EXTRON ELECTRONICS FOX Matrix 320x User Manual [ru]
Fiber Optic Matrix Switchers
FOX Matrix 320x, FOX Matrix 14400
Configurable Fiber Optic Digital Matrix Switchers
User Guide
68-1539-02 Rev. A
02 14
Safety Instructions
Safety Instructions • English
WARNING: This symbol, , when used on the product, is intended to
alert the user of the presence of uninsulated dangerous voltage within the
product’s enclosure that may present a risk of electric shock.
ATTENTION: This symbol, , when used on the product, is intended
to alert the user of important operating and maintenance (servicing)
instructions in the literature provided with the equipment.
For information on safety guidelines, regulatory compliances, EMI/EMF
compatibility, accessibility, and related topics, see the Extron Safety and
Regulatory Compliance Guide, part number 68-290-01, on the Extron website,
www.extron.com.
Instructions de sécurité • Français
AVERTISSEMENT : Ce pictogramme, , lorsqu’il est utilisé sur le
produit, signale à l’utilisateur la présence à l’intérieur du boîtier du produit
d’une tension électrique dangereuse susceptible de provoquer un choc
électrique.
ATTENTION : Ce pictogramme, , lorsqu’il est utilisé sur le produit,
signale à l’utilisateur des instructions d’utilisation ou de maintenance
importantes qui se trouvent dans la documentation fournie avec le
matériel.
Pour en savoir plus sur les règles de sécurité, la conformité à la réglementation,
la compatibilité EMI/EMF, l’accessibilité, et autres sujets connexes, lisez les
informations de sécurité et de conformité Extron, réf. 68-290-01, sur le site
Extron, www.extron.com.
Sicherheitsanweisungen • Deutsch
WARNUNG: Dieses Symbol auf dem Produkt soll den Benutzer darauf
aufmerksam machen, dass im Inneren des Gehäuses dieses Produktes
gefährliche Spannungen herrschen, die nicht isoliert sind und die einen
elektrischen Schlag verursachen können.
VORSICHT: Dieses Symbol auf dem Produkt soll dem Benutzer in der
im Lieferumfang enthaltenen Dokumentation besonders wichtige Hinweise
zur Bedienung und Wartung (Instandhaltung) geben.
Weitere Informationen über die Sicherheitsrichtlinien, Produkthandhabung,
EMI/EMF-Kompatibilität, Zugänglichkeit und verwandte Themen finden Sie in
den Extron-Richtlinien für Sicherheit und Handhabung (Artikelnummer
68-290-01) auf der Extron-Website, www.extron.com.
Инструкция по технике безопасности • Русский
ПРЕДУПРЕЖДЕНИЕ: Данный символ, , если указан
на продукте, предупреждает пользователя о наличии
неизолированного опасного напряжения внутри корпуса
продукта, которое может привести к поражению электрическим
током.
ВНИМАНИЕ: Данный символ, , если указан на продукте,
предупреждает пользователя о наличии важных инструкций
по эксплуатации и обслуживанию в руководстве,
прилагаемом к данному оборудованию.
Для получения информации о правилах техники безопасности,
соблюдении нормативных требований, электромагнитной
совместимости (ЭМП/ЭДС), возможности доступа и других
вопросах см. руководство по безопасности и соблюдению
нормативных требований Extron на сайте Extron: www.extron.com,
номер по каталогу - 68-290-01.
Chinese Simplified（简体中文）
警告： 产品上的这个标志意在警告用户该产品机壳内有暴露的危险 电压，
有触电危险。
注意： 产品上的这个标志意在提示用户设备随附的用户手册中有
重要的操作和维护(维修）说明。
关于我们产品的安全指南、遵循的规范、EMI/EMF 的兼容性、无障碍
使用的特性等相关内容，敬请访问 Extron 网站 www.extron.com，参见
Extron 安全规范指南，产品编号 68-290-01。
Chinese Traditional（ )
警告: 若產品上使用此符 號，是為了提醒使 用者，產品機殼內存在著
可能會導致觸電之風險的未絕緣危險電壓。
注意 若產品上使用此符號，是為了提醒使用者，設備隨附的用戶手冊中有重
要的操作和維護（維修）説明。
有關安全性指導方針、法規遵守、EMI/EMF 相容性、存取範圍和相關主題的詳細資
訊，請瀏覽 Extron 網站：www.extron.com，然後參閱《Extron 安全性與法規
遵守手冊》，準則編號 68-290-01。
Instrucciones de seguridad • Español
ADVERTENCIA: Este símbolo, , cuando se utiliza en el producto,
avisa al usuario de la presencia de voltaje peligroso sin aislar dentro del
producto, lo que puede representar un riesgo de descarga eléctrica.
ATENCIÓN: Este símbolo, , cuando se utiliza en el producto, avisa
al usuario de la presencia de importantes instrucciones de uso y
mantenimiento recogidas en la documentación proporcionada con el
equipo.
Para obtener información sobre directrices de seguridad, cumplimiento
de normativas, compatibilidad electromagnética, accesibilidad y temas
relacionados, consulte la Guía de cumplimiento de normativas y seguridad de
Extron, referencia 68-290-01, en el sitio Web de Extron,www.extron.com.
Japanese
警告: この記 号 が製品上に表示されている場合は、筐体内に絶縁されて
いない高電圧が流れ、感電の危険があることを示しています。
注意: この記号 が製品上に表示されている場合は、本機の取扱説明書
に 記載さ れて いる重 要な操 作 と保 守 ( 整 備)の 指 示につ いてユーザ ー の 注
意を喚起するものです。
安全上のご注意、法規厳守、EMI/EMF適合性、その他の関連項目に
つ い て は 、エ ク スト ロン の ウ ェ ブ サ イト www.extron.com よ り 『 Extron Safety
and Regulatory Compliance Guide』 ( P/N 68-290-01) をご覧ください。
Korean
경고: 이 기호 가 제품에 사용될 경우, 제품의 인클로저 내에 있는
접지되지 않은 위험한 전류로 인해 사용자가 감전될 위험이 있음을
경고합니다.
주의: 이 기호 가 제품에 사용될 경우, 장비와 함께 제공된 책자에 나와
있는 주요 운영 및 유지보수(정비) 지침을 경고합니다.
안전 가이드라인, 규제 준수, EMI/EMF 호환성, 접근성, 그리고 관련 항목에
대한 자세한 내용은 Extron 웹 사이트(www.extron.com)의 Extron 안전 및
규제 준수 안내서, 68-290-01 조항을 참조하십시오.
FCC Class A Notice
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part15 of the FCC rules. The ClassA limits provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause interference. This interference must be corrected at
the expense of the user.
ATTENTION: The Twisted Pair Extension technology works with unshielded twisted pair (UTP)
or shielded twisted pair (STP) cables; but, to ensure FCC Class A and CE compliance, STP
cables and STP Connectors are required.
For more information on safety guidelines, regulatory compliances, EMI/EMF compatibility,
accessibility, and related topics, see the “
Extron Safety and Regulatory Compliance
Guide” on the Extron website.
Copyright
© 2014 Extron Electronics. All rights reserved.
Trademarks
All trademarks mentioned in this guide are the properties of their respective owners.
The following registered trademarks, registered service marks, and trademarks are the property of RGBSystems, Inc.
or Extron Electronics:
(®)
Registered Trademarks
AVTrac, Cable Cubby, CrossPoint, eBUS, EDID Manager, EDID Minder, Extron, Flat Field, GlobalViewer, Hideaway, Inline, IPIntercom,
IPLink, Key Minder, LockIt, MediaLink, PlenumVault, PoleVault, PowerCage, PURE3, Quantum, SoundField, SpeedMount, SpeedSwitch,
System INTEGRATOR, TeamWork, TouchLink, V-Lock, VersaTools, VN-Matrix, VoiceLift, WallVault, WindoWall, XTP, and XTP Systems
Registered Service Mark
AAP, AFL (Accu-Rate Frame Lock), ADSP (Advanced Digital Sync Processing), AIS (Advanced Instruction Set), Auto-Image, CDRS (Class D
Ripple Suppression), DDSP (Digital Display Sync Processing), DMI (Dynamic Motion Interpolation), DriverConfigurator, DSPConfigurator, DSVP
(Digital Sync Validation Processing), FastBite, FOXBOX, IP Intercom HelpDesk, MAAP, MicroDigital, ProDSP, QS-FPC (QuickSwitch Front Panel
Controller), Scope-Trigger, SIS, Simple Instruction Set, Skew-Free, SpeedNav, Triple-Action Switching, XTRA, ZipCaddy, ZipClip
(SM)
: S3 Service Support Solutions
Trademarks
(™)
Conventions Used in this Guide
Notifications
The following notifications are used:
WARNING: A warning indicates a situation that has the potential to result in death or
severe injury.
ATTENTION: Attention indicates a situation that may damage or destroy the product or
associated equipment.
NOTE: A note draws attention to important information.
TIP: A tip provides a suggestion to make working with the application easier.
Software Commands
Commands are written in the fonts shown here:
^AR Merge Scene,,Op1 scene 1,1 ^B 51 ^W^C
[01] R 0004 00300 00400 00800 00600 [02] 35 [17] [03]
E X1# *X1** X2^* X2(* X2& CE}
NOTE: For commands and examples of computer or device responses mentioned
in this guide, the character “0” is used for the number zero and “O” represents the
capital letter “o.”
Computer responses and directory paths that do not have variables are written in the font
shown here:
Reply from 208.132.180.48: bytes=32 times=2ms TTL=32
C:\Program Files\Extron
Variables are written in slanted form as shown here:
ping xxx.xxx.xxx.xxx —t
SOH R Data STX Command ETB ETX
Selectable items, such as menu names, menu options, buttons, tabs, and field names are
written in the font shown here:
From the File menu, select New.
Click the OK button.
Specifications Availability
Product specification are available on the Extron website, www.extron.com.
Contents
FOX Matrix 320x and FOX Matrix 14400 • Contents
Introduction............................................................ 1
About this Guide ................................................. 1
About the FOX Matrix Switchers ......................... 1
Fiber Cable Transmission Modes .................... 3
Definitions ........................................................... 4
Features ............................................................. 4
Installation .............................................................. 7
Setup and Installation Checklist .......................... 7
Get Ready ...................................................... 7
Configure the Matrix Switcher ......................... 7
Perform Physical Installation ........................... 7
Install Software ............................................... 7
Rear Panel Boards, Cabling, and Features .......... 8
I/O Boards .................................................... 10
Remote Port ................................................. 13
Ethernet Connection ..................................... 14
Reset Button and LED .................................. 15
Power Supply Modules and Indicator
LEDs ........................................................... 15
Cooling Fan assemblies ................................ 15
Front Panel Features ......................................... 16
Reset Operations .............................................. 18
Performing Soft System Resets
(Resets 3, 4, and 5) ..................................... 19
Programming Guide ........................................... 20
Host Control Ports ............................................ 20
Serial Ports ................................................... 20
USB Port (FOX Matrix 320x) ......................... 21
Ethernet (LAN) Port ....................................... 21
Host-to-Switcher Instructions ........................... 22
Switcher-initiated Messages ............................. 22
Switcher Error Responses ................................ 23
Using the Command and Response Tables ...... 23
Command and Response Table for
SIS Commands ........................................... 24
Command and Response Table for
IP- and SNMP-Specific SIS Commands ...... 32
Special Characters ........................................... 35
Matrix Software ................................................... 36
About this Program .......................................... 36
Software Operation via Ethernet ................... 36
Software Operation via a Serial Port .............. 37
Software Operation via USB Port
(FOX Matrix 320x) ........................................ 37
Installing the Software ....................................... 38
Using the Matrix Switchers Control Program .... 39
Activating a USB Port for the First Time ........ 39
Starting the Program .................................... 40
IP Settings/Options Window ......................... 43
Updating Firmware ....................................... 47
Uploading HTML Files ................................... 51
Windows Buttons, Drop Boxes, and
Trash Can .................................................... 52
Windows menus ........................................... 52
Using Emulation Mode .................................. 56
Using the Help System ................................. 57
HTML Operation ................................................. 58
Opening the Embedded Web Pages ................. 59
Status Tab ........................................................ 60
System Status Page ..................................... 60
Input Link Page............................................. 61
Configuration Tab ............................................. 62
System Settings Page .................................. 62
Passwords Page........................................... 65
Email Settings Page ...................................... 66
SNMP Settings Page .................................... 68
Firmware Upgrade Page ............................... 70
File Management Tab ....................................... 71
File Management Page ................................. 71
Control Tab ....................................................... 72
Set and View Ties Page ................................ 72
v
Maintenance and Modifications ..................... 74
FOX Matrix 320x and FOX Matrix 14400 • Contents
Mounting the Switcher ...................................... 74
UL Guidelines ............................................... 74
Mounting Instructions ................................... 75
Battery and Power Precautions ........................ 75
Removing and Installing an I/O Board or
Blank Panel ..................................................... 75
Removing an I/O Board or Blank Panel ......... 77
Installing an I/O Board or Blank Panel ........... 77
Removing and Installing a Power Supply
Module ............................................................ 78
Removing a Power Supply Module ............... 78
Installing a Power Supply Module ................. 79
Removing and Installing a Fan Module .............. 80
Removing a Fan Module ............................... 80
Installing a Fan Module ................................. 81
Ethernet Connection ......................................... 82
Ethernet Link .................................................... 82
Ethernet Connection ..................................... 82
Default IP Address ........................................ 82
Pinging to Determine the Extron
IP Address ................................................... 83
Pinging to Determine the Web
IP Address ................................................... 83
Configuring the Switcher for Network Use
via the ARP Command ................................ 84
Connecting as a Telnet Client ........................ 85
Telnet Tips .................................................... 86
Subnetting — A Primer ..................................... 87
Gateways ..................................................... 87
Local and Remote Devices ........................... 87
IP Addresses and Octets .............................. 88
Subnet Masks and Octets ............................ 88
Determining Whether Devices Are on
the Same Subnet ......................................... 88
vi
Introduction
FOX Matrix 320x and FOX Matrix 14400 • Introduction
WARNING: Risk of serious physical injury — The FOX matrix switchers fiber optic
I/O boards output continuous invisible light that may be harmful to the eyes. Use with
caution.
• Do not look into the fiber optic cable connectors or into the fiber optic cables.
• Plug the attached dust caps into the optical transceivers when the fiber cable is
unplugged.
• About this Guide
• About the FOX Matrix Switchers
• Definitions
• Features
About this Guide
This guide contains installation, configuration, and operating information for the Extron
FOX Matrix 320x Switcher and FOX Matrix 14400 Switcher. These customizable matrix
switchers support up to 320 (FOX Matrix 320x) or 144 (FOX Matrix 14400) inputs and
outputs.
NOTE: In this guide, “FOX matrix switcher” and “switcher” refer to either switcher model
unless otherwise specified.
About the FOX Matrix Switchers
The FOX matrix switchers (see figure 1, on the next page, for a FOX Matrix 14400 example)
distribute optical and electronic input signals to one or more optical and electronic outputs.
The matrix switchers can route multiple input/output configurations simultaneously. The
switchers are configurable, assembled from individual input/output (I/O) boards, each of
which supports 16 inputs by 16 outputs in a combination of the following types of board:
• Singlemode and multimode fiber optic 16x16 I/O boards — These
non-pathologically-compliant fiber optic boards route signals that are compatible with all
Extron FOX 500, FOXBOX, and PowerCage FOX fiber optic product lines.
• FOX 3G I/O 1616 SM P board — This pathologically-compliant fiber optic board
passes digital signals in broadcasting applications, while addressing the compatibility
issues of passing pathological signals generated from 3G-SDI, HD-SDI, and SDI signals
over fiber optic systems.
• BNC 3G/HD/SD-SDI 16x16 I/O board — This pathologically-compliant board
supports and passes 3G-SDI, HD-SDI, and SD-SDI signals in their native (electronic)
format.
1
I/O Board
FO
Multimod
FO
X AV Transmitter
Multimod
FOX Matrix 14400
FO
Singlemode
r
FO
Multimod
FO
Multimod
Digital Cable
FOX Matrix 320x and FOX Matrix 14400 • Introduction
e
RS-232
RS-232
FOX 2G AV Tx
OVER FIBER
REMOTE
I
OPTICAL
Tx Rx Tx Rx
N
P
POWER
12V
U
0.8A MAX
T
S
100-240V 0.3A
50/60 Hz
100-240V 0.3A
50/60 Hz
RxTx
Y/VID
B-Y/C
AUDIO
ALARM
LR
R-Y
S-VID
12
X 500 DVI Transmitter
e
DDC
DVI - D INPUT
RESOL
X 500 RGB Transmitter
e
RGB INPUT
INPUT LOOP THRU
RGB
OR
V
H/HV
LOOP - THRU
RS-232
PASS THRU
TX Rx NA
AUDIO INPUTS
RS-232
LR
CONTROL
TX Rx 1 2
RS-232
PASS THRU
TX Rx NA
AUDIO INPUTS
RS-232
LR
CONTROL
RGB
TX Rx 1 2
XBOX VGA Transmitter
Rx
Tx
RGB
AUDIO
CONFIG
LINK
LINK
FOXBOX 4G Tx VGA
OPTICAL
X 3G HD-SDI Transceiver
e
FOX HDSDI
POWER
OPTICAL
12V
MODE
0.3A MAX
12
HD/SDI IN
BUFFERED OUTPUTS
RxTX
M
Multimode
I/O Board
S
Singlemode or
FOX 3G I/O 1616 SM P
ALARM
ALARM
FOX 500 DVI TX
OPTICAL
12*
LINK
OPTIONAL FOR
*
RETURN DATA
FOX 500 TX
OPTICAL
12*
LINK
OPTIONAL FOR
*
RETURN DATA
Modular Fiber Optic Matrix Switcher
Control
OUT
IN
OUT
OUT
IN
IN
OUT
OUT
IN
OUT
OUT
IN
OUT
OUT
IN
OUT
OUT
OUT
IN
IN
OUT
OUT
OUT
IN
OUT
OUT
IN
OUT
OUT
IN
OUT
OUT
IN
OUT
IN
OUT
OUT
LAN
ACT
LINK
REDUNDANT POWER SUPPLY
OUT
IN
OUT
IN
OUT
IN
OUT
IN
OUT
IN
OUT
IN
OUT
IN
OUT
OUT
IN
IN
OUT
OUT
IN
IN
OUT
IN
OUT
IN
OUT
IN
OUT
IN
OUT
IN
OUT
IN
OUT
IN
OUT
OUT
IN
OUT
IN
IN
RESET
IN
OUT
IN
IN
OUT
IN
IN
OUT
IN
IN
OUT
OUT
IN
IN
IN
IN
OUT
IN
IN
OUT
IN
IN
OUT
IN
IN
OUT
OUT
IN
IN
IN
IN
REMOTE
RS232/RS422
H
N
O
I
T
A
C
NI
U
MM
Tx
CO
N
O
TI
A
C
MUNI
M
Tx
CO
OUT
OUT
OUT
IN
IN
IN
OUT
IN
M
1 - 16
A
FAN ASSIMBLY
OUT
IN
S
17 - 32
A
OUT
IN
M
33 - 48
A
OUT
IN
S
49 - 64
A
OUT
OUT
IN
LINK
FAN ASSIMBLY
LINK
IN
D
65 - 80
A
A B C D E F G H I J K L M N O P
OUT
IN
S
81 - 96
A
OUT
IN
M
97 - 112
A
OUT
IN
S
A
113 - 128
OUT
IN
OUT
IN
D
129 - 144
A
A B C D E F G H I J K L M N O P
DISCONNECT BOTH POWER
CORDS BEFORE SERVICING
REDUNDANT
100-240V
50/60Hz
1.2A MAX.
PRIMARY
100-240V
50/60Hz
1.2A MAX.
ANAHEIM, CA
OUTINOUT
OUTINOUTINOUTINOUT
IN
OUT
IN
OUTINOUT
IN
OUTINOUT
IN
OUTINOUT
IN
IN
OUTINOUT
OUTINOUT
IN
OUTINOUT
IN
OUTINOUT
IN
OUTINOUT
IN
OUTINOUT
IN
OUTINOUT
PRIMARY POWER SUPPLY
IN
IN
OUT
IN
IN
OUT
IN
IN
OUT
IN
IN
IN
OUT
OUT
IN
IN
IN
OUT
IN
IN
OUT
IN
IN
OUT
IN
IN
OUT
IN
IN
OUT
IN
OUTINOUTINOUTINOUT
OUTINOUTINOUTINOUT
OUTINOUTINOUTINOUT
OUTINOUTINOUTINOUT
OUTINOUTINOUTINOUT
OUTINOUTINOUTINOUT
OUTINOUTINOUTINOUT
OUTINOUTINOUTINOUT
OUTINOUTINOUTINOUT
OUTINOUTINOUTINOUT
BCDEFGHI JKLMNOP
OUT
OUT
OUT
IN
IN
BCDEFGHI JKLMNOP
OUT
OUT
IN
OUT
IN
BCDEFGHI JKLMNOP
OUT
OUT
OUT
IN
IN
BCDEFGHI JKLMNOP
OUT
OUT
OUT
OUT
IN
OUT
IN
OUT
IN
IN
BCDEFGHI JKLMNOP
OUT
OUT
OUT
IN
IN
BCDEFGHI JKLMNOP
OUT
OUT
OUT
IN
IN
BCDEFGHI JKLMNOP
OUT
OUT
IN
OUT
IN
BCDEFGHI JKLMNOP
OUT
OUT
IN
OUT
OUT
OUT
IN
IN
OUT
IN
BCDEFGHI JKLMNOP
HD Camera
D
HD-SDI/HD-SDI/SDI
I/O Board
NOTE: All FOX 3G HD-SDI units are set
to bidirectional transceiver mode.
FOX AV Receiver
Multimode
RS-232
RS-232
OVER FIBER
REMOTE
O
U
Tx Rx Tx Rx
T
Y/VID
B-Y/C
POWER
MM R
P
AUDIO
12V
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
U
0.8A MAX
LR
T
S
R-Y
SM R
MM R
SM R
MM R
3G P BNC
SM R
MM R
SM R
SM R
3G P BNC
S-VID
FOX 500 DVI Receiver
Multimode
100-240V 0.3A
50/60 Hz
DVI - D OUTPUT
FOX 500 RGB Receiver
Singlemode
100-240V 0.3A
50/60 Hz
RGB OUTPUT
RGB
HV
FOXBOX DVI Receiver
Singlemode
DVI
CONFIG
AUDIO
FOXBOX 4G Rx DVI
FOX 3G HD-SDI Transceive
Singlemode
FOX HDSDI
POWER
OPTICAL
12V
MODE
0.3A MAX
HD/SDI IN
RxTX
FOX 2G AV Rx
ALARM
12
S
Tx
LINK
OPTICAL
12
BUFFERED OUTPUTS
OPTICAL
RxTx
RGB
Rx
Figure 1. Typical FOX Matrix 14400 Application
NOTE: The non-pathologically-compliant multimode and singlemode fiber optic I/O
boards are physically and functionally identical, with the exception of the effective
range of transmission. In this guide, any reference to fiber optic transmission
applies to either transmission mode unless otherwise specified. The pathologicallycompliant fiber optic I/O board is identified separately where appropriate.
AUDIO INPUTS
LR
AUDIO OUTPUTS
LR
LINK
Multimode
Fiber Cable
Singlemode
Fiber Cable
RS-232
PASS THRU
FOX 500 DVI TX
OPTICAL
TX Rx NA
12*
RS-232
LINK
LINK
ALARM
CONTROL
OPTIONAL FOR
TX Rx 1 2
*
RETURN DATA
RS-232
FOX 500 Rx
PASS THRU
OPTICAL
TX Rx NA
2* 1
RS-232
LINK
LINK
ALARM
CONTROL
OPTIONAL FOR
TX Rx 1 2
*
RETURN DATA
By adding or removing I/O boards, the FOX matrix switcher is expandable and contractable
within the following ranges:
• FOX Matrix 320x — Includes up to 20 I/O boards. It is expandable from a 16-input by
16-output matrix to a 320-input by 320-output matrix.
• FOX Matrix 14400 — Includes up to 9 I/O boards. It is expandable from a 16-input by
16-output matrix to a 144-input by 144-output matrix.
The Extron proprietary fiber optic signal, generated by FOX 500, FOXBOX,
PowerCage FOX, and FOX II transmitters, can include video, stereo audio, and transmitterto-receiver RS-232 serial communications. The video component of the signal can be of a
variety of formats, depending on the transmitter and receiver:
• RGB video • Digital Visual Interface (DVI) video
• 3G-SDI, HD-SDI, or SDI video • Low resolution (composite video or S-video)
NOTES:
• Compatible optical signals are digital signals from 270 Mbps through 4.25 Gbps
that are sent and received via fiber optic small form factor pluggable (SFP) modules
with LC-type connectors. The FOX matrix switchers support all compatible optical
signals, whether transmitted or received by an Extron fiber optic system component
or not.
• The FOX 500, FOXBOX, and PowerCage FOX transmitter-to receiver
communications, including the serial link, occupy one matrix switcher input
and output. This matrix switcher also supports the FOX 500 return (receiverto-transmitter) serial communications, but returning this signal stream to the
transmitter occupies a separate matrix switcher input and output.
2
The matrix switchers input and output the optical signals that they route on fiber optic
FOX Matrix 320x and FOX Matrix 14400 • Introduction
transceiver modules and the 3G-SDI, HD-SDI, and SDI video signals on BNC connectors.
The switcher has four (FOX Matrix 320x) or two (FOX Matrix 14400) internal, hot-swappable,
100 VAC to 240 VAC, 50-60 Hz, 400-watt power supplies that provide worldwide power
compatibility and reliability.
The matrix switcher is a single box solution to complex fiber optic and broadcast signal
routing applications. Each input and output is individually isolated and buffered. Any input
can be switched to any one output or all outputs with virtually no crosstalk or signal noise
between channels.
The matrix switcher can be remotely controlled using either the Extron Matrix Switchers
Control Program or the Simple Instruction Set (SIS). Control is available via:
• A rear panel Remote RS232/RS422 port
• A rear panel LAN port
• FOX Matrix 320x — A front panel mini USB Config (configuration) port
• FOX Matrix 14400 — A front panel RS-232 serial Config (configuration) port
The SIS is a set of basic ASCII code commands that provide simple control through a
control system or PC without the need to enter long strings of code. SIS commands can be
entered via any of the ports listed above.
The switcher can be operated remotely by any of the following connected to a serial port or
LAN port:
• A control system
• A PC
• An Extron MKP 2000 remote control panel
• An Extron MKP 3000 remote control panel
• (RS-232 or RS-422 only) An Extron MCP 1000 remote control panel, an MKP 1000
remote keypad, or both
The matrix switcher is housed in a rack-mountable, metal enclosure with mounting flanges
for standard 19-inch racks. The sizes are as follows:
• FOX Matrix 320x — 17U high
• FOX Matrix 14400 — 9U high
Fiber Cable Transmission Modes
Two versions of the non-pathologically compliant FOX matrix switcher fiber optic I/O
board are documented in this guide. They are categorized by the type of fiber optic cable,
multimode or singlemode, which defines the effective range of transmission:
• Multimode — Long distance, up to 300 m (985 feet)
• Singlemode — Very long distance, up to 30 km (18.75 miles)
NOTES:
• All transceiver modules on a fiber optic I/O board, as delivered from Extron, are
configured the same: either all multimode or all singlemode.
• You can mix multimode and singlemode fiber optic I/O boards in a
FOX matrix switcher, but you must ensure that you connect the proper transmission
mode fiber cables to the board.
3
Definitions
FOX Matrix 320x and FOX Matrix 14400 • Introduction
Features
The following terms, which apply to all Extron matrix switchers, are used throughout this
guide:
Tie — An input-to-output connection.
Set of ties — An input tied to two or more outputs. (An output can never be tied to more
than one input.)
Configuration — One or more ties or one or more sets of ties.
Current configuration — The configuration that is currently active in the switcher (also
called “configuration 0”).
Global memory preset — A configuration that has been stored. Up to 64 global presets
can be stored in memory. When a preset is retrieved from memory, it becomes the current
configuration. Presets can be saved and recalled via any of the serial ports or the LAN port.
Room — A subset of outputs that are logically related to each other, as determined by the
operator. The switchers support up to 10 rooms, each of which can consist of from 1 to 16
outputs.
Room memory preset — A configuration consisting of outputs in a single room that
has been stored. When a room preset is retrieved from memory, it becomes the current
configuration. Up to 10 room presets can be associated with a room.
Fiber optic inputs and outputs — With fiber optic I/O boards, the switchers input and
output fiber optic signals on SFP optical connectors. The fiber optic I/O boards support
digital signals from 270 Mbs through 4.25 Gbps.
SDI, HD-SDI, or 3G-SDI inputs and outputs — With SDI/HD-SDI I/O boards,
the switchers input and output SDI and HD-SDI signals on BNC connectors. The
SDI/HD-SDI I/O boards support multi-rate SDI at rates up to 2.97 Gbps, and comply with
SMPTE 259M-C, 292M, 424M, and ITU digital video standards.
Cross-format compatibility —
• An input on an SDI/HD-SDI I/O board can be tied to an output on a fiber optic I/O
board.
• An input on a fiber optic I/O board can be tied to an output on an SDI/HD-SDI I/O
board.
Switching flexibility — The switcher provides individually buffered, independent matrix
switched outputs.
• Any input can be tied to any or all outputs.
• Quick multiple tie — Multiple inputs can be switched to multiple outputs
simultaneously. This allows all displays (outputs) to change from source to source at the
same time.
Input link detection — In critical environments or unmanned, remote locations, it may
be vital to know that sources are active and switching. The switcher confirms that input
sources are active by detecting light. Link detection provides instantaneous feedback via
the serial ports of the switchers or local-area network (LAN) port. The input information
can be displayed on any control system or in a control program on a LAN or Internet (IP)
connection.
Rooming — The switcher can be programmed to group multiple outputs to specific
“rooms,” allowing them to have their own presets.
4
Operational reliability — The FOX matrix switcher can support round-the-clock operation
AC
Po
FOX Matrix 14400 FOX Matrix 320x
AC
AC
r
AC
FOX Matrix 320x and FOX Matrix 14400 • Introduction
in mission-critical applications, using a combination of hot-swappable components and
redundant power supplies.
• Field upgradable, hot-swappable modular design — You can repair, upgrade,
reconfigure, or expand the matrix by simply installing a new I/O board or replacing a
board of one type with one of another. Hot-swappable components let you replace any
I/O board at any time without powering down the switcher.
• Primary and redundant, hot-swappable power supplies — The hot-swappable,
externally mounted redundant power supply is configured to automatically take over the
load from the primary supply in the case of a failure.
The complete power circuit, from the plug, through the power supply, to the insertion of
the power onto the power distribution plane, is separate and redundant (see figure 2).
If the installation includes uninterruptible or completely separate power sources, the
switcher remains powered up through any power interruption except a simultaneous
loss of power on both power sources.
wer
Primary
Power
Supply
Redundant
Power
Supply
Power
Power
Primary
Supply 1
Power
Primary
Power
Supply 2
Redundant
Power
Supply 1
Powe
Redundant
Power
Supply 2
Figure 2. Redundant Power Supply Backs up Primary
The hot-swappable redundant power supply means no downtime for the switcher and
no loss of functionality should one power supply fail. Should a primary power supply fail,
the redundant power supply immediately assumes the load of the failed primary supply.
A failed power supply is easily replaceable from the rear at any time without powering
down the matrix and with no tools required.
• Ease of maintenance — A failed power supply can be easily replaceable from the rear
at any time without powering down the matrix, and with no tools required.
• Power supply status LEDs — Front panel and rear panel LEDs indicate the status of
the primary and redundant power supplies.
• Hot-swappable fans — The hot-swappable, externally mounted fans allow quick
replacement to avert overheating in the case of a failure. Fans can be replaced without
powering down the switcher.
Operational flexibility — Operations such as input and output selection and setting of
presets can be performed via the Ethernet port or either serial port. The serial ports allow
remote control via a PC or a control system. The Ethernet link allows multiple remote links
with two levels of password protection.
• Windows-based Matrix Switchers Control Program
• Simple Instruction Set (SIS)
• Remote control panels and keypads
SNMP support for remote monitoring — Supports the Simple Network Management
Protocol (SNMP) internet-standard protocol, allowing IT personnel to manage devices on
the IP network.
5
Laser controls — Non-pathologically compliant fiber optic boards can be set, via SIS
FOX Matrix 320x and FOX Matrix 14400 • Introduction
commands, to individually or globally disable the output laser drivers so that a driver does
not output light. They can also be set, individually or globally, to automatic so that a driver
turns on when a tie is made involving that driver or off when no tie is made.
Upgradeable firmware — The firmware that controls all switcher operation can be
upgraded in the field via either serial port or the Ethernet port, without taking the switcher
out of service. Firmware upgrades are available for download at www.extron.com, and can
be installed using the Matrix Switchers Control Program or the built-in HTML pages.
Global memory presets — 64 global memory presets are a time-saving feature that lets
you set up and store input/output configurations in advance. You can then recall those
configurations when needed, with a few simple steps, via serial port or Ethernet control.
Rack mounting — Rack mountable in any conventional 19-inch wide rack.
Permanent, rechargeable battery — The matrix switcher has a rechargeable lithium
battery to track time of day when power is disconnected.
WARNING: Explosion hazard — Service note to Extron personnel: There is a
danger of explosion if the battery is incorrectly replaced. Replace it only with the same
or equivalent type recommended by the manufacturer. Dispose of used batteries
according to the instructions of the manufacturer.
ATTENTION: Non-Extron personnel must not attempt to remove the battery. Doing so
will void the warranty.
6
Installation
FOX Matrix 320x and FOX Matrix 14400 • Installation
This section details the installation and configuration of the FOX Matrix Switchers, including:
• Setup and Installation Checklist
• Rear Panel Boards, Cabling, and Features
• Front Panel Features
• Reset Operations
Setup and Installation Checklist
Get Ready
c Familiarize yourself with the matrix switcher.
c Obtain IP setting information for the matrix switcher from the local network
administrator. Read Ethernet Connection, beginning on page 82.
Configure the Matrix Switcher
c Install the desired I/O boards (page 75).
Perform Physical Installation
c If desired, install the switcher in a rack (page 74).
c Cable input and output devices to the I/O ports (page 11).
c As desired, connect computers, control systems, or both to the rear panel Remote port
(page 13), LAN port (page 14), and front panel Configuration port (page 16).
c Connect power (page 15).
c Test the switcher by creating a tie (page 25).
Install Software
c Install the Matrix Switchers Control Program (page 38).
7
Rear Panel Boards, Cabling, and Features
FOX Matrix 320x and FOX Matrix 14400 • Installation
FAN ASSEMBLY
FAN ASSEMBLY
ANAHEIM, CA
OUT
OUT
OUT
IN
1 - 16
A B C D E F G H I J K L M N O P
OUT
OUT
IN
17 - 32
A B C D E F G H I J K L M N O P
OUT
OUT
IN
33 - 48
A B C D E F G H I J K L M N O P
OUT
OUT
IN
49 - 64
A B C D E F G H I J K L M N O P
OUT
OUT
IN
65 - 80
A B C D E F G H I J K L M N O P
OUT
OUT
IN
81 - 96
A B C D E F G H I J K L M N O P
OUT
OUT
IN
97 - 112
A B C D E F G H I J K L M N O P
OUT
OUT
IN
113 - 128
A B C D E F G H I J K L M N O P
OUT
OUT
IN
129 - 144
A B C D E F G H I J K L M N O P
DISCONNECT BOTH POWER
DISCONNECT BOTH POWER
CORDS BEFORE SERVICING
CORDS BEFORE SERVICING
REDUNDANT
100-240V
50/60Hz
1.2A MAX.
PRIMARY
100-240V
50/60Hz
1.2A MAX.
OUT
IN
IN
OUT
IN
OUT
IN
OUT
IN
OUT
IN
OUT
IN
OUT
IN
OUT
IN
OUT
IN
IN
OUTINOUT
3
OUT
IN
IN
OUTINOUT
OUT
IN
IN
OUTINOUT
OUT
IN
IN
OUTINOUT
OUT
IN
IN
OUTINOUT
OUT
IN
IN
OUTINOUT
OUT
IN
IN
OUTINOUT
OUT
IN
IN
OUTINOUT
OUT
IN
IN
OUTINOUT
OUTINOUTINOUTINOUT
IN
OUT
IN
OUTINOUTINOUTINOUT
IN
OUT
IN
OUTINOUTINOUTINOUT
IN
OUT
IN
OUTINOUTINOUTINOUT
IN
OUT
IN
OUTINOUTINOUTINOUT
IN
OUT
IN
OUTINOUTINOUTINOUT
IN
OUT
IN
OUTINOUTINOUTINOUT
IN
OUT
IN
OUTINOUTINOUTINOUT
IN
OUT
IN
OUTINOUTINOUTINOUT
IN
OUT
IN
PRIMARY POWER SUPPLY
OUT
IN
OUT
IN
OUT
IN
OUT
IN
OUT
IN
OUT
IN
OUT
IN
OUT
IN
OUT
IN
RS232/RS422
IN
OUT
IN
IN
OUT
IN
IN
OUT
IN
IN
OUT
IN
IN
OUT
IN
IN
OUT
IN
IN
OUT
IN
IN
OUT
IN
IN
OUT
IN
REMOTE
ACT
REDUNDANT POWER SUPPLY
OUT
IN
OUT
OUT
IN
OUT
OUT
IN
OUT
OUT
IN
OUT
OUT
IN
OUT
OUT
IN
OUT
OUT
IN
OUT
OUT
IN
OUT
OUT
IN
IN
IN
OUT
IN
IN
OUT
IN
IN
OUT
IN
IN
OUT
IN
IN
OUT
IN
IN
OUT
IN
IN
OUT
IN
1
3G P BNC
3G P BNC
2
OUT
IN
SWITCH REFERENCE
BI-LEVEL TRI-LEVEL
3G P BNC
8
OUT
OUT
LAN
IN
IN
RESET
LINK
9 6
77 3 4 5
Figure 3. FOX Matrix 14400 Switcher Rear Panel
a Fiber optic boards with connectors and LEDs (see page 11)
b 3G-SDI, HD-SDI, and SDI boards with connectors and LEDs (see page 12)
c Remote RS232/RS422 port (see page 13)
d LAN connector (Ethernet connection) (see page 14)
e Reset button and LED (see page 15)
f Primary and Redundant AC power connectors (see page 15)
g Power supply modules and indicator LEDs (see page 15)
h Switch Reference BNCs — Present but not used on the FOX Matrix 14400.
Not present on the FOX Matrix 320x.
i Cooling fan assemblies (see Removing and Installing a Fan Module on page 80)
8
FOX Matrix 320x and FOX Matrix 14400 • Installation
OUTINOUTINOUTINOUT
FAN ASSEMBLY
9
FAN ASSEMBLY
ABCDEFGHIJ MNO P
OUTINOUTINOUTINOUT
ABCDEFGHIJ MNO P
OUTINOUTINOUTINOUT
ABCDEFGHIJ MNO P
OUTINOUTINOUTINOUT
49 – 6465 – 8081 – 9697 – 112113 – 128129 – 144 1 – 1617 – 3233 – 48
ABCDEFGHIJ MNO P
OUTINOUTINOUTINOUT
ABCDEFGHIJ MNO P
OUTINOUTINOUTINOUT
ABCDEFGHIJ MNO P
OUTINOUTINOUTINOUT
ABCDEFGHIJ MNO P
OUTINOUTINOUTINOUT
ABCDEFGHIJ MNO P
OUTINOUTINOUTINOUT
ABCDEFGHIJ MNO P
OUTINOUTINOUTINOUT
ABCDEFGHIJ MNO P
OUTINOUTINOUTINOUT
161 – 176177 – 192193 – 208209 – 224225 – 240241 – 256257 – 272273 – 288289 – 304305 – 320 145 – 160
FAN ASSEMBLY
9
FAN ASSEMBLY
ABCDEFGHIJ MNO P
OUTINOUTINOUTINOUT
ABCDEFGHIJ MNO P
OUTINOUTINOUTINOUT
ABCDEFGHIJ MNO P
OUTINOUTINOUTINOUT
ABCDEFGHIJ MNO P
OUTINOUTINOUTINOUT
ABCDEFGHIJ MNO P
OUTINOUTINOUTINOUT
ABCDEFGHIJ MNO P
OUT
OUT
OUT
IN
A B C D E F G H I J K L M N O P
OUT
OUT
IN
A B C D E F G H I J K L M N O P
OUT
OUT
IN
A B C D E F G H I J K L M N O P
OUT
OUT
IN
OUT
IN
IN
OUT
OUT
IN
IN
OUT
OUT
IN
IN
OUT
OUT
IN
IN
OUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUT
OUT
IN
IN
OUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUT
OUT
IN
IN
OUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUT
OUT
IN
IN
OUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUT
OUT
IN
IN
OUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUT
OUT
IN
IN
OUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUT
OUT
IN
IN
OUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUT
OUT
IN
IN
OUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUT
OUT
IN
IN
OUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUT
OUT
IN
IN
OUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUT
OUT
IN
IN
KL
KL
KL
KL
KL
KL
KL
KL
KL
KL
OUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUT
OUT
IN
IN
OUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUT
OUT
IN
IN
OUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUT
OUT
IN
IN
OUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUT
OUT
IN
IN
OUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUT
OUT
IN
IN
3
OUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUT
OUT
IN
IN
IN
OUTINOUT
IN
OUTINOUT
IN
OUTINOUT
IN
OUTINOUT
OUTINOUTINOUTINOUT
IN
OUT
IN
OUTINOUTINOUTINOUT
IN
OUT
IN
OUTINOUTINOUTINOUT
IN
OUT
IN
OUTINOUTINOUTINOUT
IN
OUT
IN
KL
KL
KL
KL
KL
KL
OUT
IN
OUT
IN
OUT
IN
OUT
IN
OUT
IN
OUT
IN
OUT
IN
OUT
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
OUT
IN
IN
IN
IN
IN
OUT
OUT
IN
OUT
OUT
IN
OUT
OUT
IN
OUT
OUT
IN
IN
IN
OUT
IN
IN
OUT
IN
IN
OUT
IN
1
3G P BNC
3G P BNC
2
3G P BNC
3G P BNC
A B C D E F G H I J K L M N O P
LAN
REMOTE
Extron
Anaheim,
CA
RESET
DISCONNECT BOTH POWER
LINK
CORDS BEFORE SERVICING
ACT
RS232/RS422
C US
LISTED
1T23 I.T.E.
REDUNDANT
~
100-240V
50/60Hz
6.5A MAX
PRIMARY POWER SUPPLY 1
PRIMARY
~
100-240V
50/60Hz
6.5A MAX
N15799
6
7 7 7 7
PRIMARY POWER SUPPLY 2
5
4
3
Figure 4. FOX Matrix 320x Switcher Rear Panel
REDUNDANT POWER SUPPLY 2
9
I/O Boards
2
d
Location A
4
FOX Matrix 320x and FOX Matrix 14400 • Installation
Output and Input
I/O Numbers
ATTENTION:
• Use electrostatic discharge (ESD) precautions (be electrically grounded) when
making connections. Electrostatic discharge can damage equipment, even if you
cannot feel, see, or hear it.
• Remove system power before making all connections.
As shown in figure 5, each I/O board is identified by the input and output numbers supported
by the board position, which are printed on the side of each fan module (1 - 16, 17 - 32,
and so on). The transceiver modules on fiber optic I/O boards and BNC bocks on the
3G/HD/SD-SDI are identified as A through P.
I#1
I#2
I#3
I#4
I#5
I#6
I#7
I#8
I#9
I#10
I#11
I#12
I#13
I#14
I#15
I#16
Location P
O#1
O#2
O#3
O#4
O#5
O#6
O#7
O#8
O#9
O#10
O#11
O#12
O#13
O#14
O#15
O#16
Output and Input
FAN ASSIMBLY
O#43
IN
I#43
IN
IN
OUT
O#44
OUT
OUT
I#44
IN
IN
O#45
IN
OUT
I#45
OUT
OUT
IN
IN
IN
OUT
O#46
OUT
OUT
I#46
IN
IN
O#47
IN
OUT
IN
OUT
IN
I#47
I#48
O#48
OUT
IN
OUT
IN
OUT
IN
3G P BNC
OUT
IN
OUT
IN
O#35
IN
IN
OUT
IN
IN
OUTINOUT
I#35
I#36
I#37
I#38
O#36
O#37
OUT
OUT
IN
OUT
OUT
IN
IN
OUTINOUT
IN
OUTINOUT
O#38
OUTINOUTINOUTINOUT
IN
OUT
IN
I#39
O#39
O#40
OUTINOUTINOUTINOUT
IN
OUT
IN
OUTINOUTINOUTINOUT
IN
OUT
IN
I#40
O#41
I#41
I#42
O#42
OUT
OUT
IN
1 - 16
A B C D E F G H I J K L M N O P
I#33
17 - 32
33 - 48
49 - 64
O#33
OUT
OUT
I#34
O#34
OUT
IN
A B C D E F G H I J K L M N O P
OUT
IN
A B C D E F G H I J K L M N O P
Figure 5. Arrangement of Inputs and Outputs on the I/O Boards
Each module, numbered from left to right, includes one of the outputs and one of the
inputs supported by the board. (For example, the input and output numbers supported by
the I/O board in location 33 - 48 [slot 3] are as follows: A = 33, B = 34, C = 35, D = 36,
E = 37, F = 38, G = 39, H = 40, I = 41, J = 42, K = 43, L = 44, M = 45, N = 46, O = 47, and
P = 48.)
NOTE: The output on the transceiver module is to the left of the input.
Slot Inputs and Outputs Slot Inputs and Outputs
1 1 through 16 11* 161 through 176
2 17 through 32 12* 177 through 192
3 33 through 48 13* 193 through 208
4 49 through 64 14* 209 through 224
5 65 through 80 15* 225 through 240
6 81 through 96 16* 241 through 256
7 97 through 112 17* 257 through 272
8 113 through 128 18* 273 through 288
9 129 through 144 19* 289 through 304
10* 145 through 160 20* 305 through 320
* FOX Matrix 320x only
Slot 1
(1-16)
Slot
No boar
installed
Slot 3
(33-48)
Slot
(49-64)
10
Extron
Fiber Opti
Receiver
Switcher
OPTICAL
FOX Matrix 320x and FOX Matrix 14400 • Installation
Fiber optic boards
1a 1a 1a 1a 1a 1a 1a 1a1a 1a 1a 1a 1a 1a 1a 1a
OUT
OUT
OUT
OUT
IN
A B C D E F G H I J K L M N O P
IN
IN
IN
OUTINOUT
OUTINOUTINOUTINOUT
IN
OUT
IN
OUT
IN
OUT
IN
OUT
IN
OUT
IN
OUT
IN
IN
1b 1b 1b 1b 1b 1b 1b 1b1b 1b 1b 1b 1b 1b 1b 1b
Figure 6. Fiber Optic Board
a Fiber optic board, connectors (see figure 3 on page 8 and figure 4 on page 9)—
WARNING: Risk of serious physical injury — The FOX matrix switchers fiber
optic I/O boards output continuous invisible light, which may be harmful to the
eyes; use with caution.
• Do not look into the fiber optic cable connectors or into the fiber optic cables.
• Plug the attached dust caps into the optical transceivers when the fiber cable
is unplugged.
NOTES:
• Ensure that you use the proper fiber cable for your I/O board. Typically,
singlemode fiber has a yellow jacket and multimode cable has an orange or
aqua jacket.
• Unlike most Extron transmitters and receivers, which output an optical stream
on one connector in a block and receive a return optical stream on the second
connector in the same block, the FOX matrix switchers uses one connector
on the block as an input and the second connector on the same block as a
separate output.
• All transceiver modules on a fiber optic I/O board,
as delivered from Extron, are configured the same:
either all multimode or all singlemode.
• You can mix multimode and singlemode fiber optic
Fiber Optic
Transmitter
LINK
RxTx
LINK
Rx is optional
connection
I/O boards in a FOX matrix switcher, but you must
ensure that you connect the proper transmission
mode fiber cables to the board.
Ä Input connector and LED — For all one-way
video, audio, and serial communications output by a
transmitter, connect a fiber optic cable to the Input LC
connector (see figure 7).
Connect the far end of this fiber optic cable to the
Optical Tx LC connector on a FOXBOX Tx transmitter
or to any other compatible Extron fiber optic device.
OUT
1b 1a
FOX
Matrix
IN
NOTES:
• For a FOX 500 transmitter, connect this fiber
optic cable to the Optical 1 LC connector.
• Alternatively, for the serial return, (receiver-to-
transmitter) function, connect the far end of the
cable to the Optical 2 connector on a receiver.
Input LED — See Fiber optic I/O board LED
indications on the next page.
Tx is optional
connection
Extron
RxTx
LINK
c
LINK
Figure 7. Optical Connections
11
Å Output connector — For all one-way video, audio, and serial communications
OUT
IN
OUT
IN
FOX Matrix 320x and FOX Matrix 14400 • Installation
output to a receiver, connect a fiber optic cable to the Output LC connector (see
figure 7, on the previous page).
Connect the far end of this fiber optic cable to the Optical Rx LC connector on a
FOXBOX Rx receiver or to any other compatible Extron fiber optic device.
NOTES:
• For a FOX 500 receiver, connect this fiber optic cable to the Optical Rx LC
connector.
• Alternatively, for the serial return, (receiver-to-transmitter) function,
connect the far end to the Optical 2 connector on a transmitter.
Output LED — See “Fiber optic I/O board LED indications,” below.
Fiber optic I/O board LED indications
On the fiber optic I/O boards, the input and output LEDs on the transceivers provide useful
indications of the status of the lasers and the reclocking function. See the table below.
Output LED
Definition
indication
Reclocked at 4.25 Gbps On On Reclocked at 4.25 Gbps
Not reclocked, laser off, or
Off Off Not reclocked or no signal
no signal
Non-4G signal present or
Fast blink Fast blink Non-4G signal present or
not reclocked
Input LED
indication Definition
not reclocked
3G/HD/SD-SDI boards
2a 2a 2a 2a 2a 2a 2a 2a2a 2a 2a 2a 2a 2a 2a 2a
OUT
OUT
OUT
IN
A B C D E F G H I J K L M N O P
OUT
IN
IN
IN
OUTINOUT
OUTINOUTINOUTINOUT
IN
OUT
IN
OUT
IN
OUT
IN
OUT
IN
OUT
IN
IN
3G P BNC
OUT
IN
2b 2b 2b 2b 2b 2b 2b 2b2b 2b 2b 2b 2b 2b 2b 2b
Figure 8. 3G/HD/SD-SDI Board
b BNC board, connectors (see figure 3 on page 8 and figure 4 on
page 9) — Connect inputs and output using the included DIN-to-
2b
2a
female-BNC pigtail connectors, as follows:
NOTE: The pigtails are not installed on the board during shipment.
• To install the pigtails, press them onto the DIN connectors
until they snap into place.
• To remove the pigtails, pull back on the knurled collar and
pull the pigtail straight back from the DIN connector.
Ç Multi-rate SDI Input connectors — Connect 3G-SDI, HD-SDI, or
SDI video inputs to these BNC connectors.
É Multi-rate SDI Output connectors — Connect digital displays to these BNC
connectors.
12
Remote Port
RS-232FunctionPin Function
9
—
Not used
—
ansmit data (–)
ansmit data (+)
Not used
RS-422
REMOTE
FOX Matrix 320x and FOX Matrix 14400 • Installation
c Remote RS232/RS422 connector (see figure 3 on page 8 and figure 4 on
page 9) — Connect a host device, such as a computer or touch panel control, to the
switcher via this 9-pin D connector for serial RS-232 or RS-422 control (see figure 9).
1
—
9
5
RS-232/RS-422
6
1
2
3
4
5
6
7
8
Tx
Rx
—
Gnd
—
—
—
Not used
Transmit data
Receive data
Not used
Signal ground
Not used
Not used
Not used
Figure 9. Remote RS232/RS422 Connector
See Programming Guide, beginning on page 20, for definitions of the SIS commands
(serial commands to control the switcher via this connector) and Matrix Software,
beginning on page 36, for details on how to install and use the control software.
NOTE: The switcher can support either the RS-232 or the RS-422 serial
communication protocol, and can operate at 9600, 19200, 38400, or 115200
baud rates.
See the Command and Response Table for IP- and SNMP-Specific SIS
Commands on page 33 to configure this port under SIS control.
—
Not used
Tx–
Tr
Receive data (–)
Rx–
Not used
—
Signal ground
Gnd
Not used
—
Receive data (+)
Rx+
Tr
Tx+
If desired, connect an MKP 2000 or MKP 3000 remote control panel to the Remote
RS232/RS422 connector. See the MKP 2000 Remote Control Panel User Guide or the
MKP 3000 User Guide for details.
13
Ethernet Connection
reversed) is a "crossover" cable.
no pin/pair assignments are swapped.
Inser
Crossover Cable Straight-through Cable
Link
LED
Activity
LED
FOX Matrix 320x and FOX Matrix 14400 • Installation
d LAN port (see figure 3 on page 8 and figure 4 on page 9) — For IP control of the
Cabling
It is vital that your Ethernet cables be the correct cable type and that they be properly
terminated with the correct pinout. Ethernet links use Category (CAT) 3, 5e, or CAT 6,
unshielded twisted pair (UTP) or shielded twisted pair (STP) cables, terminated with RJ-45
connectors. Ethernet cables are limited to a length of 328 feet (100 meters).
NOTES:
• Do not use standard telephone cables. Telephone cables do not support Ethernet
or Fast Ethernet.
• Do not stretch or bend cables. Transmission errors can occur.
system, connect the matrix switcher to a PC or to an Ethernet LAN via
this RJ-45 connector. You can use a PC to control the networked switcher
with SIS commands from anywhere in the world. You can also control the
switcher from a PC that is running the Extron Matrix Switchers Control
Program or has downloaded HTML pages from the switcher.
Link LED indicator — The green (link) LED indicates that the switcher is
properly connected to an Ethernet LAN. This LED should light steadily.
Act LED indicator — The yellow (activity) LED indicates transmission
of data packets on the RJ-45 connector. This LED should flicker as the
switcher communicates.
The cable used depends on your network speed. The switcher supports both
10 Mbps (10Base-T — Ethernet) and 100 Mbps (100Base-T — Fast Ethernet), half-duplex
and full-duplex Ethernet connections.
• 10Base-T Ethernet requires CAT 3 UTP or STP cable at minimum.
• 100Base-T Fast Ethernet requires CAT 5e UTP or STP cable at minimum.
RJ-45 connector wiring
The Ethernet cable can be terminated as a straight-through cable or a crossover cable and
must be properly terminated for your application (see figure 10).
• Crossover cable — Direct connection between the computer and the
FOX matrix switcher
• Patch (straight) cable — Connection of the FOX matrix switcher to an Ethernet LAN
Pins:
12345678
t Twisted
Pair Wires
RJ-45
Connector
Pin
A cable that is wired as T568A at one end
and T568B at the other (Tx and Rx pairs
End 1 End 2 End 1 End 2
Wire color
1
White-green
2
Green
3
White-orange
4
Blue
5
White-blue
6
Orange
7
White-brown
8
Brown
T568A T568B
Wire color
White-orange
Orange
White-green
Blue
White-blue
Green
White-brown
Brown
Pin
Wire color
1
White-orange
2
3
White-green
4
Blue
5
White-blue
6
7
White-brown
8
Brown
A cable that is wired the same at both ends is
called a "straight-through" cable, because
Wire color
White-orange
OrangeOrange
White-green
Blue
White-blue
GreenGreen
White-brown
Brown
T568BT568B
Figure 10. RJ-45 Connector and Pinout Tables
14
Reset Button and LED
FOX Matrix 320x and FOX Matrix 14400 • Installation
e Reset button (see figure 3 on page 8 and figure 4 on page 9) —
The recessed Reset button initiates four levels of matrix switcher reset. For four
different reset levels, press and hold the button while the switcher is running or
while you power up the switcher (see Reset Operations on page 18 for details).
• Events (mode 3) reset — Toggles events monitoring on and off.
• IP settings (mode 4) reset — Reset the IP functions of the switcher.
NOTE: The IP settings reset does not replace any user-installed firmware.
• Absolute (mode 5) reset — Restore the switcher to the default factory conditions.
• Hard reset — Restore the switcher to the default factory conditions and return the
switcher to the default firmware that shipped with the unit.
NOTES:
• Factory loaded firmware is active until it is replaced or the power is cycled.
• Hard reset does not clear the current configuration.
Power Supply Modules and Indicator LEDs
f Primary and Redundant AC power connectors (see figure 3 and figure 4) —
Plug standard IEC power cords into these connectors to connect the switcher to
100 VAC to 240 VAC, 50 or 60 Hz power sources.
RESET
NOTE: For the most reliable power, connect the a power cord from the Redundant
power connector to either an uninterruptible power source or to a power source
that is completely independent from the primary power source.
g Primary and Redundant power supply indicator LEDs (see figure 3 and
figure 4) —
Green — Indicates that the associated power supply is operating within normal
tolerances.
Red — Indicates that the associated power supply is operating outside the normal
tolerances or has failed. See Removing and Installing a Power Supply Module on
page 78 to replace the power supply.
Cooling Fan assemblies
i Primary and Redundant cooling fans (see figure 3 and figure 4) — Cool the
equipment. If a fan has failed, replace it at your earliest opportunity. See Removing and
Installing a Fan Module on page 80 to replace the fans.
15
Front Panel Features
X Matrix 320x
5
1
(Gnd)
Tip
FOX Matrix 320x and FOX Matrix 14400 • Installation
CONFIG
POWER SUPPLY
PRIMARY
REDUNDANT
CONFIG
POWER SUPPLY
PRIMARY 1
REDUNDANT 1
PRIMARY 2
REDUNDANT 2
2
STATUS
FOX 4G MATRIX 320x
FIBER OPTIC DIGITAL MATRIX SWITCHER
1 3
FOX 4G MATRIX 14400
FIBER OPTIC DIGITAL MATRIX SWITCHER
FOX Matrix 14400 FO
2 3
Figure 11. Front Panel Configuration Port
a Configuration port (FOX Matrix 14400 only) — This 2.5 mm mini stereo jack
serves the same serial communications function as the rear panel Remote port
(although RS-232 only), but it is easier to access than the rear port after the matrix
switcher has been installed and cabled. The optional 9-pin D to 2.5 mm mini jack
TRS RS-232 cable (see figure 12), can be used for this connection.
6 feet
(1.8 m)
6
9
Ring
9-pin D Connection TRS Plug
Pin 2 Rx line on the computer Tip
Pin 3 Tx line on the computer Ring
Pin 5 Signal ground on the computer Sleeve
Sleeve
Figure 12. Optional 9-pin TRS RS-232 Cable
NOTES:
• This port is independent of the rear panel Remote port and is not affected by
changes to the protocol of the rear panel port. This front panel port protocol
can be changed under SIS command control only. See the Serial Ports
Parameters SIS command on page 34 to configure this port under SIS
control.
• A front panel Configuration port (RS-232) connection and a rear panel Remote
port connection can both be active at the same time.
This port is RS-232 only, with its default protocols as follows:
• 9600 baud • no parity • 8 data bits
• 1 stop bit • no flow control
16
NOTE: The maximum distance from the matrix switcher to the controlling device
FOX Matrix 320x and FOX Matrix 14400 • Installation
can be up to 200 feet (61 meters). Factors such as cable gauge, baud rates,
environment, and output levels (from the switcher and the controlling device) all
affect transmission distance. Distances of about 50 feet (15 meters) or less are
typically not a problem. In some cases the matrix switcher may be capable of
serial communications via RS-232 up to 250 feet (76 meters) away.
b Configuration port (FOX Matrix 320x only) — A mini USB B port.
c Power Supply and Status LEDs —
Primary and Redundant Power Supply LEDs —
• Green — Indicates that the associated power supply is operating within normal
tolerances.
• Amber (FOX Matrix 320x only) — Indicates that AC power has been
disconnected or the power supply has been removed.
• Red — Indicates that the associated power supply is operating outside the normal
tolerances or has failed. See Removing and Installing a Power Supply Module
on page 78 to replace the power supply.
Status LED (FOX Matrix 320x only) —
• Green — Indicates that the controller board is operating normally and that the
temperature and backplane voltages are all within normal tolerances.
• Red — Indicates that either the controller board has failed or that temperature or
backplane voltages are outside of acceptable levels. See the Request system
status SIS command on page 31 to identify the source of the indication.
17
Reset Operations
FOX Matrix 320x and FOX Matrix 14400 • Installation
The rear panel Reset button initiates four levels of resets (numbered 1, 3, 4, and 5 for the
sake of comparison with an Extron IPL product). The Reset button is recessed, so use a
pointed stylus, ballpoint pen, or small screwdriver to access it.
See the following table for a summary of the modes.
ATTENTION: Review the reset modes carefully. Using the wrong reset mode may
result in unintended loss of flash memory programming, port reassignment, or a
controller reboot.
NOTE: The reset modes listed below close all open IP and Telnet connections and close
all sockets. Also, the following modes are separate functions, not a continuation from
mode 1 to mode 5.
Reset Mode Comparison and Summary
Mode Activation Result Purpose and Notes
1 Hold down the recessed Reset button while
applying power to the switcher.
NOTE: After a mode 1 reset is
performed, update the switcher
firmware to the latest version. Do
not operate the switcher firmware
version that results from the
mode 1 reset. If you want to use
the factory default firmware, you
must upload that version again.
See Matrix Switchers Control
Program on page 47 or details
on uploading firmware.
The switcher reverts to the factory default firmware.
Event scripting does not start if the switcher is powered on in
this mode. All user files and settings, such as IP settings, are
maintained.
NOTE: If you do not want to update firmware, or you
performed a mode 1 reset by mistake, cycle power
to the switcher to return to the firmware version that
was running before the mode 1 reset. Use the
0Q SIS command on page 31 to confirm that the
factory default firmware is no longer running (look for
the asterisk [*] following the version number.
Use mode 1 to return
the switcher to the
factory default firmware
version if incompatibility
issues arise with userloaded firmware.
3 Hold the Reset button for approximately
3 seconds, until the Reset LED blinks once,
then momentarily press Reset within 1
second.
4 Hold the Reset button for approximately
6 seconds, until the Reset LED blinks
twice (once at 3 seconds and again at 6
seconds). Then momentarily press Reset
within 1 second.
5 Hold the Reset button for approximately
9 seconds, until the Reset LED blinks
three times (once at 3 seconds, again at
6 seconds, and then again at 9 seconds).
Then momentarily press Reset within 1
second.
Mode 3 turns events on or off. During resetting, the
Reset LED flashes two times if events are starting, three times
if events are stopping.
Mode 4:
Enables ARP capability.
•
• Sets the IP address to the factory default.
• Sets the subnet address to the factory default.
• Sets the gateway address to the factory default.
• Sets port mapping to the factory default.
• Turns DHCP off.
• Turns events off.
The Reset LED flashes four times in succession during the reset.
Mode 5 performs a complete reset to factory defaults
(with the exception of the firmware):
Does everything mode 4 does.
•
• Resets most settings, including:
• Clears all ties.
• Clears all presets.
• Clears all output mutes.
• (FOX Matrix 320x) Sets the output lasers to always on.
• Resets all IP options.
• Removes all files from the switcher.
The reset LED flashes four times in succession during the reset.
Mode 3 is useful for
troubleshooting.
Mode 4 enables you
to set IP address
information using ARP
and the MAC address.
Mode 5 is useful if
you want to start over
with configuration
and uploading or to
replace events. Same
as the EZQQQ} SIS
command on page 29.
18
Performing Soft System Resets (Resets 3, 4, and 5)
Release, then immediately
press and release again.
RESET
RESET
RESET
Release, then immediately
press and release again.
6 seconds
9 seconds
Press and hold
the Reset button.
3 seconds
Reset LED blinks once.
Release, then immediately
press and release again.
Reset LED blinks twice.
Press and hold
the Reset button.
Press and hold
the Reset button.
Reset LED blinks
three times.
IP Settings
Reset
Absolute
Reset
Events
Reset
(Mode 4)
(Mode 5)
(Mode 3)
FOX Matrix 320x and FOX Matrix 14400 • Installation
Perform a soft reset of the switcher as follows (see figure 13):
1. Use a small screwdriver to press and hold the rear panel Reset button until the
rear panel Reset LED blinks once (events reset), twice (system reset), or three times
(absolute reset).
Figure 13. Resets
2. Release the Reset button and then immediately press and release the Reset button
again. Nothing happens if the second momentary press does not occur within 1 second.
19
Programming Guide
FOX Matrix 320x and FOX Matrix 14400 • Programming Guide
This section describes the operation of the FOX matrix switchers using the Simple
Instruction Set, including:
• Host Control Ports
• Host-to-Switcher Instructions
• Switcher-Initiated Messages
• Switcher Error Responses
• Using the Command and Response Tables
• Special Characters
Host Control Ports
The switcher has one or two (depending on the model) serial ports, and an Ethernet LAN
port. The FOX Matrix 320x has a USB port. Any of these ports can be connected to a host
device such as a computer running the Extron DataViewer utility or the HyperTerminal utility
or a control system. These ports make control of the switcher possible.
Serial Ports
The serial ports are:
• Rear panel Remote port — A 9-pin D connector for serial RS-232 or RS-422 control
(see Remote Port and item c on page 13).
• Front panel Configuration port (FOX Matrix 14400 only) — A 2.5 mm mini stereo
jack for serial RS-232 control (see Front Panel Features and item a on page 16).
The default protocol for both ports is as follows:
• 9600 baud • no parity • 8 data bits
• 1 stop bit • no flow control
The ports can be configured to operate at the 9600, 19200, 38400, or 115200 baud rate.
NOTES:
• These two ports are independent of one another. A front panel Configuration port
connection and a rear panel Remote port connection can both be active at the
same time.
• The switcher can operate at 9600, 19200, 38400, or 115200 baud rates, but
Extron recommends leaving these ports at 9600 baud only.
• The protocol of these ports can be changed via an SIS command only. See the Set
serial ports parameters SIS command on page 34 to configure these ports using
an SIS command.
20
USB Port (FOX Matrix 320x)
FOX Matrix 320x and FOX Matrix 14400 • Programming Guide
The front panel Configuration port (see item b on page 17 and Front Panel Features on
page 16), a standard USB cable, and the Extron DataViewer utility, version 2.0 or newer, can
be used for remote control of the switcher. The USB cable, available at any local electronics
store, should be terminated on one end with a mini USB B male connector.
NOTE: Before you use the FOX Matrix 320x Configuration (USB) port for the first time,
you need to install and activate the USB driver on your computer. The simplest way to
do this is to install version 8.0 or newer of the Matrix Switchers Control Program and
then run the Found New Hardware Wizard. See Installing the Software on page 38
and Activating a USB port for the first time on page 39.
Ethernet (LAN) Port
The rear panel Ethernet connector on the switcher can be connected to an Ethernet LAN
or WAN (see item d and Ethernet Connection on page 14). Communications between
the switcher and the controlling device is via telnet (a TCP socket using port 23). The TCP
port can be changed if necessary. This connection makes SIS control of the switcher
possible using a computer connected to the same LAN or WAN. The SIS commands and
actions of the switcher are identical to the commands and actions the switcher has when
communicating to it via RS-232.
Establishing a connection
Establish a network connection to a FOX matrix switcher as follows:
1. Open a TCP socket to port 23 using the IP address of the switcher.
NOTE: If the local system administrators have not changed the value, the factory-
specified default, 192.168.254.254, is the correct value for this field.
The switcher responds with a copyright message including the date, the name of the
product, firmware version, part number, and the current date/time.
NOTES:
• If the switcher is not password-protected, the device is ready to accept SIS
2. If the switcher is password protected, enter the appropriate administrator or user
password.
If the password is accepted, the switcher responds with
Administrator
If the password is not accepted, the Password prompt reappears.
commands immediately after it sends the copyright message.
• If the switcher is password-protected, a password prompt appears below the
copyright message.
Login User or Login
.
21
Connection timeouts
FOX Matrix 320x and FOX Matrix 14400 • Programming Guide
The Ethernet link times out after a designated period of time of no communications. By
default, this timeout value is set to five minutes but the value can be changed. See the
Configure port timeout SIS commands on page 34.
NOTE: Extron recommends leaving the default timeout at 5 minutes and periodically
issuing the Query (Q) command to keep the connection active. If there are long idle
periods, Extron recommends disconnecting the socket and reopening the connection
when another command must be sent.
Number of connections
A FOX matrix switcher can have up to 200 simultaneous TCP connections, including all http
sockets and telnet connections. When the connection limit is reached, the switcher accepts
no new connections until some have been closed. No error message or indication is given
that the connection limit has been reached. To maximize performance of an IP Link device,
keep the number of connections low and close unnecessary open sockets.
Using Verbose Mode
Telnet connections to a FOX matrix switcher can be used to monitor for changes that occur
on the switcher, such as front panel operations and SIS commands from other telnet sockets
or a serial port. For a telnet session to receive change notices from the switcher, the telnet
session must be in verbose mode 1 or 3 (see the Verbose Mode SIS command on page 34).
Host-to-Switcher Instructions
SIS commands consist of one or more characters per field. No special characters are
required to begin or end a command character sequence. When a command is valid, the
unit executes it and sends a response to the host device. All responses from the unit to the
host end with a carriage return and a line feed (CR/LF = ]), which signals the end of the
response character string. A string is one or more characters.
Switcher-initiated Messages
When a local event, such as an equipment power-up, occurs, the unit responds by sending
a message to the host. The unit-initiated messages are listed below:
(c) Copyright 20yy, Extron Electronics, FOX Matrix 320x,
Vx.xx, 60-1082-01
- or -
(c) Copyright 20yy, Extron Electronics, FOX Matrix 14400,
Vx.xx, 60-1255-01
The switcher issues the appropriate copyright message (above) when it first powers on.
Vx.xx is the firmware version number; 60-xxxx-xx is the part number of the connected unit.
]
Password:
The switcher initiates the password message immediately after the copyright message when
the controlling system is connected using TCP/IP or telnet and the switcher is password
protected. This message means that the switcher requires an administrator or user level
password before it will perform the commands entered via this link. The switcher repeats
the password message response for every entry other than a valid password until a valid
password is entered.
]]
]]
22
]
ASCII to Hex Conversion Table
•
Space
FOX Matrix 320x and FOX Matrix 14400 • Programming Guide
Login Administrator
]
Login User
]
The switcher initiates the login message when a correct administrator or user password has
been entered. If the user and administrator passwords are the same, the switcher defaults
to administrator privileges.
Switcher Error Responses
When the switcher receives a valid SIS command, it executes the command and sends
a response to the host device. If the unit is unable to execute the command because the
command is invalid or it contains invalid parameters, the unit returns an error response to
the host. The error response codes are:
E01 — Invalid input channel number (too large)
E10 — Invalid command
E11 — Invalid preset number
E12 — Invalid output number (too large)
E13 — Invalid value (out of range)
E14 — Illegal command for this configuration
E17 — Timeout (caused only by direct write of global presets)
E21 — Invalid room number
E24 — Privilege violation (Ethernet only. Personnel logged in as users attempting
operations requiring supervisors privileges. Users have access to all view and read
commands [other than the administrator password], and can create ties and
presets, and mute and unmute the output.)
]
Using the Command and Response Tables
The command and response table begins on page 25. Either uppercase or lower case
letters are acceptable in the command field. Symbols, defined starting below and used
throughout the table, represent variables in the command and response fields. Command
and response examples are shown throughout the table. The ASCII to Hex conversion table
below is for use with the command and response table.
23
