MVP 104GX
Multi Video Processor
68-484-01
Printed in the USA
Precautions
Safety Instructions • English
This symbol is intended to alert the user of important operating and maintenance
(servicing) instructions in the literature provided with the equipment.
This symbol is intended to alert the user of the presence of uninsulated dangerous
voltage within the product's enclosure that may present a risk of electric shock.
Caution
Read Instructions • Read and understand all safety and operating instructions before using the
equipment.
Retain Instructions • The safety instructions should be kept for future reference.
Follow Warnings • Follow all warnings and instructions marked on the equipment or in the user
information.
Avoid Attachments • Do not use tools or attachments that are not recommended by the equipment
manufacturer because they may be hazardous.
Consignes de Sécurité • Français
Ce symbole sert à avertir l’utilisateur que la documentation fournie avec le matériel
contient des instructions importantes concernant l’exploitation et la maintenance
(réparation).
Ce symbole sert à avertir l’utilisateur de la présence dans le boîtier de l’appareil de
tensions dangereuses non isolées posant des risques d’électrocution.
Attention
Lire les instructions• Prendre connaissance de toutes les consignes de sécurité et d’exploitation avant
d’utiliser le matériel.
Conserver les instructions• Ranger les consignes de sécurité afin de pouvoir les consulter à l’avenir.
Respecter les avertissements • Observer tous les avertissements et consignes marqués sur le matériel ou
présentés dans la documentation utilisateur.
Eviter les pièces de fixation • Ne pas utiliser de pièces de fixation ni d’outils non recommandés par le
fabricant du matériel car cela risquerait de poser certains dangers.
Sicherheitsanleitungen • Deutsch
Dieses Symbol soll dem Benutzer in der im Lieferumfang enthaltenen
Dokumentation besonders wichtige Hinweise zur Bedienung und Wartung
(Instandhaltung) geben.
Dieses Symbol soll den Benutzer darauf aufmerksam machen, daß im Inneren des
Gehäuses dieses Produktes gefährliche Spannungen, die nicht isoliert sind und
die einen elektrischen Schock verursachen können, herrschen.
Achtung
Lesen der Anleitungen • Bevor Sie das Gerät zum ersten Mal verwenden, sollten Sie alle Sicherheits-und
Bedienungsanleitungen genau durchlesen und verstehen.
Aufbewahren der Anleitungen • Die Hinweise zur elektrischen Sicherheit des Produktes sollten Sie
aufbewahren, damit Sie im Bedarfsfall darauf zurückgreifen können.
Befolgen der Warnhinweise • Befolgen Sie alle Warnhinweise und Anleitungen auf dem Gerät oder in
der Benutzerdokumentation.
Keine Zusatzgeräte • Verwenden Sie keine Werkzeuge oder Zusatzgeräte, die nicht ausdrücklich vom
Hersteller empfohlen wurden, da diese eine Gefahrenquelle darstellen können.
Warning
Power sources • This equipment should be operated only from the power source indicated on the
product. This equipment is intended to be used with a main power system with a grounded
(neutral) conductor. The third (grounding) pin is a safety feature, do not attempt to bypass or
disable it.
Power disconnection • To remove power from the equipment safely, remove all power cords from
the rear of the equipment, or the desktop power module (if detachable), or from the power
source receptacle (wall plug).
Power cord protection • Power cords should be routed so that they are not likely to be stepped on or
pinched by items placed upon or against them.
Servicing • Refer all servicing to qualified service personnel. There are no user-serviceable parts
inside. To prevent the risk of shock, do not attempt to service this equipment yourself because
opening or removing covers may expose you to dangerous voltage or other hazards.
Slots and openings • If the equipment has slots or holes in the enclosure, these are provided to
prevent overheating of sensitive components inside. These openings must never be blocked by
other objects.
Lithium battery • There is a danger of explosion if battery is incorrectly replaced. Replace it only
with the same or equivalent type recommended by the manufacturer. Dispose of used batteries
according to the manufacturer's instructions.
Avertissement
Alimentations• Ne faire fonctionner ce matériel qu’avec la source d’alimentation indiquée sur
l’appareil. Ce matériel doit être utilisé avec une alimentation principale comportant un fil de
terre (neutre). Le troisième contact (de mise à la terre) constitue un dispositif de sécurité :
n’essayez pas de la contourner ni de la désactiver.
Déconnexion de l’alimentation• Pour mettre le matériel hors tension sans danger, déconnectez tous
les cordons d’alimentation de l’arrière de l’appareil ou du module d’alimentation de bureau (s’il
est amovible) ou encore de la prise secteur.
Protection du cordon d’alimentation • Acheminer les cordons d’alimentation de manière à ce que
personne ne risque de marcher dessus et à ce qu’ils ne soient pas écrasés ou pincés par des
objets.
Réparation-maintenance • Faire exécuter toutes les interventions de réparation-maintenance par un
technicien qualifié. Aucun des éléments internes ne peut être réparé par l’utilisateur. Afin
d’éviter tout danger d’électrocution, l’utilisateur ne doit pas essayer de procéder lui-même à ces
opérations car l’ouverture ou le retrait des couvercles risquent de l’exposer à de hautes tensions
et autres dangers.
Fentes et orifices • Si le boîtier de l’appareil comporte des fentes ou des orifices, ceux-ci servent à
empêcher les composants internes sensibles de surchauffer. Ces ouvertures ne doivent jamais
être bloquées par des objets.
Lithium Batterie • Il a danger d'explosion s'll y a remplacment incorrect de la batterie. Remplacer
uniquement avec une batterie du meme type ou d'un ype equivalent recommande par le
constructeur. Mettre au reut les batteries usagees conformement aux instructions du fabricant.
Vorsicht
Stromquellen • Dieses Gerät sollte nur über die auf dem Produkt angegebene Stromquelle betrieben
werden. Dieses Gerät wurde für eine Verwendung mit einer Hauptstromleitung mit einem
geerdeten (neutralen) Leiter konzipiert. Der dritte Kontakt ist für einen Erdanschluß, und stellt
eine Sicherheitsfunktion dar. Diese sollte nicht umgangen oder außer Betrieb gesetzt werden.
Stromunterbrechung • Um das Gerät auf sichere Weise vom Netz zu trennen, sollten Sie alle
Netzkabel aus der Rückseite des Gerätes, aus der externen Stomversorgung (falls dies möglich
ist) oder aus der Wandsteckdose ziehen.
Schutz des Netzkabels • Netzkabel sollten stets so verlegt werden, daß sie nicht im Weg liegen und
niemand darauf treten kann oder Objekte darauf- oder unmittelbar dagegengestellt werden
können.
Wartung • Alle Wartungsmaßnahmen sollten nur von qualifiziertem Servicepersonal durchgeführt
werden. Die internen Komponenten des Gerätes sind wartungsfrei. Zur Vermeidung eines
elektrischen Schocks versuchen Sie in keinem Fall, dieses Gerät selbst öffnen, da beim Entfernen
der Abdeckungen die Gefahr eines elektrischen Schlags und/oder andere Gefahren bestehen.
Schlitze und Öffnungen • Wenn das Gerät Schlitze oder Löcher im Gehäuse aufweist, dienen diese
zur Vermeidung einer Überhitzung der empfindlichen Teile im Inneren. Diese Öffnungen dürfen
niemals von anderen Objekten blockiert werden.
Litium-Batterie • Explosionsgefahr, falls die Batterie nicht richtig ersetzt wird. Ersetzen Sie
verbrauchte Batterien nur durch den gleichen oder einen vergleichbaren Batterietyp, der auch
vom Hersteller empfohlen wird. Entsorgen Sie verbrauchte Batterien bitte gemäß den
Herstelleranweisungen.
Instrucciones de seguridad • Español
Este símbolo se utiliza para advertir al usuario sobre instrucciones importantes de
operación y mantenimiento (o cambio de partes) que se desean destacar en el
contenido de la documentación suministrada con los equipos.
Este símbolo se utiliza para advertir al usuario sobre la presencia de elementos con
voltaje peligroso sin protección aislante, que puedan encontrarse dentro de la caja
o alojamiento del producto, y que puedan representar riesgo de electrocución.
Precaucion
Leer las instrucciones • Leer y analizar todas las instrucciones de operación y seguridad, antes de usar
el equipo.
Conservar las instrucciones • Conservar las instrucciones de seguridad para futura consulta.
Obedecer las advertencias • Todas las advertencias e instrucciones marcadas en el equipo o en la
documentación del usuario, deben ser obedecidas.
Evitar el uso de accesorios • No usar herramientas o accesorios que no sean especificamente
recomendados por el fabricante, ya que podrian implicar riesgos.
Advertencia
Alimentación eléctrica • Este equipo debe conectarse únicamente a la fuente/tipo de alimentación
eléctrica indicada en el mismo. La alimentación eléctrica de este equipo debe provenir de un
sistema de distribución general con conductor neutro a tierra. La tercera pata (puesta a tierra) es
una medida de seguridad, no puentearia ni eliminaria.
Desconexión de alimentación eléctrica • Para desconectar con seguridad la acometida de
alimentación eléctrica al equipo, desenchufar todos los cables de alimentación en el panel trasero
del equipo, o desenchufar el módulo de alimentación (si fuera independiente), o desenchufar el
cable del receptáculo de la pared.
Protección del cables de alimentación • Los cables de alimentación eléctrica se deben instalar en
lugares donde no sean pisados ni apretados por objetos que se puedan apoyar sobre ellos.
Reparaciones/mantenimiento • Solicitar siempre los servicios técnicos de personal calificado. En el
interior no hay partes a las que el usuario deba acceder. Para evitar riesgo de electrocución, no
intentar personalmente la reparación/mantenimiento de este equipo, ya que al abrir o extraer las
tapas puede quedar expuesto a voltajes peligrosos u otros riesgos.
Ranuras y aberturas • Si el equipo posee ranuras o orificios en su caja/alojamiento, es para evitar el
sobrecalientamiento de componentes internos sensibles. Estas aberturas nunca se deben obstruir
con otros objetos.
Batería de litio • Existe riesgo de explosión si esta batería se coloca en la posición incorrecta. Cambiar
esta batería únicamente con el mismo tipo (o su equivalente) recomendado por el fabricante.
Desachar las baterías usadas siguiendo las instrucciones del fabricante.
Quick Start — MVP 104GX
Installation
Step 1
Turn off power to the MVP 104GX and all other
devices that will be connected.
Step 2
If the MVP 104GX is to be rack mounted, insert
the mounting screws and washers, as shown on
the right.
Step 3
Using Inputs 1, 2, 3, and 4, attach up to four
composite/S-video input devices to the
MVP 104GX. Inputs 1 and 2 can be either
composite video or S-video, inputs 3 and 4 are
composite video only.
INPUT 1
INPUT 2
IN
OUT
INPUT 3
IN
IN
OUT
OUT
Any inputs must be either all NTSC or
all PAL, they cannot be both.
The buffered loopout connectors for all inputs
can be used to output the identical signal to other
devices. See the application connection diagram
on the right.
Step 4
Connect up to three output devices to the
MVP 104GX using composite video output A,
composite video output B, and S-video output C.
Step 5
For stereo audio input, connect up to four audio
sources to audio inputs 1, 2, 3, and 4. See the
Audio input and output section in chapter 2 for
illustrations and warnings.
Step 6
For stereo audio output, connect an audio output
device to the 3.5 mm stereo audio output
connector. See the Audio input and output section
in chapter 2 for illustrations and warnings.
Step 7
If the MVP 104GX is to be connected to a
computer or host controller for remote control,
connect the host’s RS-232/RS-422 cable to the
9-pin female RS-232/RS-422 remote connector of
the MVP 104GX. For an RS-232/RS-422 pinout
table, see the Remote Control Port (RS-232/RS-422)
section in chapter 5.
INPUT 4
IN
OUT
OUTPUT
A
BC
INPUTS OUTPUT
2LR 3LR 4LR 1LR
1LR
RS-232/RS-422
REMOTE
Rack mounting
IN
PU
1
T
S
2
3
4
F
R
E
E
Z
E
A
U
D
IO
P
R
E
S
E
T
S
1
2
3
4
S
T
O
R
E
A
C
T
IVE
A
D
JU
F
A
P
A
S
1
T
C
M
TO
T
T
E
E
N
R
2
T
Y
R
N
S
S
3
4
M
E
N
U
N
E
X
T
A
D
JU
S
T
M
U
L
M
T
I
V
V
I
P 10
D
E
O
P
4G
R
O
C
X
E
S
S
O
R
Connecting the MVP 104GX
V
-
S
R
Y
-
R
O
E
D
I
B
G
Y
/
Y
-
B
/
Y
R
/
R
H
VCR
YB
/
G
V
U
P
N
I
IN
OUT
S
1
T
K
C
O
L
N
I
N
E
G
Y
B
/
2
3
2
S
R
T
U
O
T
U
P
N
I
IN
OUT
4
T
U
P
N
I
3
T
U
P
N
IN
I
IN
2
OUT
OUT
PC Computer
External
Genlock
Timing
R
4
L
S
R
T
U
3
P
N
I
L
T
U
R
P
T
2
U
O
L
R
1L
A
C
B
Video Camera
RS-232 Control
M
I
E
H
A
7
5
N
A
E
A
A
N
S
A
T
H
S
STATE COLLEGE BLVD.
E
T
I
.
M
B
.
V
L
V
A
D
N
L
.
O
C
IN
L
.
V
A
S
O
T
I
R
n
R
o
E
r
t
C
x
E
DOUGLAS RD.
5
LEWIS ST.
m
i
e
h
a
n
A
.
D
R
L
m
u
L
i
d
A
a
t
B
S
d
n
a
l
y
e
n
s
i
D
WEST ST.
HASTER ST.
.
V
A
A
L
L
E
T
A
2
3
2
S
R
T
U
P
T
E
U
T
R
O
O
M
1
E
R
L
K
Videoconferencing System
M
I
E
H
A
7
5
N
A
E
A
A
N
S
A
T
H
S
STATE COLLEGE BLVD.
E
T
I
.
M
B
.
V
L
A
V
D
N
L
.
O
C
N
I
L
V.
A
S
O
IT
n
o
r
t
CERR
x
E
DOUGLAS RD.
5
LEWIS ST.
m
i
e
h
na
A
.
D
R
L
m
L
u
A
di
a
B
t
S
d
n
a
l
y
e
n
s
i
D
WEST ST.
HASTER ST.
.
V
A
A
L
L
E
T
A
K
Plasma Display
VCR
Extron
VSC 150
Scan
Converter
MVP 104GX
7
5
.
D
V
L
B
E
G
E
L
L
O
C
.
D
E
M
R
T
S
A
A
I
T
L
.
G
S
V
U
O
A
D
E
S
E
A
O
S
T
S
T
T
I
.
R
H
R
A
E
N
A
H
C
E
A
I
M
n
B
o
L
V
r
D
.
t
x
im
N
E
e
nah
A
m
A
.
iu
T
d
S
a
S
t
I
.
S
W
E
V
L
A
N
L
O
C
N
I
L
.
T
S
5
R
E
T
S
A
H
d
n
a
l
y
e
sn
.
i
T
S
D
.
T
S
D
E
R
W
L
L
A
B
.
V
A
A
L
L
E
T
A
K
Document Camera
O
E
D
I
V
O
U
O
E
D
I
T
I
V
S
P
N
75 OHM
U
P
PAL OUT
T
U
S
T
A
C
3
.
S
A
0
M
V
0
4
2
0
0
1
A
G
V
z
H
0
6
/
0
5
A
5
.
0
z
H
0
6
/
0
5
V
0
4
2
0
0
1
If a genlock device is to be connected to the
MVP 104GX, see Setting Up Genlock and Vertical
Interval Switching in chapter 2.
The MVP 104GX comes from the factory
already configured for RS-232. To set the
MVP 104GX for RS-422 operation, refer
to “Configuring the MVP 104GX for RS422” in the appendix.
Step 8
Power up the input and output devices, then
connect power to the MVP 104GX. A summary
of the menu system is described on the following
page. See the appropriate chapters in this
manual for further details.
Quick Start — MVP 104GX, cont’d
Menu Operation
Default Cycle menu
On power up of the MVP 104GX,
a default cycle of two
informational submenus
displaying the product name
and product type will appear
in 2-second intervals. While
in this cycle, all selected Input
button LEDs will light green.
To adjust any active window’s
sizing or positioning, press the
appropriate Active window
selection button.
Position/Size window
menu
The active window can be
sized and positioned either
vertically or horizontally by
adjusting the appropriate
sizing and positioning knobs
(see the Adjustment knobs
diagram below). Press the
Menu button to advance to the
Picture Controls menu.
Picture Controls menu
The Picture Controls menu
allows you to adjust the contrast,
brightness, tint, and color of a
window image by rotating the
Vertical sizing knob. Press the
Active window selection button
to select a window. Press the
Next button to advance to the
Contrast, Brightness, Tint, and
Color submenus, or press the
Menu button to exit the Picture
Controls menu/submenus and
advance to the Window
Blanking menu.
Window Blanking menu
Select a window by pressing the
Active window selection button.
The Window Blanking menu
adjusts the top, bottom, left, and
right blanking of each output
window. Press the Next button
to advance to the Blanking
submenu. Rotate the Vertical
sizing knob to select <manual>,
then press Next to advance to
the Top, Bottom, Left, and Right
submenus. Rotate the Vertical
sizing knob to adjust the
Exit
Menu
Power
On
Extron
MVP 104GX
Multi Video
Processor
Position/Size
Window #1 – 4
2 -second default cycle
press Freeze and Next
buttons simultaneously
System Resetting
Please Wait
Controls
Contrast
1 – 4
000 – 150
Brightness
1 – 4
000 – 050
1 – 4
Tint
000 – 032
1 – 4
Color
000 – 100
press Menu button
press the Active window
selection button
Window
Blanking
Blanking
Auto <Manual>
Top
000 – 016
Bottom
000 – 016
Left
000 – 016
Right
000 – 016
press Next button
16-second time-out
blanking. Press the Menu
button to exit the Window
Blanking menu/submenus
and advance to the Audio
Configuration menu.
Audio Configuration
menu
The Audio Configuration
menu consists of an Audio
level submenu which adjusts
a window’s audio level. Press
the Next button to advance to
the Audio Level submenu, or
press the Menu button to exit
the Audio Configuration menu
and proceed to the Advanced
Configuration menu.
Advanced Configuration
menu
The Advanced Configuration
menu allows adjustment of the
background color, window
priority, window text, window
borders, and video format of
the window image by rotating
the Vertical sizing knob (rotate
the Horizontal sizing knob
when shifting through the text
in the Window Text submenu).
Advanced
Configuration
Background Color
color
Window Priority
A<1> B3 C4 D2
Windows Text 1 – 4
1 – 16 characters
Text Style
solid
Text Location
top left
Window Borders
ON <OFF>
Video Format
<NTSC> PAL
#1 #2
Input Mode
mode mode
VCR Mode 1
Off On Off Off
Chroma 1 – 4
Off Off Off On
System Reset
Freeze and Next
Confirm Reset
Freeze and Next
–
4
1 – 4
1 – 4
1 – 4
1 – 4
select <Manual> blanking
and press Next button
A
udio
Configuration
Audio Level
-15 – +09 dB
1 – 4
The advanced configuration
settings are displayed on the
bottom of the LCD panel.
System reset and confirm reset
submenus can also be accessed
from this menu. Press the Next
button to advance to the
Background Color, Window
Priority, Window Text, Text Style,
Text Location, Window Borders,
Video Format, Input Mode, VCR
Mode, Chroma, and System Reset
submenus, or press the Menu
button to exit the Advanced
Configuration menu and proceed
to the Exit menu.
Exit menu
Press the Menu button to return
to the default cycle submenus, or
press the Next button to return to
the Picture Controls menu.
Adjustment knobs
vertical
positioning
horizontal
positioning
vertical
sizing
Genlock
not detected
Horizontal Phase
000 – 255
Subcarrier Phase
000 – 255
horizontal
sizing
Table of Contents
Chapter 1 • Introduction ................................................................................. 1-1
About the MVP 104GX ........................................................................................ 1-2
MVP 104GX Features ........................................................................................... 1-2
Chapter 2 • Installation.......................................................................................................... 2-1
Rack Mounting Procedure .............................................................................................. 2-2
Rear Panel Connectors ..................................................................................................... 2-3
Connecting the MVP 104GX ........................................................................................... 2-4
Audio input and output .................................................................................................... 2-5
Unbalanced audio ........................................................................................................ 2-5
Balanced audio ............................................................................................................. 2-6
Genlock connections .......................................................................................................... 2-7
Setting Up Genlock and Vertical Interval Switching......................................... 2-7
Genlock setup .................................................................................................................... 2-7
Oscilloscope displays .......................................................................................................... 2-9
Chapter 3 • Operation ............................................................................................................. 3-1
Front Panel Features ......................................................................................................... 3-2
Menu Flowchart................................................................................................................... 3-3
Front Panel Operation ...................................................................................................... 3-4
Input selection ................................................................................................................... 3-4
Freeze control .................................................................................................................... 3-4
Audio input selection ........................................................................................................ 3-4
User presets ........................................................................................................................ 3-5
Factory patterns ................................................................................................................. 3-5
Active window selection ................................................................................................... 3-6
Menu and Next buttons with the LCD panel ................................................................... 3-6
Horizontal sizing ................................................................................................................ 3-7
Vertical sizing ..................................................................................................................... 3-7
Horizontal positioning ....................................................................................................... 3-7
Vertical positioning............................................................................................................ 3-7
Optimizing the Image ....................................................................................................... 3-7
Using the Menu System ................................................................................................... 3-9
Default Cycle menu ........................................................................................................... 3-9
Product Name submenu ............................................................................................... 3-9
Product Type submenu ................................................................................................. 3-9
Position/Size window menu .............................................................................................. 3-9
Picture Controls menu ..................................................................................................... 3-10
Contrast submenu ...................................................................................................... 3-10
Brightness submenu ................................................................................................... 3-10
Tint submenu.............................................................................................................. 3-10
Color submenu ........................................................................................................... 3-10
Window Blanking menu .................................................................................................. 3-11
MVP 104GX Table of Contents
i
Table of Contents, cont’d
Blanking submenu ...................................................................................................... 3-11
Top submenu .............................................................................................................. 3-11
Bottom submenu ........................................................................................................ 3-11
Left submenu ............................................................................................................. 3-11
Right submenu ........................................................................................................... 3-12
Audio Configuration menu ............................................................................................. 3-12
Audio Level submenu ................................................................................................. 3-12
Advanced Configuration menu ....................................................................................... 3-12
Background Color submenu ....................................................................................... 3-12
Window Priority submenu .......................................................................................... 3-13
Window Text submenu ............................................................................................... 3-13
Text Style submenu ..................................................................................................... 3-14
Text Location submenu ............................................................................................... 3-14
Window Borders submenu ......................................................................................... 3-14
Video Format submenu .............................................................................................. 3-14
Input Mode submenu ................................................................................................. 3-14
VCR Mode submenu ................................................................................................... 3-14
Chroma submenu ....................................................................................................... 3-14
System Reset submenu ............................................................................................... 3-14
Confirm Reset submenu ............................................................................................. 3-15
System Resetting Please Wait submenu ...................................................................... 3-15
Genlock menu .................................................................................................................. 3-15
Horizontal Phase submenu ......................................................................................... 3-15
Subcarrier Phase submenu .......................................................................................... 3-15
Exit menu ......................................................................................................................... 3-15
Chapter 4 • Windows®-based Control Program ..................................................... 4-1
Installing the Windows-based Control Software ............................................... 4-2
Using the Software ............................................................................................................ 4-2
Chapter 5 • Programmer’s Guide ..................................................................................... 5-1
Remote Control Port (RS-232/RS-422) ....................................................................... 5-2
Host-to-MVP 104GX Communications ...................................................................... 5-2
MVP 104GX-initiated messages ........................................................................................ 5-2
Using the command/response table ................................................................................. 5-3
Example responses to commands ..................................................................................... 5-7
MVP 104GX error responses .............................................................................................. 5-8
MVP 104GX-generated unsolicited responses .................................................................. 5-8
Appendix • Reference Information............................................................................... A-1
Configuring the MVP 104GX for RS-422 ................................................................. A-2
Removing the top cover ................................................................................................... A-2
Relocating the ribbon cable and resetting the jumper .................................................. A-2
Replacing the top cover ................................................................................................... A-3
Specifications....................................................................................................................... A-4
ii
MVP 104GX Table of Contents
68-484-01 Rev. C
Printed in the USA
03 02
MVP 104GX
Chapter One
1
Introduction
About the MVP 104GX
MVP 104GX Features
Introduction
About the MVP 104GX
Extron’s MVP 104GX is a multi video processor featuring four inputs, three
outputs, audio switching, and genlock capability. The MVP 104GX accepts up to
four video inputs, both composite and S-video, and can simultaneously output all
four video sources to a single output device. Each of the three outputs can display
up to four discrete, scalable windows, one for every input source. This windowing
feature allows the MVP 104GX to be used in various applications, including
videoconferencing and security operations. The windows can be configured using
both factory pattern preset and user-defined configurations that include window
positioning, sizing, blanking, priority, and audio input selection.
The MVP 104GX features an LCD front panel and a menu system that are accessible
through front panel buttons and RS-232/RS-422 remote commands.
MVP 104GX Features
Multiple inputs — Two inputs can be either composite (NTSC or PAL) or
Multiple outputs — Three outputs for simultaneous display on two composite
Scalable windows — Up to four window images, one for each input, can be sized
Picture controls — Horizontal and vertical sizing, positioning, contrast,
Blanking control — Allows noise or unwanted information, such as tapehead
Freeze control — Individual window images can be frozen (locked) to the current
Factory patterns and user-defined window configurations — Twenty factory
Stereo audio switching — A 4 x 1 stereo audio switching system allows the audio
Executive mode — Locks out all front panel image adjustment functions and
Genlock — Allows for the seamless switching between video sources by using an
RS-232/RS-422 remote control — Allows third-party remote control of features
Rack mountable — The 2U high, full rack width, metal enclosure is rack
S-video. Two additional inputs are composite-only. All inputs have a
buffered loopout available through an identical loopout port.
Any inputs must be either all NTSC or all PAL, they cannot be both.
video and one S-video devices.
and positioned on each output display device. Each window can also have
its own user-specified text description.
brightness, tint, color, and blanking controls are available for each window.
switching and closed captioning, to be eliminated from the top, bottom, left,
and right of the display.
image or, using RS-232/RS-422 remote control, all window images can be
frozen.
pattern preset window configurations (all available through the menu system
or through RS-232/RS-422 commands) and 24 user-defined window
configurations (8 available through the front panel buttons or all 24 available
through RS-232/RS-422 commands) can be retrieved from memory.
input for any video input to be selected for audio output.
preset recalls except input selection. When executive mode is active, all
image adjustments are available through RS-232/RS-422 commands.
external black burst signal to synchronize devices.
and functions using Extron’s Simple Instruction Set
software for Windows
mountable.
®
.
™
(SIS™) or Extron’s control
1-2
MVP 104GX Introduction
MVP 104GX
Chapter Two
2
Installation
Rack Mounting Procedure
Rear Panel Connectors
Connecting the MVP 104GX
Setting Up Genlock and Vertical Interval Switching
MVP 104GX Introduction
Installation
If the MVP 104GX is to be rack mounted, follow the Rack Mounting Procedure below
before proceeding any further. Otherwise, skip to Rear Panel Connectors and
continue with the installation.
Rack Mounting Procedure
1. Before proceeding, verify that the MVP 104GX is not cabled to any devices or
2. Position the MVP 104GX in the mounting rack so that the 4 slots in the
connected to any power source.
mounting ears are aligned with the rack mounting holes. Use 4 large-headed
mounting screws to attach the MVP 104GX to the rack.
I
N
P
U
1
T
S
2
3
4
F
R
E
E
Z
E
A
U
D
I
P
O
R
E
S
E
T
S
1
2
3
4
S
T
O
R
E
A
C
T
I
V
E
A
D
J
F
A
C
P
T
A
O
T
T
R
E
Y
R
N
S
U
S
1
T
M
E
N
2
T
S
3
4
M
E
N
U
N
E
X
T
A
D
J
U
S
T
MULTI VIDEO PROCESSOR
M
V
P
1
0
4
G
X
Figure 2-1 — Rack mounting the MVP 104GX
2-2
MVP 104GX Installation
Rear Panel Connectors
INPUT 1
IN
OUT
100-240V 50/60 Hz 0.5A
INPUT 2
IN
OUT
INPUT 3
14
13
GENLOCK
IN
OUT
RS-232/RS-422
REMOTE
IN
OUT
OUTPUT
A
BC
INPUTS OUTPUT
1LR
2LR 3LR 4LR 1LR
INPUT 4
IN
OUT
1
2
4
3
5 6
Figure 2-2 — Rear panel of MVP 104GX
AC power — Standard AC power connector for a power source of
1
100 – 240VAC, operating at 50/60 Hz.
Input 1: composite video input and loopout — One female BNC for
2
composite video input, and one female BNC for buffered composite video
loopout.
Input 1: S-video input and loopout — One female 4-pin mini-DIN for
3
S-video input, and one female 4-pin mini-DIN for buffered S-video loopout.
Input 2: composite video input and loopout — One female BNC for
4
composite video input, and one female BNC for buffered composite video
loopout.
Input 2: S-video input and loopout — One female 4-pin mini-DIN for
5
S-video input, and one female 4-pin mini-DIN for buffered S-video loopout.
Input 3: composite video input and loopout — One female BNC for
6
composite video input, and one female BNC for buffered composite video
loopout.
Input 4: composite video input and loopout — One female BNC for
7
composite video input, and one female BNC for buffered composite video
loopout.
7 1110
98
12
8
9
10
11
12
Composite video output — Two female BNCs (A and B) for simultaneous
output of composite video (and S-video).
S-video output — One female 4-pin mini-DIN connector for simultaneous
output of S-video (and composite video).
Audio inputs — Four stereo audio balanced/unbalanced 3.5 mm, 5-pole,
captive screw inputs. See Audio input and output in this chapter.
Audio output — One stereo audio balanced/unbalanced 3.5 mm, 5-pole,
captive screw output. See Audio input and output in this chapter.
RS-232/RS-422 remote — One female 9-pin D connector for a host computer
™
or third party controller using Extron’s Simple Instruction Set
control software for Windows
®
.
(SIS™) or
The MVP 104GX comes from the factory already configured for RS-232. To
set the MVP 104GX for RS-422 operation, see “Configuring the MVP 104GX
for RS-422” in the appendix.
MVP 104GX Installation
2-3
Installation, cont’d
Genlock input — Connect an external black burst signal for genlocking the
13
video signal in broadcast or other sync-critical applications.
Genlock output — Connect any downstream equipment that requires
14
genlocking for broadcast or other sync-critical applications.
Connecting the MVP 104GX
The MVP 104GX can be connected to as many as four input devices simultaneously
and output to as many as three devices simultaneously. Follow the steps below
and see the installation example in figure 2-3.
100-240 V 0.3A
50/60 Hz
INPUTS
R/R-Y
G/Y B/B-Y
HVS
VSC 150
GENLOCK
IN
OUT
RS-232
VCR
VIDEO
O
I
U
N
T
P
MAC
P
S-VIDEO
S-VIDEO
U
PAL OUT
75 OHM
U
T
RGB
T
S
S
VGA
R-Y/B-Y/Y
PC Computer
100-240V 50/60 Hz 0.5A
Document
Camera
INPUT 1
INPUT 2
IN
OUT
INPUT 3
IN
OUT
OUTPUT
INPUT 4
IN
OUT
A
BC
INPUTS OUTPUT
2LR 3LR 4LR 1LR
1LR
IN
OUT
Video
Camera
GENLOCK
IN
RS-232/RS-422
REMOTE
OUT
Rear
VCR
Plasma Display Videoconferencing
OUTPUTS
System
RS-232
Control
Figure 2-3 — MVP 104GX installation example
If the MVP 104GX is to be rack mounted, see the earlier Rack Mounting
1
Procedure.
Turn off power to the MVP 104GX and all other devices that will be
2
connected.
Using Inputs 1, 2, 3, and 4, attach up to four composite/S-video input devices
3
to the MVP 104GX. Inputs 1 and 2 can be either composite video or
S-video, inputs 3 and 4 are composite video only. The buffered loopout
connectors for all inputs can be used to output the identical signal to other
devices.
2-4
MVP 104GX Installation
Any inputs must be either all NTSC or all PAL, they cannot be both.
Connect up to three output devices to the MVP 104GX using composite video
4
output A, composite video output B, and S-video output C.
For stereo audio input, connect up to four audio sources to audio inputs 1, 2,
5
3, and 4. See the following Audio input and output section.
For stereo audio output, connect an audio output device to the 3.5 mm stereo
6
audio output connector. See the following Audio input and output section.
If the MVP 104GX is to be connected to a computer or host controller for
7
remote control, connect the host’s RS-232/RS-422 cable to the 9-pin female
RS-232/RS-422 remote connector of the MVP 104GX. For an RS-232/
RS-422 pinout table, see the Remote Control Port (RS-232/RS-422) section in
chapter 5.
The MVP 104GX comes from the factory already configured for RS-232. To
set the MVP 104GX for RS-422 operation, see “Configuring the MVP 104GX
for RS-422” in the appendix.
Power up the input and output devices, then connect power to the
8
MVP 104GX.
Audio input and output
Before connecting audio, determine whether your audio system is unbalanced or
balanced. Then, follow the instructions and illustrations below to connect either
unbalanced audio or balanced audio.
Unbalanced audio
1. Attach the audio cable to an unbalanced powered speaker input
connector (tip and sleeve), as shown here.
2. Attach the other end of the audio cable to the audio cable connector
(Extron part number 10-319-10). Fasten the captive screws inside the
audio cable connector as shown in figure 2-4.
Wiring the audio incorrectly can damage the audio output circuits.
Tip Sleeve
Unbalanced Audio
Tip
See Warning
Sleeve (s)
Tip
See Warning
Connect the sleeve(s) to ground (GND). Connecting the sleeve(s) to a
negative (-) terminal will damage audio output circuits.
3. Slide the audio cable connector into the audio connector of the MVP
104GX, and plug the speaker end of the audio cable into the speakers.
MVP 104GX Installation
2-5
Installation, cont’d
Balanced audio
1. Attach the audio cable to a balanced speaker input connector (tip, ring,
and sleeve), as shown here.
Tip (+)
Sleeve
Ring (-)
Tip (+)
Sleeve (ground)
2. Attach the other end of the audio cable to the audio cable connector
(Extron part number 10-319-10). Fasten the captive screws inside the
audio cable connector as shown in figure 2-4.
Balanced Audio
Tip
Ring
Sleeve (s)
Tip
Ring
Connect the sleeve(s) to ground (GND). Connecting the sleeve(s) to a
negative (-) terminal will damage audio output circuits.
3. Slide the audio cable connector into the audio connector of the MVP
104GX, and plug the speaker end of the audio cable into the speakers.
2-6
MVP 104GX Installation
Figure 2-4 — Fastening captive screws
Genlock connections
A genlock (black burst generator) device can be connected to the MVP 104GX via
the BNC connectors shown below. The genlock feature allows the MVP 104GX to
be synchronized with other system components for seamless vertical interval
switching between sources. See Setting Up Genlock and Vertical Interval Switching in
this chapter.
R 1LR
Figure 2-5 —Genlock connections
Genlock input connector — Connect an external black burst signal to this
13
BNC connection for genlocking the video signal in broadcast or other synccritical applications.
Genlock output connector — Connect any downstream equipment that
14
requires genlocking to this BNC connector to route the black burst signal
throughout the system in broadcast or other sync-critical applications.
OUTPUT
13
14
GENLOCK
IN
RS-232/RS-422
REMOTE
OUT
Setting Up Genlock and Vertical Interval Switching
For vertical interval switching (to allow clean switching between signals from
several devices during the vertical blanking period of each signal), a composite
sync signal can be applied at the Genlock In connector, and also passed to another
device via the Genlock Out connector.
If the genlock connectors are used only for vertical interval switching, no horizontal
or subcarrier phase adjustments are required.
Genlock setup
Genlock differs from simple vertical interval switching in that an external device (a
black burst generator) generates a reference sync signal for the system, and every
device that uses that signal has its output signal’s horizontal and subcarrier phases
adjusted to exactly match that of the generator to allow precise timing and full
synchronization. Genlocked systems produce cleaner switches between inputs
than do those without this type of synchronization.
An oscilloscope is required for genlock setup, and a vectorscope is recommended.
Waveform monitors of types other than a vectorscope may give the appearance that
timing is adjusted correctly when it is 180 degrees out of phase, which will result in
incorrect colors or picture artifacts.
All equipment in the system must be powered up and turned on for at least 15
to 20 minutes before genlock setup adjustments can be made and before the
equipment is used in a genlocked application.
MVP 104GX Installation 2-7
Installation, cont’d
To synchronize the MVP 104GX’s video output with a genlock signal, follow these
steps:
1. Power up and turn on all the devices that will use the genlock signal.
2. Connect the active timing source signal to the Genlock In connector on
3. Connect the video input signals to the MVP 104GX, as described
4. Connect the oscilloscope (“scope”) probe A to the Genlock Out connector.
5. Connect scope probe B to the MVP 104GX’s composite video output
6. Using the instructions for the scope you are using, set the scope to view
7. Set the scope to view the subcarrier signals. Adjust the sub phase by
8. View the horizontal phases again. If the phase difference is not zero,
9. Once the settings are stable, disconnect the oscilloscope, and reconnect
10. Check the display(s) for proper colors and for undesirable artifacts in the
11. If other MVP 104GXs are part of this genlock daisy chain, connect the
The devices must be on for at least 15 to 20 minutes before proceeding
with any adjustments.
the rear panel.
Timing Source
To Scope Probe B
UT 2
INPUT 3
IN
IN
UT
OUT
INPUT 4
IN
OUT
OUTPUT
A
BC
INPUTS OUTPUT
2LR 3LR 4LR 1LR
1LR
OUT
GENLOCK
IN
RS-232/RS-422
REMOTE
OUT
75 ohm Terminator
To Scope Probe
previously in this chapter.
This will provide the scope’s reference signal. In order to avoid altering
the genlock signal, use the cabling configuration that will be used in the
installation. Either connect the genlock signal cable from the scope to the
next device in the system to be timed, or provide 75 ohm termination at
the scope’s genlock output.
connector.
the signals’ horizontal phases. Adjust the horizontal phase until there is
no (0°) difference between the composite video output’s horizontal sync
phase and the genlock signal’s horizontal phase. See Oscilloscope displays.
rotating the encoder knob until there is a zero phase difference between
the genlock signal and the NTSC/PAL output.
repeat steps 6 and 7 until the settings do not change.
the genlock cables.
image(s). Make adjustments as necessary.
oscilloscope to each device, and repeat this procedure.
2-8
MVP 104GX Installation
Oscilloscope displays
What you see on the oscilloscope while adjusting the MVP 104GX to match the
genlock signal depends on the type of signal used, the type of oscilloscope, and the
procedure the scope requires. This section shows some examples of oscilloscope
displays.
Figure 2-6 below shows the genlock input signal (top) and an out-of-alignment
NTSC composite sync output signal (bottom) displayed on a waveform monitor to
check for alignment. When the phases are aligned, the wave peaks on the bottom
waveform should line up with those in the reference signal above it.
With this method there is no way to know if the signals are 180º out of phase. A
delayed sweep on a time-based scope would allow a more accurate display of the
input and output signal phase relationships.
Figure 2-6 — Superimposed waveforms
A vectorscope is more accurate than a waveform monitor. Figure 2-7 shows an
example of a vectorscope display when the horizontal phase is adjusted to align it
with the burst (genlock) vector. Adjust the horizontal phase by rotating the encoder
knob until the difference between the two vectors is 0º. This example shows black
burst only (with no color). The burst vector is pointing to the left from the center.
0
10
350
340
330
320
310
300
290
280
270
260
250
240
230
220
210
200
190
20
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170
180
Figure 2-7 — Vectorscope screen during horizontal
phase adjustment
MVP 104GX Installation
2-9
Installation, cont’d
Figure 2-8 below shows an example of a view of a vectorscope during adjustment
of the color subcarrier phase (SC/H). The subcarrier phase should be aligned to
0º (indicated in the figure by the triangle).
+40
A1
A2
A3
B1
B2
-40
B3
0
10
350
340
330
320
310
300
290
280
270
260
250
240
230
220
210
200
190
20
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170
180
Figure 2-8 — Vectorscope screen during color subcarrier
phase adjustment
2-10
MVP 104GX Installation
MVP 104GX
Chapter Three
3
Operation
Front Panel Features
Menu Flowchart
Front Panel Operation
Optimizing the Image
Using the Menu System
MVP 104GX Installation
Operation
Front Panel Features
13 14
PRESETS ADJUSTMENTS
STORE
ACTIVE
1
2
3
FACTORY
PATTERNS
4
4
9 10
1
2 3 4
INPUTS
FREEZE AUDIO
1
2
3
4
321 5 6 7 8
Figure 3-1 — Front panel details of the MVP 104GX
Input selection — The four input buttons turn on and turn off the input
1
window images to the output. The green LED above each button lights
whenever the input image is selected.
Freeze control — Holding down this button and then pressing an input
2
window selection button (described in
above) freezes the selected input
1
image window. The red LED below each input window selection button
lights whenever the input image is frozen.
Audio input selection — Pressing this button successively 4 times cycles
3
through all four audio inputs and switches audio to audio output. The green
LED for each audio input lights as it is selected. Selecting past audio input 4
turns off the audio output and does not light any LED.
User presets — The 8 buttons recalls 8 preset user-defined window output
4
configurations including window positioning, sizing, blanking, priority, and
audio input selection. The amber LED above/below each preset button lights
whenever the button has been selected. The 8 previously mentioned user
presets, available through the 8 front panel buttons, and an additional 16 user
presets (available only through RS-232/RS-422 commands), are all available
through RS-232/RS-422 commands.
NEXTMENU
ADJUST
MVP 104GX
MULTI VIDEO PROCESSOR
11 12
Factory patterns — Pressing this button and rotating the Vertical sizing knob
5
recalls 20 factory pattern preset window output configurations.
Store preset — After a window output configuration has been set up
6
correctly, pressing this button for 2 seconds lights its green LED. At this point,
pressing any of the 8 user preset buttons (described in
that particular window output configuration to the selected user preset
button.
Active window selection — Pressing this button successively cycles through
7
all enabled input windows only (indicated by the lit input LED(s)). The
Active window selection button’s green LED lights when selected and when
the corresponding input is also enabled. The selected window, which has a
green border, can then be configured. Cycling past the fourth window
deselects all windows on the output display.
LCD menu display — A 16 x 2 LCD for displaying window configuration and
8
information menus.
Menu — This button is used to advance to the next menu group. See the
9
Menu Flowchart section which follows.
Next — This button is used to step through the submenus or to return to the
10
beginning of the menu group. See the Menu Flowchart section which follows.
MVP 104GX Operation3-2
above) will store
4
Vertical sizing — While the menu system’s LCD display is in the default
11
mode (see the Menu Flowchart section) and a window is active, rotating this
adjustment knob increases or decreases the vertical sizing of the window
image. This knob is also used to adjust other functions.
Horizontal sizing — While the menu system’s LCD display is in the default
12
mode (see the Menu Flowchart section) and a window is active, rotating this
adjustment knob increases or decreases the horizontal sizing of the window
image. This knob is also used to adjust other functions.
Vertical positioning — While the menu system’s LCD display is in the default
13
mode (see the Menu Flowchart section) and a window is active, rotating this
adjustment knob shifts the window image up or down.
Horizontal positioning — While the menu system’s LCD display is in the
14
default mode (see the Menu Flowchart section) and a window is active,
rotating this adjustment knob shifts the window image left or right.
Menu Flowchart
Exit
Menu
Power
On
Extron
MVP 104GX
Multi Video
Processor
Position/Size
Window #1 – 4
2 -second default cycle
press Freeze and Next
buttons simultaneously
Controls
Contrast
1 – 4
000 – 150
Brightness
1 – 4
000 – 050
1 – 4
Tint
000 – 032
1 – 4
Color
000 – 100
press Menu button
press the Active window
selection button
Window
Blanking
Blanking
Auto <Manual>
Top
000 – 016
Bottom
000 – 016
Left
000 – 016
Right
000 – 016
press Next button
16-second time-out
1 – 4
1 – 4
1 – 4
1 – 4
select <Manual> blanking
and press Next button
A
udio
Configuration
Audio Level
-15 – +09 dB
1 – 4
Advanced
Configuration
Background Color
color
Window Priority
A<1> B3 C4 D2
Windows Text 1 – 4
1 – 16 characters
Text Style
solid
Text Location
top left
Window Borders
ON <OFF>
Video Format
<NTSC> PAL
#1 #2
Input Mode
mode mode
VCR Mode 1
Off On Off Off
Chroma 1 – 4
Off Off Off On
–
Genlock
not detected
Horizontal Phase
000 – 255
Subcarrier Phase
000 – 255
4
System Resetting
Please Wait
Figure 3-2 — Flowchart of menus (shaded boxes) and submenus
System Reset
Freeze and Next
Confirm Reset
Freeze and Next
MVP 104GX Operation
3-3
Operation, cont’d
Front Panel Operation
INPUTS
1
2 3 4
FREEZE AUDIO
1
2
3
4
Figure 3-3 — MVP 104GX front panel
The functions of the front panel controls are described in the following sections.
Input selection
The four numbered Input selection buttons (1 – 4) will select from among the 4
separate input sources:
1 2 3 4
The Input buttons correspond to the numbered input connectors on the rear panel.
After you select an Input selection button, the green LED indicator above the
button lights. Selecting an input selects the input image to output to a window. To
deselect an Input button, press that button again.
The MVP 104GX can output all
selected input images to the single
S-video output and the two
composite video outputs
simultaneously.
Input 1: selects either a composite video or S-video input
Input 2: selects either a composite video or S-video input
Input 3: selects a composite video input
Input 4: selects a composite video input
PRESETS ADJUSTMENTS
STORE
ACTIVE
1
2
3
FACTORY
PATTERNS
4
INPUT 1
IN
OUT
INPUT 2
NEXTMENU
ADJUST
IN
OUT
MULTI VIDEO PROCESSOR
INPUT 3
IN
OUT
MVP 104GX
INPUT 4
OUT
IN
OUTPUT
A
BC
Freeze control
Pressing the Freeze control button while pressing an Input
selection button freezes the selected input image window. The
red LED below each Input selection button lights whenever the
input image is frozen. To unfreeze the individual input
windows, repeat this process for each frozen input image
window.
Audio input selection
Pressing the Audio input selection button successive times cycles through all
AUDIO
1
four audio inputs and switches the audio input to audio output. The green
2
3
4
LED for each audio input lights as it is selected.
Selecting past audio input 4 turns off all audio
output and does not light any LED.
3-4
MVP 104GX Operation
1 2 3 4 FREEZE
The only way to freeze or unfreeze all input window images in one operation is
through an RS-232/RS-422 command. See the “Programmer’s Guide”
chapter.
INPUTS OUTPUT
1LR
2LR 3LR 4LR 1LR
Selecting past audio input 4 switches audio to audio input 0 (no audio is
selected). The audio can also be deselected through an RS-232/RS-422
command and using 0 as the audio input number. See the “Programmer’s
Guide” chapter.
User presets
P
Before storing any presets, first optimize the window images by setting the
picture controls (contrast, brightness, tint, color), the sizing and positioning
(horizontal and vertical), and the blanking (top, bottom, left, right). See the
“Optimizing the Image” section.
The eight user Preset buttons save/recall eight preset user-defined window
output configurations, including window positioning, sizing, blanking,
priority, test, and audio input selection.
• To save the current window configuration, while in the Default Cycle
menu (see Default cycle menu section), press the Store button for three
seconds. The green LED above the store button lights and the amber
LED above or below each Preset
PRESETS
button flashes for 16 seconds. The
message “Select Location To Save”
also appears on the LCD panel
Select Location
To Save
during those 16 seconds. During
this time, press a Preset button to
save the configuration. The amber
LED above or below the selected
User Preset
Saved
user preset button lights and the
message “User Preset Saved” appears on the
LCD panel for 16 seconds. Wait until the
Default Cycle menu resumes before pressing any
other button.
User Preset
Recalled
• To recall a user preset, while in the Default Cycle
menu, select a user preset button. The preset’s LED lights
amber. Any configuration modification made to a selected
user preset turns the LED off.
• Above and below the Preset buttons are slots to attach labels which
identifies the preset configurations. The 8 user presets can also be
saved/recalled through RS-232/RS-422 commands. In addition to
these 8 user presets, 16 more user presets can be saved/recalled
through RS-232/RS-422 commands only. See the Programmer’s
Guide chapter.
Factory patterns
While the LCD panel is in the Default Cycle menu (see Default
cycle menu section), pressing the Factory Patterns button displays
the LCD message “Preset ## of 20 Menu= No Next=Yes”
where ## refers to the factory pattern preset from 01 to 20.
Rotating the Vertical sizing knob recalls the 20 factory
pattern preset window output configurations.
Pressing the Menu button rejects the configuration
(=No), and pressing the Next button accepts the
Preset ## of 20
Menu=No Next= Yes
configuration (=Yes). Any factory pattern preset can
be conveniently stored as a user preset (see the
previous User presets section).
See figure 3-4 for an illustration of the 20 factory pattern presets.
MVP 104GX Operation
FACTORY
PATTERNS
3-5
Operation, cont’d
Input 1
01
Input 3 Input 4
Input 2
Input 1 Input 2 Input 3
04
05
09
13
17
window patterns
Input 4
Input 1 Input 2
Input 3
Input 1
Input 2 Input 3 Input 4
Input 2
Input 1
Input 3
Input 4
Input 1
Input 1
Input 1
Input 2 Input 3 Input 4
Input 2
Input 3
Input 4
Input 2
Input 3
Input 4
Input 2
Input 3
Input 1
Input 1
Input 2
Input 3 Input 4
Input 1
Input 2 Input 3
Input 1
Input 2 Input 3
Input 2
Input 3
Input 4
Input 4
Input 1
Figure 3-4 — MVP 104GX factory preset
Input 1
Input 2
Input 1 Input 2
Input 1
Input 3 Input 4
Input 2
Input 2 Input 3 Input 4
Input 1
08
12
16
20
Active window selection
Press the Active window selection button repeatedly to cycle through all
active input windows (the green LED lights). An active window is
available only if its corresponding Input selection button has been
previously selected (indicated by the Input selection button’s green LED being lit).
The selected window, which has a green border, can then be configured. Cycling
past the fourth window turns off all LEDs, and all windows are deselected. If the
selected window has been modified, the window is deselected after 5 seconds, and
the LED turns off.
Menu and Next buttons with the LCD panel
Press the Menu button to access the menu system. Press the
Next button to step through the submenus. The LCD panel
3-6
MVP 104GX Operation
ACTIVE
NEXTMENU
1
2
3
4
displays the selected menus and submenus. See the sections Menu Flowchart and
Using the Menu System.
Horizontal sizing
While the MVP 104GX is in the Default Cycle menu (see the Default Cycle
menu section), selecting an active input window and rotating the Horizontal sizing
knob sizes the selected window image horizontally. See the Position/Size window
menu section.
Vertical sizing
While the MVP 104GX is in the Default Cycle menu (see the Default Cycle
menu section), selecting an active input window and rotating the Vertical sizing
knob sizes the selected window image vertically. See the Position/Size
window menu section.
Horizontal positioning
While the MVP 104GX is in the Default Cycle menu (see the Default Cycle
menu section), selecting an active input window and rotating the Horizontal
positioning knob positions the selected window image horizontally. See the
Position/Size window menu section.
Vertical positioning
While the MVP 104GX is in the Default Cycle menu (see the Default Cycle
menu section), selecting an active input window and rotating the Vertical
positioning knob positions the selected window image vertically. See the Position/
Size window menu section.
Optimizing the Image
Before storing any user presets, adjust the input window images for optimum
contrast, brightness, tint, color, positioning, sizing, and blanking. Upon initial
power up of the MVP 104GX, factory pattern #01 in figure 3-4 is the default
windows preset. Using this preset, all four input windows can be optimized, as
shown in the following steps. See the flowchart in the Menu Flowchart section, and
see the Using the Menu System section for further details.
1. From the Default Cycle menu, press the Menu button to advance to the
Picture Controls menu. Press the Next button to select the submenus, and
press the Active window selection button to select a window.
a. Contrast — Rotate the Vertical sizing knob to increase or
decrease the window contrast from 0 to 150 (default is 141).
b. Brightness — Rotate the Vertical sizing knob to increase or
decrease the window brightness from 0 to 50 (default is 23).
c. Tint — Rotate the Vertical sizing knob to increase or
decrease the window tint from 0 to 32 (default is 16).
d. Color — Rotate the Vertical sizing knob to increase or
decrease the window color from 0 to 100 (default is 80).
2. Press the Menu button to advance to the Default Cycle menu, then press the
Active window selection button to select a window to position or size.
a. Horizontal positioning — Rotate the Horizontal positioning knob to
move the left side of the selected window to a desired location, keeping
MVP 104GX Operation
3-7
Operation, cont’d
b. Horizontal sizing — Rotate the Horizontal sizing knob to adjust the
c. Vertical positioning — Rotate the Vertical positioning knob to move
mind that sizing the window vertically moves the bottom side of
the window only.
d. Vertical sizing — Rotate the Vertical sizing knob to adjust the bottom
3. Press the Menu button to advance to the Window blanking menu. Press the
Next button to advance to the Blanking submenu. Using the Vertical sizing
knob, select <Manual>. Press the Next button to select the submenus, and
press the Active window selection button to select a window. The following
submenus remove unwanted information or noise from the top, bottom, left,
and right edges of a displayed image.
a. Top blanking — Rotate the Vertical sizing knob to increase or
b. Bottom blanking — Rotate the Vertical sizing knob to increase or
c. Left blanking — Rotate the Vertical sizing knob to increase or
d. Right blanking — Rotate the Vertical sizing knob to increase or
4. If any of the windows requires further positioning/sizing, repeat steps 2 and
3.
5. After optimizing the window image(s), save the configuration, as follows:
Press the Store button for 2 seconds. After the Store button LED lights green
and all eight User preset button LEDs flash amber, select a User preset button
to store the saved configuration. See the User presets section for a detailed
explanation.
in mind that sizing the window horizontally moves the right side
of the window only.
right side of the window.
the top side of the selected window to a desired location, keeping in
side of the window.
decrease the top blanking from 0 to 16.
decrease the bottom blanking from 0 to 16.
decrease the left blanking from 0 to 16.
decrease the right blanking from 0 to 16.
3-8
MVP 104GX Operation
Using the Menu System
Power
On
Extron
MVP 104GX
Multi Video
Processor
The MVP 104GX menu system is accessed through the Menu and Next buttons
while viewing the LCD panel display. See the previous Menu Flowchart section as a
helpful guide while navigating the menu system. Use the chart below to reference
the various flowchart arrows.
2 -second default cycle
press Freeze and Next
buttons simultaneously
Figure 3-5 — MVP 104GX flowchart arrow designations
Default Cycle menu
After the initial power on of the MVP 104GX, the LCD displays a default cycle of
two informational submenus, with each submenu appearing in 2-second intervals.
Each submenu is for information only and displays the product name and the
product type. While in this cycle, any userenabled Input selection button LEDs light green.
Product Name submenu
This submenu identifies the product name
as the MVP 104GX. Press the Menu button
to exit the Default Cycle menu and advance
to the Picture Controls menu.
To adjust any active window’s sizing or
positioning, press the appropriate Active
window selection button.
press Menu button
press the Active window
selection button
press Next button
16-second time-out
select <Manual> blanking
and press Next button
Product Type submenu
Position/Size Window menu
While the MVP 104GX is in the Default Cycle menu,
pressing the Active window selection button selects
the Position/Size Window menu for the chosen
window (#1, 2, 3, 4, or none). The active window can
be sized and positioned either horizontally or
vertically by viewing the active window and adjusting
the appropriate knob, as indicated by the following
illustrations.
This submenu describes the product type
as a multi video processor. Press the Menu
button to exit the Default Cycle menu and
advance to the Picture Controls menu.
To adjust any active window’s sizing or positioning, press the appropriate
Active window selection button.
Position/Size
Window #1 – 4
MVP 104GX Operation 3-9
Operation, cont’d
Controls
Contrast
Brightness
Tint
Color
000 – 150
000 – 050
000 – 032
000 – 100
1 – 4
1 – 4
1 – 4
1 – 4
Vertical sizing: Horizontal sizing:
Vertical positioning: Horizontal positioning:
Press the Menu button to advance to the Picture Controls menu, or return to the
Default Cycle menu by allowing the 16-second time-out to occur.
Picture Controls menu
The Picture Controls menu adjusts the contrast,
brightness, tint, and color of a selected window
the Active window selection button, is displayed
in the upper right corner of the LCD panel. Press
the Next button to advance to the Contrast
submenu, or press the Menu button to exit the
Picture Controls menu and advance to the
Window Blanking menu. A 16-second time-out
returns you to the Default Cycle menu if no
button is pressed from either this menu or the
following submenus.
image by rotating the Vertical sizing
knob. The picture control settings are
displayed on the bottom of the LCD
panel. The selected window number
(1, 2, 3, or 4), designated by pressing
Contrast submenu
Increase or decrease the picture contrast from 0 to 150 by rotating the
Vertical sizing knob . The selected window number (1, 2, 3, or 4),
designated by pressing the Active window selection button, is displayed in
the upper right corner of the LCD panel. Press the Next button to advance to
the Brightness submenu, or press the Menu button to exit the Contrast
submenu and advance to the Window Blanking menu.
Brightness submenu
Increase or decrease the picture brightness from 0 to 50 by rotating the
Vertical sizing knob. The selected window number (1, 2, 3, or 4), designated
by pressing the Active window selection button, is displayed in the upper
right corner of the LCD panel. Press the Next button to advance to the Tint
submenu, or press the Menu button to exit the Brightness submenu and
advance to the Window Blanking menu.
Tint submenu
Increase or decrease the picture tint from 0 to 32 by rotating the Vertical
sizing knob. The selected window number (1, 2, 3, or 4), designated by
pressing the Active window selection button, is displayed in the upper right
corner of the LCD panel. Press the Next button to advance to the Color
submenu, or press the Menu button to exit the Tint submenu and advance to
the Window Blanking menu.
Color submenu
Increase or decrease the picture color from 0 to 100 by rotating the Vertical
sizing knob. The selected window number (1, 2, 3, or 4), designated by
pressing the Active window selection button, is displayed in the upper right
3-10
MVP 104GX Operation
corner of the LCD panel. Press the Next button to return to the Picture
Controls menu, or press the Menu button to exit the Color submenu and
advance to the Window Blanking menu.
Window Blanking menu
ACTIVE
Remove unwanted information/noise from the edges of each displayed image by
adjusting the blanking. After selecting a window by pressing the Active window
1
2
3
selection button (1, 2, 3, or 4), the Window Blanking menu adjusts the top, bottom,
4
left, and right blanking of each output window by rotating the Vertical sizing knob.
The selected window number is displayed in the upper right corner of the LCD
panel. The window blanking setting is displayed on the bottom of the LCD panel.
Press the Next button to advance to the Blanking submenu, or press the Menu
button to exit the Window Blanking menu and advance to the Audio Configuration
menu.
Blanking submenu
Rotate the Vertical sizing knob to select
<Manual> blanking and press the Next
Window
Blanking
button to advance to the Top submenu, or
press the Menu button to exit the Blanking
submenu and advance to the Audio
Blanking
Auto <Manual>
Configuration menu.
Top submenu
Increase or decrease the Top blanking from 0
Top
1 – 4
000 – 016
to 16 by rotating the Vertical sizing knob
until the unwanted information no longer
appears. The selected window number (1, 2,
Bottom
1 – 4
000 – 016
3, or 4), designated by pressing the Active
window selection button, is displayed in the
upper right corner of the LCD panel. Press
the Next button to advance to the Bottom
Left
1 – 4
000 – 016
submenu, or press the Menu button to exit
the Top submenu and advance to the Audio
Configuration menu.
Right
1 – 4
000 – 016
Bottom submenu
Increase or decrease the Bottom blanking
from 0 to 16 by rotating the Vertical sizing knob until the unwanted
information no longer appears. The selected window number (1, 2, 3, or 4),
designated by pressing the Active window selection button, is displayed in
the upper right corner of the LCD panel. Press the Next button to advance to
the Left submenu, or press the Menu button to exit the Bottom submenu and
advance to the Audio Configuration menu.
Left submenu
Increase or decrease the Left blanking from 0 to 16 by rotating the Vertical
sizing knob until the unwanted information no longer appears. The selected
window number (1, 2, 3, or 4), designated by pressing the Active window
selection button, is displayed in the upper right corner of the LCD panel.
Press the Next button to advance to the Right submenu, or press the Menu
button to exit the Left submenu and advance to the Audio Configuration
menu.
MVP 104GX Operation 3-11
Operation, cont’d
Right submenu
Increase or decrease the Right blanking from 0 to 16 by rotating the
Vertical sizing knob until the unwanted information no longer appears.
The selected window number (1, 2, 3, or 4), designated by pressing the
Active window selection button, is displayed in the upper right corner of
the LCD panel. Press the Next button to return to the Window Blanking
menu, or press the Menu button to exit the Right submenu and advance to
the Audio Configuration menu.
Audio Configuration menu
The Audio Configuration menu consists of an
Audio
Configuration
Audio Level submenu which adjusts the audio
level of an input. Press the Next button to advance
to the Audio Level submenu, or press the Menu
button to exit the Audio Configuration menu and
Audio Level
-15 – +09 dB
proceed to the Advanced Configuration menu. A
16-second time-out returns you to the Default
Cycle menu if no button is pressed from either this menu or the following
submenu.
Audio Level submenu
After selecting a window by pressing the Active window
selection button (1, 2, 3, or 4), increase or decrease the window’s
audio level from -15 to +9 dB by rotating the Vertical sizing
knob. The audio configuration setting is displayed on the
bottom of the LCD panel. The selected window number is
displayed in the upper right corner of the LCD panel. Press the
Next button to return to the Audio Configuration menu, or press
the Menu button to exit the Audio Level submenu and proceed
to the Advanced Configuration menu.
Advanced Configuration menu
In the Advanced Configuration menu, adjust the background color,
window priority, window text, window borders, and video format of
the window image by rotating the Vertical sizing knob (see note
below). The advanced configuration settings are displayed on the
bottom of the LCD panel.
1 – 4
ACTIVE
1
2
3
4
System Reset and Confirm Reset can also be accessed from this menu. Press the
Next button to advance to the Background Color submenu, or press the Menu
button to exit the Advanced Configuration menu and proceed to the Genlock
menu. A 16-second time-out returns you to the Default Cycle menu if no button is
pressed from either this menu or the following submenus.
Background Color submenu
Change the window background color by rotating the Vertical sizing knob.
The eight background colors are: white, yellow, cyan, green, magenta, red, blue,
and black.
Press the Next button to advance to the Window Priority submenu, or press
the Menu button to exit the Background Color submenu and proceed to the
Genlock menu.
3-12
MVP 104GX Operation
Rotating the Horizontal sizing knob while in the Window Text
submenu shifts to each character position.
Window Priority submenu
The priority of each window determines if a
window is displayed in front (priority A) or further
back (priorities B, C and D, with D being furthest
back).
While this submenu is active, all Input button
LEDs blink green. Change the priority (A, B, C, or
D, with A being the highest [top] priority and D
being the lowest [bottom] priority) of all 4 output
windows (1, 2, 3, 4) by rotating the Vertical sizing
knob to select the window. The green LED for each
active window lights as it is selected.
The window number follows each priority, with the
currently selected window being bracketed by the <
> symbols, e.g. A1 B <3> C4 D2, where window 1 is
first in priority, window 3 (currently selected) is
second in priority, window 4 is third in priority, and
window 2 is last in priority.
To change the priority of any window, select the
window by rotating the Vertical sizing knob ( <>
brackets designate the currently selected window)
and press Input button 1, 2, 3, or 4, depending on
whether the window will be changed to 1, 2, 3, or 4,
respectively, for that priority (A, B, C, or D). Repeat
this process to change the priority of any window.
Press the Next button to advance to the Window
Text submenu, or press the Menu button to exit the
Window Priority submenu and proceed to the
Genlock menu.
Window Text submenu
This submenu allows text to be displayed in each
window. While this submenu is active, the green
Advanced
Configuration
Background Color
color
Window Priority
A<1> B3 C4 D2
Windows Text 1 – 4
1 – 16 characters
Text Style
solid
Text Location
top left
Window Borders
ON <OFF>
Video Format
<NTSC> PAL
#1 Input Mode #2
mode mode
VCR Mode 1 – 4
Off On Off Off
Chroma 1 – 4
Off Off Off On
System Reset
Freeze and Next
System Resetting
Please Wait
Confirm Reset
Freeze and Next
LED for the Store button will continually blink. After selecting a window
by pressing the Active window selection button (1, 2, 3, or 4), change the
window text by rotating the Horizontal sizing knob to select the character
position (up to 16 characters long), then rotate the Vertical sizing knob to
change the character. Fifty-nine alphanumeric characters including a space
are available:
ABCDEFGHIJKLMNOPQRSTUVWXYZ
space !”#$%&’()*+,-./0123456789:;<=>?@
Pressing the Store button deletes the currently selected text character. Press
the Next button to advance to the Text Style submenu, or press the Menu
button to exit the Window Text submenu and proceed to the Genlock menu.
MVP 104GX Operation 3-13
Operation, cont’d
Text Style submenu
Specify the text style for all output windows as either solid or translucent by
rotating the Vertical sizing knob. Press the Next button to advance to the
Text Location submenu, or press the Menu button to exit the Text Style
submenu and proceed to the Genlock menu.
Text Location submenu
Specify the text location for all output windows by rotating the Vertical
sizing knob and selecting top left, top center, top right, bottom left, bottom center,
or bottom right. Press the Next button to advance to the Window Borders
submenu, or press the Menu button to exit the Text Location submenu and
proceed to the Genlock menu.
Window Borders submenu
Specify blue borders for all output windows by rotating the Vertical sizing
knob and selecting either On or Off (the <> symbols designate the selection).
Press the Next button to advance to the Video Format submenu, or press the
Menu button to exit the Window Borders submenu and proceed to the
Genlock menu.
Video Format submenu
Specify the video output format by rotating the Vertical sizing knob and
selecting either NTSC or PAL (the <> symbols designate the selection). Press
the Next button to advance to the Input Mode submenu, or press the Menu
button to exit the Video Format submenu and proceed to the Genlock menu.
Input Mode submenu
In this submenu, the green LEDs for Input buttons 1 and 2 blink continually.
Specify the input mode of Inputs 1 or 2 as either auto, video, or S-video, by
repeatedly pressing Input buttons 1 or 2, respectively. Auto allows
automatic detection and selection of the highest quality video input type
first. Press the Next button to advance to the System Reset submenu, or
press the Menu button to exit the Input Mode submenu and proceed to the
Genlock menu.
VCR Mode submenu
Horizontal noise in an input’s image can be eliminated by toggling the Input
button On (default is all inputs Off) from this submenu. Press the Next
button to advance to the Chroma submenu, or press the Menu button to exit
the VCR Mode submenu and proceed to the Genlock menu.
Chroma submenu
To enable color output, toggle the Input button On (default is all inputs On)
from this submenu. By toggling the button Off, the color is disabled and the
output is black and white. Press the Next button to advance to the System
Reset submenu, or press the Menu button to exit the Chroma submenu and
proceed to the Genlock menu.
System Reset submenu
Reset the menu system by first holding down the Freeze button, then press
the Next button (the system advances to the Confirm Reset submenu), or
press the Next button to return to the Background Color submenu, or press
the Menu button to exit the System Reset submenu and proceed to the
Genlock menu.
3-14
MVP 104GX Operation
Confirm Reset submenu
Confirm the menu system reset by first holding down the Freeze button,
then press the Next button (the system advances to the System Resetting
Please Wait submenu), or press the Next button to return to the Background
Color submenu, or press the Menu button to exit the Confirm Reset
submenu and proceed to the Genlock menu.
System Resetting Please Wait submenu
After 2 seconds, the menu system defaults to the Default Cycle menu.
Genlock menu
Press the Menu button to advance to the Exit menu, or press the Next button to
proceed to the Horizontal Phase submenu.
Horizontal Phase submenu
The horizontal phase can be adjusted from 0 to
255 by rotating the Vertical sizing knob and
observing the output display (the default is
128), or press the Next button to proceed to the
Subcarrier Phase submenu, or press the Menu
button to exit the horizontal phase and proceed
to the Exit menu.
Genlock
not detected
Subcarrier Phase submenu
Exit menu
Press the Next button to return to the Default Cycle menu, or press the Menu
button to return to the Picture Controls menu.
The subcarrier phase can be adjusted from 0 to
255 by rotating the Vertical sizing knob and
observing the output display (the default is 128),
or press the Next button to return to the
Horizontal Phase submenu, or press the Menu
button to exit the Subcarrier Phase submenu and
proceed to the Exit menu.
Horizontal Phase
000 – 255
Subcarrier Phase
000 – 255
Exit
Menu
MVP 104GX Operation
3-15
Operation, cont’d
3-16
MVP 104GX Operation
MVP 104GX
Chapter Four
4
Windows®-based Control Program
Installing Windows-based Control Software
Using the Software
MVP 104 Operation
Windows-based Control Program
The MVP and SVS Control Program (Extron part number 29-047-01), which is
used by the MVP 104GX, requires Windows 95/98, NT, or later. It provides
remote control of MVP 104GX functions.
Installing the Windows®-based Control Software
The program is contained on two 3.5-inch diskettes. The program occupies
approximately 1.5 MB (megabytes) of hard-drive space. Run the program
from the hard drive.
To install the software from the floppy disks onto the hard drive, run
SETUP.EXE from the first floppy disk, and follow the instructions that
appear on the screen.
By default, the Windows installation creates a C:\MVP+SVS directory, and it
places two icons (MVP+SVS Control Pgm and MVP+SVS Help) into a group
folder named “Extron Electronics”.
Using the Software
1. To run the MVP and SVS Control Program, double-click on the
MVP+SVS Control Pgm icon in the Extron Electronics group or folder.
The Comm menu appears on the screen.
MVP+SVS
Control Pgm
2. Click on the comm port that is connected to the MVP 104GX RS-232 port.
The Extron MVP and SVS Control Program main screen appears, as shown
below. The screen display includes controls for video inputs, audio inputs,
picture adjustment controls, and a graphic representation of the window
images.
Figure 4-1 — MVP and SVS Control Program main screen
4-2
MVP 104GX Windows-based Control Program
3. Using normal Windows controls, you can perform many of the same
adjustments as from the MVP 104GX front panel. The illustration below,
which shows the four input windows, is an example of the window
adjustment screen that appears after the Adjust Window button is selected
from the previous MVP and SVS Control Program main screen. The window
sizes, position, priorities, text, text placement, blanking around images, and
background colors can be adjusted from this window.
Figure 4-2 — Window adjustment example screen
For information about program features, you can access the help program in
any of the following ways:
• From the Extron Electronics group folder, double-click on
the MVP+SVS Help icon.
• From within the MVP and SVS Control Program, click on
the Help menu on the main screen.
MVP+SVS
Help
• From within the MVP and SVS Control Program, press the
F1 key for context-sensitive Help.
MVP 104GX Windows-based Control Program
4-3
Windows-based Control Program, cont’d
4-4
MVP 104GX Windows-based Control Program
MVP 104GXMVP 104GX
Chapter Five
5
Programmer’s Guide
Remote Control Port (RS-232/RS-422)
Host-to-MVP 104GX Communications
MVP 104 Windows Control Program
Programmer’s Guide
Remote Control Port (RS-232/RS-422)
The MVP 104GX RS-232/RS-422 port connector is used to connect to a host
or external controlling device, such as a computer or control system which
can generate the proper command codes and recognize the MVP 104GX
responses.
RS-232/RS-422
51
REMOTE
The MVP 104GX comes from the factory configured for RS-232. To set the
MVP 104GX for RS-422 operation, see “Configuring the MVP 104GX for
RS-422” in the appendix.
The RS-232/RS-422 connector is a 9-pin D female (see illustration above)
with the following pin designations:
Pin RS-232 Description RS-422 Description
96
DB9 Pin Locations
Female
1 — not used Tx(-) Transmit data (-)
2 Tx Transmit data Tx(+) Transmit data (+)
3 Rx Receive data Rx(+) Receive data (+)
4 — not used Rx(-) Receive data (-)
5 Gnd Signal ground Gnd Ground
6 — not used — not used
7 — not used — not used
8 — not used — not used
9 — not used — not used
The protocol is 9600 baud, 8-bit, 1 stop bit, no parity, and no flow control.
Commands and responses for programming the MVP 104GX from a host
system connected to the RS-232/RS-422 port are listed on the following
pages.
Host-to-MVP 104GX Communications
The MVP 104GX accepts SIS™ (Simple Instruction Set™) commands through
the RS-232/RS-422 port. SIS commands consist of one or more characters
per command field. They do not require any special characters to begin or
end the command character sequence. Each MVP 104GX response to an SIS
command ends with a carriage return and a line feed (CR/LF = ), which
signals the end of the response character string. A string is one or more
characters.
MVP 104GX-initiated messages
When a local event occurs, such as a front panel operation, the
MVP 104GX responds by sending a message to the host. The MVP 104GXinitiated messages are listed below (underlined).
(c) Copyright 2000, Extron Electronics, MVP 104GX, V
5-2
MVP 104GX Programmer’s Guide
x.xx
The copyright message is initiated by the MVP 104GX when it is first
powered on. Vx.xx is the firmware version number.
RECONFIG
The Reconfig message is initiated by the MVP 104GX when a local event
takes place, such as a front panel operation. The MVP responds by sending
an unsolicited response (Reconfig##) to the Host. See MVP 104GX-generated
unsolicited responses at the end of the command/response table.
Using the command/response table
The command/response table is shown on the following pages. Lower case
characters are acceptable in the command field only where indicated.
Symbols are used throughout the table to represent variables in the
command/response fields. Symbol definitions are shown below, and an
ASCII-to-hexadecimal (HEX) conversion table is shown in figure 5-1.
Command and response examples are shown throughout the command/
response table.
Symbol definitions:
= CR/LF • = space = CR
= escape
Esc
= Inputs, 1 - 4
= Audio inputs, 0 - 4
= Audio gain, 0 thru 9 (dB)
= Audio attenuation, 1 thru 15 (dB)
= Numerical value, -15 thru +9
= User presets, #1 thru 24
= Factory patterns, #51 thru 70 (for 1 - 20)
= Windowing values (various)
= Picture contrast, 0 - 150
= Picture brightness, 0 - 50
= Picture tint, 0 - 32
= Picture color, 0 - 100
= 1 (on) or 0 (off)
e
= Background color, 0 thru 7 (0: white, 1: yellow, 2: cyan, 3: green,
4: magenta, 5: red, 6: blue, 7: black)
= Window text, 16 characters (no lower case letters)
f
g
= Blanking values, 0 thru 16
= Video type, 0: no input; 1: NTSC 3.58; 2: PAL; 3: NTSC 4.43; 4: SECAM
h
= Video output type, 1: NTSC; 2: PAL
i
j
= Video input selection, 1: Auto; 2: Video (Composite); 3: S-video
k
= Text placement, 0: off; 1: top left; 2: top center; 3: top right; 4: bottom left;
5: bottom center; 6: bottom right
l
= Text style, 0: solid; 1: translucent
MVP 104GX Programmer’s Guide 5-3
Programmer’s Guide, cont’d
ASCII to HEX Conversion Table
Space
Figure 5-1 — ASCII-to-hexadecimal conversion table
COMMAND/RESPONSE TABLE
COMMAND ASCII RESPONSE DESCRIPTION
Left Edge Size
Left edge size right +H Hph Size left edge of input image to the right
Left edge size left –H Hph Size left edge of input image to the left
Top Edge Size
Top edge size down +/ Vph Size top edge of input image down
Top edge size up –/ Vph Size top edge of input image up
Right Edge Size
Right edge size right +: Hsz Size right edge of input image to the right
Right edge size left –: Hsz Size right edge of input image to the left
Bottom Edge Size
Bottom edge size down +; Vsz Size bottom edge of input image down
Bottom edge size up –; Vsz Size bottom edge input image up
Top Blanking
Specific value *g=T Blt
Increment up +=T Blt
Decrement down –=T Blt
g
g
g
Sets input top blanking to
Increment input top blanking one step
Decrement input top blanking one step
g
Bottom Blanking
Specific value *g=B Blb
Increment up +=B Blb
Decrement down –=B Blb
g
g
g
Sets input bottom blanking to
Increment input bottom blanking one step
Decrement input bottom blanking one step
g
Left Blanking
Specific value *g=L Bll
Increment up +=L Bll
Decrement down –=L Bll
Right Blanking
Specific value *g=R Blr
Increment up +=R Blr
Decrement down –=R Blr
5-4
MVP 104GX Programmer’s Guide
g
g
g
g
g
g
Sets input left blanking to
Increment input left blanking one step
Decrement input left blanking one step
Sets input right blanking to
Increment input right blanking one step
Decrement input right blanking one step
g
g
COMMAND ASCII RESPONSE DESCRIPTION
Contrast
Specific value * ^ Con Sets input contrast to
Increment up +^ Con Increment input contrast one step
Decrement down
–^ Con Decrement input contrast one step
Brightness
Specific value * Y Brt Sets input brightness to
Increment up +Y Brt Increment input brightness one step
Decrement down
–Y Brt Decrement input brightness one step
Color
Specific value * C Col Sets input color to
Increment up +C Col Increment input color one step
Decrement down –C Col Decrement input color one step
Tint
Specific value * T Tin Sets input tint to
Increment up +T Tin Increment input tint one step
Decrement down –T Tin Decrement input tint one step
Input Window Selection
Window on b Blk 0 Sets input window on
Window off B Blk 1 Sets input window off
All windows on b Blk 0 Sets all windows on
All windows off B Blk 1 Sets all windows off
Freeze Window
Enable freeze mode F Frz 1 Set input freeze mode on (freeze current image)
Disable freeze mode f Frz 0 Set input freeze mode off
Enable freeze all F Frz 1 Set freeze mode for all windows on
Disable freeze all f Frz 0 Set freeze mode for all windows off
Output Background Color
Background color 1*e# Bkg
e
Display background color
e
Window Priority
Window priority ~ Pri Set priority of all input
windows where the leftmost
corresponds to the window
that is first in priority (on the
top), the next to the right is
the window that is second in
priority (just below the top),
etc.
Audio Input Selection
Audio selection $ Aud Connect audio output to audio input , or no
audio ( = 0)
Window Borders
Borders on K Bdr 1 Enable window borders
Borders off k Bdr 0 Disable window borders
Write Window Name
Write name
Esc
N
f
Nam Display input window name
MVP 104GX Programmer’s Guide 5-5
Programmer’s Guide, cont’d
COMMAND ASCII RESPONSE DESCRIPTION
Audio Channel Gain
Audio gain * GIn•Aud= Set audio gain for input to
Audio Channel Attenuation
Audio gain * gIn•Aud= Set audio attenuation for input to
View Audio Input Channel Gain
View audio gain GIn•Aud= Display audio gain for input
View audio gain gIn•Aud= Display audio gain for input
User Preset Recall
Recall user preset . Rpr Recall user preset
User Preset Save
Save user preset , Spr Save user preset
Factory Patterns Recall
Recall factory pattern . Rpr Recall factory pattern
Executive Mode
Enable executive mode X Exe 1 Set executive mode on Disable
executive mode x Exe 0 Set executive mode off
VCR Mode
Enable VCR mode D Det1 Set VCR mode for a window on
Disable VCR mode d Det0 Set VCR mode for a window off
Enable VCR mode for all D Det1 Set VCR mode for all windows on
Disable VCR mode for all d Det0 Set VCR mode for all windows off
Chroma
Enable chroma J Kro1 Set chroma for a window on
Disable chroma j Kro0 Set chroma for a window off
Enable chroma for all J Kro1 Set chroma for all windows on
Disable chroma for all j Kro0 Set chroma for all windows off
Text Location
Set text location 2*k# Tlc
k
Set window text location
Text Style
Set text style 3*l# Txs
l
Set window text style
Autoblanking
Set autoblanking 4* # Abl Set window autoblanking
Video Input Type
Set video input type 1 1*j\ TpA
Set video input type 2 2*j\ TpB
j
j
Specify video input type 1
Specify video input type 2
Video Output Type
Set video output type 0*i\ TpO
i
Specify composite video output type
Query Firmware Version
Query firmware version Q/q Ver x.xx Display firmware version
Request Part Number
Request part number N/n Nxx-xxx-xx Display Extron part number
5-6
MVP 104GX Programmer’s Guide
COMMAND ASCII RESPONSE
Request Information
General I/i A •Aud •Pri •Bdr •Bkge•Exe •Abl •TpO
•TpAj•TpBj•Tlck•Txs
Current picture control IT
h
•Aud •Col •Tin •Con •Brt •Frz •Blk •Det
•Kro •[f]
Current windowing i Hph •Hsz •Vph •Vsz •Bltg•Blbg•Bllg•Blr
User preset picture * ITh•Aud •Col •Tin •Con •Brt •Frz •Blk •Det
control •Kro •[f]
l
g
i
User preset windowing * i Hph •Hsz •Vph •Vsz •Bltg•Blbg•Bllg•Blr
g
Factory pattern picture * ITh•Aud •Col •Tin •Con •Brt •Frz •Blk •Det
control •Kro •[f]
Factory pattern * i Hph •Hsz •Vph •Vsz •Bltg•Blbg•Bllg•Blr
g
windowing
General user presets *0I A •Aud •Pri •Bdr •Bkg
TpOi•TpAj•TpB
j•Tlck•Txs
General factory patterns *0I A •Aud •Pri •Bdr •Bkg
TpOi•TpAj•TpB
j•Tlck•Txs
e•Exe •Abl •
l
e•Exe •Abl •
l
Example responses to commands
1. Response to Request general information (I/i) command:
A1•Aud+06•Pri2314•Bdr1•Bkg2•Exe0•Abl1•TpO2•TpA1•TpB2•
Tlc3•Txs0
Audio input selection (A) = input 1
Audio gain (Aud) = +06
Window priority (Pri) = 2314, where window 2 is on the top,
followed by window 3, then window 1, and window 4 is
on the bottom, if windows overlap.
Window borders (Bdr) = 1 (on)
Background color (Bkg) = 2 (cyan)
Executive mode (Exe) = 0 (off)
Autoblanking (Abl) = 1 (on)
Video output type (TpO) = 2 (PAL)
Video input 1 type (TpA) = 1 (auto)
Video input 2 type (TpB) = 2 (composite)
Text location (Tlc) = 3 (top right)
Text style (Txs) = 0 (off, i.e. solid)
2. Response to Request User preset picture control information command
(3*2I) with User preset = 3 and Input = 2:
MVP 104GX Programmer’s Guide
5-7
Programmer’s Guide, cont’d
T2•Aud+02•Col100•Tin22•Con95•Brt20•Frz0•Blk0•Det1
•Kro1•[FEW WORDS]
The following response example refers to input 2.
Video type detected (T) = 2 (PAL)
Audio gain (Aud) = +02dB
Picture color (Col) = 100
Picture tint (Tin) = 22
Picture contrast (Con) = 95
Picture brightness (Brt) = 20
Freeze window (Frz) = 0 (off, i.e. image not frozen)
Window blanking (Blk) = 0 (blanking off, i.e. window is visible)
Enable VCR mode (Det) = 1 (on)
Enable Chroma (Kro) = 1 (on)
Window text ([]) = FEW WORDS (user-defined text)
MVP 104GX error responses
When the MVP 104GX receives an SIS command and determines that it is
valid, it performs the command and sends a response to the host device. If
the MVP 104GX is unable to perform the command because the command is
invalid or contains invalid parameters, the MVP 104GX returns an error
response to the host. The error response codes are:
E01 — Invalid input number
E09 — Invalid function number (too large)
E10 — Invalid command
E11 — Invalid preset
E13 — Invalid value (out of range)
MVP 104GX-generated unsolicited responses
Whenever there is a front panel operation (only), the MVP 104GX responds
by sending an unsolicited response (Reconfig##) to the Host. Use the 2 digit
code ## to locate the event below.
Reconfig00 = More than one window configuration changed
Reconfig01 = Window 1’s configuration changed
Reconfig02 = Window 2’s configuration changed
Reconfig03 = Window 3’s configuration changed
Reconfig04 = Window 4’s configuration changed
Reconfig20 = Audio selection changed
5-8
MVP 104GX Programmer’s Guide
MVP 104GX
Appendix
A
Reference Information
Configuring the MVP 104GX for RS-422
Specifications
MVP 104 Programmer’s Guide
Reference Information
Configuring the MVP 104GX for RS-422
The MVP 104GX comes configured from the factory for RS-232 communications. If
an RS-422 configuration is required, follow the procedures below. The procedures
involve removing the top cover, relocating the serial port ribbon cable, setting the
jumper, and replacing the top cover.
Removing the top cover
The top cover of the MVP 104GX must first be removed to gain access to the ribbon
cable and jumper.
1. Disconnect the power cord from the MVP 104GX.
2. If the MVP 104GX is rack mounted, remove the MVP from the rack.
3. Remove the fourteen screws which secure the top cover of the
MVP 104GX, as shown in figure A-1.
Lift Cover
straight up
A
5
.
0
z
H
0
6
/
0
5
V
0
4
2
-
0
0
1
S
T
U
3L
P
N
I
T
U
R
P
T
2
U
O
L
R
1
L
4
T
A
U
P
N
I
C
3
T
U
P
N
B
IN
I
IN
2
T
T
U
U
O
P
N
I
T
U
O
IN
1
T
U
P
N
I
T
U
O
N
I
T
U
O
R
4
LR
2
2
-4
S
/R
2
3
-2
S
R
T
U
P
T
E
U
T
R
O
O
M
1
E
R
L
Remove (14)
Screws
Figure A-1 — Top cover removal
4. Lift the cover straight up and set it aside.
Relocating the ribbon cable and setting the jumper
If the MVP 104GX is currently configured for RS-232 communication, the ribbon
cable must be relocated and the jumper must be reset for RS-422 communication.
See figure A-2.
1. Disconnect the ribbon cable from the RS-232 receptacle, noting that the
2. Reconnect the ribbon cable to the RS-422 receptacle, as shown in
A-2
MVP 104GX Reference Information
red stripe of the cable is positioned relative to pin #1 of the receptacle.
Both RS-232 and RS-422 receptacles are mounted with pin #1 located on the
same side, relative to the circuit board.
figure A-2. The red stripe of the ribbon cable must be positioned relative
to pin #1 of the RS-422 receptacle.
3
1
1
RS-232 RS-422
J23
IN
OUT
IN
IN
P
U
T
1
OUT
IN
P
U
IN
T
2
IN
IN
OUT
P
U
T
3
IN
OUT
A
P
U
T
4
B
O
U
T
P
U
T
C
1L
R
INPUTS
L
2
R3
L
R4L
R
O
U
T
P
U
L
T
1
R
Ribbon Cable
G
E
N
L
O
C
K
IN
R
S
-2
3
2
/4
2
2
O
U
T
R
E
M
O
T
E
RS-422 Pin Connector
RS-232 Pin Connector
Figure A-2 — RS-232 to RS-422 cable and jumper positioning
3. Remove and replace the jumper on the alternate jumper position, as
shown in figure A-2.
3
3
1
Replacing the top cover
1. Before replacing the top cover, be sure that all internal wiring is safely
within the enclosure.
2. Carefully position the top cover and replace the fourteen screws which
were previously removed.
3. Attach the power cord to the MVP 104GX and plug the cord into an AC
power source. Check that the MVP 104GX is operating properly.
4. If the MVP 104GX is to be rack mounted, disconnect the power cord and
install the MVP 104GX in a rack, then reattach the power cord.
MVP 104GX Reference Information A-3
Specifications — MVP 104GX
Video
Gain ................................................ Unity
Differential phase error .............. 1.5º, 0 to 10 MHz
Differential gain error ................. 1.5%, 0 to 10 MHz
Video input and loopthrough
Number/signal type ................... 4 S-video, 8 NTSC/PAL composite video
Connectors ................................... 4 4-pin mini-DIN female ....... S-video
8 BNC female .......................... composite video
Minimum/maximum level(s) .... 2.0V p-p
Impedance .................................... 75 ohms
Vertical frequency ....................... 50 Hz to 60 Hz
Video processing
Encoder ......................................... 10 bit digital
Video output
Number/signal type ................... 1 S-video, 2 composite video
Connectors ................................... 1 4-pin mini-DIN female ....... S-video
2 BNC female ......................... composite video
Nominal level ............................... S-video ....................... 0.7V p-p Y, 0.288V p-p C (burst)
Composite video ..... 0.5V to 1V p-p
Impedance .................................... 75 ohms
Sync
Standards ...................................... NTSC 3.58, PAL
Audio
Gain ................................................ Unbalanced 0dB, balanced +6dB
Frequency response .................... 20 Hz to 20 kHz, ±0.05dB
THD + Noise................................. 0.03% @ 1 kHz, 0.3% @ 20 kHz at rated maximum output drive
(+19.5dBu input, +21dBu output, balanced/unbalanced)
S/N ................................................ >90dB, output +21dBu, balanced, at rated maximum output drive
Crosstalk ....................................... <-80dB @ 1 kHz
Stereo channel separation .......... >80dB @ 1 kHz
CMRR ............................................ >75dB @ 20 Hz to 20 kHz
Audio input
Number/signal type ................... 4 stereo, balanced/unbalanced
Connectors ................................... 4 3.5 mm captive screw connectors, 5-pole
Impedance .................................... >50 kohms unbalanced, 25 kohms balanced, DC coupled
Minimum level ............................. -10dBu for full power out
Maximum input level .................. +19.5dBu (balanced/unbalanced) @ stated %THD+N
Input gain adjustment ................. -15dB to +9dB, adjustable per input via RS-232 or front panel
Audio output
Number/signal type ................... 1 stereo, balanced/unbalanced
A-4
MVP 104GX Reference Information
Connectors ................................... 1 3.5 mm captive screw connector, 5-pole
Impedance .................................... 50 ohms unbalanced, 100 ohms balanced
Gain error ..................................... ±0.1dB channel to channel
Maximum level (Hi-Z) ................ >+21dBu, balanced at stated %THD+N
Maximum level (600 ohm) ......... >+15dBu, balanced at stated %THD+N
0dBu = 0.775 volts (RMS).
Control/remote — video processor
Serial control port ........................ RS-232/RS-422, 9-pin female D connector
Baud rate and protocol ............... 9600, 8-bit, 1 stop bit, no parity
Serial control pin configurations .... 2 = TX, 3 = RX, 5 = GND
Program control .......................... Extron’s control program for Windows®
Extron’s Simple Instruction Set™ – SIS™
General
Power ............................................ 100VAC to 240VAC, 50/60 Hz, 40 watts, internal
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) / 10% to 90%, non-condensing
Operating +32° to +122°F (0° to +50°C) / 10% to 90%, non-condensing
Rack mount .................................. Yes
Enclosure type .............................. Metal
Enclosure dimensions ................. 3.4" H x 17.5" W x 9.5" D (2U high, full rack width)
8.6 cm H x 44.4 cm W x 24.1 cm D
(Depth excludes connectors and knobs. Width excludes rack ears.)
Product weight............................. 6.9 lbs (3.2 kg)
Shipping weight ........................... 13 lbs (5.9 kg)
Vibration ....................................... ISTA/NSTA 1A in carton (International Safe Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
Specifications are subject to change without notice.
MVP 104GX Reference Information
A-5
A-6
MVP 104GX Reference Information
FCC Class A Notice
Note: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference, in which case the user will be required to correct the interference at his own expense.
Note: This unit was tested with shielded cables on the peripheral devices. Shielded cables must be
used with the unit to ensure compliance.
Extron’s Warranty
Extron Electronics warrants this product against defects in materials and workmanship for a period
of three years from the date of purchase. In the event of malfunction during the warranty period
attributable directly to faulty workmanship and/or materials, Extron Electronics will, at its option,
repair or replace said products or components, to whatever extent it shall deem necessary to restore
said product to proper operating condition, provided that it is returned within the warranty period,
with proof of purchase and description of malfunction to:
USA, Canada, South America, Europe, Africa, and the Middle East:
and Central America:
Extron Electronics, Europe
Extron Electronics Beeldschermweg 6C
1230 South Lewis Street 3821 AH Amersfoort
Anaheim, CA 92805, USA The Netherlands
Asia: Japan:
Extron Electronics, Japan
Extron Electronics, Asia Daisan DMJ Bldg. 6F,
135 Joo Seng Road, #04-01 3-9-1 Kudan Minami
PM Industrial Bldg. Chiyoda-ku, Tokyo 102-0074
Singapore 368363 Japan
This Limited Warranty does not apply if the fault has been caused by misuse, improper handling
care, electrical or mechanical abuse, abnormal operating conditions or non-Extron authorized
modification to the product.
If it has been determined that the product is defective, please call Extron and ask for an Applications
Engineer at (714) 491-1500 (USA), 31.33.453.4040 (Europe), 65.6383.4400 (Asia), or 81.3.3511.7655 (Japan)
to receive an RA# (Return Authorization number). This will begin the repair process as quickly as
possible.
Units must be returned insured, with shipping charges prepaid. If not insured, you assume the risk
of loss or damage during shipment. Returned units must include the serial number and a
description of the problem, as well as the name of the person to contact in case there are any
questions.
Extron Electronics makes no further warranties either expressed or implied with respect to the
product and its quality, performance, merchantability, or fitness for any particular use. In no event
will Extron Electronics be liable for direct, indirect, or consequential damages resulting from any
defect in this product even if Extron Electronics has been advised of such damage.
Please note that laws vary from state to state and country to country, and that some provisions of
this warranty may not apply to you.
Extron Electronics, USA
1230 South Lewis Street
Anaheim, CA 92805
USA
www.extron.com
714.491.1500
Fax 714.491.1517
Extron Electronics, Europe
Beeldschermweg 6C
3821 AH Amersfoort
The Netherlands
+31.33.453.4040
Fax +31.33.453.4050
Extron Electronics, Asia
135 Joo Seng Road, #04-01
PM Industrial Building
Singapore 368363
+65.6383.4400
Fax +65.6383.4664
© 2002 Extron Electronics. All rights reserved.
Extron Electronics, Japan
Daisan DMJ Building 6F
3-9-1 Kudan Minami
Chiyoda-ku, Tokyo 102-0074 Japan
+81.3.3511.7655
Fax +81.3.3511.7656
Loading...
