FOX USB Extender
Fiber Optic Extender for USB Peripherals
User Guide
Fiber Optic Extenders
68-2097-01 Rev. A
07 12
Safety Instructions • English
This symbol is intended to alert the user of important operating and maintenance (servicing) instructions in the literature provided with the equipment.
This symbol is intended to alert the user of the presence of uninsulated
dangerous voltage within the product’s enclosure that may present a risk of
electric shock.
Caution
Read Instructions • Read and understand all safety and operating instructions before using the equipment.
Retain Instructions • The safety instructions should be kept for future reference.
Follow Warnings • Follow all warnings and instructions marked on the equipment or in the user information.
Avoid Attachments • Do not use tools or attachments that are not recommended by the equipment
manufacturer because they may be hazardous.
Warning
Power sources • This equipment should be operated only from the power source indicated on the product. This
equipment is intended to be used with a main power system with a grounded (neutral) conductor. The third
(grounding) pin is a safety feature, do not attempt to bypass or disable it.
Power disconnection • To remove power from the equipment safely, remove all power cords from the rear of
the equipment, or the desktop power module (if detachable), or from the power source receptacle (wall plug).
Power cord protection • Power cords should be routed so that they are not likely to be stepped on or pinched
by items placed upon or against them.
Servicing • Refer all servicing to qualified service personnel. There are no user-serviceable parts inside. To prevent
the risk of shock, do not attempt to service this equipment yourself because opening or removing covers may
expose you to dangerous voltage or other hazards.
Slots and openings • If the equipment has slots or holes in the enclosure, these are provided to prevent
overheating of sensitive components inside. These openings must never be blocked by other objects.
Lithium battery • There is a danger of explosion if battery is incorrectly replaced. Replace it only with the
same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the
manufacturer’s instructions.
Consignes de Sécurité • Français
Ce symbole sert à avertir l’utilisateur que la documentation fournie avec le
matériel contient des instructions importantes concernant l’exploitation et la
maintenance (réparation).
Ce symbole sert à avertir l’utilisateur de la présence dans le boîtier
de l’appareil de tensions dangereuses non isolées posant des risques
d’électrocution.
Attention
Lire les instructions• Prendre connaissance de toutes les consignes de sécurité et d’exploitation avant
d’utiliser le matériel.
Conserver les instructions• Ranger les consignes de sécurité afin de pouvoir les consulter à l’avenir.
Respecter les avertissements • Observer tous les avertissements et consignes marqués sur le matériel ou
présentés dans la documentation utilisateur.
Eviter les pièces de xation • Ne pas utiliser de pièces de fixation ni d’outils non recommandés par le
fabricant du matériel car cela risquerait de poser certains dangers.
Sicherheitsanleitungen • Deutsch
Dieses Symbol soll dem Benutzer in der im Lieferumfang enthaltenen
Dokumentation besonders wichtige Hinweise zur Bedienung und Wartung
(Instandhaltung) geben.
Dieses Symbol soll den Benutzer darauf aufmerksam machen, daß im Inneren
des Gehäuses dieses Produktes gefährliche Spannungen, die nicht isoliert sind
und die einen elektrischen Schock verursachen können, herrschen.
Achtung
Lesen der Anleitungen • Bevor Sie das Gerät zum ersten Mal verwenden, sollten Sie alle Sicherheits-und
Bedienungsanleitungen genau durchlesen und verstehen.
Aufbewahren der Anleitungen • Die Hinweise zur elektrischen Sicherheit des Produktes sollten Sie
aufbewahren, damit Sie im Bedarfsfall darauf zurückgreifen können.
Befolgen der Warnhinweise • Befolgen Sie alle Warnhinweise und Anleitungen auf dem Gerät oder in der
Benutzerdokumentation.
Keine Zusatzgeräte • Verwenden Sie keine Werkzeuge oder Zusatzgeräte, die nicht ausdrücklich vom
Hersteller empfohlen wurden, da diese eine Gefahrenquelle darstellen können.
Instrucciones de seguridad • Español
Este símbolo se utiliza para advertir al usuario sobre instrucciones importantes de operación y mantenimiento (o cambio de partes) que se desean
destacar en el contenido de la documentación suministrada con los equipos.
Este símbolo se utiliza para advertir al usuario sobre la presencia de elementos con voltaje peligroso sin protección aislante, que puedan encontrarse
dentro de la caja o alojamiento del producto, y que puedan representar
riesgo de electrocución.
Precaucion
Leer las instrucciones • Leer y analizar todas las instrucciones de operación y seguridad, antes de usar el
equipo.
Conservar las instrucciones • Conservar las instrucciones de seguridad para futura consulta.
Obedecer las advertencias • Todas las advertencias e instrucciones marcadas en el equipo o en la
documentación del usuario, deben ser obedecidas.
Evitar el uso de accesorios • No usar herramientas o accesorios que no sean especificamente
recomendados por el fabricante, ya que podrian implicar riesgos.
Avertissement
Alimentations • Ne faire fonctionner ce matériel qu’avec la source d’alimentation indiquée sur l’appareil. Ce
matériel doit être utilisé avec une alimentation principale comportant un fil de terre (neutre). Le troisième
contact (de mise à la terre) constitue un dispositif de sécurité : n’essayez pas de la contourner ni de la
désactiver.
Déconnexion de l’alimentation• Pour mettre le matériel hors tension sans danger, déconnectez tous les
cordons d’alimentation de l’arrière de l’appareil ou du module d’alimentation de bureau (s’il est amovible) ou
encore de la prise secteur.
Protection du cordon d’alimentation • Acheminer les cordons d’alimentation de manière à ce que personne
ne risque de marcher dessus et à ce qu’ils ne soient pas écrasés ou pincés par des objets.
Réparation-maintenance • Faire exécuter toutes les interventions de réparation-maintenance par un
technicien qualifié. Aucun des éléments internes ne peut être réparé par l’utilisateur. Afin d’éviter tout danger
d’électrocution, l’utilisateur ne doit pas essayer de procéder lui-même à ces opérations car l’ouverture ou le
retrait des couvercles risquent de l’exposer à de hautes tensions et autres dangers.
Fentes et orices • Si le boîtier de l’appareil comporte des fentes ou des orifices, ceux-ci servent à empêcher les
composants internes sensibles de surchauffer. Ces ouvertures ne doivent jamais être bloquées par des objets.
Lithium Batterie • Il a danger d’explosion s’ll y a remplacment incorrect de la batterie. Remplacer uniquement
avec une batterie du meme type ou d’un ype equivalent recommande par le constructeur. Mettre au reut les
batteries usagees conformement aux instructions du fabricant.
Vorsicht
Stromquellen • Dieses Gerät sollte nur über die auf dem Produkt angegebene Stromquelle betrieben werden.
Dieses Gerät wurde für eine Verwendung mit einer Hauptstromleitung mit einem geerdeten (neutralen) Leiter
konzipiert. Der dritte Kontakt ist für einen Erdanschluß, und stellt eine Sicherheitsfunktion dar. Diese sollte nicht
umgangen oder außer Betrieb gesetzt werden.
Stromunterbrechung • Um das Gerät auf sichere Weise vom Netz zu trennen, sollten Sie alle Netzkabel aus der
Rückseite des Gerätes, aus der externen Stomversorgung (falls dies möglich ist) oder aus der Wandsteckdose
ziehen.
Schutz des Netzkabels • Netzkabel sollten stets so verlegt werden, daß sie nicht im Weg liegen und niemand
darauf treten kann oder Objekte darauf- oder unmittelbar dagegengestellt werden können.
Wartung • Alle Wartungsmaßnahmen sollten nur von qualiziertem Servicepersonal durchgeführt werden.
Die internen Komponenten des Gerätes sind wartungsfrei. Zur Vermeidung eines elektrischen Schocks
versuchen Sie in keinem Fall, dieses Gerät selbst öffnen, da beim Entfernen der Abdeckungen die Gefahr eines
elektrischen Schlags und/oder andere Gefahren bestehen.
Schlitze und Öffnungen • Wenn das Gerät Schlitze oder Löcher im Gehäuse aufweist, dienen diese zur
Vermeidung einer Überhitzung der empndlichen Teile im Inneren. Diese Öffnungen dürfen niemals von
anderen Objekten blockiert werden.
Litium-Batterie • Explosionsgefahr, falls die Batterie nicht richtig ersetzt wird. Ersetzen Sie verbrauchte Batterien
nur durch den gleichen oder einen vergleichbaren Batterietyp, der auch vom Hersteller empfohlen wird.
Entsorgen Sie verbrauchte Batterien bitte gemäß den Herstelleranweisungen.
Advertencia
Alimentación eléctrica • Este equipo debe conectarse únicamente a la fuente/tipo de alimentación eléctrica
indicada en el mismo. La alimentación eléctrica de este equipo debe provenir de un sistema de distribución
general con conductor neutro a tierra. La tercera pata (puesta a tierra) es una medida de seguridad, no
puentearia ni eliminaria.
Desconexión de alimentación eléctrica • Para desconectar con seguridad la acometida de alimentación
eléctrica al equipo, desenchufar todos los cables de alimentación en el panel trasero del equipo, o desenchufar
el módulo de alimentación (si fuera independiente), o desenchufar el cable del receptáculo de la pared.
Protección del cables de alimentación • Los cables de alimentación eléctrica se deben instalar en lugares
donde no sean pisados ni apretados por objetos que se puedan apoyar sobre ellos.
Reparaciones/mantenimiento • Solicitar siempre los servicios técnicos de personal calicado. En el interior no
hay partes a las que el usuario deba acceder. Para evitar riesgo de electrocución, no intentar personalmente la
reparación/mantenimiento de este equipo, ya que al abrir o extraer las tapas puede quedar expuesto a voltajes
peligrosos u otros riesgos.
Ranuras y aberturas • Si el equipo posee ranuras o orificios en su caja/alojamiento, es para evitar el
sobrecalientamiento de componentes internos sensibles. Estas aberturas nunca se deben obstruir con otros
objetos.
Batería de litio • Existe riesgo de explosión si esta batería se coloca en la posición incorrecta. Cambiar esta
batería únicamente con el mismo tipo (o su equivalente) recomendado por el fabricante. Desachar las baterías
usadas siguiendo las instrucciones del fabricante.
安全须知 • 中文
这个符号提示用户该设备用户手册中有重要的操作和维护说明。
这个符号警告用户该设备机壳内有暴露的危险电压，有触电危险。
注意
阅读说明书 • 用户使用该设备前必须阅读并理解所有安全和使用说明。
保存说明书 • 用户应保存安全说明书以备将来使用。
遵守警告 • 用户应 遵守产品和用户指南上的所有安全和操作说明。
避免追加 • 不要使用该产品厂商没有推荐的工具或追加设备，以避免危险。
警告
电源 • 该设备只能使用产品上标明的电源。 设备必须使用有地线的供电系统 供电。 第三条线
（地线）是安全 设施，不能不用或跳过 。
拔掉电源 • 为安 全地从设备拔掉电源，请拔掉所有设备后或桌面电源的电源线，或任何接到市
电系统的电 源线。
电源线保护 • 妥善布线， 避免被踩 踏，或重物 挤压。
维护 • 所有维修必须由认证的维修人员进行。 设备内部没有用户可以更换的零件。为避免出现
触电危险不要自己试图打开设备盖子维修该设备。
通风孔 • 有些设备机 壳上有通风 槽或孔，它们是用来 防止机内敏感 元件过热。 不要用任何东
西挡住通风 孔。
锂电池 • 不正确的更 换电池会有爆炸的危险。必须使用与厂家推荐的相同或相近型号的电池。
按照生 产厂的建议处理废弃电池。
FCC Class A Notice
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC rules. The Class A limits provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is
likely to cause interference; the user must correct the interference at his own expense.
NOTE: This unit was tested with shielded I/O cables on the peripheral devices. Shielded
cables must be used to ensure compliance with FCC emissions limits.
For more information on safety guidelines, regulatory compliances,
EMI/EMF compatibility, accessibility, and related topics, see the “Extron Safety
and Regulatory Compliance Guide” on the Extron website.
Conventions Used in this Guide
Notifications the following are used:
WARNING: A warning indicates a situation that has the potential to result in death or
severe injury.
ATTENTION: Attention indicates a situation that may damage or destroy the product or
associated equipment.
NOTE: A note draws attention to important information.
Copyright
© 2012 Extron Electronics. All rights reserved.
Trademarks
All trademarks mentioned in this guide are the properties of their respective owners.
Contents
Introduction ............................................ 1
About this Guide ............................................. 1
About the FOX USB Extender ........................... 1
Features ........................................................... 3
Installation and Operation ..................... 4
Mounting Overview ......................................... 4
Connections .................................................... 5
System Startup and Operation ......................... 6
Indications ................................................... 6
Startup ........................................................ 7
Operation .................................................... 7
Troubleshooting ............................................... 8
Reference Information ........................... 9
Specifications ................................................... 9
Part Numbers ................................................. 11
FOX USB Extender Part Numbers ................ 11
Included Parts ............................................ 11
Cables ....................................................... 11
Mounting the FOX USB Extender ................... 12
Tabletop Use .............................................. 12
Mounting .................................................. 12
FOX USB Extender • Contents v
FOX USB Extender • Contents vi
Introduction
WARNING: The FOX USB Extender Transmitter and Receiver units output continuous
invisible light, which may be harmful to the eyes; use with caution.
• Do not look into the rear panel fiber optic cable connectors or into
• Plug the attached dust caps into the optical transceivers when the fiber
• About this Guide
• About the FOX USB Extender
• Features
About this Guide
This guide contains information to install, congure, and operate the Extron Electronics
FOX USB Extender.
the fiber optic cables themselves.
cable is unplugged.
About the FOX USB Extender
The FOX USB Extender (see gure 1, on the next page) is a USB transmitter and receiver
pair that extends the usable distance of USB 1.0, 1.1, and 2.0 standards with data transfer
rates up to 480 Mbps. The Extender is also compatible with the Extron FOX Matrix Switcher
models (see figure 2, on the next page).
The transmitter and receiver are categorized by the type of fiber optic cable, multimode or
singlemode, which define the effective range of transmission:
• Multimode — Long distance, up to 2 km (1.2 miles) (depending on the fiber cable)
• Singlemode — Very long distance, up to 30 km (18.75 miles)
NOTE: The multimode and singlemode units are physically and functionally
identical, with the exception of the effective range of transmission. In this
manual, any reference applies to either transmission mode model unless
otherwise specified.
A FOX USB Extender system consists of a transmitter (Tx) and a receiver (Rx). The transmitter
connects directly to a USB port on a PC or USB host. The receiver features a four port USB
hub to connect multiple peripheral devices.
The FOX USB Extender complies with the USB 2.0 standard, supporting USB 2.0 (480 Mbps
high speed), USB 1.1 (12 Mbps full speed), and USB 1.0 (1.5 Mbps low speed) for data
transmission throughout the system. It also supplies +5 VDC (up to 500 mA) of power on
each of the receiver USB peripheral ports.
The transmitter and receiver both feature a front panel USB host activity LED, power
indicator, and a ber cable Link LED for local or remote troubleshooting.
FOX USB Extender • Introduction 1
Extron
FOXBOX Tx DV I Plus
Extron
Fiber Optic Transmitter
PC
USB
DVI
Fiber
ALARM
RS-232
OVER FIBER
AUDIO
Tx Rx 1 2
DVI-D INPUT
FOXBOX Tx DVI Plus
POWER
12V
1.0A MAX
HOST
POWER
12V
0.8A MAX.
Extron
FOX USB Extender Tx
Fiber Optic Extender
for USB Peripherals
RxTx
LINK
OPTICAL
Fiber
LINK
Extron
Extron
FOXBOX Rx DVI Plus
FOXBOX Rx DVI Plus
Fiber Optic Receiver
Fiber Optic Receiver
ALARM
RS-232
OVER FIBER
AUDIO
Tx Rx 1 2
DVI-D OUTPUT
MODE
FOXBOX Rx DVI Plus
POWER
12V
1.0A MAX
Fiber
DVI
Flat Panel
Display
Extron
FOX USB Extender Rx
Fiber Optic Extender
for USB Peripherals
Rx
Tx
LINK
LINK
POWER
12V
1.0A MAX.
OPTICAL
Figure 1. Typical FOX USB Transmitter and Receiver Application
Extron
FOX 500 Tx
100-240V 0.3A
50/60 Hz
RGB INPUT
PC
RGB
H/HV
INPUT LOOP THRU
OR
V
RGB
Fiber Optic Transmitte r
AUDIO INPUTS
LR
PASS THRU
CONTROL
RS-232
Tx Rx NA
RS-232
Tx Rx 1 2
FOX 500 Tx
OPTICAL
12*
ALARM
LINK
OPTIONAL FOR
*
RETURN DATA
LINK
Extron
Extron
FOX USB Extender Tx
Fiber Optic Extender
for USB Peripherals
Extron
FOXBOX Tx DVI Plus
Fiber Optic Transmitte r
PC
POWER
0.8A MAX
CONFIG
FOXBOX Tx DVI Plus
DVI-D INPUT
FOXBOX Tx DVI Plus
RxTx
LINK
LINK
OPTICAL
Rx
Tx
LINK
LINK
OPTICAL
RS-232
AUDIO
ALARM
OVER FIBER
Tx Rx 1 2
ANAHEIM, CA
REMOTE
LAN
RS-232/RS-422
ACT LINK
REFERENCE
RESET
BI-LEVEL
TRI-LEVEL
SWITCH
1 - 8
9 - 16
17 - 24
25 - 32
OUT
OUT
OUT
OUT
100-240V 50/60Hz 1.2A MAX.
DISCONNECT BOTH POWER
CORDS BEFORE SERVICING
100-240V 50/60Hz 1.2A MAX.
HOST
12V
DVI
OVER
TEMP
AUDIO
POWER
12V
1.0A MAX
FOX Matrix 3200
Modular Fiber Optic
Matrix Switcher
OUT
OUT
OUT
IN
IN
A
B
OUT
IN
IN
A
B
OUT
IN
IN
A
B
OUT
IN
IN
A
B
REDUNDANT
PRIMARY
IN
C
OUT
IN
C
OUT
IN
C
OUT
IN
C
PRIMARY POWER SUPPLY
IN
D
OUT
IN
D
OUT
IN
D
OUT
IN
D
Keyboard
HUB
3
4
1
2
USB
FOXBOX SR HDMI
Fiber Optic Scaling
Receiver
POWER
12V
1.0 A MAX
OUT
OUT
IN
IN
E
F
OUT
OUT
IN
IN
E
F
OUT
OUT
IN
IN
E
F
OUT
OUT
IN
IN
E
F
REDUNDANT POWER SUPPLY
USB
Mouse
RxTx
LINK
LINK
OPTICAL
FOXBOX SR HDMI
OUT
OUT
IN
IN
H
G
OUT
OUT
IN
IN
H
G
OUT
OUT
IN
IN
H
G
OUT
OUT
IN
IN
H
G
POWER
12V
1.0 A MAX
HDMI INPUT
OUTPUTS
HDMI AUDIO
AUDIO
LR
ON
OFF
HDMI
POWER
12V
1.0A MAX
LINK
OPTICAL
Extron
FOX USB Extender Rx
Fiber Optic Extender
for USB Peripherals
RS-232
OVER FIBER
Tx Rx 1 2
RxTx
ALARM
LINK
LINK
OPTICAL
FOXBOX Tx HDMI
AUDIO INPUT
RS-232
REMOTE
ALARM
OVER FIBER
RS-232
Tx Rx 1 2
Tx Rx
RxTx
HUB
1
3
LINK
2
4
Extron
FOXBOX Tx HDMI
Fiber Optic Transmitte r
PC
Extron
FOX USB Extender Tx
Fiber Optic Extender
for USB Peripherals
POWER
0.8A MAX
HOST
12V
RxTx
LINK
LINK
OPTICAL
Extron
FOX USB Extender Tx
Fiber Optic Extender
for USB Peripherals
POWER
0.8A MAX
HOST
12V
RxTx
LINK
LINK
OPTICAL
Figure 2. Typical FOX USB Transmitter and Receiver Application with Matrix
Switcher
FOX USB Extender • Introduction 2
Features
The FOX USB Extenders are in 3 inches deep, quarter rack width, 1 inch high metal
enclosures. They can be set on a tabletop or mounted in a rack, behind a display, under or
through furniture, or to a projector pole.
• Transmits USB signals long distances over two fiber optic cables — Up to 30 km
(18.75 miles) on singlemode cables.
• One inch high, quarter rack width, metal enclosures — With low prole enclosures,
the transmitter and receiver can be discreetly installed in locations such as behind a
plasma or LCD flat-panel display.
• External 100 VAC to 240 VAC, 50-60 Hz, international power supply — Included
with each transmitter and receiver.
FOX USB Extender • Introduction 3
Installation and Operation
This sections details the installation of the FOX USB Extender, including:
• Mounting Overview
• Connections
• System Startup and Operation
• Troubleshooting
Mounting Overview
The 3 inches deep, 1 inch high, quarter rack width FOX USB Extender transmitter and
receiver can be placed on a tabletop, behind a display, mounted on a rack shelf, or mounted
under a desk or tabletop. The receiver can be mounted on a projector bracket.
Mounting details are included in “Mounting the FOX USB Extender” in the “Reference
Information” section on page 12. Mounting instructions are included with each optional
mounting kit.
ATTENTION: Installation and service must be performed by authorized personnel only.
FOX USB Extender • Installation and Operation 4
Connections
HOST
POWER
12V
0.3A MAX
LINK
LINK
OPTICAL
RxTx
HUB
1
2
3
4
POWER
12V
1.0A MAX
LINK
LINK
OPTICAL
RxTx
BYPASS
EMULATION
1 2
1 12 3 4 3 5
Rx
Tx
Figure 3. Rear Panel Connectors
Power input connector — Connect external power supplies to these 2-pole,
a
3.5 mm captive screw connectors. If the USB port of a connected PC or laptop is capable
of providing USB power, an external supply for the transmitter is not required.
ATTENTIONS: • Always use a power supply supplied by or specied by Extron for use
with the FOX USB Extender Series. Use of an unauthorized power
supply voids all regulatory compliance certification and may cause
damage to the supply and the FOX USB Extenders.
• Unless otherwise stated, the AC/DC adapters are not suitable for
use in air handling spaces or in wall cavities. The power supply is
to be located within the same vicinity as the Extron AV processing
equipment in an ordinary location, Pollution Degree 2, secured to
the equipment rack within the dedicated closet, podium or desk.
• The installation must always be in accordance with applicable
provisions of National Electrical Code ANSI/NFPA 70, article 75
and the Canadian Electrical Code part 1, section 16. The power
supply shall not be permanently fixed to building structure or similar
structure.
USB host connector — This USB Type A connector supports a computer host. Do
b
not connect a device at this time; see “Startup“ on page 7.
Fiber optic connectors and LEDs — Connect two fiber optic
cables between the LC connectors on the transmitter and receiver.
Connect each Tx port to the Rx port on the opposite unit (see the
drawing at right).
c
LINK
Transmitter
OPTICAL
LINK
WARNING: These units output continuous invisible light, which
may be harmful to the eyes; use with caution. For
additional safety, plug the attached dust caps into
the optical transceivers when the fiber cable is
unplugged.
Receiver
NOTE: Use the proper ber cable for your transmitter and
receiver pair. Typically, singlemode fiber has a yellow jacket
and multimode cable has an orange or aqua jacket.
LINK
Tx
OPTICAL
Rx
LINK
Tx Link and Rx Link LEDs — When lit, the link is active (light is present, either
transmitted or received).
FOX USB Extender • Installation and Operation 5
DIP Switch —
ReceiverTransmitter
d
Emulation (down) position — Enables the peripheral emulation, which is internal
to the transmitter. This emulation allows connected hosts, some of which require a
connected USB device, to boot up normally.
Bypass (up) position — Bypasses the internal peripheral emulation of the
transmitter.
NOTES: • The FOX USB Extender system supports up to four USB hubs connected
to the receiver when the DIP switch on the transmitter is in the Bypass
position. The system supports up to three hubs when the DIP switch is in
the Emulation position.
• DIP switch 2 has no function.
Hub connectors — These female USB Type A connectors support up to four USB
e
devices. Do not connect devices at this time; see “Startup“ on the next page.
The connections are USB 2.0 compatible, and can provide +5 VDC at up to 500 mA to
connected USB peripherals requiring power.
System Startup and Operation
Indications
LINK
ACTIVITY
HOST
HUB
1
3
2
4
FOX USB EXTENDER Rx
5
ACTIVITY
HOST
LINK
FOX USB EXTENDER Tx
43 43
Figure 4. Front Panel Indications
Power LED (transmitter) — Indicates that the transmitter is receiving power from
a
21
an external power supply.
Power LED (receiver) — Indicates that the receiver is receiving power from an
b
external power supply.
Link LED — Indicates that the unit is receiving light on its rear panel Rx connector.
c
NOTE: The receiver Link LED indicates light from the transmitter.
The transmitter Link LED indicates light from the receiver.
Host LED — Indicates that the Extender is communicating with the computer
d
connected to the rear panel Host port on the transmitter.
Hub LEDs — Indicate that the receiver is communicating with the USB peripheral
e
connected to the rear panel Hub port on the receiver.
FOX USB Extender • Installation and Operation 6
Startup
HOST
HOST
HUB
For proper operation, the transmitter, receiver, USB host, and peripherals must be connected
properly as shown in figure 5 and in the sequence described below.
Laptop
Transmitter Receiver
POWER
12V
0.3A MAX
2
HOST
USB
3
1 4
RxTx
LINK
OPTICAL
SM or MM Fiber Cable
BYPASS
LINK
1 2
EMULATION
POWER
12V
1.0A MAX
2
LINK
OPTICAL
Keyboard
RxTx
LINK
Figure 5. FOX USB Extender Connection Guide with Two External Supplies
1. Power down the transmitter, receiver, USB host computer (connected to the transmitter)
and all peripherals and devices that will be connected to the receiver.
2. Connect fiber cables between the transmitter and receiver (a on figure 5).
3. Connect external power supplies to the transmitter and receiver and apply power (b).
The Power LEDs and Link LEDs on both units light to indicate proper link cable
connection between the transmitter and receiver.
4. Connect a type A-B cable between the FOX USB Extender transmitter Host port
and the USB host (a computer or other USB host device) (c).
5. Apply power to the host computer and boot the computer.
After the computer starts, the transmitter Host LED lights, indicating
communication between the PC and transmitter hub controller.
USB
HUB
1
2
Four USB 2.0 compatible type A female
connectors provide +5 VDC at up to
500 mA to connected USB peripherals.
3
4
LINK
Shortly after, the receiver Host LED lights indicating communication
between the transmitter and receiver.
6. Connect USB peripherals, such as keyboards and mice, to the FOX USB Extender receiver
using USB 2.0 compatible cables (d).
As each peripheral is recognized by the PC, the appropriate FOX USB Extender
Hub LED on the front panel of the receiver lights.
1
2
3
4
Operation
No drivers are required for a host to function with the FOX USB Extenders. The transmitter is
detected by Windows and appropriate USB drivers are loaded. Certain USB peripherals, such
as gaming keyboards, USB interactive whiteboards, scanners, printers, and similar devices,
require specic drivers to be installed on the host computer. See the USB device installation
instructions or the peripheral manufacturer website to obtain drivers.
After the transmitter, the receiver, the USB host, and the peripherals are connected and
powered up, and the appropriate drivers are loaded for the peripherals, the system is
fully operational. If any problems are encountered, verify that the cables are routed and
connected properly and the latest drivers for each peripheral are installed.
FOX USB Extender • Installation and Operation 7
Troubleshooting
Transmitter Receiver
LED Lit Unlit Lit Unlit
The 12 VDC supply is connected
and operating properly or the
host is properly supplying
power.
Both the transmitter and
Link
receiver have power and the
fiber optic cables are connected
properly.
(The transmitter Link LED
indicates light from the
receiver.)
When the transmitter Host
Host
LED is on, the transmitter is
communicating with the host
computer.
N/A N/A Lights when the peripheral
Hub
USB signals are generally reliable but are susceptible to bad connections or cables that are
too long. To avoid the loss of data and communications, follow these guidelines:
• The transmitter host USB cable and receiver hub port USB cables should not exceed
10 feet (3 m).
• Avoid or limit the use of adapters.
• The FOX USB Extender works as described in point-to-point applications. Do not use
additional adapters, patch panels, or couplers with the host USB cables, hub USB cables,
or fiber optic cables. Additional links in the signal chain can result in the reduction of
signal integrity and overall cable length performance.
When properly connected and operating, both transmitter and receiver Power LEDs,
Link LEDs and Host LEDs are lit. The Hub LED for each connected peripheral recognized by
the host PC is also lit.
Front panel LEDs may also be useful for troubleshooting. The table on the next page outlines
operating details indicated by the LEDs.
Table 1. System Troubleshooting
The 12 VDC supply is not
connected or is defective.
If a transmitter supply is not
being used, the USB host is
either not on or not providing
power, or the USB cable is
disconnected.
If both Power LEDs are on,
the fiber optic cable is not
connected.
If a transmitter supply is not
being used, the USB host is
either not on or is not providing
power.
If the transmitter Host LED is on,
the USB cable is not connected.
The LED blinks if the transmitter
is not communicating with the
receiver.
The 12 VDC supply is
connected and operating
properly.
Both the transmitter and
receiver have power and the
fiber optic cables are connected
properly.
(The receiver Link LED indicates
light from the transmitter.)
Lights when communication
with the host computer is
established.
on the USB port has been
recognized by the host
computer.
The 12 VDC supply is not
connected or defective.
If both Power LEDs are on,
the fiber optic cables are not
connected or are improperly
wired.
If either Power LED is off, see
the Power LED troubleshooting
instructions above.
The host USB port is not
connected or the host is not
communicating.
The peripheral on the USB port
has not been recognized or is
improperly connected.
If your problems persist, call the Extron S3 Sales & Technical Support Hotline. See the contact
numbers on the last page of this guide for the Extron ofce nearest you
FOX USB Extender • Installation and Operation 8
Reference Information
This section provides the specifications, part numbers, and accessories, and mounting
instructions for the FOX USB Extender. Topics that are covered include:
• Specifications
• Part Numbers
• Mounting the FOX USB Extender
Specifications
USB
USB standards ................................ USB 2.0, USB 1.1, USB 1.0 compatible
USB data rates ................................ Low speed (1.5 Mbps), full speed (12 Mbps), high speed (480 Mbps)
Signal transmission distance ........... 30 km (18.64 miles) with singlemode (SM) cables
300 m (985') with 62.5 µm OM1 multimode (MM) cables
1 km (3280') with 50 µm OM2 multimode (MM) cables
2 km (6561') with 50 µm OM3/OM4 2000 MHz bandwidth laser optimized
multimode cables
NOTE: Operating distance is approximate. These are typical maximum distances that may vary depending on
factors such as fiber type, fiber bandwidth, connector splicing, losses, modal or chromatic dispersion,
environmental factors, and kinks.
USB host — FOX USB Extender Tx
Number/signal type ........................ 1 USB (supports USB 2.0, 1.1, 1.0 speeds)
Connectors .................................... 1 female USB type B
Interconnection between transmitter and receiver
Connectors .................................... 2 LC connectors
Nominal peak wavelength .............. 850 nm for MM, 1310 nm for SM
Data rate ........................................ 600 Mbps
Transmission power ........................ -5 dBm, typical
Maximum receiver sensitivity
Singlemode ............................. -18 dBm, typical
Multimode ............................... -12 dBm, typical
Optical loss budget
Singlemode ............................. 13 dB, maximum
Multimode ............................... 7 dB, maximum
USB hub — FOX USB Extender Rx
Number/signal type ........................ (1) 4-port USB hub
Connectors .................................... 4 female USB type A
9FOX USB Extender • Reference Information
General
Power supply .................................. External
Input: 100-240 VAC, 50-60 Hz
Output: 12 VDC, 1 A, 12 watts
Power consumption
Device
FOX USB Extender Tx
FOX USB Extender Rx ......... 11.5 watts
Device and power supply
FOX USB Extender Tx ......... 3.4 watts
FOX USB Extender Rx ......... 13.9 watts
Temperature/humidity .................... Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Cooling .......................................... Convection, vents on top and sides
Thermal dissipation
Device
FOX USB Extender Tx ......... 8.8 BTU/hr
FOX USB Extender Rx ......... 10.1 BTU/hr
Device and power supply
FOX USB Extender Tx ......... 11.4 BTU/hr
FOX USB Extender Rx ......... 18.3 BTU/hr
Mounting
Rack mount ............................. Yes, with optional rack shelf or rack mounting brackets
Furniture or wall mount ........... Yes, with optional mounting kits
Enclosure type ................................ Metal
Enclosure dimensions ..................... 1.0" H x 4.3" W x 3.0" D
Product weight ............................... 0.25 lbs (0.1 kg)
Shipping weight ............................. 1 lb (<1 kg)
Vibration ........................................ ISTA 1A in carton (International Safe Transit Association)
Regulatory compliance
Safety ...................................... CE, c-UL, UL
EMI/EMC ................................. CE, C-tick, FCC Class A, ICES, VCCI Class A
Environmental .......................... Complies with the appropriate requirements of RoHS, WEEE
MTBF ............................................. 30,000 hours
Warranty ........................................ 3 years parts and labor
......... 2.6 watts
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
(2.5 cm H x 10.9 cm W x 7.6 cm D)
(Depth excludes connectors.)
NOTES: • All nominal levels are at ±10%.
• Specifications are subject to change without notice.
FOX USB Extender • Reference Information 10
Part Numbers
FOX USB Extender Part Numbers
Included Parts
Extender part numbers Part number
FOX USB Tx (SM) 60-1234-12
FOX USB Rx (SM) 60-1234-22
FOX USB Tx (MM) 60-1234-11
FOX USB Rx (MM) 60-1234-21
These items are included in each order for a FOX USB Extender transmitter or receiver:
Included part numbers Part number
12V, 1A external power supply
IEC power cords (qty. 1)
SFP Module (SM or MM, depending on the model)
10’ LC-LC duplex patch cable (SM or MM, depending on the model)
Rubber feet (qty. 4)
FOX USB Extender Setup Guide
Cables
Fiber cable assemblies
MHR Mini High Resolution Cable Part Number
4LC MM LC to LC Multimode Fiber Optic Cable Assemblies 26-652-nn
2LC OM4 MM P LC to LC Laser-Optimized Multimode Fiber Optic
Cable Assemblies — Plenum
2LC SM P LC to LC Bend-Insensitive Singlemode Fiber Optic Cable
Assemblies — Plenum
26-671-nn
26-670-nn
Bulk fiber cable and termination tools
RG6 Super High Resolution Cable Part Number
OM4 MM P/2K Plenum 2 km (6,562 foot) Spool 22-225-02
SM P/2K Plenum 2 km (6,562 foot) Spool 22-223-02
Fiber Optic Termination Kit Termination Kit 100-656-01
QLC MM/10 Fiber Optic connectors, multimode, qty. 10 101-018-01
QLC SM/10 Fiber Optic connectors, singlemode, qty. 10 101-017-01
FOX USB Extender • Reference Information 11
Mounting the FOX USB Extender
ATTENTION: Installation and service must be performed by authorized personnel only.
Any of the units can be placed on a tabletop or behind a display, mounted on a rack shelf,
or mounted under or through a desk or other furniture. The receiver can be mounted to a
projector bracket.
Tabletop Use
Affix the four included rubber feet to the bottom of the unit and place it in any convenient
location.
Mounting
If desired, mount the unit using any of the following optional kits:
• RSF 123 3.5-inch deep rack shelf kit (part number 60-190-20)
• RSB 123 3.5-inch deep rack shelf (part number 60-604-21)
• RSU 126 6-inch deep universal rack shelf kit (part number 60-190-10)
• RSB 126 6-inch deep basic rack shelf (part number 60-604-11)
• RSU 129 9.5-inch deep universal rack shelf kit (part number 60-190-01)
• RSB 129 9.5-inch deep basic rack shelf (part number 60-604-02)
• MBB 100 Back of the rack mounting kit (part number 70-367-01)
• MBU 125 under-desk mounting kit (part number 70-077-01)
• MBD 129 through-desk mounting kit (part number 70-077-02)
• PMK 300 projector mount kit (part number 70-374-01)
• PMK 350 low profile projector mount kit (part number 70-563-03)
Follow the instructions included with the kit.
UL Guidelines for Rack Mounting
The following Underwriters Laboratories (UL) guidelines pertain to the installation of a
FOX USB Extender unit into a rack.
1. Elevated operating ambient — If installed in a closed or multi-unit rack assembly,
the operating ambient temperature of the rack environment may be greater than room
ambient. Therefore, consider installing the equipment in an environment compatible
with the maximum ambient temperature specied by Extron (Tma = +122 °F [+50 °C]).
2. Reduced air flow — Installation of the equipment in a rack should be such that the
amount of air flow required for safe operation of the equipment is not compromised.
3. Mechanical loading — Mounting of the equipment in the rack should be such that a
hazardous condition is not achieved due to uneven mechanical loading.
4. Circuit overloading — Consideration should be given to the connection of the
equipment to the supply circuit and the effect that overloading of the circuits might
have on overcurrent protection and supply wiring. Appropriate consideration of
equipment nameplate ratings should be used when addressing this concern.
5. Reliable earthing (grounding) — Reliable earthing of rack-mounted equipment
should be maintained. Particular attention should be given to supply connections other
than direct connections to the branch circuit (such as the use of power strips).
FOX USB Extender • Reference Information 12
Extron Warranty
Extron Electronics warrants this product against defects in materials and workmanship for a period of three years
from the date of purchase. In the event of malfunction during the warranty period attributable directly to faulty
workmanship and/or materials, Extron Electronics will, at its option, repair or replace said products or components,
to whatever extent it shall deem necessary to restore said product to proper operating condition, provided that it is
returned within the warranty period, with proof of purchase and description of malfunction to:
USA, Canada, South America,
and Central America:
Extron Electronics
1001 East Ball Road
Anaheim, CA 92805
U.S.A.
Europe and Africa:
Extron Europe
Hanzeboulevard 10
3825 PH Amersfoort
The Netherlands
Japan:
Extron Electronics, Japan
Kyodo Building, 16 Ichibancho
Chiyoda-ku, Tokyo 102-0082
Japan
China:
Extron China
686 Ronghua Road
Songjiang District
Shanghai 201611
China
Asia:
Extron Asia
135 Joo Seng Road, #04-01
PM Industrial Bldg.
Singapore 368363
Middle East:
Extron Middle East
Dubai Airport Free Zone
F12, PO Box 293666
United Arab Emirates, Dubai
Singapore
This Limited Warranty does not apply if the fault has been caused by misuse, improper handling care, electrical or
mechanical abuse, abnormal operating conditions, or if modifications were made to the product that were not
authorized by Extron.
NOTE: If a product is defective, please call Extron and ask for an Application Engineer to receive an RA (Return
Authorization) number. This will begin the repair process.
USA: 714.491.1500 or 800.633.9876 Europe: 31.33.453.4040
Asia: 65.6383.4400 Japan: 81.3.3511.7655
Units must be returned insured, with shipping charges prepaid. If not insured, you assume the risk of loss or damage
during shipment. Returned units must include the serial number and a description of the problem, as well as the
name of the person to contact in case there are any questions.
Extron Electronics makes no further warranties either expressed or implied with respect to the product and its quality,
performance, merchantability, or fitness for any particular use. In no event will Extron Electronics be liable for direct,
indirect, or consequential damages resulting from any defect in this product even if Extron Electronics has been
advised of such damage.
Please note that laws vary from state to state and country to country, and that some provisions of this warranty may
not apply to you.
Extron Headquarters
+1.800.633.9876 (Inside USA/Canada Only)
Extron USA - West Extron USA - East
+1.714.491.1500 +1.919.850.1000
+1.714.491.1517 FAX +1.919.850.1001 FAX
Extron Europe
+800.3987.6673
(Inside Europe Only)
+31.33.453.4040
+31.33.453.4050 FAX
Extron Asia
+800.7339.8766
(Inside Asia Only)
+65.6383.4400
+65.6383.4664 FAX
© 2012 Extron Electronics All rights reserved. www.extron.com
Extron Japan
+81.3.3511.7655
+81.3.3511.7656 FAX
Extron China
+4000.398766
Inside China Only
+86.21.3760.1568
+86.21.3760.1566 FAX
Extron Middle East
+971.4.2991800
+971.4.2991880 FAX
Extron Korea
+82.2.3444.1571
+82.2.3444.1575 FAX
Extron India
1800.3070.3777
Inside India Only
+91.80.3055.3777
+91.80.3055.3737 FAX
Loading...
