Extron Electronics MLC 104 Plus User Manual

Download

Reference Manual

Check the Extron Web site (www.extron.com) for updates.

MLC 104 Plus Series

MediaLink® Controllers

68-1443-01 Rev. B

01 09

Precautions

Safety Instructions • English

This symbol is intended to alert the user of important operating and maintenance (servicing) instructions in the literature provided with the equipment.

This symbol is intended to alert the user of the presence of uninsulated dangerous voltage within the product’s enclosure that may present a risk of electric shock.

Caution

Read Instructions • Read and understand all safety and operating instructions before using the equipment. Retain Instructions • The safety instructions should be kept for future reference. Follow Warnings • Follow all warnings and instructions marked on the equipment or in the user

information.

Avoid Attachments • Do not use tools or attachments that are not recommended by the equipment

manufacturer because they may be hazardous.

Consignes de Sécurité • Français

Ce symbole sert à avertir l’utilisateur que la documentation fournie avec le matériel contient des instructions importantes concernant l’exploitation et la maintenance (réparation).

Ce symbole sert à avertir l’utilisateur de la présence dans le boîtier de l’appareil de tensions dangereuses non isolées posant des risques d’électrocution.

Attention

Lire les instructions• Prendre connaissance de toutes les consignes de sécurité et d’exploitation avant

d’utiliser le matériel.

Conserver les instructions• Ranger les consignes de sécurité aﬁn de pouvoir les consulter à l’avenir. Respecter les avertissements • Observer tous les avertissements et consignes marqués sur le matériel ou

présentés dans la documentation utilisateur.

Eviter les pièces de xation • Ne pas utiliser de pièces de ﬁxation ni d’outils non recommandés par le

fabricant du matériel car cela risquerait de poser certains dangers.

Sicherheitsanleitungen • Deutsch

Dies es Symbol soll dem Benut zer in der im Liefer umfang ent haltenen Dokumentation besonders wichtige Hinweise zur Bedienung und Wartung (Instandhaltung) geben.

Dieses Symbol soll den Benutzer darauf aufmerksam machen, daß im Inneren des Gehäuses dieses Produktes gefährliche Spannungen, die nicht isoliert sind und die einen elektrischen Schock verursachen können, herrschen.

Achtung

Lesen der Anleitungen • Bevor Sie das Gerät zum ersten Mal verwenden, sollten Sie alle Sicherheits-und

Bedienungsanleitungen genau durchlesen und verstehen.

Aufbewahren der Anleitungen • Die Hinweise zur elektrischen Sicherheit des Produktes sollten Sie

aufbewahren, damit Sie im Bedarfsfall darauf zurückgreifen können.

Befolgen der Warnhinweise • Befolgen Sie alle Warnhinweise und Anleitungen auf dem Gerät oder in der

Benutzerdokumentation.

Keine Zusatzgeräte • Verwenden Sie keine Werkzeuge oder Zusatzgeräte, die nicht ausdrücklich vom

Hersteller empfohlen wurden, da diese eine Gefahrenquelle darstellen können.

Warning

Power sources • This equipment should be operated only from the power source indicated on the product. This

equipment is intended to be used with a main power system with a grounded (neutral) conductor. The third (grounding) pin is a safety feature, do not attempt to bypass or disable it.

Power disconnection • To remove power from the equipment safely, remove all power cords from the rear of

the equipment, or the desktop power module (if detachable), or from the power source receptacle (wall plug).

Power cord protection • Power cords should be routed so that they are not likely to be stepped on or pinched by

items placed upon or against them.

Servicing • Refer all servicing to qualiﬁed service personnel. There are no user-serviceable parts inside. To

prevent the risk of shock, do not attempt to service this equipment yourself because opening or removing covers may expose you to dangerous voltage or other hazards.

Slots and openings • If the equipment has slots or holes in the enclosure, these are provided to prevent

overheating of sensitive components inside. These openings must never be blocked by other objects.

Lithium battery • There is a danger of explosion if battery is incorrectly replaced. Replace it only with the

same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions.

Avertissement

Alimentations• Ne faire fonctionner ce matériel qu’avec la source d’alimentation indiquée sur l’appareil. Ce

matériel doit être utilisé avec une alimentation principale comportant un ﬁl de terre (neutre). Le troisième contact (de mise à la terre) constitue un dispositif de sécurité : n’essayez pas de la contourner ni de la désactiver.

Déconnexion de l’alimentation• Pour mettre le matériel hors tension sans danger, déconnectez tous les cordons

d’alimentation de l’arrière de l’appareil ou du module d’alimentation de bureau (s’il est amovible) ou encore de la prise secteur.

Protection du cordon d’alimentation • Acheminer les cordons d’alimentation de manière à ce que personne ne

risque de marcher dessus et à ce qu’ils ne soient pas écrasés ou pincés par des objets.

Réparation-maintenance • Faire exécuter toutes les interventions de réparation-maintenance par un technicien

qualiﬁé. Aucun des éléments internes ne peut être réparé par l’utilisateur. Aﬁn d’éviter tout danger d’électrocution, l’utilisateur ne doit pas essayer de procéder lui-même à ces opérations car l’ouverture ou le retrait des couvercles risquent de l’exposer à de hautes tensions et autres dangers.

Fentes et orices • Si le boîtier de l’appareil comporte des fentes ou des oriﬁces, ceux-ci servent à empêcher

les composants internes sensibles de surchauffer. Ces ouvertures ne doivent jamais être bloquées par des objets.

Lithium Batterie • Il a danger d’explosion s’ll y a remplacment incorrect de la batterie. Remplacer uniquement

avec une batterie du meme type ou d’un ype equivalent recommande par le constructeur. Mettre au reut les batteries usagees conformement aux instructions du fabricant.

Vorsicht

Stromquellen • Dieses Gerät sollte nur über die auf dem Produkt angegebene Stromquelle betrieben werden.

Dieses Gerät wurde für eine Verwendung mit einer Hauptstromleitung mit einem geerdeten (neutralen) Leiter konzipiert. Der dritte Kontakt ist für einen Erdanschluß, und stellt eine Sicherheitsfunktion dar. Diese sollte nicht umgangen oder außer Betrieb gesetzt werden.

Stromunterbrechung • Um das Gerät auf sichere Weise vom Netz zu trennen, sollten Sie alle Netzkabel

aus der Rückseite des Gerätes, aus der externen Stomversorgung (falls dies möglich ist) oder aus der Wandsteckdose ziehen.

Schutz des Netzkabels • Netzkabel sollten stets so verlegt werden, daß sie nicht im Weg liegen und niemand

darauf treten kann oder Objekte darauf- oder unmittelbar dagegengestellt werden können.

Wartung • Alle Wartungsmaßnahmen sollten nur von qualiziertem Servicepersonal durchgeführt werden.

Die internen Komponenten des Gerätes sind wartungsfrei. Zur Vermeidung eines elektrischen Schocks versuchen Sie in keinem Fall, dieses Gerät selbst öffnen, da beim Entfernen der Abdeckungen die Gefahr eines elektrischen Schlags und/oder andere Gefahren bestehen.

Schlitze und Öffnungen • Wenn das Gerät Schlitze oder Löcher im Gehäuse aufweist, dienen diese zur

Vermeidung einer Überhitzung der empndlichen Teile im Inneren. Diese Öffnungen dürfen niemals von

anderen Objekten blockiert werden.

Litium-Batterie • Explosionsgefahr, falls die Batterie nicht richtig ersetzt wird. Ersetzen Sie verbrauchte

Batterien nur durch den gleichen oder einen vergleichbaren Batterietyp, der auch vom Hersteller empfohlen wird. Entsorgen Sie verbrauchte Batterien bitte gemäß den Herstelleranweisungen.

Instrucciones de seguridad • Español

Este símbolo se utiliza para advertir al usuario sobre instrucciones importantes de operación y mantenimiento (o cambio de partes) que se desean destacar en el contenido de la documentación suministrada con los equipos.

Este símbolo se utiliza para advertir al usuario sobre la presencia de elementos con voltaje peligroso sin protección aislante, que puedan encontrarse dentro de la caja o alojamiento del producto, y que puedan representar riesgo de electrocución.

Precaucion

Leer las instrucciones • Leer y analizar todas las instrucciones de operación y seguridad, antes de usar el

equipo.

Conservar las instrucciones • Conservar las instrucciones de seguridad para futura consulta. Obedecer las advertencias • Todas las advertencias e instrucciones marcadas en el equipo o en la

documentación del usuario, deben ser obedecidas.

Evitar el uso de accesorios • No usar herramientas o accesorios que no sean especiﬁcamente recomendados

por el fabricante, ya que podrian implicar riesgos.

安全须知 • 中文

这个符号提示用户该设备用户手册中有重要的操作和维护说明。

这个符号警告用户该设备机壳内有暴露的危险电压，有触电危险。

注意

阅读说明书 • 用户使用该设备前必须阅读并理解所有安全和使用说明。保存说明书 • 用户应保存安全说明书以备将来使用。遵守警告 • 用户应遵守产品和用户指南上的所有安全和操作说明。避免追加 • 不要使用该产品厂商没有推荐的工具或追加设备，以避免危险。

Advertencia

Alimentación eléctrica • Este equipo debe conectarse únicamente a la fuente/tipo de alimentación eléctrica

indicada en el mismo. La alimentación eléctrica de este equipo debe provenir de un sistema de distribución general con conductor neutro a tierra. La tercera pata (puesta a tierra) es una medida de seguridad, no puentearia ni eliminaria.

Desconexión de alimentación eléctrica • Para desconectar con seguridad la acometida de alimentación eléctrica

al equipo, desenchufar todos los cables de alimentación en el panel trasero del equipo, o desenchufar el módulo de alimentación (si fuera independiente), o desenchufar el cable del receptáculo de la pared.

Protección del cables de alimentación • Los cables de alimentación eléctrica se deben instalar en lugares donde

no sean pisados ni apretados por objetos que se puedan apoyar sobre ellos.

Reparaciones/mantenimiento • Solicitar siempre los servicios técnicos de personal calicado. En el interior no

hay partes a las que el usuario deba acceder. Para evitar riesgo de electrocución, no intentar personalmente la reparación/mantenimiento de este equipo, ya que al abrir o extraer las tapas puede quedar expuesto a voltajes peligrosos u otros riesgos.

Ranuras y aberturas • Si el equipo posee ranuras o oriﬁcios en su caja/alojamiento, es para evitar el

sobrecalientamiento de componentes internos sensibles. Estas aberturas nunca se deben obstruir con otros

objetos.

Batería de litio • Existe riesgo de explosión si esta batería se coloca en la posición incorrecta. Cambiar esta

batería únicamente con el mismo tipo (o su equivalente) recomendado por el fabricante. Desachar las baterías usadas siguiendo las instrucciones del fabricante.

警告

电源 • 该设备只能使用产品上标明的电源。设备必须使用有地线的供电系统供电。第三条线

（地线）是安全设施，不能不用或跳过。

拔掉电源 • 为安全地从设备拔掉电源，请拔掉所有设备后或桌面电源的电源线，或任何接到市

电系统的电源线。

电源线保护 • 妥善布线，避免被踩踏，或重物挤压。维护 • 所有维修必须由认证的维修人员进行。设备内部没有用户可以更换的零件。为避免出

现触电危险不要自己试图打开设备盖子维修该设备。

通风孔 • 有些设备机壳上有通风槽或孔，它们是用来防止机内敏感元件过热。不要用任何东

西挡住通风孔。

锂电池 • 不正确的更换电池会有爆炸的危险。必须使用与厂家推荐的相同或相近型号的电池。

按照生产厂的建议处理废弃电池。

FCC Class A Notice

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The Class A limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at his own expense.

This unit was tested with shielded cables on the peripheral devices. Shielded cables must be used with the unit to ensure compliance with FCC emissions limits.

Chapter One • Introduction ......................................................................................................1-1

About This Manual ....................................................................................................................1-2

About the MLC 104 Plus Series MediaLink® Controllers ....................................1-2

MLC 104 Plus Series features ...................................................................................................1-2

Additional features for IP models ..........................................................................................1-2

Controlling other devices .........................................................................................................1-3

Projector Control ........................................................................................................................ 1-3

How the MLC 104 Plus Series Controllers Work: MLC Components and

Interactions ....................................................................................................................................1-4

Optional Control Modules and IR 402 Remote Control ......................................1-5

System Requirements..............................................................................................................1-6

Hardware requirements ........................................................................................................... 1-6

Software requirements ...........................................................................................................1-6

Chapter Two • Operation, Features, and Cabling ...................................................2-1

Setup Checklist: How to Proceed With Installation .............................................. 2-2

Front Panel Features and Operation ..............................................................................2-3

Buttons .......................................................................................................................................2-3

Volume control ..........................................................................................................................2-4

Conﬁguration port....................................................................................................................2-5

Front Panel Security Lockout (Executive Mode) ...................................................................2-6

Enabling and disabling front panel lockout via the embedded Web pages

and the front panel ............................................................................................................. 2-6

Using the Web pages (IP models) Using the front panel (all models)

Preparing the MLC for front panel lockout ..........................................................................2-8

Setting up and

Scheduling front panel lockouts.........................................................................................2-8

enabling or disabling PINs.........................................................................2-8

................................................................................. 2-6

................................................................................2-7

IR Control ........................................................................................................................................2-8

IR learning .................................................................................................................................. 2-8

IR remote control ......................................................................................................................2-8

Panels and Cabling .................................................................................................................... 2-9

Host/Conﬁg port cabling ..........................................................................................................2-9

Right/rear panel and cabling .................................................................................................2-10

Projector/display connections ...........................................................................................2-10

Additional control connections ........................................................................................2-12

Power connection ..............................................................................................................2-20

Top panel: IR learning sensor ................................................................................................2-20

Left side panel: reset features ...............................................................................................2-21

PRELIMINARY

Resetting the Unit ....................................................................................................................2-22

Pinout Guide ...............................................................................................................................2-23

MLC 104 Plus Series • Table of Contents

TOC-i

Table of Contents, cont’d

Chapter Three • Software-based Conﬁguration and Control ........................3-1

Conﬁguration and Control: an Overview ...................................................................3-2

The Basic Setup Steps: a Guide to this Chapter and Other Resources ...... 3-2

Communicating with the MLC ...........................................................................................3-3

Conﬁguring IP-enabled MLCs for Network Communication ..........................3-3

Conﬁguring the MLC 104 IP Plus for network communication

via Global Conﬁgurator software ...........................................................................................3-4

Conﬁguring the MLC 104 IP Plus for network communication

using the ARP command ..........................................................................................................3-4

Conﬁguring the MLC 104 IP Plus for network communication via a Web browser ........3-5

Conﬁguring the MLC 104 IP Plus for network communication using SIS™ commands ...3-6

RS-232 ...................................................................................................................................3-6

Telnet ....................................................................................................................................3-6

Setting up the PC for IP communication with an IP-enabled MLC ....................................3-7

Global Conﬁgurator Software for Windows® .........................................................3-9

Downloading the software and getting started ................................................................3-10

PC system requirements .........................................................................................................3-10

Using Global Conﬁgurator: helpful tips ..............................................................................3-10

Resources and notes .......................................................................................................... 3-10

A brief guide to Global Conﬁgurator’s tabs .................................................................... 3-11

PRELIMINARY

Advanced Conﬁguration .....................................................................................................3-12

IR learning to create customized IR driver ﬁles ..................................................................3-12

Advanced conﬁguration options in Global Conﬁgurator .................................................3-12

Power Settings (Display power up/power down settings)

Volume settings ................................................................................................................. 3-13

Miscellaneous settings.......................................................................................................3-13

Conﬁguring an auxiliary (MLS, PVS) switcher .....................................................................3-14

Setting up passwords for IP models ..................................................................................... 3-14

Printing a wiring block diagram ...........................................................................................3-14

Updating ﬁrmware .................................................................................................................3-15

Saving and uploading the conﬁguration ............................................................................ 3-15

.............................................. 3-12

Controlling an IP Link-enabled MLC .............................................................................3-15

Embedded Web pages............................................................................................................3-15

Status ..................................................................................................................................3-16

System Status ...............................................................................................................3-16

Statistics ........................................................................................................................3-17

Conﬁguration ....................................................................................................................3-17

System Settings ...........................................................................................................3-18

Passwords .....................................................................................................................3-18

Email Alerts ..................................................................................................................3-19

Firmware Upgrade .......................................................................................................3-19

File Management...............................................................................................................3-20

Control ...............................................................................................................................3-21

User Mode .................................................................................................................... 3-21

IR Drivers ......................................................................................................................3-22

Serial Devices (serial drivers)

GlobalViewer® Web Pages ..................................................................................................... 3-23

.......................................................................................3-22

TOC-ii

MLC 104 Plus Series • Table of Contents

Customizing the MLC’s Control Web Pages ............................................................. 3-24

Chapter Four • SIS™ Programming and Control ........................................................4-1

Host-to-MLC Communications ............................................................................................4-2

MLC-initiated messages............................................................................................................4-2

Password information (IP models) ..........................................................................................4-3

Error responses ..........................................................................................................................4-3

Error response references ........................................................................................................4-3

Commands and Reponses .....................................................................................................4-4

Using the command/response tables .....................................................................................4-4

Symbol deﬁnitions ....................................................................................................................4-5

Command/response table for SIS commands ........................................................................ 4-8

Command/response table for special function SIS commands

(accessible via RS-232 only) ....................................................................................................4-33

Chapter Five • Special Applications ....................................................................................5-1

Using Monitoring to Make Functions Track Actual Conditions .....................5-2

Setting up a front panel button .............................................................................................5-3

Setting up monitoring conditions .......................................................................................... 5-4

Working With Combination Source Devices ..............................................................5-7

Available methods ....................................................................................................................5-7

Using an IRCM-DV+ control module and one MLC input button for DVD-VCR control ...5-7

Scheduling Front Panel Lockout Periods ...................................................................5-10

Sending E-mail by Pressing a Button (IP Models) ................................................5-11

Working With a Non-MediaLink Extron Switcher ................................................5-14

Using Digital Inputs ................................................................................................................ 5-15

Using a motorized surface access enclosure to trigger digital input .............................. 5-15

Using digital input of an IP model for an alert notiﬁcation system ................................5-17

Using Digital Outputs ............................................................................................................5-20

Controlling a Low Voltage Screen Motor Controller .........................................................5-20

Cabling the equipment .....................................................................................................5-20

Conﬁguring the MLC for screen control ..........................................................................5-21

Conﬁgure the MLC’s digital I/O ports to control the IPA T RLY4’s relays .................5-21

Conﬁgure the MLC’s Display Power buttons to operate the digital outputs .......... 5-22

Using an Ampliﬁer and Volume Controller with the MLC .............................5-25

Volume control hardware setup ...........................................................................................5-25

Volume control software setup ............................................................................................ 5-27

Controlling a Second Projector/Display .....................................................................5-29

Connecting the second projector/display ............................................................................5-29

Conﬁguring the MLC for a second projector/display .........................................................5-29

PRELIMINARY

MLC 104 Plus Series • Table of Contents

TOC-iii

Table of Contents, cont’d

PRELIMINARY

Customizing HTML Files to Control Devices, Modify Pages, and Send E-mail Alerts (IP models only)

Creating and using server side includes (SSIs) .....................................................................5-33

About server side includes and the MLC ..........................................................................5-33

SSI command types and syntax ......................................................................................... 5-34

Host vs. remote commands .........................................................................................5-34

Command syntax .........................................................................................................5-34

Example: SSI use in notiﬁcation e-mails .....................................................................5-34

SSI use in an MLC’s Web page .....................................................................................5-35

Creating and using query strings ..........................................................................................5-36

Query string command types and syntax .........................................................................5-36

Host vs. remote commands .........................................................................................5-36

Command syntax .........................................................................................................5-36

.....................................................5-33

Embedded Web

Chapter Six • Labeling, Installation, and Mounting ..............................................6-1

UL/Safety Requirements .........................................................................................................6-2

Installing or Replacing Button Labels ...........................................................................6-2

Button labeling procedure ...................................................................................................... 6-2

Moving a button cap to a different button ..........................................................................6-3

Wiring Peripherals to the MLC ...........................................................................................6-3

Mounting the MLC .....................................................................................................................6-4

Grounding to reduce electrostatic discharge .......................................................................6-4

Mounting the MLC to an electrical box or mud ring ...........................................................6-6

Installing an Extron MR Series mud ring ............................................................................... 6-7

Determining the installation location ................................................................................6-7

Preparing the site and installing the mud ring using the doglegs ................................... 6-7

Modifying the mud ring......................................................................................................6-8

Mounting the MLC to a wall or furniture ...........................................................................6-10

Rack mounting an MLC 104 IP Plus L ...................................................................................6-10

Procedure ........................................................................................................................... 6-10

UL rack mounting

Mounting the MLC in a Euro Channel .................................................................................6-11

guidelines ............................................................................................6-11

Appendix A • Reference Material ........................................................................................ A-1

Speciﬁcations — MLC 104 IP Plus Series ..................................................................... A-2

Speciﬁcations — MLC 104 Plus ......................................................................................... A-5

Part Numbers and Accessories .......................................................................................... A-7

Controllers ................................................................................................................................. A-7

Included parts ........................................................................................................................... A-7

Accessories ................................................................................................................................ A-7

Glossary ........................................................................................................................................... A-9

File Types: a Key to Extron-speciﬁc File Names .................................................... A-12

TOC-iv

MLC 104 Plus Series • Table of Contents

Cut-out Templates ................................................................................................................... A-13

MLC 104 Plus and MLC 104 IP Plus ....................................................................................... A-13

MLC 104 IP Plus AAP or MLC 104 IP Plus DV+ .................................................................... A-14

MLC 104 IP Plus L .................................................................................................................... A-15

MLM 104 LAAP ....................................................................................................................... A-16

MLM 104 6GWP ...................................................................................................................... A-17

Appendix B • Firmware Updates ...........................................................................................B-1

Determining the Firmware Version ................................................................................B-2

Using the Global Conﬁgurator software ...............................................................................B-2

Using a Web browser (IP models only) ..................................................................................B-2

Updating the Main Firmware .............................................................................................B-4

Locating and downloading the ﬁrmware .............................................................................B-4

Updating ﬁrmware via the MLC’s embedded Web page (IP models) ...............................B-4

Updating ﬁrmware via Extron Firmware Loader software .................................................B-5

Updating ﬁrmware via Extron IP Link™ File Manager software (for IP models) ..............B-7

Resetting the MLC and restoring its conﬁguration .............................................................B-9

Appendix C • Index ...........................................................................................................................C-1

Index ..................................................................................................................................................C-2

All trademarks mentioned in this manual are the properties of their respective owners.

68-1443-01 Rev. B

01 09

PRELIMINARY

MLC 104 Plus Series • Table of Contents

TOC-v

Table of Contents, cont’d

PRELIMINARY

TOC-vi

MLC 104 Plus Series • Table of Contents

MLC 104 Plus Series

Chapter One

Introduction

About This Manual

About the MLC 104 Plus Series MediaLink

How the MLC 104 Plus Series Controllers Work:

MLC Components and Interactions

Optional Control Modules and IR 402 Remote Control

Controllers

Projector Control

PRELIMINARY

System Requirements

Introduction

About This Manual

This manual provides detailed information and best practices recommendations about cabling and conﬁguring the Extron MLC 104 Plus Series MediaLink® Controllers, and reference information about the controllers’ speciﬁcations, dimensions, programming, and special applications.

It does not contain instructions on the most basic setup steps: those are covered in the MLC 104 Plus Series Setup Guide, which describes how to set up the hardware, how to use the Global Conﬁgurator (GC) program to download drivers, add A/V devices to a GC conﬁguration, conﬁgure the front panel buttons, set a shutdown schedule, and set up e-mail alerts to ﬂag a projector disconnection or warn that lamp hours are exceeded.

About the MLC 104 Plus Series MediaLink® Controllers

The MLC 104 Plus Series MediaLink Controllers are capable of controlling a projector and various other items such as lights, a projector lift, or a screen motor. Throughout this manual they are also referred to as the MLC 104, MLC, or “controller.” All models offer RS-232 and IR-based projector (display) control; digital inputs and outputs for controlling items such as a projector lift, motorized projection screen, and lights; and RS-232 remote control of an Extron switcher.

MLC 104 Plus requires GC version 2.50 or higher.

The IP models work with GC version 2.2 or higher

PRELIMINARY

MLC 104 Plus Series features

All models can be conﬁgured and controlled via a host computer using RS-232 communication, and the MLC 104 IP Plus models can also be conﬁgured and controlled via IP Link™ Ethernet control. Setup and control can be accomplished by simple ASCII commands (Simple Instruction Set, SIS™) or via the included Global Conﬁgurator program. The software offers many more setup options than does SIS programming.

All models offer front panel controls. The optional IR 402 remote control (which requires an optional IR signal repeater) and optional SCP 104 Series hardwired control pads can be used with the MLC, and they mirror the MLC’s front panel controls. Additionally, the MLC 104 IP Plus DV+ includes an IRCM-DV+ control module (for DVD and VCR control) installed in the faceplate.

Additional features for IP models

Via Ethernet/IP communication the MLC 104 IP Plus models can make use of the controller’s embedded Web pages, which include online diagnostics and monitoring of basic control features. As an integrated part of the MLC 104 IP Plus, IP Link provides the following advantages:

Global compatibility — The MLC uses standard Ethernet communication protocols,

including ARP, DHCP, ICMP (ping), TCP/IP, Telnet, HTTP, and SMTP.

Embedded Web page serving — The MLC 104 IP Plus offers up to 7.25 MB of

ﬂash memory for storing Extron and user-supplied Web pages, conﬁguration settings, and device drivers. Data in ﬂash memory is served at a transfer rate of 6 Mbits per second.

Multi-user support — Up to two hundred (200) simultaneous connections enable

each IP Link device to support many concurrent users and improve system throughput by sending information in parallel.

Management ability via Global Conﬁgurator 2.2 and higher — The included

software and the GlobalViewer Web pages associated with it allow you to control, monitor, and schedule various functions of products connected to IP Link products such as the MLC.

1-2

MLC 104 Plus Series • Introduction

NFIG

DISP

MLC

104 IP

Plus

VOLUME

VCR

RGBHV

S-Video

Audio

Video

DVD/VCR

Combo

Laptop

RS-232 or IR Projector control

Extron MLC 104 IP Plus

MediaLink Controller

Projector on/off control Projector input switching Projector volume control

Help Desk PC

Extron SI 3CT LP

Full-range Ceiling Speakers

BASS

TREB

I POW

AMPLIFI

MPA 122

LIMITER

STEREO

Extron MPA 122

Mini Power Amplifier

TCP/IP

Network

E-mail notiﬁcation — The MLC 104 IP Plus can be set up to send an e-mail when

the projector has been disconnected or the projector’s lamp has been used for a designated number of hours.

Controlling other devices

The MLC 104 Plus Series offers two methods of projector or display control: RS-232 or infrared (IR). The MLC can learn IR signals from remote controls to communicate with sources such as VCRs and DVD players. Users can create their own device drivers (IR or RS-232) or go to the Extron Web site (www.extron.com) to obtain device drivers.

A typical application for an MLC 104 IP Plus MediaLink Controller

Projector Control

The MLC can control a projector or other display device by using IR or RS-232 control. The MLC must be conﬁgured for projector control in one of the following ways before it will send commands to the projector:

• AnIRoranRS-232driverlecanbeinstalledfromadisk,downloadedfromthe

Extron Web site (www.extron.com), or downloaded from Extron using the driver subscription feature within Global Conﬁgurator. The driver is saved to a folder within C:\Program Files\Extron\Driver2, and it is uploaded to the MLC via Global Conﬁgurator.

• RS-232commandstringscanbeentereddirectlyfromahostcomputerusing

Extron Global Conﬁgurator software.

• IRcommandscanbeentereddirectlyfromanIRremotecontrolthroughIR

learning and the Extron IR Learner software to create a driver that the MLC can use. IR learning is convenient for installing new or updated commands into the MLC in the ﬁeld.

PRELIMINARY

MLC 104 Plus Series • Introduction

1-3

Introduction, cont’d

MAIN EVENT

(0.evt)

Host

Port

LAN

Port

Serial Driver

RS-232

Proj. Port

2-way

RS-232

Proj.

Proj. Driver

(2.evt)

MLC 104

IP Plus

Firmware

FPC*

Lights

with

Global

Config-

urator

Web

Browser

MLC 104 IP Plus

Memory

SCP*

Lights

* FPC = front panel control

SCP = secondary control panel

MAIN EVENT

(0.evt)

Host

Port

Serial Driver

RS-232

Proj. Port

2-way

RS-232

Proj.

Proj. Driver

(2.evt)

MLC 104

Plus

Firmware

FPC*

Lights

with

Global

Config-

urator

MLC 104 Plus

Memory

SCP*

Lights

* FPC = front panel control

SCP = secondary control panel

Refer to the Global Conﬁgurator help ﬁle or the IR Learner help ﬁle (which come with the software) for details on setting up the MLC and for downloading, programming, or learning projector control commands.

How the MLC 104 Plus Series Controllers Work: MLC Components and Interactions

Unlike the Extron MLC 206 Series MediaLink Controllers, the MLC 104 Plus Series requires and uses event ﬁles to perform all functions except basic input switching and volume control. The event ﬁles deﬁne, monitor, and govern how an MLC 104 Plus Series controller works. Below are example diagrams of how the MLCs interact with accessories, event scripts, drivers, ports, and input and output devices.

PRELIMINARY

The MLC can be conﬁgured completely via the Extron Global Conﬁgurator software. Once you have set up how you want it to work (assigned drivers to

1-4

MLC 104 Plus Series • Introduction

VCR CONTROL

REW PLAYFWD PAUSESTOP

SCREEN POSITION

DOWN UPSTOP

DVD & VCR CONTROL

PLAY NEXT/FWD PAUSE STOP

TUNER

PREV/REW

ENTER

TITLE MENU

TV/VCR

DVD VCR

CM-3BLB

CM-9BLB

AUDIO CONFERENCE

VOLUME

123ON/OFF

456HANG UP

789 FLASH

0#UNMUTE MUTE

IRCM-VCR

IRCM-DV+

CM-19AC

RCM-SC

CM-5BB

CM-3BLB

CM-9BLB

CM-20BB

IR 402

IR remote control

ports, conﬁgured buttons and digital inputs or outputs, and set up IP addresses and functions), that information is saved to a project ﬁle that is uploaded into the MLC.

The conﬁguration information is used to create the “main event” (0.evt) script ﬁle that deﬁnes the MLC’s operation. The main event ﬁle also controls and monitors ports, optional SCP control panel(s), and changes made at the MLC’s front panel (FPC, front panel control).

Each button on the MLC and on any connected SCPs has two switch numbers assigned to it: one for the button press, one for release. Scripts are compiled to generate the main event ﬁle to monitor any button press or release and to generate the actions (issuing commands, triggering relays, switching inputs) associated with the buttons.

Optional Control Modules and IR 402 Remote Control

The MLC can “learn” IR commands from a VCR’s, DVD’s, tape deck’s or other device’s remote control, allowing you to create an IR driver ﬁle that can be incorporated into the MLC’s event scripts. A command can be associated with each of the buttons on an optional infrared control module (such as the Extron IRCM-VCR, CM-5BB, CM-9BLB, or IRCM-DV+) in order to allow limited control of source devices.

A total of four control modules (a maximum of four control module addresses) can be installed with this MLC. Refer to the Control Modules User’s Manual and the

IRCM‑DV+ Control Module User’s Manual for installation details and read the Global Conﬁgurator Help ﬁle to learn about conﬁguration. See chapter 4 of this manual for

special SIS commands for the IRCM-DV+.

A few optional IRCM, RCM, and CM control modules

The buttons on the optional IR 402 remote duplicate the MLC’s front panel controls and also those of a VCR and a DVD player for normal operation (but not for setup). The IR 402 can also be used to control a MediaLink Switcher. The controller or switcher responds to commands from the IR 402 remote as if the corresponding button or knob were pressed or turned on the controller or switcher.

MLC 104 Plus Series • Introduction

1-5

PRELIMINARY

Introduction, cont’d

MLC 104 IP Plus

IR Link

IR 402

SIGNAL

IR LINK

CONFIG

DISPLAY

VOLUME

MLC 104 IP PLUS

VCR

DVD

OFF

30’ (max.)

40°40°

From a distance of no more than 30 feet and within 40° of the perpendicular axis, the IR 402 sends infrared (IR) signals to a MediaLink Controller or MediaLink Switcher via an optional, connected IR signal repeater.

The IR 402 remote’s Display Power buttons, Display Mute buttons, and the VCR and DVD control buttons will not function until they have been programmed using GC version 2.2 or higher (2.5 or higher for the MLC 104 Plus) and the conﬁguration has been uploaded into the MLC.

PRELIMINARY

N N

Setup operations cannot be performed from the remote control. Pressing the remote’s Display Mute On and Display Mute Off

buttons sends the 1M and 0M SIS commands (respectively) to the MLC. See page 4‑8 to learn about these commands.

To increase audio volume, press the Volume up (^) button, rotate the MLC’s

Volume knob clockwise, or select a larger number in the Control tab of the MLC’s embedded Web page.

IR commands are transmitted from the MLC’s Display RS-232/IR port (via IR Emitter) when the corresponding button is pressed on the remote or on the controller’s, SCP’s, or control module’s front panel. Refer to the Control Modules User’s Manual.

System Requirements

The MLC 104 Plus Series Controllers and Global Conﬁgurator have the following hardware and software requirements:

Hardware requirements

• Intel® Pentium® III, 1 GHz processor

• 512MBofRAM

• 50MBofavailableharddiskspace

• Anetworkconnectionwithaminimumdatatransferrateof10Mbps(100Mbps

is recommended) — for IP models

Software requirements

• Microsoft® Windows® operating system

○ Windows NT service pack 4, or ○ Windows 2000 service pack 2, or

1-6

MLC 104 Plus Series • Introduction

○ Windows XP service pack 2, or ○ a higher version of Windows

• MicrosoftInternetExplorer® 6.0 with ActiveX® enabled — for IP models

• MicrosoftWindowsScript5.6

Do not run Global Conﬁgurator software on a PC that uses an earlier

version of Windows.

MLC 104 Plus Series

Chapter Two

Operation, Features, and Cabling

Setup Checklist: How to Proceed With Installation

Front Panel Features and Operation

IR Control

Panels and Cabling

Resetting the Unit

PRELIMINARY

Pinout Guide

Operation, Features, and Cabling

Setup Checklist: How to Proceed With Installation

Get Ready

Familiarize yourself with the MLC's features.







Download and install the latest version of the Extron Global Conﬁgurator software and the latest driver package. (See the

MLC 104 Plus Series Setup Guide, chapter 1.)

PRELIMINARY



Congure the MLC



Obtain IP setting information from the network administrator for the MLC. (Read the MLC 104 Plus Series Setup Guide, chapter 3.)



Connect the MLC to the included external power supply. (See MLC 104 Plus Series Setup Guide, chapter 2.)



Connect the PC to the MLC via Ethernet patch or crossover cable. (See MLC 104 Plus Series Setup Guide, chapter 2.)



Conﬁgure MLC using Global Conﬁgurator. (Refer to MLC 104 Plus Series Setup Guide, chapter 3, and the Global Conﬁgurator help ﬁle.)



Create a new Global Conﬁgurator project.





Set the MLC’s IP address, subnet mask, and other IP settings (for IP models).



Deﬁne the MLC’s GlobalViewer Tree location.





Add the MLC to the project.





Deﬁne e-mail settings and contacts.





Add serial and IR drivers.



Conﬁgure ports (Display, MLS, and Digital I/O) and assign device drivers as



needed.



Conﬁgure front panel buttons.





Conﬁgure control module buttons.





Create a display shutdown schedule.





Create a display lamp hours warning e-mail (for IP models).





Create a display disconnection warning e-mail (for IP models).





Perform conﬁgurations for special applications, if needed. (See chapter 5.)





Save the Global Conﬁgurator project/conﬁguration.





Build and upload the conﬁguration.



2-2

Perform Physical Installation



 

MLC 104 Plus Series • Operation, Features, and Cabling

Install or replace button labels.



Cable peripheral devices to ports on the MLC. (See chapters 2 and 6 of this manual or chapter 2 of the setup guide.)



Test the system.



Mount the MLC to an electrical box, wall, furniture, or rack and ground the unit. (See chapter 6 in this manual.)

CONFIG

DISPLAY

VOLUME

MLC 104 IP PLUS

VCR

DVD

OFF

MLC 104 IP Plus Front Panel

3 4

Display power buttons, page 2-3

Input selection buttons, page 2-4

Volume control, pg. 2-4

Config port, page 2-5

N The front panels

of the IP and non-IP models are identical except for the product name.

Front Panel Features and Operation

Many features must be set up in order for the MLC to function. See chapter 3,

“Software‑based Conﬁguration and Control”, and the MLC 104 Plus Series Setup Guide for information about Global Conﬁgurator, which you must use to set up most features of the MLC.

Buttons

The MLC 104 Plus Series controllers have backlit buttons. The functions, events, and scripts associated with these buttons are available with all models. Pressing the corresponding button on the Extron IR 402 remote control or an Extron SCP 104 keypad will cause that button’s functions to be executed exactly as if you had pressed a front panel button.

By default all buttons illuminate brightly when selected (active), and light dimly when deselected. The button caps are removable so the button labels can be changed.

Each Display On/Off, Function/Room, and Input button can be set up to perform a sequence of several functions, which can be combinations of the following options:

• a driver operation—execute an RS-232 or IR control command that is part of a device driver (for a projector, VCR, DVD, audio source, etc.)

• a time delay operation—insert delays between executed commands

• a button light operation—change a front panel button’s brightness, color, or

ﬂashing

• a digital input/output operation—turn the digital output on or off, toggle it, or pulse it

• a user-deﬁned RS-232 operation—issue a non-driver-associated RS-232 command (one that you programmed separately) via a speciﬁc port (IR/Serial Out A, B, C; or the projector control port) or an internal command for the MLC, itself

Display On/Off buttons — After they have been conﬁgured, press the On

button to turn the projector or display device on, and press the Off button to

MLC 104 Plus Series • Operation, Features, and Cabling

2-3

PRELIMINARY

Button Command

Input 1 1! Input 2 2! Input 3 3! Input 4 4!

Operation, Features, and Cabling, cont’d

power it off. By default, only one of these two buttons can be selected (active) at once. Via Global Conﬁgurator (GC) software, other functions and relays can be associated with each of these buttons.

If the MLC is used without an optional switcher and the MLC has been set up

To avoid conﬂicts with the front panel lockout PIN feature, Extron recommends

conﬁguring the Display Power buttons so that the MLC sends projector/display commands upon the button release instead of on the button press.

Input selection buttons — These buttons, labeled 1 through 4, can

be conﬁgured to perform a variety of functions. Each button can be conﬁgured for input selection and to execute the IR or RS-232 commands of your choice, or trigger event scripts and/or port monitoring. By default they are a mutually exclusive group: only one of these buttons can be selected at a time. Also, by default each button is associated with an Extron input switching Simple Instruction Set (SIS bidirectional communication via the MLC’s MLS RS-232 port. See the picture at right.

Alternatively, the buttons can be reconﬁgured (via software) to select different inputs and to trigger different commands. See chapters 3 and 4 for details.

Press an input selection button to select the desired audio and video input on the projector or an optional Extron switcher. The button for that selection lights brighter and remains lit brighter until a different input is selected.

When these input selection buttons are conﬁgured for input switching, there is a

default 0.5 second delay between when one input is selected and when a different input can be selected. This allows time for the projector to adjust to the change of sync signals. The delay period is adjustable.

for use with a projector, the selectable inputs on the MLC correspond to the number of inputs available on the projector. If an optional Extron switcher is connected to the MLC, all four input buttons are selectable. Which buttons are or aren’t conﬁgured for input switching can be set via Global Conﬁgurator.

When an input selection button is designated for input switching, pushing that

button causes the MLC to send out an SIS input change command via the MLS RS‑232 connector. In addition it can make the MLC send projector control commands through the Display RS‑232/IR port, send a digital output signal, or send a serial command via the MLS RS‑232 port.

The default Extron SIS commands sent for each input via the MLS connector are shown at right. If desired, you can reassign (remap) any input from 1 to 99 to these input buttons. Button remapping can be convenient if a switcher is slaved to (controlled by) the MLC.

™

) command (1!, 2!, 3!, and so forth) and

2-4

Volume control

Volume knob and LEDs — Rotate this knob clockwise to increase the audio

volume, counterclockwise to decrease volume. Volume can be adjusted via this front panel knob, the corresponding knob on an SCP control panel, the Volume up/down buttons on an IR 402 remote control, or via RS-232/Telnet/ Web browser control.

The Global Conﬁgurator software lets you select whether this knob controls the projector’s audio levels or the optional switcher’s audio levels. If the knob controls the projector’s audio levels, you can specify incremental adjustments or range-based adjustments (via device driver only). See chapter 3 and the software’s help ﬁle for details.

MLC 104 Plus Series • Operation, Features, and Cabling

VOLUME VOLUME VOLUME VOLUME VOLUME VOLUME VOLUME

Range-based Volume Adjustment

Minimum,

0% of Max.

Volume

1% to 19%

of Max.

Volume

20% to 39%

of Max.

Volume

40% to 59%

of Max.

Volume

60% to 79%

of Max.

Volume

80% to 99%

of Max.

Volume

100% of

Max.

Volume

VOLUME VOLUME VOLUME VOLUME VOLUME VOLUME VOLUME

Range-based Volume Adjustment

VOLUME

Increment/Decrement-based Volume Adjustment

Minimum,

0% of Max.

Volume

1% to 19%

of Max.

Volume

20% to 39%

of Max.

Volume

40% to 59%

of Max.

Volume

60% to 79%

of Max.

Volume

80% to 99%

of Max.

Volume

100% of

Max.

Volume

Not all devices that use RS‑232 for audio level control can be properly controlled

using the MLC’s Volume knob. Some devices cannot respond quickly enough to the commands issued to them by the MLC.

• Iftheprojectorusesrangeadjustments,thatcanresultinchoppyaudiolevel

ramping (volume changing in jumps).

• Iftheprojectorusesincrementaladjustments(volumeup/downcommands),

that can result in slow audio ramping (requiring many turns of the knob to change the volume).

If you experience problems using range‑based audio control with a projector or other device, try slowing down the MLC’s volume knob command rate by using the 49# SIS command (see chapter 4 on SIS programming for details) or encoder scaling in Global Conﬁgurator (see the Global Conﬁgurator Help ﬁle). If you need further assistance, contact Extron and ask to speak with an applications engineer.

If the MLC is conﬁgured for use with a MediaLink Switcher or for some projectors, the MLC’s LEDs indicate volume ranges (with steadily lit LEDs) and minimum/maximum volume limits (with ﬂashing LEDs), as shown in the following diagram.

If the MLC is conﬁgured for increment/decrement volume adjustment, the LEDs scroll up/down brieﬂy. See the example below.

Conﬁguration port

Conﬁg (host control) port — This port makes it possible to upload and

conﬁgure device drivers and also to initiate IR learning via a front panel connection after the MLC has been installed.

Connect a Windows-based PC or an RS-232 control system to this 2.5 mm mini stereo-style (tip-ring-sleeve) connector. You can use the Extron 9-pin D to 2.5 mm stereo mini TRS RS-232 cable (part #70-335-01) or make your own cable. See page 2

This port requires 38400 baud communication, a higher speed than many

other Extron products use. The conﬁguration software automatically sets the connection for the appropriate speed. If using HyperTerminal or a similar application, make sure the PC connected to these ports is set for 38400 baud.

Extron recommends conﬁguring and controlling the MLC via the LAN

connector. Ethernet connections are faster and more reliable.

-9 for a wiring diagram and port protocol.

PRELIMINARY

MLC 104 Plus Series • Operation, Features, and Cabling

2-5

Operation, Features, and Cabling, cont’d

Front Panel Security Lockout (Executive Mode)

To prevent accidental changes to settings, the MLC features front panel security lockout (executive) modes for disabling access to controls. When front panel lockout is enabled, if a button is pressed, the button ﬂashes red, but no change occurs. Nothing—not input switching, projector control, room control, volume adjustment, or any other knob- or button-executable function—results from front panel actions when lockout is active. Button and knob functions on the IR 402 remote control, SCPs, or control modules are also locked. Changes can still be made via RS-232 or, for IP models, via Ethernet (Telnet or Web browser) control.

The SIS command 3X corresponds to and also enables this mode ( For details, see chapters 3 and 4. The only way to override a front panel lockout via the front panel is to enter a personal identiﬁcation number (PIN) to unlock the panel, using the MLC’s input buttons as a numeric keypad for PIN entry, as shown

page 2-7.

Enabling and disabling front panel lockout via the embedded Web pages and the front panel

Front panel lockout can be enabled/disabled using the embedded Web pages whether or not a PIN has been set. However, a PIN must be set up before you can enable or disable lockout using the front panel buttons.

Using the Web pages (IP models)

1. Using a Web browser, enter the MLC’s IP address to open the MLC’s embedded Web page. If an administrator password has been set and if you are prompted to do so, type in the administrator password.

2. Click on the Configuration tab, which opens to the System Settings page.

3. Select either Off or Disable Front Panel, SCP, Control Modules and IR in the

Executive Mode settings area. See the following picture.

see page 4 -10).

PRELIMINARY

If Disable Front Panel, SCP, Control Modules and IR is selected via the

System Settings factory default Web page, front panel lockout can’t be enabled/ disabled via the front panel unless PIN Mode is enabled. See page 4‑40 to ﬁnd the SIS commands for PIN enabling/disabling.

2-6

MLC 104 Plus Series • Operation, Features, and Cabling

CONFIG

DISPLAY

VOLUME

OFF

CONFIG

DISPLAY

VOLUME

OFF

CONFIG

DISPLAY

VOLUME

CONFIG

DISPLAY

VOLUME

OFF

CONFIG

DISPLAY

VOLUME

OFF

CONFIG

DISPLAY

VOLUME

OFF

CONFIG

DISPLAY

VOLUME

CONFIG

DISPLAY

VOLUME

Press and hold

both Display On/Off buttons simultaneously.

The Display On/Off buttons light green, the other buttons dim, and the bottom Volume LED blinks.

While still pressing the Display buttons, enter the PIN. Use the input selection buttons as a 4-key numeric keypad; press one button at a time.

One green Volume LED lights at a time as the buttons are pressed.

Release

all

buttons.

Release

all

buttons.

If the correct PIN is entered, the green Volume LEDs flash and all buttons flash red 3 times, indicating that front panel is locked.

Locking the Front Panel of an MLC 104 Plus Series Controller

Unocking the Front Panel of an MLC 104 Plus Series Controller

1 2

If an incorrect PIN is entered, no buttons flash, the green Volume LEDs turn off, and the red (top) LED blinks.

Release

all

buttons.

If the correct PIN is entered, the green Volume LEDs flash and all buttons flash green 3 times, indicating that front panel is locked.

If an incorrect PIN is entered, no buttons flash, the green Volume LEDs turn off, and the red (top) LED blinks.

This example shows the default administrator PIN:

1 2a , 4 2b , 2 2c , 3 2d .

This example shows the default administrator PIN:

1 2a , 4 2b , 2 2c , 3 2d .

Press and hold

both Display On/Off buttons simultaneously.

The Display On/Off buttons light red, the other buttons dim, and the bottom Volume LED blinks.

While still pressing the Display buttons, enter the PIN. Use the input selection buttons as a 4-key numeric keypad; press one button at a time.

One green Volume LED lights at a time as the buttons are pressed.

1 2

Then the buttons light as they were lit before front panel lockout was set.

Release

all

buttons.

Using the front panel (all models)

One or more PINs must be conﬁgured before this procedure can be used. See “Preparing the MLC for front panel lockout” on page 2-8. To lock/unlock the front panel, you use the Display On/Off buttons to change modes and use the input buttons as a numeric keypad.

N N

Make sure the projector or display is off before using a PIN to lock the front panel. Failure to conﬁgure the On or Off buttons to send display/projector commands

upon button release (instead of button press) may cause problems with the PIN Mode feature. (If one On/Off button is pressed before the other, and the buttons are conﬁgured to send commands at the button press, the ﬁrst button’s actions can be executed, preventing you from locking the front panel until the display’s warm‑up or cooldown period ﬁnishes.)

The PIN can be

entered via either the MLC or the SCP.

PRELIMINARY

MLC 104 Plus Series • Operation, Features, and Cabling

2-7

Operation, Features, and Cabling, cont’d

MLC 104 IP Plus Top Panel

IR Learning Receiver

1 2 3

4 5 6

7 809

2"–12" (4–30 cm)

Preparing the MLC for front panel lockout

To allow access to front panel changes to speciﬁc personnel while the front panel is locked, you can set a user and/or administrator PIN and set which type of PIN, if any, is allowed to unlock the panel.

Setting up and enabling or disabling PINs

Using the Advanced Configuration tab within Extron Global Conﬁgurator (GC) software, you can conﬁgure which PIN to enable (which PIN will be allowed to unlock the front panel), or disable both PINs so that no one can access the front panel during front panel lockout. And you can set the fourdigit PINs for the administrator and for users.

PRELIMINARY

Scheduling front panel lockouts

IR Control

IR learning

Each digit of the PIN must be a number

from 1 to 4 because they represent the MLC’s four input buttons, which will be used as a numeric keypad. By default, both PINs are set to 1423. Refer to the Global Conﬁgurator

Help ﬁle for the PIN setup procedure.

You can set the MLC’s front panel to be automatically locked at certain times and days by setting up a schedule using the Schedule tab within the Global Conﬁgurator software and uploading it to the MLC. The Global Conﬁgurator Help ﬁle includes instructions on how to set up a scheduled action.

The IR learning receiver sensor on the MLC 104 Plus Series’ top panel can receive and “learn” commands from other devices’ infrared remotes so you can create an IR driver ﬁle to control the projector or input devices such as a VCR or DVD player. IR learning of projector control codes is only necessary if there are no RS-232 codes available for that projector or if you need to customize the driver. Refer to the IR Learner help ﬁle for IR learning procedures.

This receiver accepts infrared signals of from

30 kHz to 62 kHz. The IR remote control must be pointed directly at the receiver for best results. The diagram at right indicates the best distances and angles at which to hold the remote control.

2-8

The MLC 104 Plus requires IR Learner version 1.23

or higher.

IR remote control

The MLC 104 Plus Series controllers do not have a built-in IR receiver that accepts signals for controlling the MLC, itself. However, you can connect an Extron IR Link or an IR Sensor remote IR receiver to the MLC’s CommLink port as shown in “Additional control connections,” starting on page 2-12. Those devices can receive signals from an Extron IR 402 infrared remote control, which mirrors the MLC’s front

MLC 104 Plus Series • Operation, Features, and Cabling

panel controls, and sends them to the MLC.

CONFIG

DISPLAY

VOLUME

MLC 104 IP PLUS

VCR

DVD

OFF

MLC 104 Plus Series Front Panel

6 feet

(1.8 m)

Part #70-335-01

9DBF-2.5mm TRS cable_031504.eps

Sleeve (Gnd)

Ring

Tip

9-pin D Connection TRS Plug

Pin 2 Computer's RX line Tip Pin 3 Computer's TX line Ring Pin 5 Computer's signal ground Sleeve

Panels and Cabling

Host/Conﬁg port cabling

Front panel Conﬁg (host control) port — For MLC conﬁguration and control,

connect a Windows

-based PC or an RS-232 control system to the MLC via this 2.5 mm mini stereo jack. This port is accessible even after the MLC has been installed and cabled. The optional 9-pin D to 2.5 mm stereo mini TRS RS-232 cable (part #70-335-01, shown below) can be used for this connection.

RS-232 protocol:

•38400 baud

•1stopbit

•noparity

•8databits

•noowcontrol

This conﬁguration port requires 38400 baud communication. This is a higher

speed than many other Extron products use. Global Conﬁgurator software may automatically set the connection for the appropriate speed. If using HyperTerminal or a similar application, make sure the PC or control system connected to these ports is set for 38400 baud.

For the IP models, Extron recommends conﬁguring and controlling the MLC via

the LAN connector on the right side panel. Ethernet connections are faster and more reliable.

MLC 104 Plus Series • Operation, Features, and Cabling

PRELIMINARY

2-9

Operation, Features, and Cabling, cont’d

RUN 100

2 3

GROUND

IR IN

GROUND

IR OUT

SCP

GROUND

Tx Rx

DISPLAY

RS-232/IR

LAN

PRESS TAB WITH

TWEEKER TO REMOVE

A B

MLS PWR

RS-232 12V

DIGITAL

I/O

A B C D E

COMM LINK

+V OUT

GROUND

+12V IN

Rear Panel

MLC 104 IP Plus Right Side Panel

(IP models only)

Projector/

Panel Display

MLC 104 Plus Series

Right Side Panel

To a Source’s IR Receiver

Ground ( )

Receive (Rx)

Transmit (Tx)

Ground ( )

Receive (Rx)

Transmit (Tx)

Bidirectional RS-232

Ground ( ) IR Signal

Unidirectional IR Output

via White Striped Wire

Strip wires 3/16”

(5 mm)

max.

NOTE The connector accepts one wire

per pole. You may need to splice projector and IR Emitter ground wires to a single wire that is inserted into this port.

IR Emitter

100'

(30.5 m)

GRO UND

IR OU T

DISPLAY

RS-232/IR

Right/rear panel and cabling

Display control (Display RS-232/IR) port (page 2-10)

CM/IR/SCP (CommLink) port (page 2-12)

Digital I/O ports (24 V, 1 A) (page 2-14 and “Using Digital Inputs” and

“Using Digital Outputs”

in chapter 5)

PRELIMINARY

2-10

MLS connector (page 2-17)

PWR (power) connector (page 2-20)

LAN (IP) connector and LEDs (page 2-19) — IP models only

Projector/display connections

Display control (Display RS-232/IR) port (-5 VDC to +5 VDC) —

From this port, commands from a projector driver or user-deﬁned command strings entered via Global Conﬁgurator can be sent to the display device. Connect a cable between the projector or display and the left three poles (TX, RX, Ground) of this 3.5 mm direct insertion captive screw connector for bidirectional RS-232 control. The IR Out and Ground pins (the right two poles) can be used for one-way infrared signal output to control the display/ projector or some other device, such as a VCR or DVD player. Use the following illustrations as a wiring guide.

Wiring for RS-232 display control and IR source device control

MLC 104 Plus Series • Operation, Features, and Cabling

Projector,

Panel Display,

or Source Device

MLC 104 Plus Series

Right Side Panel

Ground ( ) IR Output

Ground ( ) IR Control

Unidirectional IR

Strip wires 3/16” (5 mm) max.

GRO UND

IR OU T

DISPLAY

RS-232/IR

(+)

(-)

(+)

(-)

(+)

(-)

(+)

(-)

IR Signal

Ground

Single and Dual IR Emitter Two Single IR Emitters

Dual IR EmittersTwo Single & 0ne Dual IR Emitter

Ground

(+)

(-)

(+)

(-)

(+)

(–)

Black wire w/white stripe

Black wire

Legend

VCR

DVD Player

Wiring for IR display control

Wiring varies depending on the projector/display model. In most cases the drivers are bidirectional, but sometimes only the transmit (Tx) and ground connections will be needed for projector/display control. For bidirectional RS-232 communication, the transmit, ground, and receive pins must be wired at both the MLC and the projector or display.

Each projector or display may require different wiring. For details, refer to

the manual that came with the projector/display or the Extron device driver communication sheet.

Maximum distances between the MLC and the device being controlled may vary

up to 200 feet (61 m). Factors such as cable gauge, baud rates, environment, and output levels (from the MLC and the device being controlled) all affect transmission distance. Distances of about 50 feet (15 m) are typically not a problem. In some cases the MLC may be capable of transmitting and controlling a given device via RS‑232 up to 250 feet (76 m) away, but the RS‑232 response levels of that device may be too low for the MLC to detect.

Wiring for IR control of up to two sources

Alternatively, an MLC can use infrared signals and IR Emitters to control several source devices. However, the MLC’s direct insertion captive screw connectors have small openings that accept just one wire per pole. To connect up to two IR Emitters to the MLC, insert one ground and one signal wire in the MLC’s Display RS-232/IR port, then connect the IR Emitters to those wires. If using all single emitters or all double emitters, wire the emitters in parallel. If using a mix of both single and dual emitters, see the

IR Emitter

Installation Guide, part number 68-808-01.

MLC 104 Plus Series • Operation, Features, and Cabling

2-11

PRELIMINARY

Operation, Features, and Cabling, cont’d

3/16” (5 mm) Max.

7/8”

(22 mm)

Heat Shrink on Outer Jacket to Inner Conductor Transition

Extron

Comm-Link

Cable

Additional control connections

CM/IR/SCP (CommLink) port — For remote control of the MLC 104 Plus

Series controller or other items, you can connect up to four Extron control modules (IRCMs, ACMs, RCMs, CMs), one Extron infrared signal repeater (IRL 20 or IR Link), and/or up to two Extron SCP 104 control panels to this port. A maximum of seven devices can be connected to this port. See the ﬁgures on pages 2-13 and 2-14.

The SCP 104 must have ﬁrmware 1.01 or greater and DIP switch 4 in the

On (up) position to operate with an MLC 104 Plus Series controller. Refer to the SCP 104 User’s Manual for more details.

The SCP 104 replicates the MLC’s front panel controls. The SCP 104 and the IR signal repeater can receive IR signals from an optional IR 402 remote control and send them to the controller. Control modules can be used (once the MLC is set up) to control VCRs, DVD players, tape decks, a projector lift, or screen control. Refer to the appropriate device’s user’s manual.

If outside factors such as ﬂuorescent light interfere with and affect the function

of the MLC, you can disable IR control of the MLC. Using a special function SIS command (65#), you can turn off the MLC’s ability to receive IR signals from IR signal repeaters and SCPs.

The control modules, IR signal repeater, and SCPs can be daisy chained. Wire the connections as shown in the diagrams on the following pages.

PRELIMINARY

Extron Comm-Link (CTL and CTLP) cable is recommended for these connections. Before inserting wires in the connectors, strip the cable and apply heat shrink as shown at right.

For best results and to avoid short circuits, Extron

recommends using shielded wires or wires insulated using heat shrink (instead of bare wires) for the common/drain wires.

The maximum distance between the MLC and a

connected device is 200’ (61 m).

The CommLink port provides up to 12 VDC for powering the SCP control panel

or other devices. The automatic current protection circuit for this port limits the draw to 0.5 amperes.

SCP control panel or control modules (CM, IRCM, RCM) used with the MLC are

affected by front panel security lockout (executive mode) status changes.

2-12

MLC 104 Plus Series • Operation, Features, and Cabling

Extron CTLP Cable Color Code:

Ground ( ) & Drain Wire

E D C B A

SCP Communication Modulated IR (for IR Link) Control Module Communication

+12 VDC

= White

= Black and Drain Wire

= Violet

= Gray

= Red

Heat Shrink over Drain Wire

MLC 104 Plus Series

Right Side Panel

IR IN

SC P

A B C D E

COMM LINK

+V OU T

GRO UN D

SCP communication (IR)

Modulated IR (from IR Link)

Ground ( ) IRCM, ACM, RCM

+12 VDC

C B A

Maximum = 2 SCPs Per System

Maximum = 4 Control Modules (4 module addresses)

Maximum = 1 IR Link

Ground ( )

IRCM/ACM/RCM

+12 VDC

Ground and Drain

+12 VDC

DVD & VCR CONTROL

PLAY NEXT/FWD PA USE STOP

TUNER

PREV/REW

ENTER

TITLE MENU

TV/VCR

DVD VCR

IRCM-DV+

SCP 104

IR Link

IR 402

SIGNAL

IR LINK

DISPLAY

VOLUME

OFF VCR

DVD

SCP 104

200' (61 m) Max. to Last Device

MLC 104 Plus Series Rear Panel

RUN 100

2 3 4

SCP 104 Rear Panel

ADBC EADBC E

CM-3BLB

Rear

ADBC EADBC E

CM-3BLB

Rear

CM-3BLB

CM-3BLB Front

CM-3BLB

CM-3BLB Front

Basic connections to an SCP, control module, and IR signal repeater

If you connect a CM‑3BLB or CM‑9BLB to an SCP 226’s 3‑pole connector

instead of to its 5‑pole connector, the CM‑xBLB control module’s buttons will not light.

MLC 104 Plus Series • Operation, Features, and Cabling

PRELIMINARY

2-13

Operation, Features, and Cabling, cont’d

MLC 104 IP Plus DV+ Rear Panel

A DB C EA DB C E

RUN 100

ADBC EADBC E

2 3 4

SCP 104 Rear Panel

IRCM-DV+ Rear Panel

ADBC EADBC E

2 3 4

SCP 104 Rear Panel

IRCM-DV+ Rear Panel

Factory-wired MLC - to - IRCM-DV+ Connection

Right

Side Panel

GR OUN D

DIGITAL

I/O

MLC 104 IP Plus DV+ connections: The MLC 104 IP Plus DV+ consists of an MLC 104 IP Plus controller and an

IRCM-DV+ installed in a high-impact plastic faceplate. The wiring is the same as in the previous diagram, except the IRCM-DV+ is cabled to the MLC at the factory, as shown in the following diagram.

PRELIMINARY

2-14

MLC 104 Plus Series • Operation, Features, and Cabling

An MLC 104 IP Plus DV+ with SCPs and additional control modules

Digital I/O ports — The Digital I/O area (shown at right) provides

three ports that can be conﬁgured as digital inputs or outputs, with or without +5 VDC pull-up. Connecting these ports to sensors, switches, LEDs, or relays allows for a way to trigger events or functions (such as triggering relays, issuing commands, or sending an e-mail) that have been conﬁgured using Global Conﬁgurator (GC) software.

Conﬁgure these ports using Global Conﬁgurator software or SIS commands

ﬁrst, and then connect wires the MLC’s ports. A mismatch between port conﬁguration and wiring can cause malfunctions or unit failure.

Digital input — To allow the MLC to monitor devices such as push buttons, connect a switch, motion sensor, moisture sensor, tally feedback output, or a similar item to a digital input port. When one of these ports is conﬁgured as a digital input, it is set to measure two states: high and low. The port accepts 0 to 12 VDC input. The threshold voltages are as follows: a voltage below

2.0 VDC is measured as logic low, and a voltage above 2.8 VDC is measured as logic high. There is also an internal, +5 VDC, selectable, pull-up resistor for this circuit.

MLC104 DigInput-02

MLC 104 IP Plus

+12 V

Digital Input

Normally Open Switch

GND

2k ohms

SW 2

+5.0 V

CTL

Digital input is triggered b

y an external switch wired between the I/O pin and ground. The pull-up resistor to +5.0 VDC is activated (switch 2 is enabled/closed).

Pin 1, 2, or 3 of the Digital I/O Port

Digital I/O Port GND

MLC104 DigInput-04

SW 1

MLC 104 IP Plus HSA 822M/MS

+12 V+12 V

Digital Input

GND

Status Pin

GND

2k ohms

SW 2

+5.0 V

CTL CTL

Digital input at the MLC is triggered by a digital output from a motorized Extron HSA 822M.

A closure to ground (switch 1) occurs when a certain condition is met on the HSA. This closure to ground triggers the MLC.

The MLC must have the pull-up resistor to +5.0 VDC activated (switch 2 is enabled/closed).

Pin 1, 2, or 3 of the Digital I/O Port

Digital I/O Port

GND

Using these pins and an external switch to trigger digital input

Using a motorized surface access enclosure to trigger digital input

See “Using Digital Inputs” in chapter 5, “Special Applications”, for a wiring diagram for this example.

MLC 104 Plus Series • Operation, Features, and Cabling

PRELIMINARY

2-15

Operation, Features, and Cabling, cont’d

MLC104 DigOutput-01

MLC 104 Plus Series

+12 V

SW 1

I/O

GND

2k ohms

SW 2

+5.0 V

CTL

When a digital I/O pin is configured as a digital output, it is set to offer two output states: “on” and “off”.

When the port is set to an “on” state, switch 1 (SW 1) closes and the I/O pin connects to ground.

When the port is set to the “off” state, switch 1 opens and the I/O pin floats.

The MLC 104 Plus Series controller cannot provide TTL level outputs like some of the IP Link interfaces. Switch 2 cannot be enabled when I/O pin is used as an output.

When used as a digital output, a digital output pin on the MLC may not work with certain devices requiring contact closure control. Although the illustration shows a short to ground when switch 1 is enabled, the actual circuit does not provide a completely grounded output. For any devices requiring contact closure control, it is recommended that relays be used.

Pin 1, 2, or 3 of the Digital I/O Port

Digital I/O Port GND

MLC104 DigOutput-02

MLC 104 Plus Series

+12 V

390

Ohms

LED

+5 V

External Source

Digital Output

GND

CTL

The digital output pin drives an LED using an external +5 VDC source.

The LED lights only when the I/O pin is set to “on” (switch 1 is closed).

SW 1

N The I/O pin is capable of sinking a maximum of 250 mA from 12 VDC, max.

Digital output — To power LEDs, incandescent lights, or other devices that accept a TTL signal, or to provide contact closure control for projector lifts, motorized screens, room or light switches via an Extron IPA T RLY4, you can use one or more of these ports as a digital output. Each I/O port is capable of accepting 250 mA, maximum. If the application calls for TTL compatibility, the digital output circuit can be set up to provide a 2k ohm pull-up resistor to +5 VDC.

PRELIMINARY

2-16

MLC 104 Plus Series • Operation, Features, and Cabling

MLC104 DigOutput-03

MLC 104 Plus Series

+12 V+12 V

Ohms

LED

Digital

Output

GND

CTL

SW 1

Pin 1, 2,

or 3

The digital output pin drives an LED using the +12 VDC output of the controller as a voltage source.

The LED lights only when the I/O pin is set to “on” (switch 1 is closed).

N The I/O pin is capable of sinking a maximum of 250 mA from 12 VDC, max.

MLC104 DigOutput-04

Lamp

MLC 104 Plus Series

+12 V+12 V

Digital

Output

+12 V Out

GND

CTL

SW 1

The digital output pin drives an incandescent lamp using the +12 VDC output of the controller as the voltage source.

The lamp lights only when the I/O pin is set to “on” (switch 1 is closed).

MLS connector — To control an optional Extron switcher or other RS-232

controllable device, connect a cable between this 3.5 mm direct insertion captive screw connector and the RS-232 port of the other device. By default this port supports any Extron switcher without additional drivers. If it is used to control other products, additional device drivers may be required.

If you connect an optional switcher (such as an Extron MLS Series or PVS Series switcher) to the MLC, you must connect a ground wire between the switcher and the MLC, as shown in the following diagrams.

The commands issued from this port are standard Extron SIS commands, and

they follow the typical Extron RS‑232 protocol:

•9600baud

•8databits

•1stopbit

•noparity

MLC 104 Plus Series • Operation, Features, and Cabling

PRELIMINARY

2-17

Operation, Features, and Cabling, cont’d

Connecting an MLC 104 Plus Series controller to an external power supply

MLC/IR

A B C

MLS 304SA Rear Panel

Connecting an MLC 104 Plus Series to a MediaLink Switcher and an external power supply

MediaLink Switcher's rear panel MLC/IR port

NOTE You must connect a

ground wire between the MLC and MLS.

MLC's MLS and Power ports

NOTE If you use cable that

has a drain wire, tie the drain wire to ground at both ends.

GROUN D

IR IN

GROUN D

IR OU T

SCP

GROUN D

DISPLAY

RS-232/IR

LAN

PRESS TAB WITH

TWEEKER TO REMOVE

A B

DIGITAL

I/O

A B C D E

COMM LINK

+V OU T

GROUN D

+12V IN

MLS

RS-232

PWR 12V

AUDIO INPUTS

LINE LEVEL

MONO

AUDIO

AUX/MIX

ADJUST

-42dB TO

+24dB

INPUTSOUTPUTS

VIDEO

INPUTS

MONITOR OUT

LINEOUT

100-240V

1.0A MAX.

50-60Hz

RS-232/MLC/IR

RxIR 12V

PREAMP

AMPLIFIED OUTPUT

4/8 ohm

RIGHTLEFT

STEREO OR DUAL MONO

CLASS 2 WIRING

MLC 104 IP Plus

Right Side Panel

PWR

12V

MLS

RS-232

GR OUN D

A B

+1 2V IN

PWR

12V

MLS

RS-232

GR OUN D

A B

+1 2V IN

Ground ( )

Transmit (Tx)

Receive (Rx)

Transmit (Tx)

Receive (Rx)

B A

Strip wires 3/16” (5 mm) max.

Ground ( )

+12 VDC input

Ground ( )

+12 VDC input

Ground all devices.

External

Power Supply

(12 VDC)

External

Power Supply

(12 VDC)

External

Power Supply

Ground all devices.

MLC's MLS and

Power ports

PWR

12V

MLS

RS-232

GR OUN D

A B

+1 2V IN

Ground ( )

+12 VDC

Transmit (Tx)

Receive (Rx)

Transmit (Tx)

Heat Shrink over Shield

Receive (Rx)

B A

NOTE If you use cable that has a drain

wire, tie the drain wire to ground at both ends.

RS-232/MLC/IR

PVS 204SA Switcher's rear panel RS-232/MLC/IR port

ABCDE

Tx Rx IR

+12V

Ground ( )

Heat Shrink over Shield

Connecting an MLC 104 Plus Series controller to a PVS Switcher

PRELIMINARY

2-18

MLC 104 Plus Series • Operation, Features, and Cabling

LAN

RJ-45 Port

Link LED

Activity

12345678

RJ-45 Connector

Insert

Tw isted

Pair Wires

Pins:

Side View

Straight-through Cable

(for connection to a switch, hub, or router)

End 1 End 2

Pin Wire Color Pin Wire Color

1 white-orange 1 white-orange 2 orange 2 orange 3 white-green 3 white-green 4 blue 4 blue 5 white-blue 5 white-blue 6 green 6 green 7 white-brown 7 white-brown 8 brown 8 brown

Crossover Cable

(for direct connection to a PC)

End 1 End 2

Pin Wire Color Pin Wire Color

1 white-orange 1 white-green 2 orange 2 green 3 white-green 3 white-orange 4 blue 4 blue 5 white-blue 5 white-blue 6 green 6 orange 7 white-brown 7 white-brown 8 brown 8 brown

LAN (IP) connector and LEDs (IP models only) — An Ethernet connection

can be used to connect and to control the MLC (and the devices connected to it) in an Ethernet network. Plug a cable into this RJ-45 socket and connect the other end of the cable to a network switch, hub, router, or PC connected to an Ethernet LAN or the Internet.

• For10Base-T(10Mbps)networks,useaCAT3orbettercable.

• For100Base-T(max.155Mbps)networks,useaCAT5cable.

You will also need to conﬁgure this port before using it. Activity LED — This yellow LED blinks to indicate

network activity.

Link LED — This green LED lights to indicate a good

network connection.

• Useastraight-through cable for connection to a switch, hub, or router.

• Use a crossover cable for connection directly to a PC. Wire the connector

as shown in the following tables.

Conﬁgure the settings for this port via either SIS commands or Global Conﬁgurator. See the programming sections of this manual (chapters 3 and 4) for details.

LAN port defaults:

•MLC’s IP address: 192.168.254.254

• gateway’s IP address: 0.0.0.0

•subnet mask: 255.255.0.0

•DHCP: off

MLC 104 Plus Series • Operation, Features, and Cabling

PRELIMINARY

2-19

Operation, Features, and Cabling, cont’d

Connecting an MLC 104 Plus Series controller to an external power supply

MLC's MLS and Power ports

PWR

12V

MLS

RS-232

GR OUN D

A B

+1 2V IN

Ground ( )

+12 VDC input

Ground all devices.

External

Power Supply

(12 VDC)

MLC 104 Plus Series Top Panel

IR Learning

Receiver

1 2 3

4 5 6

7 809

2–12" (4–30 cm)

3/16” (5 mm) MAX.

MLC's Power Port

12V

PWR

GROUND

+12V IN

Power Supply Output Cord

End View of Power

Supply Output Cord

SECTION A–A

Power connection

PWR (power) connector — To provide power to the MLC, connect a cable

between this port and a 12 VDC, 2 amp (maximum) power supply. See the following diagram.

Power the controller via an external power supply, not from an Extron switcher.

The controller requires a separate 12 VDC power supply.

Check the power supply’s

polarity before connecting it to the MLC. See the illustration at right.

PRELIMINARY

Top panel: IR learning sensor

In most cases, Extron has already produced an IR driver ﬁle for controlling the projector or display you plan to use. If a device driver ﬁle is not available, you can create your own using Extron IR Learner software, the projector or display’s remote control, and the MLC’s IR learning receiver sensor, shown below.

Refer to the IR Learner Help File for instructions on how to create the driver ﬁle. During the IR command capturing process, hold the projector’s remote between 2" and 12" from and pointed directly at the MLC’s IR learning sensor, as shown above.

The MLC 104 Plus requires IR Learner version 1.23 or higher.

2-20

MLC 104 Plus Series • Operation, Features, and Cabling

MLC 104 Plus Series Left Side

Reset button

Reset LED

Left side panel: reset features

Reset button and LED — Pressing this recessed button causes various IP functions

and Ethernet connection settings to be reset to the factory defaults. The green LED ﬂashes in a predetermined pattern depending on the selected reset mode. See “Resetting

the Unit” on page 2-22 for details.

PRELIMINARY

MLC 104 Plus Series • Operation, Features, and Cabling

2-21

Operation, Features, and Cabling, cont’d

The MLC reverts to the factory default firmware. Event scripting will not start if

the MLC is powered on in this mode. All user files and settings (drivers, adjustments, IP settings, etc.) are maintained.

If you do not want to update firmware, or you performed a mode 1 reset by mistake, cycle power to the MLC to return to the firmware version that was running prior to the mode 1 reset. Use the 0Q SIS command to confirm that the factory default firmware is no longer running (look for asterisks following the version number.)

Mode 3 turns events on or off. During resetting, the Reset LED flashes 2 times if events are starting, 3 times if events are stopping.

Mode 4

• Enables ARP capability.

• Sets the IP address back to factory

default.

• Sets the subnet back to factory default.

• Sets the default gateway address back

to the factory default.

• Sets port mapping back to factory default.

• Turns DHCP off.

• Turns events off.

The Reset LED flashes 4 times in quick succession during reset.

Mode 5 performs a complete reset to factory defaults (except the firmware).

• Does everything mode 4 does.

• Resets almost all the real time

adjustments: all audio settings, limit initial power up volume, power up/down delay, auto power down, and misc. options. This does not affect an optional MLS switcher, however.

• Clears driver-port associations and port configurations (IR/RS-232).

• Removes button configurations.

• Resets all IP options.

• Removes scheduling settings.

• Removes/clears all files from switcher.

The Reset LED flashes 4 times in quick succession during the reset.

Reset Mode Comparison/Summary

Mode

Activation Result Purpose/Notes

1 Hold down the recessed

Reset button while applying power to the MLC.

After a mode 1 reset

is performed, update the MLC’s firmware to the latest version. Do not operate the MLC firmware version that results from the mode 1 reset. If you want to use the factory default firmware, you must upload that version again. See appendix B, “Firmware Updates,” for details on uploading firmware.

3 Hold down the Reset button

for about 3 sec. until the Reset LED blinks once, then release and press Reset momentarily (<1 sec.) within 1 second.

4 Hold down the Reset button

for about 6 sec. until the Reset LED has blinked twice (once at 3 sec., again at 6 sec.). Then release and press Reset momentarily (for <1 sec.) within 1 second.

5 Hold down the Reset button

for about 9 sec. until the Reset LED has blinked three times (once at 3 sec., again at 6 sec., again at 9 sec.). Then release and press Reset momentarily (for <1 sec.) within 1 second.

Use mode 1 to revert to the factory default firmware version if incompatibility issues arise with user-loaded firmware.

Mode 3 is useful for troubleshooting.

Mode 4 enables you to set IP address information using ARP and the MAC address.

Mode 5 is useful if you want to start over with configuration and uploading, and also to replace events.

Resetting the Unit

There are four reset modes (numbered 1, 3, 4, and 5 for the sake of comparison with an Extron IPL product) that are available by pressing the Reset button on the side panel. The Reset button is recessed, so use a pointed stylus, ballpoint pen, or Extron Tweeker to access it. See the following table for a summary of the modes.

Review the reset modes carefully. Using the wrong reset mode may result

in unintended loss of ﬂash memory programming, port reassignment, or a controller reboot.

The reset modes listed below close all open IP and Telnet connections and close

all sockets. The following modes are separate functions, not a continuation from Mode 1 to Mode 5. Also, IP settings do not apply to the MLC 104 Plus.

PRELIMINARY

2-22

MLC 104 Plus Series • Operation, Features, and Cabling

2 3

GROUND

IR IN

GROUND

IR OUT

SCP

GROUND

Tx Rx

DISPLAY

RS-232/IR

LAN

PRESS TAB WITH

TWEEKER TO REMOVE

A B

MLS PWR

RS-232 12V

DIGITAL

I/O

A B C D E

COMM LINK

+V OUT

GROUND

+12V IN

LAN

PRE

TAB WIT

WEEKER T

REM

MLC 104 Plus Series Right Side Panel

To / from sensors, switches, control equipment (screen controllers, lights, relays), LEDs, etcetera

Ground ( )

Transmit (Tx)

Receive (Rx)

To/from an optional Extron switcher

From an external 12 VDC, 2 A (max.) power supply

Ground ( )

Receive (Rx)

Transmit (Tx)

To a projector or display (or source device)

RS-232

IR Output

Ground ( )

Digital I/O

Ground ( ) +12 VDC input

SCP communication (IR)

Modulated IR (for IR Link or IRL 20)

Ground ( ) IRCM, ACM, RCM

+12 VDC

To / from optional Extron control modules, IR Link IR repeater, or SCP control pads

To / from LAN or Internet

(IP models only)

Pinout Guide

The illustration below summarizes the pin assignments of all of the MLC’s side panel connectors that are covered in detail on the preceding pages.

MLC 104 Plus Series • Operation, Features, and Cabling

PRELIMINARY

2-23

Operation, Features, and Cabling, cont’d

PRELIMINARY

2-24

MLC 104 Plus Series • Operation, Features, and Cabling

MLC 104 Plus Series

Chapter Three

Software-based Conﬁguration

and Control

Conﬁguration and Control: an Overview

The Basic Setup Steps: a Guide to this Chapter and Other Resources

Communicating with the MLC

Conﬁguring IP-enabled MLCs for Network Communication

Global Conﬁgurator Software for Windows

PRELIMINARY

Advanced Conﬁguration

Controlling an IP Link-enabled MLC

Customizing the MLC’s Control Web Pages

Software-based Conﬁguration and Control

Conﬁguration and Control: an Overview

An MLC Plus Series controller must be conﬁgured before use or it will not be able to control other devices. The IP models can be conﬁgured and controlled via a host computer attached to the right/rear panel LAN (local area network) port or the front panel Conﬁg port. The MLC 104 Plus can be conﬁgured from the front panel Conﬁg port. See chapter 2 for pin assignments and other details on the conﬁguration and control ports.

PRELIMINARY

• TheprimarymeansforconguringthecontrollerisbyusingtheExtronGlobal

• Alternatively,forIPmodels,thedefaultWebpagesembeddedwithintheMLC

• ThethirdwaytocontrolandcongurethecontrollerisbyusingSimple

For IP models, Extron recommends conﬁguring and controlling the MLC via the

LAN connector. Ethernet connections are faster and more reliable.

Conﬁgurator (GC) software. This method requires a properly conﬁgured PC with Windows Conﬁgurator generates GlobalViewer for IP models, can be used to control the MLC and make adjustments to its settings.

provide a means to perform some setup, adjustment, and control via a Web browser (Netscape® Navigator® version 6.0+, Internet Explorer version 5.5+, or Mozilla® Firefox® version 1.0+) from any type of network-enabled computer.

Instruction Set (SIS™) commands via Telnet (IP models), a Web browser (IP models), or RS-232. SIS commands are discussed in detail in chapter 4.

2000, Windows XP, or a higher version of Windows installed. Global

Microsoft® Internet Explorer® is currently the only Web browser that fully

supports GlobalViewer pages.

Netscape and Firefox cannot be used for viewing the Serial Control pages of the

factory‑embedded Web page. Run Internet Explorer to use those pages.

Web pages that are uploaded to the MLC and,

The Basic Setup Steps: a Guide to this Chapter and Other Resources

Setup/conﬁguration may be performed away from the job site.

Conﬁgure the MLC for network communication. See “Conﬁguring IP-

enabled MLCs for Network Communication“

on page 3-3.

Download or install Global Conﬁgurator and other Extron software

(IR Learner) and device drivers. See chapter 1 of the MLC 104 Plus Series Setup Guide, the software disk(s) that were shipped with the unit, and the

Extron Web site for instructions.

3-2

MLC 104 Plus Series • Software-based Conguration and Control

The MLC 104 Plus Series Setup Guide is shipped with the MLC. It is also

available as a PDF ﬁle on the Extron Web site (www.extron.com). The CD included with the unit contains software, device drivers, a PDF ﬁle of the full reference manual, and additional documentation available when the unit was shipped. The setup guide outlines most of the common tasks required to set up an MLC.

Create a Global Conﬁgurator project and conﬁgure basic settings and

functions. See chapter 3 of the

Global Conﬁgurator Help ﬁle for step-by-step procedures.

Conﬁgure additional or advanced functions, if desired. See the Global

Conﬁgurator Help ﬁle. For information on IR learning, read the IR Learner Help ﬁle.

Save and upload the conﬁguration to the MLC. See the MLC 104 Plus Series

Setup Guide, chapter 3.

For IP models, control the MLC and devices connected to it by using the

MLC’s embedded Web pages or its GlobalViewer (GV) Web pages. See

“Controlling an IP Link-enabled MLC” later in this chapter.

MLC 104 Plus Series Setup Guide, or see the

Communicating with the MLC

To communicate with the MLC, you must power on the MLC and the PC you’ll use to conﬁgure it, and connect the two devices for IP (network, for IP models) or serial (RS-232) communication.

• Power: see chapter 2 for wiring instructions. It’s best to power the unit using the 12 VDC external power supply that is shipped with the MLC.

• Communication: to connect the MLC to a network (IP models) or to connect it directly to the PC using a serial cable (all models), of this manual for wiring instructions. See “Conﬁguring IP-enabled MLCs for Network Communication,“ below to set the unit up to talk with the PC.

Conﬁguring IP-enabled MLCs for Network Communication

To function together, both the PC and the MLC must be conﬁgured correctly. Unless you use an RS-232 connection for all setup and communication with the controller, the PC must be network-capable with the proper protocols, and the MLC 104 IP Plus must be set up so it can be connected to a LAN or other network.

see page 2-9 or page 2-19

When you power on the MLC for the ﬁrst time, you have a choice of several ways to set up the controller’s IP address:

• UsetheGlobalConguratorsoftwareviatheLANconnector.

•UsetheARP(addressresolutionprotocol)commandviatheLANconnector.

•UseaWebbrowserviatheLANconnector.

• UseSIScommandsviaanRS-232connection.

• UseSIScommandsviaTelnetandtheLANconnector.

If you use a Web browser or Telnet the ﬁrst time you connect a PC to an IP model controller via IP, you will probably need to temporarily change the PC’s IP settings in order to communicate with the controller. See “Setting up the PC for

IP communication with an IP-enabled MLC” later in this chapter. Then you must

change the controller’s default settings (IP address, subnet mask, and [optional] administrator name and password) in order to use the unit on an intranet (LAN) or on the Internet. After you have set up the MLC for network communication, you can reset the PC to its original network conﬁguration via RS-232 or IP connection.

MLC 104 Plus Series’s RS-232 protocol:

• 38400 baud

• 8databits

• 1stopbit

• Noparity

• Noowcontrol

Network and IP features apply only to the MLC 104 IP Plus products, which are

the IP‑enabled models. The MLC 104 Plus does not support IP Link® features.

PRELIMINARY

MLC 104 IP Plus’s LAN port defaults (IP models):

• MLC’s IP address: 192.168.254.254

• Gateway’s IP address: 0.0.0.0

• Subnet mask: 255.255.0.0

• DHCP: off

• Link speed and duplex level: autodetected

The conﬁguration port requires 38400 baud communication. This is a

higher speed than many other Extron products use. The Global Conﬁgurator program automatically sets the connection for the appropriate speed. If using HyperTerminal or a similar application, make sure the PC or control system connected to this port is set for 38400 baud.

MLC 104 Plus Series • Software-based Conguration and Control

3-3

Software-based Conﬁguration and Control, cont’d

Once an IP-enabled controller has been conﬁgured, an Ethernet (intranet or Internet) connection can be used to contact, conﬁgure, or control it.

The following instructions assume that you have already connected the Windows-based PC to the MLC 104 IP Plus’s LAN port or to the Conﬁg port, and powered on the controller and the PC.

Both your computer and the MLC must be connected to the same subnet on a LAN

(using a straight‑through cable). Alternatively, you can use a crossover Ethernet cable to connect the controller directly to your computer’s Ethernet card.

Conﬁguring the MLC 104 IP Plus for network communication via Global Conﬁgurator software

You can conﬁgure the controller’s IP address via an IP/Ethernet connection using the Extron Global Conﬁgurator (GC) Windows-based software.

Read the Global Conﬁgurator help ﬁle for basic information on using Global Conﬁgurator software and setting up a project. Also read the MLC 104 Plus Series Setup Guide, revision B or higher, included with the controller, for step-by-step instructions of how to use GC to set up the MLC’s IP address.

Conﬁguring the MLC 104 IP Plus for network communication using the ARP command

You can use the ARP command to set up an IP address for the controller. The ARP command tells your computer to associate the controller’s MAC (media access control) address with the assigned IP address. You must then use the ping utility to access the controller, at which point the controller’s IP address is reconﬁgured.

Use ARP to conﬁgure the MLC’s IP address as follows:

PRELIMINARY

1. Obtain a valid IP address for the controller from your network administrator.

2. Obtain the controller’s MAC address (UID #) from the label on its rear, top, or

side panel. The MAC address should have this format: 00-05-A6-xx-xx-xx.

3. If the MLC has never been conﬁgured and is still set for factory defaults, go to step 4. If not, perform a Mode 4 system reset. For detailed information on reset modes, see “Resetting the Unit” in chapter 2, “Installation”.

4. At the PC, access the MS-DOS command prompt, then enter the arp –s

arp –s 10.13.197.9 00-05-A6-00-9A-BB

After the arp -s command is issued, the controller changes to the new address

The MLC must be conﬁgured with the factory default IP address

(192.168.254.254) before the ARP command is executed, as described below.

command. Enter the desired new IP address for the MLC and the MLC’s MAC address. For example:

The MAC address is listed on the controller’s rear or bottom panel.

and starts responding to the ping requests, as described in the next step.

3-4

MLC 104 Plus Series • Software-based Conguration and Control

5. Execute a ping command by entering “ping” followed by a space and the new IP address at the command prompt. For example:

ping 10.13.197.9 You must ping the MLC in order for the IP address change to take place.

The response should show the controller’s new IP address, as shown in the following picture.

You can reconnect using either Telnet or a Web browser to verify that the

update was successful.

6. After verifying that the IP address change was successful, enter and issue the arp –d command at the DOS prompt. For example:

arp –d 10.13.197.9 removes 10.13.197.9 from the ARP table or arp –d* removes all static IP addresses from the ARP table.

Conﬁguring the MLC 104 IP Plus for network communication via a Web browser

The default Web pages that are preloaded on the MLC 104 IP Plus are compatible with popular Web browsers such as Netscape Navigator (version 6.0 or higher), Microsoft Internet Explorer (version 5.5 or higher), or Mozilla Firefox (version 1.0 or higher). However, the MLC and the PC must both be part of the same subnet before they can communicate via the LAN port. You must change the PC’s IP address to one that is on the same subnet as the default IP address of the MLC (192.168.254.254).

N N

1. Temporarily change the host PC’s IP address. See “Setting up the PC for IP

2. Obtain a valid IP address for the controller from your network administrator.

3. Launch the Web browser on the connected PC (for which you set up the

This method requires a crossover cable. See page 2‑9 for cabling details. Make a note of the host PC's TCP/IP conﬁguration before changing its IP

address and make sure the PC and MLC are on the same subnet.

communication with an IP-enabled MLC” later in this chapter for step-by-step

instructions.

network conﬁguration earlier), and enter “http://192.168.254.254/” in the address box. The MLC’s default Web page is displayed.

PRELIMINARY

MLC 104 Plus Series • Software-based Conguration and Control

3-5

PRELIMINARY

Software-based Conﬁguration and Control, cont’d

4. Select the Configuration tab, then select System Settings from the menu on the left of the screen. A Web page appears. The top part of a typical screen is shown in the following picture.

5. Set the MLC for the new IP address using either step 5a or step 5b. 5a. Enter the new IP address for the MLC, the corresponding subnet mask,

and the gateway address. IP addresses, subnet mask, and e-mail addresses follow standard naming and numbering conventions. The IP network administrator should provide the IP addresses and subnet mask to be used with this controller.

5b. Select DHCP On.

6. Click Submit. It takes a minute or so for the controller to store the new

settings. Once the controller’s IP address is changed, you lose communication with the controller.

7. Close the browser.

8. After changing the controller’s IP settings, change your PC’s TCP/IP settings

back to their original conﬁguration.

3-6

Conﬁguring the MLC 104 IP Plus for network communication using SIS™ commands

RS-232

The MLC can also be conﬁgured using serial (RS-232) communication and a terminal emulation program such as HyperTerminal, which is installed with Windows. For information on RS-232 port requirements (including 38400 baud) and on Simple Instruction Set (SIS) commands, variables, and syntax, see chapter 4.

Telnet

The MLC and the PC must both be part of the same subnet before they can communicate via the LAN port. You must change the PC’s IP address to one that is on the same subnet as the default IP address of the MLC (192.168.254.254).

MLC 104 Plus Series • Software-based Conguration and Control

This method requires connecting the MLC to the PC’s LAN port using a

crossover network cable. See page 2‑9 for cabling details.

Make a note of the host PC's TCP/IP conﬁguration before changing its IP

address and make sure the PC and MLC are on the same subnet.

1. Temporarily change the host PC’s IP address. See “Setting up the PC for IP communication with an IP-enabled MLC” on the next page for step-by-step instructions.

2. Start Telnet on the PC a. Click the Start menu and select Run. The Run dialog box appears. b. Type telnet, a space, and the default IP address (192.168.254.254) into the

Open area, and click OK.

3. Set the MLC for the new IP address by doing one of the following.

• Enter SIS command

chapter 4, “SIS™ Programming and Control”) to set the IP address.

• Enter SIS command 1DH

4. After changing the controller’s IP address, change your PC’s TCP/IP settings back to their original conﬁguration.

E X1$

}

, where

}

to enable DHCP.

X1$

is the new IP address (see

Setting up the PC for IP communication with an IP-enabled MLC

You need a Windows-based (Windows 2000, XP, or higher) PC equipped with an operating network adapter. To allow your PC to work with Extron’s Ethernetcontrolled products, the TCP/IP protocol must be installed and properly conﬁgured.

When setting up the MLC for network communication via a Web browser or Telnet connection, you must change the IP address of the PC to one that is on the same subnet as the MLC. This is not required if you are setting up the MLC for network communication via Global Conﬁgurator, the ARP command, or SIS commands via an RS-232 connection.

If you use an existing Ethernet LAN intranet, your network administrator can provide you with a unique IP address for the controller or conﬁrm whether you need to set up the MLC 104 IP Plus for DHCP (Dynamic Host Conﬁguration Protocol) to have an address assigned automatically when you sign on.

1. Open the Network Connections page as follows:

• Locate and right-click on My

Network Places on the Windows

(2000, XP, or higher) desktop, then click on Properties.

PRELIMINARY

MLC 104 Plus Series • Software-based Conguration and Control

3-7

Software-based Conﬁguration and Control, cont’d

• Click on the Start menu, click on Settings (if needed), click on Control Panel to open the Control Panel window, then double-click on Network and Dial-up Connections (Windows 2000) or Network Connections (Windows XP, shown below).

2. Right-click on Local Area Connection, then select Properties.

PRELIMINARY

3. Select Internet Protocol (TCP/IP) and click on the Properties button (shown at right). If Internet Protocol (TCP/IP) is not on the list, it must be added (installed). Refer to the Microsoft Windows user’s manual or the Windows online help system for information on how to install the TCP/IP protocol.

4. Write down the PC’s current IP address and subnet mask below. If your PC is set to “Obtain an IP address automatically,” make a note of that, instead. You will need to restore these settings to the PC later.

IP address:

. . . .

Subnet mask:

. . . .

3-8

MLC 104 Plus Series • Software-based Conguration and Control

5. Change the PC’s IP address so it can communicate with the MLC 104 IP Plus and change the controller’s IP settings.

a. Select the “Use the following IP address:” radio button. b. Enter the following values, as shown in the following picture: IP address: 192.168.254.253

Subnet mask: 255.255.0.0 Default gateway: blank or 0.0.0.0

c. Click the OK button to save the changes and exit the network setup.

Reboot the PC, if required, for the changes to become effective.

6. Plug one end of a Category 5 network/Ethernet crossover cable into the MLC’s Ethernet (LAN) connector. See chapter 2 for RJ-45 LAN connector wiring. Plug the other end of the Ethernet cable into the Ethernet port on the PC.

7. Set up the MLC’s IP address using a Web browser, or SIS commands as

8. Restore the PC’s previous IP conﬁguration by following steps 1, 2, 3, and 5 but

If a network hub or switch is used between the PC and the MLC, use a straight‑

through CAT 5 cable instead of a crossover cable. See page 2‑19.

described earlier in this chapter.

using the PC’s original IP address settings you wrote down in step 4.

Global Conﬁgurator Software for Windows®

The included Extron Global Conﬁgurator (GC) program for Windows offers the most complete way to conﬁgure and customize the controller via either RS-232 (all models) or IP connection (IP models). GC provides the ability to generate a Web browser-based GlobalViewer® (GV) application and Web pages for each IP Link-based device (IP Link interface, System 5 IP, MLC 226 IP, MLC 104 IP, MLC 104 IP Plus, or other Extron device) on a network. Once an MLC 104 IP Plus is conﬁgured, its GlobalViewer Web pages allow the user to manage, monitor, and control the MLC and the devices connected to it.

PRELIMINARY

MLC 104 Plus Series • Software-based Conguration and Control

3-9

Software-based Conﬁguration and Control, cont’d

Global Conﬁgurator offers the best and easiest way to conﬁgure the controller. Other setup options include using SIS commands and the MLC’s factory-embedded Web pages, but many setup features are available only via Global Conﬁgurator. GC includes some functions found on the controller’s front panel and many additional features that are available only through the software.

Downloading the software and getting started

Global Conﬁgurator software is included with the controller. Global Conﬁgurator software updates and a large variety of device drivers can be downloaded at no charge from the Extron Web site (http://www.extron.com).

PRELIMINARY

Refer to the MLC 104 Plus Series Setup Guide for speciﬁc information on how to download the software. Refer to that guide and to the Global Conﬁgurator Help ﬁle for details and step-by-step procedures on how to start a GC project and perform basic setup tasks for an MLC 104 IP Plus. Both the setup guide and the help ﬁle contain instructions on how to set the MLC’s IP address, gateway IP address,

subnet mask, mail server IP address, domain name, Telnet port, Web port, SMTP username, and SMTP password so that the MLC is able to communicate with the

network. Obtain these parameters from your network administrator and set them before continuing.

Device drivers (for controlling projectors, VCRs, DVD players, etc.) can be

used by other Extron IP Link products, so they may be listed on the Extron Web site as an IP Link driver package. You may also want to download the optional IR Learner™, a free software utility for capturing infrared codes from a handheld IR remote control to create custom drivers for operating IR‑controlled devices like the MLC that use IP Link and GlobalViewer.

Do not change the directory or the name of the directory where the software ﬁles

are installed by default.

PC system requirements

The MLC 104 IP Plus and Global Conﬁgurator have the following hardware and software requirements:

• Intel

• MicrosoftWindowsoperatingsystem

• MicrosoftInternetExplorer6.0withActiveX® enabled

• MicrosoftWindowsScript5.6

• 512MBofRAM

• 50MBofavailableharddiskspace

• Anetworkconnectionwithaminimumdatatransferrateof10Mbps(100Mbps

C N

Pentium® III 1 GHz processor

• WindowsNTservicepack4,or

• Windows2000servicepack2,or

• WindowsXPservicepack2,oralaterversion

is recommended)

Do not run this software on a PC that uses an earlier version of Windows.

The MLC 104 Plus requires GC version 2.50 or higher. IP models can use GC

version 2.20 or higher.

3-10

Using Global Conﬁgurator: helpful tips

Resources and notes

• TheGlobal Conﬁgurator Help ﬁle provides information on settings and how to use the Global Conﬁgurator program, itself.

MLC 104 Plus Series • Software-based Conguration and Control

• TheMLC 104 Plus Series Setup Guide, which is shipped with the MLC, covers basic setup steps. It includes instructions and examples on how to use the basic tabs in GC.

• SomeitemsinGlobalConguratorcorresponddirectlytothefrontpanel

controls. See chapter 2 of this manual for features and settings.

• IfyouwillconguretheMLCattheinstallationsite,Extronrecommendsusing

the driver subscription function within Global Conﬁgurator to download drivers for all manufacturer and device types before you go out into the ﬁeld.

• TheGlobalConguratorprojectle(*.gc2 or *.gcz) contains conﬁguration settings and it can be saved to a directory or folder for backup or for installation on another MLC 104 IP Plus Series controller. Saving a conﬁguration is recommended before you perform a ﬁrmware upgrade.

• The MLC can be set up to allow conﬁguration access to administrators only, and to prevent other users from making changes to the controller’s settings, events, and drivers. If an administrator password is set for the controller, nonadministrator users can select inputs and adjust output volume but are prevented from making any other changes using GlobalViewer Web pages.

• IPaddresses,subnetmask,ande-mailaddressesfollowstandardnamingand

numbering protocol. The network administrator provides the IP addresses and subnet mask to be used with this controller.

• Theunitnameisanyname(e.g.,Room107MLC104IPplus,Lab1234mlc104IP,

ConfRoomSystem, LectureHall8-cntrlr, etc.) that you want to use to label a speciﬁc MLC controller unit. The default is a combination of the product name and part of the hardware address. This can be changed to your choice of alphanumeric characters and hyphens (-).

• Spacesarenotpermittedwithinaunit’sname.

• Underscores(_)arenotpermitted.

• ValidcharactersareA-Z,a-z,0-9,and-(hyphen).

• Thenamecannotstartwithanumberorahyphen,anditcannotendwitha

hyphen.

• Maximumnamelengthis24characters.

PRELIMINARY

A brief guide to Global Conﬁgurator’s tabs

In the upper right side of the GC software window are several tabs that divide the program into groups of functions you can view and conﬁgure. The left three, IP Link Settings, Schedule, and Monitor, are displayed for all IP Link-enabled products. Any tabs to the right of those three vary in quantity, type, and layout, depending on the product being conﬁgured. See the illustration below for an example of the tabs that may be available when you conﬁgure an MLC.

To learn about the functions available on each of these tabs, look in the Global Conﬁgurator Help ﬁle. In the contents pane on the left, click on “Reference Information”, click “Global Conﬁgurator Window”, then click on the name of the tab you want to know more about.

MLC 104 Plus Series • Software-based Conguration and Control

3-11

Software-based Conﬁguration and Control, cont’d

Advanced Conﬁguration

IR learning to create customized IR driver ﬁles

If you do not ﬁnd a driver on the Extron Web site for the device you plan to use, you can create your own IR driver ﬁle. Extron IR Learner™ software lets you create a customized driver ﬁle of IR commands that can be used with the Global Conﬁgurator software for port setup and button conﬁguration. Visit

http://www.extron.com

Once IR Learner is installed on the PC, you can start the program directly by double-clicking the IR Learner icon, shown at right.

Or, you can select Run IR Learner from Global Conﬁgurator’s Tools menu, as shown at right. The IR Learner utility opens in a new window.

Additional information on how to use the software is available in the IR Learner Help ﬁle.

The MLC 104 Plus requires IR Learner version 1.23 or higher.

Advanced conﬁguration options in Global Conﬁgurator

In Global Conﬁgurator in the Advanced Configuration tab you can set

to download IR Learner and install it on your PC.

PRELIMINARY

• whathappensduringpower-upandpower-downcyclesandforhowlong

• personalidenticationnumbers(PINs)andwhetherornoteachPINisenabled

during front panel lockout (executive mode) (see page 2-6 for details)

• volumeadjustmentparameters

• congurationforeachdigitalport

• miscellaneoussettingsincludingwhethertoresetbuttonstatisticsoruploadthe

enhanced Web pages when the conﬁguration is uploaded to the MLC

The Global Conﬁgurator Help ﬁle explains these features in the reference section about the Advanced Configuration tab and in the MLC-speciﬁc instructions for conﬁguring advanced settings. You may want to keep the following items in mind while conﬁguring advanced settings. And not all features of this tab are listed below.

Power Settings (Display power up/power down settings)

When the display is on, delay I/O switching for: — This feature prevents a

second input switch for the speciﬁed duration (0 to 5.0 seconds in 0.5 second increments). This allows a projector to synchronize with the new input signal before switching inputs again.

The I/O switching delay period can be set here or by using special SIS command

54# on

When powering up/down delay for: — Most projectors require a certain amount

of time for lamp warm-up and cool-down during which they cannot display an image. These delays can also be set using special SIS commands (1# and 2#, see

page 4-33 in the SIS programming chapter).

Repeat IR power down — Some IR-controled projectors/displays must receive a

second power down command. If selected, this feature automatically sends the

page 4-40.

Global Conﬁgurator automatically sets the warm‑up and cool‑down delay times

based on default values in the display/projector’s driver. SIS commands override the default settings. For best results, set delay times to 2 to 4 seconds longer than the times required by the display/projector. This ensures that the correct Display power button state is shown on the front panel and on the GV and standard embedded Web pages.

3-12

MLC 104 Plus Series • Software-based Conguration and Control

power off/power down command twice. The MLC must be conﬁgured to send the IR power off command upon display power off button release (not at the button press).

Send channel IR/232 as display powers up — This setting ensures that the

inputs of the MLC and of the display device are coordinated when the display is powered on.

Lockout I/O switching while display powers On or Off — This feature prevents

input switching during the display power up and power down periods. This I/O switching lockout is the same as SIS special command 53# ( this command to work you must also set the power up and power down delay periods (mentioned above).

Hold power-down button for two seconds — This prevents shutting down the

display or projector by accidentally pressing the Display Off button. When this feature is enabled, you must press and hold the front panel Display Off button for two seconds before the power-off sequences can start. The corresponding SIS command is 22#.

Volume settings

When adjusting the volume use — For a projector, display, or audio output

device, volume is controlled by one of two methods: selecting a setting within a speciﬁc range of values, or sending a simple command to increase or decrease the volume by a ﬁxed increment. Refer to the user’s manual for the display or audio device to choose the best method for volume adjustment.

Volume encoder scaling factor (0-255) — This feature allows you to slow

Encoder scaling gives the programmer the ability to slow the knob down to

Although this feature is mainly for range type volume control, it applies to any

The power‑up volume limit is limited by the maximum volume setting (SIS

special command 47#). If the maximum volume (47# command) is set, the limit audio level feature (SIS special command 11#) is automatically set to 25% of the maximum volume (47#). See pages 4‑33 and 4‑39.

down the volume knob (the encoder) on the MLC’s front panel. This feature addresses a scenario that occurs with some projectors that use range type volume control. When the MLC’s knob controls projector volume, sometimes the MLC sends the volume commands faster than the projector is able to detect and process. When the projector does not detect some of the volume change commands, a choppy volume ramp occurs.

a speed the projector can handle. The drawback is that users must turns the knob more times to change from minimum to maximum volume. It is up to the user to ﬁnd a balance between smooth audio ramping and the number of knob turns needed to cover the volume range. This requires trial and error for each projector exhibiting this problem.

range type command programmed to be executed by the volume knob. The SIS special command 49# sets the encoder scaling factor.

page 4-33). For

PRELIMINARY

Miscellaneous settings

Reset button statistics on upload — For more information on button statistics

(which track how many times each front panel button is pressed), see “Statistics” on page 3-17.

Upload enhanced web pages — See “Control” on page 3-21 to see examples of

both basic and enhanced Web pages (which show photo-like versions of the MLC’s and control modules’ front panels).

Enable/Disable IR Receiver determine’s the MLC’s ability to receive IR signals

through the CM/IR/SCP port on the side panel. This feature is the same as the 65# SIS command (page 4-40).

MLC 104 Plus Series • Software-based Conguration and Control

3-13

Software-based Conﬁguration and Control, cont’d

Conﬁguring an auxiliary (MLS, PVS) switcher

An Extron MediaLink Switcher (MLS) or PoleVault Switcher (PVS) can be connected to the MLC to expand the number of inputs available to the projector/ display. However, if the MLS or PVS switcher is disabled, the MLS RS-232 port can be used as an auxiliary, bidirectional RS-232 port, just like the Display port. To enable and conﬁgure an auxiliary switcher, follow the Global Conﬁgurator Help ﬁle’s procedure to add and conﬁgure a MediaLink switcher.

Setting up passwords for IP models

To control access to the MLC through a LAN connection, you can set administrator and user passwords. Full instructions are available in the MLC 104 Plus Series Setup Guide or the Global Conﬁgurator Help ﬁle’s section on advanced conﬁguration.

1. Open an existing Extron Global Conﬁgurator (GC) project or start a new project.

2. Click Tools and select Change Device Settings from the drop-down menu.

PRELIMINARY

3. In the Device Settings window, select (click on) the name of the desired MLC.

4. Click Settings and choose Set Administrator

Password or Set User Password from the dropdown menu, as shown at right. A Set for <IP address> window appears.

5. Type the desired password into both areas of the window and click OK. The Set for... window closes.

6. Click the Close button.

7. Complete the rest of the conﬁguration, save the

8. Click Exit after the ﬁles have been uploaded.

Passwords must contain 4 to 12 alphanumeric

characters. Symbols and spaces are not allowed, and the passwords are case sensitive.

project, and upload (build) the conﬁguration to the MLC. The Upload Manager window appears.

Printing a wiring block diagram

Once you have conﬁgured a system using Global Conﬁgurator, you can generate and print a simple block diagram of what products to wire to which of the MLC’s ports. The diagram includes model names, DIP switch settings for control modules, and the type of communication (IR or RS-232) conﬁgured for each port. Read the Global Conﬁgurator Help ﬁle’s “Reference Information” section about the File menu for details.

3-14

Procedure overview:

In Global Conﬁgurator, click on the File drop-down menu and select Print and then Wiring Diagram. In the Print Wiring Diagrams window, select the devices to include in the diagram. Click the Print button at the bottom of the window.

MLC 104 Plus Series • Software-based Conguration and Control

This procedure requires Microsoft Word software. The installer or user must

provide that software. It is not an Extron product.

GC processes the information about the selected device(s), generates a document containing the wiring diagram, and opens that document in Word. Print the diagram(s), save the ﬁle, if desired, and exit Word. Close the Global Conﬁgurator Print Wiring Diagrams window.

Updating ﬁrmware

If the need arises, you can replace the MLC’s ﬁrmware without opening the unit or changing ﬁrmware chips. See appendix B, “Firmware Updates”, for instructions on how to update the controller’s ﬁrmware.

Save the existing conﬁguration project before replacing the ﬁrmware.

Saving and uploading the conﬁguration

This is not an advanced conﬁguration function, but when you ﬁnish creating the conﬁguration in Global Conﬁgurator, you must save the GC project and upload the conﬁguration to one or more MLC units. See chapter 3 of the MLC 104 Plus Series Setup Guide (shipped with the MLC) for instructions.

Controlling an IP Link-enabled MLC

You can control the MLC 104 IP Plus and devices connected to it by using the MLC’s factory-embedded Web pages or its GlobalViewer (GV) Web pages that were created when you uploaded the GC conﬁguration or a customized graphical user interface (GUI).

Embedded Web pages

The MLC 104 IP Plus features an embedded Web server, which includes factoryset Web pages. These pages can be replaced with user-designed ﬁles, but the default Web pages provide many basic features for monitoring, conﬁguring, and controlling the MLC via a Web browser. These Web pages provide some of the features of the conﬁguration program. This section provides an overview of the embedded Web pages.

To access the embedded Web pages,

1. Launch a Web browser (Internet Explorer, Netscape Navigator, Mozilla Firefox) on the connected PC, and enter the MLC’s IP address in the address ﬁeld.

2. In the Connect to <IP address> dialog box, shown at right, enter the MLC’s IP address or text of your choice in the User Name ﬁeld, type in the administrator password in the Password ﬁeld, and click OK. The MLC 104 IP Plus’s default Web page appears.

If the MLC has not already been

conﬁgured with a password, this password dialog box does not appear; the default Web page opens directly.

Passwords must contain 4 to 12 alphanumeric characters. Symbols and spaces

are not allowed, and the passwords are case sensitive.

Administrators have access to all of the Web pages and are able to make

changes to settings. Users can access the System Status and Control: User Mode pages only.

PRELIMINARY

MLC 104 Plus Series • Software-based Conguration and Control

3-15

Software-based Conﬁguration and Control, cont’d

Status

The Status Web pages provide only settings information. Changes must be made via the Configuration Web page or via the Global Conﬁgurator software or SIS programming. Personnel who have user access can view these pages but do not have access to conﬁguration pages.

System Status

The System Status page provides information about the MLC’s model, part number, ﬁrmware level, voltages and internal temperatures, port and IP settings, and the status of projector lamp hours and the display connection, as shown in the following example. This information is useful when troubleshooting problems.

PRELIMINARY

Projector lamp hours are a reﬂection of time elapsed since the lamp was changed

as determined by the driver/events associated with the MLC’s Display RS‑232/ IR port.

3-16

MLC 104 Plus Series • Software-based Conguration and Control

Statistics

The Statistics page is mainly for administrators and maintenance personnel. It shows information about system usage: the number of hours the system has been turned on, how many hours the projector lamp has been used, how much time per day and per week the system is turned on, and how many times each button on the MLC has been pressed, either physically or virtually (via conﬁguration software, SIS commands, or event scripts). All of the button press and system use statistics (with the exception of lamp hours) can be reset to 0 by clicking the Reset Statistics button at the bottom of this screen.

This page is not available unless the MLC has been conﬁgured with Global

Conﬁgurator ver. 2.x or higher.

PRELIMINARY

Conﬁguration

There are four Conﬁguration Web pages, which only administrators can access: System Settings, Passwords, Email Alerts, and Firmware Upgrade.

MLC 104 Plus Series • Software-based Conguration and Control

3-17

Software-based Conﬁguration and Control, cont’d

System Settings

This is for IP, date/time, and executive mode (front panel lockout) setting changes.

PRELIMINARY

Passwords

In the Passwords page you can change the administrator and/or user passwords.

Unit Name is any name (e.g., Room108MLC104IPplus, Lab1234mlc104 IP,

ConfRoomSystem, LectureHall8‑cntrlr) you use to label this speciﬁc MLC. The default is a combination of the product name and part of the hardware address. This can be changed to your choice of alphanumeric characters and hyphens (‑).

• Spaces()andunderscores(_)arenotpermittedwithinaunit’sname.

• ValidcharactersareA-Z,a-z,0-9,and-(hyphen).

• Thenamecannotstartwithanumberorhyphen.Itcannotendwithahyphen.

• Maximumlengthis24characters.

3-18

MLC 104 Plus Series • Software-based Conguration and Control

Passwords must contain 4 to 12 alphanumeric characters. Symbols and

spaces are not allowed, and the passwords are case sensitive. A minimum of 4 characters are required when creating passwords via the Web pages.

Email Alerts

In this page you can specify the Web server’s IP address and domain name, set up SMTP veriﬁcation credentials, and specify e-mail alert recipients’ addresses and which e-mail ﬁle they will be sent.

Firmware Upgrade

Through this page you can locate and load new ﬁrmware to the unit.

The MLC must ﬁrst be conﬁgured with Global Conﬁgurator before e‑mail

addresses and e‑mail ﬁle names appear on this page.

PRELIMINARY

See appendix B,

“Firmware Updates”, for instructions on how to update the controller’s ﬁrmware.

Save the existing

conﬁguration project before replacing the ﬁrmware.

MLC 104 Plus Series • Software-based Conguration and Control

3-19

Software-based Conﬁguration and Control, cont’d

File Management

This Web page allows you to sort by ﬁle type (see the Filter by File Extension drop-down box). Personnel with administrator access can view these pages and make changes. Those with user-level privileges are not able to see this page. See

appendix A for an explanation of ﬁle types.

PRELIMINARY

C C

You can also view ﬁles in subfolders, including those containing GlobalViewer ﬁles if they have been installed on the MLC.

 Fileswiththe.cdcextension(___.cdc ﬁles) should NOT be deleted. Eventles(__.evt)shouldNOTbedeleted.Theyarenecessaryforthe

controller’s operation. Never delete the main event ﬁle (0.evt).

3-20

MLC 104 Plus Series • Software-based Conguration and Control

Control

User Mode

The ﬁrst of the Control Web pages is User Mode, which is a representation of the controller’s front panel buttons, volume control, and any optional control modules (IRCMs, RCMs, ACMs) that are part of the system. Clicking on a button on screen emulates a button press on the corresponding device. This page is accessible to both administrators and users.

From the factory, the MLC 104 IP Plus comes with a preloaded Web page with a basic representation of the MLC’s front panel controls and the buttons of any optional attached control modules. See the example below.

Typical User Mode page

Web pages that show a more realistic representation of the MLC’s front panel and of control modules (as shown at right) are included with the conﬁguration software. These pages (over 200 ﬁles) can be uploaded into the MLC if you select Upload Enhanced Web Pages from the Advanced Configuration page in Global Conﬁgurator before you build the conﬁguration and load it into the MLC.

Enhanced User Mode page

PRELIMINARY

MLC 104 Plus Series • Software-based Conguration and Control

3-21

Software-based Conﬁguration and Control, cont’d

IR Drivers

This Web page lists IR driver ﬁles only and allows you to select a ﬁle to see and execute the commands stored in it. This page is available only to those logged in as an administrator.

An example for a speciﬁc IR driver is shown below.

The MLC must ﬁrst be conﬁgured with Global Conﬁgurator before this page can

be used.

PRELIMINARY

Serial Devices (serial drivers)

Once the ports have been set up in the conﬁguration program, each conﬁgured serial port (projector/display control port and MLS port) is listed in this section of

the Control page menu. Click on a port name to bring up a page that shows the available

commands for the device cabled to that port. See the sample screen shot on the next page.

If you want to execute a command that is available in the driver (whether associated with an MLC button or not) for a conﬁgured device, you can click on a button or select an option from a pull-down menu to execute that command.

You must use Microsoft Internet Explorer version 6.0 or higher with ActiveX

enabled in order to use the serial devices’ control pages.

3-22

MLC 104 Plus Series • Software-based Conguration and Control

Example of a page for a projector driver

GlobalViewer® Web Pages

The MLC 104 IP Plus controller can be used as part of a network of devices based on Extron IP Link technology, such as IP Link interfaces. Global Conﬁgurator (GC) is a Windows-based program used for conﬁguring and customizing the Web browser-based GlobalViewer (GV) application for each IP Link interface, System 5 IP, MLC 226 IP, MLC 104 IP Plus, or other IP Link-based device on a network. Once an MLC 104 IP Plus is conﬁgured, its GlobalViewer Web pages allow the user to manage, monitor, and control the MLC and the devices connected to it.

Refer to the Global Conﬁgurator help ﬁle and the for speciﬁc information on how to use the software and perform basic setup tasks for a MLC 104 IP Plus.

Four screens for the MLC are available via Global Viewer: Control, Monitor, Schedule, and Info ( Global Conﬁgurator Help ﬁle for details on each screen and how to use the GlobalViewer pages.

To work with Global Viewer Web pages, you must use Microsoft Internet

Explorer version 6.0 or higher with ActiveX enabled.

If the MLC has been conﬁgured with passwords, the GlobalViewer Web pages are

password protected. Although default embedded Web pages are accessible via the GlobalViewer Web pages, nonadministrators (people with only user access) are able to access the Control and Status default Web pages only.

PRELIMINARY

MLC 104 IP Plus Series Setup Guide

). Read the

MLC 104 Plus Series • Software-based Conguration and Control

3-23

Software-based Conﬁguration and Control, cont’d

Customizing the MLC’s Control Web Pages

Extron offers Web page templates that can be customized using standard HTML editing tools to provide a different interface to the user while still using GlobalViewer functions. An experienced Web developer can add images, modify text, and change background colors to create a look and feel that reﬂects your brand or your user’s speciﬁc requirements. For example, a university with dozens of devices and rooms to control may wish to create customized Web pages with the university’s school colors and logo. End users can control the system using these customized pages instead of the standard GV pages.

Alternatively, Extron can create a customized graphical user interface (GUI) for you to upload to each MLC in the system. End users can view the Web pages of this customized GUI while administrators and installers still have access to the factoryset Web pages and the standard GV Web pages in addition to the customized ones.

For a small, one-time fee, Extron will turn the following items into ﬁles ready to upload to the MLC IP models:

• yourGlobalViewerprojectlecontainingsystemcongurationdetails

• yourchoiceofavailablecolorschemes

• yourchoiceoflabelsforpanelbuttons

• acompanyorinstitutionlogo

These customized Web pages, whether created by Extron or modiﬁed by an outside HTML developer from Extron-supplied templates, can also include button sets for any control modules (IRCMs, RCMs, CMs, etc.) used in the system.

Visit the Extron Web site (http://www.extron.com/product/customgui.aspx) or contact an Extron customer support representative for more information on this service and on available template options.

PRELIMINARY

3-24

MLC 104 Plus Series • Software-based Conguration and Control

MLC 104 Plus Series

Chapter Four

SIS™ Programming and Control

Host-to-MLC Communications

Commands and Reponses

PRELIMINARY

SIS™ Programming and Control

The MLC 104 Plus Series controller can be remotely set up and controlled via a host computer or other device (such as a control system) attached to the rear panel Conﬁg/RS-232 port or LAN port, or the front panel Conﬁg port.

MLC 104 Plus Series units must be conﬁgured before use. As shipped the

The

controller can trigger basic input switching on an optional MLS switcher, but it cannot control any other devices before being conﬁgured.

The MLC can be set up and controlled by using Extron’s Simple Instruction Set (SIS) commands or the Extron Global Conﬁgurator software (version 2.2 or higher for IP models, version 2.5 or higher for MLC 104 Plus), and both of those methods can be accessed via RS-232 (all models) or Ethernet LAN connection (IP models). See chapter 2 for pin assignments and other details on the conﬁguration and control ports. For information on the software and the MLC 104 IP Plus’s embedded Web pages, see chapter three.

104 Plus Series RS-232 protocol:

MLC

• 38400baud

• 8databits

• 1stopbit

• noparity

• noowcontrol

PRELIMINARY

LAN port defaults (IP models):

•

• gateway’s IP address: 0.0.0.0

• subnet mask: 255.255.0.0

• DHCP: off

The conﬁguration port requires 38400 baud communication. This is a

higher speed than many other Extron products use. The Global Conﬁgurator (version 2.2 or higher for IP models, version 2.5 or higher for MLC 104 Plus) software automatically sets the connection for the appropriate speed. If using HyperTerminal or a similar application, make sure the PC or control system connected to these ports is set for 38400 baud.

MLC’s IP address: 192.168.254.254

Host-to-MLC Communications

SIS commands consist of one or more characters per ﬁeld. No special characters are required to begin or end a command sequence. When the MLC determines that a command is valid, it executes the command and sends a response to the host device. All responses from the MLC to the host end with a carriage return and a line feed (CR/LF = ]), which signals the end of the response character string. A string is one or more characters.

MLC-initiated messages

If you are communicating with the MLC via RS-232 or via a verbose (see page 4-21) Telnet connection, when a local event such as a front panel selection or adjustment takes place, the MLC responds by sending a message to the host. No response is required from the host. The MLC-initiated messages are listed here (underlined).

X!]

Chn The unit sends this response when an input is switched.

(c) Copyright 2007, Extron Electronics, MLC 104 IP PLUS, Vx.xx, 60-818-00 Day, DD Mon YYYY HH:MM:SS Vx.xx is the ﬁrmware version number. The MLC sends the boot and copyright messages under the following circumstances:

(where X! is the input number)

]

4-2

MLC 104 Plus Series • SIS Programming and Control

• IftheMLC is off and an RS-232 connection is already set up (the PC is cabled

to the MLC and a serial terminal emulation program such as HyperTerminal is open), the connected unit sends these messages via RS-232 when it is ﬁrst powered on.

• IfanMLC IP model is on, it sends the boot and copyright messages when you

ﬁrst open a Telnet connection to the MLC. You can see the day of the week, date, and time if the MLC is connected via Telnet, but not via RS-232. If you are using a Telnet connection, the copyright message, date, and time are followed by a password prompt.

Additional messages may be sent by the MLC in response to front panel selections and volume adjustments and when scripts are executed during scheduled events.

Password information (IP models)

The “]Password:” prompt requires a password (administrator level or user level) followed by a carriage return. The prompt is repeated if the correct password is not entered.

]

If the correct password is entered, the unit responds with “

]

or “ for both administrator and user, the unit will default to administrator privileges.

Error responses

When the MLC receives a valid SIS command, it executes the command and sends a response to the host device. If the MLC is unable to execute the command because the command is invalid or it contains invalid parameters, it returns an error response to the host.

The error response codes and their descriptions are as follows: E01 – Invalid input channel number (the number is too large)

E12 – Invalid port number E13 – Invalid value (the number is out of range/too large) E14 – Not valid for this conﬁguration E17 – System timed out E22 – Busy E24 – Privilege violation E25 – Device is not present E26 – Maximum number of connections has been exceeded E27 – Invalid event number E28 – Bad ﬁlename or ﬁle not found E30 – Hardware failure (followed by colon and descriptor number) (This is an unsolicited response.)

Error response references

The following superscripted numbers are used within the command descriptions on the following pages to identify commands that may respond as shown:

= Commands that give an E14 (not valid for this conﬁguration) response if the

unit’s current conﬁguration doesn’t support that command.

= Commands that yield an E22 (busy) response.

= Commands that give an E24 (privilege violation) response if you are not logged

in at the administrator level.

= Commands that may yield an E27 (invalid event number) response.

= Commands that may give an E28 (ﬁle not found) response.

PRELIMINARY

MLC 104 Plus Series • SIS Programming and Control

4-3

SIS™ Programming and Control, cont’d

ASCII to Hex Conversion Table

•

Space

Commands and Reponses

Using the command/response tables

The MLC can be controlled via either a Telnet (port 23, IP models only) or RS-232 connection using ASCII commands. IP models can also be controlled via a Web browser (port 80) connection using URL-encoded commands. The ASCII and URL commands listed in the tables starting on page 4-8 perform the same functions, but they are encoded differently to accommodate the requirements of each port (Telnet or browser).

The ASCII to hexadecimal (HEX) conversion table shown at right is for use with the command/response tables.

PRELIMINARY

The command/response tables list valid ASCII (for Telnet or RS-232) command codes, the corresponding URL (uniform resource locator) encoded (for Web browsers) command codes, the MLC’s responses to the host, and a description of the command’s function or the results of executing the command.

• Upperandlowercasecharactersmaybeusedinterchangeablyinthecommand

• Commandsmaybesentback-to-backwithoutspaces(forexample,2!65V1Z).

• Numberscanbeenteredas1,2,or3digits,e.g.,8V=08V=008V.

• Thereareafewdifferencesinhowtoenterthecommandsdependingonwhether

The non‑IP model

(MLC 104 Plus) does not support Telnet or Web access.

ﬁeld unless otherwise speciﬁed.

you are using Telnet or a Web browser.

When using these commands through a Web browser, the URL reference



is used to shorten the examples. “URL” refers to the full URL of the control interface and Web page reference including all path information (e.g., http://192.168.100.10/myform.htm).

To send any of the commands using a Web browser you must preﬁx them



with the full URL followed by ?cmd=.

For control via a Web browser, all non-alphanumeric characters must be



represented as the hexadecimal equivalent, %xx, where xx represents the two-character hex byte. A comma (,), for example, would be represented as %2C. Characters such as %, +, and the space character ( ) must be encoded as hex bytes, or they will be misinterpreted by the MLC. For example, the ASCII command +V must be encoded as %2BV for Web browser use.

Some characters differ depending on the method you use to send the



commands: Telnet Web browser Escape (hex 1B) W [must not be hex encoded] Carriage return (hex 0D) Pipe character (|) [must not be hex encoded]

With Telnet you can use either an “Escape” (E) command or a “W”

command, and the carriage return or the pipe character. With the Web browser, you are required to use a “W” command and the pipe character.

ASCII to Hex conversion table

4-4

MLC 104 Plus Series • SIS Programming and Control

In either method, {Data} = data that will be directed to a speciﬁed port

and must be hex encoded if non-alphanumeric.

Symbol deﬁnitions

]

= CR/LF (carriage return/line feed) (hex 0D 0A)

}

= Carriage return (no line feed, hex 0D)

(for URL-encoded commands, use the pipe character,

• = Space character

= Pipe (vertical bar) character

* = Asterisk character (which is a command

X1!

X1@

character, not a variable)

= Escape key (hex 1B)

(use W instead of Esc for Web browsers)

= Speciﬁc port number or relay number

1 = front panel host (Conﬁg) port 2 = Display RS-232/IR port 3 = MLS port

= Command data section.

For Web encoding only: data will be directed

to the speciﬁed port and must be encoded (URL encoding) if it is non‑alphanumeric. Change any non-alphanumeric character (%, +,

|, }

, etc.) within the data section into the corresponding hexadecimal equivalent, %xx, where xx represents the two‑character hex byte. For example, a space (hex: 20) would be encoded as %20 (hex: 25 32 30) and a plus sign (hex: 2B) would be encoded as %2B or hex 25 32 42.

= Greenwich Mean Time (GMT) offset value

(-12.00 to +14.00) represents the time difference in hours and minutes (+/-hh:mm) relative to Greenwich, England. The leading zero is optional. For example, 5:30 = 05:30. Do not use a plus (+) sign if the GMT offset is positive.

= On/off status

0 = off/disable (default for audio mute and DHCP) 1 = on/enable

= Volume level (0 – 100 steps). The maximum

volume level is limited by the max. volume range command (

Default volume = 25.

= Version (typically listed to two decimal

places, e.g., x.xx)

= MLC’s name. The name is a text string of up

to 24 characters drawn from the alphabet

(A-Z),digits(0-9),andminussign/

hyphen (-). No blank or space characters are permitted as part of a name. No distinction is made between upper and lower case. The ﬁrst character must be a letter. The last character must not be a minus sign/hyphen.

If you make adjustments (changes to volume, etc.), whether via the front panel

or via RS‑232 or IP communication, it will take up to 1 minute 40 seconds (100 seconds) for the data in the MLC’s RAM to be saved to ﬂash memory. Do not remove power during that period.

X1#

= Local date and time format

, instead)

Set format (MM/DD/YY-HH:MM:SS).

Read format (day of week, date month year

X1$

X1% X1&

X1*

X1(

X2)

*47#).

Example: 01/18/05‑10:54:00.

HH:MM:SS). Example: Tue, 3 Jul 2007 18:19:33.

= IP address (xxx.xxx.xxx.xxx). Leading zeros

in each of four ﬁelds are optional in setting values, and they are suppressed in returned values. MLC’s default address: 192.168.254.254 Default broadcast address:

255.255.255.255. = E-mail domain name; for example, extron.com = Time in tens of milliseconds to wait until the

ﬁrst response character is received via a serial port before terminating the current receive operation. (Default = 10 = 100 ms, max. = 32767.) The response includes leading zeros.

X1&

and

X1&

and

X1&

X2)

may be

X2)

may be

For commands that use both

variables must be zero or both must be non‑zero. In the RS (send data) command, omitted as long as

= Hardware (MAC) address (xx-xx-xx-xx-xx-xx)

(00-05-A6-xx-xx-xx)

= Subnet mask (xxx.xxx.xxx.xxx). Leading

zeros are optional in setting values in each of four ﬁelds, and they are suppressed in returned values. Default = 255.255.0.0.

= Time in tens of milliseconds to wait between

characters being received via a serial port before terminating the current command or receive operation. The response includes leading zeros. (Default = 2 = 20 ms, max. = 32767)

For commands that use both

variables must be zero or both must be non‑zero. In the RS (send data) command, omitted as long as

X2)

is also missing.

X2)

is also missing.

, both

PRELIMINARY

, both

MLC 104 Plus Series • SIS Programming and Control

4-5

SIS™ Programming and Control, cont’d

PRELIMINARY

X2!

= Parameter (#L or #D) to set either the Length

of message to receive or the Delimiter value. # = byte count (for L) or # = a single ASCII character expressed in decimal form (for D). The parameter is case sensitive; you must use capital D or capital L. Byte count # can be from 0 to 32767, default = 0. The ASCII decimal # can be from 0 to 00255, default = 00000L.

Examples:

X2@

X2#

X2%

X2^

X2& X2* X3#

X3$

A 3-byte length = 3L. A delimiter of ASCII 0A = 10D. The response from the MLC includes leading zeros.

= Verbose/response mode status:

0 = clear/none, default for Telnet connections; responses are not echoed to the host 1 = verbose mode is on, default for RS-232 host control; responses are echoed to the host and displayed to the user 2 = send tagged responses for queries 3 = verbose mode is on and tagged responses are sent for queries

If tagged responses are enabled, all read

commands return the constant string + data, the same as for setting a value. For example,

CN }, the response is Ipn•

for rather than just the data.

= Priority status for receiving timeouts:

0 = use send data string command parameters (0 = default) 1 = use conﬁgure receive timeout command parameters

= Baud rate: 300, 600, 1200, 1800, 2400, 3600,

4800, 7200, 9600, 14400, 19200, 28800, 38400, 57600, or 115200

= Parity (only the ﬁrst letter is needed):

O = odd E = even N = none (default) M = mark

S = space = Data bits: 7, 8 (default = 8) = Stop bits: 1, 2 (default = 1) = Password (minimum length = 4 characters,

maximum length = 12 characters,

no special characters are allowed).

Passwords are case sensitive.

A user password cannot be assigned if no

administrator password exists; the E14 error code will be returned. If the administrator password is cleared, then the user password is also removed.

= Daylight saving time (DST) is a region-

speciﬁc 1-hour offset that begins in spring

and ends in fall.

0 = off/ignore

1 = USA on – Starting in 2007, DST begins

on the second Sunday of March at 2 AM

and ends at 2 AM on the ﬁrst Sunday

of November. For example, time in

California is GMT -8:00 from March to

November and GMT -7:00 from November

X1@ ]

to March. However, DST should be turned off in Hawaii, American Samoa, Guam, Puerto Rico, the Virgin Islands, the eastern time zone portion of the state of Indiana, and the state of Arizona (excluding the Navajo Nation). 2 = Europe on – begins on the last Sunday in March, ends on the last Sunday in October. DST should be turned off for Iceland.

X3%

= Event number, range = 0 - 99

(valid only while events are running)

X4)

= I/O mode

0 = input (default) 1 = output 2 = input and pull-up resistor 3 = output and pull-up resistor

X4!

= Password to display on screen (response to

password query or set). When the MLC connects to a host device via RS-232, the

password ( When the connection is via IP,

asterisks (****) if a password has been assigned, or it is an empty ﬁeld ( ) if a password hasn’t been assigned.

X4#

= I/O state

0 = off 1 = on

X4%

= E-mail event number or mailbox (1 - 64). The

response is two digits with a leading zero.

X4^

= E-mail recipient’s address (e.g.,

JDoe@extron.com) for the person to whom messages will be sent. The e-mail address has a 31 character maximum.

X4&

= Name (numeral) of e-mail ﬁle to be sent

X4(

= Default name: a combination of the model

name and the last 3 pairs of the MLC’s MAC address (e.g., MLC-104-IP-PLUS-02-74-62)

X5@

= Connection’s security level

11 = user 12 = administrator

X5&

= IR playback ﬁle number (0 to 99) (no

extension). The response includes leading zeros.

X5*

= IR playback function number (1 to 137).

The response includes leading zeros. IR function numbers 0 and 127 or higher can return information only. 0 = return all data 129 = manufacturer 130 = model 131 = class 132 = remote 133 = creation date 134 = comments 137 = user ﬁle name (a descriptive name the user/installer gave the ﬁle)

X5(

= IR playback mode

0 = play once 1 = play continuously 2 = stop continuous playback

X3#

), itself, is the response.

X4!

is 4

4-6

MLC 104 Plus Series • SIS Programming and Control

X6#

= Pulse time in 20 ms increments. If this

parameter is missing or = 0, then pulse length = default = 25 = 500 ms. 1 = 20 ms (minimum pulse time) to 65535 = 1310700 ms (maximum pulse time).

X6$

= Broadcast repetition interval in seconds

(0 to 255, default = 0 = off)

X6(

= IP connection timeout period speciﬁed in

10-second steps (1 - 65000, default = 30 = 300 seconds). If no data is received during the speciﬁed period, the Ethernet connection closes. Responses are returned with leading zeros.

X7)

= The number to insert into an email message

if a ____.eml ﬁle has an embedded server-side include “<!--#echo var =

” -->” (the E C R} command

“WCR

with no parameters.) The numeral is a 16-bit number to be employed as the user deﬁnes. This is an optional parameter. Use 0 as a

placeholder if the optional used but

Maximum = 65535.

X7#

= An e-mail account username of up to 31

characters. Do not use commas. This parameter is optional during setup and is used for SMTP authentication.

X7$

= An e-mail account password (for SMTP

authentication) of up to 31 characters. Do not use commas. This parameter is optional during setup.

X7%

= An optional string for a destination email

address using the form test@extron.com

X20)

= Speciﬁc input number (1 – 4)

1 = input 1 (the default after a reset) 2 = input 2 3 = input 3 4 = input 4

X20%

= Lamp hours elapsed (0 to 99999 hours)

The ﬁve-digit response includes leading zeros. The default is 99999 hours, which yields an “N/A” response.

X20^

= Voltage (in volts)

X20&

= Temperature in degrees Celsius (the response

is 3 digits including leading zeros)

X20*

= Display (projector) power status

0 = display power is off (default) 1 = display power is on 2 = display is powering down/off (cooling down) 3 = display is powering up/on (warming up)

X20(

= Front panel lockout (executive mode) status

0 = off/unlocked (default) 3 = on, disable/lock entire front panel (buttons, volume control) and optional connected SCP, control module(s), and IR remote control input

X21!

= Status (in hexadecimal characters) of script

or ﬁrmware button control. This variable is an 8-digit hexadecimal character calculated from a binary bit map. It is case-sensitive. Use capital letters. This bit mapped number indicates whether

X7)

is not needed.

X4&

variable is

a button is controlled by ﬁrmware or by scripts. See page 4-29 for details.

X21@

= Status (in hexadecimal characters) of control

of all button lights). This variable is an 8-digit hexadecimal character calculated from a binary bit map, and it is case-sensitive. Use capital letters. This bit mapped number indicates whether a button is controlled by ﬁrmware or by scripts. See page 4-31 for details.

X21%

= IR output port number

1 = projector/display port

X21^

= Display mute or connection status

0 = off/disconnected (default for mute) 1 = on/connected 2 = unknown/unavailable (default for connection status)

X21&

= Firmware’s event status polling period from

0 to 255 in 20 ms increments. optional: if it is not set, it defaults to 100 (2 seconds) and is not shown in the

command’s response. If the ﬁrmware does not poll for event status.

The event number that is polled is set by

X22#

the EN command.

= Digital I/O port (specifying which port)

1 = digital I/O port 1 2 = digital I/O port 2 3 = digital I/O port 3

X21&

is set to 0,

X3%

PRELIMINARY

MLC 104 Plus Series • SIS Programming and Control

4-7

SIS™ Programming and Control, cont’d

= 1, 2, 3, 4) (audio

X20)

(

PRELIMINARY

X20)

= The MLC responds with an E14 error

Additional description

and video).

Select input

code (invalid for this conﬁguration) if the

]

desired input is not set up to switch inputs

(is not in input button mode). Events are

X20)

Response

(MLC to host)

%21 Chn

URL Encoded (Web)

(host to MLC)

X20)

= The MLC sends a “busy” response (E22)

still triggered, though.

if switching functions are locked.

X20*

On (discrete).

Off (discrete).

Show the display power status.

Example: the display is powering off.

This command is used only by scripts. It

provides a way to set the power status to

match the actual state of the projector.

X20*]

Pwr

X20*]

Pwr

]

X20*]

%2A0P Pwr

X20*

For

= 0 (off), 1 (on), or 2 (unknown).

X21^

0 = display power is off

1 = display power is on (default)

2 = display is powering down/off

3 = display is powering on (warming up).

Mute.

Unmute.

Show display mute status.

This command is used only by scripts. It

provides a way to set the status to match the

actual state of the projector.

]

X21^]

X21^

X21^]

Mut

%2A0M Mut

X21^

(host to MLC)

Command/response table for SIS commands

Command ASCII (Telnet)

4-8

MLC 104 Plus Series • SIS Programming and Control

X20)

14, 22

Select an input

Input selection

Turn display power on 1P 1P

Display (projector) power

Turn display power off 0P 0P

P P

Example:

View display power status P P

*0P

X20*

Set power status

This command does not trigger the warm up/cool down (power on/power off) sequences or the button’s events.

commands to function.

The 1M and 0M commands emulate the IR 402’s Display Mute On and Display Mute Off buttons. You must program these buttons on the remote for the 1M and 0M

Display mute

Turn display mute on 1M 1M

Turn display mute off 0M 0M

View display mute status M M

*0M

X21^

This command does not trigger button events.

Set mute status

Additional description

This command sets a speciﬁc volume level

for the audio output at either the display

= volume level (0 to 100). Default

device or via an optional auxiliary Extron

switcher.

volume = 25.

X*]

Response

(MLC to host)

URL Encoded (Web)

(host to MLC)

V Vol

*47#).

When no switcher is detected at the MLS

port, the maximum volume level is limited

Example: set volume to 27.

by the max. volume range command

(

]

Vol027

Show the output volume.

Increase audio output.

Decrease audio output.

X*]

Vol

X*]

Increase audio output.

X*]

Vol

Show the output volume.

Decrease audio output.

X*]

Vol

Mute all audio outputs.

]

Amt1

= 0 (off) or 1 (on).

Unmute all audio outputs.

Show the status of audio mute.

Default setting. Adjustments and selections

can be made from the front panel in

]

Amt0

X%]

]

Exe 0

addition to via RS-232, Telnet, or Web

browser.

Lock all front panel selections and

adjustments via MLC, control modules, SCP,

and IR remote. Make selections, changes,

and conﬁgure features via RS-232 or Web/

]

Exe 3

Ethernet only. All front panels in the control

system are locked.

PRELIMINARY

(host to MLC)

Command/response table for SIS commands (continued)

Command ASCII (Telnet)

the MLC is in increment/decrement volume mode (volume mode 1). This command works only when the MLC is in volume

mode 0. See the 46# volume knob mode SIS command.

The MLC responds with an E14 (not valid for this conﬁguration) error if you attempt to set a discrete volume level while

Set the overall output volume

level

Volume adjustment (discrete, for volume mode = 0)

27V 27V

Example:

Increment the volume +V %2BV

Decrement the volume -V %2DV

View the volume level V V

Mute off 0Z 0Z

Decrement the volume -V %2DV

View the volume level V V

Increment the volume +V %2BV

Volume adjustment (for volume mode = 1)

Audio mute

Mute on 1Z 1Z

View the audio mute status Z Z

0X 0X

Disable lockout modes

Front panel security lockout modes (executive modes)

MLC 104 Plus Series • SIS Programming and Control

3X 3X

Enable lockout mode 3

4-9

SIS™ Programming and Control, cont’d

PRELIMINARY

= 0 (off, unlocked) or 3 (front panels,

control modules, and remote control

Additional description

Show lockout (executive mode) status.

X20(

locked/disabled).

Executive mode is off.

represents the number of elapsed

X20%] X20%

X20%

Response

(MLC to host)

X20(]

URL Encoded (Web)

(host to MLC)

]

X20%]

represents the ﬁve-digit numeric v

This command lets you know whether

hours of projector lamp use. The MLC

responds with two sets of lamp hours only

if two lamp hours have been set. If a lamp’s

status has not been set, it is shown as the

default (99999 hours) or “N/A”.

alue for elapsed lamp use hours, and it is

used by script to determine the number

sent in response to the “view lamp hours”

command (6S).

] X20%

X20%

the MLC’s scripts have determined if the

X20%]

X20%

X21^]

%2A 6S Lhr*

X20%

%2A 6S Lhr*

X20%

%2A

X20%

= 0 (disconnected), 1 (connected), or 2

(unknown).

display is still connected to the MLC.

X21^

) used by scripts.

X21^

0 = projector not connected.

1 = projector is connected.

This command is used to reset the

projector/display connection status ﬂag

2 = undetermined status.

(

X21^]

%2A 7S Pcs

X21^

Command/response table for SIS commands (continued)

4-10

*6S

(host to MLC)

View the lockout mode status X X

Command ASCII (Telnet)

X X

Example:

View lamp hours status 6S 6S

Status commands

X20%

Set lamp hours status for 1 lamp

X20%

Set lamp hours status for 2 lamps

MLC 104 Plus Series • SIS Programming and Control

View connection status 7S 7S

*7S

X21^

Set display connection status

= voltage in volts.

X20^

= temperature in degrees Celsius (the

Additional description

View all voltages and the MLC’s internal

temperature at once.

Display the operating voltage of the MLC’s

power input.

]

•20S

Show the ﬁeld-programmable gate array

(FPGA) voltage.

Display the internal operating temperature.

X20&

response is 3 digits including leading zeros).

Response

(MLC to host)

responses from commands

12S•13S•14S•15S

URL Encoded (Web)

(host to MLC)

11S 11S

X20^]

12S 12S

X20^]

13S 13S

X20^]

14S 14S

X20^]

X20&]

PRELIMINARY

View +12 V power supply

voltage

View +5 V IR receiver port

View all voltages and

Command/response table for SIS commands (continued)

Command ASCII (Telnet)

temperature status

voltage

View +3.3 V IP Link/FPGA

View +1.5 V FPGA voltage 15S 15S

voltage

View internal temperature status 20S 20S

MLC 104 Plus Series • SIS Programming and Control

4-11

SIS™ Programming and Control, cont’d

ASCII to Decimal Conversion Table

0 1 2 3 4 5 6 7 8 9

10 LF CR

Esc

space ! “ # $ % & ’

( ) * + , - . / 0 1

2 3 4 5 6 7 8 9 : ;

< = > ? @ A B C D E

F G H I J K L M N O

P Q R S T U V W X Y

Z [ \ ] ^ _ ‘ a b c

100

d e f g h i j k l m

110

n o p q r s t u v w

120

x y z { | } ~ Del

ASCII to Decimal Conversion Table

To ﬁnd the decimal equivalent of the ASCII character, add

the row heading and column heading numbers together.

LF = line feed

CR = carriage return (

})

Esc = escape

Del = delete

PRELIMINARY

Additional description

= speciﬁc port number

= command data section (< 200 bytes).

2 = Display RS-232/IR port

3 = MLS port

]

| X@

Response

(MLC to host)

response from command

X2!

%2A

X2)

%2A

X1&

%2A

} X@ X!

URL Encoded (Web)

(host to MLC)

X2!

X2)

X1&

E X!

= time in tens of ms for the MLC to wait

X1&

until receipt of the ﬁrst response character

before terminating the current receive

= time in tens of milliseconds (ms) for

the MLC to wait between characters being

received via a serial port before terminating

X2)

operation (default = 10 = 100 ms, max. =

32767). The response includes leading zeros.

the current receive operation (default = 2 =

= #L or #D. The letter parameter is case

sensitive (requires a capital “D” or capital

X2!

“L”). The response includes leading zeros.

20 ms, max. = 32767). The response includes

leading zeros.

]

response from command

<data>

X2!

is also missing. If these three variables are not speciﬁed, the

X2)

must both a) equal zero and b) be nonzero, or c) both be omitted.

X2)

and

X1&

may be omitted only if

X1&

, convert nonalphanumeric characters to hex numbers. A space (hex = 20) is encoded as %20.

W05%2A4%2A7%2A3L RS

<data>

}

05*4*7*3L RS

is optional.

X2!

X2)

X1&

A plus sign (hex = 2B) is encoded as %2B.

For Web encoding for

Example:

default values are used. For this command,

) in this RS command is limited to 200 bytes.

The data string (

Use the ASCII to decimal table below to convert the byte count number for

L = length of the message to be received.

D = delimiter value.

# = byte count (for L) or a single ASCII

character expressed in decimal form (for D).

Byte count # can be from 0 to 32767, default

= 0. The ASCII decimal delimiter # value

can be from 0 to 00255, default = the byte

count.

Examples: A 3‑byte length = 3L. A delimiter of

ASCII 0A = 10D.

Command/response table for SIS commands (continued)

4-12

These commands apply to any port that uses RS-232 communication: both 1-way (output) and 2-way (bidirectional) RS-232 communication.

Send data string

Serial data port conﬁguration and use

MLC 104 Plus Series • SIS Programming and Control

Command ASCII (Telnet)

), data bits

X2^

) for port

X2*

), parity (

X2%

), and stop bits (

= 300, 600, 1200, 1800, 2400, 3600, 4800,

= parity (only the ﬁrst letter is needed):

Additional description

X2&

Set baud rate (

X2%

7200, 9600, 14400, 19200, 28800, 38400, 57600,

(

O = odd

E = even

X2^

or 115200 baud.

= data bits: 7, 8 (default = 8).

= stop bits: 1, 2 (default = 1).

N = none (default)

M = mark

S = space.

X2&

X2*

Set the projector control port for 9600 baud,

= waiting time in

X1&

= waiting time in

X2)

: 0 = default, use send data string

X2#

tens of ms between characters before

terminating) and priority status

no parity, 8 data bits, and 1 stop bit.

Set the time to wait (

tens of ms until receipt of the ﬁrst response

character before terminating the receive

operation,

(

= #L or #D (see previous page).

X2!

command parameters; 1 = use conﬁgure

receive timeout command parameters) for

port

The response includes leading zeros.

Response

(MLC to host)

}

URL Encoded (Web)

(host to MLC)

X2*

X2&

X2^

X2%

(host to MLC)

E X!

X2*

%2C

X2&

%2C

X2^

%2C

X2%

%2A

] X2*

X2&

X2^

X2%

•Ccp

Cpn

] X2!

X2!

%2A

X2#

X2)

X1&

•Cce

X !

Cpn

]

] X2(

X2&

X2^

Cpn2•Ccp9600,N,8,1

X2#

%2A

X2)

%2A

X1&

}

| X2%

%2A

X !

X2!

W2%2A9600%2CN%2C8%2C1CP

}

2*9600,N,8,1CP

}

E X!

X2#

X2)

X1&

E X!

] X2!

X2#

X2)

X1&

X !

}

E X!

PRELIMINARY

Example:

Command/response table for SIS commands (continued)

Conﬁgure serial port parameters

Command ASCII (Telnet)

MLC 104 Plus Series • SIS Programming and Control

View serial port parameters

Conﬁgure receive timeout

View receive timeout

4-13

SIS™ Programming and Control, cont’d

= IR

X5*

= IR playback

X5(

(1 = display port).

X21%

PRELIMINARY

= the IR ﬁle number (0-99),

Additional description

Send an IR command via IR/Serial Output

port number

X5&

mode (0 = play once, 1 = play continuously,

2 = stop). The response includes leading

function number (1-137),

] X5(

X5*

X5&

X21%

Response

(MLC to host)

X5(

%2C

Irs

X5*

%2C

X5&

%2C

}

X21%

URL Encoded (Web)

(host to MLC)

X5(

X5*

X5&

X21% E

= the IR ﬁle number (0-99), as in ﬁles

The response to this command is the name/

description (e.g., Power On, Power Off,

Enter, Play, Stop, RGB, Menu) of the speciﬁc

command you ask about.

zeros.

X5&

= IR playback function number (1-137),

Each___.eirlecontainscommandsfora

speciﬁc device.

X5*

which corresponds to a speciﬁc function/

1.eir, 2.eir, 3.eir, etc. stored in the controller.

command set contained within the ﬁle. IR

]

{descriptive text}

X5*

%2C

X5&

}

X5*

E X5&

Command/function 1 in ﬁle 3.eir is the

Power command.

function numbers 0 and 127 or higher can

return information only.

0 = return all data

129 = manufacturer

130 = model

131 = class

132 = remote

133 = creation date

134 = comments

137 = user ﬁle name (a descriptive name the

user/installer gave the ﬁle)

Command/function 2 in ﬁle 3.eir is not

]

POWER

E13

W3%2C1IR

W3%2C2IR

}

3,1IR

3,2IR

deﬁned or does not exist, so the controller

returns E13, the invalid value error number.

Command/response table for SIS commands (continued)

4-14

Send an IR command

Command ASCII (Telnet)

IR/serial data port

13, 28

Get IR command info

MLC 104 Plus Series • SIS Programming and Control

Example:

An IR driver must be loaded into the MLC before IR command information can be read.

return the E13 error response.

X6(

= IP connection timeout period

Additional description

The global port timeout is the default

timeout period for all Telnet sessions.

X6(

speciﬁed in 10-second steps (1 - 65000,

default = 30 = 300 seconds). If no data is

received during the speciﬁed period, the

X6( ]

Response

(MLC to host)

Pti 1*

X6(

URL Encoded (Web)

(host to MLC)

W1%2A

= timeout period in seconds. See

The current port timeout period applies

to the currently open Telnet session only.

When you start another Telnet session, it

uses the default global port timeout period.

Ethernet connection closes. Responses are

returned with leading zeros.

This timeout period is applicable only when

the MLC is connected via Ethernet, and you

must be logged in as an administrator to

change this setting.

] X6(

]

Pti 0*

X6(

| X6(

W1TC

W0%2A

the description above. This variable is

applicable only when the MLC is connected

via Ethernet. If the MLC is connected via

RS-232 protocol, only the global timeout

commands apply, and any commands

involving

]

| X6(

W0TC

PRELIMINARY

}

X6(

(host to MLC)

Command/response table for SIS commands (continued)

Command ASCII (Telnet)

Set global IP port

timeout period

Ethernet data port conﬁguration and use

MLC 104 Plus Series • SIS Programming and Control

}

X6(

1TC

13, 24

Set current port’s timeout

View global IP port

period

timeout period

}

0TC

View current port’s

timeout period

4-15

SIS™ Programming and Control, cont’d

) for a

X4)

X22#

PRELIMINARY

= port number

1 = Digital I/O port 1

Additional description

Set the input/output mode (

speciﬁc port (

X4)]

X22#

2 = Digital I/O port 2

X22#

Response

(MLC to host)

%5B Iom

X4)

%2A

URL Encoded (Web)

(host to MLC)

X22#

[

X4)

= mode

3 = Digital I/O port 3

0 = input (default)

1 = output

2 = input and pull-up resistor

X4)

= 2), the digital input can be triggered by an external switch. When the

3 = output and pull-up resistor.

X4)

= Pulse time in 20 ms per unit. If this

parameter is missing or = 0, then pulse

Brieﬂy change the I/O state.

X6#

X4# ]

X22#

= I/O state:

length = default (25 = 500 ms).

65535 (1310 s) = max. pulse time.

X4#

0 = off

Switch the input/output state from on to off

1 = on

] X4#

or from off to on.

X22#

X4)]

%5D Sio

X6#

%5B

%2A3%2A

X22#

]

%2A2%5D Sio

X22#

X6#

*3*

[

*2]

]

* 1

X22#

%2A1%5D Sio

X22#

*1]

]

* 0

X22#

%2A0%5D Sio

X22#

*0]

X4#]

%5D

X22#

]

Command/response table for SIS commands (continued)

4-16

(host to MLC)

Command ASCII (Telnet)

X22#

An input voltage below 2.0 VDC is considered to be logic low. An input voltage above 2.8 VDC is considered to be logic high. These thresholds are not adjustable.

Set the input/output (I/O)

Digital I/O data port (dedicated Digital I/O ports) conﬁguration and use

mode

switch closes, the voltage drops from 5 V to 0 V.

When set for input with pull‑up resistor (

When set for output with pull‑up resistor, the MLC’s digital I/O port can drive devices such as relays and LEDs.

See the diagrams in chapter 2 and the special application examples in chapter 5 for more details.

X22#

Pulse the digital I/O state

View the digital I/O mode

MLC 104 Plus Series • SIS Programming and Control

X22#

Otherwise the E14 error (invalid for this conﬁguration) is returned by the MLC.

This and the following three commands are valid only when the port is in output mode or in output with pull‑up mode.

Toggle the I/O state

X22#

Set the I/O state to on

Set the I/O state to off

View the I/O state

)

X1!

]

) under IP setup commands later in this

}

Additional description

X2@ E

Response

(MLC to host)

URL Encoded (Web)

(host to MLC)

]

Show the MLC’s ﬁrmware version (

to two decimal places. This query yields the

number of the currently running version of

the user-updatable ﬁrmware

X1! ]

or Ver01*

or Ver01*1.01

Show the bootstrap, factory-installed, and

updated ﬁrmware versions.

response from 2Q}–{response from 3Q}–{response from 4Q}

{response from 2Q}–{response from 3Q}–{response from 4Q}

or Ver00*{

See 2Q, 3Q, and 4Q below.

The bootstrap ﬁrmware is not user-

X1! ]

MLC104IP -Thu, 28 Jun 2007 00:35:39 GMT)

replaceable, but you may need this

information during troubleshooting.

X1! ]

]

or Ver02*

1.03

Factory-installed ﬁrmware is different from

the bootstrap ﬁrmware, but it is also not user-

replaceable. This ﬁrmware was installed at

the factory; it is the version the controller

reverts to after a mode 1 reset (see chpt. 2).

In this example the factory ﬁrmware version

is 1.00 and the IP Link kernel version is 1.57

for the MLC 104 IP Plus, dated 16 January

2003.

(kernel version–model description–date time of upload)

X1!

(kernel version–model description–date time of upload)

X1!

or Ver03*

1.00(1.57-MLC104IP -Wed, 16 Jan 2003 00:00:00 GMT)

PRELIMINARY

(host to MLC)

A question mark (? or ?.??) indicates that the factory default ﬁrmware is the only ﬁrmware loaded in the MLC.

A carat (^) indicates the version of ﬁrmware that should be running, but, since a mode 1 reset was performed, the factory default ﬁrmware version is loaded and running instead.

In a query response, an asterisk (*) after the version number indicates the version that is currently used.

Command/response table for SIS commands (continued)

Command ASCII (Telnet)

Firmware version, part number and information requests

table.

An exclamation point (!) indicates that the ﬁrmware is corrupted.

Responses to commands differ depending on which, if any, verbose response mode the MLC is in. See the CV command (

Query ﬁrmware version number Q or 1Q Q or 1Q

1Q 1Q 1.01

Example:

0Q 0Q

Query verbose ﬁrmware version information

MLC 104 Plus Series • SIS Programming and Control

0Q 0Q 2.16-1.00(1.57-MLC104IP -Wed, 16 Jan 2003 00:00:00 GMT)-1.01*(1.65-

Example:

2Q 2Q

Query bootstrap ﬁrmware

2Q 2Q

Example:

version

3Q 3Q

Example:

Query factory ﬁrmware version 3Q 3Q

4-17

SIS™ Programming and Control, cont’d

]

PRELIMINARY

Additional description

Use this command to ﬁnd out which version

of the ﬁrmware, if any, was uploaded into

the controller after it left the factory

In this example the current ﬁrmware version

(kernel version–model description–date time of upload)

X1!

(kernel version–model description–date time of upload)

Response

(MLC to host)

X1!

or Ver04*

URL Encoded (Web)

(host to MLC)

1.01*(1.65-MLC104IP -Thu, 28 Jun 2007 00:35:39 GMT)

) under IP setup commands later in this

}

is 1.01, the IP Link kernel version is 1.65, for

the MLC 104 IP Plus, dated 28 June, 2007.

Show the ﬁeld-programmable gate array

(FPGA) ﬁrmware version to two decimal

places (x.xx).

X2@

Show the MLC’s part #.

IP models respond with 60-818-00,

the MLC 104 Plus shows 60-1014-00.

]

or 60-1014-00

]

or Pno60-818-00

X1! ]

or Pno60-1014-00

60-818-00

Show which input is active (selected).

X20) ]

Chn

is the input number.

X20)

MLC 104 IP Plus.

]

Inf01*MLC 104 IP PLUS

MLC 104 IP PLUS

]

MLC 104 IP Plus.

Show amount of memory used and total

available memory for system operations.

]

Inf02*MLC 104 IP PLUS

MLC 104 IP PLUS

# bytes used out of # of kbytes

or Inf03*# bytes used out of # of kbytes

# bytes used out of # of kbytes

]

Show amount of user memory used and

total available user memory.

or Inf04*# bytes used out of # of kbytes

P1##•P2##•K1##•K2##•K3##•K4##•S

Command/response table for SIS commands (continued)

4-18

(host to MLC)

Query updated ﬁrmware version 4Q 4Q

4Q 4Q

Example:

table.

Responses to commands differ depending on which, if any, verbose response mode the MLC is in. See the CV command (

Query FPGA version 32Q 32Q

Request the MLC’s part number N N

I I

The MLC responds with an E14 error if no input buttons are set up for ﬁrmware control (input switching).

Request A/V input number

Command ASCII (Telnet)

MLC 104 Plus Series • SIS Programming and Control

32I 32I

4I 4I 217856 Bytes Used out of 7232 KBytes

Example:

Request the model description 2I 2I

Request the model name 1I 1I

Request system memory usage 3I 3I

Request user memory usage 4I 4I

Request status of attached hardware

Prefixes for connected devices:

P1 = SCP #1, address 0

P2 = SCP #2, address 1

K1 = control module #1, address 0

K2 = control module #2, address 1

K3 = control module #3, address 2

K4 = control module #4, address 3

S = MediaLink device, typically

a slaved (auxiliary) MLS

switcher.

For :

00 = not present

01 = MLS 306

02 = MLS 506

03 = MLS 506MA 70 V

04 = MLS 506SA

05 = MLS 506MA 100 V

06 = MLS 100 A

07 = MLS 103 V

08 = MLS 103 SV

09 = MLS 102 VGA

10 = MLA-VC10

11 = MLS 304MA

12 = MLS 406

13 = MLS 406MA

14 = MLS 406SA

15 = MLS 304SA

16 = PVS 204SA

99 = non-MLS, non-

PVS switcher.

For ##:

00 = not present

01 = present (SCP)

or IRCM-VCR

02 = IRCM-DVD

03 = IRCM DVD+

04 = ACM-Level

05 = ACM-Tone

06 = RCM-SC

07 = RCM-SCLT

08 = IRCM-Tape

09 = CM-5BB

10 = CM-20BB

11 = IRCM-DV+

12 = CM-9BLB

13 = CM-3BLB

14 = CM-19AC

99 = unrecognized.

000 = not present 101 = IPI 101 AAP 104 = IPI 104 AAP

For ???:

), such as “AuditoriumMLC”,

X1@

Additional description

Show the absence of or types of connected

devices.

Response

(MLC to host)

URL Encoded (Web)

(host to MLC)

]

This example includes one SCP (P101),

an IRCM-DVD+ (K111 and K211), an

RCM-SCLT (K307), an IRCM-Tape (K408),

and an MLS 102 VGA (S09).

P101 P200 K111 K211 K307 K408 S09

32I 32I

= the name the MLC was shipped with:

Change the MLC’s name to one of your

choosing (

“Rm316-AVcenter”, or “exec-boardroom-

ctrl”. The name consists of up to 24

alphanumeric characters (and the minus

sign). The ﬁrst character must be a letter,

the last character cannot be a minus sign

MLC-104-IP-PLUS-##-##-##, a combination

(hyphen). Either case (upper, lower) is OK.

of the model name and the last 3 pairs

is the MLC’s current, user-deﬁned unit

is the MLC’s factory default name.

of hex numbers in the controller’s MAC

name.

address (e.g., MLC-104-IP-PLUS-02-74-62).

X4(

X4( ] X1@

X1@ ]

Ipn•

X4( ] X4(

Ipn•

X1@

The non‑IP model accepts these commands, but it does not have a LAN port, so it cannot make use of the settings.

W%20CN

PRELIMINARY

| X1@ ]

WCN

}

C N

E X1@

}

•CN

}

Command/response table for SIS commands (continued)

Command ASCII (Telnet)

Examples:

Set the unit name

IP setup commands (IP models only)

Set unit name to factory default

MLC 104 Plus Series • SIS Programming and Control

Read the unit name

4-19

SIS™ Programming and Control, cont’d

MM/DD/YY‑HH:MM:SS.

) for the MLC’s location. GMT

= Local date and time format.

Additional description

X1# ] X1#

Response

(MLC to host)

Ipt•

= Local date and time format. The

The set format is

Example: 09/07/06‑10:54:00.

Read format is day of week, DD month year

HH:MM:SS.

Example: Fri, 08 Sept 2006 18:19:33.

Set the Greenwich Mean Time (GMT) offset

value (

offset (-12.00 to +14.00) represents the time

difference in hours and minutes (+/-hh:mm)

X # ]

X1# ] X1#

relative to Greenwich, England. The leading

zero is optional. For example, 5:30 = 05:30.

Do not use a plus (+) sign if the GMT offset

is positive.

] X3$

]

Ipx

]

1 Idh

]

0 Idh

= IP address (xxx.xxx.xxx.xxx). Leading

= 0 (off) or 1 (on).

zeros in each of the four ﬁelds are optional

in setting values.

] X1$ X1$

] X%

= hardware (MAC) address (xx-xx-xx-

X1*

Leading zeros in each of the four ﬁelds are

]

xx-xx-xx).

suppressed in returned values.

] X1*

]

Iph•

PRELIMINARY

X1#

URL Encoded (Web)

(host to MLC)

}

C T

(host to MLC)

E X1#

Command/response table for SIS commands (continued)

Set date/time

Command ASCII (Telnet)

CZ| Ipz

X #

W CT

}

Read date/time

CZ

E X#

Set GMT offset

| X#

X3$

WCZ

= Daylight saving time (DST) is a region-speciﬁc 1-hour offset that begins in spring and ends in fall.

X3$

– Starting in 2007, DST begins on the second Sunday of March at 2 AM and ends at 2 AM on the ﬁrst Sunday of November.

0 = off/ignore

1 = USA on

For example, time in California is GMT -8:00 from March to November and GMT -7:00 from November to March. However, DST should

}

C X

}

E X3$

Read GMT offset

Set daylight saving time

| X3$

W CX

W1DH

W0DH

}

be turned off in Hawaii, American Samoa, Guam, Puerto Rico, the Virgin Islands, the eastern time zone portion of the state of Indiana,

and the state of Arizona (excluding the Navajo Nation).

2 = Europe on – begins on the last Sunday in March, ends on the last Sunday in October. DST should be turned off for Iceland.

Read daylight saving time

Set DHCP on

Set DHCP off

CI| Ipi•

| X%

X1$

WDH

| X1$

W CI

| X1*

WCH

}

C I

}

E X1$

Changing DHCP from on to off also resets the IP address to the factory default (192.168.254.254).

View DHCP mode

Set IP address

}

Read IP address

}

Read hardware address (MAC)

4-20

MLC 104 Plus Series • SIS Programming and Control

X2@

= subnet mask (xxx.xxx.xxx.xxx).

] X1(

Syntax is the same as for IP addresses.

Additional description

X1(

Response

(MLC to host)

Ips•

X1(

URL Encoded (Web)

(host to MLC)

= IP address (xxx.xxx.xxx.xxx).

Leading zeros are optional in setting values.

Leading zeros are suppressed.

Leading zeros are optional.

] X1$ X1$

Ipg•

| X1(]

| X1$ ]

X1$

WCS

WCG

Enable or disable the verbose mode via this

command. For

0 = clear/none, default for Telnet connections;

responses are not echoed to the host

1 = verbose mode is on, default for RS-232

host control; responses are echoed to the

host and displayed to the user

2 = send tagged responses for queries

3 = verbose mode is on and tagged

responses are sent for queries.

] X2@

Vrb

rather than just the data.

X2@

X1@ ]

]

Example: This shows two client connections.

]

| X2@

WCV

]

Icc [total number of client connections]

[total number of client connections]

002

WCC

PRELIMINARY

}

X1$ E

}

X1(

(host to MLC)

}

X2@ E

,theresponseisIpn•

}

For example, for

the controller can send out unsolicited information (such as notice of a volume or input change or a change in some other setting). That is an example of a verbose (wordy)

relationship between the controller and a connected device. Verbose mode creates more network trafﬁc than usual, which can slow down network performance.

Verbose mode is usually enabled for troubleshooting and disabled for daily use.

• ForadirectRS-232connection,thecontrollerissetforverbosemodebydefault.

• WhentheMLCisconnectedviaEthernet,verbosemodeisdisabled(bydefault)inordertoreducetheamountofcommunicationtrafconthenetwork.

Verbose mode is a communication mode in which the device responds with more information than it usually would—more than the device, itself, requires. For example,

If tagged responses are enabled, all read commands return the constant string + data, the same as for setting a value.

Read subnet mask

Command/response table for SIS commands (continued)

Set subnet mask

Command ASCII (Telnet)

Set gateway IP address

Read gateway IP address

Set verbose response mode on/

off

MLC 104 Plus Series • SIS Programming and Control

If you want to use the verbose mode with a controller connected via Ethernet, this mode must be set to “on” each time you reconnect to the controller.

Example:

Read verbose mode status

Get a connection listing

4-21

SIS™ Programming and Control, cont’d

= Broadcast repetition interval in

Additional description

This command details how often and to

what subnet work the MLC broadcasts a

message.

X6$

] X1$

= IP address (xxx.xxx.xxx.xxx). Leading

X1$

seconds (0 to 255 [4.25 minutes], default = 0

= off).

X6$

Response

(MLC to host)

Bmd

zeros in each of four ﬁelds are optional in

setting values, and they are suppressed in

returned values.

Default broadcast address: 255.255.255.255.

This command sets the repeat interval to

zero, turning off the broadcast mode.

]

,255.255.255.255

X6$

Bmd

] X1$

Bmd 000,255.255.255.255

X5@

For

]

Set the administrator access password

11 = user

12 = administrator

]

X5@ ]

X4!

Pvl

Ipa•

), itself, is the

X3#

= Password to display on

X4!

, 4 to 12 alphanumeric characters).

X3#

The password is case sensitive. Special

characters (spaces, symbols) are not

(

allowed.

screen (response to password query).

When the MLC connects to a host device

via RS-232, the password (

response. When the connection is via IP,

is 4 asterisks (****) if a password has

X4!

been assigned, or it is an empty ﬁeld ( )

if a password hasn’t been assigned.

Clear/remove all passwords (administrator

]

Ipa•

and user).

PRELIMINARY

X1$

%2C

X6$

URL Encoded (Web)

(host to MLC)

X6$

W 0 EB

| X6$

W EB

| X5@

WCK

]

| X4! ]

X3#

W%20 CA

WCA

}

X1$

X6$

(host to MLC)

Command/response table for SIS commands (continued)

Command ASCII (Telnet)

Set the broadcast mode

}

X6$ E

Set the broadcast mode to the

default address

}

0 EB

View the broadcast mode

Clear the broadcast mode

Password and security settings

}

Read connection’s security level

}

X3# E

Set administrator password

Clear administrator password

}

•CA

}

A user password cannot be assigned if an administrator password does not exist. Also, if the administrator password is cleared, the user password is also cleared.

Read administrator password

4-22

MLC 104 Plus Series • SIS Programming and Control

= Password

is 4 to 12

X4!

X3#

alphanumeric characters). The password is

case sensitive. Special characters (spaces,

Additional description

Set the user password (

symbols) are not allowed.

to display on screen.

This clears the user password only.

Select a number for the port that will not

conﬂict with any other ports.

This resets the Telnet port to port 23.

Setting the port number to 0 disables the

]

port.

]

This resets the Web port to port 80.

]

This resets the direct access port to port

]

2001.

]

X4! ]

Response

(MLC to host)

Ipu•

X3#

URL Encoded (Web)

(host to MLC)

}

X3#

(host to MLC)

14, 24

A user password cannot be assigned if an administrator password does not exist. Also, if the administrator password is cleared, the user password is also cleared.

]

Ipu•

| X4! ]

W%20CU

WCU

}

•CU

]

Pmt port#

Pmt 00023

Pmt 00000

port#

Pmh port#

Wport# MT

W23MT

W0MT

}

port# MT

23MT

0MT

parameter) error.

Do not set two or more ports to the same port number. Setting two ports to the same number could cause networking conﬂicts and will also result in an E13 (invalid

If you remap a port, you must set the port number to 1024 or higher, unless you reset the port to the default number or disable the port by setting it to 0.

WMT

}

Wport# MH

port# MH

Pmh 00080

Pmh 00000

W80MH

W0MH

}

80MH

0MH

]

port#

Pmd port#

WMH

Wport# MD

}

port# MD

Pmd 02001

W2001MD

}

2001MD

]

Pmd 00000

port#

W0MD

WMD

}

0MD

PRELIMINARY

Command/response table for SIS commands (continued)

Set user password

Command ASCII (Telnet)

Read user password

Clear user password

For security reasons the network administrator may wish to assign new/different port numbers to the controller’s Telnet, Web browser, and direct access ports or to disable

one or more ports. Typically Telnet uses port 23, Web access is via port 80 (HTTP), and direct access is via port 2001.

Remapping port designations (IP models only)

Set the Telnet port map

Reset the Telnet port map

Disable the Telnet port map

Read the Telnet port map

Disable the Web (HTTP) port

Set the Web (HTTP) port map

Reset the Web (HTTP) port map

Read the Web (HTTP) port map

MLC 104 Plus Series • SIS Programming and Control

Set the Direct Access port map

Disable the Direct Access port

Reset the Direct Access port

map

Read the Direct Access port map

4-23

SIS™ Programming and Control, cont’d

next‑level.

]

PRELIMINARY

Additional description

The directory’s name must be composed

of alphanumeric characters and may

include the minus sign (hyphen, -) and the

colon (:). The ﬁrst character must be a letter.

Case does not matter. No blank or space

characters are permitted in the name.

]

Response

(MLC to host)

Dir•path/directory/

URL Encoded (Web)

(host to MLC)

W path %2F directory %2F CJ

}

path/directory/ CJ

(host to MLC)

Include the full path, not just the name of

the directory. Nonalphanumeric characters

in the path (e.g. /) must be encoded to hex.

characters for use with a Web browser.

In this case, the path is majordirectory/

subdirectory/. The directory that was just

created or changed to is called

Dir•majordirectory/subdirectory/next‑level/

}

W majordirectory %2F subdirectory %2F next‑level %2F CJ

majordirectory/subdirectory/next‑level/ CJ

This example just created a subdirectory for

storing the user’s custom-made HTML ﬁles.

The directory that was just created is called

HTMLﬁles.

]

Dir•custompages/HTMLﬁles

}

W custompages %2F HTMLﬁles %2F CJ

custompages/HTMLﬁles/ CJ

]

Dir•oak

Dir•/

W oak %2F CJ

W %2F CJ

}

oak/CJ

/CJ

]

Dir•path/directory/

path/directory/

W %2E %2E CJ

}

.. CJ

CJ W CJ

]

Del•ﬁlename

Ddl

W ﬁlename EF

W %2F EF

}

ﬁlename EF

/EF

Command/response table for SIS commands (continued)

4-24

the MLC may have the same names.

A directory does not fully exist until a ﬁle has been copied into that path. Also, the MLC operates differently from PC operating systems: ﬁles stored in and directories created in

Example:

Change or create a directory

Command ASCII (Telnet)

Directory commands

MLC 104 Plus Series • SIS Programming and Control

Example:

Change back to the root directory

The current directory is determined on a per‑connection basis. At the beginning of each IP connection/session, the current directory is selected as the root directory.

Go up one directory level

View the current directory

24,28

Erase the user-supplied Web page

and ﬁles

Erase the current directory and

its ﬁles

File handling commands

]

in bytes]”;

]]

]

Additional description

]•[day,datetimeofupload]GMT•[lesizen in bytes]

]

Response

(MLC to host)

Ddl

[lename1]•[day,datetimeofupload]GMT•[lesize1inbytes]][lename2]•[day,datetimeofupload]GMT•[lesize2inbytes]][lename3]•[day,datetimeofupload]GMT•[lesize3inbytes]]…

[ﬁlename n

URL Encoded (Web)

(host to MLC)

W %2F %2F EF

W DF

Retrieve a list of ﬁles stored in the controller.

Each line of the response lists a different

ﬁlename and its corresponding ﬁle size. The

last line of the response indicates how much

available ﬁle space there is.

]]

server-side include (inserted between <script> </script> tags into

™

var ﬁle=new Array();

[spaceremaining(to7-digits)]•BytesLeft

ﬁle[1]=“[ﬁlename 1],[day, date time1 of upload] GMT,[ﬁle size 1 in bytes]”; ]ﬁle[2]=“[ﬁlename 2],[day, date time2 of upload] GMT,[ﬁle size 2 in bytes]”; ]ﬁle[3]=“[ﬁlename 3],[day, date time3 of upload] GMT,[ﬁle size 3 in bytes]”; ]…

ﬁle[n]=“[ﬁlename n],[day, date timen of upload] GMT,[ﬁle size n

ﬁle[n+1]=”[space remaining (to 7-digits)],Bytes Left";

4.evt Tue, 01 Mar 2005 02:03:07 GMT 42233

1.eml Tue, 01 Mar 2005 02:03:34 GMT 200

2.eml Tue, 01 Mar 2005 02:03:34 GMT 300

2.eir Tue, 01 Mar 2005 02:03:34 GMT 1683

6.evt Tue, 01 Mar 2005 02:03:36 GMT 17956

4.eir Tue, 01 Mar 2005 02:03:47 GMT 6849

MLCmain.sc Tue, 01 Mar 2005 02:03:52 GMT 8515

0.evt Tue, 01 Mar 2005 02:03:56 GMT 34413

99.eml Tue, 01 Mar 2005 02:04:19 GMT 178

buttons.xml Tue, 01 Mar 2005 02:04:19 GMT 17214

MLC.cfg Wed, 16 Mar 2005 21:34:45 GMT 7188

6568448 Bytes Left

PRELIMINARY

W DF

}

//EF

(host to MLC)

24,28

HTML source code) follows this structure:

When working with the MLC’s embedded Web pages, the response visible in a JavaScript

Erase the current directory and

its subdirectories

List ﬁles from the current

Command/response table for SIS commands (continued)

Command ASCII (Telnet)

Command/response table for special function SIS commands (accessible via RS-232 only)

Command ASCII

Command

(host to MLC)

Response

(MLC to host)

values

and additional descriptions

Delay times

Most projectors require a certain amount of time during warm-up and cool-down during which they do not accept commands. Set the “lock input selection during power on/off” command (53#, page 4-39) ﬁrst. Then send this command (1#) to specify the amount of time for the MLC to wait between sending the projector a power-on or power-off command and when the next input button press can occur.

Global Conﬁgurator automatically sets the warm‑up and cool‑down delay times based on default values in the display/

Power on delay

Example:

Power off delay

Example:

Power off button delay

projector’s driver. This SIS command overrides the default settings. For best results, set delay times to 2 to 4 seconds longer than the times required by the display/projector. This ensures that the correct Display power button state is shown on the front panel and on the GV and standard embedded Web pages.

X?*1# WarmUp*

8*1# WarmUp*008 Example: set a 16 second power

1# 023 Example: view the power on

*2# CoolDown*

23*2#

*22# PwrOffDly*

CoolDown*023

X?]

X? ]

]

X? ]

0 = 0 seconds, 1 = 2 seconds, 2 = 4 seconds, ... in 2 second steps up to

150 = 300 seconds (5 minutes).

on delay.

delay setting (23 = 46 seconds). 0 = 0 seconds, 1 = 2 seconds, 2 = 4 seconds,... in 2 second

steps up to 150 = 300 seconds. Example: set a 46 second power

off delay. 0 = the power off button

requires no hold delay (default), 1 = the power off button

requires a 2-second hold delay before starting the power-off sequence.

Audio settings

Limit audio level on display power-on

The maximum is limited by the maximum volume setting (47#). If the maximum volume (47# command) is set, the

limit audio level feature (11# command) is automatically set to 25% of the maximum volume (47#). See page 4‑39.

*11# VolLimit*

X? ]

If this feature is enabled, the maximum initial power-up volume level does not exceed the level speciﬁed by this command.

0 = audio off, ..., 20 = default value, ..., 100 = no limit on audio level at

power-on.

PRELIMINARY

MLC 104 Plus Series • SIS Programming and Control

4-33

SIS™ Programming and Control, cont’d

Button to

associate the

VCR half

(even address,

2 or 4) with

Button to

associate the

DVD half

(odd address,

1 or 3) with

(A x 16) + (B) =

X? is a decimal

number from 000 to 67.

Button to

associate the

VCR half

(even address,

2) with

Button to

associate the

DVD half

(odd address,

1) with

= (3 x 16) + (4) = 52

Command/response table for special function SIS commands, continued

PRELIMINARY

Command ASCII

Command

(host to MLC)

Example:

28*11#

Response

(MLC to host)

VolLimit*028

]

values

and additional descriptions

Example: limit power-up volume to audio level 28.

Button associations (virtual mapping) for an IRCM-DV+

By design an IRCM-DV+ can be assigned paired module addresses (by DIP switch) of either 1&2 or 3&4 only. It cannot be assigned to addresses 2&3 or 1&4. The odd-numbered module address (1 or 3) is reserved for DVD control, the even-numbered module address (2 or 4) is for VCR control. The address DIP switches must be set in order for the MLC to recognize and reserve memory space for the module. Refer to the Control Modules User’s Manual.

To use an optional IRCM-DV+ with an MLC, you need to associate the DVD portion of this module with an MLC input selection button, and also associate the VCR portion with a different MLC input selection button. The associated button must be selected (pressed) in order to activate and use the VCR portion or the DVD portion of the module. You cannot activate both parts (VCR and DVD) at the same time. If you do not associate (map) the IRCM-DV+’s addresses (1&2 or 3&4) with MLC buttons, you cannot activate and use either the DVD or the VCR part of the IRCM-DV+.

For MLC 104 IP Plus Series MediaLink Controllers, you can assign both the DVD and VCR portions of an

Here is how to determine the value of

IRCM-DV+ address 2, address 1 button association

Associate MLC’s buttons w/IRCM-DV+

Example:

IRCM‑DV+ to the same input selection button. A and B must both be inputs that are set up for input switching mode (ﬁrmware control) via Global Conﬁgurator.

X? for the following commands:

*25# DVA_VMap*

52*25# DVA_VMap*052

X?]

Associate speciﬁc MLC input selection buttons with the VCR and DVD halves of the IRCM-DV+ that has DIP switchbased addresses of 1 and 2.

can be from 0 to 67.

Associate the MLC’s input 4 button with IRCM-DV+ address 1 (DVD functions) and the MLC’s input 3 button with IRCM-DV+ address 2 (VCR functions). See the illustration at left.

IRCM-DV+ address 4, address 3 association

Associate MLC’s buttons w/IRCM-DV+

*26# DVB_VMap*

IRCM-DV+ activation

Force an IRCM-DV+ to activate or to turn off one half (DVD or VCR)

X?*Y?

*24# DV_Force*X?*

This command overrides the 25# and 26# commands listed above.

Read an IRCM-DV+’s status

4-34

This command does not require each half of the IRCM‑DV+ to be associated

with an input button.

*24#

MLC 104 Plus Series • SIS Programming and Control

X?]

Y? X?

Associate MLC buttons with the VCR & DVD parts of an IRCM-DV+ that has DIP switchset addresses of 3 and 4.

= DIP switch address (1, 2, 3,

or 4) of the IRCM-DV+.

For

: 0 = turn off IRCM-DV+, 1 = force the DVD half on (make it active), 2 = force the VCR half on.

See the X? and Y? values above.

CONFIG

DISPLAY

VOLUME

MLC 104 IP PLUS

VCR

DVD

OFF

2 3

GROUND

IR IN

GROUND

IR OUT

SCP

GROUND

Tx Rx

DISPLAY

RS-232/IR

LAN

PRESS TAB WITH

TWEEKER TO REMOVE

A B

MLS PWR

RS-232 12V

DIGITAL

I/O

A B C D E

COMM LINK

+V OUT

GROUND

+12V IN

1 2

107

9 10 11 12

MLC 104 Plus Series

SCP 104

Button/Switch Memory Block Numbering for the

MLC 104 Plus Series, SCP 104 Series, and IR 402

25 24

Clock-

wise

Counterclockwise

Digital

Inputs/Outputs

MLC 104 Plus Series Right Side

(rotated)

121 123

111

109

125 110

116 118

120 122 124

113

112

114

119

117

115

108

IR 402

See MLC 104 Plus Series front panel.

9-23

Command/response table for special function SIS commands, continued

Command ASCII

Command

Response

(MLC to host)

values

and additional descriptions

(host to MLC)

Button press/release emulation

Emulating a button press or release causes the commands and actions that are associated with the button via the main event script to be executed. Button emulation triggers only what has been set up via the Front Panel tab in Global Conﬁgurator. Emulation does not trigger the built-in SIS input switching commands ( on/off commands (1P or 0P).

See the diagrams below and on the next page to determine the number of the memory block associated with each button. Button press/release emulation commands start on page 4-37.

The input button register numbering shown in the following illustrations is for a stand‑alone MLC. It does not

include button numbering for an optional auxiliary switcher connected to the MLS port.

X20)

!) or the projector power

PRELIMINARY

MLC 104 Plus Series • SIS Programming and Control

4-35

SIS™ Programming and Control, cont’d

SCREEN POSITION

DOWN UPSTOP

DVD & VCR CONTROL

PLAY NEXT/FWD PAUSE STOP

TUNER

PREV/REW

ENTER

TITLE MENU

TV/VCR

DVD VCR

DVD & VCR CONTROL

PLAY NEXT/FWD PAUSE STOP

TUNER

PREV/REW

ENTER

TITLE MENU

TV/VCR

DVD VCR

CM-3BLB

CM-9BLB

CM-3BLB, DIP switch set for address 3 (module 4)

Button/Switch Memory Block Numbering for Control Modules (IRCMs, ACMs, RCMs, CMs)

Memory Block Numbering

for Any Control Module

with Black Buttons

(Example is for Control Module 1)

Memory Block Numbering

for Control Modules with

Clear, Backlit Buttons

26 27 28 29 30

26 27 28

40 45

31 35343332 36 40393837 41 45444342

26 27 28

86 87 88

26 27 28

29 30 31

32 33 34

Memory Block Numbering Examples

for Modules with Black Buttons

DVD Half (module 1)

IRCM-DV+ with DIP switch set for addresses 0 and 1 (modules 1 and 2)

RCM-SC with DIP switch set for address 2 (module 3)

VCR Half (module 2)

31 353332 36 39

41 45444342

66 68 70

71 76 77 78 79

67 69

82 83 84

81 85

72 73 74 75

26 28 30

36 37 38 39

27 29

42 43 44

41 45

32 33 34 35

7068

51 555352 56 59

61 65646362

Module 3 has memory blocks 66-85.

Module 1 has memory blocks 26-45.

46 48 50

56 57 58 59

47 49

62 63 64

61 65

52 53 54 55

Module 2 has memory blocks 46-65.

Module 4 has memory blocks 86-105.

Buttons and memory blocks are numbered in a grid of 5 columns and 4 rows of buttons on each module, as on the CM-20BB, shown above.

Backlit button modules feature a grid of 3 columns and 1 or 3 rows of buttons, as shown at left.

N There are still 20 memory

blocks for each module.

• Module 1: memory blocks 26-45.

• Module 2: memory blocks 46-65.

• Module 3: memory blocks 66-85.

• Module 4: memory blocks 86-105.

CM-3BLB

CM-9BLB

86 87 88

89 90 91 92 93 94

• • •

104 105 —

Command/response table for special function SIS commands, continued

Command ASCII

Command

Response

(MLC to host)

(host to MLC)

Each control module (IRCM, ACM, RCM, CM) has 20 memory blocks reserved for it, no matter how many buttons are physically present on the module:

•module1:blocks26-45

•module2:blocks46-65

MLC 104 Plus Series units can be connected to a maximum of four control modules. See page 2‑12 for cabling

•module3:blocks66-85

•module4:blocks86-105

instructions.

Memory block numbers for each module are sequential from left to right, top row to bottom row, as shown below.

PRELIMINARY

values

and additional descriptions

4-36

MLC 104 Plus Series • SIS Programming and Control

Extron Electronics MLC 104 Plus User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

FCC Class A Notice

Table of Contents

About This Manual

About the MLC 104 Plus Series MediaLink® Controllers

MLC 104 Plus Series features

Additional features for IP models

Controlling other devices

Projector Control

How the MLC 104 Plus Series Controllers Work: MLC Components and Interactions

Optional Control Modules and IR 402 Remote Control

System Requirements

Hardware requirements

Software requirements

Setup Checklist: How to Proceed With Installation

Front Panel Features and Operation

Buttons

Volume control

Front Panel Security Lockout (Executive Mode)

Enabling and disabling front panel lockout via the embedded Web pages and the front panel

Using the Web pages (IP models)

Using the front panel (all models)

Preparing the MLC for front panel lockout

Setting up and enabling or disabling PINs

Scheduling front panel lockouts

IR Control

IR learning

IR remote control

Panels and Cabling

Right/rear panel and cabling

Projector/display connections

Additional control connections

Power connection

Top panel: IR learning sensor

Left side panel: reset features

Resetting the Unit

Pinout Guide

The Basic Setup Steps: a Guide to this Chapter and Other Resources

Communicating with the MLC

RS-232

Telnet

Setting up the PC for IP communication with an IP-enabled MLC

Downloading the software and getting started

PC system requirements

Resources and notes

In Global Conﬁgurator in the Advanced Configuration tab you can set

Power Settings (Display power up/power down settings)

Volume settings

Miscellaneous settings

Setting up passwords for IP models

Printing a wiring block diagram

Controlling an IP Link-enabled MLC

Embedded Web pages

Status

System Status

Statistics

System Settings

Passwords

Email Alerts

Firmware Upgrade

File Management

Control

User Mode

IR Drivers

Serial Devices (serial drivers)

GlobalViewer® Web Pages

Customizing the MLC’s Control Web Pages

Host-to-MLC Communications

MLC-initiated messages

Password information (IP models)

Error responses

Error response references

Commands and Reponses

Using the command/response tables

Command/response table for SIS commands

Command/response table for special function SIS commands (accessible via RS-232 only)
