Eyeris ERB-L747N, ERB-L747P, ERB-L755N, ERB-L755P Installation And Operating Instruction Manual

Download
www.eyerisdigital.com
Installation and Operating
Instruction Manual
MINI C/CS(BOX) MOUNT CAMERA
ERB-L747N/P ERB-L755N/P
Thank you for your purchase of this product.
completely.
Product specifications and its contents subject to change without any prior notice.
The picture is for reference, the object as the standard.
Page 1
CONTENTS
1. General Information
- Safety Precaution
- Package contents
2. Installation of Camera
- Camera Connection
- Installation of Camera
- Tips for Camera Location
- Dimension
3. Operation Guide
- Menu structure
- Function Description
4. Technical Specification
5. Troubleshooting
6. Cleaning and Care
7. Maintenance and Support
Page 2
1. General Information
> Safety Precaution
1.Read these instructions carefully before commissioning the camera in order to avoid damages caused by improper installation or use.
2.Do not abuse the camera. Avoid striking, shaking, etc. The camera could be damaged by improper handing or storage.
3.Use a dry cloth to clean the camera lens glass when dirty. When the dirt is hard to remove, use a mild detergent and wipe gently. Then wipe off the remaining detergent with a dry cloth.
4.Do not aim the camera at bright objects. Whether the camera is in use or not, never aim it at the sun or other extremely bright objects. Otherwise, blooming or smears may be caused.
5.In case of outdoor use, you have to install the camera in a suitable weather protection case incl. heating element.
6.Operate the camera with the designated voltage only.
7.Use the camera at temperatures within -10 C to +50 C and humidity below 90%.
> Package Contents
1.Mini C/CS(Box) Mount Camera
2.Operating Instructions
3.Mounting Template Sticker
Caution To Reduce the risk of electric shock, do not remove cover. No user serviceable parts inside. Refer servicing to qualified service personnel.
Page 3
2.Installation of Camera
> Camera Connections
12V DC Power Supply
Use standard 12V DC output power supply with 2.1mm standard DC power female pin. Before connect power check power supply polarity (+ and -).
Video Output Connection
Use standard 75 Male BNC pin terminate with Co-axial video cable then connect to camera video out BNC Female pin.
> Installation of Camera
Mounting Template Sticker: The mentioned technical drawing is for reference only. Actual size of Mounting Template Sticker is matched with Dome Base. Stick Mounting Template Sticker supplied for drilling the mounting hole on the mounting surface.
> Tips for Camera Location
1. Never expose the camera to direct sunlight without additional camera housing. Keep sufficient distance to direct heat sources.
2. Never install the camera at humid, oily or dusty locations without using an additional housing. (Without additional housing the camera is not suitable for outdoor use)
3. Do not aim the camera towards indoor lighting, the windows, the sunlight or the sky. (To get good pictures, camera and light should be aimed towards the object)
4. Avoid peak light as background (Also caused by reflection)
Page 4
> Dimension
57MM
40MM
40MM
Page 5
> Menu Structure
E. SHUTTER
BLC
LENS
SETUP MENU
AGC
WHITE BALANCE CONTROL
FUNCTION
ADJUST
LANGUAGE
RESET
EXIT
DC
VIDEO
MANUAL
FLK
AUTO
MANUAL
FIXED
CONTRAST
CB GAIN CR GAIN
SHARPNESS
ATW
FIXED
MANUAL
AWB
OFF
ON
OFF
ON
OFF
ON
CAMERAID
GAMMA
PRIVACY
MOTION
DAY/NIGHT
MIRROR
ENGLISH
JAPANESE
TRADITIONAL CHINES
SIMPLE CHINESE
KOREAN
3. Operation Guide :
Page 6
> Function Description
1.Lens: Three Mode - DC, Manual and video & you can set brightness level from 0 up
to 100.
2.Electronic Shutter : 4 Mode - FLK, Fixed, Manual and Auto. (1/100 or 1/120 @ FLK), (1/50,1/250,1/500, 1/1000, 1/2000, 1/4000, 1/10000, 1/100000 @ Fixed).
3.BLC (Back Light Composition) : On/Off with 64 selectable zones for BLC.
4.AGC (Auto Gain Controller) : On/Off
5.WB (White Balance) : 4 Mode - ATW, AWB, FIXED, MANUAL
In Fixed : Indoor, Outdoor. In Manual : Red, Blue.
6.FUNCTION :
Camera ID : A TO Z, 0 TO 9, & etc. Can set position of ID also.
` Mirror : On/Off
Day Night : 3 Mode - Auto / color / B/W Motion : On/Off with 64 Selectable Zone Privacy : On/Off with 4 Selectable Zone Gamma : Can be adjust within the range of 0.05 to 1.0
7.ADJUST : 4 Mode Contrast : Can be adjust within the range of 0 to 255 Sharpness : Can be adjust within the range of 0 to 30 CB Gain : Can be adjust within the range of 0 to 255 CR Gain : Can be adjust within the range of 0 to 255
Page 7
4. Technical Specification
Video
ERB-L747N/P ERB-L755N/P
Model Number
CCD
1/3" SONY Super HAD II CCD
Lens
C/CS Mount Lens
Effe Pixel@ERB-L755N/P
Effe Pixel@ERB-L747N/P
Horizontal Resolution
470 TVL 550 TVL
Min. Illumination@Day
Min. Illumination@Night
0.02 Lux
0.002 Lux
Gamma
Scanning Frequency (V)
Scanning Frequency (H)
0.45 Adjustable
S/N Ratio
More than 48db
Video Output
1V p-p, 75
Operational
Sync System
2:1 Internal
Exposure Mode
Lens
Flicker/Manual/fixed
DC/VIDEO/Manual
On / Off
AGC
Shutter Speed
Privacy Masking
Motion Detection
Mirror
Day/Night Mode
BLC
On /Off, Supports upto 4 Zone
On /Off, Supports upto 64 Zone
ON/OFF
Auto/Color/B/W
On / Off, Supports up to 64 Zone
Color Control
Contrast, Sharpness, CB Gain, CR Gain
Electrical
White Balance
Camera Name
ATW / AWB / MANUAL / FIXED
Yes, A to Z, 0 to 9, & etc
95%
Current Consumption Lighting Protection
Power Supply
10mA
3000V
12V DC Standard ±10%
NTSC : 512 x 492, PAL : 500 x 582 NTSC : 768 x 494, PAL : 752 x 582
15.734KHz
59.94KHz
15.625KHz 50Hz
AUTO
FLK 1/100
Fixed 1/50-1/100000
AUTO
FLK 1/120
Fixed 1/60-1/100000
Page 8
5. Troubleshooting
Error Cause
No Picture Check supply voltage, check power cable and video cable
The picture is noisy Insufficient light (Properly adjusted to the camera)
The picture is too bright Too much peak light, change camera location or active back
light function of the camera
The picture is not sharp Lens focus not adjusted properly
The picture is distorted Different GND potentials between camera and monitor (Bad
connection)
Ghost Image Wrong 75 termination, shield of video cable interrupted.
Dimensional
Weight
Housing
Dimension
Environmental
Mini Box Camera
57(L) x 40(H) x 40(W) mm
-10°C ~ 50°C 95%
250g
Operating Temperature Humidity
6.Cleaning and Care
-Before you start to clean the camera body, disconnect the unit from power supply.
-For reasons of electrical safety never clean the camera with water or other liquid matters and never put the camera under water.
-To clean use a soft dry cloth. Cleaning the camera inside is strictly forbidden and may only be done by your authorized dealer
-Since all camera functions are self adjusting and the camera does not contain any parts or components that are subject to wear. We advice you not to open the camera (except for the flap for settings), unless the camera appears to be defective.
Page 9
7. Maintenance and Support
1. How to request after-sale service?
When ever you want to send repairing material back to us kindly use the same Channel where u purchased the material must with Return Material Authorization (RMA) Form download from our website.
http://www.eyerisdigital.com/RMA%20Form.pdf
2. Following cases should be paid even within the warranty period.
A)When defects are caused by the careless handling of the user. B)When improper or unauthorized repairs are done or when the inside is modified or
damaged. C)Defects caused by natural disaster or power problem.
Technical Support: For any type of product operating, Function, Installation related queries or want to know more about our product details specification or function, contact our website or E-mail to us.
http://www.eyerisdigital.com/support.html
www.eyerisdigital.com
