Ezze Mobile Tech VI1 User Manual

VI-1 User Manual

(Version 1.0)

1

CONTENTS

1. General Information

1. 1 Introduction

1. 2 For your safety

1. 3 Battery Use

1. 4 Charger Use

2 Getting started

2. 1 What is in the box

2. 2 Phone feature

2. 3 SIM card

2. 4 Operation

2. 5 Key function

3. Overview of menu

3. 1 Phonebook

3. 2 Message Center

3. 3 Call History

3. 4 Music

3. 5 Camera

3. 6 FM Radio

3. 7 Organizer

3. 8 Services

3. 9 Entertainment

3. 10 Settings

3. 11 Bluetooth

3. 12 File Manager

2

ea

ous o

ega

1. General Information

1. 1 Introduction

Thank you for purchasing the Mass1 GSM. Please read all
information carefully before getting stared to install and use the
Mobile. This would help you to make good use of this mobile and
fully understand the functions of mobile and be easy to operate.
Mass1 GSM is aimed to design for GSM/GPRS network. Mass1
GSM complies with GSM/GPRS Technique regulations and it is
certified by internal and external authorities.

For your safely, read the guidelines carefully.
Br

king the rules may be danger

1. 2 For your safety

Don’t use a hand-held phone while driving.

Stop and park your vehicle safely before using your phone.

Switch off in aircraft

Wireless devices can cause interference in aircraft. The use of
mobile telephones in an aircraft is illegal. Please switch off your
mobile before taking off the plane and please ensure the alarm
clock should be closed when the mobile is turned off.

Switch off near blasting

To avoid interference in the process of blasting, don’t use the
phone where you may read the sign of “Blasting Spot” or “Turn off
your wireless”. Observe restrictions and follow any regulations or
rules.

r ill

l.

3

Switch off near dangerous stuff.

Don’t use the phone at a refueling point. Don’t use near fuels or
chemicals.

Switch the phone off in hospitals.

Switch the phone off near medical equipment. There may be a
hazard associated with the operation of phones close to
inadequately protected personal medical devices such as hearing
aids and pace makers. Don’t put your phone on pacemakers which
means not to put it in the pocket of clothes.

Use your phone promptly

The antenna is straight over your shoulder when you are talking to
the phone. Don’t touch the antenna if not necessary.

Emergency calls

Ensure the phone is switched on and in service. Enter the
emergency number

Radio frequency (RF) exposure and SAR

This phone meets European Union (EU) requirements concerning
exposure to radio waves. Your mobile phone is a radio transmitter
and receiver. It is designed and manufactured to not exceed the
limits for exposure to radiofrequency (RF) energy, as
recommended by the EU Council. These limits are part of
comprehensive guidelines and establish permitted levels of RF
energy for the general population. The guidelines were developed
by independent scientific organizations through the periodic and
thorough evaluation of scientific studies. The limits include a
substantial safety margin designed to ensure the safety of all
persons, regardless of age and health. The exposure standard for

4

mobile phones employs a unit of measurement known as Specific
Absorption Rate (SAR).
Specific Absorption Rate (SAR) is the unit of measurement for the
amount of radio frequency energy absorbed by the body when
using a mobile phone. The SAR value is determined at the highest
certified power level in laboratory conditions, but the actual SAR
level of the mobile phone while it is operating can be well below
this value. This is because the mobile phone is designed to use the
minimum power required to reach the network. Variations in SAR
below the radio frequency exposure guidelines do not mean that
there are variations in safety. While there may be differences in
SAR levels among mobile phones, all mobile phone models are
designed to meet radio frequency exposure guidelines. Before a
phone model is available for sale to the public, it must be tested
and certified by the Federal Communications Commission (FCC)
that it does not exceed the limit established by the government­adopted requirement for safe exposure. The tests are performed in
positions and locations (that is, at the ear and worn on the body) as
required by the FCC for each model. For body-worn operation, this
phone has been tested and meets FCC RF exposure guidelines
when the handset is positioned a minimum of 15 mm from the body
without any metal parts in the vicinity of the phone or when used
with the original accessory intended for this phone and worn on the
body. Use of other accessories may not ensure compliance with
FCC RF exposure guidelines.
The SAR limit recommended by the EU Council is 2.0W/kg

The highest SAR value for this model phone is W/kg.
SAR tests are conducted using standard operating positions with

A

5

the phone transmitting at its highest certified power level in all
tested frequency bands.

-----------------------------------------------------------------------------------------

 If you use the phone near the network’s base station, it uses less

 Battery charging time depends on the remaining battery charge,

 If left unused, a fully charged battery will discharge itself over

A. The SAR limit for mobile phones used by the public is

2.0 watts/kilogram (W/kg) averaged over ten grams of
body tissue. The limit incorporates a substantial margin
of safety to give additional protection for the public and
to account for any variations in measurements. The
SAR values may vary, depending on national reporting

1. 3 Battery Use

Use only approved batteries. Use of any unauthorized accessories
could damage you and your phone and may be dangerous. If
jewelry, keys, beaded chains, or other conductive materials touch
exposed battery terminals, this could complete an electrical circuit
(short circuit), become very hot, and could cause damage or injury.
Never use a charger or battery that is damaged.
Use the battery only for its intended purpose.

power. Talk and standby time are greatly affected by the signal
strength on the cellular network and the parameters set by the
network operator.

the type of battery , and the charger used. The battery can be
charged and discharged hundreds of times, but it will gradually
wear out. When the operation time is noticeably shorter than
normal, it is time to buy a new battery.

requirements and the network band.

6

time.

 Use only approved batteries, and recharges your battery only

approved chargers. Disconnect the charger from the power
source when it is not in use. Do not leave the battery connected
to a charger for more than a week, since overcharging may
shorten its life.

 Extreme temperatures will affect the charging capacity of your

battery: it may require cooling or warming first.

 Do not leave the battery in hot or cold places because the

capacity and lifetime of the battery will be reduced. Try to keep
the battery at room temperature. A phone with a hot or cold
battery may not work temporarily, even when the battery is fully
charged.

 Do not short-circuit the battery. Accidental short-circuiting can

occur when a metallic object like a coin, clip or pen causes a
direct connection between the + and – terminals of the battery
(metal strips on the battery). For example, do not carry a spare
battery in a pocket or bag where the battery may contact metal
objects. Short-circuiting the terminals may damage the battery or
the object causing the short-circuiting.

 Dispose of used batteries in accordance with local regulations.

Always recycle. Do not dispose of batteries in a fire.

 The phone could explode if the battery is replaced with an

incorrect type.

 Dispose of used batteries according to the manufacturer’s

instructions.

 At very high volumes, prolonged listening to a headset can

damage your hearing.

7

 To avoid risk of personal injury, do not dispose of your battery in

a fire.

 Do not throw your battery or mobile device in the trash.

2. Getting Started

2. 1 Unpack

Make sure you have each item

• Phone

8

• Battery

• Earphone

• User’s Guide

• Travel Charger

• Service Booklet

• USB Data Cable

• SD Memory Card (Optional)

2.2 Phone feature

KEY DEFINITION

Soft Keys

Perform functions identified by left/right display
prompt.
Right button: Cancel numbers & letters when
you make a call or input letter for phonebook,
message or WAP.

9

S

HORTCUTS

Navigation Keys

Scroll through the menu options.
Move the cursor up and down in the normal
editing mode.
Move the cursor to left and right in all editing
mode.

Send Key

Dial or answer a call.
Recall the last call numbers in the idle mode.

Power on/off Key & End Key
To end a call
Switch the phone on and off. (press this key
and hold)
Cancel your input in the menu facility and
return to the idle mode.

Alphanumeric Keys
You may enter numbers, letters and special
characters.
It changes camera settings in camera mode.

Special Function Keys

Enter Special Characters / Perform Various
Functions

10

Left: Access to “Messages”
Right: Access to “FM Radio”
Up: Access to “Bluetooth”
Down: Access to “Music Player”

from an idle mode
You may dedicate the left navigation key for
favorite menu in ‘Dedicated key’ setting menu

(Menu > 11.Settings > 1.Phone Setup >

5.Dedicated Key)

WAP K ey

Access to WAP menu (press shortly), and
launch WAP browser (press and hold).

To activate the “Keypad Lock”, press this key
and hold.

To activate the “Light Only Mode” option, press
this key and hold.

SIDE KEY

Volume Key (side)

Press up or down key to increase or decrease
the volume.

D

ISPLAY LAYOUT

The idle screen display includes three areas.

Status Indicator Icons

11
