Extron Electronics MTP SW6 User Manual

Download

MTP SW6

Six Input MTP Twisted Pair Switcher

User Manual

Twisted Pair

68-1462-01 Rev. B

02 10

Safety Instructions • English

This symbol is intended to alert the user of important operating and maintenance (servicing) instructions in the literature provided with the equipment.

This symbol is intended to alert the user of the presence of uninsulated dangerous voltage within the product’s enclosure that may present a risk of electric shock.

Caution

Read Instructions • Read and understand all safety and operating instructions before using the equipment. Retain Instructions • The safety instructions should be kept for future reference. Follow Warnings • Follow all warnings and instructions marked on the equipment or in the user information. Avoid Attachments • Do not use tools or attachments that are not recommended by the equipment

manufacturer because they may be hazardous.

Warning

Power sources • This equipment should be operated only from the power source indicated on the product. This

equipment is intended to be used with a main power system with a grounded (neutral) conductor. The third (grounding) pin is a safety feature, do not attempt to bypass or disable it.

Power disconnection • To remove power from the equipment safely, remove all power cords from the rear of

the equipment, or the desktop power module (if detachable), or from the power source receptacle (wall plug).

Power cord protection • Power cords should be routed so that they are not likely to be stepped on or pinched

by items placed upon or against them.

Servicing • Refer all servicing to qualiﬁed service personnel. There are no user-serviceable parts inside. To prevent

the risk of shock, do not attempt to service this equipment yourself because opening or removing covers may expose you to dangerous voltage or other hazards.

Slots and openings • If the equipment has slots or holes in the enclosure, these are provided to prevent

overheating of sensitive components inside. These openings must never be blocked by other objects.

Lithium battery • There is a danger of explosion if battery is incorrectly replaced. Replace it only with the

same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions.

Consignes de Sécurité • Français

Ce symbole sert à avertir l’utilisateur que la documentation fournie avec le matériel contient des instructions importantes concernant l’exploitation et la maintenance (réparation).

Ce symbole sert à avertir l’utilisateur de la présence dans le boîtier de l’appareil de tensions dangereuses non isolées posant des risques d’électrocution.

Attention

Lire les instructions• Prendre connaissance de toutes les consignes de sécurité et d’exploitation avant

d’utiliser le matériel.

Conserver les instructions• Ranger les consignes de sécurité aﬁn de pouvoir les consulter à l’avenir. Respecter les avertissements • Observer tous les avertissements et consignes marqués sur le matériel ou

présentés dans la documentation utilisateur.

Sicherheitsanleitungen • Deutsch

Dieses Symbol soll dem Benutzer in der im Lieferumfang enthaltenen Dokumentation besonders wichtige Hinweise zur Bedienung und Wartung (Instandhaltung) geben.

Dieses Symbol soll den Benutzer darauf aufmerksam machen, daß im Inneren des Gehäuses dieses Produktes gefährliche Spannungen, die nicht isoliert sind und die einen elektrischen Schock verursachen können, herrschen.

Achtung

Lesen der Anleitungen • Bevor Sie das Gerät zum ersten Mal verwenden, sollten Sie alle Sicherheits-und

Bedienungsanleitungen genau durchlesen und verstehen.

Aufbewahren der Anleitungen • Die Hinweise zur elektrischen Sicherheit des Produktes sollten Sie

aufbewahren, damit Sie im Bedarfsfall darauf zurückgreifen können.

Befolgen der Warnhinweise • Befolgen Sie alle Warnhinweise und Anleitungen auf dem Gerät oder in der

Benutzerdokumentation.

Keine Zusatzgeräte • Verwenden Sie keine Werkzeuge oder Zusatzgeräte, die nicht ausdrücklich vom

Hersteller empfohlen wurden, da diese eine Gefahrenquelle darstellen können.

Instrucciones de seguridad • Español

Este símbolo se utiliza para advertir al usuario sobre instrucciones importantes de operación y mantenimiento (o cambio de partes) que se desean destacar en el contenido de la documentación suministrada con los equipos.

Este símbolo se utiliza para advertir al usuario sobre la presencia de elementos con voltaje peligroso sin protección aislante, que puedan encontrarse dentro de la caja o alojamiento del producto, y que puedan representar riesgo de electrocución.

Precaucion

Leer las instrucciones • Leer y analizar todas las instrucciones de operación y seguridad, antes de usar el

equipo.

Conservar las instrucciones • Conservar las instrucciones de seguridad para futura consulta. Obedecer las advertencias • Todas las advertencias e instrucciones marcadas en el equipo o en la

documentación del usuario, deben ser obedecidas.

安全须知 • 中文

这个符号提示用户该设备用户手册中有重要的操作和维护说明。

这个符号警告用户该设备机壳内有暴露的危险电压，有触电危险。

注意

阅读说明书 • 用户使用该设备前必须阅读并理解所有安全和使用说明。保存说明书 • 用户应保存安全说明书以备将来使用。遵守警告 • 用户应遵守产品和用户指南上的所有安全和操作说明。避免追加 • 不要使用该产品厂商没有推荐的工具或追加设备，以避免危险。

Eviter les pièces de ﬁxation • Ne pas utiliser de pièces de ﬁxation ni d’outils non recommandés par le fabricant

du matériel car cela risquerait de poser certains dangers.

Avertissement

Alimentations • Ne faire fonctionner ce matériel qu’avec la source d’alimentation indiquée sur l’appareil. Ce

matériel doit être utilisé avec une alimentation principale comportant un ﬁl de terre (neutre). Le troisième contact (de mise à la terre) constitue un dispositif de sécurité : n’essayez pas de la contourner ni de la désactiver.

Déconnexion de l’alimentation• Pour mettre le matériel hors tension sans danger, déconnectez tous les

cordons d’alimentation de l’arrière de l’appareil ou du module d’alimentation de bureau (s’il est amovible) ou encore de la prise secteur.

Protection du cordon d’alimentation • Acheminer les cordons d’alimentation de manière à ce que personne

ne risque de marcher dessus et à ce qu’ils ne soient pas écrasés ou pincés par des objets.

Réparation-maintenance • Faire exécuter toutes les interventions de réparation-maintenance par un

technicien qualiﬁé. Aucun des éléments internes ne peut être réparé par l’utilisateur. Aﬁn d’éviter tout danger d’électrocution, l’utilisateur ne doit pas essayer de procéder lui-même à ces opérations car l’ouverture ou le retrait des couvercles risquent de l’exposer à de hautes tensions et autres dangers.

Fentes et oriﬁces • Si le boîtier de l’appareil comporte des fentes ou des oriﬁces, ceux-ci servent à empêcher les

composants internes sensibles de surchauffer. Ces ouvertures ne doivent jamais être bloquées par des objets.

Lithium Batterie • Il a danger d’explosion s’ll y a remplacment incorrect de la batterie. Remplacer uniquement

avec une batterie du meme type ou d’un ype equivalent recommande par le constructeur. Mettre au reut les batteries usagees conformement aux instructions du fabricant.

Vorsicht

Stromquellen • Dieses Gerät sollte nur über die auf dem Produkt angegebene Stromquelle betrieben werden.

Dieses Gerät wurde für eine Verwendung mit einer Hauptstromleitung mit einem geerdeten (neutralen) Leiter konzipiert. Der dritte Kontakt ist für einen Erdanschluß, und stellt eine Sicherheitsfunktion dar. Diese sollte nicht umgangen oder außer Betrieb gesetzt werden.

Stromunterbrechung • Um das Gerät auf sichere Weise vom Netz zu trennen, sollten Sie alle Netzkabel aus der

Rückseite des Gerätes, aus der externen Stomversorgung (falls dies möglich ist) oder aus der Wandsteckdose ziehen.

Schutz des Netzkabels • Netzkabel sollten stets so verlegt werden, daß sie nicht im Weg liegen und niemand

darauf treten kann oder Objekte darauf- oder unmittelbar dagegengestellt werden können.

Wartung • Alle Wartungsmaßnahmen sollten nur von qualiﬁziertem Servicepersonal durchgeführt werden.

Die internen Komponenten des Gerätes sind wartungsfrei. Zur Vermeidung eines elektrischen Schocks versuchen Sie in keinem Fall, dieses Gerät selbst öffnen, da beim Entfernen der Abdeckungen die Gefahr eines elektrischen Schlags und/oder andere Gefahren bestehen.

Schlitze und Öffnungen • Wenn das Gerät Schlitze oder Löcher im Gehäuse aufweist, dienen diese zur

Vermeidung einer Überhitzung der empﬁndlichen Teile im Inneren. Diese Öffnungen dürfen niemals von anderen Objekten blockiert werden.

Litium-Batterie • Explosionsgefahr, falls die Batterie nicht richtig ersetzt wird. Ersetzen Sie verbrauchte Batterien

nur durch den gleichen oder einen vergleichbaren Batterietyp, der auch vom Hersteller empfohlen wird. Entsorgen Sie verbrauchte Batterien bitte gemäß den Herstelleranweisungen.

Evitar el uso de accesorios • No usar herramientas o accesorios que no sean especiﬁcamente recomendados

por el fabricante, ya que podrian implicar riesgos.

Advertencia

Alimentación eléctrica • Este equipo debe conectarse únicamente a la fuente/tipo de alimentación eléctrica

indicada en el mismo. La alimentación eléctrica de este equipo debe provenir de un sistema de distribución general con conductor neutro a tierra. La tercera pata (puesta a tierra) es una medida de seguridad, no puentearia ni eliminaria.

Desconexión de alimentación eléctrica • Para desconectar con seguridad la acometida de alimentación

eléctrica al equipo, desenchufar todos los cables de alimentación en el panel trasero del equipo, o desenchufar el módulo de alimentación (si fuera independiente), o desenchufar el cable del receptáculo de la pared.

Protección del cables de alimentación • Los cables de alimentación eléctrica se deben instalar en lugares

donde no sean pisados ni apretados por objetos que se puedan apoyar sobre ellos.

Reparaciones/mantenimiento • Solicitar siempre los servicios técnicos de personal caliﬁcado. En el interior no

hay partes a las que el usuario deba acceder. Para evitar riesgo de electrocución, no intentar personalmente la reparación/mantenimiento de este equipo, ya que al abrir o extraer las tapas puede quedar expuesto a voltajes peligrosos u otros riesgos.

Ranuras y aberturas • Si el equipo posee ranuras o oriﬁcios en su caja/alojamiento, es para evitar el

sobrecalientamiento de componentes internos sensibles. Estas aberturas nunca se deben obstruir con otros objetos.

Batería de litio • Existe riesgo de explosión si esta batería se coloca en la posición incorrecta. Cambiar esta

batería únicamente con el mismo tipo (o su equivalente) recomendado por el fabricante. Desachar las baterías usadas siguiendo las instrucciones del fabricante.

警告

电源 • 该设备只能使用产品上标明的电源。设备必须使用有地线的供电系统供电。第三条线

（地线）是安全设施，不能不用或跳过。

拔掉电源 • 为安全地从设备拔掉电源，请拔掉所有设备后或桌面电源的电源线，或任何接到市

电系统的电源线。

电源线保护 • 妥善布线，避免被踩踏，或重物挤压。维护 • 所有维修必须由认证的维修人员进行。设备内部没有用户可以更换的零件。为避免出现

触电危险不要自己试图打开设备盖子维修该设备。

通风孔 • 有些设备机壳上有通风槽或孔，它们是用来防止机内敏感元件过热。不要用任何东

西挡住通风孔。

锂电池 • 不正确的更换电池会有爆炸的危险。必须使用与厂家推荐的相同或相近型号的电池。

按照生产厂的建议处理废弃电池。

FCC Class A Notice

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause undesired operation.

The Class A limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at his own expense.

Trademarks

All trademarks mentioned in this manual are the properties of their respective owners.

Contents

Introduction ............................................ 1

About this Manual ........................................... 1

About the MTP SW6 Switcher .......................... 1

RS-232 Function .......................................... 2

Twisted Pair (TP) Cable Advantages .............. 3

Features ........................................................... 5

Installation and Operation ..................... 6

Mounting the MTP SW6 .................................. 6

Tabletop Use ................................................ 6

Rack Shelf Mounting .................................... 6

Furniture Mounting ...................................... 8

Connectors and Settings .................................. 9

Making Connections .................................. 12

Receiver Considerations ............................. 14

Operation ...................................................... 15

Switch Mode ............................................. 16

Optimizing the Video ..................................... 17

Level/Peaking Setting ................................. 17

Skew Delay Compensation ......................... 18

Remote Control ......................................19

Simple Instruction Set™ Control ...................... 20

Host-to-Interface Communications ............. 20

Symbol Deﬁnitions ..................................... 20

Unit-Initiated Messages .............................. 21

Error Responses.......................................... 21

Timeout ..................................................... 22

Using the Command/Response Table .......... 22

Command/response Table

for SIS Commands ..................................... 23

Windows-Based Program Control .................. 26

Installing the Software ............................... 26

Using the Software .................................... 27

Contact Closure Remote Control ................... 27

IR 102 Infrared Remote Control ..................... 28

Reference Information ..........................29

Speciﬁcations ................................................. 29

Part Numbers ................................................. 31

Included Parts ............................................ 31

Accessories ................................................ 31

Cables ....................................................... 31

Connectors ................................................ 32

MTP SW6 • Contents iv

Introduction

This section gives an overview of the manual and describes the Extron® MTP SW6 and its features, including:

• About this Manual

• About the MTP SW6 Switcher

• Features

About this Manual

This manual describes the function, installation, conﬁguration, and operation of the MTP SW6 twisted pair switcher.

About the MTP SW6 Switcher

The Extron MTP SW6 is a 6-input, 1-output twisted pair switcher that is compatible with the entire line of Extron MTP transmitters and receivers.

The Extron MTP transmitters and receivers are a system for long-distance distribution of video and either audio or RS-232 communications. The MTPs transmit and receive over Extron Enhanced Skew-Free™ A/V UTP cable or over CAT 5, 5e, or 6 shielded twisted pair (STP), unshielded twisted pair (UTP), or foil shielded twisted pair (FTP) cable.

The MTP switcher receives up to six sets of signals from compatible MTP devices on RJ-45 connectors (ﬁgure 1). You can select one input to output to a compatible MTP device on an RJ-45 connector. The signal sets are comprised of high or low resolution video signals (RGB, bi-level or tri-level component video, S-video, or composite video) and can also include either RS-232 serial signals or audio.

VCR

™

Extro n MTP SW6

Mini Twisted Pair Switcher

AUDIO IN

COMPUTER IN

Extro n MTP T 15HD A D

Transmitter

POWER 12V

0.5A MAX

1 2 3 4 5 6

Extro n MTP T 15HD A AAP

Transmitter

Laptop

TouchLink

Control System

RS-232 INSERT

SPARE

Tx Rx

MONO AUDIO OUTPUT

PRE-PEAK

OUTPUT

OFF

INPUT

COMPUTER

AUDIO IN

MTP T 15HD A

DVD

DOC CAM

LAPTOP

OFF

DISPLAY MUTE

SCREEN UP

SCREEN DOWN

TCP/IP

100

RELAY

LINK

ACT

INPUT

3 1

COM

IPL 250

Switcher Control

MTP SW6

REMOTE

Display Control

Extro n MTP U R RSA SEQ

Universal R eceiver

Extro n

INPUT INPUT

INPUT

L R

MTP T SV A

Transmitter

MTP T SV A

S-VIDEO OUTPUT

MAX

12V

0.5a

OUTPUTS

B-Y

R-Y

RGB

POWER

12V

0.5A MAX

INPUT

YUV

AUDIO IN

COMPUTER IN

MTP T 15HD A

XPA 1002

2 1

LIMITER/PROTECT

Extro n

SIGNAL OVER TEMP

XPA 1002

Power Amplier

Audio

RS-232

SPACE

S-video

Tx Rx

MONO AUDIO

VID

Y/C

RGBHV

Extro n MTP T 15HD A WM

Transmitter

Extro n SI 28

Surface -mount Speakers

RS-232

Flat Panel Display with Speaker s

Blu-ray Playe r

DVD

Laptop

Figure 1. Typical MTP SW6 application

MTP SW6 • Introduction 1

NOTE: The remote power capabilities of certain MTP models are not supported by this

switcher.

The MTP switcher has image enhancement features that allow you to correct for long distance transmissions and skew:

• Level and Peaking controls enhance the TP signals received on the inputs.

• A Pre-Peaking control enhances the TP output for optimum display.

• Delay (skew correction) controls correct for skew delay (misconvergence) commonly

encountered when using CAT 5, 5e, or 6 TP cables for RGB video, and component video transmission.

NOTE: Skew correction should not be necessary when Extron Enhanced Skew-Free

A/V UTP cable is used and the transmission distance is less than 1,000 feet (300 m).

Bidirectional RS-232 signal from a dedicated source (rather than from the selected input) can be directly inserted into the signal set routed to the TP output. You can even route RS-232 on a link that is normally audio, such as to an MTP R 15HD RSA D receiver, which can autodetect whether the signal input to it includes an audio component or an RS-232 component.

The MTP switcher is housed in a rack-mountable, 1U high, half rack-width metal enclosure. This switcher is shipped with an external 12 V power supply that accepts 100 to 240 VAC, 50 Hz or 60 Hz input and provides worldwide power compatibility.

RS-232 Function

When the TP link includes RS-232 signals, they are unidirectional (switcher to receiver).

NOTE: The RS-232 insert signal path is bidirectional.

The RS-232 link:

• Supports software ﬂow control (XON, XOFF).

NOTE: Hardware ﬂow control is not supported.

• Supports full duplex and half duplex operation.

• Supports baud rates up to 38,400, data bits, parity, stop bits, and data format without

conﬁguration.

NOTE: Higher rates are possible, but performance will vary as a function of baud

rate and TP cable length.

MTP SW6 • Introduction 2

Twisted Pair (TP) Cable Advantages

Twisted pair cable is much smaller, lighter, more ﬂexible, and less expensive than coaxial cable. These TP products make cable runs simpler and less cumbersome. Termination of the cable with RJ-45 connectors is simple, quick, and economical.

Transmission distance

NOTE: VGA video transmitters provide pre-peaking, which boosts the signal before it is

transmitted.

The maximum distance is determined by the frequency and resolution of the signal that is input to the transmitter. Figure 2 and Table 1, on the next page, deﬁne the switcher

input cables ( transmission distances on the input and output. Table 1 also deﬁnes the output Pre-Peak switch positions (item d on page 10) using Extron Enhanced Skew-Free A/V UTP cable or UTP CAT 5, 5e, or 6 cable, terminated with RJ-45 connectors.

NOTES: • It is possible to exceed the recommended distance; however, image quality

• The MTP units are designed for and perform best with Extron Enhanced

• Resolutions marked with an asterisk in table 1 have the same range

) and output cables (2) and specify the recommended maximum

may be reduced.

Skew-Free A/V cable terminated in accordance with the TIA/EIA T 568 A wiring standard. CAT 5, 5e, and 6 cables are acceptable, but less preferable. We also recommend the use of preterminated and tested cables. Cables terminated on site should be tested before use to ensure that they comply with Category 5 speciﬁcations.

speciﬁcations at 75 Hz.

MTP SW6 • Introduction 3

AUDIO

MTP T 15HD A

PRE-PEAK

POWER

12V .5A MAX

INPUT

MTP Transmitter

OFF

OUTPUT

MONITOR

POWER

12V

0.5A MAX

1 2 3 4 5 6

MTP Receiver

MTP SW6

RS-232 INSERT

OUTPUT

INPUT

PRE-PEAK

OFF

Tx Rx

MONO AUDIO OUTPUT

L R

REMOTE

SPARE

OUTPUTS

MTP U R A

POWER

VID

12V

0.5A MAX

MONO AUDIO

Y/C

RGB

INPUT

Figure 2. Transmission cables

Table 1. Recommended transmission distances at 60 Hz

Video

format

MTP SW6 Pre-Peak High quality Variable quality

Off On Input

Output

Input

Output

Component, S-video,

<300' (90 m) >350' (105 m) 700' (215 m) 700 (215 m) 700' (215 m) 800 (245 m)

composite 640 x 480 <300' (90 m) >350' (105 m) 550' (170 m) 600' (185 m) 550' (170 m) 700' (215 m) 800 x 600 <300' (90 m) >350' (105 m) 500' (150 m) 500' (150 m) 600' (185 m) 600' (185 m) 1024 x 768* <300' (90 m) >350' (105 m) 450' (135 m) 450' (135 m) 550' (170 m) 550' (170 m) 1280 x 960* <300' (90 m) >350' (105 m) 350' (105 m) 350' (105 m) 450' (135 m) 450' (135 m) 1280 x 1024* <250' (75 m) >300' (90 m) 350' (105 m) 350' (105 m) 450' (135 m) 450' (135 m) 1360 x 765 <250' (75 m) >300' (90 m) 350' (105 m) 350' (105 m) 500' (150 m) 500' (150 m) 1365 x 768 <250' (75 m) >300' (90 m) 350' (105 m) 350' (105 m) 450' (135 m) 450' (135 m) 1366 x 768 <250' (75 m) >300' (90 m) 350' (105 m) 350' (105 m) 450' (135 m) 450' (135 m) 1440 x 900 <250' (75 m) >300' (90 m) 350' (105 m) 300' (90 m) 400' (120 m) 400' (120 m) 1400 x 1050 <250' (75 m) >300' (90 m) 350' (105 m) 300' (90 m) 400' (120 m) 400' (120 m) 1600 x 1200* <250' (75 m) >300' (90 m) 300' (90 m) 300' (90 m) 450' (135 m) 450' (135 m) 1920 x 1200 <250' (75 m) >300' (90 m) 300' (90 m) 250' (75 m) 400' (120 m) 400' (120 m) HDTV 720p <250' (75 m) >300' (90 m) 400' (120 m) 400' (120 m) 500' (150 m) 500' (150 m) HDTV 1080i <250' (75 m) >300' (90 m) 300' (90 m) 250' (75 m) 400' (120 m) 400' (120 m) HDTV 1080p <250' (75 m) >300' (90 m) 300' (90 m) 250' (75 m) 400' (120 m) 400' (120 m)

MTP SW6 • Introduction 4

Features

Compatible with all Extron MTP Series Twisted Pair products — Broad compatibility with all MTP products enables design ﬂexibility when selecting components, and allows the use of an economical CAT 5-type cable infrastructure for A/V system integration.

Dynamic input skew equalization — Adjustments are stored in memory for each input, maintaining RGB color alignment at all times.

Video level and peaking compensation on each input — Actively compensates for input signal attenuation for various cable lengths, resulting in a brighter and sharper image.

Switchable video pre-peaking for output — Provides additional compensation for optimal performance on the longest cable runs, ensuring the highest quality signal at the display.

Local dual mono audio output — A line level output on the product splits mono audio feed from the MTP transmitter into two channels for direct connection of audio equipment that is located within the same rack as the MTP SW6.

Local audio output volume adjustment and muting — A local line level output has volume and muting control via RS-232 that can be set dynamically to feed an audio ampliﬁer, eliminating the need for a preampliﬁer in many systems.

Auto-input switching — Automatically switches to the highest-numbered input with an active video signal.

Local RS-232 insertion port — Allows direct insertion of bi-directional serial control signals into the MTP output. This eliminates the need for additional control system wiring to the remote display and extends the serial control beyond the recommended 100-foot distance.

RS-232 and contact closure control — Provides versatile control options, simplifying remote control integration.

External universal power supply included — Provides worldwide power capability.

MTP SW6 • Introduction 5

Installation and Operation

This section describes the installation and the operation of the MTP SW6, including:

• Mounting the MTP SW6

• Connectors and Settings

• Operation

• Optimizing the Video

Mounting the MTP SW6

The MTP SW6 can be set on a table, mounted on a rack shelf, or mounted under a desk, podium, or tabletop.

Tabletop Use

Four self-adhesive rubber feet are included with the switcher. For tabletop use, attach one foot at each corner on the bottom of the unit and place the unit in the desired location.

Rack Shelf Mounting

For rack mounting, mount the switcher using any of the following rack mounting options:

• RSU 129 9.5-inch deep 1U universal rack shelf kit (part #60-190-01) (ﬁgure 3)

• RSB 129 9.5-inch deep 1U basic rack shelf (part #60-604-02)

• RSU 126 6-inch deep universal rack shelf kit (part #60-190-10) (ﬁgure 4)

• RSB 126 6-inch deep basic rack shelf (part #60-604-11)

UL Guidelines for Rack Mounting

The following Underwriters Laboratories (UL) guidelines pertain to the installation of an MTP SW6 unit onto a rack.

1. Elevated operating ambient — If installed in a closed or multi-unit rack assembly,

the operating ambient temperature of the rack environment may be greater than room ambient. Therefore, consider installing the equipment in an environment compatible with the maximum ambient temperature speciﬁed by the manufacturer [Tma = +32 to +122 °F (0 to +50 °C)].

2. Reduced air ﬂow — Installation of the equipment in a rack should be such that the

amount of air ﬂow required for safe operation of the equipment is not compromised.

3. Mechanical loading — Mounting of the equipment in the rack should be such that a

hazardous condition is not achieved due to uneven mechanical loading.

4. Circuit overloading — Consideration should be given to the connection of the

equipment to the supply circuit and the effect that overloading of the circuits might have on overcurrent protection and supply wiring. Appropriate consideration of equipment nameplate ratings should be used when addressing this concern.

MTP SW6 • Installation and Operation 6

5. Reliable earthing (grounding) — Reliable earthing of rack-mounted equipment

6" Deep Rack Shelf

Front false faceplate uses 2 screws.

1/2 Rack Width Front False Faceplate

Use 2 mounting holes on opposite corners.

(2) 4-40 x 3/16" Screws

should be maintained. Particular attention should be given to supply connections other than direct connections to the branch circuit (such as the use of power strips).

Rack shelf mounting instructions

1. Remove feet from the bottom of the MTP SW6 if installed.

2. Mount the switcher on the rack shelf, using two 4-40 x 3/16” screws in opposite

(diagonal) corners to secure it to the shelf (figure 3).

3. Install blank panel(s) or other unit(s) on the rack shelf.

4. Attach the rack shelf to the rack using the supplied bolts.

1U Universal Rack Shelf

Figure 3. Mounting the switcher on a universal rack shelf

Figure 4. Mounting the switcher unit on a 6-inch deep rack shelf

MTP SW6 • Installation and Operation 7

Furniture Mounting

For furniture mounting, do not attach the rubber feet. Furniture mount the switcher using the optional MBU 125 under desk mounting kit (part #70-077-01) as follows:

1. Remove feet from the bottom of the MTP SW6 if installed.

2. Attach the furniture mounting brackets to the switcher with the four machine screws

supplied with the mounting kit (ﬁgure 5).

Figure 5. Attaching the furniture mounting brackets to an MTP SW6

3. Hold the switcher with the attached brackets against the underside of the mounting

surface. Mark the location of the bracket’s screw holes on the surface.

4. Drill 3/32-inch (2 mm) diameter pilot holes, 1/4 inch (6.3 mm) deep in the mounting

surface at the marked locations.

5. Insert #8 wood screws into the four pilot holes. Tighten each screw into the

mounting surface until just less than 1/4” of the screw protrudes.

6. Align the mounting screws with the slots in the brackets and place the switcher

against the surface, with the screws through the bracket slots.

7. Slide the switcher slightly forward or back to align it with the edge of the surface,

then tighten all four screws to secure the unit in place.

MTP SW6 • Installation and Operation 8

Connectors and Settings

REMOTE

1 2 3 4 5 6

INPUT

PRE-PEAK

OFF

OUTPUT

MONO AUDIO OUTPUT

L R

POWER

12V

0.5A MAX

MTP SW6

RS-232 INSERT

Tx Rx

SPARE

1 3 74 6

Figure 6. MTP SW 6 rear panel features

DC power connector — Plug the external 12 VDC power supply into this 2-pole

captive screw connector. See Power supply wiring to wire the connectors.

NOTE: The remote power capabilities available with certain MTP models are not

supported by this unit; the transmitter, switcher, and receiver must all be powered.

Input connectors — Connect up to six TP cables from transmitters to these RJ-45

female connectors. See TP cable termination to wire the RJ-45 connectors.

CAUTION: Do not connect this device to a computer data or telecommunications

network.

NOTES: • See Table 1 for recommended transmission ranges.

• You must conﬁgure the switcher for the appropriate content on the audio/RS-232 wire pair (pins 3 and 6) for each TP input. See the

Audio/RS-232 TP input (wire pair 3 and 6) conﬁguration

SIS commands.

• For best results, use a combined cable length of at least 50 feet (15 m) between the transmitter and the receiver on the MTP SW6 output.

• RJ-45 termination with CAT 5, CAT 5e, or CAT 6 cable must comply with the TIA/EIA T568A or TIA/EIA T568B wiring standards for all connections.

• RJ-45 termination with Enhanced Skew-Free A/V UTP cable must comply with TIA/EIA T568A only.

• When low resolution MTPs (S-video and composite video) are the TP inputs, the MTP SW6 audio circuits are compatible only with the newer generation, mono audio models. See the appropriate MTP transmitter/receiver user’s manual to determine which MTP models you have.

Output connector — Connect one end of a terminated TP cable to this RJ-45 female

connector.

Connect the free end of the same TP cable from the switcher to the RJ-45 female

connector on a compatible MTP receiver.

See TP Cable Termination to properly wire the RJ-45 connectors.

MTP SW6 • Installation and Operation 9

Pre-Peak switch — The Pre-Peak switch alters the TP signal output to correct for long

cable runs. See Table 1 for suggested switch settings based on the transmitted video format and transmission distance.

RS-232 Insert connector — For bidirectional RS-232 data that is routed from a common

source to the TP output regardless of the selected input, connect a serial device to this

3.5 mm, 5-pole captive screw connector.

Figure 7 shows how to wire the connector.

NOTE: For the RS-232 insert to be available on the TP output, it must be enabled

via an SIS command or the Windows-based control program. See the

RS-232 insert enable SIS commands.

NOTE: When the RS-232 insert is enabled, any content on the audio/RS-232 wire

pair for the TP input tied to the output is disabled.

SPARE

RxTx

RS-232

Do not tin the wires!

Device

Transmit (Tx) Receive (Rx) Ground ( )

Bidirectional

Transmit (Tx) Receive (Rx)

Ground ( )

Figure 7. RS-232 insert wiring

Mono Audio (local audio) output — Connect an audio device, such as an audio

ampliﬁer or powered speakers to this 3.5 mm, 5-pole captive screw connector. This connector outputs the selected unampliﬁed, mono line level audio. See

ﬁgure 8 to

properly wire the output connector. Use the supplied tie-wrap to strap the audio cable to the extended tail of the connector.

Do not tin the wires!

Ring

Sleeve(s)

Ring

Tip

Mono Output

L R

Figure 8. Captive screw connector wiring for audio output

CAUTION: Connect the sleeve to ground (Gnd). Connecting the sleeve to a

negative (-) terminal will damage the audio output circuits.

CAUTION: The length of the exposed (stripped) portion of the copper wires is

important. The ideal length is 3/16” (5 mm). Longer bare wires can short together. Shorter bare wires are not as secure in the direct insertion connectors and could be pulled out.

The volume level for the local output can be set under serial port control. See the Local

audio output volume SIS commands for details.

By default, the audio ties follow the video ties. Audio breakaway switching, which can

be performed under serial port control, allows you to select from any one of the audio input sources and route it separately from its corresponding video source. See the Input

selection SIS Commands for details.

MTP SW6 • Installation and Operation 10

Remote RS-232/contact closure connector — Connect a computer or control

system to this 9-pin D connector (ﬁgure 9) to allow remote control using the Simple Instruction Set (SIS™), the Extron graphical control program for Windows, or a contact closure device. See Remote Control for details.

Contact Closure

REMOTE

RS-232

— In #1 Input #1

TX — Transmit data

RX — Receive data

— In #2

Gnd Gnd Ground

— In #3

— In #4

— In #5

— In #6

Function

Input #2

Input #3 Input #4 Input #5 Input #6

Figure 9. Remote connector pinout

You can also connect a KP 6 remote control keypad (part #60-111-20) or an IR 102 Kit

infrared remote control (part #70-224-01) system to this connector.

NOTE: The switcher can be controlled only by an RS-232 device OR a contact

closure device, not both.

NOTE: The cable used to connect the Remote port to a computer, control, contact

closure device, or IR control kit may need to be modiﬁed by removing pins or cutting wires. If unneeded pins are connected, the switcher may hang up. See Remote Control for additional information.

MTP SW6 • Installation and Operation 11

Making Connections

SECTION A–A

Ridges

Smooth

2-Pole Captive Screw Connector (12 V)

Tie Wrap

3/16”

(5 mm) Max.

Power supply wiring

Figure 10 shows how to wire the power connector. Use the supplied tie-wrap to strap the power cord to the extended tail of the connector.

Figure 10. Power connector wiring

CAUTION: Always use a power supply supplied and or speciﬁed by Extron. Use of an

unauthorized power supply voids all regulatory compliance certiﬁcation and may cause damage to the supply and the end product. Unless otherwise stated, the AC/DC adapters are not suitable for use in air handling spaces or in wall cavities. The installation must always be in accordance with the applicable provisions of National Electrical Code ANSI/NFPA 70, article 75 and the Canadian Electrical Code part 1, section 16. The power supply shall not be permanently ﬁxed to building structure or similar structure.

Power supply voltage polarity is critical. Incorrect voltage polarity can

damage the power supply and the unit. The ridges on the side of the cord (ﬁgure 10) identify the power cord negative lead.

To verify the polarity before connection, plug in the power supply with no load and check the output with a voltmeter.

WARNING: The two power cord wires must be kept separate while the power supply

is plugged in. Remove power before wiring.

CAUTION: The length of the exposed (stripped) copper wires is important. The

ideal length is 3/16 inch (5 mm). Longer bare wires can short together.

Shorter wires are not as secure in the connectors and could be pulled out.

NOTE: Do not tin the power supply leads before installing them in the direct insertion

connector. Tinned wires are not as secure in the connectors and could be pulled out.

Rather than the included power supply, you can use an optional Extron PS 123 Universal 12 VDC Power Supply, part #60-814-01, can power multiple Extron 12 VDC devices using only one AC power connector.

MTP SW6 • Installation and Operation 12

TP cable termination

RJ-45

NOTE: RJ-45 termination with CAT 5, CAT 5e, or CAT 6 cable must comply with the

TIA/EIA T568A or TIA/EIA T568B wiring standards for all connections.

RJ-45 termination with Skew-Free A/V UTP cable must comply with TIA/EIA

T568A only.

Figure 11 details the recommended termination of TP cables with RJ-45 connectors in accordance with the TIA/EIA T568A or TIA/EIA T568B wiring standards. You can use either standard with CAT 5/5e/6 cable, but ensure that you use the same standard on both ends of the cable.

Pins:

123 4 5678

Insert

Twisted

Pair Wires

Figure 11. TP cable termination

Connector

T568A T568B Video input (via transmitter) Secondary input

Wire color

1 Red+/V. sync+

White-green

2 Red–/V. sync–

Green

3 RS-232+

White-orange

White-blue

5 6 RS-232-

Orange

7 Blue+/H. sync+

White-brown

8 Blue-/H. sync-

Brown

NOTE If you are using Enhanced Skew-Free A/V cable, use the TIA/EIA T568A standard only.

Wire color

White-orange Orange White-green

White-blue Green White-brown

Brown

RGB

Green+Blue Blue Green-

Composite

Reserved Reserved

Video+ Video-

Reserved Reserved

S-video

Chroma (C)+ Chroma (C)-

Luma (Y)+ Luma (Y)-

Reserved Reserved

Stereo audio

Mono audio+

Mono audio-

RS-232

NOTE: The audio data that is carried on wire pair 3 and 6 is incompatible with the

Extron TPX 88A, which cannot switch the audio, output it locally, or break it away.

NOTES: • Enhanced Skew-Free A/V cable is not recommended for Ethernet/LAN

applications. This cable is specially designed for compatibility with Extron’s Twisted Pair products that are wired using the TIA/EIA T568A standard.

• The green, brown, and blue wire pairs of this cable have virtually identical lengths and should be used to transmit the RGB signals.

• The orange wire pair of this cable has a different length and should not be used to transmit the RGB signals.

MTP SW6 • Installation and Operation 13

Receiver Considerations

• The receivers’ buffered outputs do not provide pre-peaking control. The total

recommended distance for an entire daisy chain is the same as for a single transmitter and receiver. The transmitter’s Pre-Peak switch has the same affect on the recommended transmission distance for a daisy chain as for a single transmitter and receiver.

• See the recommended transmission ranges in Table 1. The recommendations in the

table apply equally for the switcher and one receiver and for a transmission daisy chain. For example, the maximum suggested range for high quality transmission of 1024 x 768 video is 600 feet between either the switcher and one receiver or the switcher and three daisy-chained receivers.

• For daisy-chained units, the ﬁrst receiver in the chain must be at least 100 feet from

the switcher when the Pre-Peak switch is on.

• For daisy-chained units, any receiver in the chain closer than 350 feet may experience

some form of over-peaking when the Pre-Peak switch is on.

• If a receiver is the last receiver in a daisy chain, its end unit DIP switch setting needs

to be changed. Refer to the MTP 15HD RS Series User’s Manual that applies to your receiver or details.

MTP SW6 • Installation and Operation 14

Operation

AUTO

SWITCH

MODE

1 3 4 5 9 10876

NORMAL

AUTO

INPUT

SELECT

DELAY

RED

GREEN

BLUE

ADJUST

RGB

PEAKING

LEVEL

MTP SW6

MTP SWITCHER

Figure 12. Switcher’s front panel features

Auto Switch LED — When lit, the Auto Switch LED indicates that the switcher is in

auto switch mode. When unlit, the switch is in normal (manual) mode. See Switch

Mode in this chapter.

Input Buttons and LEDs — When the auto switch mode is off, these buttons select

the input. The LED for the selected input lights.

The LEDs continue to indicate the selected input when the auto switch mode is on. If

no input LED is lit, no input has active sync pulses and no input is selected.

NOTE: Front panel input selection cannot be performed when the auto switch

mode is on (Auto Switch [a] is lit).

Mode button — Use this button, with either the Auto or the Normal button, to

manually turn auto switch mode on or off. This control is a secondary function of the Input 1 button.

Normal button — Use this button, with the Mode button, to manually turn auto

switch mode off. This control is a secondary function of the Input 2 button.

Auto button — Use this button, with the Mode button, to manually turn auto switch

mode on. This control is a secondary function of the Input 3 button.

Delay Select button — This recessed button selects the red, green, or blue video

signal to adjust and resets all three video signals to a skew delay of zero nanoseconds.

Use a Tweeker to press and release this button to select among the red, green, or blue

video signal to adjust. The selected signal is indicated by the Delay Red, Green, and Blue LEDs (g).

The switcher automatically saves the setting for the video signal that is being

deselected when you push this button or when the selection times out after 10 seconds.

Press and hold this button for approximately 3 seconds to zero the skew delay for red,

green, and blue. The Delay Red, Green, and Blue LEDS (g) all turn off. Release the button.

Delay Red, Green, and Blue LEDs — These LEDs Indicate the video signal that is

selected by the Select button (f) for skew adjustment using the Adjust control (h). The LED for the selected color ﬂashes when the skew compensation for that color’s video signal has reached the minimum or maximum limit.

MTP SW6 • Installation and Operation 15

The control’s movement is smooth; it does not have mechanical steps or high- and

Watch the displayed image to observe the steps of delay. The Delay Red, Green, or Blue LED (g) (whichever is selected) ﬂashes to indicate

Switch Mode

In auto switch mode, the switcher automatically switches to the highest-numbered input with video sync signals present. Input selection, by the front panel buttons or the Remote port, is blocked while in auto switch mode. However, the front panel LEDs remain functional and the Input 1 through Input 3 buttons can be used to view or change the mode.

Delay Adjust (skew adjustment) control — This control delays the selected

red, green, or blue video signal by up to 62 nanoseconds. The delay is applied in incremental, 2-nanosecond, steps. Rotate the control counterclockwise to reduce the delay or clockwise to increase the delay.

low-limit stops.

that the control has reached the minimum (counterclockwise rotation) or maximum (clockwise rotation) limit.

Level control — The Level control alters the video output voltage to affect the

brightness of the displayed image. Adjust the knob while viewing the displayed image to set the level/boost that provides the best picture quality.

Peaking control — Peaking affects the sharpness of a picture. Increased peaking

can compensate for mid- and high-frequency detail loss from low bandwidth system components or capacitance in long cables. The minimum setting (at the counterclockwise limit) provides no peaking. The maximum setting (at the clockwise limit) provides 100% peaking. Adjust this control while viewing the displayed image to obtain the optimum picture sharpness.

NOTES: • The switcher must be in normal (manual) mode for contact closure to work.

• Audio breakaway (available via SIS or Windows-based control program

control only) is disabled in auto switch mode; audio always follows video.

Turn auto switch mode on as follows:

1. Press and hold the Mode (Input 1) button.

2. Press and release the Auto (Input 3) button. The Auto Switch Active LED lights.

3. Release the Mode button.

NOTE: Manual switching is disabled.

Turn auto switch mode off as follows:

1. Press and hold the Mode (Input 1) button.

2. Press and release the Normal (Input 2) button. The Auto Switch Active LED goes off.

3. Release the Mode button.

NOTE: When the switcher exits auto switch mode, it deselects all inputs (no

output).

MTP SW6 • Installation and Operation 16

Optimizing the Video

Most MTP transmitters and the MTP SW6 output have a pre-peaking feature. Set these features as follows for the best image quality:

1. For inputs from MTP T 15HD products only — If the cable between the MTP

transmitter and the MTP SW6 is > 300 feet, turn the transmitter’s Pre-Peak switch on. For shorter cables, turn the switch off.

2. For the output — If the cable between the MTP SW6 and the receiver is > 300 feet,

turn the switcher’s Pre-Peak switch on. For shorter cables, turn the switch off.

NOTE: Unless the TP cable lengths are changed, these settings should need to be

Level/Peaking Setting

1. Connect an oscilloscope (preferred) or a monitor (acceptable) to the switcher’s output

via a very short (less than 25 feet [7.5 m]) TP cable and a compatible MTP receiver).

2. If using an oscilloscope, apply a white ﬁeld test pattern to the input to be optimized

via an MTP transmitter. If using a monitor, apply a grayscale or Color Bars test pattern to the input to be optimized via an MTP transmitter.

TIP: The Extron VTG 300 or VTG 400 are recommended to provide the test

made only once, during installation.

pattern.

3. Select the input to be optimized.

4. Observe the oscilloscope or the monitor with a critical eye while you adjust the front

panel input level and peaking controls to compensate for signal loss between the transmitter and the MTP SW6.

5. If necessary, repeat steps 1 through 4 for each input.

6. If level/peaking and skew adjustments are available on the connected receiver(s), set

them in accordance with the applicable MTP receiver product manual.

7. Disconnect the oscilloscope or monitor connected in step 1.

NOTES: • A simpler way to set the input level/peaking is to use the optional

MTP signal generator and the auto calibration function on each input, available as an SIS command. See the Auto level and peaking

adjustment SIS command.

• The auto calibration function compensates for signal losses on the

inputs only. Compensate for signal losses on the output via the connected receivers’ level and peaking controls.

MTP SW6 • Installation and Operation 17

Skew Delay Compensation

CAT 5/5e/6 TP cable can lead to registration errors between the red, green, and blue video signals. Pair skew can be measured with test equipment or identiﬁed by viewing a crosshatch test pattern with a critical eye to determine if either the red, green, or blue video image leads (appears to the left of) the other two video images.

NOTE: Skew correction should not be necessary when Extron Enhanced Skew-Free A/V

UTP cable is used and the transmission distance is less than 1,000 feet (300 m).

NOTE: Unless the TP cable lengths are changed, these settings should need to be made

only once, during installation.

NOTE: For best results, repeat the skew compensation for each input.

The switcher has built-in skew compensation capabilities for its TP output. Adjust the equalization as follows:

1. Select an input

2. Zero the skew delay for red, green, and blue as follows: a. Use a Tweeker or other small screwdriver to press and hold the Delay Select

button for 3 seconds. The Delay Red, Green, and Blue LEDs all go out.

b. Release the Delay Select button.

3. Use UTP cable test equipment or examine the displayed video image with a critical eye

to determine which video signal — red, green, or blue — is most shifted to the left.

TIP: The Extron VTG 300 or VTG 400 are recommended to provide a crosshatch

test pattern, which is ideal for determining skew. A black background with vertical white lines can also be useful.

4. Adjust the leftmost video signal as follows:

NOTE: The switcher cannot shift the rightmost video image to the left.

a. Use a Tweeker or other small screwdriver to press and release the Delay Select

button until the LED lights for the left-shifted color — Delay Red, Green, or Blue.

b. Slowly rotate the Delay Adjust control clockwise while monitoring the display.

Observe that the leftmost color shifts rightward one step at a time. Continue to rotate the control until that color is properly converged.

NOTE: A 2-nanosecond adjustment is very ﬁne. Up to 10 nanoseconds of

delay may be necessary before you detect a change in the display.

c. Use a Tweeker or other small screwdriver to press the Delay Select button one

more time to save the most recent adjustment or allow the 10-second timeout to elapse.

5. If one of the remaining colors is left shifted, repeat steps 3 and 4.

6. Repeat step 1 through 5 for each input.

MTP SW6 • Installation and Operation 18

Remote Control

This section discusses how to connect and conﬁgure the MTP SW6. Topics that are covered, include:

• Simple Instruction Set Control

• Windows-Based Program Control

• Contact Closure Control

• IR 102 Infrared Remote Control

The switcher can be remotely controlled via its rear panel Remote connector (Figure 13). Remote control devices can be:

• A host device such as a computer or control system

• A device such as an Extron IR 102 Universal remote control kit

• A contact closure device such as an Extron KP 6 Keypad Control

REMOTE

Contact Closure

RS-232

— In #1 Input #1

TX — Transmit data

RX — Receive data

— In #2

Gnd Gnd Ground

— In #3

— In #4

— In #5

— In #6

Function

Input #2

Input #3 Input #4 Input #5 Input #6

Figure 13. Remote connector pinout

NOTES: • The cable used to connect the Remote port to a computer, control

system, contact closure device, or IR control kit may need to be modiﬁed by removing pins or cutting wires. If unneeded pins are connected, the switcher may hang up.

• For RS-232, Windows-based program, and IR control, use a control cable with only pins 2, 3, and 5 connected. Otherwise, either cut the wires to the other pins in hard-shelled connectors or remove the unneeded pins from molded plugs

• See Simple Instruction Set Control for deﬁnitions of the SIS commands.

• See Windows-Based Program Control for details on how to install and use the control software.

• For contact closure, use a control cable with pins 2 and 3 disconnected. Otherwise, either cut the wires to these pins in hard-shelled connectors or remove these pins from molded plugs. See Contact Closure Control for information on how to make a remote contact closure device.

MTP SW6 • Remote Control 19

Simple Instruction Set™ Control

Host-to-Interface Communications

SIS commands consist of one or more characters per ﬁeld. No special characters are required to begin or end a command character sequence. When a command is valid, the unit executes the command and sends a response to the host device. All responses from the unit to the host end with a carriage return and a line feed (CR/LF = ]), which signals the end of the response character string. A string is one or more characters.

Symbol Deﬁnitions

Symbols (variables), deﬁned on the next page, are used throughout the Unit-Initiated

Messages section and the Command/Response Table for SIS Commands. The symbols

represent variables in the unit-initiated messages and the command/response table ﬁelds.

] = CR/LF (carriage return/line feed) } = Carriage return (no line feed)

• = Space (hard) character

X! = Input 1 – 6 X@ = Threshold 0 = outside of threshold range

X# = Input peaking range 00 – 65 X$ = Input level range 00 – 255 X% = Skew adjustment range 00 – 31 (each step = 2ns) X^ = Video plane 0 = red

X& = RS-232 insert status 0 = disabled

X* = Audio/RS-232 wire pair input type 0 = audio

X( = Audio gain 0 – 24 (1 dB/step) X1) = Numeric dB value –18 to +24 (45 steps of gain or

X1! = Audio attenuation 1 – 18 (1 dB/step) X1@ = Volume adjustment range 0 – 100 X1# = Mute, Front panel lock 0 = off

X1$ = Switch mode 1 = normal (manual)

X1% = Firmware version v.vv

1 = within threshold

1 = green 2 = blue

1 = enabled

1 = RS-232

attenuation) (Default = 0 dB)

1 = on

2 = auto

MTP SW6 • Remote Control 20

Unit-Initiated Messages

When a local event, such as a front panel operation, auto switch, or error condition, occurs, the unit responds by sending a message to the host. The unit-initiated messages are listed below:

The connected unit issues the appropriate copyright message (above) when it ﬁrst powers on. v.vv is the ﬁrmware version number.

ALL

]

The unit sends the All message as a unit-initiated message under two conditions:

• You press a front panel input button.

• An input selection occurs via auto switch mode.

NOTE: The switcher returns the All message for every press of an input button, even if

no switch occurs. No switch will occur if you press an already selected button or if the switcher is in auto switch mode (front panel input selection is disabled).

X1$

]

The unit sends the F message whenever the switch mode is changed from the front panel.

ILVLX!*

The unit sends the Ilvl message whenever the level adjustment is changed from the front panel.

IPEKX!*

]

]]

The unit sends the Ipek message whenever the peaking adjustment is changed from the front panel.

X!*X%*X%*X%

ISEQ

The unit sends the Iseq message whenever the skew settings have been changed from the front panel. The X% values are the red, green, and blue skew values, in that order.

ZPK

]

The unit sends the Zpk message whenever the skew settings have been reset from the front panel.

]

Error Responses

When the unit receives a valid SIS command, it executes the command and sends a response to the host device. If the unit is unable to execute the command because the command is invalid or it contains invalid parameters, the unit returns an error response to the host. The error response codes are:

E10 - Invalid command E11 - Invalid preset number E13 - Invalid parameter E14 - Invalid command for this conﬁguration

MTP SW6 • Remote Control 21

Timeout

Pauses of 10 seconds or longer between command ASCII characters result in a timeout. The command operation is aborted with no other indication.

Using the Command/Response Table

The command/response table begins on page 23. Lower case letters are acceptable in the command ﬁeld except where indicated for the audio level (gain and attenuation) commands. Symbols are used throughout the table to represent variables in the command/response ﬁelds. Command and response examples are shown throughout the table. The ASCII to HEX conversion table below is for use with the command/response table.

ASCII to HEX Conversion Table

Space

MTP SW6 • Remote Control 22

Command/Response Table for SIS Commands

Command ASCII Command

(host to unit)

Response

(unit to host)

Additional description

Input selection

NOTE: The switcher supports 1-, 2-, or 3-digit numeric entries (1!, 02&, or 003%). The switcher reports all selections with 1-digit

numbers.

NOTE: The & select and % select commands for video can be used interchangeably.

Select input X! video and audio to output

Example: 1!

Select input X! video only to output

Example (see 2nd note above):

Select input X! video only to output

Select input X! audio only to output

Example: 2$

! All

& Vid

% Vid

$ Aud

Auto level and peaking adjustment

X!]

All1

Vid1

Aud2

]

X!]

]

X!]

]

Select input X! video and audio to be the output.

Select input 1 video and audio. Select X! video (audio is broken away).

Select input 5 video.

Select X! video (audio is broken away).

Select X! audio (audio is broken away).

Select input 2 audio.

NOTE: The switcher must be running ﬁrmware version 1.02 or newer (issue the Q SIS command). Older ﬁrmware versions appear to

respond correctly, but do not adjust the level and peaking values correctly.

Execute auto peaking calibration

(with optional MTP signal generator)

EX!AADJ} AadjX!*2] {start}

AllX!] {switch} AadjX!*X@] {ﬁnished} IpekX!*X#] {new value} IlvlX!*X$] {new value}

Switch input X! to the output and auto adjust the peaking on input X!. The X@ value in the responses reports whether the adjustment value was within or outside of the threshold.

NOTE: Before issuing the auto calibration command:

1. Disconnect the power and RJ-45 cables at the MTP transmitter connected to X!.

2. Connect the two cables to the optional MTP signal generator.

3. If the input cable is longer than 300 feet (90 m), set the MTP signal generator Pre-

Peak switch on (up when the RJ-45 connector on the signal generator is to the right as shown). If the cable is shorter than 300 feet (90 m), set the switch down.

Manual video peaking adjustment

Set a peaking value Increment peaking Decrement peaking Show peaking

EX!*X# EX!

+IPEK

EX!

-IPEK

EX!

IPEK

}

} X#]

}

IpekX!* IpekX!* IpekX!*

X#] X#] X#]

Set the peaking to X#. Increase peaking setting 1 step. Decrease peaking setting 1 step.

Manual video level adjustment

Set a level value Increment level Decrement level Show level

NOTE:

= Input number 1-6

= Threshold 0 = outside threshold 1 = within threshold

= Input peaking range 00 - 65

= Input level range 000 - 255

EX!*X$ EX! EX! EX!

}

ILVL

}

+ILVL

}

-ILVL

} X$]

ILVL

IlvlX!* IlvlX!* IlvlX!*

X$] X$] X$]

Set the level to X$. Increase level setting 1 step. Decrease level setting 1 step.

Pre-Peak is on

MTP SW6 • Remote Control 23

Command/response table for SIS commands (continued)

Command ASCII Command

(host to unit)

Response

(unit to host)

Skew adjustment

Set all skew values for an input

Example:

Increment one skew value for an input

Decrement one skew value for an input

Example:

Read skew values

EX!*X%*X%*X%

2*0*0*4Iseq

EX!*X^

E EX!

+Iseq

-Iseq

}

2*2-Iseq

} X%*X%*X%]

Iseq

}

Iseq

}

X!*X%*X%*X%]

Iseq Iseq02*00*00*04

IseqX!*X%*X%*

Iseq02*00*00*03

RS-232 insert enable

Disable the RS-232 insert Enable the RS-232 insert Read the RS-232 insert

status

E E E

}

1*0Lrpt

}

1*1Lrpt

} X&]

1Lrpt

Lrpt0 Lrpt1

] ]

Audio/RS-232 TP input (wire pair 3 and 6) conﬁguration

NOTE: The RS-232 insert, when enabled (

Conﬁgure input as audio

Conﬁgure input as RS-232

Show TP input conﬁguration

*0\ TypX!*0

*1\ TypX!*1

1*1Lrpt}), overrides the audio/RS-232 TP input conﬁguration.

]

X*]

Audio input gain and attenuation level

]

X%]

]

Additional description

Set speciﬁc skew adjustment values for TP input X!. X% values are listed in RGB order.

Set input 2’s skew settings as follows: Red = 0 ns Green = 0 ns Blue = 8 ns (delayed 8 ns)

Increase input X!’s X^ plane’s skew value by 1 step (2 ns).

Decrease input X!’s X^ plane’s skew value by 1 step (2 ns). Decrease input 2’s blue skew by 2 ns to 6 ns.

Disable the RS-232 insert. Enable the RS-232 insert.

Deﬁne the audio/RS-232 input as audio, such as provided by an MTP 15HD A transmitter. Deﬁne the audio/RS-232 input as bidirectional serial communications, such as provided by an MTP 15HD RS transmitter. Show the audio/RS-232 wire pair input deﬁnition.

NOTE: The set gain (G) and set attenuation (g) commands are case sensitive. The increment, decrement, and read commands are

not case sensitive.

Set the input audio gain to a +dB value

Example: 1*2G

Set the input audio attenuation to a -dB value Increment gain

Example: 5+G

Decrement gain

Example: 7-G

Read input level

NOTE:

= Input number 1-6

= Skew adjustment range 00 - 31 (each step = 2 ns)

= Video plane 0 = red 1 = green 2 = blue

= RS-232 insert status 0= disabled 1 = enabled

= Audio/RS-232 wire pair input type 0 = audio 1 = RS-232

= Video plane 0 = red 1 = green 2 = blue

X1)

= RS-232 insert status 0= disabled 1 = enabled

X1!

= Audio/RS-232 wire pair input type 0 = audio 1 = RS-232

X!*X(

G InX!•Aud

In01•Aud+02

X!*X1!

g InX!•Aud

+G InX!•Aud

In05•Aud+03

-G InX!•Aud In07•Aud-09

X1)]

]

Set input 1 audio gain to +2 dB.

Increase gain by 1 dB. Increase audio input 5 level from +2 dB to +3 dB. Decrease gain by 1 dB. Decrease audio input 7 level from -8 dB to -9 dB.

MTP SW6 • Remote Control 24

Command/response table for SIS commands (continued)

Command ASCII Command

(host to unit)

Response

(unit to host)

Additional description

Local audio output volume

Set the local audio output volume to a speciﬁc value

Example: 50V

Increment volume +V

Example: +V Decrement volume -V Read output volume V

X1@

V Vol

X1@]

Vol50

X1@]

Vol Vol51

X1@]

Vol

X1@]

]

Set the output volume to 50%. Increment volume by 1%.

Decrement volume by 1%

Audio or RS-232 mute commands

Audio or RS-232 mute 1Z Audio or RS-232 unmute 0Z Read audio/RS-232 mute

status

Amt1 Amt0

X1#]

] ]

Mute (silence) the audio or RS-232 output. Unmute the audio or RS-232 output (audio on). 1 = mute on, 0 = mute off.

Switch mode

Set normal (manual) switch mode Set auto switch mode 2#

]

The user selects an input manually, from the front panel or under remote control. The switcher automatically switches to the highest numbered input with signals present. Manual input selection is disabled.

Front panel lock (executive mode)

Lock the front panel 1X

Unlock the front panel 0X View lock status X

Exe1

Exe0

X1#]

]

Lock the front panel level, peaking, and skew functions. The switch mode (auto or manual) cannot be changed. Input selection is still available. All front panel functions are available.

Resets

Reset all video level and peaking adjustments Reset all skew adjustments Reset audio input levels

Reset audio output levels

Reset whole switcher

EZT}

EZK}

EZA}

EZV}

ZXXX

}

Zpt

Zpk

Zpa

Zpv

Zpx

]

Clear all video level and peaking adjustments to their default (0) values. Clear all input and output skew values to 0 ns.

Reset all audio input levels (gain and attenuation) to 0 dB. Reset the audio output level (volume) to 100% (no attenuation. Reset all level and peaking, skew, audio input gain and attenuation values to 0. Reset output volume to 100% ( no attenuation).

Information requests

Information request I

Request part number N Query controller version Q

Example: Q

Request system threshold status

42S

X!•AX!•FX1$

68-928-01

X1%]

]

1.23

X@]

]

•Vmt

X1#

•Amt

X1#]

•Exe

V (selected video input) • A (selected audio input) • F (switch mode) • Vmt (video mute — not supported by this switcher) • Amt (audio mute status) • Exe (front panel lock).

The factory-installed ﬁrmware version is 1.23 (sample value only).

NOTE:

= Input number 1-6

= Threshold 0 = outside threshold 1 = within threshold

X1@

= Volume adjustment range 0 - 100

X1#

= Mute, front panel lock 0 = off 1 = on

X1$

= Switch mode 1 = normal (manual) 2 = auto

X1%

= Firmware version v.vv

MTP SW6 • Remote Control 25

Windows-Based Program Control

The Windows-based Extron Universal Switcher Control Program, which communicates with the switcher via the Remote port, provides an easy way to conﬁgure and operate the MTP SW6 switcher. The program is compatible with Windows 2000 and Windows XP or higher versions.

Installing the Software

The program is contained on the Extron Software Products DVD. Install the software as follows:

1. Insert the disk into the drive. The Extron software DVD window should appear

automatically (ﬁgure 14).

Figure 14. Software CD window

NOTE: If the window does not self-start, run Launch.exe from the DVD.

2. Click the Software tab (ﬁgure 14).

3. Scroll to the desired program and click Install (ﬁgure 15).

Figure 15. Software installation

4. Follow the on-screen instructions. By default, the installation of the Universal

Switchers Control Program creates a C:\Program Files\Extron\UniversalSwitcher folder, and it places four icons into a group folder named “Extron Electronics\Universal Switcher.” The four installed icons are:

о Check for Universal Switcher Updates о Uninstall Universal Switcher о Universal Switcher Control Program о Universal Switcher Help

MTP SW6 • Remote Control 26

Using the Software

Run the program as follows:

1. Click Start > Programs > Extron Electronics > Universal Switcher (New) >

Universal Switcher Control Pgm.

2. Click the comm port that is connected to the switcher’s RS-232 port.

3. The Extron Universal Switcher Control Program window (ﬁgure 16) displays the

selected video and audio input.

Figure 16. Universal Switcher Control program window

о To set up for audio follow switching (the output has the same audio and video

input selected), select the Audio and Video check boxes. To set up for audio breakaway switching (the output has different audio and video inputs selected), deselect the Audio or Video check box.

о To select an input, click the input button. о To set the input audio level (gain and attenuation), click the Gain/Att tab. о To manually adjust the level and peaking, click the Level/Peak tab. о To select or deselect auto switch mode, click the Auto Switch tab. о To set the output volume, click the Volume tab. о To set the RS-232 or audio deﬁnition for wire pair 3 and 6, click the RJ-45 tab. о To set the skew adjustments, click the Skew tab.

Contact Closure Remote Control

The Remote connector also provides a way to select an input to the switcher using a remote contact closure device. Contact closure control uses pins on the Remote connector that are not used by the RS-232 interface. Figure 13 shows the contact closure pin assignments.

To select a different input number using a contact closure device, momentarily short the pin for the desired input number to logic ground (pin 5). To force one of the inputs to be always selected, leave the short to logic ground in place. The short overrides front panel input selections.

MTP SW6 • Remote Control 27

IR 102 Infrared Remote Control

REMOTE

1 2 3 4 5 6

INPUT

PRE-PEAK

OFF

OUTPUT

MONO AUDIO OUTPUT

L R

POWER 12V

0.5A MAX

MTP SW6

RS-232 INSERT

Tx Rx

SPARE

IR 102 Remote

Control Receiver

IR 102 Remote Control

IR Detector

3' Cable

6' Cable

Power

Supply

RS-232

Control

MTP SW6 Switcher

IR-102

+10

IR 102

The optional Extron IR 102 kit consists of the following components:

• IR 102 handheld remote control unit

• IR 102 remote receiver with 3-foot cable and RS-232 connector

• IR detector with 6-foot cable and captive screw connector

• External 12 VDC power supply

Install and operate the remote control in accordance with the IR 102 User’s Guide included with the remote.

Figure 17. IR 102 Remote application

MTP SW6 • Remote Control 28

Reference Information

This section discusses the speciﬁcations, part numbers, and accessories for the MTP SW6. Topics that are covered, include:

• Speciﬁcations

• Part Numbers

Speciﬁcations

Video

Gain �� Unity

Video input — see MTP Series transmitter speciﬁcations

Number/signal type �� 6 sets of proprietary analog signals Connectors �� 6 female RJ-45

Video output — See MTP Series receiver speciﬁcations

Number/signal type �� 1 set of proprietary analog signals Connectors �� 1 female RJ-45 Maximum resolution �� 1920x1200

N

Refer to the applicable MTP 15HD transmitter/receiver user’s manual for the maximum distances recommended for speciﬁc resolutions.

Audio

Number/signal type �� 1 set of proprietary analog signals Connectors �� 1 female RJ-45 Gain �� Unbalanced output: 0 dB; balanced output: +6 dB Frequency response �� 20 Hz to 20 kHz, ±1 dB THD + Noise �� 0�15% @ 1 kHz, 0�3% @ 20 kHz at nominal level S/N �� >70 dB at maximum output (unweighted) CMRR �� >43 dB @ 20 Hz to 20 kHz

Audio input — see MTP Series transmitter speciﬁcations

Number/signal type �� 6 sets of proprietary analog signals Connectors �� 6 female RJ-45

N

0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV ≈ 2 dBu

Audio output — local

Number/signal type �� 1 dual mono, balanced/unbalanced Connectors �� (1) 3�5 mm captive screw connector, 5 pole Impedance �� 50 ohms unbalanced, 100 ohms balanced Gain error �� ±1 dB channel to channel Maximum level (Hi-Z) �� >+18 dBu, balanced or unbalanced at 1% THD+N Maximum level (600 ohm) �� >+15 dBm, balanced or unbalanced at 1% THD+N

MTP SW6 • Reference Information 29

Audio output — see MTP Series receiver speciﬁcations

Number/signal type �� 1 set of proprietary analog signals Connectors �� 1 female RJ-45

Control/remote— switcher host control

Serial control port �� 1 RS-232, 9-pin female D connector Baud rate and protocol �� 9600 baud, 8 data bits, 1 stop bit, no parity Serial control pin conﬁguration �� 2 = TX, 3 = RX, 5 = GND Program control �� Extron control/conﬁguration program for Windows

Extron Simple Instruction Set (SIS™)

Control/remote — external device (pass-through)

Serial control port �� RS-232, 3�5 mm captive screw connector, 5 pole (uses 3 poles) Baud rate and protocol �� Up to 38400 baud; 5-8 data bits; 1 or 2 stop bits; odd, even, or no parity; XON, XOFF, or

no ﬂow control

N

Serial control pin conﬁguration �� 1 = TX, 2 = RX, 3 = GND

Protocol is mirrored between the switcher and the receiver.

General

Recommended cable type �� CAT5/5E/6 (shielded or unshielded) External power supply �� 100 VAC to 240 VAC, 50/60 Hz, external; to 12 VDC, 2 A, regulated Power input requirements �� 12 VDC, 0�8 A Temperature/humidity �� Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing

Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing Cooling �� Convection, vents on right and left sides Mounting

Rack mount �� Yes, with optional 1U, 9�5" deep rack shelf (RSU 129, #60-190-01 or RSB 129, 60-604-02)

or 1U, 6" deep rack shelf (RSU 126, #60-190-10 or RSB 126, 60-604-11)

Furniture mount �� Yes, with optional Under-Desk Mounting Kit (MBU 125, #70-077-01) Enclosure type �� Metal Enclosure dimensions �� 1�7" H x 8�7" W x 6�0" D (1U high, half rack wide)

(4�3 cm H x 22�1 cm W x 15�2 cm D)

(Depth excludes connector and knob�) Product weight �� 1�2 lbs (0�5 kg) Shipping weight �� 3 lbs (2 kg) Vibration �� ISTA 1A in carton (International Safe Transit Association) Regulatory compliance

Safety �� CE, c-UL, UL

EMI/EMC �� CE, C-tick, FCC Class A, ICES, VCCI MTBF �� 30,000 hours Warranty �� 3 years parts and labor

NOTE: All nominal levels are at ±10%. NOTE: Speciﬁcations are subject to change without notice.

MTP SW6 • Reference Information 30

Part Numbers

Included Parts

These items are included in each order for an MTP SW6:

Included parts Part number

MTP SW6 switcher 60-928-01 IEC power cord Tweeker (small screwdriver)

MTP SW6 Setup Guide Desktop power supply, 12 V, 2 A 70-775-01 Captive screw 5-pole connectors (qty. 2) 10-457-12 Captive screw 2-pole connector (qty. 1) Extron Software Products DVD

(Universal Switcher Control Program)

Accessories

Accessory Part number

RSU 129 1U universal rack shelf 60-190-01 RSB 129 1U basic rack shelf 60-604-02 RSU 126 6-inch deep universal rack shelf 60-190-10 RSB 126 6-inch deep basic rack shelf 60-604-11 MBU 125 under-desk mounting kit 70-077-01 MTP signal generator 70-647-01 KP 6 remote control keypad 60-111-20

IR 102 remote control kit 70-224-01

Cables

NOTE: Enhanced Skew-Free A/V UTP cables are not recommended for

Ethernet/LAN applications.

Enhanced Skew-Free™ A/V cable Part number

Enhanced Skew-Free A/V cable (cut, various lengths) 26-569-xx Enhanced Skew-Free A/V 1000’ (Bulk) (non-plenum) 22-141-03 Plenum enhanced Skew-Free A/V 1000’ (Bulk) 22-142-03

MTP SW6 • Reference Information 31

Connectors

Connector Part number

CAT 6 jack (black), qty. 10 100-476-01 CAT 6 jack (red), qty. 10 100-477-01 CAT 6 jack (blue), qty. 10 100-478-01 CAT 6 jack (orange), qty. 10 100-479-01 CAT 6 jack (gray), qty. 10 100-480-01 CAT 6 jack (white), qty. 10 100-481-01 CAT 6 jack (ivory), qty. 10 100-482-01

MTP SW6 • Reference Information 32

Extron Warranty

Extron Electronics warrants this product against defects in materials and workmanship for a period of three years from the date of purchase. In the event of malfunction during the warranty period attributable directly to faulty workmanship and/or materials, Extron Electronics will, at its option, repair or replace said products or components, to whatever extent it shall deem necessary to restore said product to proper operating condition, provided that it is returned within the warranty period, with proof of purchase and description of malfunction to:

USA, Canada, South America, and Central America:

Extron Electronics 1001 East Ball Road Anaheim, CA 92805 U.S.A.

Europe, Africa, and the Middle East:

Extron Europe Hanzeboulevard 10 3825 PH Amersfoort The Netherlands

Asia:

Extron Asia 135 Joo Seng Road, #04-01 PM Industrial Bldg. Singapore 368363 Singapore

This Limited Warranty does not apply if the fault has been caused by misuse, improper handling care, electrical or mechanical abuse, abnormal operating conditions, or modiﬁcation were made to the product that were not authorized by Extron.

Japan:

Extron Electronics, Japan Kyodo Building, 16 Ichibancho Chiyoda-ku, Tokyo 102-0082 Japan

China:

Extron China 686 Ronghua Road Songjiang District Shanghai 201611 China

Middle East:

Extron Middle East Dubai Airport Free Zone F12, PO Box 293666 United Arab Emirates, Dubai

NOTE: If a product is defective, please call Extron and ask for an Application Engineer to receive an RA (Return

Authorization) number. This will begin the repair process.

USA: (714) 491-1500 Europe: 31.33.453.4040

Asia: 65.383.4400 Japan: 381.3.3511.7655

Units must be returned insured, with shipping charges prepaid. If not insured, you assume the risk of loss or damage during shipment. Returned units must include the serial number and a description of the problem, as well as the name of the person to contact in case there are any questions.

Extron Electronics makes no further warranties either expressed or implied with respect to the product and its quality, performance, merchantability, or ﬁtness for any particular use. In no event will Extron Electronics be liable for direct, indirect, or consequential damages resulting from any defect in this product even if Extron Electronics has been advised of such damage.

Please note that laws vary from state to state and country to country, and that some provisions of this warranty may not apply to you.

Extron USA - West

Headqu arters

+80 0.633 .987 6

Inside USA / Canada Only

+1.714.491.1500 +1.714.491.1517 FAX

Extron USA - East

+80 0.633 .987 6

Inside USA / Canada Only

+1.919.863.1794 +1.919.863.1797 FA X

Extron Europe

+80 0.398 7.6673

Inside Europe Only

+31.33. 453. 404 0 +31.33. 453. 405 0 FAX

Extron Asia

+80 0.7339 .876 6

Inside Asia Only

+65.6 383 .440 0 +65.6 383 .46 64 FAX

Extron Japan

+81.3.3 511.7655 +81.3.3 511.7656 FA X

Extron China

+40 0.88 3.1568

Inside China Only

+86. 21.376 0.1568 +86. 21.376 0.1566 FAX

Extron Middle East

+971.4. 299 1800 +971.4. 299 1880 FA X

Extron Electronics MTP SW6 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Introduction

About this Manual

About the MTP SW6 Switcher

RS-232 Function

Twisted Pair (TP) Cable Advantages

Features

Installation and Operation

Mounting the MTP SW6

Tabletop Use

Rack Shelf Mounting

UL Guidelines for Rack Mounting

Rack shelf mounting instructions

Furniture Mounting

Connectors and Settings

Making Connections

Power supply wiring

TP cable termination

Receiver Considerations

Operation

Switch Mode

Optimizing the Video

Level/Peaking Setting

Skew Delay Compensation

Remote Control

Simple Instruction Set™ Control

Host-to-Interface Communications

Unit-Initiated Messages

Error Responses

Timeout

Using the Command/Response Table

Command/Response Table for SIS Commands

Windows-Based Program Control

Installing the Software

Using the Software

Contact Closure Remote Control

IR 102 Infrared Remote Control

Reference Information

Part Numbers

Included Parts

Accessories

Cables

Connectors
