Ezonetronics RM-LC2010 User Manual

Car Mirror Camera

User Manual

Model Number: RM-LC2010

Product Panel description

No.

Icon

Name

Operation instructions

1

Power button

In any mode, Long press to power on / off the unit; short press to on / off the

screen backlight;

2

The menu button

In recording standby / photo mode: press this button to go to setup menu;

In video replaying mode: press this button to go to the delete choice of the file.

3

Mode button

Press this button to switch from video record / photo / video replay mode .

4

Page up / Camera view

switch

Video recording/standby/picture mode: press this key to switch the front/rear

camera view.
Menu mode: press this key to select the up one

5

Turn down / audio

recording control button

Video recording mode: press this button to open/close the audio recording
feature.

Menu mode: press this key to select the down one;

6

OK

Confirm button

Video mode: press this button to start/stop the recording Camera

Photo mode: press this to take a photo

Menu mode: confirm

7

Display

4.3 inch 16:9TFT, high-definition display screen

8

The USB socket

Connect to the cigarette USB cord to supply the unit power

9

Camera video input

Provide rear camera video

10

Reset button

System reset button

11

Microphone

Microphone for audio recording

12

Front camera

Front camera to record the front view

13

TF card slot

TF memory card slot, insert the TF card to save video files, up to 32GB
