Eyeris ERN-R3645N, ERN-R3645P, ERN-R3655P, ERN-R3655N Installation And Operating Instruction Manual
www.eyerisdigital.com
Installation and Operating
Instruction Manual
NIGHVISION OUTDOOR BULLET CAMERA
ERN-R3645N/R3645P
ERN-R3655N/R3655P
Thank you for your purchase of this product.
Before attempting to connect or operate this product, please read these instructions
completely.
Product specifications and its contents subject to change without any prior notice.
The picture is for reference, the object as the standard.
Page 1
CONTENTS
1. General Information
- Safety Precaution
- Package contents
2. Installation of Camera
- Camera Connection
- Installation of Camera
- Tips for Camera Location
- Dimension
3. Technical Specification
4. Troubleshooting
5. Cleaning and Care
6. Maintenance and Support
Page 2
1.General Information
> Safety Precaution
1.Read these instructions carefully before commissioning the camera in order to avoid
damages caused by improper installation or use.
2.Do not abuse the camera. Avoid striking, shaking, etc. The camera could be damaged
by improper handing or storage.
3.Use a dry cloth to clean the camera front glass when dirty. When the dirt is hard to
remove, use a mild detergent and wipe gently. Then wipe off the remaining detergent
with a dry cloth.
4.Do not aim the camera at bright objects. Whether the camera is in use or not, never aim
it at the sun or other extremely bright objects. Otherwise, blooming or smears may be
caused.
5.In case of outdoor use, you have to install the camera in a suitable weather protection
case incl. heating element.
6.Operate the camera with the designated voltage only.
7.Use the camera at temperatures within -10 C to +50 C and humidity below 90%.
> Package Contents
1.
2.Operating Instructions
3.Mounting Template Sticker
Nighvision Outdoor Bullet Camera
Caution
To Reduce the risk of electric shock, do not remove cover. No
user serviceable parts inside. Refer servicing to qualified
service personnel.
Page 3
2.Installation of Camera
> Camera Connections
12V DC Power Supply
Use standard 12V DC output power supply with 2.1mm
standard DC power female pin. Before connect power check
power supply polarity (+ and -).
Video Output Connection
Use standard 75 Male BNC pin terminate with Co-axial video cable then connect to
camera video out BNC Female pin.
> Installation of Camera
Mounting Template Sticker: The mentioned technical drawing is for reference only.
Actual size of Mounting Template Sticker is matched with Dome Base. Stick Mounting
Template Sticker supplied for drilling the mounting hole on the mounting surface.
> Tips for Camera Location
1. Never expose the camera to direct sunlight without additional camera housing. Keep
sufficient distance to direct heat sources.
2. Never install the camera at humid, oily or dusty locations without using an additional
housing. (Without additional housing the camera is not suitable for outdoor use)
3. Do not aim the camera towards indoor lighting, the windows, the sunlight or the sky.
(To get good pictures, camera and light should be aimed towards the object)
4. Avoid peak light as background (Also caused by reflection)
Ω
Page 4
> Dimension
75mm
90mm
120mm
Page 5
3. Technical Specification
Video
ERN-R3645N/P ERN-R3655N/P
Model Number
CCD
1/3" SONY Super HAD II CCD
Lens
6mm M12 Standard lens
Effec Pixel@ERN-R3647N/P
Effec Pixel@ERN-R3655N/P
NTST : 512 x 492, PAL : 500 x 582
NTST : 768 x 494, PAL : 752 x 582
Horizontal Resolution
450 TVL 550 TVL
Min. Illumination@Day
1.0 Lux at Day(Cut Off)
Gamma
Scanning Frequency (V)
Scanning Frequency (H)
0.45
NTSC : 59.94KHz, PAL : 50Hz
NTSC : 15.734KHz, PAL : 15.625KHz
S/N Ratio
More than 48db
Video Output
1V p-p, 75Ω
Sync System
2:1 Internal
Min. Illumination@Night
0 Lux At Night(IR LED On)
Night Vision
IR Distance
IR LED
30 Meter
36 IR LED
IR Wave Length
850nM
ǿ0.5
Diameter
Electrical
Power Supply
12V DC Standard ±10%
Current Consumption
80mA
Operational
AGC
IRIS
Auto
Electronically
BLC
Auto
Auto
AE
Exposure Mode
Day/Night Mode
NTSC : Auto 1/60s-1/100,000s
PAL : Auto 1/50s-1/100,000s
ATW
Shutter Speed
White Balance
IR Consumption
500mA
Page 6
4. Troubleshooting
Error Cause
No Picture Check supply voltage, check power cable and video cable
The picture is noisy Insufficient light (Properly adjusted to the camera)
The picture is too bright Too much peak light, change camera location or active back
light function of the camera
The picture is not sharp Lens focus not adjusted properly
The picture is distorted Different GND potentials between camera and monitor (Bad
connection)
Ghost Image Wrong 75 termination, shield of video cable interrupted.
5. Cleaning and Care
-Before you start to clean the camera body, disconnect the unit from power supply.
-For reasons of electrical safety never clean the camera with water or other liquid
matters and never put the camera under water.
-To clean use a soft dry cloth. Cleaning the camera inside is strictly forbidden and may
only be done by your authorized dealer.
-Since all camera functions are self adjusting and the camera does not contain any
parts or components that are subject to wear. We advice you not to open the camera
(except for the flap for settings), unless the camera appears to be defective.
Environmental
Dimensional
Operating Temperature
-10°C ~ 50°C
95%
Humidity
Weight
Housing
Outdoor Wall Mount with Cable Managed Bracket
Dimension
120(L) x 90(H) x 75(W)
670g
Protection Class
IP 66
Page 7
6. Maintenance and Support
1. How to request after-sale service?
When ever you want to send repairing material back to us kindly use
the same Channel where u purchased the material must with Return Material
Authorization (RMA) Form download from our website.
http://www.eyerisdigital.com/RMA%20Form.pdf
2. Following cases should be paid even within the warranty period.
A)When defects are caused by the careless handling of the user.
B)When improper or unauthorized repairs are done or when the inside is modified or
damaged.
C)Defects caused by natural disaster or power problem.
Technical Support: For any type of product operating, Function, Installation related
queries or want to know more about our product details specification or function,
contact our website or E-mail to us.
http://www.eyerisdigital.com/support.html
www.eyerisdigital.com
Page 8
