User’s Manual

Extron Electronics, USA

1230 South Lewis Street Anaheim, CA 92805 USA

714.491.1500 Fax 714.491.1517

Extron Electronics, Europe

Beeldschermweg 6C 3821 AH Amersfoort The Netherlands +31.33.453.4040 Fax +31.33.453.4050

Extron Electronics, Asia

135 Joo Seng Road, #04-01 PM Industrial Building Singapore 368363 +65.6383.4400 Fax +65.6383.4664

Extron Electronics, Japan

Daisan DMJ Building 6F 3-9-1 Kudan Minami Chiyoda-ku, Tokyo 102-0074 Japan +81.3.3511.7655 Fax +81.3.3511.7656

www.extron.com

HIgh Resolution Video, Composite Video, and Stereo Audio

Twisted Pair Cable Transmission Products

TP Receivers Family

CAUTION

Do not connect this device to a computer data or telecommunications network

68-547-02 Rev. G

Printed in the USA

08 03

Precautions

This symbol is intended to alert the user of important operating and maintenance (servicing) instructions in the literature provided with the equipment.

This symbol is intended to alert the user of the presence of uninsulated dangerous voltage within the product's enclosure that may present a risk of electric shock.

Caution

Read Instructions • Read and understand all safety and operating

instructions before using the equipment.

Retain Instructions • The safety instructions should be kept for future

reference.

Follow Warnings • Follow all warnings and instructions marked on the

equipment or in the user information.

Avoid Attachments • Do not use tools or attachments that are not

recommended by the equipment manufacturer because they may be hazardous.

Warning

Power sources • This equipment should be operated only from the power source

indicated on the product. This equipment is intended to be used with a main power system with a grounded (neutral) conductor. The third (grounding) pin is a safety feature, do not attempt to bypass or disable it.

Power disconnection • To remove power from the equipment safely, remove all

power cords from the rear of the equipment, or the desktop power module (if detachable), or from the power source receptacle (wall plug).

Power cord protection • Power cords should be routed so that they are not likely to

be stepped on or pinched by items placed upon or against them.

Servicing • Refer all servicing to qualified service personnel. There are no user-

serviceable parts inside. To prevent the risk of shock, do not attempt to service this equipment yourself because opening or removing covers may expose you to dangerous voltage or other hazards.

Slots and openings • If the equipment has slots or holes in the enclosure, these are

provided to prevent overheating of sensitive components inside. These openings must never be blocked by other objects.

Lithium battery • There is a danger of explosion if battery is incorrectly replaced.

Replace it only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions.

Ce symbole sert à avertir l’utilisateur que la documentation fournie avec le matériel contient des instructions importantes concernant l’exploitation et la maintenance (réparation).

Ce symbole sert à avertir l’utilisateur de la présence dans le boîtier de l’appareil de tensions dangereuses non isolées posant des risques d’électrocution.

Attention

Lire les instructions• Prendre connaissance de toutes les consignes de

sécurité et d’exploitation avant d’utiliser le matériel.

Conserver les instructions• Ranger les consignes de sécurité afin de

pouvoir les consulter à l’avenir.

Respecter les avertissements • Observer tous les avertissements et

consignes marqués sur le matériel ou présentés dans la documentation utilisateur.

Eviter les pièces de fixation • Ne pas utiliser de pièces de fixation ni

d’outils non recommandés par le fabricant du matériel car cela risquerait de poser certains dangers.

Avertissement

Alimentations• Ne faire fonctionner ce matériel qu’avec la source d’alimentation

indiquée sur l’appareil. Ce matériel doit être utilisé avec une alimentation principale comportant un fil de terre (neutre). Le troisième contact (de mise à la terre) constitue un dispositif de sécurité : n’essayez pas de la contourner ni de la désactiver.

Déconnexion de l’alimentation• Pour mettre le matériel hors tension sans danger,

déconnectez tous les cordons d’alimentation de l’arrière de l’appareil ou du module d’alimentation de bureau (s’il est amovible) ou encore de la prise secteur.

Protection du cordon d’alimentation • Acheminer les cordons d’alimentation de

manière à ce que personne ne risque de marcher dessus et à ce qu’ils ne soient pas écrasés ou pincés par des objets.

Réparation-maintenance • Faire exécuter toutes les interventions de réparation-

maintenance par un technicien qualifié. Aucun des éléments internes ne peut être réparé par l’utilisateur. Afin d’éviter tout danger d’électrocution, l’utilisateur ne doit pas essayer de procéder lui-même à ces opérations car l’ouverture ou le retrait des couvercles risquent de l’exposer à de hautes tensions et autres dangers.

Fentes et orifices • Si le boîtier de l’appareil comporte des fentes ou des orifices,

ceux-ci servent à empêcher les composants internes sensibles de surchauffer. Ces ouvertures ne doivent jamais être bloquées par des objets.

Lithium Batterie • Il a danger d'explosion s'll y a remplacment incorrect de la

batterie. Remplacer uniquement avec une batterie du meme type ou d'un ype equivalent recommande par le constructeur. Mettre au reut les batteries usagees conformement aux instructions du fabricant.

Safety Instructions • English

Consignes de Sécurité • Français

Sicherheitsanleitungen • Deutsch

Dieses Symbol soll dem Benutzer in der im Lieferumfang enthaltenen Dokumentation besonders wichtige Hinweise zur Bedienung und Wartung (Instandhaltung) geben.

Dieses Symbol soll den Benutzer darauf aufmerksam machen, daß im Inneren des Gehäuses dieses Produktes gefährliche Spannungen, die nicht isoliert sind und die einen elektrischen Schock verursachen können, herrschen.

Achtung

Lesen der Anleitungen • Bevor Sie das Gerät zum ersten Mal verwenden,

sollten Sie alle Sicherheits-und Bedienungsanleitungen genau durchlesen und verstehen.

Aufbewahren der Anleitungen • Die Hinweise zur elektrischen Sicherheit

des Produktes sollten Sie aufbewahren, damit Sie im Bedarfsfall darauf zurückgreifen können.

Befolgen der Warnhinweise • Befolgen Sie alle Warnhinweise und

Anleitungen auf dem Gerät oder in der Benutzerdokumentation.

Keine Zusatzgeräte • Verwenden Sie keine Werkzeuge oder Zusatzgeräte,

die nicht ausdrücklich vom Hersteller empfohlen wurden, da diese eine Gefahrenquelle darstellen können.

Vorsicht

Stromquellen • Dieses Gerät sollte nur über die auf dem Produkt angegebene

Stromquelle betrieben werden. Dieses Gerät wurde für eine Verwendung mit einer Hauptstromleitung mit einem geerdeten (neutralen) Leiter konzipiert. Der dritte Kontakt ist für einen Erdanschluß, und stellt eine Sicherheitsfunktion dar. Diese sollte nicht umgangen oder außer Betrieb gesetzt werden.

Stromunterbrechung • Um das Gerät auf sichere Weise vom Netz zu trennen,

sollten Sie alle Netzkabel aus der Rückseite des Gerätes, aus der externen Stomversorgung (falls dies möglich ist) oder aus der Wandsteckdose ziehen.

Schutz des Netzkabels • Netzkabel sollten stets so verlegt werden, daß sie nicht

im Weg liegen und niemand darauf treten kann oder Objekte darauf- oder unmittelbar dagegengestellt werden können.

Wartung • Alle Wartungsmaßnahmen sollten nur von qualifiziertem

Servicepersonal durchgeführt werden. Die internen Komponenten des Gerätes sind wartungsfrei. Zur Vermeidung eines elektrischen Schocks versuchen Sie in keinem Fall, dieses Gerät selbst öffnen, da beim Entfernen der Abdeckungen die Gefahr eines elektrischen Schlags und/oder andere Gefahren bestehen.

Schlitze und Öffnungen • Wenn das Gerät Schlitze oder Löcher im Gehäuse

aufweist, dienen diese zur Vermeidung einer Überhitzung der empfindlichen Teile im Inneren. Diese Öffnungen dürfen niemals von anderen Objekten blockiert werden.

Litium-Batterie • Explosionsgefahr, falls die Batterie nicht richtig ersetzt wird.

Ersetzen Sie verbrauchte Batterien nur durch den gleichen oder einen vergleichbaren Batterietyp, der auch vom Hersteller empfohlen wird. Entsorgen Sie verbrauchte Batterien bitte gemäß den Herstelleranweisungen.

Este símbolo se utiliza para advertir al usuario sobre instrucciones importantes de operación y mantenimiento (o cambio de partes) que se desean destacar en el contenido de la documentación suministrada con los equipos.

Este símbolo se utiliza para advertir al usuario sobre la presencia de elementos con voltaje peligroso sin protección aislante, que puedan encontrarse dentro de la caja o alojamiento del producto, y que puedan representar riesgo de electrocución.

Precaucion

Leer las instrucciones • Leer y analizar todas las instrucciones de

operación y seguridad, antes de usar el equipo.

Conservar las instrucciones • Conservar las instrucciones de seguridad

para futura consulta.

Obedecer las advertencias • Todas las advertencias e instrucciones

marcadas en el equipo o en la documentación del usuario, deben ser obedecidas.

Evitar el uso de accesorios • No usar herramientas o accesorios que no

sean especificamente recomendados por el fabricante, ya que podrian implicar riesgos.

Advertencia

Alimentación eléctrica • Este equipo debe conectarse únicamente a la fuente/tipo

de alimentación eléctrica indicada en el mismo. La alimentación eléctrica de este equipo debe provenir de un sistema de distribución general con conductor neutro a tierra. La tercera pata (puesta a tierra) es una medida de seguridad, no puentearia ni eliminaria.

Desconexión de alimentación eléctrica • Para desconectar con seguridad la

acometida de alimentación eléctrica al equipo, desenchufar todos los cables de alimentación en el panel trasero del equipo, o desenchufar el módulo de alimentación (si fuera independiente), o desenchufar el cable del receptáculo de la pared.

Protección del cables de alimentación • Los cables de alimentación eléctrica se

deben instalar en lugares donde no sean pisados ni apretados por objetos que se puedan apoyar sobre ellos.

Reparaciones/mantenimiento • Solicitar siempre los servicios técnicos de personal

calificado. En el interior no hay partes a las que el usuario deba acceder. Para evitar riesgo de electrocución, no intentar personalmente la reparación/ mantenimiento de este equipo, ya que al abrir o extraer las tapas puede quedar expuesto a voltajes peligrosos u otros riesgos.

Ranuras y aberturas • Si el equipo posee ranuras o orificios en su caja/alojamiento,

es para evitar el sobrecalientamiento de componentes internos sensibles. Estas aberturas nunca se deben obstruir con otros objetos.

Batería de litio • Existe riesgo de explosión si esta batería se coloca en la posición

incorrecta. Cambiar esta batería únicamente con el mismo tipo (o su equivalente) recomendado por el fabricante. Desachar las baterías usadas siguiendo las instrucciones del fabricante.

Instrucciones de seguridad • Español

FCC Class A Notice

Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at his own expense.

Note: This unit was tested with shielded cables on the peripheral devices. Shielded cables must be used with the unit to ensure compliance.

Extron’s Warranty

Extron Electronics warrants this product against defects in materials and workmanship for a period of three years from the date of purchase. In the event of malfunction during the warranty period attributable directly to faulty workmanship and/or materials, Extron Electronics will, at its option, repair or replace said products or components, to whatever extent it shall deem necessary to restore said product to proper operating condition, provided that it is returned within the warranty period, with proof of purchase and description of malfunction to:

USA, Canada, South America, Europe, Africa, and the Middle East: and Central America:

Extron Electronics, Europe Extron Electronics Beeldschermweg 6C 1230 South Lewis Street 3821 AH Amersfoort Anaheim, CA 92805, USA The Netherlands

Asia: Japan:

Extron Electronics, Japan Extron Electronics, Asia Daisan DMJ Bldg. 6F, 135 Joo Seng Road, #04-01 3-9-1 Kudan Minami PM Industrial Bldg. Chiyoda-ku, Tokyo 102-0074 Singapore 368363 Japan

This Limited Warranty does not apply if the fault has been caused by misuse, improper handling care, electrical or mechanical abuse, abnormal operating conditions or non-Extron authorized modification to the product.

If it has been determined that the product is defective, please call Extron and ask for an Applications Engineer at (714) 491-1500 (USA), 31.33.453.4040 (Europe), 65.6383.4400 (Asia), or 81.3.3511.7655 (Japan) to receive an RA# (Return Authorization number). This will begin the repair process as quickly as possible.

Units must be returned insured, with shipping charges prepaid. If not insured, you assume the risk of loss or damage during shipment. Returned units must include the serial number and a description of the problem, as well as the name of the person to contact in case there are any questions.

Extron Electronics makes no further warranties either expressed or implied with respect to the product and its quality, performance, merchantability, or fitness for any particular use. In no event will Extron Electronics be liable for direct, indirect, or consequential damages resulting from any defect in this product even if Extron Electronics has been advised of such damage.

Please note that laws vary from state to state and country to country, and that some provisions of this warranty may not apply to you.

iTP Receivers • Table of Contents

Chapter 1 • Introduction ..........................................................1-1

About the TP Receivers....................................................... 1-2

Features ...................................................................................... 1-3

TP R BNC A receiver ............................................................... 1-3

TP R BNC AV receiver ............................................................. 1-4

TP R AV receiver ..................................................................... 1-4

TP R 15HD A receiver .............................................................1-5

Chapter 2 • Installation and Operation ......................... 2-1

Installation Overview .......................................................... 2-2

Video jumpers ........................................................................ 2-3

Video DIP switch .................................................................... 2-5

Audio jumpers ....................................................................... 2-5

Mounting the receiver .......................................................... 2-7

Rack mounting (TP R BNC A, TP R BNC AV, TP R 15HD A) .. 2-7

Furniture mounting ........................................................... 2-9

Projector mounting ......................................................... 2-10

Rear panel features and cabling ........................................ 2-11

Transmitted signal cabling............................................... 2-11

Output cabling ................................................................ 2-12

Computer video ........................................................ 2-12

Composite video........................................................ 2-13

Audio ........................................................................ 2-14

Power connector ............................................................. 2-14

Termination of TP cable ...................................................... 2-15

Cable testing ................................................................... 2-16

Equalizing pair skew ........................................................ 2-16

Front Panel Controls and Indicators .......................... 2-18

Troubleshooting ...................................................................2-19

If the image does not appear ............................................. 2-19

If the image is not displayed correctly ............................... 2-20

If the receiver’s Manual/Auto LED flashes.......................... 2-20

Table of Contents

TP Receivers • Table of Contents

Table of Contents, cont’d

TP Receivers

Chapter One

Introduction

About the TP Receivers

Features

Appendix • Specifications, Accessories, and Part Numbers

................................................................................... A-1

Specifications ......................................................................... A-2

Included Parts ......................................................................... A-5

Accessories ............................................................................... A-6

Cables /Adapters ................................................................... A-6

68-547-02 Rev. G

Printed in the USA

08 03

All trademarks mentioned in this manual are the properties of their respective owners.

TP Receivers • Introduction

Introduction, cont’d

Introduction

About the TP Receivers

The Extron Twisted Pair (TP) receivers receive transmissions of RGB video, component video, S-video, composite video, and stereo audio over Extron’s Skew-Free™ A/V UTP cable or standard Category (CAT) 5 unshielded twisted pair (UTP), shielded twisted pair (STP), or foil shielded twisted pair (FTP) cable. The TP R BNC A, TP R BNC AV, and TP R AV receivers are designed for longer transmission distances (200 to 1000 feet) and the TP R 15HD A is designed for shorter transmission distances (100 to 800 feet).

The minimum reliable transmission distance for the TP R BNC A, TP R BNC AV, and TP R AV is 50 feet. The TP R 15HD A provides reliable reception and high quality video output without the minimum distance limitation.

The maximum distance is determined by the output frequency and resolution. The following table specifies the recommended maximum transmission distances using Extron skew-free A/V UTP cable or UTP CAT 5 cable, terminated with CAT 6, or at least CAT 5e, rated connectors.

Extron recommends using the highest quality cable available and affordable. We also recommend the use of pre-terminated and tested cables. Cables terminated on site should be tested before use to ensure that they comply with Category 5e specifications.

Recommended transmission ranges at 60 Hz, TP R 15HD A

Video format Maximum range

Composite video and audio 800 feet Component video and S-video 800 feet 640 x 480 500 feet 800 x 600 400 feet 1024 x 768 300 feet 1280 x 1024 200 feet 1600 x 1280 100 feet

Recommended transmission ranges at 60 Hz, all others

Video format Maximum range

Composite video and audio 1000 feet Component video and S-video 1000 feet 640 x 480 1000 feet 800 x 600 800 feet 1024 x 768 600 feet 1280 x 1024 400 feet 1600 x 1280 200 feet

1-2

It is possible to exceed the recommended distances, however, image quality may be reduced.

The TP receivers can only receive and output signals transmitted by Extron TP transmitters. This user’s manual documents the installation, features, and operation of the TP receivers only. For information about the TP transmitters, refer to the TP Transmitters Family User’s Manual, which accompanies the transmitters.

Features

All Extron TP receivers provide the following features: Audio output — Provides unbalanced (left/right) audio on

RCA connectors, and balanced or unbalanced audio on

3.5 mm, 5-pole captive screw connectors.

Level control — Allows you to manually control the image

brightness.

Peaking control — Allows you to manually control the image

sharpness.

TP R BNC A receiver

The TP R BNC A receiver has the following features: Video output — Provides RGBHV, RGBS, or RGsB video on 5

BNC connectors.

RJ-45 connector — Allows attachment to an Extron TP

transmitter.

Cable length compensation — Allows you to select whether to

compensate for long cable runs automatically or manually.

Mounting —

Mounts in a rack with Extron’s 1U rack shelf (part #60-190-01) or 1U Basic Rack Shelf (part #60-604-01).

Mounts to a projector mounting bracket with Extron’s Projector Mounting Kit (part #70-077-04).

Mounts under or through furniture with Extron’s Under Desk Mounting Kit (part #70-077-01) or Through Desk Mounting Kit (part #70-077-02).

1-3

TP Receivers • Introduction

Introduction, cont’d

TP R BNC AV receiver

The TP R BNC AV receiver has the following features: Video output — Provides RGBHV, RGBS, or RGsB video on 5

BNC connectors, and composite video on 1 BNC connector.

RJ-45 connector — Allows attachment to an Extron TP

transmitter. One connector is for computer input, and one is for A/V input.

Cable length compensation — Allows you to select whether to

compensate for long cable runs automatically or manually.

Mounting —

Mounts in a rack with Extron’s 1U rack shelf (part #60-190-01) or 1U Basic Rack Shelf (part #60-604-01).

Mounts to a projector mounting bracket with Extron’s Projector Mounting Kit (part #70-077-04).

Mounts under or through furniture with Extron’s Under Desk Mounting Kit (part #70-077-01) or Through Desk Mounting Kit (part #70-077-02).

TP R AV receiver

The TP R AV receiver has the following features: Video output — Provides composite video on one BNC

connector.

RJ-45 connector — Allows attachment to an Extron TP

transmitter.

Cable length compensation — Allows you to select whether to

compensate for long cable runs automatically or manually.

Mounting —

Mounts to a projector mounting bracket with Extron’s Projector Mounting Kit (part #70-077-04).

Mounts under or through furniture with Extron’s Under Desk Mounting Kit (part #70-077-01) or Through Desk Mounting Kit (part #70-077-02).

1-4

TP R 15HD A receiver

The TP R 15HD A receiver has the following features: Video output — Provides RGBHV, RGBS, and RGsB on a 15-pin

HD connector. With an optional SY 15 HD-RGBHV cable, the receiver can output component video, S-video, or composite video.

RJ-45 connector — Allows attachment to an Extron TP

transmitter.

Mounting —

Mounts in an Extron VersaTools™ 19" 1U Rack Shelf (part #60-190-20), VersaTools 1U Basic Rack Shelf (part #60-604-20), a standard Universal 1U Rack Shelf (part #60-190-01), or a 1U Basic Rack Shelf (part #60-604-01).

Mounts under furniture or to a projector bracket with Extron’s optional mounting kits (part #70-212-01, furniture, or 70-217-01, projector).

1-5

TP Receivers • Introduction

Introduction, cont’d

TP Receivers

Chapter Two

Installation and Operation

Installation Overview

Front Panel Controls and Indicators

Troubleshooting

1-6

This page was intentionally left blank

TP Receivers • Installation and Operation

Installation and Operation, cont’d

2-3

Installation Overview

To install and set up a TP receiver and the associated TP transmitter(s) for operation, perform the following steps:

Disconnect power from all of the equipment, including the video source(s) (such as computers or DVD players), the transmitter, the receiver, and the output display(s).

For component, S-video, or composite video, ensure that the internal jumpers (TP R BNC A and TP R BNC AV) or external DIP switch (TP R 15HD A) are in the correct position. See Video jumpers or Video DIP switch in this chapter.

TP R BNC AV and TP R AV only — If desired, configure the audio jumpers to make the receiver compatible with unmodified TP transmitters. See Audio jumpers in this chapter.

The TP R BNC AV and TP R AV are redesigned (modified) receivers. The audio jumpers configure the audio portion of the composite video TP link to work with either similarly redesigned TP T 15HD AV and TP T AV transmitters or with older, unmodified transmitters. Redesigned receivers and transmitters have an identifying label.

Mount the receiver in a rack (all except TP R AV) (the TP R 15HD A can be mounted in a standard rack or in a VersaTools rack), under a desk or podium, in a desk or table (all except TP R 15HD A), or on a projector bracket. See Mounting the receiver in this chapter.

Connect the cable(s) between the TP transmitter(s) and the receiver. See Transmitted signal cabling in this chapter and refer to the TP Transmitters Family User ’s Manual, part #68-546-01.

Connect the output cables. See Output cabling in this chapter.

Configure the TP transmitter(s). Refer to the TP Transmitters Family User ’s Manual, part #68-546-01.

Connect power cords to the TP receiver, the TP transmitter, and turn on the video source(s) and the output display(s).

2-2

All TP transmitters include a 15V external power supply. The transmitters also receive power from the associated Extron TP receiver(s) (with the exception of the TP R 15HD A) via the TP cable. Extron recommends using the local power supply; however, the power supply may not be necessary in some applications. Use the following guidelines:

• The TP T 15HD A, TP T 15HD AV, and TP T BNC may not require a local power supply for cable lengths of 300 feet or less.

• The TP T AV may not require a local power supply for cable lengths of 800 feet or less.

• The TP T BNC DA4 and any transmitter connected to a TP R 15HD A always require the local power supply.

If problems are encountered, use the local power supply.

Adjust the picture controls on the transmitter(s) and the receiver. See Controls and Indicators in this chapter and refer to the TP Transmitters Family User’s Manual, part #68-546-01.

Video jumpers

The TP R BNC A and TP R BNC AV receivers can be configured to receive component video, S-video, or composite video.

The receivers are factory configured for RGB video. To receive any other type of video, reconfigure the jumpers.

Installation and Operation

TP Receivers • Installation and Operation

Installation and Operation, cont’d

2-52-4

1. Remove the three screws on each side and the two screws

on top of the cover (figure 2-1).

RGB

Bottom PC board (inside case)

TP R BNC A and TP R BNC AV

For TP R BNC AV

Remove Top PC board

U25

Component, S-video, Composite

ISOG

C SYNC

Lift Cover Straight Up

TP R BNC AV

Remove 8

Screws

Remove 5 (TP R BNC A) or 6 (TP R BNC AV) BNC Hex Nuts

Figure 2-1 — Video jumper configuration

2. Using an Extron BNC extraction tool (part #100-096-01) or a

14 mm, deep well socket with thin walls, remove the five or six hex nuts securing the BNC connectors to the rear panel.

3. Slide the cover forward until the cover clears the BNC

connectors and then lift the cover off.

4. TP R BNC AV only: Remove the four screws securing the

video board to the RGB board and lift the video board out of the way.

5. Locate J3 on the RGB video printed circuit board. See

figure 2-1.

a. For RGB video, ensure that pin 2 is jumpered to

pin 3.

b. For any other video format, ensure that pin 1 is

jumpered to pin 2.

6. Reinstall the video board, replace the cover, and reinstall

the screws and BNC connector hex nuts.

Video DIP switch

The TP R 15HD A receiver can be configured to receive component video, S-video, or composite video. To configure the receiver for RGB video, set DIP switch 3 (C video) on the back of the transmitter to off (down). For any other video format set the switch on (up).

Audio jumpers

Older (unmodified) receivers and transmitters are fully compatible with each other but not with the TPX 88 A twisted pair matrix switcher.

Redesigned (modified) receivers and transmitters are fully compatible with each other and with the TPX 88 A. They can also be jumpered to be compatible with the older (unmodified) transmitters and receivers but not the TPX 88 A.

Redesigned (modified) receivers and transmitters have an identifying label.

The TP R BNC AV and TP R AV receivers are factory configured to receive the audio that is associated with the composite video link on wire pair 3 and 6. This configuration is compatible with redesigned TP transmitters and the TPX 88 A.

If you intend to match this receiver with an older, unmodified TP transmitter, and do not plan to include a TPX 88 A in your system, you can set the receiver to receive the audio on wire pair 7 and 8, to be compatible with an older TP transmitter, by shifting internal jumpers as follows:

C SYNC

SOG

C VIDEO

N/C

TP Receivers • Installation and Operation

Installation and Operation, cont’d

2-6 2-7

1. Remove the three screws on each side and the one or two

screws on top of the cover (figure 2-2).

J10 J11

J11

J10

AV board in TPR BNC AV

TP R AV

Wire Pair

3&6*

Wire Pair

7&8

Wire Pair

3&6*

* TPX Compatible

Wire Pair

7&8

TP R AV or TP R BNC AV

Remove (7)

Screws

-V

15V .5A DC

Remove 1 (TP R AV) or 6 (TP R BNC AV) BNC Hex Nuts

Lift Cover straight up

Figure 2-2 — Audio jumper configuration

2. Using an Extron BNC extraction tool (part #100-096-01) or a

14 mm, deep well socket with thin walls, remove the one or six hex nuts securing the BNC connectors to the rear panel.

3. Slide the cover forward until the cover clears the BNC

connectors and then lift the cover off.

4. Locate J10 and J11 on the composite video printed circuit

board. See figure 2-2.

a. For compatibility with redesigned (modified)

receivers and the TPX 88 A, ensure that pin 1 is

jumpered to pin 2 on both jumper locations.

b. For compatibility with older (unmodified)

receivers, ensure that pin 2 is jumpered to pin 3 on

both jumper locations.

5. Replace the cover, and reinstall the screws and BNC

connector hex nut(s).

Mounting the receiver

Rack mounting (TP R BNC A, TP R BNC AV, TP R 15HD A)

TP R BNC A, TP R BNC AV, or TP R 15HD AV — For optional rack mounting, mount the receiver on a 19" 1U Universal Rack Shelf (Extron part #60-190-01) (figure 2-3). The TP R BNC A and TP R BNC AV mount on the left or right side of the rack. The TP R 15HD A mounts in one of eight locations on the rack.

L E

V E

G B

P E

IN G

L E

IN G

L E

V E

TP R BNC AV

V I

D E

N U

A L

A U

T O

E V

E L

P E A

K I N

N U

A L

A U

T O

E V

E L

P E A

K I N

(2) 4-40 x 3/16" Screws Use 2 Mounting Holes on

Opposite Corners

Figure 2-3 — Rack mounting the TP R 15HD A and TP R BNC AV

TP Receivers • Installation and Operation

Installation and Operation, cont’d

2-8

TP R 15HD A only — For optional rack mounting, mount the receiver on a VersaTools 19" 1U Rack Shelf (Extron part #60-190-20) (figure 2-4). The TP R 15HD A mounts in one of four locations on the rack.

(2) 4-40 x 3/16" screws

Use 2 Mounting Holes on

Opposite Corners

VersaTools Rack Shelf

1/4 Rack Width False Front

Face Plate

P E

L E V

G B

P E

A K

IN G

L E

V E

Figure 2-4 — VersaTools rack mounting the TP R 15HD A

1. If feet were previously installed on the bottom of the

receiver, remove them.

2. Mount the receiver on the rack shelf, using two 4-40 x 3/16

screws in opposite (diagonal) corners to secure the receiver to the shelf.

3. Install blank panel(s) (included in the 1U universal and

VersaTools rack kits, optional for the 1U basic rack kit) or other unit(s) to the rack shelf.

Only the TP R 15HD A and products in the Extron VersaTools line can be mounted on a VersaTools shelf. Any 1U rack-mountable Extron product can be mounted on the standard shelf.

Furniture mounting

All of the receiver models can be mounted under furniture such as a table or podium surface using the appropriate optional mounting bracket, Extron’s Mini Under-Desk Mounting Kit (part #70-212-01) (TP R 15 HD A) or Under-Desk Mounting Kit (part #70-077-01) (all other models).

All models except the TP R 15HD A can be mounted through a table or podium using Extron’s Through-Desk Mounting Kit (part #70-077-02). Furniture mount the receiver as follows:

1. Attach the mounting brackets to the receiver with the

machine screws provided (figure 2-5).

Extron

TP R BNC A

Extron

TP R BNC A

Extron

TP R 15HDA

RGB INPUT

RGB OUTPUT

H/HV

AUDIO

SOG

C SYNC

15V

A D

S O G

C S

Y N C

Through-desk

Mounted

Under-desk

Mounted

Under-desk

Mounted

TP R 15HD A

Figure 2-5 — Under-desk or through-desk mounting

2. For through-surface mounting (all except TP R 15HD A),

cut the proper sized hole in the mounting surface.

3. Hold the receiver with the attached brackets against the

underside of the table or other furniture. Mark the location of the screw holes of the bracket on the mounting surface.

4. Drill 3/32” (2 mm) diameter pilot holes, 1/4” (6.3 mm)

deep in the mounting surface at the marked screw locations.

2-9

TP Receivers • Installation and Operation

Installation and Operation, cont’d

5. For through-surface mounting (all except TP R 15HD A),

insert four #8 wood screws through the bracket and into the four pilot holes. Tighten all four screws to secure the receiver in place.

6. For under-surface mounting, insert #8 wood screws into

the four pilot holes. Tighten each screw into the mounting surface until just less than 1/4” of the screw protrudes.

7. For under-surface mounting, align the mounting screws

with the slots in the brackets and place the receiver against the surface, with the screws through the bracket slots.

8. For under-surface mounting, slide the receiver slightly

forward or back, then tighten all four screws to secure the switcher in place.

Projector mounting

All of the receiver models can be mounted on a projector bracket using the appropriate optional mounting bracket, Extron’s Mini Projector Mounting Kit (part #70-217-01) (TP R 15 HD A) or Projector Mounting Kit (part #70-077-04) (all other models).

Secure the mounting bracket to the receiver using two machine screws in the side of the receiver (TP R 15HD A) or the three #8 machine screws provided (all other models). Secure the receiver to a projector mount or other surface by inserting the mounting bolt through the bracket’s slotted hole (figure 2-6).

-V O U TP

O U TP U T

P O W E R

1 5 V . 5 A D C

A V I N P U T

V I D E O

TP R AV

TP R 15HD A

Mounting Bolt

C S Y

N C

S O G C V I

D E O

N / C

A U D I O

O U T P U T

A V I N P U T

R G B

P O W E R

1 5 V

. 3 4 A M A X

Mounting Bolt

Projector Mounting

Bracket

Projector Mounting

Bracket

Figure 2-6 — Projector bracket mounting a receiver

2-10

Rear panel features and cabling

TP R BNC A

TP R BNC AV

TP R AV

RGB INPUT

A-V INPUT

50/60 Hz

100-240V 0.3A

RGB OUTPUT

VIDEO

G B H/HV V

AUDIO

SOG

C SYNC

A-V AUDIO

RGB INPUT

RGB OUTPUT

R G B H/HV V

AUDIO

SOG

C SYNC

POWER

15V .5A DC

TP R 15HD A

A-V OUTPUT

A-V INPUT

VIDEO

AUDIO

POWER

15V .5A DC

C SYNC

SOG

C VIDEO

N/C

AUDIO

OUTPUT

AV INPUT

RGB

POWER

15V

.34A MAX

2 6 7 8 9

1 4 8 9

Figure 2-7 — Installation features, TP receivers

Transmitted signal cabling

CAUTION

Do not connect this device to a computer data or telecommunications network

RJ-45 termination must comply with the TIA/EIA T 568A wiring standards for all connections.

RGB video transmission connector — Attach one end of a TP cable to this RJ-45 female connector (figure 2-7). Attach the other end to an Extron TP 15HD or BNC transmitter. See Termination of TP cable on page 2-15 for pin assignments.

2-11

TP Receivers • Installation and Operation

Installation and Operation, cont’d

2-12

Composite video transmission connector — Attach one end of a TP cable to this RJ-45 female connector. Attach the other end to an Extron TP composite video transmitter. See Termination of TP cable on page 2-15 for pin assignments.

Output cabling

Computer video

The TP R BNC A, TP R BNC AV and TP R 15HD A receive and output RGB video. These receivers can also receive component video, S-video, or composite video and output them on the R, G, and B signal lines.

Reception of component video, S-video, or composite video requires that an internal jumper (TP R BNC AV and TP R BNC) or external DIP switch (TP R 15HD A) be repositioned. See Video jumpers or Video DIP switch in this chapter.

RGB Output BNCs (TP R BNC A and TP R BNC AV) — Connect the desired video output device to the rear panel output BNCs:

For RGBHV video, use the R, G, B, H/HV, and V BNCs.

RGBH/HVV

For RGBS video, use the R, G, B, and H/HV BNCs.

RGBH/HVV

For RGsB or component video, use the R (R-Y), G (Y), and B (B-Y) BNCs.

RGBH/HVV

For S-video, use the R (C-chroma) and G (Y-luma) BNCs.

RGBH/HVV

For composite video, use the R, G, and/or B BNC.

-or- -or-

G B H/HV V

The H/HV and V BNCs only output sync, not video, signals.

RGB Output 15HD (TP R 15HD A) — Connect the desired video output device to the rear panel output 15HD connector.

At the TP transmitter, input only sync signals, no video signals, on the sync pins, 13 and 14. For component video, use the R (R-Y) and R return pins (pins 1 and 6), G (Y) and G return pins (pins 2 and 7), and B (B-Y) and B return pins (pins 3 and 8). For S-video, use the R, R return (C-chroma), G, and G return (Y-luma) pins. For composite video, use the G pin and the associated return pin. For additional genlocked video signals, use the R, B, and associated return pins.

DIP switches

SOG switch — Set this rear panel switch up for

RGsB video and down for RGBHV or RGBS video.

C Sync switch — Set this rear panel switch up for

RGBS video and down for RGBHV or RGsB video.

C video switch (TP R 15HD A only) —

Configures the transmitter for RGB or component/S-video/composite video. See

Video DIP switch in this chapter.

Set all three DIP switches down for RGBHV video.

N/C (TP R 15HD A only) — No connection.

Composite video

The TP R BNC AV and the TP R AV receive and output composite video.

Video connector — Connect a composite video device to this rear panel BNC connector. Digital audio can also be connected to this connector.

2-13

C SYNC

SOG

C VIDEO

N/C

SOG

C SYNC

15 11

610

Female

TP Receivers • Installation and Operation

Installation and Operation, cont’d

Audio

All Extron TP receivers receive and output stereo audio. All receivers except the TP R 15HD A output the audio on both left and right RCA connectors and on 3.5 mm, 5-pole captive screw connectors. The TP R 15HD A outputs audio on the captive screw connector only.

Stereo audio output connectors — Connect left and right stereo audio cables between these rear panel RCA connectors and the output device’s stereo audio inputs.

Only analog, line level, unbalanced audio signals can be output on these connectors.

Stereo audio 5-pole captive screw connector — Connect audio devices, such as an audio amplifier or powered speakers, to these connectors. These 3.5 mm, 5-pole captive screw connectors output unamplified, line level audio. Figure 2-8 shows how to properly wire an output connector.

Unbalanced Output

Tip

See warning

Sleeve

Tip

See warning

Balanced Output

Tip

Ring

Sleeve (s)

Tip

Ring

Figure 2-8 — Audio output connector wiring

CAUTION

Connect the sleeve to ground (Gnd). Connecting the sleeve to a negative (-) terminal will damage the audio output circuits.

If only an audio signal, no video, is received, connect a ground wire between the chassis ground and an earth ground in the equipment rack or other grounded device. If the receiver is not grounded, a crackling sound may be heard in the audio output.

Power connector

Power

TP R BNC AV — Plug a standard IEC power cord into this

connector to connect the TP R BNC AV to a 100 to 240VAC, 50 Hz or 60 Hz power source.

If the distance between the transmitter and receiver is too great for the receiver to power the transmitter, the video image will be missing, distorted, or noisy, or the receiver’s Manual/Auto LED will flash. The transmitter requires a local 15V power supply.

TP R BNC A and TP R AV — Wire the external 15V power

supply into this 3-pole captive screw connector (figure 2-9) and plug the connector into the receiver. The power supply is included with the unit.

Power Supply Output Cord

Captive Screw Connector

TP R 15HD A

Power 12VDC

Captive Screw Connector

TP R BNC A

TP R AV

Power 15VDC

RidgesSmooth

N/C

Figure 2-9 — Power connector wiring

TP R 15HD A — Wire the external 15V power supply into

this 2-pole captive screw connector (figure 2-11) and plug the connector into the receiver. The power supply is included with the unit.

Termination of TP cable

Figure 2-10 details the recommended termination of TP cables in accordance with the TIA/EIA T 568A wiring standards.

Clip DownSide

1&2

3&6 4&5

7&8

2345678

12345678

Pin Wire color

RGB video and audio AV Video and audio

Signal Level Signal Level

1 White-green Red/V. sync+ ±0.35V Video+ +0.35V

2 Green Red/V. sync- ±0.35V Video- -0.35V 3 White-orange

Audio & power

+15V with ±0.5 V

+15V

4 Blue Green+ +0.35V Reserved None 5 White-blue Green- -0.35V Reserved None

6 Orange

Audio & power

Audio+* &

power+

Audio-* &

power-

±0.5 V 0V

7 White-brown Blue/H. sync+ ±0.35V Reserved None

8 Brown

* Audio can be jumpered to wire pair 7 and 8. See

Audio jumpers

in this chapter.

Blue/H. sync- ±0.35V Reserved None

RJ-45 connector

Twisted Pairs

Figure 2-10 — TP cable termination

2-14 2-15

TP Receivers • Installation and Operation

Installation and Operation, cont’d

2-16

Cable testing

To ensure proper cable termination, each transmission cable system that uses CAT 5e should be tested (Extron’s Skew-Free UTP cable does not need to be tested). Testing the cable from the RJ-45 connections at the transmitter and receiver gives the most accurate indications of cable problems.

There are two varieties of cable runs: simple runs, in which a single cable is terminated only at the transmitter and receiver, and complex runs, which can include patch bays and multiple terminations and lengths of cable. In either case, the entire cabling system should be tested.

A complete test measures cable length and tests the wire map, attenuation, NEXT, PSNEXT, ELFEXT, PSELFEXT, return loss, ACR and PSACR. All of these tests are critical for digital data transfer. While all of these tests are important indicators of the quality of the cable termination, the most critical testing parameters for video transfer are wire map (T-568-A termination) and pair length measurements. The largest concern is equalization of skew between cable pairs. Cable systems of 300 feet or less should exhibit no transmission problems if they pass at least CAT 5e or preferably CAT 6-D5 channel certification testing.

The Microtest OMNI SCANNER 2 performs comprehensive certification testing to the proposed CAT 6 standards. Other manufacturers also make testing equipment. The tests include advanced diagnostics for troubleshooting the cause and location of many cable and termination problems. For simple installation testing, the Microtest MICRO SCANNER PRO tests wire map and cable length, including individual cable pair length.

Equalizing pair skew

The manufacturing process for network (CAT 5e) UTP cable leads to a condition called pair skew. For best results, pair skew needs to be equalized when using the CAT 5e cable in A/V applications. The design of Extron’s skew-free A/V UTP cable minimizes pair skew to the point that equalization is not required.

Skew exists between pairs when the physical length of one wire pair is different from another. As the transmission cable length increases, the amount of skew increases. Skew affects the displayed image when the differential length between wire pairs exceeds 2 feet, causing the timing of the red, green, and blue video signals to appear out of alignment (horizontal registration errors). A white vertical line on a black field can appear as individual red, green, and blue lines that are close

together; the signal transmitted on the shortest wire pair leads the other colors and appears to the left on the display.

UTP cable test equipment measures and reports wire pair length. The report on the various pair lengths can be used in equalizing pair skew. The nominal velocity of propagation (NVP — the speed at which the signal travels on the transmission line, measured as a percentage of the speed of light) of TP cable is very close to that of conventional coaxial cable. The similarity in NVP means that an additional length of coax equal to the length of pair skew, placed on the receiver’s output, equalizes the effects of pair skew (figure 2-11).

If UTP cable test measurement cannot be done, pair skew can still be equalized by viewing a test pattern with a critical eye. Examine the test pattern for loss of horizontal registration and, through a process of trial and error, equalize any pair skew with coax extensions on the red, green, and/or blue outputs.

TP T 15HD A

TP R BNC A

TP T 15HD A

S H

I F T

B U

F F

E R

E D

C O

M P U

T E R

N P U

A U D

I O

ID PIN 4

ID PIN 11

L O

C A

L M

N I T

O R

PC Computer

CAT 5 UTP Cable

Audio

LCD Projector

... THEN insert a four foot

extension cable to equalize

TP skew for red video.

IF cable measurement indicates that the pair with wires

1 and 2

is four feet shorter than the other pairs...

SOG

C SYNC

Pair RGB video

1, 2 Red 4, 5 Green 7, 8 Blue

Figure 2-11 — Pair skew equalization

2-17

TP Receivers • Installation and Operation

Installation and Operation, cont’d

Front Panel Controls and Indicators

The TP R BNC A and TP R BNC AV have similar controls and indicators (figure 2-12). The TP R 15HD A has a reduced set of controls (figure 2-13).

TP R BNC AV

VIDEO

MANUAL

AUTO

LEVEL PEAKING

RGB

MANUAL

AUTO

LEVEL PEAKING

2 3 4 5

Figure 2-12 — TP R BNC AV control and indicators

TP R 15HD A

RGB

PEAKING

LEVEL

4 5

Figure 2-13 — TP R 15HD A control and indicators

Power LED

Amber — indicates that power is applied, but that the

transmitter is not connected to a receiver.

On the TP R BNC AV only, and only if the composite video TP link is used and the RGB link is not used, this LED will only light amber.

Green — indicates that a transmitter is connected and any

of the following grounding conditions exist:

• The transmitter is powered by a local power supply and the receiver’s output is connected to a device that provides a reference ground.

• The transmitter is powered by the receiver, is locally grounded, and the receiver’s output is connected to a device that provides a reference ground.

• The transmitter is receiving power from the receiver, a local monitor is connected to the transmitter, and the receiver’s output is connected to a device that provides a reference ground.

• The receiver is connected to a TP switcher that is connected to a device that provides a reference ground.

Manual/Auto switch (TP R BNC A and TP R BNC AV) — With this switch in the Auto position, the receiver automatically adjusts the level and peaking to compensate for long cable runs. In the Manual position, you can manually compensate for long cable runs using the level and peaking controls.

Auto LED (TP R BNC A and TP R BNC AV) — Indicates that the Manual/Auto switch is in the Auto position.

Level control — Adjusts the image brightness.

Peaking control — Adjusts the image sharpness.

For details on the SOG and C SYNC switches, see Computer video earlier in this chapter.

Troubleshooting

If the image does not appear

1. Ensure that all devices are receiving power. The

transmitter’s and receiver’s front panel Power LEDs indicate that they are receiving power.

2. Ensure that the transmitter is receiving a video input.

3. Ensure that the TP cable(s) are properly terminated in

accordance with TIA/EIA T 568A standards and that the RJ-45 connections are securely made. If the Power LEDs on the transmitter and the receiver are lit green, a transmitter is properly connected to a receiver.

4. For computer/RGB video, ensure that the receiver’s SOG

and C Sync switches are in the correct positions for the video output.

5. For computer video, ensure that the transmitter’s ID bit

switches are on.

6. For computer video on an LCD projector, ensure that the

transmitter’s DDSP switch is on.

7. The transmission distance may be too far for remote

power. Try connecting the local 15V power supply to the transmitter.

8. The transmission distance may be too short. Ensure that

the UTP cable is at least 50 feet long.

9. If the Manual/Auto switch is in the manual position,

ensure that the receiver’s level controls are not set too high. Too much level and peaking can cause display problems.

2-18 2-19

TP Receivers • Installation and Operation

Installation and Operation, cont’d

TP Receivers

Appendix

Specifications,

Accessories, and Part Numbers

Specifications

Included Parts

Accessories

Cables/Adapters

10. For computer video from a laptop or for ungrounded AC

distribution systems, the transmitter may need to be grounded. See Grounding the transmitter in the TP Transmitter Family User ’s Manual, part #68-546-01.

11. Call the Extron S

Sales & Technical Support Hotline if

necessary.

If the image is not displayed correctly

1. For computer/RGB video, if the output image looks too

green, ensure that the receiver’s SOG switch is off.

2. For computer video, if the picture hangs off the edge of the

screen, adjust the transmitter’s H Shift control.

DDSP disables the horizontal shift control.

3. Place the receiver’s Manual/Auto switch to manual and

adjust the level and peaking controls for optimum quality.

4. The transmission distance may be too far for remote

power. Try connecting the local 15V power supply to the transmitter.

5. For computer video from a laptop or for ungrounded AC

distribution systems, the transmitter may need to be grounded. See Grounding the transmitter in the TP Transmitters Family User ’s Manual, part #68-546-01.

6. If the image still does not display properly, call the Extron

Sales & Technical Support Hotline.

If the receiver’s Manual/Auto LED flashes

1. The transmission distance may be too far for remote power.

Connect the local 15V power supply to the transmitter.

2. Check the RJ-45 connector for a loose connection.

2-20

TP Receivers • Specifications, Accessories, and Part NumbersTP Receivers • Specifications, Accessories, and Part Numbers

Specifications, Accessories, and Part Numbers cont’d

A-3A-2

Video

Number/signal type ................... 1 or 2 sets of proprietary analog signals

Connectors .................................... 1 or 2 shielded RJ-45 female

Video input — refer to the TP Transmitters Family User’s Manual, part #68-546-02

Video output

Number/signal type

TP R BNC A,

TP R 15HD A .................... 1 analog RGBHV, RGBS, RGsB,

component video, or S-video; or 1 S-video and 1 NTSC/PAL/SECAM composite video from a single source; or 3 NTSC/PAL composite video from a single source

TP R BNC AV ................... 1 analog RGBHV, RGBS, RGsB,

component video, or S-video; or 1 S-video and 1 NTSC/PAL/SECAM composite video from a single source; or 3 NTSC/PAL/SECAM composite video from a single source and 1 NTSC/PAL/SECAM composite video

TP R AV ............................ 1 NTSC/PAL/SECAM composite video

Connectors

TP R BNC A ...................... 5 BNC female

TP R BNC AV ................... 6 BNC female

TP R 15HD A .................... (1) 15-pin HD female

TP R AV ............................ 1 BNC female

Nominal level ............................... 1V p-p for Y of component video and

S-video, and for composite video

0.7V p-p for RGB

0.3V p-p for R-Y and B-Y of component

video, and for C of S-video

Minimum/maximum levels ...... 0.3V to 1.45V p-p

Impedance .................................... 75 ohms

Audio

Number/signal type ................... 1 or 2 sets of analog proprietary signals

Connectors .................................... 1 or 2 shielded RJ-45 female

Frequency response ..................... 20 Hz to 20 kHz, ±0.05dB

THD + Noise ................................ 0.03% @ 1 kHz, 0.3% @ 20 kHz at rated

maximum output drive

S/N ................................................ >63dB at nominal level

Crosstalk ....................................... <-80dB @ 1 kHz, fully loaded

Stereo channel separation .......... >80dB @ 1 kHz

CMRR ............................................ >33dB @ 20 Hz to 20 kHz

Audio input — refer to the TP Transmitters Family User’s Manual, part #68-546-02

Audio output

Number/signal type

TP R BNC A,

TP R AV ............................ 1 stereo audio balanced/unbalanced, and

1 stereo audio unbalanced

TP R 15HD A .................... 1 stereo audio balanced/unbalanced

TP R BNC AV ................... 2 stereo audio balanced/unbalanced, and

2 stereo audio unbalanced

Connectors

TP R 15HD A .................... (1) 3.5 mm, 5-pole captive screw connector

per input

All other models .............. 2 female RCA (left/right) per input

(1) 3.5 mm, 5-pole captive screw connector

per input

Impedance .................................... 50 ohms unbalanced, 100 ohms balanced

Gain error ...................................... ±0.1dB channel to channel

Maximum level (600 ohm) ......... >+11.5dBm, balanced at stated %THD+N

General

Power

TP R BNC A, TP R AV .... 15VDC, 0.8 A, external power supply.

Product requires 0.3 A (minimum).

TP R 15HD A .................... 15VDC, 0.8 A, external power supply.

Product requires 0.34 A (maximum).

TP R BNC AV ................... 100VAC to 240VAC, 50/60 Hz, 40 watts,

internal

Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) /

10% to 90%, non-condensing

Operating +32° to +122°F (0° to +50°C) /

10% to 90%, non-condensing

Rack mount

TP R AV ............................ No, but projector mountable with optional

mounting kit (#70-077-04), furniture

mountable with optional mounting

brackets (#70-077-01 and #70-077-02).

Specifications, Accessories, and Part Numbers

TP Receivers • Specifications, Accessories, and Part NumbersTP Receivers • Specifications, Accessories, and Part Numbers

Specifications, Accessories, and Part Numbers cont’d

A-4

TP R 15HD A .................... Yes, with optional VersaTools 1U rack

shelf, part #60-190-20 or optional standard size 1U rack shelf, part #60-190-01. Also, projector mountable with optional mounting kit, part #70-212-01 or underfurniture mountable with optional mounting brackets, part #70-217-01.

TP R BNC A, TP R BNC AV

Yes, with optional 1U rack shelf, part #60-190-01. Also, projector mountable with optional mounting kit, part #70-077-04 or furniture mountable with optional mounting brackets #70-077-01,

70-077-02.

Enclosure type.............................. Metal

Enclosure dimensions

TP R BNC A ...................... 1.3” H x 8.75” W x 7.0” D

(<1U high, half-rack width)

(3.3 cm H x 22.2 cm W x 17.8 cm D)

(Depth excludes connectors.)

TP R BNC AV ................... 1.7” H x 8.75” W x 7.0” D

(1U high, half-rack width)

(4.3 cm H x 22.2 cm W x 17.8 cm D)

(Depth excludes connectors.)

TP R 15HD A .................... 1.6” H x 4.25” W x 3.0” D

(1U high, quarter-rack width)

(4.1 cm H x 10.8 cm W x 7.6 cm D)

(Depth excludes connectors.)

TP R AV ............................ 1.25” H x 4.75” W x 7.0” D

(3.2 cm H x 12.1 cm W x 17.8 cm D)

(Depth excludes connectors.) Product weight

TP R BNC A ...................... 1.6 lbs (0.7 kg)

TP R BNC AV ................... 2.6 lbs (1.2 kg)

TP R 15HD A .................... 0.4 lbs (0.2 kg)

TP R AV ............................ 0.9 lbs (0.4 kg)

Shipping weight

TP R BNC A ...................... 4 lbs (1.8 kg)

TP R BNC AV ................... 5 lbs (2.3 kg)

TP R 15HD A .................... 2 lbs (0.9 kg)

TP R AV ............................ 3 lbs (1.4 kg)

Vibration ....................................... ISTA/NSTA 1A in carton (International

Safe Transit Association)

Listings .......................................... UL, CUL

Compliances ................................. CE, FCC Class A

MTBF ............................................. 30,000 hours

Warranty ....................................... 3 years parts and labor

Specifications are subject to change without notice.

Included Parts

These items are included in each order for a specific TP receiver:

Included parts Part number

All

TP Receivers User’s Manual Captive screw connector, 5 pole, 3.5 mm (1 or 2) 10-319-10

TP R BNC A 60-351-02

Single output external power supply, 15V, 0.8A 70-057-01 Captive screw connector, 3 pole, 3.5 mm 10-265-03

TP R 15HD A 60-450-01

Single output external power supply, 15V, 0.34A 70-160-01

TP R AV 60-352-03

Single output external power supply, 15V, 0.8A 70-057-01 Captive screw connector, 3 pole, 3.5 mm 10-265-03

TP R BNC AV 60-350-03

The TP R AV and TP R BNC AV are redesigned receivers. The audio portion of the composite video TP link can be configured to work with either similarly redesigned TP T AV and TP T 15HD AV transmitters or with older, unmodified transmitters. See Audio jumpers in chapter 2, Installation and Operation. Redesigned receivers and transmitters have an identifying label.

A-5

TP Receivers • Specifications, Accessories, and Part NumbersTP Receivers • Specifications, Accessories, and Part Numbers

Specifications, Accessories, and Part Numbers cont’d

Accessories

Accessories Part number

P/S 150 Multiple output 15V power supply 60-432-01 Extron 19" 1U Universal Rack Shelf 60-190-01 Extron 19" 1U Basic Rack Shelf 60-604-01 Extron VersaTools 19" 1U Universal Rack Shelf 60-190-20 Extron VersaTools 19" 1U Basic Rack Shelf 60-604-20 Extron Under Desk Mounting Kit 70-077-01 Extron Thru-desk Mounting Kit 70-077-03 Extron Projector Mounting Kit 70-077-04

Cables/Adapters

Skew-Free™ A/V cable, RJ-45 jacks Part number

Skew-Free A/V UTP cables are not recommended for Ethernet/LAN applications.

Skew-Free A/V UTP 1000’ (Bulk) (non-plenum) 22-141-03 Skew-Free A/V UTP 1000’ (Bulk) (plenum) 22-142-03 3’ Skew-Free A/V UTP 26-569-01 6’ Skew-Free A/V UTP 26-569-02 12’ Skew-Free A/V UTP 26-569-03 25’ Skew-Free A/V UTP 26-569-04 35’ Skew-Free A/V UTP 26-569-05 50’ Skew-Free A/V UTP 26-569-06 75’ Skew-Free A/V UTP 26-569-07 100’ Skew-Free A/V UTP 26-569-08 150’ Skew-Free A/V UTP 26-569-09 200’ Skew-Free A/V UTP 26-569-10 250’ Skew-Free A/V UTP 26-569-11 300’ Skew-Free A/V UTP 26-569-12 25’ Skew-Free Plenum 26-570-04 35’ Skew-Free Plenum 26-570-05 50’ Skew-Free Plenum 26-570-06 75’ Skew-Free Plenum 26-570-07 100’ Skew-Free Plenum 26-570-08

Skew-Free A/V cable, RJ-45 jacks Part number

150’ Skew-Free Plenum 26-570-09 200’ Skew-Free Plenum 26-570-10 250’ Skew-Free Plenum 26-570-11 300’ Skew-Free Plenum 26-570-12 CAT 6 Jack (various colors) 10-463-xx

Video cables and adapters Part number

BNC-5-3’ MHR (3 feet/0.9 meters) 26-260-15 BNC-5-6’ MHR (6 feet/1.8 meters) 26-260-01 BNC-5-12’ MHR (12 feet/3.7 meters) 26-260-02 BNC-4-3’ MHR (3 feet/0.9 meters) 26-210-01 BNC-4-6’ MHR (6 feet/1.8 meters) 26-210-02 BNC-4-12’ MHR (12 feet/3.7 meters) 26-210-03 SVHS 6’ (6 feet/1.8 meters) 26-316-02 SVHS 12’ (12 feet/3.7 meters) 26-316-03 S-video male to 2 BNC adapter, female, 8” 26-353-02 S-video female to 2 BNC, male, 8” 26-353-01 RG6/SHR 1-3’ (3 feet/0.9 meters) 26-383-01 RG6/SHR 1-6’ (6 feet/1.8 meters) 26-383-12 RG6/SHR 1-12’ (12 feet/3.7 meters) 26-383-07

Skew compensation cable Part number

2’ Skew Cable (red/green/blue) 26-524/525/526-01 4’ Skew Cable (red/green/blue) 26-524/525/526-02 6’ Skew Cable (red/green/blue) 26-524/525/526-03 8’ Skew Cable (red/green/blue) 26-524/525/526-04 10’ Skew Cable (red/green/blue) 26-524/525/526-05 12’ Skew Cable (red/green/blue) 26-524/525/526-06 14’ Skew Cable (red/green/blue) 26-524/525/526-07 16’ Skew Cable (red/green/blue) 26-524/525/526-08 18’ Skew Cable (red/green/blue) 26-524/525/526-09

A-7A-6

TP Receivers • Specifications, Accessories, and Part Numbers

Specifications, Accessories, and Part Numbers cont’d

A-8

This page was intentionally left blank

Extron electronics TP R AV, TP R BNC A, TP R 15HD A, TP R BNC AV User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
