegand
output. When any Radio Key® transponder is presented to the
unit, whether or not it has been programmed into the unit, the
appropriate transponder ID will be sent out via the white and
green wires.

Program the Input (RK65K/RK100M)

The input is set at the factory as a Remote Open input.
Connecting the brown and the orange wire (usually with a push
button switch) will activate the relay for the time set for the latch
timer. This input may also be confi gured as an LED control or
as an LED/beeper control. When confi gured as an LED control,
grounding the brown wire will turn on the Red LED, grounding
the orange wire will turn on the Green LED and grounding the
yellow wire will turn on the beeper.

To confi gure the input, put the unit into the Program mode,
(See Page 8). Press THRU TWICE. Then press either the “1”
or “2” button. Press ENTER. Selections are:

“1” - Remote Open (Factory default).
“2” - LED Control.

Secura Key  18

(RK65K/RK100M)

Radio Key® RK-65 K Operating Gu ide

For example, to program the input for LED control, the following
sequence would be followed:

+ + 2 +

(THRU)

(Input No. 2)

(ENTER)(THRU)

BASIC OPERATION (RK65K/RK100M)

®

To use a Key Tag with Radio Key

RK-65K, simply hold your
Radio Key® Transponder near the Radio Key® RK-65K Unit.
The Radio Key® RK-65K Unit generates an RF fi eld, which
causes the Key Tag to transmit a unique Transponder ID
Number back to the Unit.

If the Transponder ID Number is stored in memory, the latch
relay is activated, unlocking the controlled door or gate . A
green light and a beep indicates that access is granted. If the
Transponder ID Number is not stored in memory, the door or
gate remains locked and a red light and beep indicate that
access is denied. Otherwise the LED is normally off.

Secura Key  19

Radio Key® RK-65 K Operating Gu ide

Remote Open (Request to Exit) Input (RK65K/RK100M)

When the Remote open input is activated, the relay will
activate. When the remote open input is deactivated, the relay

will return to the inactive state after the latch timer times out. A
green light and a beep indicates that access is granted.

NOTE: Remote Open Input is disabled when the unit is
confi gured for use with SecuRelay™.

Secura Key  20

Radio Key® RK-65K Ope rating Guide

CONVERTING TO RK100M MODE

The RK100M has been replaced by the new RK-65K. The

RK100M was designed to read randomly numbered cards and
tags without facility codes (RKCM-01, RKKT-01). The RK100M
unit is only able to enroll up to 100 users. If you need to replace
an existing RK100M, or if you want a reader that uses random
cards and tags, you may convert this product to the RK100M
mode, as shown below.

In the RK100M mode, some programming steps differ from the
RK-65K. The following section also describes those different
program steps.

Converting between RK-65K and RK100M modes:

Place the unit in the Program Mode (see Page 8). Pr ess MODE,
followed by “5” (for RK65K mode) or “6” (for RK100M mode).
Press ENTER. (RK-65K mode is the default.)

+ 5 + (For RK65K mode)

(Mode Number 5)

(MODE)

(ENTER)

+ 6 + (For RK100M mode)

(Mode Number 6)

(MODE)

(ENTER)

Secura Key  21

®

Radio Key

RK-65K Ope rating Guide

ADDING AND DELETING USERS: RADIO KEY® 100M

Radio Key® Transponders (Key Tags and Cards) are pre­encoded and engraved at the factory with unique Transponder
ID numbers. Because these numbers are unique, Facility
Codes (Site Codes) are not required. The steps for adding
and deleting users is different from the RK-65K. Follow the
directions on the following pages.

Transponder ID Numbers are not pre-programmed into the Radio

®

100M; you must add them to the system as described below.

Key

Radio Key® 100M

allows you to assign a Transponder to each User ID
Number (1 - 100) for programming purposes. The User ID Number
is associated with the individual person using the transponder.

Be sure to record the User ID Number, the Transponder ID
Number and the user’s name, and keep this information in a
secure place. A blank User Log Form has been included for
this convenience.

Because a new Transponder ID Number can be assigned to any
available User ID Number, the reader always has capacity to
store 100 Transponders, even after many Transponders have
been voided from the reader.

Secura Key  22

®

Radio Key

RK-65 K Operating Gu ide

Add a Transponder (Key Tag or Card) to the System:

Put the unit into the Program mode (See Page 8). Press
ADD, then press the sequence of digits representing the
desired User ID Number (1-100), then press ENTER. Hold the
Transponder near the Unit. A green light and beep means that
the Transponder was accepted. For example, to program a
transponder into User ID Number 12, the following sequence
would be followed;

+ 1 + 2 + (Hold Key Tag or
Card near unit)

(ADD)

(User ID Number 12)

(ENTER)

Record the User ID Number and Transponder ID Number.

NOTE: If you assign a new transponder to a User ID Number where
another transponder was already assigned, the new transponder
will replace the old transponder for that User ID Number.

NOTE: Adding the Same Transponder More Than Once

If you add the same Transponder to the system more than
once, the Transponder ID will be deleted from the previous
User ID Number position and added to the newest User ID
Number position.

Secura Key  23

®

Radio Key

RK-65K Ope rating Guide

Add a Transponder by Entering the Transponder ID:

Instead of presenting the transponder, you can also use the
Programmer to enter the Transponder ID number: Put the
unit into the Program mode (See Page 8). Press ADD then
press the sequence of digits representing the desired User ID
Number (1 - 100). Press THRU. Press the sequence of digits
representing the ID number printed on the Transponder, then
press ENTER. For example, to program a Transponder ID
Number 995 into User ID Number 12, the following sequence
would be followed;

+ 1 + 2 + + 9 + 9 + 5 +

(ADD)

(User ID Number 12)

(ID Number 995)(THRU)

(ENTER)

Record the User ID Number and Transponder ID Number in
the User Log Form.

NOTE: If you assign a new transponder to a User ID Number where
another transponder was already assigned, the new transponder
will replace the old transponder for that User ID Number.

Add a Series of Transponders to the System:

Put the unit into the Program mode (See Page 8). Press ADD,
then press the sequence of digits representing the desired

Secura Key  24

Radio Key® RK- 65K Operating Guide

starting User ID Number to the unit. Press THRU. Then press the
sequence of digits representing the desired ending User ID Number.
Press THRU, then press ENTER. Present the Transponders to
the reader in the desired order (making a careful record of which
transponders are assigned to which User ID Numbers). If one or
more Transponders are already entered into the User ID Number
range you have selected, they will be overwritten. For example,
to program ten transponders into User ID Numbers 1 through 10,
the following sequence would be presented;

+ 1 + + 1 + 0 + +

(ADD)

(Starting

User No. 1)

(THRU)

(Ending User ID

Number 10)

(THRU)

(ENTER)

then present the ten transponders to the unit one at a time.

Delete a Transponder from the System:

Put the unit into the Program mode (See Page 8). Press VOID,
then press the sequence of digits representing the desired User
ID Number (1 - 100). Then press ENTER. A green light and
beep means that the Transponder was deleted. For example,
to delete the transponder for User ID Numbers 12, the following
sequence would be executed;

+ 1 + 2 +

(VOID)

(User ID Number 12)

(ENTER)

Secura Key  25

®

Radio Key

RK-65K Operating Guide

Delete a Range of Transponders from System:

Put the unit into the Program mode (See Page 8). Press VOID,
then press the sequence of digits representing the desired
starting User ID Number. Press THRU, then press the sequence
of digits representing the desired ending User ID Number.
Finally, press ENTER. A green light and beep mean that the
range of Transponders was deleted.

+ 1 + + 1 + 0 +

(VOID)

(Starting User

No. 1)

(THRU)

(Ending User ID

Number 10)

(ENTER)

Delete a Transponder by Presenting to Reader:

Put the unit into the Program mode (See Page 8). Press VOID,
then press ENTER. Hold the Transponder near the Radio Key
100M Unit. A green light and beep means that the Transponder
was deleted.

+ (Hold Key Tag near Unit)

(VOID) (ENTER)

Secura Key  26

®

®

Radio Key

RK-65K Operating Guide

Delete a Transponder by Entering Transponder ID:

Put the unit into the Program mode (See Page 8). Press VOID.
Press THRU, then press the sequence of digits representing
the ID number printed on the Transponder. Finally, press
ENTER. A green light and beep means that the transponder
was deleted. For example, to delete Transponder ID Number
995, the following sequence would be followed;

+ + 9 + 9 + 5 +

(VOID)

(THRU)

(ID Number 995)

(ENTER)

Secura Key  27

®

Radio Key

RK-65K Ope rating Guide

WARRANTY (U.S. and Canadian)

“This product is warranted against defects in materials
and workmanship for life. Secura Key shall, at its option,
either replace or repair this product, if returned to us freight
prepaid within the warranty period. This warranty does
not include freight, taxes, duties, or installation expenses
THE WARRANTY SET FORTH ABOVE IS EXCLUSIVE
AND NO OTHER WARRANTY, WHETHER WRITTEN
OR ORAL, IS EXPRESSED OR IMPLIED. SECURA KEY
SPECIFICALLY DISCLAIMS ANY IMPLIED WARRANTIES
OR MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. The remedies provided herein are the buyers’ sole
and exclusive remedies. In no event shall Secura Key be liable
for direct, indirect, special, incidental or consequential damages
(including loss of profi ts), whether based on contract, tort or
any other legal theory.” Contact Secura Key for Card/Tag and
Export Warranty Policies.

Secura Key  28

®

Radio Key

RK-65 K Operating Gu ide

SPECIFICATIONS

Models RK-65K RK-65KS

Physical

Depth 0.60” (1.52 cm) 0.84” (2.13 cm)
Width 1.60” (4.06 cm) 3.20” (8.12 cm)
Height 3.50” (8.89 cm) 4.50 (11.43 cm)
Weight 2.88 oz. (81.65 gm) 6.67 oz. (189.15 gm)
Material ABS Lexan

®

Color Black Beige

Power Requirements 5-14 VDC, 90 mA Max., 40 mA Idle

Wiegand Output Any Wiegand Format up to 40 bits

Maximum Distance: 500 Ft.- 5 or 6 conductor 20 gauge
shielded cable

Outputs

SPST Solid State Relay, 1A max. @60 VAC or DC.
Normally open or normally closed (fi eld programmable).
May also be used with SecuRelayTM intelligent relay
module (sold separately).

Inputs
Programmable as Remote Open (requires contact closure);
Bicolor (Red or Green) LED Control or Buzzer/LED Control

Secura Key  29

Radio Key® RK-65K Ope rating Guide

Environment

Ambient Temperature -40° to +70° C (-40° to +158° F)
Humidity 0% to 100% (non-condensing)

Operational

Reading Distance
Molded Card: Up to 6” (15.24 cm)
Key tag & ISO Card: Up to 5” (12.70 cm)
User Capacity
RK-65K: 65,000 key tags or cards (26 or 32 bit),
10 Facility Codes

RK-100M mode: 100 tags/cards (random numbered only)

Card/Key Tag Operation Passive
Transmit Frequency 125 kHz
Memory Non-Volatile
Latch Timer P rogrammable

0.25 sec. to 18 hours or Toggle Mode

Accessories

RK-HHP Hand-held Programmer
RK-PD1 Proximity Programming Deck
RK600-PS 9VDC, 200 mA, plug-in Power Supply,
120 VAC Input. For Access Unit Only.
SK-SR SecuRelay

TM

- Smart relay module, DPDT.

This product complies with UL 294 Standards, with Part 15,
Class B FCC Rules and (European Standards).

Secura Key  30

Radio Key® RK-65K Ope rating Guide

FCC ID: NNHRK-100M

INSTRUCTION TO THE USER

This equipment has been tested and found to comply with the limits for a class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more or the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet of a circuit different from
that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.
This equipment has been certifi ed to comply with the limits for a class B
computing device, pursuant to FCC Rules. In order to maintain compliance
with FCC regulations, shielded cables must be used with this equipment.
Operation with non-approved equipment or unshielded cables is likely to
result in interference to radio and TV reception. The user is cautioned that
changes and modifi cations made to the equipment without the approval of
the manufacturer could void the user’s authority to operate this equipment.

Secura Key  31

A Division of Soundcraft, Inc.

20301 Nordhoff Street

Phone: [phone] • Fax: [phone]

Chatsworth, CA 91311

TOLL FREE [phone]
Website: www.securakey.com
E-mail: [e-mail]
