Extron electronics Video and Audio Line Drivers with Gain and EquaLization CVEQ 100, SVEQ 100 Specifications

Specifications — CVEQ 100, SVEQ 100

Video

Gain ............................................... Composite video and Y of S-video: -1 dB to +3 dB (x0.9 to x1.4), adjustable

C of S-video: 0dB to +10 dB (x1 to x3), adjustable

Equalization.................................. 0 dB to +7 dB (x1 to x2) at 5 MHz, adjustable

Bandwidth (Y of S-video) ........... 185 MHz (-3 dB)

Output cable driving distance ... Up to 1000' (300 m) with Extron MHR cable

Video input

Number/signal type

CVEQ 100 .......................... 1 composite video

SVEQ 100 .......................... 1 S-video

Connectors

CVEQ 100 .......................... 1 female BNC

SVEQ 100 .......................... 2 female BNC

Nominal level ............................... 1 Vp-p for Y of S-video, and for composite video (including sync)

0.3 Vp-p for C of S-video

Minimum/maximum levels

CVEQ 100 .......................... 0.4 to 2.0 Vp-p with no offset at unity gain

SVEQ 100 .......................... For Y: 0.4 to 2.0 Vp-p with no offset at unity gain

Impedance .................................... 75 ohms

Return loss .................................... <-25 dB @ 0 to 5 MHz

DC offset (max. allowable) ......... 4.0 V

Input coupling.............................. AC

Video output

Number/signal type

CVEQ 100 .......................... 1 composite video

SVEQ 100 .......................... 1 S-video

Connectors

CVEQ 100 .......................... 1 female BNC

SVEQ 100 .......................... 2 female BNC

Nominal level ............................... 1 Vp-p for Y of S-video, and for composite video (including sync)

0.3 Vp-p for C of S-video

Minimum/maximum levels ...... 0.4 to 2.0 Vp-p (follows input)

Impedance .................................... 75 ohms

Return loss .................................... -30 dB @ 5 MHz

DC offset ....................................... ±5 mV with no input signal

Floating: +0.1 to -0.6 V, depending on input signal content

Sync

Standards ...................................... NTSC 3.58, NTSC 4.43, PAL, SECAM

Audio

Gain ............................................... Unbalanced output: 0 dB; balanced output: +6 dB

Frequency response ..................... 20 Hz to 20 kHz, +0.05 dB, -0.0 dB

THD + Noise ................................ 0.015% @ 1 kHz at nominal level

S/N ................................................ >100 dB at maximum output (unweighted)

Stereo channel separation .......... >80 dB @ 1 kHz

Output cable driving distance ... Up to 1000' (300 m) with Extron STP cable

1-2

CVEQ 100, SVEQ 100 Line Drivers • Specifications

Audio input

Number/signal type ................... 1 stereo unbalanced

Connectors .................................... 2 RCA female

Impedance .................................... 20k ohms unbalanced, DC coupled

Nominal level ............................... -10 dBV (316 mVrms)

Maximum level ............................ +16 dBu (4.9 V), balanced at 1% THD+N

0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV 2 dBu

Audio output

Number/signal type ................... 1 stereo, balanced/unbalanced

Connectors .................................... (1) 3.5 mm captive screw connector, 5 pole

Impedance .................................... 50 ohms unbalanced, 100 ohms balanced

Nominal level ............................... -10 dBV (316 mVrms), unbalanced; -2 dBu (632 mV), balanced output

Maximum level ............................ +9 dBV (2.8 V) unbalanced, +17 dBu (5.6 V) balanced at 1% THD+N with a

10k ohm load

General

External power supply ............... 100 VAC to 240 VAC, 50/60 Hz, external, autoswitchable; to 12 VDC, 1 A,

regulated

Power input requirements ......... 12 VDC, 0.2 A

Temperature/humidity .............. Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing

Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing

Rack mount................................... Yes, with optional 1U rack shelf, part #60-190-01 or 60-604-01; or 1U, 6" deep rack

shelf, part #60-190-10 or 60-604-10; or VersaTools

#60-190-20 or 60-604-20.

Also furniture and projector mountable with optional mounting kits.

Enclosure type .............................. Metal

Enclosure dimensions

CVEQ 100 .......................... 1.0" H x 4.3" W x 3.0" D (<1U high, quarter rack wide)

2.5 cm H x 11.0 cm W x 7.6 cm D

(Depth excludes connectors. )

SVEQ 100 .......................... 1.7" H x 4.3" W x 3.0" D (1U high, quarter rack wide)

4.3 cm H x 11.0 cm W x 7.6 cm D

(Depth excludes connectors. )

Product weight ............................. 0.7 lbs (0.3 kg)

Shipping weight ........................... 3 lbs (2 kg)

Vibration ....................................... ISTA 1A in carton (International Safe Transit Association)

Listings .......................................... UL, CUL

Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES

MTBF ............................................. 30,000 hours

Warranty ....................................... 3 years parts and labor

®

3" deep rack shelf, part

All nominal levels are at ±10%.

Specifications are subject to change without notice.

(7.52-090206-D2)
