Page 1
canalettoHDi quick start
eyeheight
2. Typical Connections
IN 1
OUT 1
IN 2
IN 3
OUT 2
AES D-BUS
GPI - T/C
REF
I-BUSRS-232
NLE
Monitor
Mains
eyeheight
next
prev
info
drop
next dev
prev dev
canalettoHDi
User Manual &
Quickstart
Feet
Power Cord
1.Box Contents
All video connections are HD-SDI
Page 2
3. Control Panel
eyeheight
next
prev
info
drop
next dev
prev dev
1 5
2 6
3
4
4. Main Menus
1. Power/Status LED
Green - normal operation
Orange - product is loading
2. Menu Display/Button (1 of 4)
Green menus adjust via push and digipot
Yellow menus are information only
Blue menus navigate the menu hierarchy
Red menus have multiple variables, press the
menu to “open” then adjust with digipots
3. Next Menu Button
Navigates between menu sets in a level
of hierarchy
4. Previous Menu Button
Navigates between menu sets in a level
of hierarchy
5. Digipot Active LED (1 of 4)
6. Digipot (1 of 4)
Adjusts associated menu variable
See manual for full menu listing
BACK
=main=
BACK
=main=
BACK
=main=
Black
Lift=
+0.0 I
BACK
master
Luma
Gain=
100.0%
Hue
Rota’n
=+0
BACK
master
Chroma
Gain=
100.0%
Green
Gamma
=1.00
Blue
Gamma
=1.00
BACK
gamma
Red
Gamma
=1.00
Green
Gain
=1.00
Blue
Gain
=1.00
BACK
Grade=
Red
Gain
=1.00
Green
Offset
=+0
Blue
Offset
=+0
BACK
Grade=
Red
Offset
=+0
BACK
Utils=
<S.ACT
<4:3
<THIN
BACK
=util=
SAFE
ACTION
OFF
Gamma
Mode=
RGBsep
BACK
=util=
Gamma
Range=
Fixed
BACK
Legal=
LoRing
Thresh
+0.0%
HiRing
Thresh
100.0%
BACK
=clip=
Ring
Supr’n
=OFF
LoKnee
Level=
+0.0 %
BACK
=clip=
LoClip
Level=
+0.0 %
HiKnee
Level=
100.0%
BACK
=clip=
HiClip
Level=
100.0%
