2.4GHZ Digital Wireless
Microphone System

USER GUIDE

TABLE OF CONTENTS

1. Description of the units ....................................... ........................3

1. Quick Set Up and Operation .......................................................4

2. Installation....................................................................................5

3. Guidelines For Best Performance................................................6

4. Troubleshooting Guide.................................................................7

5. Technical Specifications...............................................................8

6. Factory Service ............................................................................9

7.

Accessories and Parts ............................... ................................. 9

DESCRIPTION

Base (Receiver)

Transmitter

Green LED: In-use, Record

RED LED: Charging
Green LED: Full charge

Terminal
For charging

Antenna
Connection

Modular Jack

Audio Jack Input

Record Button

Lapel Mic. Cover

Emergency Button

Green: In-use (Light On)

Record (Flashing)

RED LED: Out of Range

RED LED: Low Battery

Audible and Vibration
Selectable Switch

Power On/Off
Switch

1. QUICK SET UP AND OPERATION

Synching Up the Transmitter and Base
The synch operation only needs to be performed the first time a system is used, or a new bodypack is used

with a base previously synched to another bodypack. Do not perform the synch operation multiple times;

it only needs to be done one time when a new bodypack is used with a new base.

1) Turn the transmitter power switch to ON and place the transmitter in the recharge cradle of the base.
The transmitter goes in the base with the belt clip facing out.

2) The recharge LED will light (Green if fully charged, Red if charging). Leave the transmitter in the cradle
for 4 hours for a full charge.

3) Press the REC button on the transmitter and hold until the In-Use LED on the transmitter and base start
to flash, then release the button.

4) After a few seconds the light will stop flashing, and a beep will sound (If the beep is enabled).

5) The transmitter and base are now synched and will continue to be until another transmitter is linked to
that base.

Normal Operation

1) With the transmitter synched up, remove it from the cradle, plug in the lapel microphone (if used)

and place the transmitter on your belt.

2) When you remove Transmitter from the cradle, The TR and Base’s In-USE LED will light a constant

Green and you will hear short beep. To start the recording, press the REC button and the In-Use
LED will blink in green.

3) To end recording, press the REC button and the In-Use LED will light a constant green.

4) At the end of your shift turn the transmitter off and replace it in the charging cradle.

Out of Range

1) The transmitter will alert you with Audible warning beeps (two tone) and the In-Use LED will blink in
red.

2) Move closer to the receiver base and the link will be re-established once you return to normal
range. The In-Use LED will light constant green when link is back to normal operation.

3) If the link is not re-established within 30 seconds, the transmitter and receiver will return to standby
mode.

4) If you went out of range in Standby mode, or the unit reverted to standby mode, re-enter normal range
and press the In-Use button. Operation will return to normal.

5) If you will be out of range for a long period of time, turn the bodypack off.

Low Battery Warning

1) If the transmitter Low BATT indicator (red) starts flashing or you hear warning beeps, return the
transmitter to its cradle on the receiver to fully charge the transmitter.

2) The Charge LED indicator will light constant green when the unit is fully charged.

EMG Panic Button (if wired for use in your vehicle)

1) The EMG or Panic Button can be programmed to do many things but may not be connected in your
vehicle. Check with your technical department to understand what this button will control before you use
it.

2) In Record mode: Press the EMG button on the transmitter, a beep will sound and the relay will be
triggered at the receiver.

3) In Standby mode: Press the EMG button on the transmitter, a beep will sound, the green In-Use
indicator will blink and the relay will be triggered at the receiver.

Disabling the Beep Sound On the Transmitter

1) All of the audible beep signals on the transmitter can be disabled by setting the BEEP switch to the

off position.

Record Trigger (if video recording equipment supports)

1) The Record trigger feature is used to turn on recording whenever the video recorder is turned on.

Some video record units can be triggered by other events (lights and siren being turned on etc.) and
ensures the microphone starts recording at the same time.
The transmitter must be turned on and in standby mode.

2) A +12V signal on the line means the microphone is Record off.

3) 0V or ground on the line turns on the microphone is Record on.

2. INSTALLATION

PIN DESCRIPTION OF THE BASE OUTPUT PORT

Connector wire (RJ45)

Pin #1 : Transmitter Audio out
Pin #2 : In Car Mic. Audio out
Pin #3 : 12V DC_IN
Pin #4 : Ground
Pin #5 : Record Trigger OUT
Pin #6 : Record Trigger IN
Pin #7 : Panic Trigger Out
Pin #8 : In Car Mic. Trigger IN

Terminated Connector ( Optional )

Type A

1) Wire the un-terminated signal wires to the control unit according to the signal chart. 5 Amp fast

blow fuse is recommend in the 12VDC power supply line to protect the equipment.

2) Plug the 3.5mm stereo plug into the audio input jack of the recording device.

3) If it is to be used, plug in the in-car microphone into the In-Car Mic jack in the side of the receiver

base.

4) Turn on the transmitter and place it in the charging cradle with the beltclip facing out. The Charge

LED will light if there is power. If the LEDs do not come on, check the connections and repeat.

Description

Position

Audio Ground

Sleeve

Transmitter Audio

Ring

Inside Car Mic. Audio

Tip

8

1

8

1

Type B

Wire the un-terminated signal wires to the control unit according to the signal chart. A 5 Amp fast blow fuse is
recommend in the 12VDC power supply line to protect the equipment.

Type C

Wire the un-terminated signal wires to the control unit according to the signal chart. A 5 Amp fast blow fuse is
recommend in the 12VDC power supply line to protect the equipment.

1) Plug the 3.5mm stereo plug into the audio input jack of the recording device.

2) If it is to be used, plug in the in-car microphone into the In-Car Mic jack in the side of the receiver

base.

3) Turn on the transmitter and place it in the charging cradle with the beltclip facing out. The Charge

LED will light if there is power. If the LEDs do not come on, check the connections and repeat.

Installation is complete. Refer to Operation Section for more information.

3. GUIDELINES AND RECOMMENDATIONS FOR BEST PERFORMANCE

Compatibility

The transmitter and receiver must synchronize to work together (see Synch process on page 3). The synch
operation only needs to be performed the first time a system is used, or when a new bodypack is used with a
base previously synched to another bodypack. Do not synch multiple times, just once until a new

bodypack is used. Any Base can be synchronized with any Transmitter.
Using Multiple Wireless Systems

Description

Position

Audio Ground

Sleeve

Transmitter Audio

Ring

Inside Car Mic. Audio

Tip

Pin #1 : Transmitter Audio out
Pin #2 : In Car Mic. Audio out
Pin #3 : 12V DC_IN
Pin #4 : Ground
Pin #5 : Record Trigger Out
Pin #6 : Record Trigger IN
Pin #7 : Panic Trigger Out
Pin #8 : In Car Mic. Trigger IN

8

1

The PW24 system has 95 possible “channels” that are really different frequency hopping schemes. Each
synchronized base and transmitter will automatically find a clear channel so up to 40 systems can work
together in one location depending on other interference problems

Potential Sources of Interference

There are many potential sources of interference for your wireless system. Any electronic product that
contains digital circuitry including digital signal processors (reverb/multi-effects units), electronic keyboards,
digital lighting controllers, CD and DVD players, and computers, all emit RF energy that can adversely affect
the performance of your wireless system. It is always best to place the receiver as far away as possible from
these devices to minimize potential problems.
The PW24 operates in the 2.4MHz ISM band and other devices in that band may interfere. The spread
spectrum technique used in the PW24 is very robust and should operate even in the presence of other

2.4MHz devices such as walkie-talkies, LANs, cordless phones, etc. in the area.

Battery Recommendations

The Lithium-Ion battery built into the PW24 transmitter will work at full capacity for over 500 charge cycles. If
you notice lower than usual battery life over time, it may be time to replace the cell

Warnings

Do not use this product in or near water, i.e. near a bathtub, sink, or swimming pool.
Do not use this product in the vicinity of a gas leak or to report a gas leak.

4. TROUBLE SHOOTING GUIDE

Problem

Possible Causes

Solutions

No audio and no In-Use LED
light on the receiver when
Transmitter is on and In-use

Receiver is not powered

Make sure that the power
supply is properly connected

Transmitter and receiver not
synchronized

Turn on transmitter and place
In recharge cradle. Press the
In-use button until the In-Use
LEDs flash 3 and the fair will
be synched

No(or low) Audio with all in-Use
LEDs solid green

Lapel Microphone not connected
or positioned properly

Check the mic. connection and
Placement of the microphone

Receiver audio output cable is
Damaged or disconnected

Connect, repair or replace
cable

Interference

Another 2.4GHz device in the
Area causing interference

Push the In-Use button and
the PWW24 will automatically
select a clear channel. If the
interference is too strong,
this may not completely
eliminate it.

Shot range or drop-outs

RF reflective metal obstacles
between the transmitter and
receiver

Move the obstacles, or
reposition the receiver if
possible

In-Use LED on bodypack
flashes red and two tone
beep sounds

Transmitter is out of range

Move closer to the receiver

Variable sync times or failure
to synch

Synch process run more than
one time with same pair

Power cycle the base station
and Synch one time.

5. TECHNICAL SPECIFICATIONS

RECEIVER BASE STATION

Controls

Video Trigger Active +12/GND

Indicators

INUSE LED: GREEN
CHARGE LED : CHARGING -> RED

FULL CHARGED -> GREEN

RECORD LED GREEN FLASHING

Connections

In Car Mic. 2.5mm Mono Plug
Un-terminated Cord

RED +12V DC Power
BLUE Record Trigger out (Record on =DC12V, OFF= GND)
YELLOW Inside MIC Trigger IN (Ground to enable, OFF=12V)
ORANGE POWER GROUND
BLACK AUX (Panic) Trigger out (+12V when EMG is pushed, OFF=GND)
GRAY RECORD TRIGGER IN (GND= RECORD LED ON, +5V DC REC LED OFF)

Audio Connector

Tip Inside Car Mic
Ring Transmitter Audio
Sleeve Audio Ground

RF Specifications

Frequency Range: 2.4GHz
Number of Channels: 95 possible Diversity:
Internal antenna Receiver Type: FHSS
RF Sensitivity: -102 +/-3 dBm FCC type
acceptance: Approved Part 15

Audio Specifications

Frequency Response: 200 ~ 4000Hz +/- 3 dB Audio
Output Level: 3.6Vp-p
Distortion: Less than 2% Signal to
Noise Ratio: > 40 dB Dynamic
Range: > 50 dB

General Specifications

Range 1000feet typical Power
Supply: External 12 VDC Current
Draw: 190mA Typical
Size: 2.75in x 2.99in x 3.15in

(70mm x 76mm x 80mm)

Weight 233 g

Transmitter

Controls

On/Off Switch
Beep On/Off Switch
In Use Button Emergency
Button

Indicators

Red LED Low battery indicator/Emergency indicator
Yellow LED In Use

Battery Internal Li-ion 3.7V/1300mAh cell
Battery Life 15 hours In Use with full charge

14days Standby

Battery Recharge Time 3.5 hours from full discharge
Antenna Internal

2.5mm Mic Connector Tip Signal, Sleeve Ground
Secondary Microphone Internal

RF Output 30 ~ 40 mW (typical)
Size 2.5 in. x 1.8 in. x 0.94 in.

64 mm x 46 mm x 24 mm

Weight 74 g

6. FACTORY SERVICE ( NORTH AMERICA )

Police Wireless GPW24

Model

DESCRIPTION

PW24-IM

In Car Microphone

Eye3Data

9624 Cincinnati-columbus Rd.
Cincinnati, OH 45241
Tel: [phone]
Fax: [phone]

8. ACCESSORIES AND PARTS

PWB-24
PWR-24
EXA-2410F
TC-24
PW24-LM

Transmitter with internal microphone, battery, belt clip
Receiver and recharge station, RJ45 cable
External ANT – 10Feet
Optional TX Charger Base for PWB-24
Lapel Microphone
