Extron electronics MGP 464 DI, MGP 464 User Manual

MGP 464

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. [phone]
Fax [phone]

[e-mail]

MGP 464 DI

Multi-Graphic Processor

68-1235-01 Rev. A

03 06

Precautions

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. [phone]
Fax [phone]

[e-mail]

Safety Instructions • English

This symbol is intended to alert the user of important operating and maintenance
(servicing) instructions in the literature provided with the equipment.

This symbol is intended to alert the user of the presence of uninsulated dangerous
voltage within the product’s enclosure that may present a risk of electric shock.

Caution

Read Instructions • Read and understand all safety and operating instructions before using the equipment.
Retain Instructions • The safety instructions should be kept for future reference.
Follow Warnings • Follow all warnings and instructions marked on the equipment or in the user

information.

Avoid Attachments • Do not use tools or attachments that are not recommended by the equipment

manufacturer because they may be hazardous.

Consignes de Sécurité • Français

Ce symbole sert à avertir l’utilisateur que la documentation fournie avec le matériel
contient des instructions importantes concernant l’exploitation et la maintenance
(réparation).

Ce symbole sert à avertir l’utilisateur de la présence dans le boîtier de l’appareil
de tensions dangereuses non isolées posant des risques d’électrocution.

Attention

Lire les instructions• Prendre connaissance de toutes les consignes de sécurité et d’exploitation avant

d’utiliser le matériel.

Conserver les instructions• Ranger les consignes de sécurité afi n de pouvoir les consulter à l’avenir.
Respecter les avertissements • Observer tous les avertissements et consignes marqués sur le matériel ou

présentés dans la documentation utilisateur.

Eviter les pièces de fi xation • Ne pas utiliser de pièces de fi xation ni d’outils non recommandés par le

fabricant du matériel car cela risquerait de poser certains dangers.

Sicherheitsanleitungen • Deutsch

Dieses Symbol soll dem Benutzer in der im Lieferumfang enthaltenen
Dokumentation besonders wichtige Hinweise zur Bedienung und Wartung
(Instandhaltung) geben.

Dieses Symbol soll den Benutzer darauf aufmerksam machen, daß im Inneren des
Gehäuses dieses Produktes gefährliche Spannungen, die nicht isoliert sind und
die einen elektrischen Schock verursachen können, herrschen.

Achtung

Lesen der Anleitungen • Bevor Sie das Gerät zum ersten Mal verwenden, sollten Sie alle Sicherheits-und

Bedienungsanleitungen genau durchlesen und verstehen.

Aufbewahren der Anleitungen • Die Hinweise zur elektrischen Sicherheit des Produktes sollten Sie

aufbewahren, damit Sie im Bedarfsfall darauf zurückgreifen können.

Befolgen der Warnhinweise • Befolgen Sie alle Warnhinweise und Anleitungen auf dem Gerät oder in der

Benutzerdokumentation.

Keine Zusatzgeräte • Verwenden Sie keine Werkzeuge oder Zusatzgeräte, die nicht ausdrücklich vom

Hersteller empfohlen wurden, da diese eine Gefahrenquelle darstellen können.

Warning

Power sources • This equipment should be operated only from the power source indicated on the product. This

equipment is intended to be used with a main power system with a grounded (neutral) conductor. The
third (grounding) pin is a safety feature, do not attempt to bypass or disable it.

Power disconnection • To remove power from the equipment safely, remove all power cords from the rear of

the equipment, or the desktop power module (if detachable), or from the power source receptacle (wall
plug).

Power cord protection • Power cords should be routed so that they are not likely to be stepped on or pinched by

items placed upon or against them.

Servicing • Refer all servicing to qualifi ed service personnel. There are no user-serviceable parts inside. To

prevent the risk of shock, do not attempt to service this equipment yourself because opening or removing
covers may expose you to dangerous voltage or other hazards.

Slots and openings • If the equipment has slots or holes in the enclosure, these are provided to prevent

overheating of sensitive components inside. These openings must never be blocked by other objects.

Lithium battery • There is a danger of explosion if battery is incorrectly replaced. Replace it only with the

same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the
manufacturer’s instructions.

Avertissement

Alimentations• Ne faire fonctionner ce matériel qu’avec la source d’alimentation indiquée sur l’appareil. Ce

matériel doit être utilisé avec une alimentation principale comportant un fi l de terre (neutre). Le troisième
contact (de mise à la terre) constitue un dispositif de sécurité : n’essayez pas de la contourner ni de la
désactiver.

Déconnexion de l’alimentation• Pour mettre le matériel hors tension sans danger, déconnectez tous les cordons

d’alimentation de l’arrière de l’appareil ou du module d’alimentation de bureau (s’il est amovible) ou
encore de la prise secteur.

Protection du cordon d’alimentation • Acheminer les cordons d’alimentation de manière à ce que personne ne

risque de marcher dessus et à ce qu’ils ne soient pas écrasés ou pincés par des objets.

Réparation-maintenance • Faire exécuter toutes les interventions de réparation-maintenance par un technicien

qualifi é. Aucun des éléments internes ne peut être réparé par l’utilisateur. Afi n d’éviter tout danger
d’électrocution, l’utilisateur ne doit pas essayer de procéder lui-même à ces opérations car l’ouverture ou le
retrait des couvercles risquent de l’exposer à de hautes tensions et autres dangers.

Fentes et orifi ces • Si le boîtier de l’appareil comporte des fentes ou des orifi ces, ceux-ci servent à empêcher

les composants internes sensibles de surchauffer. Ces ouvertures ne doivent jamais être bloquées par des
objets.

Lithium Batterie • Il a danger d’explosion s’ll y a remplacment incorrect de la batterie. Remplacer uniquement

avec une batterie du meme type ou d’un ype equivalent recommande par le constructeur. Mettre au reut les
batteries usagees conformement aux instructions du fabricant.

Vorsicht

Stromquellen • Dieses Gerät sollte nur über die auf dem Produkt angegebene Stromquelle betrieben werden.

Dieses Gerät wurde für eine Verwendung mit einer Hauptstromleitung mit einem geerdeten (neutralen)
Leiter konzipiert. Der dritte Kontakt ist für einen Erdanschluß, und stellt eine Sicherheitsfunktion dar. Diese
sollte nicht umgangen oder außer Betrieb gesetzt werden.

Stromunterbrechung • Um das Gerät auf sichere Weise vom Netz zu trennen, sollten Sie alle Netzkabel

aus der Rückseite des Gerätes, aus der externen Stomversorgung (falls dies möglich ist) oder aus der
Wandsteckdose ziehen.

Schutz des Netzkabels • Netzkabel sollten stets so verlegt werden, daß sie nicht im Weg liegen und niemand

darauf treten kann oder Objekte darauf- oder unmittelbar dagegengestellt werden können.

Wartung • Alle Wartungsmaßnahmen sollten nur von qualifi ziertem Servicepersonal durchgeführt werden.

Die internen Komponenten des Gerätes sind wartungsfrei. Zur Vermeidung eines elektrischen Schocks
versuchen Sie in keinem Fall, dieses Gerät selbst öffnen, da beim Entfernen der Abdeckungen die Gefahr
eines elektrischen Schlags und/oder andere Gefahren bestehen.

Schlitze und Öffnungen • Wenn das Gerät Schlitze oder Löcher im Gehäuse aufweist, dienen diese zur

Vermeidung einer Überhitzung der empfi ndlichen Teile im Inneren. Diese Öffnungen dürfen niemals von
anderen Objekten blockiert werden.

Litium-Batterie • Explosionsgefahr, falls die Batterie nicht richtig ersetzt wird. Ersetzen Sie verbrauchte

Batterien nur durch den gleichen oder einen vergleichbaren Batterietyp, der auch vom Hersteller
empfohlen wird. Entsorgen Sie verbrauchte Batterien bitte gemäß den Herstelleranweisungen.

Instrucciones de seguridad • Español

Este símbolo se utiliza para advertir al usuario sobre instrucciones importantes
de operación y mantenimiento (o cambio de partes) que se desean destacar en el
contenido de la documentación suministrada con los equipos.

Este símbolo se utiliza para advertir al usuario sobre la presencia de elementos con
voltaje peligroso sin protección aislante, que puedan encontrarse dentro de la caja
o alojamiento del producto, y que puedan representar riesgo de electrocución.

Precaucion

Leer las instrucciones • Leer y analizar todas las instrucciones de operación y seguridad, antes de usar el

equipo.

Conservar las instrucciones • Conservar las instrucciones de seguridad para futura consulta.
Obedecer las advertencias • Todas las advertencias e instrucciones marcadas en el equipo o en la

documentación del usuario, deben ser obedecidas.

Evitar el uso de accesorios • No usar herramientas o accesorios que no sean especifi camente recomendados

por el fabricante, ya que podrian implicar riesgos.

安全须知 • 中文

这个符号提 示用户该设备用户手册中有重要的操 作和维护说明。

这个符号警告用户该设备机壳内有暴露的危险电压，有触电危险。

注意

阅读说明书 • 用户使用该设备前必须阅读并理解所有安全和使用说明。
保存说明书 • 用户应保存安全 说明书以备将来使用。
遵守警告 • 用户应遵守产品和用户指南上的所有安 全和操作说明。
避免追加 • 不要使用该产品厂商没有推荐的工具或追加设备，以避免危险。

Advertencia

Alimentación eléctrica • Este equipo debe conectarse únicamente a la fuente/tipo de alimentación eléctrica

indicada en el mismo. La alimentación eléctrica de este equipo debe provenir de un sistema de distribución
general con conductor neutro a tierra. La tercera pata (puesta a tierra) es una medida de seguridad, no
puentearia ni eliminaria.

Desconexión de alimentación eléctrica • Para desconectar con seguridad la acometida de alimentación eléctrica

al equipo, desenchufar todos los cables de alimentación en el panel trasero del equipo, o desenchufar el
módulo de alimentación (si fuera independiente), o desenchufar el cable del receptáculo de la pared.

Protección del cables de alimentación • Los cables de alimentación eléctrica se deben instalar en lugares donde

no sean pisados ni apretados por objetos que se puedan apoyar sobre ellos.

Reparaciones/mantenimiento • Solicitar siempre los servicios técnicos de personal califi cado. En el interior no

hay partes a las que el usuario deba acceder. Para evitar riesgo de electrocución, no intentar personalmente
la reparación/mantenimiento de este equipo, ya que al abrir o extraer las tapas puede quedar expuesto a
voltajes peligrosos u otros riesgos.

Ranuras y aberturas • Si el equipo posee ranuras o orifi cios en su caja/alojamiento, es para evitar el

sobrecalientamiento de componentes internos sensibles. Estas aberturas nunca se deben obstruir con otros
objetos.

Batería de litio • Existe riesgo de explosión si esta batería se coloca en la posición incorrecta. Cambiar esta

batería únicamente con el mismo tipo (o su equivalente) recomendado por el fabricante. Desachar las
baterías usadas siguiendo las instrucciones del fabricante.

警告

电源 • 该设备只能使用产品上标明的电源。 设备必须使用有地线的供电系统供电。 第三条线

（地线）是安全 设施，不能不用或跳过 。

拔掉电源 • 为安全地从设备拔掉电源，请拔掉所有设备后或桌面电源的电源线，或任何接到市

电系统的电源线。

电源线保护 • 妥善布线， 避免被踩踏，或重物挤压。
维护 • 所有维修必须由认证的维修人员进行。 设备内部没有用户可以更换的零件。为避免出

现触电危险不要自己试图打开设备盖子维修该设备。

通风孔 • 有些设备机壳上有通风槽或孔，它们是用来防止机内敏感元件过热。 不要用任何东

西挡住通风 孔。

锂电池 • 不正确的更换电池会有爆炸的危险。必须使用与厂家推荐的相同或相近型号的电池。

按照生产厂的建议处理废弃电池。

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. [phone]
Fax [phone]

[e-mail]

Quick Start — MGP 464

Installation

Step 1

Install the four rubber feet on the bottom of the
MGP 464, or mount the unit using the supplied
rack mounting brackets.

2
2

4
/
2
3

2

­S

R

G
R

UT

TP
OU
I

S

D
I

T

V

7

U

1

P

Y

N
I

O

D DV

E

N

ID

U

D

V

I

O

4

V

1

Y

GR

L

K

A

C

U

ID

T

BA

V

R

8

D

VI

I

I

Y

1

-

D

V

V

R

1

1

Y

C

ID
V

5

D
I

Y

1

-

V

R

8

Y

C

ID
V

9

Y

D

1

-

I

B

V

2

ID

Y

1

-

V

R

5

Y

C

ID
V

6

Y

D

1

-

I

B

V

9

Y

-
R
C

D
I

V

3

1

-Y

4

ID

B

V

6

Y

-
R

R

C

D
I
V

Y

0

1

-Y

R-

B

V

H/H

S

ID

T

V

U

7

Y

-

P

B

N
I

3

O

G/Y

E
D
I

VID

V

R

V

B

Y

-

G

/HV

R

R

H
HV
H/

B/C
B-Y

2

D

­I

G/Y

V

D

-

ID

4

V

T

R

V

U

P

Y

-

N
I

R

H/HV

/HV
H

B/C
B-Y

1

D

­I

G/Y

V

D

-
3

VID

R

T

V

U
P

-Y

N

HV

I

R

H/
/HV
H

B/C
B-Y

D

­I

G/Y

V

D

-
2

VID

T

V

U

P

V

N
I

H/H

B/C
B-Y

z

-D

H

I
V

0

6

D

/
0

1-

5

T
U

0

P

4

N

2

I

­0
0
1

X
A
M

A
.5

MBD 249

2-U Rack Mount Bracket
(Use four lower holes.)

Rack mounting the MGP 464

Step 2

Turn off power to the input and output devices,
and remove the power cords from them.

Step 3

Attach the input devices to the MGP 464. The
inputs can accept the following signal types:

Inputs 1, 2, 3, 4 — RGB, component video,

S-video, or composite video (fully
confi gurable)

DVI inputs 1 – 4 — DVI (MGP 464DI only)

INPUT 1-DVI-D

N

Analog is not available on this DVI-I

connector.

Virtual inputs 5 – 19 — Component video,

S-video, or composite video (confi gurable

®

via Windows

-based control software, SIS™

commands, or Web pages only). In each

N
A
L

R

T
U

P
T
U

O

Y

-

B

/
B

,
Y

-

Y

-
B

R
,
Y

/
B

/Y
G

/
R
Y

-
R

V

/
H
V
H

column, you can connect inputs as follows:
Three composite video inputs

•
One S-video input and one composite video

•
input

N

The S-video must always be connected to

the top two BNCs (Y on top, C second).
If desired, a composite video source can be
connected to the bottom BNC.

One interlaced component video source

•
(connects to all three BNCs in the column).

S-video

Composite

5

6

7

VID

VID

B-Y

VID

R-Y

Y

C

and

Composite

5

6

7

VID

VID
B-Y

VID

R-Y

Y

C

Component

5

6

7

VID

VID

B-Y

VID

R-Y

Y

C

PRELIMINARY

RGBHV

Video

R/R-Y

G/Y

H/HV

VID

V

B/C

B-Y

R/R-Y

G/Y

VID

B/C
B-Y

Connecting to inputs 1 – 4

RGBS or
RGBcvS

Video

R/R-Y

G/Y

H/HV

VID

B/C

V

B-Y

S-Video Composite

Video

R/R-Y

H/HV

V

H/HV

G/Y

VID

B/C
B-Y

RGsB or

Component

R/R-Y

G/Y

VID

B/C
B-Y

V

Video

H/HV

V

Virtual input connection examples

DVI Background input — DVI for live

background video only

N

Analog is not available on this DVI-I

connector.

Step 4

Attach an output device to the RGBHV/YUV
BNC connectors (shown on the next page)
and/or to the DVI-I output connector (shown
below).

DVI-D OUTPUT

N

Analog is not available on this DVI-I

connector.

MGP 464 • Quick Start

QS-1

Quick Start — MGP 464, cont’d

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. [phone]
Fax [phone]

[e-mail]

PRELIMINARY

RGBHV RGBS

R

/R-Y

H
/HV

R

/R-Y

H
/HV

G

/Y

V

G

/Y

V

B

/B-Y

B

/B-Y

R

/R-Y

H

/HV

R

/R-Y

H
/HV

G

/Y

V

G

/Y

V

RGsB HD YUV Component Video

BNC output connectors

Step 5

Plug the MGP 464, input devices, and output
devices into a grounded AC source, and power
on the input and output devices. The following
diagram shows an example of an MGP 464DI
application.

Remote User and
Administration Control

Extron
MGP 464DI

Four Window
Multi-Graphic Processor

Camera

DVD

.

M

D

I

V
L

E

B
E

H

G

7

E

A

5

L
L

N

O

A

C

EAST

E

A

T

N

A

A

T

H

ST.

S

E
I
M
B

.

L

V

V

A

D

N

.

L
O
C
N
I

L

.

.

V

D

A

R

S
O

S

T
I

A

R

L

n

R

G

o

E

r
t

C

U

x
E

O
D

5

.
T
S
S
I
W
E
L

im
he
a

m
n
A
iu
d
ta
S

.
D
R

LL

.

A

.

T

B

T

S

S

d

T

an

R

yl

S

e

E

E

isn

T

D

W

S
A
H

.
V

A
A
LL
E

T
A
K

PC PC PC PC

Control System

TCP/IP

Network

N
A
L

R

T
U

P

2
2
4

UT

/
2

3

O

2

-

Y

S

-

R

/

B

B

,
Y

-

Y

-
B

Y, R

B/

Y
/

G

G

R

/
R
Y

-
R

V

/
H
V
H

T
U
P
T
U

O
I
V
D

S

D
I

V

7

UT

1

P

Y

N
O I

D
N

D
I

U

DE

V

I

O

4

R

V

1

Y

G
K

AL

C

U

A

D
I

T

B

V

I

8

D

V

IR

I

Y

1

-

D

V

V

R

1
1

Y

C
D
I
V

5

D
I

Y

1

-

V

R

8

Y

C

D

I

V

9

Y

D

1

-

I

B

V

2

D
I

Y

1

-

V

R

Y

C

D
I
V

6

Y

D

1

-

I

B

V

9

Y

-
R
C

D
I
V

3

Y

D

1

-

45

I

B

V

6

Y

-

R

R

C

D
I
V

Y

0

-
Y

1

-

R

B

V
/H
H

D
I

TS

V

U

7

Y

-

P

B

IN

3

Y

O

G/
ID

IDE

V

V

R

V

B

Y

-

G

HV

R

R

H/
V
H/H

B/C

-Y
B

2

D

Y

­I

G/

V

D

-

ID

4

V

T

R

V

U
P

Y

-

N
I

/HV

R

H

V
/H
H

/C
B

-Y
B

1

D

-

Y

I

G/

V

D

-

ID

3

V

R

T

V

U
P

V

Y

-

N
I

/H

R

H
HV
/
H

/C
B
Y
B-

D

-

/Y

I

G

V

D

-

D

2

VI

T

V

U
P

V

N
I

/H
H

/C
B

-Y
B

z

D

­I

H

V

60

D

-

0/

1

5

T

0

PU

4

N

2

I

­0
0
1

X

A
M
A
5
.

.

M

D

I

V
L

E

B

E

H

G

7
5

E

A

L
L

N

O

A

C

E

E

A

A

T

ST

N

A

A

T

H

ST

S

E

.

I
M
B

.

L

V

V

A

D

N

.

L
O
C
N
I
L

.

.

V

D

A

R

S
O

S

T
I

A

R

L

n

R

o

G

E

tr

C

U

x
E

O
D

5

.
T
S

S
I
W
E
L

m
ei
h

m
na
u
A
di
ta
S

.

D
R
LL

.

A

.

T

B

T

S

S

T

nd
la

R

S

ey

E

n

E

is

T

D

W

S
A
H

.

V

A

A
LL
E
AT
K

Projector

Getting Started

After you have installed and connected the

B

/B-Y

MGP 464, follow these steps to confi gure and
adjust the unit to get it ready for use.

Extron

MGP 464 V1.00

2 sec.

Multi-Graphic

Processor

MENU

Auto


MENU

Input

Configuration

MENU

Output

Configuration

MENU

Window

Configuration

MENU

Background

Capture

MENU

2 sec.

B

/B-Y

Preview
Monitor

Power

on

20 sec.

20 sec.

20 sec.

20 sec.

20 sec.

Default

Cycle

MGP 464DI connection diagram

Step 6

Use the LCD menu screens and Adjust knobs to
confi gure the MGP 464 and adjust the picture
controls (see the following section, Confi guring
the MGP 464 and Adjusting the Picture Controls, in
the next section). See chapter 2 for installation
instructions, chapter 3 for front panel operation
information, chapter 4 for control via the RS­232/422 interface, and chapter 5 for Ethernet
control.

QS-2

MGP 464 • Quick Start

MENU

Comm. / IP

Configuration

MENU

Advanced

Configuration

MENU

Exit Menu

Press Next

NEXT

Main menu

20 sec.

20 sec.

20 sec.

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. [phone]
Fax [phone]

[e-mail]

Confi guring the MGP 464

Step 1

Use the Input Confi guration menu to confi gure
inputs 1 through 4.

N

The virtual inputs (5 through 19) can

be confi gured only via the Windows­based control software, SIS commands,
or the Web pages. For information on
confi guring those inputs, see chapter 4,
Software Confi guration and Control,
and chapter 5, Ethernet Confi guration
and Control.

Step 2

Use the Output Confi guration menu to confi gure
the output signal type and the output rate for the
desired resolution.

Step 3

From the Advanced Confi guration menu, Test
Pattern submenu, select the Alternating Pixels
(Alt. Pixels) test pattern. Adjust your display’s
active pixels, total pixels, and pixel phase settings
for optimal picture quality.

Step 4

From the Advanced Confi guration menu, change
the test pattern to Crop, and adjust your display’s
positioning until all four sides of the crop pattern
are visible.

Adjusting the picture controls

Step 5

Use the Window Confi guration menu to select a
window border color for each window. This will
aid in window sizing and positioning.

Step 6

Select input 1 for windows 1, 2, 3, and 4.

Step 7

Adjust windows 1, 2, 3, and 4 to full screen.

N

a. Press one of the Window Select buttons to

If your MGP is set to factory defaults,

you can select default window preset #1,
31, 61, 91, or 121 to set the windows to
full screen size. See Recalling a window
preset in chapter 3 for instructions on
selecting one of these presets.

select the window to adjust.

b. Press the Window/Image Position button

once, and turn the Adjust knobs until both
the H and V values = 0000.

c. Press the Window/Image Size button once,

and turn the Adjust knobs to the right until
they stop. The window size setting displays
the same resolution as the output.

d. Repeat steps a through c for the remaining

windows.

N

When all the windows are at full size, you

will need to mute the other three windows
while adjusting the fi rst.

Step 8

For each input, size and position the image
within all four windows.

a. Press one of the Window Select buttons.
b. Press one of the 19 input buttons.
c. Press the Window/Image Size or the

Window/Image Position button twice.
The LCD window displays the number of
the input whose image you are sizing or
positioning.

d. Rotate the Adjust knobs until the H and

V values represent the image dimensions
or position coordinates you want for the
selected input.

e. Repeat steps c and d as needed to refi ne the

size and position adjustments for the selected
input.

f. Repeat steps a through e for the remaining

windows for the same input.

g. Repeat steps a through f for each remaining

input.

Auto Image

Auto Image provides a quick way to size an
input to fi t the current window size. To auto-size
an image, follow these steps:

a. Press the button for the input that you want

to auto-size.

b. Press the Menu button to select the Auto

Image menu.

c. Press the Next button to display the Auto

Image selection screen.

d. Turn either Adjust knob to select window 1,

2, 3, or 4.

e. Press the Next button again to implement

your selection.

PRELIMINARY

MGP 464 • Quick Start

QS-3

PRELIMINARY

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. [phone]
Fax [phone]

[e-mail]

Quick Start — MGP 464, cont’d

Step 9

Use the Input Confi guration menu to make
any desired advanced adjustments, including
Horizontal and Vertical Start, Pixel Phase, Total
Pixels, Active Pixels, and Active Lines. See
chapter 3, Operation, for information on these
adjustments.

Step 10

When fi nished adjusting the desired picture
controls, save your confi guration as a window
preset:

a. Press the Preset Recall/Save button and hold

it for at least 2 seconds.

b. Use either Adjust knob to select the preset

number/name to which you want to save
this confi guration.

c. Press the Enter button.

Step 11

You can now size and position windows for each
of your applications and save each one with any
one of the remaining 127 window preset names
for easy recall of window settings.

You can also save presets using the MGP 464 Web
pages (see chapter 5) or the MGP 464 Windows
based control software (see Using the Windows
based Control Software in chapter 4 for instructions
on accessing the software and its Help fi le).

®

-

®

-

QS-4

MGP 464 • Quick Start

Table of Contents

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. [phone]
Fax [phone]

[e-mail]

Chapter One • Introduction ...................................................................................................... 1-1

About This Manual .................................................................................................................... 1-2

About the MGP 464 Multi-Graphic Processor ........................................................... 1-2

Features ............................................................................................................................................ 1-2

Application Diagrams .............................................................................................................. 1-3

Chapter Two • Installation .......................................................................................................... 2-1

Installation Overview .............................................................................................................. 2-2

Mounting the MGP 464 ......................................................................................................... 2-2

Tabletop use ............................................................................................................................... 2-2

Rack mounting .......................................................................................................................... 2-2

Installing or Replacing Button Labels ........................................................................... 2-4

Rear Panel Features .................................................................................................................. 2-4

Chapter Three • Operation ........................................................................................................ 3-1

Front Panel Features ............................................................................................................3-2

Power-up and Default Cycle ................................................................................................ 3-4

Window Select Buttons .......................................................................................................... 3-5

Input Selection ............................................................................................................................. 3-5

Muting an input ...................................................................................................................... 3-5

Menus, Confi guration, and Adjustments ....................................................................3-5

Menu system overview ............................................................................................................. 3-5

Using the menus .................................................................................................................. 3-6

Auto Image menu ..................................................................................................................... 3-8

Input Confi guration menu ......................................................................................................3-9

Input confi guration submenu adjustments ..................................................................... 3-10

Output Confi guration menu ................................................................................................. 3-11

Resolution and Refresh Rate submenu ............................................................................ 3-12

Output Type submenu ....................................................................................................... 3-12

Sync Polarity submenu ...................................................................................................... 3-13

Window Confi guration menu ............................................................................................... 3-13

Window Priority submenu ................................................................................................ 3-13

Window Border submenus ................................................................................................ 3-14

Window Effect submenu ................................................................................................... 3-14

Available effects ..........................................................................................................3-14

Effect Duration submenu .................................................................................................. 3-15

Background Capture menu ................................................................................................... 3-16

Memory space for background fi les ................................................................................. 3-16

Saving a background to memory ..................................................................................... 3-16

Recalling a background from memory ............................................................................. 3-17

Communication/IP Confi guration menu ..............................................................................3-17

Editing the RS-232/422 port and IP settings ..................................................................... 3-18

PRELIMINARY

MGP 464 • Table of Contents

i

Table of Contents, cont’d

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. [phone]
Fax [phone]

[e-mail]

Advanced Confi guration menu ............................................................................................3-19

Background Color submenu ............................................................................................. 3-19

Blue Mode submenu ......................................................................................................... 3-19

Test Pattern submenu ........................................................................................................ 3-20

Internal Temperature screen ............................................................................................. 3-21

Factory Default submenu .................................................................................................. 3-21

Adding and Confi guring Window Text ...............................................................................3-21

Picture Controls ......................................................................................................................... 3-21

Adjusting the picture controls .............................................................................................. 3-22

Memory Presets ........................................................................................................................ 3-23

Window presets ....................................................................................................................... 3-23

Saving a window preset .................................................................................................... 3-23

Recalling a window preset ................................................................................................ 3-24

Default presets .................................................................................................................. 3-24

Input presets ............................................................................................................................ 3-25

Additional Features ................................................................................................................ 3-26

Freeze mode ............................................................................................................................ 3-26

Locking the Front Panel (Executive Mode) ......................................................................... 3-26

Resetting the unit ................................................................................................................... 3-26

PRELIMINARY

Chapter Four • Software Confi guration and Control ........................................... 4-1

Setting Up RS-232/422 Communication ........................................................................ 4-2

Connector pin assignments ..................................................................................................... 4-2

Communication software ........................................................................................................ 4-3

Using Simple Instruction Set (SIS) Commands ........................................................ 4-3

Host-to-MGP communications ................................................................................................ 4-3

MGP-initiated messages ........................................................................................................... 4-3

Error responses .......................................................................................................................... 4-4

Telnet and Web communications ...........................................................................................4-4

Symbol defi nitions .................................................................................................................... 4-6

Using the Windows®-based Control Software ........................................................4-31

Installing the software ........................................................................................................... 4-31

Starting the control program ................................................................................................ 4-33

Chapter Five • Ethernet Confi guration and Control ............................................. 5-1

Accessing the Web Pages ...................................................................................................... 5-2

Viewing System Status ........................................................................................................... 5-3

Using the Confi guration Page ............................................................................................ 5-4

System Settings screen ............................................................................................................. 5-4

Scaler I/O Settings screen ......................................................................................................... 5-5

Confi guring the inputs ........................................................................................................ 5-5

Naming inputs ................................................................................................................ 5-5

Selecting the video signal type ..................................................................................... 5-6

Confi guring the output ....................................................................................................... 5-6

Enabling/disabling blue mode ...................................................................................... 5-7

ii

MGP 464 • Table of Contents

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. [phone]
Fax [phone]

[e-mail]

Window Settings screen ........................................................................................................... 5-7

Setting window priority ...................................................................................................... 5-9

Passwords screen ....................................................................................................................... 5-9

Assigning a password .......................................................................................................... 5-9

Clearing a password .......................................................................................................... 5-10

Email Alerts screen .................................................................................................................. 5-10

Setting up e-mail alerts ..................................................................................................... 5-11

Setting up SMTP authorization ........................................................................................ 5-11

Firmware Upgrade screen ...................................................................................................... 5-12

Determining the current fi rmware version ...................................................................... 5-12

Downloading the fi rmware .............................................................................................. 5-12

Updating the fi rmware on the MGP 464 ........................................................................ 5-13

Using the File Management Page .................................................................................. 5-14

Uploading fi les ........................................................................................................................ 5-14

Adding a directory .................................................................................................................. 5-14

Other fi le management activities ......................................................................................... 5-15

Using the Control Page ......................................................................................................... 5-16

Picture Controls screen ........................................................................................................... 5-16

Window Selection .............................................................................................................. 5-16

Input sections ..................................................................................................................... 5-17

Window Controls ............................................................................................................... 5-17

Image Controls ................................................................................................................... 5-18

Presets screen ........................................................................................................................... 5-19

Window Presets ................................................................................................................. 5-20

Default presets ............................................................................................................. 5-20

Naming a window preset ............................................................................................ 5-21

Saving (creating) a window preset ............................................................................. 5-21

Recalling a window preset .......................................................................................... 5-21

Selecting a window preset transition effect .............................................................. 5-21

Input Presets ...................................................................................................................... 5-22

Saving (creating) an input preset ............................................................................... 5-22

Recalling an input preset ............................................................................................ 5-22

PRELIMINARY

Using the Background Page ............................................................................................... 5-22

Selecting a background color ................................................................................................ 5-22

Displaying a background image ........................................................................................... 5-22

Using a DVI input ............................................................................................................... 5-23

Using a bitmap image ....................................................................................................... 5-23

Uploading an image .................................................................................................... 5-23

Selecting a background image ................................................................................... 5-23

Chapter Six • Special Applications ...................................................................................... 6-1

Application 1: Connecting the MGP 464 to a Matrix Switcher ...................... 6-2

Setting up the MGP to work with the switcher .................................................................. 6-3

Additional setup procedures with third party control software ....................................... 6-4

Application 2: Connecting Multiple MGP 464s in Succession
(Daisy-chaining)

Setting up MGPs for daisy-chaining ....................................................................................... 6-6

..........................................................................................................................6-4

MGP 464 • Table of Contents

iii

Table of Contents, cont’d

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. [phone]
Fax [phone]

[e-mail]

Appendix A • Specifi cations, Part Numbers, and Accessories ..................... A-1

Specifi cations .............................................................................................................................. A-2

Part Numbers and Accessories .......................................................................................... A-4

Included parts ........................................................................................................................... A-4

Optional accessories ................................................................................................................ A-4

Appendix B • Firmware Update Guide ..............................................................................B-1

Determining the Firmware Version ................................................................................ B-2

Using the LCD display at power-on ........................................................................................ B-2

Using a Web browser ...............................................................................................................B-2

Using the Windows-based confi guration software .............................................................B-4

Updating the Firmware ..........................................................................................................B-4

Downloading the fi rmware ................................................................................................B-4

Updating the fi rmware on the MGP 464 ..........................................................................B-5

Updating using the Web pages ....................................................................................B-5

Updating using the Windows-based control software ...............................................B-6

PRELIMINARY

All trademarks mentioned in this manual are the properties of their respective owners.

68-1235-01 Rev A

03 06

iv

MGP 464 • Table of Contents

MGP 464 Multi-Graphic Processor

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. [phone]
Fax [phone]

[e-mail]

Chapter One

1

Introduction

About This Manual

About the MGP 464 Multi-Graphic Processor

Features

Application Diagrams

PRELIMINARY

PRELIMINARY

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. [phone]
Fax [phone]

[e-mail]

Introduction

About This Manual

This manual discusses how to install, confi gure, and operate the Extron MGP 464
multi-graphic processor.

Throughout this manual, the terms “MGP,” “multi-graphic processor,” and
“processor” are used interchangeably to refer to the same product.

About the MGP 464 Multi-Graphic Processor

The MGP 464 is a four-window RGB and video signal processor that can display up
to four video sources on a single screen in picture-in-picture or picture-by-picture
format. The MGP accepts RGB, HDTV, component, S-video, and composite video
signals on four fully-confi gurable inputs and 15 virtual inputs; and has one scaled
output. The processor provides switching among inputs and has picture controls
and presets.

The MGP 464 DI is an MGP 464 with a DVI input card installed, providing four DVI
input connectors. Both versions can be controlled remotely via the RS-232/RS-422
interface using Special Instruction Set (SIS
control software, or via an Ethernet LAN using the MGP 464’s embedded Web
pages.

Features

Four windows — Up to four windows can be shown on a single display

Inputs — The MGP 464 has four fully confi gurable video inputs, which accept RGB,

DVI background input — A DVI input is provided on both models as a means to

Virtual inputs — 15 virtual inputs can be confi gured through software to accept

Output — The MGP 464 has one scaled output, available on a set of fi ve BNC

Picture controls — Picture controls allow you to adjust the size, position,

Window and input presets — Window presets save sizing, positioning, and

Window transition effects — Six types of window transition effects (22 different

Freeze control — Freeze control freezes (locks) a window to the current image.
3:2 pulldown detection for NTSC video and 2:2 fi lm detection for PAL — These

When fi lm is converted to NTSC video, the fi lm frame rate has to be matched

™

) commands or the Windows®-based

simultaneously, allowing up to four video and computer sources to be viewed
at once.

HDTV, component, S-video, and composite video signals. The MGP 464 DI
has four DVI inputs in addition.

display live video from a DVI source as a background.

standard defi nition component video, S-video, and composite video.

connectors for RGB and a DVI-I connector for DVI.

brightness, contrast, color, tint, detail, and zoom for each window.

priority information. Input presets save input signal type information and
picture control settings.

effects altogether) seamlessly mute and unmute (close and open) the four
windows.

advanced fi lm mode processing features help maximize image detail and
sharpness for video sources that originated from fi lm.

to the video frame rate in a process called 3:2 pulldown. Jaggies and other
image artifacts can result if conventional deinterlacing techniques are used on
fi lm-source video.

1-2

MGP 464 • Introduction

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. [phone]
Fax [phone]

[e-mail]

The MGP 464’s advanced fi lm mode processing recognizes signals that

originated from fi lm. The MGP then applies video processing algorithms
that optimize the conversion of video made in the 3:2 pulldown process. This
results in richly detailed images with sharply defi ned lines.

A similar process, 2:2 fi lm detection, is used for PAL fi lm-source video.
Background image capture, save, and recall — Background Capture enables you

to capture and save the image currently on the output screen. You can then
recall the captured image and display it as a background later.

Auto Image

Remote operation — The MGP 464 can be operated remotely via the RS-232/422

Rack mounting — The 2U high and full rack wide metal enclosure can be rack

Front panel security lockout (executive mode) — Locks the front panel controls to

RGB and video scaling — All sources are scaled to a single output rate.

™

— Auto Image automatically sizes, centers, and optimizes the image

to the scaled output rate, fi lling the window.

interface using the Windows-based control software or SIS commands, or via
the Ethernet interface using the embedded Web pages.

mounted using the included rack/through-desk mounting brackets.

prevent accidental changes to the unit’s settings.

Application Diagrams

The following application diagrams show examples of how devices may be
connected to the MGP 464 and the MGP 464 DI.

Camera

DVD

Extron
MGP 464DI

Four Window
Multi-Graphic Processor

ANAHEIM

A
N

.
V
A

LN

CO
IN
L

5

.

D

R
L
L

.

A

T

B

S
T

and

S

neyl

E

Dis

W

.
AV
A

L

L
E
T

A
K

Remote User and
Administration Control

Control System

PRELIMINARY

TCP/IP

Network

N

LA

R

T
U
P

2

T

42

U

O

32/

Y

S-2

-

R

B

/

B

,
Y

-

Y

-

B

R

,
Y
/
B

Y
/

G

G

R

/

R

Y

-

R

V

/

H

V
H

T
TPU
U

VI O

D

S

D
I

T

V

7

U

1

P

Y

N
I
O

D

E

D
I
V

ID

OUN

4

V

R

1

Y

L

KG

A

C

U

A

D
I

T

B

V

R

D

VI

I

I

Y

18

-

D

V

V

R

11

Y

C
ID
V

D
I

Y

15

-

V

R

8

Y

C

D

I

V

Y

D

19

-

I

B

V
D
I

Y

12

-

V

R
Y

C

D
I
V
Y

D

16

-

I

B

V

9

Y

-
R
C

D

I

V

Y
D

13

-

45

I

B
V

6

Y

-
R

R

C

D
I
V

Y

-
Y

10

-

R

B

/HV

H

S

D
I

T

V

U

7

Y

-

P

B

N

I

3

Y

O

G/

E
D

I

VID

V

R

V

B

V

Y

-

G

R

R

H/H
/HV
H

/C
B
B-Y

2

Y

I-D

G/

DV

VID

T 4-

R

V

U

P

V

Y

-

IN

R

H/H

HV
H/

B/C
Y
B-

1

Y
G/

VI-D
D

VID

R

T 3-

V

U

Y

-

INP

R

H/HV

H/HV

B/C
B-Y

-D
I

G/Y

DV

ID
V

T 2-

V

PU
IN

H/HV

B/C

-Y
B

z
H
0

6

DVI-D

/
0

5

T 1-

U

0
4
2

INP

-

0
0
1

X
A
M
A

5
.

.
D

IM

V
L

E

B
E

H

G

7

E

5

A

L
L

N

O

A

C

EAS

E

A

T

N

A

T

A

T

S

H

S

E

T
.

I
M
B

.

L

V

V

A

D

N

.

L
O
C

N
I
L

.

.

V

D

A

R

S
O

S

T
I

A

R

L

n

R

o

G

E

r
t

C

U

x
E

O
D

5

.
T
S
S
I
W
E
L

m

i
e
h
a

m
n
u
A
i
d
a
t
S

.
D

R
L
L

.

A

.

T

B

T

S

S

d

T

n
a
l

R

y

S

e

E

n

E

s
i

T

D

W

S
A
H

.

AV
A
L
L

E
T
A
K

Preview
Monitor

Projector

.
D
V
L
B
E
G

7

E

5

L
L
O
C

EAST ST.

E
T
A

A

T

H

S

E
I
M
B
L
V

D
.

.

.

V

D

A

R

S
O

S

T
I

A

R

L

R

G

E
C

U

Extron

O
D

.
T
S
S
I
W
E
L

m

Anahei

ium

Stad

.
T
S
R
E
T
S

A
H

Connection diagram for MGP 464 DI

PC PC PC PC

MGP 464 • Introduction

1-3

Introduction, cont’d

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. [phone]
Fax [phone]

[e-mail]

Camera

DVD

Extron
MGP 464

Four Window
Multi-Graphic Processor

Video Camera

DVD

Control System

TCP/IP

Network

.

M

D

I

V
L

E

B
E

H

G

7

E

5

A

L
L

N

O

A

C

EAST

E

A

T

N

A

A

T

ST

H

S

E

.

I
M
B

.

L

V

V

A

D

N

.

L
O
C

N
I
L

.

.

V

D

A

R

S

S

TO
I

A

R

L

n

R

o

G

E

r
t

C

U

x
E

O
D

5

.
T
S
S
I

N

LA

R

T
U
P

2

T

2

U

2/4

O

3
2

-

Y

-

RS

/

B

B

,
Y

Y

-

-
B

R
,
Y
/
B

/Y

G

G

R

/
R

Y

-

R

V

/
H

V
H

PUT
T
U

DVI O

S

D
I

T

V

U

17

P

Y

N

I
O
E

ID

D

V

I
V

14

Y

L

A

CKGROUND

U

D
I

T

BA

V

D

IR

I

Y

18

-

V

DVI

V

R

11

Y

C
ID
V

D
I

Y

15

-

V

R

8

Y

C

D

I

V

Y

D

19

-

I

B

V

ID

Y

12

-

V

R

Y

C

D
I
V

6

Y

D

1

-

I

B

V

9

Y

-
R
C

D
I
V
Y

13

-

4 5

ID

B

V

6

Y

-
R

R

C

D
I
V

Y

-
Y

10

-

R

B

V

H/H

S

D
I

T

V

U

7

-Y

P

B

N

I

3

O

G/Y

E

ID

VID

V

R

V

B

V

Y

-

G

R

H/H

R

V
/H
H

B/C
B-Y

2

-D

I

G/Y

V

-D

VID

T 4

R

V

U

Y

-

NP

HV

I

R

H/

V

H/H

B/C
B-Y

1

-D

I

G/Y

DV

VID

R

T 3-

V

U

Y

-
R

H/HV
HV
H/

/C
B
B-Y

INP

G/Y

VI-D
D

VID

2-
T

V

U

V

INP

H/H

/C
B

-Y
B

z

-D

H
0
6

DVI

/
0

5

T 1-

0
4
2

INPU

-

0
0
1

X
A
M
A

5
.

8

7

6

S
T

U

5

P
T

U

O

4

T
E

S

3

E

LINK

R

2

ACT

LAN

1

R

G

2
1

R

1

1

0

G

1

9

B

8

S
T

U

P

7

N
I

H

6

5

4

3

2

1

12

V

Y
S
V

NC
Y
S

H

1
1

0
1

9

8

67

S

T

5

U

P
N
I

4

3

8

B

7

6

H

5

4

V

S

T

U

3

P

T

U

O

2

1

NC

2
1

Extron

W
E
L

m
i

e
h
a

m
n

u
A

i
d
a
t
S

.
D

R
L
L

.

A

.

T

B

T

S

S

d
n

T

a
l

R

y

S

e

E

n

E

s
i

T

D

W

S
A
H

.
V

A
A
L
L
E

T
A
K

Preview
Monitor

Projector

CrossPoint 450 Plus Series

Matrix Switcher

Extron
RGB 109xi

Interface

PRELIMINARY

VCR

PCLaptop

PC

Connection diagram for MGP 464 (with CrossPoint 450 Matrix Switcher)

1-4

MGP 464 • Introduction

MGP 464 Multi-Graphic Processor

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. [phone]
Fax [phone]

[e-mail]

Chapter Two

2

Installation

Installation Overview

Mounting the MGP 464

Installing or Replacing Button Labels

Rear Panel Features

PRELIMINARY

Installation

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. [phone]
Fax [phone]

[e-mail]

Installation Overview

The MGP 464 processor can be connected to as many as 19 input devices
simultaneously, and two output devices. Follow the steps below, and see the
example in the illustration.

1

Disconnect power to the MGP, and turn off all other devices that will be

connected.

2

If desired, mount the MGP. See Mounting the MGP 464, in the next section.

3

Attach video input devices to the MGP, using the four sets of BNC connectors

for the fully confi gurable inputs and/or the 15 BNC connectors for the virtual
inputs.

For the MGP 464 DI, connect up to four DVI sources to the DVI-I connectors if
desired.

4

Connect one or two output devices to the RGBHV/YUV BNC output

connectors and/or to the DVI-I output connector.

5

If the MGP 464 will be connected to a computer or to a host controller for

remote operation, connect the host’s RS-232 cable to the processor’s 9-pin
RS-232/422 D-sub connector; or use the optional 9-pin female to 2.5 mm TRS
cable to connect the host to the MGP’s front panel RS-232/422 confi guration
port.

6

Connect an active LAN Ethernet cable to the RJ-45 port on the MGP rear panel

to establish a link to the network.

7

Power up the input and output devices, then connect power to the MGP.

PRELIMINARY

Mounting the MGP 464

Tabletop use

Four self-adhesive rubber feet are included with the MGP 464. For tabletop use,
attach one foot to each corner of the bottom side of the unit and place the unit in the
desired location.

Rack mounting

For optional rack mounting, do not install the rubber feet. To mount the MGP 464
in a rack, follow these steps:

1. Attach the included rack/through-desk mounting brackets (part #70-077-03)

to the unit using eight machine screws supplied with the mounting kit. (See
the illustration on the next page.)

2-2

MGP 464 • Installation

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. [phone]
Fax [phone]

[e-mail]

LAN

R

T

U

TP

U

2/422

O

-Y

RS-23

/

B

B

-Y,

Y

-
B

R

,
Y
/

B

Y

/

G

G

R

/

R

Y

-

R

V

/
H
V

S

ID

T

V

17

PU

Y

N

I

O

D
I
V

IDE

V

14

Y

L
A
U

ID

T

V

R
I

ID

Y

18

-

DVI BACKGROUND DVI OUTPUT

V

V

R

11

Y

C

D
I
V

ID

15

-Y

V

R

8

Y

C

D
I
V
Y

19

-

ID

B

V

D

I

Y

12

-

V

R

5

Y

C

ID
V

Y

16

-

ID

B

V

9

-Y
R
C

D
I
V

Y

D

13

-

4

I

B

V

6

Y

-
R

R

C

ID
V

-Y

10

-Y

R

B

H/HV

S

T

U

P

IN

3

O

E

VID

R

B

G

R

R

2

G/Y
VID

R

-Y

R

H/HV

B/C
B-Y

1

G/Y
VID

R

V

-Y

INPUT

R

H/HV

H/HV

B/C
B-Y

G/Y

2-DVI-D

VID

V

INPUT

H/HV

B/C
B-Y

z

H

0
0/6
5

0
4
2

INPUT 1-DVI-D

-

0
0
1

X

A
M
.5A

ID
V

7

Y

-
B

G/Y

D

VI

V

V

Y

-
H/H

H/HV

B/C
B-Y

I-D

4-DV

V

INPUT

H/HV

I-D

3-DV

MBD 249
2-U Rack Mount Bracket
(Use four lower holes.)

Attaching the mounting brackets

2. Insert the unit into the rack and align the holes in the mounting brackets with

the holes in the rack. Use four machine screws to attach the brackets to the
rack.

H

MBD 249

2-U Rack Mount
Bracket (Use four
lower holes.)

Rack mounting the MGP 464

PRELIMINARY

MGP 464 • Installation

2-3

Installation, cont’d

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. [phone]
Fax [phone]

[e-mail]

Installing or Replacing Button Labels

You may wish to customize your MGP’s button labels. The labels can be changed
at any time, but it is convenient to change them before you install the MGP. You
can use a Brother P-Touch label maker or a similar device to create custom labels.
Cut the labels so that they are ½ inch square.

Follow these steps to change the translucent button labels:

1. Use a small, fl at bladed screwdriver such as an

Extron Tweeker to gently pry a button out from the
front panel.

2. Locate the notch in the corner of one side of the

button’s clear outer layer.

3. Separate the translucent white backing plate from

the clear button cap by inserting the blade of the
small screwdriver into the corner notch and gently
twisting the blade. Save the backing plate.

4. Remove the text/label insert from the transparent

button cap.

5. Insert a button label into the clear button cap, align

the white backing plate with the cap, and fi rmly
snap it into place.

6. Gently, but fi rmly, press the reassembled button into place in the panel.

7. Repeat steps 1 through 6 as needed to relabel other buttons.

Use notch to
remove button.

TEXT

Separate two
piece button here.

PRELIMINARY

Rear Panel Features

The diagram below shows the rear panel of the MGP 464 DI, which has four DVI-I
connectors (

DVI capability, and therefore does not have these connectors. In all other respects
the MGP 464 and the MGP 464 DI rear panels are identical.

100-240

.5A MAX

11

50/60 Hz

1

R

R-Y

G/Y
VID

B/C
B-Y

INPUT 1-DVI-D

2

R

R-Y

G/Y

H/HV

V

H/HV

H/HV

VID

B/C

H/HV

B-Y

INPUT 2-DVI-D INPUT 3-DVI-D INPUT 4-DVI-D

10

MGP 464 rear panel

1

Inputs 1, 2, 3, and 4 — Plug RGB, high or standard defi nition component

in the illustration below). The standard MGP 464 does not have

j

4

1

3

R

R-Y

G/Y
VID

V

B/C
B-Y

45

R

R-Y

G/Y

H/HV

VID

V

B/C

H/HV

B-Y

6

H/HV

7

V

H/HV

2

VIRTUAL VIDEO INPUTSRGB VIDEO INPUTS

8

11

14

VID

VID

Y

Y

9

12

VID

VID

B-Y

B-Y

C

C

10

13

VID

VID

R-Y

R-Y

17

VID

VID

Y

15

VID
B-Y

C

16

VID
R-Y

VID

Y

Y

18

VID

VID

B-Y

B-Y

DVI-D BACKGROUND

C

C

19

VID
R-Y

INPUT

VID
R-Y

9

3

RS-232/422

DVI-D OUTPUT

8

5

LAN

R

RGB/Y, R-Y, B-Y OUTPUT

R/

G/Y

R-Y

V

H/
HV

7

B/

B-Y

video, S-video, or composite video sources into these fully confi gurable BNC
connectors, as shown in the following diagram. These connectors can be
confi gured for the desired signal types via the front panel, the Windows-based
control software, SIS commands, or the MGP 464 Web pages.

6

2-4

MGP 464 • Installation

1

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. [phone]
Fax [phone]

[e-mail]

111 1 1

RGBHV

Video

R/R-Y

R/R-Y

RGBS or
RGBcvS

Video

RGsB or

Component

R/R-Y

Video

S-Video Composite

R/R-Y

Video

R/R-Y

G/Y

VID

B/C

B-Y

H/HV

V

G/Y

VID

B/C

B-Y

H/HV

V

G/Y

VID

B/C
B-Y

H/HV

V

G/Y

VID

B/C
B-Y

H/HV

V

Connecting to RGB/HD/VIDEO inputs 1 through 4

2

Virtual inputs (inputs 5 through 19) — Connect standard defi nition

component video, S-video, and/or composite video sources to these BNC
connectors. The 15 connectors for the virtual inputs are arranged in columns
of three BNCs.

In each column, you can connect inputs as follows:

Three composite video inputs

•
One S-video input and one composite video input

•

The S-video must always be connected to the top two BNCs (Y on

top, C second). If desired, a composite video source can be connected
to the bottom BNC.

•

One interlaced component video source (connects to all three BNCs
in the column).

S-video

and

Composite

5

6

7

VID

VID

B-Y

VID

R-Y

Y

C

Composite

5

6

7

VID

VID
B-Y

VID

R-Y

Y

C

Component

5

6

7

VID

VID

B-Y

VID

R-Y

Y

C

G/Y

VID

B/C
B-Y

H/HV

V

PRELIMINARY

Virtual input connector confi guration examples

You can confi gure these virtual inputs for the desired signal types using the

3

Windows-based control software, SIS commands, or the Web pages. They
cannot be confi gured via the front panel.

RS-232/422 connector — Plug a computer or other

5

RS-232 or RS-422 host device into this connector. Wire the
connector as shown on the next page. See chapter 4 for
more information on controlling the MGP 464 remotely.

96

MGP 464 • Installation

2-5

Installation, cont’d

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. [phone]
Fax [phone]

[e-mail]

Pin RS-232 function Description

1 – No connection

2 Tx Transmit data
3 Rx Receive data
4 – No connection
5 Gnd Signal ground
6 – No connection

7 – No connection

8 – No connection
9 – No connection

4

LAN connector — Plug an RJ-45 network cable into

this connector to connect the unit to a network (via a
switch, hub, or router) or to a single computer.

Activity LED — This yellow LED blinks to indicate

network activity.

Link LED — This green LED lights to indicate a good

network connection.

Use a straight-through cable to connect to a network, or

a crossover cable to connect directly to a computer.

• For 10BaseT (10 Mbps) networks, use a Cat 3 or better cable.

• For 100BaseT (max. 155 Mbps) networks, use a Cat 5 cable.

Pin RS-422 function Description

1 – No connection

2 Tx- Transmit ground
3 Rx- Receive ground
4 – No connection
5 Gnd Signal ground
6 – No connection

7 Rx+ Receive data

8 Tx+ Transmit data
9 – No connection

LAN

RJ-45
Por t

Link
LED

Activity
LED

PRELIMINARY

Clip Down

12345678

1

2345678

3&6

1&2

4&5

RJ-45
Connector

Twisted
Pairs

7&8

Straight-through Cable

(for connection to a switch, hub, or router)

End 1 End 2

Pin Wire Color Pin Wire Color

1 white-orange 1 white-orange
2 orange 2 orange
3 white-green 3 white-green
4 blue 4 blue
5 white-blue 5 white-blue
6 green 6 green
7 white-brown 7 white-brown
8 brown 8 brown

Crossover Cable

(for direct connection to a PC)

End 1 End 2

Pin Wire Color Pin Wire Color

1 white-orange 1 white-green
2 orange 2 green
3 white-green 3 white-orange
4 blue 4 blue
5 white-blue 5 white-blue
6 green 6 orange
7 white-brown 7 white-brown
8 brown 8 brown

You will also need to confi gure the LAN port before using it. This is done

by using SIS commands. See chapter 4, Software Confi guration and Control,
Command/response table for SIS commands, in chapter 4, for details.

2-6

MGP 464 • Installation

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. [phone]
Fax [phone]

[e-mail]

LAN port defaults:

MGP’s IP address: 192.168.254.254

•

Gateway IP address: 0.0.0.0

•

Subnet mask: 255.255.0.0

•

DHCP: off

•

5

Reset button — Pressing this recessed button causes various IP functions and

Ethernet connection settings to be reset to the factory defaults.

6

Reset LED — This green LED, located to the upper-right of the reset button,

blinks a varying number of times to indicate which reset mode has been
entered. See Resetting the unit, in chapter 3, for details.

7

BNC output connectors — Plug an output device into this 5 BNC connector,

as shown below.

RGBHV RGBS

R

/R-Y

H
/HV

R

/R-Y

H
/HV

G

/Y

V

G

/Y

V

RGsB HD YUV Component Video

B

/B-Y

B

/B-Y

R

/R-Y

H

/HV

R

/R-Y

H
/HV

G

/Y

V

G

/Y

V

B

/B-Y

B

/B-Y

Connecting to output BNC connectors

8

DVI output — Plug a DVI output device into this DVI-I

DVI-D OUTPUT

connector.

N
N

Analog RGB is not available on the DVI-I connector.

When two output devices are attached (one to each

DVI connector

output connector), they both display the same image.)

9

DVI background input — Connect a DVI input source to this DVI-I connector

in order to display the DVI video source live as a background on your output
screen. The four MGP windows are displayed in front of this DVI image.
When a DVI background is used, the MGP output is locked to the input rate
of the DVI background. This input is not scaled.

N

This input connector can be used only to receive the background image. The

input is not scaled or processed. To process DVI input signals, you must use the
MGP 464 DI model.

PRELIMINARY

10

11

DVI inputs 1, 2, 3, and 4 (MGP 464 DI only) — Connect up to four DVI input

sources to these DVI-D input connectors. These inputs are available only on
the MGP 464 DI model, which has the DVI card installed.

AC power connector — Plug the power cord provided with the MGP 464 into

this connector to connect the MGP to a 100–250 VAC, 50/60 Hz power source.

MGP 464 • Installation

2-7
